From Otic Induction to Hair Cell Production: Pax2 EGFP Cell Line Illuminates Key Stages of Development in Mouse Inner Ear Organoid Model

Mice

All mice were housed as per institutional standards and used according to experimental protocols approved by the University of Michigan Institutional Animal Care and Use Committee.

We used mice carrying the Pax2^EGFP allele, in which EGFP is inserted upstream of the Pax2 translational start site, and wild-type (WT) controls on the same genetic background [29]. Breeding cages with Pax2^EGFP/+ mice were set up to obtain embryos of all 3 genotypes; postnatal studies were performed only with WT and Pax2^EGFP/+ genotypes as the Pax2^EGFP/EGFP genotype is perinatal lethal due to renal agenesis [29]. Genotyping was performed using the following primers: EGFP-F (5′-CTCGTGACCACCCTGACCTA-3′) and EGFP-R (5′-GTCCATGCCGAGAGTGATCC-3′); WT-F (5′-ACCGTATTACCGCCATGCAT-3′) and WT-R (5′-ACCTCTACAAATGTGGTATGGCT-3′). Amplification with EGFP primers results in a 525-bp PCR product, and amplification with WT results in a 230-bp PCR product. Presence of the 525-bp product represents the Pax2^EGFP allele.

To prepare images of marker expression at roughly equivalent developmental stages in comparison with differentiating mESC aggregates, timed pregnant C57BL/6 mice at E11.5 and E15.5 were obtained from The Jackson Laboratory. Embryos were collected at E11.5 and E15.5, fixed in 4% paraformaldehyde (PFA), cryoprotected with sucrose, and cryosectioned in optimal cutting temperature compound (OCT) in transverse and parasagittal planes at 12 μm thickness. Staining of cryosections was performed according to the method described for mESC aggregates below.

Auditory brainstem response recording

Mice were anesthetized with 65–120 mg/kg ketamine and 7 mg/kg xylazine, with or without 2 mg/kg acepromazine, administered intraperitoneally before the procedure. Mice were then placed on a heating pad inside the recording booth. Electrodes were then attached at the vertex of the head, beneath the test ear, and beneath the contralateral ear. Acoustic stimuli consisting of 4 ms tone bursts with 1 ms rise and fall times were delivered from a speaker at 30 bursts per second via a tube placed just outside the ear canal. Auditory-evoked potentials were recorded at 3 tone frequencies: 8, 16, and 32 kHz. Data were acquired using the Tucker Davis Technologies System III, with up to 1,024 responses averaged for each stimulus. Recordings began at 80 dB sound pressure level, which was sufficient to elicit a response. Stimulus level was reduced systematically in 5–10 dB decrements. The minimum level eliciting a reproducible waveform was determined to be the response threshold. The recording system was routinely calibrated in a closed system using a reference microphone and lock-in amplifier.

Derivation of Pax2^EGFP mESCs

Blastocysts were flushed from the uterine horns of Pax2^EGFP/+ females 3.5 days after mating to Pax2^EGFP/+ males. Individual blastocysts were placed in wells of a 96-well culture plate seeded with irradiated mouse embryonic feeder (MEF) cells in Dulbecco's modified Eagle's medium (DMEM) (high glucose; Gibco) supplemented with 15% fetal bovine serum (FBS; Harlan), 0.1 mM β-mercaptoethanol (Sigma), 50 IU/mL penicillin and 50 μg/mL streptomycin (Gibco), 1,000 U/mL leukemia inhibitory factor (LIF; Chemicon), and 12.5 μM PD98059 (Sigma). Inner cell mass outgrowths were trypsinized and passaged sequentially until mESC lines were established in 35-mm cell culture dishes. For genotyping, mESCs were passaged on gelatin-coated dishes twice to eliminate feeder cells before being genotyped as described [29]. For expanding cultures, mESCs were maintained on irradiated MEF cells with media consisting of DMEM (Gibco), 15% FBS (Atlas Biologicals), 1× sodium pyruvate, 1× nonessential amino acids, 2× glutamax, and 0.1 mM β-mercaptoethanol (all from Gibco), and 1,000 U/mL LIF (ESGRO). Cells used in this study were frozen at passage 8, thawed, and expanded in feeder-free culture conditions before organoid formation.

mESC cultures

ESCs from the Pax2^EGFP/+ mouse line were used to generate organoids between passages 13 and 17. Pluripotency staining was performed at passages 10 and 21. Colonies were maintained in feeder-free conditions on a 0.1% gelatin substrate with maintenance medium consisting of DMEM (high glucose; Gibco), 10% FBS (Atlas Biologicals), 1.5 mM l-glutamine (Gibco), 5.4 mM HEPES (Gibco), 5.4 μM β-mercaptoethanol (Sigma), and 500 U/mL LIF (Gibco). At passage, colonies were dissociated to single cells using cell dissociation buffer (Gibco) with 0.5 M ethylenediaminetetraaceticacid solution (AccuGENE).

Differentiation protocol

Spherical aggregates of mESCs were differentiated according to the inner ear organoid protocol modified from Koehler et al. [3,4]. In brief, mESC colonies were dissociated to single cells and aggregated at 3,000 cells per well in round-bottomed 96-well Nunclon Sphera Microplates (Thermo Scientific) in 100 μL ectodermal differentiation medium. Medium consisted of Glasgow's minimum essential medium, 10% KnockOut serum replacement (KSR), 15 mM HEPES, 1× nonessential amino acids, 1 mM sodium pyruvate (all from Gibco), and 0.1 mM β-mercaptoethanol (Sigma). Y-27632 (Calbiochem) was included in the medium at 10 μM on day 0 only.

On day 1, half of the volume was replaced with medium containing growth factor-reduced (GFR) Matrigel (Corning) to achieve 2% final concentration. On day 3, 25 μL of medium containing SB431542 (1 μM; Stemgent) and BMP4 (10 ng/mL; Stemgent) was added to each well. On day 4.5, 25 μL of medium containing LDN193189 (1 μM; Stemgent) and FGF2 (0, 5, 25, or 100 ng/mL; Sigma) was added to each well. Aggregates were transferred into a new 96-well plate in 200 μL maturation medium containing 1% GFR Matrigel on day 8, with half of the medium exchanged daily for the remainder of the protocol. Maturation medium consisted of advanced DMEM/F12, 1× N-2 supplement, 15 mM HEPES, and 1 × glutamax (all from Gibco). CHIR99021 (3 μM; Stemcell Technologies) was optionally added on day 8 as noted.

Modifications to the Koehler et al. [4] protocol included use of 10% KSR in the ectodermal differentiation medium instead of 1.5%, our variation of FGF2 dose, and our use of nonenzymatic dissociation buffer for passaging and forming aggregates from mESCs.

Immunostaining

Aggregates were collected, fixed 20 min overnight in 4% PFA, and rinsed in phosphate-buffered saline (PBS) before further processing.

For staining of cryosections, fixed aggregates were cryoprotected via 30-min incubations with increasing concentrations of sucrose up to 30% in PBS. Following overnight incubation in 30% sucrose at 4°C, aggregates were incubated 4–5 h in a 1:1 mixture of 30% sucrose and OCT at room temperature, incubated 1 h in OCT, and frozen in cryomolds on dry ice. A Leica 3050S cryostat was used to section tissue at 10-μm thickness. Slides were dried overnight, rehydrated in PBS for 15 min, and then transferred to humid chambers for the remainder of the staining procedure. Sections were blocked and permeabilized 15 min with 10% normal donkey serum (NDS) and 0.1% Triton X-100. Primary antibodies were applied overnight at 4°C in a 1:1 mixture of blocking/permeabilization solution with PBS. Alexa Fluor secondary antibodies were applied at 1:500 in PBS for 1 h at room temperature with slides covered to prevent photobleaching. Nuclei were counterstained by 5-min incubation with Hoechst 33242. Coverslips were added with ProLong Gold Antifade Mountant (Molecular Probes). For a list of antibodies used, refer to Supplementary Table S1 (Supplementary Data are available online at www.liebertpub.com/scd). Control tissues stained without primary antibody were used to ensure that the Pax2^EGFP signal would not preclude use of green fluorophores.

For staining of whole-aggregate tissue, fixed aggregates were processed as described previously [3]. To prepare a custom imaging chamber, Sylgard 184 (1:10) prepared at ∼1-mm thickness was cut to fit glass slides, and a metal punch was used to create a well to hold ScaleA2 solution containing a stained aggregate. A coverslip was placed across the well, and the imaging chamber was sealed with clear nail polish.

For staining of isolated organoids, fixed aggregates were transferred to PBS for microdissection of the hair cell-containing regions. Minutien pins were used to stabilize aggregates against 35-mm dishes of Sylgard, while hair cell-containing cysts were dissected using iris scissors and fine forceps. The regions of protruding cysts distal to the aggregate bodies were cut open using scissors to expose the apical surfaces of hair cells, and the aggregate bodies were cut or teased away using scissors or forceps and discarded. The hair cell-containing epithelia were retained. Custom-made microwells were used to process single tissues in small solution volumes. Organoids were blocked and permeabilized in PBS with 5% NDS and 0.1% Triton X-100 for 15 min and incubated with primary antibodies in blocking/permeabilization solution overnight at 4°C. Alexa Fluor secondary antibodies (1:500) and phalloidin conjugates (1:100) were added in PBS for 1 h at room temperature, and Hoechst 33242 was applied for 5 min at 1:2,500 in PBS. Organoids were mounted using ProLong Gold.

For staining of mouse organs of Corti, 4-week-old WT and Pax2^EGFP/+ mice were decapitated under anesthesia (80 mg/kg ketamine and 20 mg/kg xylazine). Each temporal bone was removed and inner ear placed in 4% PFA. The cochlear duct was then perfused with 4% PFA by perforating the cochlear windows and apex. Following dissection, surface preparations of the apical turn were blocked and permeabilized in 5% NDS and 0.1% Triton X-100 in PBS for 1 h at room temperature and incubated with primary antibody overnight at 4°C. After extensive washes, the preparations were stained with Alexa Fluor secondary antibodies (1:500) and Alexa Fluor 488 phalloidin (1:200) for 2 h and counterstained by a 5-min application of Hoechst 33242 (1:2,500). After a final series of washes in PBS, preparations were mounted using ProLong Gold.

For pluripotency staining, colonies grown on gelatin-coated coverslips or in 6-well culture plates were washed with PBS and fixed with 4% PFA for 15 min. They were then blocked and permeabilized in PBS with 5%–10% NDS and 0.1% Triton X-100 for 15 min. Primary antibodies were diluted in PBS or a 1:1 mixture of blocking/permeabilization solution for incubation at 4°C overnight. Alexa Fluor secondary antibodies (1:500) were diluted in PBS for incubation at room temperature for 1–2 h. Hoechst 33242 was then applied for 5 min at 1:2500 in PBS.

Brightfield and epifluorescence images were obtained using Leica DM IL and Olympus BX51WI microscopes. Confocal images were obtained using Olympus FluoView 1000, Leica TCS SP5, and Leica TCS SP8 confocal microscopes.

FM 4-64FX labeling

For live imaging of FM 4-64FX dye labeling, a day 20 organoid (with distal portion of cyst removed to expose hair cells) was dissected away from the aggregate body, affixed to a collagen droplet in a 35-mm dish, and maintained through day 33. After dissection, the culture was maintained in serum-free medium consisting of 1× basal medium Eagle (Sigma), 2.2 g/L sodium bicarbonate, 1× insulin–transferrin–selenium–ethanolamine (Gibco), 1% bovine serum albumin, 5 mg/mL glucose, and 8.8 U/mL penicillin G (Sigma). A stock solution of 2 mM FM 4-64FX in distilled water was prepared and stored at −20°C. The 5 μM working solution was prepared immediately before use by 1:400 dilution with low-calcium Hank's balanced salt solution (LC-HBSS), prepared by adding 0.1 mM CaCl₂ to HBSS (Gibco) and filter sterilizing. The organoid tissue to be labeled was rinsed in LC-HBSS, incubated 10 s in FM 4-64FX working solution at room temperature, and washed 3 times with LC-HBSS for 1 min per wash. The time needed to add and remove the dye, taking care not to dislodge the tissue, and add the first wash totaled <30 s. Organoids were immediately imaged live in LC-HBSS.

Aminoglycoside treatment

Organoids were dissected and maintained on collagen droplets as described above. On day 33 of culture, gentamicin (Sigma) was applied to the media at 6 μM final concentration. After 72 h, organoids were fixed in 4% PFA for 30 min at room temperature and assayed for presence of stereocilia bundles via staining with rhodamine phalloidin (1:100; Thermo Fisher Scientific).

FGF assay

Solutions containing 1 μM LDN193189 and varying concentrations of FGF2 in ectodermal differentiation medium were prepared and added at day 4.5 of the differentiation protocol. After brief incubation at 37°C in a humidified culture incubator with 5% CO₂, aggregates were collected and rinsed twice with prechilled PBS with 1× Halt phosphatase inhibitor cocktail (phosphatase inhibitor [PI]; Thermo Scientific). Aggregates were lysed in RIPA lysis and extraction buffer (Thermo Scientific) with 1× PI. For lysis, aggregates were incubated 15 min on ice and sonicated on ice in three 10-s pulses at 50% power. Lysates were centrifuged at 14,000 g for 15 min and supernatants retained. Total protein concentration was assayed using the BCA Protein Assay Kit (Thermo Scientific).

Western blotting

Lysates were diluted 1:1 with 2× Laemmli buffer from Bio-Rad (1610737) and denatured at 95°C for 5 min. Bio-Rad Mini Protean TGX gels (4%–15%) were loaded with equal amounts of total protein per well. Molecular weight standards from Bio-Rad (1610317) and Cell Signaling Technology (7720) were used. Proteins were transferred to nitrocellulose membranes, and membranes were blocked with 5% nonfat dry milk in TBS +0.1% Tween (TBST) for 1 h. Primary antibody incubations were performed overnight in TBST at 4°C. Horseradish peroxidase-conjugated secondary antibody incubations were performed for 1 h in TBST at room temperature. For a list of antibodies used, refer to Supplementary Table S1. Enhanced chemiluminescent substrates included SuperSignal West Pico (Thermo Scientific) and Amersham ECL Select (GE Healthcare). Images were obtained using a FluorChem SP system (Alpha Innotech). Densitometry was performed using Fiji software (version 2.0) [30].

Vesicle and organoid quantification

The percentage of aggregates with at least 1 organoid, indicated by EGFP signal at the base of a protruding cyst, was quantified at day 20. The percentage of aggregates with at least 1 visible EGFP⁺ otic vesicle-like structure was estimated at day 12 using epifluorescence. This analysis excluded vesicles not yet formed at day 12 or not visible due to orientation away from the camera. Therefore, since all organoids arose from vesicles, quantifying the percentage of aggregates with vesicles identified at day 12 or organoids at day 20 (referred to as “% vesicle- or organoid-positive”) more accurately reflected the total number of vesicle-positive aggregates. Note that this percentage does not double-count aggregates in which both structures were identified.

Aggregate size measurements

Average long-axis diameter of 4 aggregates per time point was measured from brightfield images in Fiji software (version 2.0) [30]. Data were averaged across multiple cultures and plotted to track changes in aggregate size over time.

Statistical analysis

Statistical comparisons between 2 groups were performed using unpaired t-tests in Microsoft Excel. Comparisons among more than 2 groups were performed by one-way analysis of variance with Tukey's post-hoc test using the XLSTAT plug-in.

Pax2^EGFP/+ mice develop normal inner ears

To develop a reporter system for monitoring otic induction during inner ear organoid formation, we derived mESCs from mice encoding EGFP between 5′ regulatory elements and the endogenous Pax2 transcription start site in 1 allele (Fig. 1A). Mice with a single copy of the allele (Pax2^EGFP/+) develop normal kidneys and midbrain/hindbrain tissues [29]. Moreover, they appear to form normal otic vesicles, with EGFP in the ventromedial domain where Pax2 is expressed (Fig. 1B–D′) [22], as do the majority of mouse lines carrying Pax2 loss-of-function alleles [29,31 –33]. No apparent difference was seen in the gross morphology of cochlear and vestibular structures in Pax2^EGFP/+ mice compared to WT animals (data not shown).

OPEN IN VIEWER

FIG. 1.

Features of Pax2^EGFP reporter system and characterization of Pax2^EGFP/+ mice and WT controls at 4 weeks postnatal. (A) Schematic for creating the Pax2^EGFP allele, adapted from Soofi et al. [29]. BamHI-NotI and Not-NcoI arms homologous to 5′ Pax2 sequence were ligated with an EGFP-PGK-Neo construct. This resulted in insertion of EGFP-PGK-Neo just upstream of the translation start site. Clones resistant to neomycin were obtained. Mice expressing this sequence were crossed with flippase mice, removing the PGK-Neo fragment and resulting in Pax2^EGFP/+ mice. Both Pax2^EGFP/+ and Pax2^EGFP/EGFP mESC lines were then derived. (B) Epifluorescence image of Pax2^EGFP/EGFP (left) and Pax2^EGFP/+ (right) embryos at E10.5. EGFP expression marks Pax2⁺ tissues, including otic vesicles. (C, C′) Lateral close-up view of Pax2^EGFP/+ embryo at E10.5. Box in (B) marks the region shown in (C, C′). (D, D′) Isolated otic vesicle from Pax2^EGFP/+ embryo. (E–F′) Immunofluorescence staining of organ of Corti surface preparations from Pax2^EGFP/+ and WT mice. Midapical regions are shown. In both genotypes, stereocilia bundles rich in F-actin and cell bodies expressing Myo7a were present in the typical pattern: 1 row of inner hair cells and 3 rows of outer hair cells. Equivalent staining of neuronal projections marked by Tuj1 in Pax2^EGFP/+ and WT tissues suggested normal innervation as well. (G) Thresholds for auditory-evoked potentials measured by auditory brainstem response testing of WT (dark bars) and Pax2^EGFP/+ (light bars) mice. No significant difference in sound response was found at any of the 3 frequencies presented (unpaired t-test, P > 0.5, n = 4 mice per genotype; mean ± standard deviation). Scale bars: 1 mm (B), 200 μm (C, C′), 100 μm (D, D′), 50 μm (E–F′). WT, wild type; mESC, mouse embryonic stem cell.

To investigate more closely, we stained whole-mount preparations of the organ of Corti from adult Pax2^EGFP/+ and WT littermates for markers of hair cells and neurons. Staining for myosin VIIa (Myo7a), an unconventional myosin characteristic of hair cells, and phalloidin labeling of F-actin-rich hair bundles revealed the characteristic pattern of 3 rows of outer hair cells and 1 row of inner hair cells in both WT and Pax2^EGFP/+ mice (Fig. 1E–F′). Tuj1 staining revealed robust peripheral projections extending toward the hair cells, with some continuing past the inner hair cells and into the outer hair cell region. In 1 of 3 Pax2^EGFP/+ embryos, we detected an aberrant pattern of innervation. Instead of extending radially toward the outer hair cells, multiple neurites traversed the tunnel of Corti at acute angles, occasionally parallel to the curvature of the organ of Corti.

Auditory brainstem response (ABR) testing was performed on postnatal mice at 4 weeks of age to measure thresholds for response to auditory stimuli. Three frequencies, processed by different regions of the mouse cochlea, were presented: 8, 16, and 32 kHz. Average thresholds from WT and Pax2^EGFP/+ mice were not significantly different at any frequency (unpaired t-test, P > 0.5, n = 4 mice per genotype) (Fig. 1G).

Overall, our investigation of Pax2^EGFP/+ mice revealed normal auditory and vestibular function based on ABR testing for auditory-evoked potentials and absence of behavioral signs of vestibular dysfunction (eg, circling, head bobbing, or torticollis). The Pax2^EGFP allele, therefore, reports a normal pattern of Pax2 expression and permits development of the inner ear from the otic vesicle to mature auditory and vestibular organs in heterozygotes. This supports the use of Pax2^EGFP/+ ESCs to produce inner ear organoids.

Pax2^EGFP/+ mESCs form inner ear organoids

Clonal mESCs were obtained from Pax2^EGFP/+ blastocysts (clone C5, Fig. 2A). We transitioned these cells from MEF dependence to feeder-free maintenance on gelatin. At passage 10, Pax2^EGFP/+ cells were screened for the pluripotency marker Oct3/4, which was uniformly expressed throughout colonies (Fig. 2B–B′′′). To assay maintenance of pluripotency, cells were stained at passage 21 for a panel of pluripotency markers (Fig. 2C–E′′′). Oct3/4, Sox2, and Rex1 were uniformly expressed, but Klf4 and Nanog were variable with regard to staining intensity and the percentage of positive cells, suggesting that some cells in these populations may be switching between naive and epiblast-like states.

OPEN IN VIEWER

FIG. 2.

Establishment of Pax2^EGFP/+ mESC line. (A) Genotyping mESC lines at the Pax2 locus. Blastocysts from a Pax2^EGFP/+ heterozygous cross were cultured in embryonic stem cell media and clonally isolated. DNA from individual clones were analyzed for the WT Pax2 allele. PCR and primer pairs were as described previously [29]. The cells used in this study were from clone C5. (B–B′′′) Brightfield and epifluorescence images of Pax2^EGFP/+ mESC colonies stained at passage 10. Oct3/4 staining throughout colonies supports characterization as pluripotent, undifferentiated stem cells. (C–E′′′) Epifluorescence images of Pax2^EGFP/+ mESC colonies stained at passage 21 to assay maintenance of pluripotency. Note uniform expression of Oct3/4, Sox2, and Rex1 in (D′′, E′′, E′′′) but variable expression of Klf4 and Nanog in (C′′, C′′′, D′′′). Scale bars: 100 μm (B–E′′′).

Pax2^EGFP/+ cells at passages 13–17 were evaluated for capacity to generate inner ear organoids (Fig. 3A). At day 0, mESC aggregates were formed, and their size expansion was tracked over the course of the protocol (Fig. 3B and Supplementary Fig. S1). When 1.5% KSR was included in the ectodermal differentiation medium as per the original protocol, aggregates expanded at a slower rate than expected and never reached the 1.5–2 mm diameter by day 12 described by Koehler and Hashino [3]. When 10% KSR was used, aggregates began at an average diameter of 320.3 ± 21.6 μm (n = 21) at day 1 and expanded to 1054.3 ± 36.0 μm by day 8 (n = 11) after 100 ng/mL FGF2 was applied at day 4.5. By day 20, aggregates treated in this way reached a final diameter of 1449.9 ± 81.7 μm (n = 6). The final diameter of aggregates treated with 25 ng/mL FGF2 at day 4.5 (n = 5) was not significantly different (P = 0.201). In addition, the inclusion of the Wnt signaling agonist CHIR99021 during early maturation did not appear to affect aggregate size. For all experiments going forward, the ectodermal differentiation medium contained 10% KSR, a departure from the original inner ear organoid protocol, which may reflect a unique requirement of this cell line.

OPEN IN VIEWER

FIG. 3.

Process of forming Pax2^EGFP/+ organoids. (A) Timeline of inner ear organoid formation. Additions of growth factor-reduced Matrigel and exogenous patterning molecules are indicated as well as milestones for successful cultures. Differentiation is guided via exogenous factors at day 3 and day 4.5; otherwise, organoid formation occurs through self-patterning. After the transfer of aggregates from ectodermal differentiation medium to maturation medium at day 8, 50% of medium is exchanged every other day, so the percentage of Matrigel becomes progressively dilute over time. The Wnt pathway agonist CHIR99021 (a GSK3β inhibitor) promotes formation of preorganoid, otic vesicle-like structures when applied between days 8 and 10 [34]. It was not necessary for our cell line, however, and was not included in our cultures unless noted. (B–M) Progression of aggregates through inner ear organoid protocol. (B–F) and (L–M) exemplify aggregates treated with 25 ng/mL FGF2 at day 4.5 and without CHIR99021 at day 8. The aggregate in (G) was treated with 100 ng/mL FGF2 at day 4.5 and without CHIR99021 at day 8. (H–K) Exemplify aggregates treated with 100 ng/mL FGF2 at day 4.5 and with CHIR99021 at day 8. (B, C) Aggregates expand to over twice their original size and develop ruffled edges by day 4.5. (D–F) Cryosectioning and immunofluorescence staining at days 5–6 reveal an outer layer expressing markers of non-neural ectoderm, E-cadherin (ECAD) and Tfap2a (AP2), and excluding markers of mesendoderm, Brachyury and N-cadherin (NCAD). (G, H) Epifluorescence images of representative vesicle-positive aggregates at day 12. The Pax2^EGFP allele permits observation and tracking of vesicles as they form early during the maturation phase and later migrate and expand into organoid-containing cysts protruding from the surface. (I, J) Adjacent cryosections stained for preplacodal markers Six1 and Eya1 or otic placodal markers Pax2 and Pax8. Pax2 signal is concentrated at vesicles, in accordance with epifluorescence imaging. Vesicles were also positive for Six1 and Eya1. Pax8 was not detected. (L, M) Brightfield and epifluorescence images of a representative organoid-positive aggregate at day 20. Pax2^EGFP expression indicates the location of hair cells at the organoid region bordering the protruding cyst and the body of the aggregate. Note also the presence of a vesicle that did not expand and protrude, marked with an arrow. Scale bars: 200 μm (D–H, L, M), 100 μm (B, C, I, J), 50 μm (K). FGF, fibroblast growth factor.

Guided differentiation along the otic lineage was assessed via immunofluorescence staining of cryosections. Following treatment with BMP4 and an inhibitor of TGFβ signaling SB431542 (B/S) at day 3 to encourage differentiation of non-neural ectoderm and reduce mesoderm and endoderm, the aggregates formed a layer positive for E-cadherin (ECAD) and Tfap2a (AP2) (Fig. 3C–F). This layer, detected at day 5–6, excluded staining for brachyury and N-cadherin (NCAD), markers of mesendoderm and neural ectoderm, respectively.

The addition of FGF2 and an inhibitor of BMP signaling LDN193189 (F/L) at day 4.5 guided non-neural ectoderm toward preplacodal and, specifically, otic placodal fate. By day 12, otic vesicle-like structures were easily visualized due to the upregulation of EGFP driven by the Pax2 promoter (Fig. 3G, H). In trials of 1.5% KSR, we observed markedly weaker EGFP epifluorescence than in trials of 10% KSR (not shown). In 10% KSR trials, EGFP signal increased gradually throughout the aggregates beginning on day 9 but was brighter in the vesicles compared to surrounding tissue. Staining for Pax2 confirmed the uniform expression of Pax2 in vesicle epithelia as well as scattered expression throughout the aggregates, whereas Pax8 expression was absent at this same time point (Fig. 3I). Preplacodal markers Eya1 and Six1 were detected at the vesicle epithelia at day 12 (Fig. 3J, K). Inclusion of CHIR99021 early in the maturation phase (days 8–10) appeared to increase the size and number of vesicles at day 12 (Fig. 3H) [34]; however, this condition was not necessary for vesicle formation using Pax2^EGFP/+ cells and was not included unless otherwise noted.

Aggregates were observed via epifluorescence microscopy until day 20, by which time the progressive expansion of vesicles into protruding cysts described by Koehler et al. was replicated in our cultures (Fig. 3L, M) [4]. The EGFP signal became concentrated at the base of each protrusion, bordering the aggregate body, marking the “organoid” region where hair cells were expected. Overall, the Pax2^EGFP/+ mESC aggregates cultured with 10% KSR met major checkpoints for otic differentiation and reported on formation of Pax2⁺ vesicles and organoids.

Otic induction during organoid protocol supports FGF-ERK-Pax2 mechanism

FGF signaling is a necessary step in the adoption of inner ear fate. Therefore, we investigated whether a relationship existed between FGF2 dose and the efficiency of organoid production. Using a range of FGF2 doses (0, 5, 25, and 100 ng/mL) at day 4.5, we maintained cultures through day 20 and quantified the percentage of aggregates featuring at least 1 organoid as defined by an EGFP⁺ border region at the base of a protruding cyst. A clear pattern of dose dependency was observed: FGF2 was required for organoid formation, and increasing doses resulted in more aggregates forming organoids (Fig. 4A–A′′). The efficiency of vesicle production also corresponded with FGF2 dose, as expected, based on our finding that all organoids arose from EGFP⁺ vesicles (Fig. 4A′, B). Using 25 ng/mL FGF2 resulted in a similar percentage of organoid-positive aggregates (24.1% ± 10.0) compared to the 10%–20% reported previously [3]. The maximum dose tested, 100 ng/mL, resulted in an even higher percentage of organoid-positive aggregates (41.8% ± 19.8) (Fig. 4B).

OPEN IN VIEWER

FIG. 4.

Evidence of ERK mediating FGF-driven otic induction in mouse organoid model. (A) Quantification of aggregates with EGFP⁺ organoid regions at the bases of protruding cysts at day 20. The percentage with organoids increased with higher doses of FGF2. (A′) Quantification of aggregates with EGFP⁺ vesicles estimated via observation of live aggregates by epifluorescence. (A′′) Quantification of aggregates positive either for vesicles at day 12 or organoids at day 20. In (A–A′′), N indicates the number of cultures examined, and the data represent mean ± standard deviation (*P < 0.05). (B) Schematic illustrating percentage of original aggregates progressing to vesicle or organoid stages. Note that the vesicle-positive percentage is taken from Fig. 5A′′, since all organoid-positive aggregates progress through an intermediate, vesicle-positive stage. (C) Western blotting for phosphorylated ERK (pERK), total ERK (tERK), and actin. The proportion of phosphorylated-to-total ERK (pERK/tERK) increased with higher doses of FGF2. Fold change in pERK/tERK relative to 0 ng/mL FGF2 baseline is quantified (unpaired t-test, *P < 0.05; mean ± standard deviation).

FGF receptors signal through multiple downstream pathways, including those mediated by ERK, AKT, and PLCγ. Recent reports have demonstrated the necessity of ERK as a mediator of otic induction in chickens and zebrafish [27,28]. Furthermore, the zebrafish study provided evidence that ERK is needed for hair cell development, whereas AKT is involved in otic neurogenesis. Given the correlation between vesicle formation and FGF2 dose, we decided to investigate whether ERK activation would demonstrate the same relationship. We hypothesized that the process of otic induction in organoids would replicate the in vivo developmental mechanism, supporting the use of inner ear organoids as a model to study signaling mechanisms involved in early mammalian otic development.

To examine the activation of ERK downstream of FGF2, aggregates were harvested at 1 h after application of LDN193189 and varying doses of FGF2 (0, 5, 25, and 100 ng/mL) at day 4.5. Lysates were prepared and screened for the activated, phosphorylated form of ERK (pERK). ERK phosphorylation increased in an FGF2 dose-dependent manner (Fig. 4C). Interestingly, the strongest ERK activation was induced by 100 ng/mL FGF2, a 4-fold higher dose than prescribed by the original organoid protocol [3,4]. These data reveal correlations between FGF2 and both organoid production and ERK phosphorylation, in agreement with developmental literature on otic induction [27,28].

Pax2^EGFP/+ organoids model several features of developing ear

Organoids were screened for Myo7a⁺ cells with F-actin⁺ apical structures, indicative of hair cells with stereocilia bundles. Myo7a⁺/Pax2⁺ cells were found in the organoid regions where EGFP was observed (Fig. 5A). Cryosectioning revealed the presence of internal organoids containing Myo7a⁺ hair cells arrayed in an epithelial layer with F-actin⁺ stereocilia-like bundles oriented inward toward the central lumen of each cyst (Fig. 5B, B′). Protruding organoids were dissected and stained as isolated surface preparations. Imaging the apical face of the preparation revealed a variety of bundle morphologies, with some splayed and some tightly bundled stereocilia (Fig. 5C). A network of thick F-actin-rich belts similar to those formed by supporting cells in vivo invariably marked the organoid regions where hair cells were found; this distinctive feature served as a useful marker by which to screen tissues for hair cells efficiently.

OPEN IN VIEWER

FIG. 5.

Characterization of Pax2⁺ inner ear organoids. (A) Confocal z-projection showing whole-mount immunofluorescence of an aggregate at day 20. Note that Myo7a⁺/Pax2⁺ cells are found at the border between the aggregate (dashed line) and the protrusion (solid line). Following fixation and staining of tissues, the native EGFP signal was no longer observed, so fluorophores emitting green light could be used. (B) Myo7a⁺ cells with F-actin-rich bundles arranged in an epithelial layer shown via both cryosection and dissected organoid preparation staining. (B′) Vestibular hair cells stained for Myo7a and F-actin in E15.5 C57BL/6 control mouse embryo. (C) Surface preparation of isolated organoid demonstrating variety of bundle morphologies. Vestibular-like bundles are shown in insets at higher magnification. (D) Confocal image showing whole-mount immunofluorescence for Sox2⁺ cells reveals a supporting cell layer immediately below Myo7a⁺ hair cells. Because the hair cells are also Sox2⁺, they are evidently immature [35,36]. (D′) Vestibular hair cells and supporting cells in a C57BL/6 control embryo also express Myo7a and Sox2 at E15.5. (E) Each stereocilia bundle in an organoid contains a single cilium positive for acetylated tubulin, reflecting a vestibular or immature cochlear phenotype. (F) FM4-64FX dye, applied for 10 s before washout, is rapidly taken up by hair cells, presumably through mechanotransduction channels. Note the flask shape suggestive of type I vestibular hair cells [68]. Scale bars: 100 μm (A), 50 μm (B, B′, D, D′), 20 μm (C), 10 μm (E). FGF2 doses: 25 ng/mL (C, F), 100 ng/mL (A, B′, D, E).

We screened for additional characteristics of auditory and vestibular organs to demonstrate the suitability of the Pax2^EGFP/+ cell line for inner ear organoid formation. The organoid hair cells were lined basally by a layer of Sox2⁺ cells similar to supporting cells of the inner ear. The hair cells themselves were positive for Sox2 as well (Fig. 5D). This may be evidence of arrest at an immature stage as Sox2 is downregulated in auditory hair cells of neonatal mice [35,36]. Alternatively, it may point to a vestibular phenotype as particular vestibular hair cells express Sox2 into adulthood [37]. The presence of a single kinocilium, marked by expression of acetylated tubulin (AceTub), at each apical bundle supports characterization as either vestibular or immature auditory hair cells (Fig. 5E).

To test for functional mechanotransduction channels, we applied the styryl dye FM4-64FX to an organoid that had been dissected at day 20 and cultured until day 33 adhered to a collagen droplet. Following 10-s application, the dye was washed out, and the organoid was imaged live. Positive labeling indicative of hair cells was observed (Fig. 5F). Because the dye application was brief, entry presumably occurred through functional mechanotransduction channels rather than via endocytosis or uptake through other large pores such as those from P2X receptors [38].

To test for susceptibility to aminoglycoside-induced ototoxicity, additional organoids cultured on collagen to day 33 were treated with 6 μM gentamicin for 72 h. Rhodamine phalloidin was used to screen for stereocilia bundles. Bundles were present in 3 out of 4 organoids in both treated and untreated conditions, indicating that the hair cells were not severely affected by aminoglycoside treatment (not shown).

Vesicle-associated neurons model features of embryonic inner ear neurogenesis

The incidence of neurons in inner ear organoids has been reported [4]. This prompted us to further investigate the source and synaptogenic potential of these neurons. We first examined whether the neurons in our organoids arose from neuroblasts associated with vesicles at day 12. Staining revealed cells expressing islet-1/2 (Isl1/2) immediately adjacent to vesicles positive for Pax2 (Fig. 6A). This pattern closely resembled Isl1/2⁺/Sox2⁺ neuroblasts delaminating from otocysts in C57BL/6 mouse control tissue at E11.5 (Fig. 6A′, A′′) [39,40].

OPEN IN VIEWER

FIG. 6.

Comparison of immunofluorescence staining for Isl1 and SHH in day 12 aggregates and E11.5 embryos and evidence of organoid synapses. (A–A′′) Pax2 is enriched in otic vesicle of day 12 aggregate (treated with 100 ng/mL FGF2 at day 4.5 and 3 μM CHIR99021 at day 8) and E11.5 C57BL6 mouse embryo relative to surrounding tissue. Isl1/2⁺ cells are found adjacent to the vesicles in both tissues, suggesting a process of delamination in aggregates similar to cvg formation in embryos. (B) SHH staining is localized to specific sources in E11.5 control embryo at the level of the otic vesicle: the ventral neural tube (large arrowhead) and notochord (small arrowhead). In (A, B), the otic vesicle is marked by a dashed line, the neural tube is marked by a dotted line, and neuroblasts or putative neuroblasts are marked by arrows. (C) Dissected organoid preparation with neurons clustered near hair cells. Tuj1⁺ projections traverse through the hair cell region. (D) Presynaptic Ctbp2 and postsynaptic GluA2 puncta are directly apposed at the base of hair cells. (E, F) Some projections appear to terminate at hair cells, forming bouton endings [arrowhead in (E)] or calyceal endings [the latter suggesting type I vestibular phenotype, asterisks in (F)]. Others continue past the hair cells, in some cases appearing to form en passant synapses [arrow in (E)]. Scale bars: 100 μm (A, B), 20 μm (C), 10 μm (E). CHIR99021 treatment was included in (D, E). FGF2 dose: 100 ng/mL (C–F). SHH, sonic hedgehog.

In development, SHH signaling extrinsic to otic tissue impacts the specification of cochleovestibular ganglion (cvg) neuroblasts indirectly through neurogenin 1, and SHH signaling intrinsic to otic tissue is necessary for cvg neuroblast proliferation and survival [41]. Given these relationships between SHH and inner ear neurogenesis, we therefore examined SHH expression in our day 12 aggregates through immunofluorescence staining. SHH signal was faint and nonspecific (not shown). In contrast, SHH is readily detected at the ventral neural tube and notochord in E11.5 mice (Fig. 6B).

Whether or not organoid-associated neurons are specified by SHH, their ability to form synaptic contacts with hair cells is important to evaluate as this could be exploited in disease modeling or regeneration studies. Tuj1⁺ neurons were found in clusters near regions of Myo7a⁺ hair cells within the isolated day 30 organoids (Fig. 6C). These cells extended projections traversing the hair cell epithelia. Furthermore, these cells formed putative synaptic connections on hair cells as indicated by the colocalization of the presynaptic marker Ctbp2 and postsynaptic marker GluA2 in puncta at the basal aspect of hair cells (Fig. 6D). This direct apposition of presynaptic and postsynaptic markers mimics the one-to-one pairing of these markers in the mature inner ear [42,43].

To characterize the interaction between neurons and hair cells in our organoids, we stained for neurofilament and Tuj1 and found projections with terminal boutons and calyces as well as en passant synapses (Fig. 6E, F). Altogether, these results support the potential use of inner ear organoids as a model not only of hair cell development but also inner ear neurogenesis.

Tracking protocol efficiency is necessary for optimization

As mentioned, the adaptability of the inner ear organoid protocol to several distinct cell lines has been demonstrated. DeJonge et al. optimized FGF2/LDN193189 treatment timing for each cell line within a window of just 6 h [34]. This showed that careful consideration of the relative efficiencies of different cell lines is crucial. Our experience suggested that cultures vary in efficiency not only with parameters defined by the protocol (eg, timing or dose of drug treatments) but also with additional parameters yet to be elucidated. We found that mESC passage number, reagent lots, and seasonal environmental fluctuations may influence outcomes. In addition, the reliance on Matrigel, an animal-derived product that varies unpredictably in composition from lot to lot, is not ideal, although no reliable alternative has been established.

The data presented in this study were produced during a single period of cultures meeting criteria for “success” in generating otic cultures. At least 10% of aggregates were vesicle positive, with some expanding into large, protruding cysts. During that time, nonotic cultures (lacking one or both criteria for success) corresponded to higher mESC passage numbers. It is important to note that subsequently, without changing materials or methods, our success rate dropped suddenly and without relationship to passage number for a prolonged interval. In contrast, hair cells were reliably identified in the organoid region at the base of each protruding cyst in our previous and subsequent cultures.

We present a summary of our culture attempts categorized by major variations to the original protocol tested (Supplementary Fig. S2) as well as a strategy we recommend for adopting the inner ear organoid protocol (Table 1). The summary corresponds to our trials with Pax2^EGFP/+ cells only, although we tested other cell lines (R1, R1/E, and E14Tg2a). As noted, our Pax2^EGFP/+ cell line required 10% KSR in the ectodermal differentiation medium. During the period when our cultures were consistently producing organoids, we performed drug treatments within ±3 h from the timing prescribed by the original protocol with no adverse effects. The combinations of additional variables predicted to influence the success of inner ear organoid cultures are myriad; this presents a challenge even when using cell lines known to be amenable to the protocol.

The collective understanding of stem cell differentiation and pluripotency is still evolving, despite the fact that mESCs were first derived several decades ago [60,61]. Naive and primed states of pluripotency have recently been distinguished, and pharmacological means of reverting primed cells to a naive state are being discovered [62 –64]. Although our outcomes did not correlate with passage number, maintenance of naive pluripotency is a key consideration for stem cell cultures. Interestingly, human ESCs are more comparable to mouse epiblast stem cells (primed) than to mESCs (naive), perhaps underlying the modifications that have been necessary to adapt mouse organoid protocols for human cells [44,65,66]. As our study demonstrated, the influence of cells surrounding target tissue in three-dimensional stem cell culture paradigms—in terms of both secreted factors and physical cues—is relatively uncharacterized. In addition, the possibility that selecting for reporter cells may bias outcomes toward higher efficiency has been suggested in retinal organoid literature [67]. Until we gain control over pluripotency states, environmental cues, and distinctions between cell lines, these remain necessary caveats for organoid researchers.

Efforts to understand, refine, and apply inner ear organoid technology are still in early stages. However, the potential value of reporter lines able to recapitulate endogenous expression patterns and restore function in vivo cannot be overstated. The many parallels between the Pax2^EGFP/+ organoids and true organs of hearing and balance are a strong impetus for continued investment in what may be a highly lucrative area of research.
