Facility Design and Health Management Program at the Sinnhuber Aquatic Research Laboratory

Keeping the water on

Water availability and quality are paramount, and thus, they impact nearly every aspect of husbandry facility design. For example, at the SARL, we have found that redundancy in every critical component of water purification and delivery, or at least an onsite replacement, is an essential operating practice. Specialty, components that are difficult to quickly replace should be designed and built redundantly into the system, because they can and will fail at the worst possible time. Simple, but often overlooked considerations are can a component be bypassed for some period? If so, for how long? Is appropriate valving designed into the system to allow easy bypassing for replacement or maintenance? The apparent costs of system redundancy and careful design are high, but compared to the potential for negative impacts to colony health, lost or diminished productivity during the ensuing recovery period, and the enormous stress and cost of dealing with emergency heavy repairs, these costs are nearly insignificant.

Incoming water and processing systems

High-quality groundwater is the starting point for the SARL system water. Three groundwater pumps are available depending on need and serviceability. Dechlorination is not required for this source, as it would be with a municipal water supply, resulting in reduced water processing cost. Fish health protection is also enhanced by removing the potential for dechlorination equipment failure. Groundwater runs through an aeration/degassing column and is held in an outdoor cistern. Influent groundwater receives pretreatment before being delivered to the recirculating life support systems (RLSS).

System pressure is boosted to 35 psi and particulate filtration (100 μm) is employed using a self-cleaning screen filter. Afterward, the water undergoes ultraviolet sterilization to reduce threats from biological entities. This unit has been customized to include UV TOC (185 nm) bulbs to also degrade organic chemicals that might be present. This u.v. unit was repurposed from a system with higher throughput, delivering ∼480,000 μw·s/cm². Pretreated water is then sent to the recirculating fish support systems.

Recirculating systems water

Water additions to the RLSS are further filtered utilizing a reverse osmosis filtration system followed by activated carbon filtration and a 1-μm particulate filter, before delivery to the supply water holding tanks in each of the two RLSS units. The components of RLSS units are familiar to the aquatic research community, but a brief overview is provided. An overview of the SARL water flow system is included as Supplementary Figure S1 (Supplementary Data are available online at www.liebertpub.com/zeb). Both of our RLSS units were provided by Aquaneering, Inc. (San Diego, CA).

Each RLSS unit has a clean and dirty water treatment loop facilitated by a semisegregated sump. The clean loop water is drawn from the dirty loop discharge side of the sump, particulate filtered to 50 μm using a multiple bag filter manifold, and UV filtered (40,000 μw·s/cm² uvc irradiance older system, 80,000 μw·s/cm² uvc irradiance newer system) before delivery to fish tanks. The dirty loop water is drawn from the tank drain return side of the sump, particulate filtered using a propeller bead filter, and biologically filtered using a fluidized bed filter.

We have implemented an additional side-stream activated carbon filtration loop in our RLSS units. This includes a small pump and granular activated carbon filter with its own plumbing. This filtration loop removes organic chemicals introduced by the mechanical system, plumbing, the fish, or the diet. The RLSS unit water parameters are computer monitored and logged. Programmable logic controllers are used to drive chemical pumps to maintain conductivity and pH levels. The monitoring system sends an alarm if parameters exceed limits and immediately contacts personnel through phone, text, and e-mail.

Iterative system for water supply to quarantine

SARL has three walk-in environmental chambers with quarantine racks. Because there can be no water return from quarantine to the SPF system, quarantine water is single pass and iterative to eliminate pathogens or research chemicals into the facility waste stream. Quarantine supply water comes from the filtered water pressure line from one of the RLSS utilizing an electric switch timer and an electronic ball valve. An iterative water delivery schedule is developed to maintain at least three water changes per day divided evenly over a 24-h period. Influent water is delivered to the three quarantine rooms in parallel, with no water being shared from one quarantine room to another, before being disposed. When necessary, effluent water can be filtered using particulate and chemical means for hazardous waste disposal.

Quarantine design and biosecurity

A well-designed quarantine facility is vital to the success of SPF maintenance, regardless of species, and for the SARL is a critical line of defense against disease infiltration. Complete isolation, spatially and through workflow, of quarantine and the SPF colony is essential. A dedicated staff member is charged with daily husbandry and line propagation responsibilities. Any person entering and interacting with quarantine water or fish is not allowed into the SPF space for the remainder of the day. Entry into the quarantine space requires the use of gloves, shoe covers, and full-length gowns to minimize potential spread of organisms into the common areas of the facility. Fish food for each isolation chamber is dispensed into separate disposable containers.

Additional separation levels within quarantine can also be a valuable tool to achieve a more thorough level of testing to prevent disease transmission when importing fish. For example, the SARL quarantine space consists of three fully self-contained isolation chambers, (1) RED—new acquisition, unknown status but assumed Microsporidia carrier, (2) YELLOW—Microsporidia detectable, status known, (3) GREEN—final round of screening indicates no Microsporidia, fish can transition to SPF facility. Each chamber has a fish rack, benchtop, sink, and climate control and ventilation and dedicated supplies. These levels within quarantine, combined with a countercurrent workflow, reduce recontamination of fish, speeding up the overall progress of new acquisitions to SPF status.

SPF design and biosecurity

We have invested substantially to establish and maintain the SPF status of the SARL, and aggressive facility access controls are used to protect it. Many facilities allow full researcher access to the main fish rooms to help increase research productivity and to allow researchers to gain experience in husbandry and fish handling. We have taken the opposite approach and have implemented a closed core facility. Entry into the fish rooms is limited to only facility staff and select researchers who have undergone extensive training on the methods needed to adhere to all aspects of the SPF biosecurity plan.

Dedicated shoes for all long-term staff and shoe covers for all visitors are required for entry into the fish rooms and SPF space. Sticky mats are at the main entry where shoe changes occur. All persons entering the facility must immediately wash their hands with Sporicidin Antimicrobial Lotion Soap (Contec, Inc., Spartanburg, SC) at a dedicated hands free wash station. Only new and unopened disposables may be brought into the facility. Any equipment or supplies that have come in contact with other aquatic species are not allowed in the SPF fish facility. All persons having come into casual contact with another aquatic colony (aquarium, tour, etc.) are not allowed in the fish rooms for at least 24 h, and anyone coming in contact with the fish or water systems is not allowed regular contact with other aquatic colonies.

Because of the closed core status, facility staff are responsible for all husbandry, line maintenance, spawning, and genotyping needs within the facility. Researchers submit requests for embryos, adult fish, or other special services such as fin clipping. Embryos, fish, or samples are transferred to an incubator in a neutral area for pick up and use. All fish or embryos leaving the SPF area must be classified as having a terminal endpoint, as fish are never allowed back into the SPF facility after leaving. All experiments that must remain within the SPF space are executed in a collaborative manner between the researcher and facility staff to ensure that biosecurity is maintained. Placing limitations on who comes into contact with the colony allows for substantially better control over biosecurity and ultimately creates a more stable SPF research environment.

Quarantine testing and import procedures

The multistage quarantine scheme at the SARL isolates animals by import status and generation, and provides dedicated husbandry workspace for health assessment and decontamination before introduction into the SPF facility. As mentioned, newly imported lines are housed in the RED quarantine chamber and visually monitored for signs of illness or parasitic infection before spawning. The majority of imported lines arrive as embryos; therefore, they are visually monitored until they reach sexual maturity at ∼3 months of age. Imported adults would be monitored for ∼4 weeks before spawning.

Once spawned, embryos are surface sanitized using methods previously described ² and moved to the YELLOW quarantine chamber 2. All contributing parents are kept in RED for secondary testing while the offspring are raised until 15 days postfertilization (dpf) and a portion of the population ¹ is sacrificed for analysis in-house through polymerase chain reaction (PCR) for the presence of Pseudoloma neurophilia. Whole larval fish are pooled in groups (n = 10 per sample), and DNA is extracted as templates for PCR. If larval fish are negative for the pathogens, the remainder of that population is isolated until all contributing parents are tested. Contributing parents are euthanized, frozen, and shipped overnight for diagnostic testing (IDEXX Bioresearch, Colombia, MO). All animals are tested through PCR for P. neurophilia as well as Mycobacterium species: Mycobacterium abscessus, Mycobacterium chelonae, Mycobacterium fortuitum, Mycobacterium haemophilum, Mycobacterium marinum, and Mycobacterium peregrinum.

If all parent animals are negative for pathogens, the remaining larval animals in isolation can be transferred to SPF rooms within the facility. In the event that the offspring test positive for a pathogen of concern, the founding animals are spawned until clean offspring are obtained, utilizing the GREEN isolation chamber as needed. If clean offspring or parents cannot be obtained, either a secondary source of the line is found or alternatively, all research using this line must stay within the confines of quarantine. Only lines that produce two clean subsequent generations of animals may be introduced into the SPF fish room.

Elimination of live feed

All live feed sources have been removed from our feeding regimen in an effort to reduce labor cost and to eliminate variations introduced by inconsistent live food quality. Adult fish are fed size-appropriate GEMMA Micro (Skretting, Inc., Fontaine Les Vervins, France) twice a day. Larval and juvenile fish also receive age-appropriate GEMMA Micro feed but are fed thrice a day.

The SARL has been free of early-stage live feed such as paramecia or rotifers since 2009. Brine shrimp (Artemia nauplii) was removed from the SARL feeding regimen after a multiyear study in which both larval survival and lifetime embryo production were assessed utilizing only GEMMA Micro without supplementation of any live feed, both at the larval and adult life stages. This trial clearly indicated that we could maintain high-level embryo production without the use of any live feed. In addition to equivalent fish performance and reduced risk of introducing contaminants through live feed, a labor assessment showed that the overall cost of our feeding program was reduced considerably.

Tank housing

A large portion of the fish at SARL are housed in 50 or 100 gallon brood stock tanks. All additional fish are housed in small polycarbonate enclosures at ∼6 fish per liter. SARL houses ∼50,000 adult fish within the SPF fish rooms. Although stocking densities as high as 12 fish per liter have been reported as appropriate for research zebrafish, ³ SARL utilizes the lower density to allow better fish observation during daily health surveillance screens. Dedicated outcross tanks are utilized to reduce potential for biological or genetic contamination back to our main wild-type stocks. All fish in the outcross tanks are euthanized after they are no longer needed and are not returned to the main wild-type population. In an effort to reduce handling of wild-type spawning populations, they are housed in large brood stock tanks and spawned in place using an internal collection apparatus that is plumbed to an external collection spigot.

Tank cleaning

Tank cleaning is regularly scheduled and the procedures are tailored to the type of enclosure. Large brood stock tanks are cleaned in place by manual scrubbing and flushing of debris. The large brood stock tanks are designed for zero light ingress for use as light cycle tanks, and each has its own timed overhead LED light source. Sidewall growth has been significantly minimized to a point that they only require quarterly cleaning. When fish stocks are removed, the tanks are emptied, isolated from the system, and sanitized in place using sodium hypochlorite. All other tanks and tank supplies are changed out every 2–4 weeks and are washed in a Tecniplast 650a Aquatic Cage Washer, which utilizes a three-stage chemical sanitization and neutralization process to eliminate biologicals. The cage washer is tested quarterly using adenosine triphosphate (ATP) detection probes to ensure proper function. ⁴

Health monitoring and testing

The health monitoring program within the SPF portion of the facility has four main components: sentinels, wild-type stocks at both 15 dpf and retirement, select retiring generations, moribund and mortality.
