Immunoelectronmicroscopic Analysis of the Ligand-induced Internalization of the Somatostatin Receptor Subtype 2 in Cultured Human Glioma Cells

Abstract

We analyzed the internalization of the receptor subtype 2 (sst₂) for the neuropeptide somatostatin in glioma cells at the ultrastructural level using an antibody against an extracellular amino acid sequence. Intact cells derived from solid human gliomas or those of the human glioma cell line U343 were receptor-labeled (a) by classical gold immunocytochemistry using a 15-nm gold-labeled second antibody, (b) directly with the sst₂ antibody adsorbed to 5-nm colloidal gold, and (c) with the physiological ligand somatostatin conjugated to 5-nm colloidal gold. The receptor was predominantly internalized via uncoated vesicles budding from the cell membrane but only rarely via coated pits, which has been mostly reported for G-protein-coupled, seven transmembrane-domain receptors. In the presence of ligand and sst₂ antibody vesicles, tubule-like structures, and multivesicular bodies were labeled in superficial and in perinuclear portions of the cells within the first 30 min. Lysosomal labeling was observed after 30 min and especially after an hour of internalization time. This internalization route is also used to study the directly labeled sst₂ antibody or the labeled ligand. However, the late endosomal compartment appears to be reached more rapidly in these latter experiments.

Keywords

somatostatin receptor internalization glioma cells endosomes

Endocytosis of cell surface receptors is a crucial step in the initiation of the intracellular signal transduction cascade after binding of extracellular ligands such as neurotransmitters or hormones. Many receptor-ligand complexes assemble at clathrin-coated pits budding off the membrane to form coated vesicles. After shedding their coats, these vesicles fuse with early endosomes (Mellman 1996). Although this is accepted as the predominant pathway for agonist-induced internalization of many G-protein-coupled receptors (Böhm et al. 1997), alternative routes must be taken into account (Anderson 1993). In particular, single transmembrane domain receptors are internalized via caveolae or other endosomal vesicles (Wu et al. 1997), but this is also discussed for certain seven transmembranedomain receptors, e.g., a β-adrenergic receptor (Raposo et al. 1989), the endothelin receptor subtype A (Chun et al. 1994), and the cholecystokinin receptor (Roettger et al. 1995). These different internalization routes (coated or noncoated pits) may indicate special signal transduction pathways (Mellman 1996; Parton 1996) governed by the equipment of the endocytosing membrane (Liu et al. 1997).

Despite the complexity of these internalization processes most investigations were performed with subcellular fractionation techniques or by confocal laser microscopy and used mostly transfected cells that were not the physiological target for the ligand (Garland et al. 1994; Ashworth et al. 1995; Nouel et al. 1997; Roosterman et al. 1997). Studies using high-resolution electron microscopic techniques are lacking up to now. Therefore, the aim of the present study was to analyze the agonist-induced internalization of a seven-transmembrane domain G-protein-coupled receptor at the ultrastructural level in a nontransfected cell. We investigated the receptor subtype 2 (sst₂) for the widely distributed inhibitory neuropeptide somatostatin in human glioma cells. These cells are known to express sst₂ in large amounts compared to the natural target cell, the nonmalignant astrocyte (Feindt et al. 1995). Therefore, glioma cells appear to be a good model for investigating internalization processes by electron microscopic analysis.

The internalization of the sst₂ receptor is described at the ultrastructural level by use of an antibody against an amino acid sequence in the extracellular part of the receptor molecule and with an electrondense conjugate of the ligand. Visualization of the dynamics of the receptor internalization on intact cells was accomplished by (a) classical gold immunocytochemistry using the sst₂ antiserum as first antibody and a gold-labeled anti-rabbit immunoglobulin as second antibody, (b) labeling the sst₂ antibody directly with colloidal gold, and (c) adsorption of the physiological ligand somatostatin to colloidal gold and affinity-labeling of the receptor.

Materials and Methods

Antisera

The sst₂ receptor antibody was raised in rabbits against a synthetic peptide corresponding to residues 33-43 (QTEPYYDLTSN) plus a C-terminal cysteine that was conjugated via SH groups to keyhole limpet hemocyanin (Eurogentec; Seraing, Belgium). This sequence does not occur in any of the other sst subtypes, but is common to the splice variants A and B of the human sst₂. The antibody was affinity-purified (affinity gel-peptide coupled to EAH Sepharose; Pharmacia, Uppsala, Sweden) and analyzed by SDS-PAGE and ELISA. A further anti-peptide antibody against the C-terminal sequence of sst_2A (ETQRTLLNGDLQTSI) was obtained from Gramsch Laboratories (Schwabhausen, Germany); compare Feindt et al. (1997).

Membrane Fractionation and Western Blotting

A total of 1-2 × 10⁶ cells were lysed in 10 ml 5 mM Hepes buffer, pH 7.4, with 1 mM phenylmethanesulfonyl fluoride, 0.1 mM N-ethylmaleimide, and 0.1 mg/ml bacitracin and were disrupted by sonication (1 min). After addition of 1 ml 1.4 M NaCl in 200 mM Hepes, pH 7.4, nuclei and cell debris were removed by centrifugation (10 min, 800 × g at 4C) and a membrane fraction obtained (2 hr, 48,000 × g) that was suspended in 1 ml 0.14 M NaCl, 20 mM Hepes, pH 7.4. An aliquot (5-10 μg protein) was reduced and denatured in sample buffer, separated by SDS-PAGE (10% gel), transferred by semidry blotting (90 min, 65 mA) onto a polyvinylidene difluoride membrane (PVDF; Millipore, Bedford, MA) that was blocked with 5% casein, 0.1% Tween, 1 mM EDTA in PBS for 60 min, incubated overnight at 4C with anti-sst₂ (1:20 in Tween-EDTA-PBS), washed (three times for 15 min in EDTA-PBS), incubated (30 min) with peroxidase-labeled goat anti-rabbit IgG (1:40,000; Sigma, St Louis, MO), washed (three times for 15 min in EDTA-PBS), and visualized by enhanced chemiluminescence (ECL system; Amersham, Poole, UK). Rainbow-colored as well as biotinylated proteins (Amersham, plus streptavidin-peroxidase with the second antibody) served as molecular mass markers. The sst₂ antibody was inactivated by co-incubation with 50 μM of the peptide QTEPYYDLTSN.

Reverse Transcription-Polymerase Chain Reaction (RT-PCR) and cAMP Assay

RT-PCR for detection of sst_2A and sst_2B was performed (Feindt et al. 1995) with the sense primer 5′-TGGTGGTCCTCACCTATG-3′ in combination with the anti-sense primers I 5′-CTGTATAGGCATTACCTACG-3′or II 5′-CCTCCAAACCAGTATCTGA-3′ (Taylor et al. 1994). PCR products were identified by agarose gel electrophoresis and controlled by cycle sequencing using the DyeDeoxy Terminator Cycle Sequencing Ready Reaction Kit (Applied Biosystems; Foster City, CA). The expected length of the PCR products with the anti-sense primer I is 623 bp for sst_2A and 283 bp for sst_2B. With anti-sense primer II, only sst_2A yields a 221-bp product. For assay of cAMP, cells were stimulated in serum-free Dulbecco's modified Eagle's medium (DMEM) for 10 min with 50 μM forskolin in combination with 1 nM octreotide (a gift from Novartis/Sandoz Pharma; Basel, Switzerland) and anti-sst₂ (1:500), lysed, and intracellular cAMP determined by RIA (Feindt et al. 1995).

Labeling of Antibody and Ligand with Colloidal Gold

A total of 100 μg affinity-purified sst₂ antibody dialyzed vs 2 mM borate buffer, pH 9.0, was stirred for 1 hr with 20 ml colloidal gold sol (EM GC 15 or EM GC 5; British Biocell, Cardiff, UK) previously adjusted with 0.2 M K₂CO₃ to pH 9.0. Then 1 ml of 10% bovine serum albumin (BSA) in bidistilled water adjusted to pH 9.0 was added. After stirring for another 10 min the conjugate was concentrated to 1 ml by ultrafiltration (YM 10 membrane; Amicon, Temecula, CA), purified by gel filtration (Superdex S-300 1.6 × 60-cm column equilibrated and eluted with 0.14 M NaCl, 0.2% BSA, 10 mM Hepes, pH 8.0), and concentrated again by ultrafiltration. Labeling of somatostatin has been previously described (Mentlein et al. 1990). In brief, 10 ml of 5-nm gold sol adjusted to pH 9.0 was incubated with 100 μl (100 nmol) of 1 mM somatostatin stock solution in water for 24 hr at 4C. After stabilization with 1 ml 10% BSA, excess peptide and other substances were removed by gel chromatography and repeated ultrafiltration as above. Particle concentrations of colloidal gold sols were calculated from their absorbance at 520 nm (Mentlein et al. 1990).

Cell Culture

Astrocytes were obtained from dissociated cerebral cortices of 2–day-old Fisher F344 rats, purified, and subcultivated (McCarthy and De Vellis 1980). Cells from surgical human gliomas (classified as glioblastoma WHO Grade IV) and the human glioma cell line U343 (Deutsches Krebsforschungszentrum; Heidelberg, Germany) were purified and cultivated in DMEM containing 10% fetal calf serum (Feindt et al. 1995). All cultures used were more than 95% immunopositive for the astroglia/glioma marker glial fibrillar acidic protein (GFAP) and less than 1% reactive with the microglia/ macrophage marker CD68 (Lucius et al. 1995).

Receptor Labeling and Internalization

Subconfluent cells (10⁵ U343 or glioma cells) grown on polyd-lysine-coated coverslips in DMEM plus 10% fetal calf serum for 3 days were equilibrated to room temperature, washed in Gey's balanced salt solution plus 0.6% glucose (GBSS+G), and cooled to 8C in the refrigerator for 60 min. After preincubation with 10 nM somatostatin in GBSS+G (8C, 60 min), cells were exposed to the sst₂ antibody (1:500 in GBSS+G, 150 min, 8C) and after a washing step to goat anti-rabbit IgG conjugated to 15-nm colloidal gold (British Biocell; 45 min, 8C), or, alternatively, only to the gold-labeled anti-sst₂, all in the presence of 10 nM somatostatin. For light microscopy, surface-labeled cells (8C) were washed briefly in GBSS+G and PBS, fixed with 3% glutaraldehyde in 0.1 M phosphate buffer, pH 7.4, for 25 min, washed in PBS (3 min), 0.1 M lysine in PBS (10 min) and twice again in PBS, and then incubated overnight at 8C with goat anti-rabbit IgG coupled to gold particles of less than 0.8 nm (1:30 in PBS plus 0.2% gelatin; Aurion, Wageningen, The Netherlands). After thorough washing in PBS plus 0.1% gelatin and bidistilled water, specimens were silver-intensified with R-Gent (Aurion), washed in bidistilled water, counterstained in Mayer's hemalum, rinsed in tapwater, and embedded. For electron microscopy, cells were washed in cold GBSS+G without somatostatin and immediately fixed in cold 3% glutaraldehyde in PBS (30 min, 8C) or exposed to 37C for different times (5, 10, 15, 20, 30, 45, and 60 min) in GBSS+G. After fixation with 3% glutaraldehyde in PBS (5 min at 20C and 25 min at 8C), the specimens were embedded in Araldite, sectioned, double-contrasted (Mentlein et al. 1990), and viewed in a Zeiss 902 electron microscope. Internalization experiments with gold-labeled somatostatin (10 nM) were performed as above (additionally every 2 min up to 10 min at 37C) but without unlabeled somatostatin and all antisera.

Controls

Cells were incubated only with gold-labeled second antibody (anti-rabbit IgG-Au), or without anti-sst₂, with anti-sst₂ replaced by preimmune serum, or with antigen-inactivated anti-sst₂ (1 μM peptide, 30 min, 37C) and fixed after 10 min at 37C. Internalization was performed without preincubation with somatostatin and after washing in 20 mM citrate, 140 mM NaCl, pH 5.5. Under hyperosmolar conditions (0.4 M sucrose in GBSS) or in potassium-free buffer (140 mM NaCl, 1 mM CaCl₂, 1 mM MgCl₂, 1 mg/ml glucose, 20 mM Hepes, pH 7.4), internalization times of 5 and 10 min were used.

Results

Glioma Cells Express the sst_2A Somatostatin Receptor

Expression of the sst₂ receptor in human glioma cells could be verified by Western blotting and RT-PCR experiments. The affinity-purified sst₂ antiserum directed to the N-terminal extracellular portion of the receptor strongly reacted with a 75-kD band in U343 human glioma cells (Figure 1). The immunoreactivity was abolished completely in the presence of the immunization peptide or by omitting the primary antibody. A corresponding 75-kD band was also stained by a different sst_2A-directed antiserum raised against the C-terminal 15 intracellular residues of this splice variant of the receptor. The mRNA for sst_2A could be detected in U343 glioma cells by RT-PCR with two different primer pairs, whereas mRNA for the splice product sst_2B was undetectable (not shown).

Figure 1

Western blot analysis of the somatostatin receptor sst₂ in U343 glioma cell membranes using different antibodies. Different blots with two electrophoresis lanes were stained with the sst₂-antibody directed to the extracellular part of the receptor (anti sst₂ 33-43) or with an sst_2A antibody generated to the intracellular C-terminal amino acids of the splice variant A (anti sst_2A 355-369) and detected by chemiluminescence. (Control) Immunostaining in the presence of the peptide antigen. Rainbow-colored (cM) and biotin-labeled (bM) proteins were used as molecular mass markers.

Binding of the antibody to sst₂ had no influence on its signal transduction. The somatostatin analogue octreotide (sst₂-specific in glioma cells at 1 nM due to the absence of sst₃ and sst₅) reduced intracellular cAMP levels in U343 cells elevated by the adenylyl cyclase activator forskolin (50 μM at 37C for 10 min; compare Feindt et al. 1995) irrespective of whether anti-sst₂ was present or absent (not shown).

The sst₂ Receptor Can be Visualized on the Surface of Glioma Cells

After cooling to 8C subconfluent cultures either of the glioma cell line U343 or from solid human gliomas, the somatostatin receptor could be always stained with the sst₂ antibody at the light or electron microscopic level on the cell surface, but with different intensity on single cells (Figure 2). Unstained and heavily stained cells were in direct juxtaposition. When the antibody was inactivated with the immunization peptide, no labeling was observed. At the electron microscopic level, the labeling on U343 cells was rather uniformly distributed mainly on the cell somata, whereas the delicate processes of human glioma cells were labeled up to their finest tips (Figure 3).

Figure 2

Light microscopic immunocytochemistry of the sst₂ receptor on intact glioma cells. (A) U343 cells incubated with sst₂ antiserum; note the differing staining intensity of the cells. (B) U343 cells incubated with the peptide-adsorbed sst₂ antiserum; all cells are completely unstained. (C) Human glioma cells (WHO IV) incubated with the active sst₂ antiserum; positively reacting cells, labeled up to their fine processes, are directly adjacent to unstained cells.

The Antibody-labeled Somatostatin Receptor is Internalized via Endosomal Vesicles and Not via Coated Pits

Although U343 cells and cells of human glioblastoma differ in their surface morphology (Figure 3), there were no fundamental differences in their internalization pattern. Cells fixed without warming carried singly dispersed gold particles exclusively on the surface of short, coarse processes in U343 cells or on the filiform network of glioblastoma cells (Figure 3). After warming at 37C for 5 min, assembly of gold particles was observed on the cell somata between the processes, and a few of them were found in inconspicuous vesicles opening at or positioned directly beneath the cell surface (Figure 4A). On tangential sections through the superficial parts of the cell, a high regional amount of gold assembly on limited areas of the cell surface was even more evident (not shown).

The labeling intensity of these vesicles increased with increasing internalization times; the vesicles sometimes became elongated to little tubules (Figure 4B). They still were most often found in the superficial parts of the cells. Coated pits were only rarely labeled, at most in about 1% of labeled vesicles. After 15 min at 37C a few gold particles were included in multivesicular bodies (Figure 4C). Their number and the number of engulfed gold particles enlarged with increasing internalization times. In addition, after 30 min at 37C, labeled multivesicular bodies were located in the vicinity of Golgi areas and lysosome-like bodies containing gold particles were first observed (Figure 4D). Thereafter, their number and labeling intensity increased, but even after 60 min of internalization labeled lyso- some-like bodies were clearly less common than labeled multivesicular bodies. Binding and internalization continued even for longer times at 37C, however, with decreasing labelling intensity at the cell membrane after 45 min and still less intensity after 60 min at 37C. Then, heavily labeled lysosomal bodies were conspicuous although staining was dense in superficial cytoplasmic vesicles, tubules, and multivesicular bodies.

Figure 3

Electron microscopic immunocytochemistry of the sst₂ receptor on glioma cells at 4C. (A) Soma of a U343 cell, with gold particles only on its surface; tilting angle 2308. (B) Coarse proximal process of a U343 cell; tilting angle 1158. (C) Fine processes of a cell cultivated from a human glioma (WHO IV) are decorated with gold particles.

With 5-nm gold-labeled sst₂ antibodies, fundamentally the same internalization pattern was observed as with unlabeled primary and 15-nm gold-labeled secondary antibodies. Gold particles were mostly engulfed in uncoated vesicles, moving slowly with longer incubation times into the perinuclear region. Multivesicular bodies took the same route with a slight shift in time. After 5 min the first labeled multivesicular bodies were observed, which is clearly earlier than in experiments using 15-nm gold-IgG as indicator for the bound sst₂ antibody. However, no differences were evident regarding the appearance of gold-containing lysosome-like bodies.

Incubation Controls. When somatostatin was omitted from the incubation, no differences in the surface labeling could be observed up to 30 min. Gold particles were localized at the cell surface and were included in vesicles immediately beneath the cell membrane. However, they appeared as singlets and their numbers were clearly lower compared with preparations in which the receptor had been activated. Even after 30 min of incubation, late endosomes were hardly labeled. Only after 45 min were a few multivesicular bodies and even fewer lysosome-like bodies seen in perinuclear regions. Under potassium-deficient conditions, labeling was confined to the cell surface; intracellular gold particles were a rare exception (Figure 5A). Under hyperosmolar conditions, the cells exhibited a strongly condensed cytoplasm and internalization could not be observed, the profiles of coated and uncoated vesicles being greatly diminished (Figure 5B). When peptide-inactivated sst₂ antiserum or anti-IgG-Au was used instead of gold-labeled anti-sst₂, surface and cytoplasmic labeling was hardly observable and was presumed to represent background staining (Figure 5C).

Figure 4

Electron microscopic immunocytochemistry of the sst₂ receptor on glioma cells after different internalization times in the presence of the ligand. (A) U343 cell after 5 min at 37C; assembled gold particles are engulfed in smooth omega-shaped vesicles budding off from the cell membrane (arrows). Coated pits (arrowhead) are empty. (B) U343 cell, after 10 min at 37C; assembled gold particles are included in fusing vesicles (arrows). Bars = 200 nm. (C) U343 cell after 30 min at 37C still has some bound gold particles at its surface. A considerable number of them, however, are included in endosomal vesicles (e) and multivesicular bodies (MVB) rather close to the cell surface. (D) Human glioma cell (WHO IV) after 45 min at 37C displays labeled multivesicular bodies (MVB) and lysosome-like bodies (L) in the perinuclear region close to the Golgi area. Bars = 400 nm.

Labeled Somatostatin Is Internalized via Endosomal Vesicles and Not via Coated Pits

The gold-labeled ligand was internalized in the same way as the antibody-labeled receptor. In previous studies we have shown that this electron-dense conjugate of somatostatin to 5-9-nm colloidal gold is still biologically active in displacing radiolabeled peptide from pituitary or cortical binding sites and in reducing basal or growth hormone-releasing hormone-induced somatotropin release from adenohypophyseal cells (Mentlein et al. 1989,1990). Moreover, the conjugate was physically stable for at least 1 hr at 37C at pH values between 4 and 8.6 (Mentlein et al. 1989). After 5 min of internalization, the ligand was observed at the cell surface and in omega-shaped uncoated vesicles (Figure 6), but coated pits were only rarely labeled. As early as 5 min after incubation at 37C, multivesicular bodies contained the small gold particles along with early endosomal vesicles and tubular structures. The lysosomal compartment was not reached earlier than in experiments using 15-nm gold-labeled anti-rabbit IgG as tag for receptor antibodies.

Figure 5

Incubation controls, internalization time 10 min. (A) U343-cells; under potassium-deficient conditions gold particles indicating the sst₂ antibody are found exclusively at the cell surface. (B) Glioma cells (WHO IV); under hyperosmolar conditions cells display highly condensed cytoplasm and greatly reduced numbers of vesicles at the cell membrane, with no intracellular gold particles indicating the sst₂ antibody. (C) Glioma cells (WHO IV); the sst₂ antibody is replaced by anti-rabbit IgG coupled to 15 nm gold (1:30). No intracellular and very weak extracellular staining are present.

Figure 6

Internalization of 5-nm gold-labeled somatostatin (arrows) in U343 glioma cells at different internalization times. (A,B) The ligand is rapidly internalized via smooth endosomal vesicles; coated pits remain unstained. (C) With increasing internalization time endosomal vesicles (e) fuse to tubules. (D) After 10 min the gold particles are included in early (e) and in developing late endosomes (star). (E) After 15 min they are localized in multivesicular bodies (star) in the vicinity of Golgi areas (G).

Finally, we attempted to double label the receptor with the 5-nm gold-labeled ligand and the 15-nm gold-labeled antibody (either directly or via the second antibody). However, in these combination studies only the 5-nm gold-tagged ligand could be demonstrated. The preparations were completely devoid of 15-nm gold particles, irrespective of whether ligand and receptor antibody were applied together or in sequence.

Discussion

With a triple electron microscopic approach (classical immunocytochemistry with gold-labeled second antibodies, directly gold-labeled antibody, and affinitylabeling with gold-tagged ligand), the internalization pathway of ligand-activated sst₂ was studied in glioblastomas cultivated after neurosurgery and in a human glioblastoma cell line (U343). The results achieved in these three approaches are congruent. The predominant internalization route is via uncoated vesicles budding from the cell membrane. Under permanent internalization conditions for half an hour, labeled vesicles and tubule-like structures as well as labeled multivesicular bodies (MVB) are observed in superficial and perinuclear parts of the cells. Lysosomal labeling begins after 30 min and is fully expressed after an hour of internalization time. Only then is labeling intensity at the cell surface decreased. Slight differences between the results achieved with labeled receptor antibodies and labeled ligand appear to concern internalization dynamics. The ligand appears more rapidly in the late endosomal compartment (MVB) than the labeled antibodies. It does not, however, enter the lysosomal compartment more rapidly.

Neither the gold-labeled ligand nor the sst₂ antibody is suitable to discriminate between the splice variants sst_2A and sst_2B which differ in the intracellular C-terminal residues. However, in the U343 cell line and in gliomas, only the subtype 2A is detectable, as has been reported for other tumors, e.g., carcinomas and melanomas (Taylor et al. 1994). In the presence of antibody the receptor was still able to transduce intracellular signals, i.e., inhibition of the adenyl cyclase.

Internalization processes terminate after very short periods, with sorting in early endosomes being completed after 2-3 min (Mellman 1996). Coated pits can lose their coats so rapidly that the presently used internalization times are too long to observe them. We did not intend to investigate the time course of the different internalization steps but rather to observe the organelles involved. Therefore, the internalization conditions were kept unchanged over a rather long time so that all internalization steps could be expected to be observable at least during the first 5-10 min.

Internalization of receptor-selective ligands (Koenig et al. 1997; Nouel et al. 1997) or somatostatin receptor subtypes (Hipkin et al. 1997; Roosterman et al. 1997) has been described in transfected cells on the basis of confocal fluorescence microscopy. A main internalization route via coated pits has been proposed from the pattern of fluorescent signals in incubations with phenylarsine oxide, hypertonic sucrose, or in potassium-deficient conditions. These additions have been reported to block internalization processes via coated pits (Larkin et al. 1983; Heuser and Anderson 1989; Hansen et al. 1993). These studies, however, were focused exclusively on coated pits, disregarding all other membrane-associated vesicles. Hence, it can not be taken for granted that these conditions similarly impede other internalization routes. Clear ultrastructural demonstration has been lacking up to now. Using this superior technique, these previous findings on somatostatin receptors cannot be corroborated, at least for human glioma cells.

The alternative internalization route via caveolae or other endosomal vesicles has been suggested only for a few of the other seven transmembrane domain receptors (Raposo et al. 1989; Chun et al. 1994; Roettger et al. 1995; Wu et al. 1997). Caveolin, the integral membrane protein of caveolae, co-purifies with G-proteins and receptors with tyrosine kinase activity like that of insulin and neurotrophin receptors (Wu et al. 1997). Moreover, a specific interaction between caveolin and inactive G_α-subunits has been described (Li et al. 1995), the activation of the latter being impeded by caveolin. A cytosolic amino terminal domain of caveolins binds to trimeric G_α-subunits (G_αα and particularly G_iα2), thus preventing activation of the G_α-subunit (Couet et al. 1997). According to Gu and Schonbrunn (1997), sst_2A couples to G_iα1, G_iα2, and G_iα3. In astrocytes, caveolae have been demonstrated by immunofluorescence microscopy of caveolin-1 and by conventional electron microscopy (Cameron et al. 1997).

In the present electron microscopic study we did not observe the receptor directly but only indirectly via one or two antibodies or via the labeled ligand. However, given a pH of 6.3-6.8 in early endosomal vesicles (Mellman 1996), antibody and ligand binding to gold can be accepted to be stable (Mentlein et al. 1990). Therefore, our experimental protocol appears to be a suitable model to determine possible internalization pathways of a G-protein-coupled receptor. In initial experiments on the internalization of somatostatin- gold by cultivated somatotrophs, we were also unable to find labeled coated pits, although the gold-labeled ligand was functionally active in inhibiting growth hormone release (Mentlein et al. 1989).

The expression of somatostatin receptors on gliomas cannot be associated only with malignancy. In addition to neurons (Krisch 1994), astrocytes also bear somatostatin receptors on certain subpopulations in situ and in vitro (Mentlein et al. 1990; Krisch et al. 1991). In cultured astrocytes, somatostatin has been shown to induce several signal transduction pathways. Activation of sst inhibits adenylate cyclase activity (Feindt et al. 1995), stimulates phospholipase A2 activity (Krisch and Mentlein 1994), and activates a protein phosphatase that inhibits the autophosphorylation of the receptor for epidermal growth factor (unpublished observations). As a result of the reduction in cAMP levels, somatostatin inhibits interleukin 6 release from astrocytes (Grimaldi et al. 1997). Antisecretory effects on gliomas have not yet been described.

In conclusion, in glioma cells the sst_2A receptor is an example of a further G-protein-coupled seven transmembrane-domain receptor that after ligand binding is not internalized via coated pits but via uncoated endosomal vesicles.

Footnotes

Acknowledgments

Supported by grants from the Deutsche Forschungsgemeinschaft (Kr 569/7-1) and the Hensel Foundation.

We are greatly indebted to Ms Martina Burmester, Ms Dagmar Freier, and Ms Helga Prien for skillful technical assistance.

This work is dedicated to Prof Dr Helmut Leonhardt on the occasion of his eightieth birthday.

References

Anderson

RGW

(1993) Caveolae: where incoming and outgoing messengers meet. Proc Natl Acad Sci USA 90:10909–10913.

Ashworth

Nelson

Gershengorn

Hinkle

(1995) Visualization of the thyrotropin-releasing hormone receptor and its ligand during endocytosis and recycling. Proc Natl Acad Sci USA 92:512–516.

Böhm

Grady

Bunnett

(1997) Regulatory mechanisms that modulate signalling by G-protein-coupled receptors. Biochem J 322:1–18.

Cameron

Ruffin

Rasmussen

Cameron

(1997) Identification of caveolin and caveolin-related protein in the brain. J Neurosci 17:9520–9535.

Chun

Liyanage

Lisanti

Lidish

(1994) Signal transduction of a G protein-coupled receptor in caveolae: Colocalization of endothelin and its receptor with caveolin. Proc Natl Acad Sci USA 91:11728–11732.

Couet

Okamoto

Ikezu

Lisanti

(1997) Identification of peptide and protein ligands for the caveolin-scaffolding domain. Implication for the interaction of caveolin with caveolae-associated proteins. J Biol Chem 272:6525–6533.

Feindt

Becker

Blömer

Hugo

H-H

Mehdorn

Krisch

Mentlein

(1995) Expression of somatostatin receptor subtypes in cultured astroytes and gliomas. J Neurochem 65:1997–2005.

Feindt

Mentlein

Krisch

(1997) Time-dependent influence of the somatostatin analogue octreotide on the proliferation of rat astrocytes and glioma cells. Brain Res 746:309–313.

Garland

Grady

Payan

Vigna

Bunnett

(1994) Agonist-induced internalization of the substance P (NK1) receptor expressed in epithelial cells. Biochem J 303:177–186.

10.

Grimaldi

Florio

Schettini

(1997) Somatostatin inhibits interleukin 6 release from rat cortical type I astrocytes via the inhibition of adenylylcyclase. Biochem Biophys Res Commun 235:242–248.

11.

Schonbrunn

(1997) Coupling specificity between somatostatin receptor sst_2A and G proteins. Isolation of the receptor-G-protein complex with a receptor antibody. Mol Endocrinol 11:527–537.

12.

Hansen

Sandvig

van Deurs

(1993) Clathrin and HA2 adaptors: effects of potassium depletion, hypertonic medium and cytosol acidification. J Cell Biol 121:61–72.

13.

Heuser

Anderson

RGW

(1989) Hypertonic media inhibit receptor- mediated endocytosis by blocking clathrin-coated pit formation. J Cell Biol 108:389–400.

14.

Hipkin

Friedman

Clark

Eppler

Schönbrunn

(1997) Agonist-induced desensitization, internalisation, and phosphorylation of the sstr2A somatostatin receptor. J Biol Chem 272:13869–13876.

15.

Koenig

Edwardson

Humphrey

PPA

(1997) Somatostatin receptors in Neuro2A neuroblastoma cells: ligand internalization. Br J Pharmacol 120:52–59.

16.

Krisch

(1994) Somatostatin binding sites in functional systems of the brain. Prog Histochem Cytochem 28:1–41.

17.

Krisch

Mentlein

(1994) Neuropeptide receptors and astrocytes. Int Rev Cytol 148:119–168.

18.

Krisch

Buchholz

Mentlein

(1991) Somatostatin binding sites on rat diencephalic astrocytes. Light microscopic study in vitro and in vivo. Cell Tissue Res 263:253–263.

19.

Larkin

Brown

Goldstein

Anderson

RGW

(1983) Depletion of intracellular potassium arrests coated pit formation and receptor-mediated endocytosis in fibroblasts. Cell 33:273–285.

20.

Okamoto

Chun

Sargiacomo

Casanova

Hansen

Nishimoto

Lisanti

(1995) Evidence for a regulated interaction between heterotrimeric G proteins and caveolin. J Biol Chem 270:15693–15701.

21.

Liu

Horner

Rogers

Schnitzer

(1997) Organized endothelial ell surface signal transduction in caveolae distinct from glycosylphosphatidylinositol-anchored protein microdomains. J Biol Chem 272:7211–7222.

22.

Lucius

Sievers

Mentlein

(1995) Enkephalin metabolism by microglia aminopeptidase N (CD 13). J Neurochem 64:1841–1847.

23.

McCarthy

De Vellis

(1980) Preparation of separate astroglial and oligodendroglial cell cultures from rat cerebral tissue. J Cell Biol 85:890–902.

24.

Mellman

(1996) Endocytosis and molecular sorting. Annu Rev Cell Dev Biol 12:575–625.

25.

Mentlein

Buchholz

Krisch

(1989) Binding and internalizaion of gold-conjugated somatostatin and growth hormone-releasing hormone incultured somatotropes. Cell Tissue Res 258:309–317.

26.

Mentlein

Buchholz

Krisch

(1990) Somatostatin-binding sites on rat telencephalic astrocytes. Cell Tissue Res 262:431–443.

27.

Nouel

Gaudriault

Houle

Reisine

Vincent

J-P

Mazella

Beaudet

(1997) Differential internalization of somatostatin in COS-7 cells transfected with SST₁ and SST₂ receptor subtypes: a confocal microscopic study using novel fluorescent somatostatin derivatives. Endocrinology 138:296–306.

28.

Parton

(1996) Caveolae and caveolins. Curr Opin Cell Biol 8:542–548.

29.

Raposo

Dunia

Delavier-Klutchko

Kaveri

Strosberg

Benedetti

(1989) Internalization of β-adrenergic receptor in A431 cells involves non-coated vesicles. Eur J Cell Biol 50:340–352.

30.

Roettger

Rentsch

Pinon

Holicky

Hadac

Larkin

Miller

(1995) Dual pathways of internalization of the cholecystokinin receptor. J Cell Biol 128:1029–1041.

31.

Roosterman

Roth

Kreienkamp

Richter

Meyerhof

(1997) Distinct agonist-mediated endocytosis of cloned rat somatostatin receptor subtypes expressed in insulinoma cells. J Neuroendocrinol 9:741–751.

32.

Taylor

Theveniau

Bashirzadeh

Reisine

Eden

(1994) Detection of somatostatin receptor subtype 2 (SSTR2) in established tumors and tumor cell lines: evidence for SSTR2 heterogeneity. Peptides 15:1229–1236.

33.

Butz

Ying

Y-S

Anderson

RGW

(1997) Tyrosine kinase receptors concentrated in caveolae-like domains from neuronal plasma membrane. J Biol Chem 272:3554–3559.
