Papillary Thyroid Carcinoma Metastatic to the Frontal Sinus and Frontal Recess: Case Report

Introduction

Papillary thyroid carcinoma (PTC) is the most frequent type of differentiated carcinoma of the thyroid^1-3. Distant metastases are observed in 5 to 15% in patients with PTC^1,4, with the most common sites being the lung followed by bone and brain ¹ . There have been only isolated case reports of thyroid carcinomas metastatic to the paranasal sinuses (PNS)^2,3,5, and most have been of follicular carcinomas^5-7. The few reported cases of PTC metastasizing to the PNS have been described mostly in the maxillary sinuses^2,7. We present a case of an unusual metastasis of PTC in the frontal sinuses, 5 years after primary cancer diagnosis.

Case Report

We report the case of a 39-year-old man with a history of PTC staged T3N1aM0 that was diagnosed five years earlier and treated with total thyroidectomy, ¹³¹I therapy and two neck dissections. During follow-up, he presented symptoms of headache and purulent rhinorrhea. Nasal endoscopy evidenced secretions in the right middle meatus with no signs of tumor. There was no elevation in thyroglobulin level. A cervical and facial computed tomography (CT) (Figure 1A) and a magnetic resonance imaging (MRI) (Figure 1B) showed opacification of the frontal sinuses and the anterior ethmoid sinus without signs of angiogenesis, bone destruction, or calcification. The patient underwent endoscopic sinus surgery following antibiotic therapy and local nasal treatment as there was no symptomatic improvement. After the anterior ethmoidectomy was performed, a bleeding red lesion mimicking thyroid tissue was observed in the frontal recess and biopsied (Figure 2). Histologic examination revealed papillary carcinoma (Figure 3). Diagnosis of PTC metachronous metastasis was established. A complete endoscopic resection, as decided at the multidisciplinary oncological meeting, using Draf 3 technique, was carried out. Surgery was followed by ¹³¹I therapy. The postoperative period was uneventful. The patient has been on regular follow-up until this day and no evidence of recurrence was observed (Figure 2C).OPEN IN VIEWER

OPEN IN VIEWER

Figure 2.

(A). Endoscopic view showing lesion mimicking thyroid tissue in the right frontal recess" (B). Biopsy of the lesion "(C). Endoscopic view one month after the intervention".

OPEN IN VIEWER

Figure 3.

Fragments of sinonasal mucosa infiltrated by islands of malignant cells displaying a papillary architecture. The papillae contain a thin fibro-vascular core lined by a single layer of cuboidal cells. The nuclei are enlarged and crowded, sometimes overlapping. A few nuclear grooves and pseudoinclusions can be seen. The cells express both TTF1 and PAX8.

Discussion

PTC accounts for 85% of the well-differentiated thyroid carcinomas^1,3. It is often slow-growing and localized. PTC has a low mortality rate (6% after 16 years of follow-up) ⁸ . The distant metastasis rate is 5 to 15% in patients with PTC ⁴ . Recurrence and cancer-related mortality risk factors are age at diagnosis, histologic type, extent of the tumor, and presence of metastases^1,8. PTC often shows lymphogenous rather than hematogenous spread^1,9. The lung is the most common site of distant metastases, followed by bone and brain^1,4.

Cancer metastatic to the PNS is uncommon and most often originates secondarily to renal cell carcinoma and bronchogenic carcinoma^7,9. The proposed route of spread is through the nonvalved vertebral venous plexus. Reflux occurs when interpleural or abdominal pressure is elevated, causing tumor cells to reach the intracranial venous plexus and finally migrate farther to the PNS ⁹ .

Metastasis of thyroid carcinomas to the PNS is rarely reported worldwide. There have been only isolated case reports of thyroid tumors metastatic to the paranasal sinuses (PNS)^2,3,5. The commonest histology reported is follicular carcinomas^5-7. The most frequently affected is the maxillary sinus followed by the sphenoid sinus^2,7. In 77% of cases, metastasis is found in a single paranasal sinus lesion ⁶ . There are no specific symptoms but the main complaint described is intermittent epistaxis^2,3.

Thyroglobulin level may serve as a good indicator to assist in monitoring of patients surgically treated for differentiated thyroid cancer. However, when thyroglobulin is undetectable, a degree of caution is advisable in the presence of thyroglobulin-antibodies ¹ .

Metastasic disease in differentiated thyroid carcinoma is a poor prognosis sign and their treatment requires careful consideration, as skull base involvement is not rare, thus often making surgical treatment impossible ⁵ . ¹³¹I therapy is considered to be the first line of treatment for distant metastases from thyroid carcinomas^1-3,5. Radical treatment by endoscopic endonasal surgery (EES) remains controversial and can be used for palliative treatment, for example, to relieve pain and control bleeding ¹⁰ . An exception is an isolated metastasis case, for which a radical ESS may be a viable option ² . In our case, metastasis of the thyroid carcinoma was found in the frontal sinus and frontal recess without any extra-sinusal extension. Decision of the extent of resection and its surgical margin remain difficult, as there is no consensus due to limited reported cases. Our decision to perform a Draf III technique was explained by better access to the different lesions and better control during follow-up. Further investigations are required for the surgical method for treating thyroid metastatic lesions in the PNS.

Conclusion

This report describes a case of PTC metastasis to the frontal sinus and frontal recess, managed through EES surgery. To our best knowledge, it is the first case of PTC metastatic to the frontal sinus and frontal recess described within the literature. Although rare, metastases should be included in the differential diagnosis in patients with sinus lesions and a history of PTC.

Further investigations are required for the surgical treatment of thyroid metastatic lesions in the PNS.
