Clinical and Pathologic Features of Neuronal Ceroid-Lipofuscinosis in a Ferret ( Mustela putorius furo )

History

A spayed female ferret was imported and kept with other young ferrets. There was no information concerning the pedigree of the ferret. At 3 months of age, the ferret showed ataxia and was isolated from the others because it was suspected to have an infectious disease. The clinical signs progressed gradually with additional signs including weight loss, dysphagia, swimming-like movements, tremors, diarrhea, and dysstasia appearing by 4 months of age. No aggressive behavior was recognized during the clinical course. Blood biochemistry and radiographic examinations revealed no abnormalities, except for a mild increase in the activities of liver enzymes (aspartate aminotransferase 301 units per liter, alanine aminotransferase 277 units per liter, and alkalinephosphatase 469 units per liter). Magnetic resonance imaging (MRI) examination with a T1-weighted image (MRP-7000 AD/AIRIS, Hitachi Medical, Tokyo, Japan) revealed severe dilation of the lateral ventricles and atrophy of the cerebral cortex. Because a poor prognosis was suspected, the animal was euthanatized. At necropsy, brain, heart, lung, gastrointestinal tracts, liver, pancreas, spleen, kidney, bladder, and lymph nodes were fixed in 10% formalin. Paraffin sections 2 μm thick were prepared and stained with hematoxylin and eosin (HE), PAS, LFB, Sudan black B, and Ziehl-Neelsen. Selected formalin-fixed tissues were postfixed in osmium tetroxide and embedded in epoxy resin. Immunohistochemical examinations were performed using Envision polymer reagent (Dako-Japan, Kyoto, Japan). Monoclonal antibodies against neurofilament (NF, prediluted, Dako-Japan), CDV-nuclear protein (CDV-NP, 1:200, VMRD, Inc, Pullman, WA), HLA-DR (1:25, Dako-Japan), rabbit polyclonal antibodies against glial fibrillary acidic protein (GFAP, prediluted, Dako-Japan), and Iba-1 (1:250, Wako, Osaka, Japan) were used. Rabbit origin polyclonal antibody against a synthetic peptide corresponding to the residues 1–11 of amino-terminal sequence of SCMAS (1:10, kindly provided by Dr J. Ezaki, Department of Biochemistry, School of Medicine, Juntendo University, Tokyo, Japan), ¹⁵ a monoclonal antibody against recombinant saposin of human origin (clone F-15, 1:100, Santa Cruz Biotechnology, Santa Cruz, CA), and rabbit polyclonal antibody against a recombinant fragment containing a sequence corresponding to a region within amino acids 72–262 of human cathepsin D (1:500, Abcam, Cambridge, UK) were also used as primary antibodies. For immunostaining with antibodies to SCMAS, saposin, and cathepsin D, paraffin sections from the brain of a 2-year-old female Border Collie affected by NCL caused by a mutation CLN5 ¹⁷ were used as a positive control.

Pathologic Findings

Severe lesions were found in the cerebrum; these lesions were characterized by marked cortical atrophy, neuronal loss, and diffuse astrogliosis (Fig. 1). Surviving neurons were shrunken, and these cells and macrophages sometimes contained pale pink intracytoplasmic pigments (Fig. 2). The pigments were positive for PAS (Fig. 3a), Sudan black B (Fig. 3b), and LFB (Fig. 3c) but negative for Ziehl-Neelsen. Those pigments exhibited a green autofluorescence under fluorescent microscopy (Fig. 4d). Electron microscopic examinations revealed the accumulation of electron-dense granular materials, approximately 100 to 500 nm in diameter, within the lysosomes of neurons and microglia (Figs. 4a and 4b). These characteristics of the pigments were consistent with those of ceroid-lipofuscin. Proliferating astrocytes exhibited morphological features of gemistocytic astrocytes with abundant eosinophilic cytoplasm and intense immunoreactivity to GFAP (Fig. 5a). A large number of Iba-1– and HLA-DR–positive microglia and macrophages were also diffusely present throughout the cerebral cortex (Fig. 5b). These phagocytic cells were filled with ceroid-lipofuscin. The immunostaining for NF revealed a marked decrease in axons and neurons in the cerebral cortex. In the hippocampus, thalamus, and brainstem, neurons were not diminished but contained variably intense intracytoplasmic accumulations of ceroid-lipofuscin. Astrocytes and microglia were moderately abundant in these regions; however, lesions were very mild compared with those in the cerebral cortex. In the cerebellum, there was a moderate decrease in numbers of Purkinje cells and granule cells with a mild to moderate diffuse accumulation of microglia and macrophages. There were ceroid-lipofuscin accumulations in Purkinje cells and phagocytes. Astrocytosis in the cerebellum was less prominent than that seen in the cerebrum. No CDV antigens were detected in the central nervous system (CNS) tissues.

OPEN IN VIEWER

Figure 1. Cerebral cortex; ferret. There are prominent diffuse accumulations of gemistocytic astrocytes and severe neuronal loss. HE stain.

Figure 2. Cerebral cortex; ferret. High-power magnification of the severely affected region of the cerebral cortex. Proliferations of gemistocytic astrocytes and pigment-laden macrophages (arrowheads) surround a shrunken neuronal cell (arrow). HE stain.

Figure 3. Cerebral cortex; ferret. The cytoplasmic pigments are positive for PAS (a), Sudan black B (b), and LFB (c) stain. These pigments exhibit a green autofluorescence by fluorescent microscopy (d).

Figure 4. Cerebral cortex, ferret. Accumulation of electron-dense granular materials within the lysosome of microglial cells (a). High-power magnification of the electron-dense granules (b). Transmission electron microscopy.

Figure 5. Cerebral cortex; ferret. A large number of GFAP-positive astrocytes (a) and Iba-1–positive microglial cells and/or macrophages (b) are observed in the cerebral cortex. Immunohistochemistry for GFAP (a) and Iba-1 (b).

Figure 6. Cerebral cortex (a and b), cerebellum (c), and medulla oblongata (d); ferret. Saposin immunostaining reveals a large number of immunopositive granules within macrophages/microglia and astrocytes in the severely affected cerebral cortex (a). Fine intracytoplasmic saposin-positive granules are also found in the neurons in the relatively preserved cerebral cortex (b), Purkinje and basket cells in the cerebellum (c), and large neurons in the medulla oblongata (d). Immunohistochemistry for saposin.

Ceroid-lipofuscin–laden macrophages were also observed in other visceral organs. These cells accumulated around the blood vessels and bronchi in the lungs and were multifocally present within hepatic sinusoids. Similar cells were observed in splenic and lymph node sinuses. There were no significant lesions in the heart, gastrointestinal tract, pancreas, kidneys, or urinary bladder.

After immunostaining for SCMAS, no significant immune-positive material was seen in the brain, lungs, or liver of the ferret, although in the control tissues (brain of NCL dog), many SCMAS-positive granules were found in macrophages and neurons that contained ceroid-lipofuscin. Saposin immunostaining revealed numerous immune-positive granules in the cytoplasm of neurons, astrocytes, microglia, and macrophages in the brain of the ferret. The number of saposin-positive granules increased with the degree of severity of the lesions. In the cerebral cortex, numerous saposin-positive granules were distributed mainly in microglia, macrophages, and astrocytes (Fig. 6a), and in the areas with mild lesions those granules were found also in surviving neurons (Fig. 6b). In the cerebellum, fine saposin-positive granules were mostly distributed in the cytoplasm of Purkinje cells, basket cells, and macrophages in the Purkinje cell layer (Fig. 6c). In the other brain regions, such as medulla oblongata, a small number of fine saposin-positive granules were found within the cytoplasm of neurons (Fig. 6d). In the brain of the NCL dog, saposin-positive granules were also found in the surviving neurons, but the number of affected cells was much less than those seen in the ferret brain, especially in the cerebrum. In the lungs and liver, there was no significant immunoreactivity for SCMAS or saposin. In the brains of both ferret and dog examined, cathepsin D immunostaining revealed intensely staining intracytoplasmic granules within the surviving neuron, whereas the immunopositive materials were reduced in the severely affected regions of the brain attributable to neuronal loss.

Discussion

Based on the clinical and pathological features in the present study, the ferret was diagnosed as affected by NCL. Clinical features of this ferret, such as onset at an early age and progressive neurological signs, are consistent with those of some types NCL reported in humans and other animals.^10,29 Antemortem MRI examination revealed severe cerebral atrophy with a marked ventricular dilation. The atrophic cerebrum was characterized by ceroid-lipofuscin deposition as well as very severe astrogliosis and neuronal loss. In dogs affected by NCL, brain atrophy with ventricular dilation has been observed by MRI examinations, ¹⁴ although these features also occur in aged dogs infected with CDV, a condition commonly termed “old dog encephalitis.” ⁷ However, early clinical onset, histopathological features, and absence of CDV antigens in the CNS rule out the possibility of the viral infection in the present case.

In the described ferret, the most prominent pathologic features are astrocytosis and severe neuronal loss in the cerebrum. The infiltration of microglia and macrophages was most severe in the cerebral cortex compared with other CNS regions. Such lesions might result from a severe inflammatory reaction rather than a direct effect of the neuronal ceroid-lipofuscin, because accumulation of the pigment was commonly observed throughout the CNS. In humans, different distribution patterns of lesions and severity of neuronal degeneration and glial activation among NCL subtypes have been recognized. ¹⁰ Although the subtypes have not been as well elucidated in animals affected by NCL, severe cerebral atrophy was reported in NCL of South Hampshire sheep affected by the mutation of the ovine NCL6 gene.^24,25 Oswald et al ²⁵ suggested that prominent activation of astrocytes and microglia precedes neuronal degeneration and that in this ovine NCL, the glial reaction is more important for neuronal loss than ceroid-lipofuscin accumulation. A similar hypothesis might explain the brain lesions seen in the affected ferret.

The results of immunohistochemical studies for SCMAS and saposin may indicate that the major storage materials in the brain of the ferret are saposins, as seen in humans with mutations in CLN1 or CLN10 ¹⁰ or the NCL affecting Miniature Schnauzers. ²⁶ Because the SCMAS antibody recognizes an epitope that is well preserved among mammals, ¹⁵ the lack of significant immunoreactivity for SCMAS in the brain of the ferret case is not likely due to species differences. Numerous SCMAS-immunopositive granules were found in the brain of the Border Collie dog affected by NCL caused by the mutation of canine homologue to CLN5, ¹⁸ whereas the number of saposin-immunopositive granules was much less than that seen in the ferret brain. In both humans and animals affected by some types of NCL, saposins A and D have been shown to be the major materials stored.^10,26,30 Because the saposin antibody used in this study could not precisely distinguish between saposin A, B, C, and D, further studies using more specific antibodies available for paraffin sections will be needed to confirm the specific saposins stored in the affected ferret. A deficiency of cathepsin D encoded by a mutated CLN10 gene has been known to cause NCL in both humans and animals.^2.10,30 In this study, cathepsin D immunostaining revealed intensely staining intracytoplasmic granules in surviving neurons throughout the brains of both the affected canine control tissues and the affected ferret. These findings may be due to the normal distribution of this protease in the ferret. Ceroid-lipofuscin–laden macrophages were observed also in other visceral organs, including the lung, liver, spleen, and lymph nodes, whereas those were negative for both saposins and SCMAS. These findings may indicate that these pigment-laden macrophages accumulate because of different pathological mechanisms.

Further studies, especially those focused on the type of NCL caused by the mutation of CLN1 gene, will be necessary to identify complete pathogenesis of this disease in ferrets. Although the biochemical and genetic characteristics remain unclear, the present study has more clearly demonstrated the unique clinical and pathological features of NCL in the ferret.
