A modified Gritti-Stokes amputation technique as a solution for recurring aseptic loosening of a knee arthroplasty: A single-patient case study

Background

When a patient is not able to function with a total knee arthroplasty (TKA), for example because of loosening of the arthroplasty, and revision of the TKA is no longer an option, amputation may be the solution. Either a transfemoral amputation (TFA) or a knee disarticulation (KD) with removal of the total knee, is possible. However, little is known about the outcome of a KD with removal of the total knee. Only one case study ¹ has described a KD in which the proximal part of the total knee was also removed, and the patella was attached to the anterior cruciate ligaments. The patient, an 89-year-old woman, was left with a fully weight-bearing residual limb, but apart from mention of limited household walking, no functional outcome was reported.

Another way to modify a KD, and thereby retain the advantages of a KD, such as an end-bearing residual limb, is to place the patella intercondylar beneath the femur, similar to a Gritti-Stokes amputation (GSA). In a GSA, the end of the femur is sawn through at the level of the adductor tubercle with a traditional right angle cut or with a sloped cut (upward and backward from the anterior aspect) to prevent the patella from slipping forward. The articular surface of the patella is sawn off. ² To keep the patella in place at the end of the femur, holes are bored through the edge of the patella and femur so that the patella can be stitched to it. ³ Alternatively, the patella is secured to the distal end of the femur by absorbable sutures through the joint capsule and into the soft tissues behind the femur, so there is no fixation through the bone itself. ²

GSA has varied in its popularity, and its use has been discussed among different surgeons and limb-fitting centers with concerns primarily about non-union of the patella, painful residual limb, and difficulties in fitting a satisfactory prosthesis.^2,4,5 However, the results for patients have been mainly positive,^{3,4,6 –8} raising questions as to why this technique has fallen out of favor.

The aim of this case study was to describe the amputation technique and the functional outcome 1 year post-surgery in a young, still-working patient, who suffered from persistent knee pain and poor physical functioning due to recurring aseptic loosening of his revised TKA. A secondary aim was to evaluate if the residual limb resulting from GSA is indeed end-bearing.

Case description

Treatment surgery technique

The surgery technique consisted of removing the TKA (both the tibial and femoral implants), automatically leading to shortening of the amputation level and a slight angulation of the femoral condyle transection in order to prevent the patella from slipping forward. Also, the overlying cartilage and subchondral surfaces of both the patella and femur were removed to create a well-perfused bony surface. Because of the emerged central intercondylar cavity and weakened remaining condyles, the patella was placed intercondylar, beneath the femur. While in the normal GSA, the patella itself is sutured to the distal end of the femur, we stitched the patella tendon to the posterior knee capsule to create an end-bearing distal surface. We defined this as a modified GSA (Figure 1).

OPEN IN VIEWER

Figure 1.

X-ray of the residual limb, with the patella placed intercondylar, beneath the femur. On the left the anterior–posterior image, on the right the lateral image.

Outcomes

Data were collected retrospectively by analysis of the patient records. The prosthesis consisted of the following components: seal in liner X5, rigid closed outer socket (without ischial weight-bearing), 3R80 knee (Otto Bock), and Vari-Flex foot (Össur). In this way, the residual limb was fully end-bearing. After 3 weeks of inpatient and 4 months of outpatient rehabilitation, the patient was able to walk with his prosthesis on level surfaces without a walking aid and at longer distances outside with a cane. Functional outcome measurements at the end of the rehabilitation phase were as follows: 6 minute walking test 326.4 m, L-test 24.09 s, and Four Square Step Test 11.7 s. ⁹

At 1-year post-surgery, the patient had no residual limb pain with the full end-bearing socket, no residual limb problems, and no signs of patella fusion failure. He wore his prosthesis during the entire day. He could walk without pain for distances up to 2 km outside without using a walking aid, was able to climb stairs step by step (i.e. a typical community ambulator: able to walk at a variable cadence and to traverse most environmental barriers) and to cycle (<6 km) on a regular grandma bike with adaptation of the pedal (toeclip). He also engaged in exercise, walking on a treadmill (6 km) and handbiking, three times a week. He was independent in daily life and household activities such as taking a shower, getting dressed, vacuum cleaning, setting the table, and cooking while standing. He was satisfied with these activities. For his driver’s license, he needed a new medical examination and the accelerator pedal needed to be transposed to the left side. His next focus was work reintegration, and he was pursuing a different line of work.

Conclusion

This case report describes a modified GSA for a patient who experienced recurring loosening of a TKA. The procedure resulted in a pain-free and fully end-bearing residual limb with good functional outcome at 1-year follow-up.

Opinion on the GSA is divided in the literature. Some surgeons recommend it, others strongly condemn it. In this single-patient case study, in which a KD was no longer an option, we compared the GSA with the TFA. For both amputation techniques, a longer residual limb length is preferred because thigh muscle function is better preserved, which reduces the risk of hip flexion ³ and abduction contractures, especially when amputating at or below the Hunter’s canal level, to preserve the function of the proximal part of the adductor. ¹⁰ Greater leverage results in reduced metabolic expenditure during ambulation and more stability for sitting and facilitating transfers.^3,7

Specific advantages and disadvantages of the GSA, mentioned in the literature, are shown in Table 1. Despite the majority of these arguments being in favor of a GSA, the GSA is not widely performed anymore. ³ Surgeons became unfamiliar with this amputation technique. Its disuse partly stems from its poor reputation of painful non-union of the patella with poor prosthetic fitting.^2,3,5

OPEN IN VIEWER

Table 1.

Specific advantages and disadvantages of the Gritti-Stokes amputation.

Advantages of the GSA over TFA

Disadvantages of the GSA

- Preservation of the collateral blood supply around the knee, including the superior genicular system, which helps to preserve the skin flaps and potentially results in increased healing rates3,6,7 - Minimal muscle tissue division—tendons rather than muscle mass are cut3,4 - Low blood loss as a result of the minimal muscle tissue division and a less sharp bony edge in direct contact with the muscles, leading to less muscle injury and possibly bleeding 8 - An end-bearing residual limb, resulting in an end-bearing prosthesis without the need for ischial tuberosity weight-bearing, and the possibility to use an open outer socket which is lighter and more comfortable (especially during sitting) with a better degree of proprioception3,4 - In cases of bilateral GSA, the ability to turn over in bed unaided and move around at home on the knees, gives extra mobility and independence 2 - When the amputation is below or through the level of the femoral condyles, a bulbous residual limb will suspend the prosthesis well and prevent it from rotating 6 - Early postoperative mobilization and rehabilitation, with a preliminary pylon to be fit within a few weeks as a result of the limited degree of residual limb shrinkage and molding3,4 - A reduced need for assistive devices for mobilization 7

- High peak loads during weight-bearing, with possible failure of patella union 5 - Loss of an end-bearing residual limb when the remaining portion of the patella fails to fuse 11 - Long-term residual limb problems 3 - Difficulty in fitting a cosmetically attractive prosthesis3,5 - Longer time needed for prosthetic fitting 5

GSA: Gritti-Stokes amputation; TFA: transfemoral amputation.

The disadvantages described in italics are discussed in the discussion section.

To overcome the disadvantages of the GSA, it is important to achieve a fusion between the patella and the femoral condyles. Fusion can only be achieved by (1) complete removal of the overlying cartilage and subchondral surfaces of both the patella and femur and (2) creating a stable patella fixation by tensioning the patella over the distal femoral surface. If there is any doubt, consolidation/non-union can best be determined by a computed tomography (CT) scan. Once there is union, high peak loads on the patella during weight-bearing should not be a problem, as the patella is already the most loaded surface within the human body, capable of withstanding cyclic loading up to three to five times body weight during normal stair climbing and running. ¹² The prosthetic fitting problems and cosmetic issues have become less important with the development of modern prosthetic knee mechanisms. ⁵

A limitation of this single-patient case study is that we did not have functional outcome measurement data before the amputation to compare between pre- and post-amputation, and we were unable to compare our results to an alternative therapy, such as a knee arthrodesis. Our patient had no peripheral vascular disease, which is, in general, the main cause for amputation. It should be investigated whether a vascular patient could also benefit from a modified GSA. In the future, we recommend measuring mobility and psychosocial outcomes for persons with a lower limb amputation, before and after amputation in a case series of TKA failure leading to a modified GSA. Because of the many important advantages of the GSA, we suggest this technique might be reintroduced and given more consideration as an alternative to the TFA.

In conclusion, a modified GSA was earlier only described as an ultimate therapy for an older patient with limited walking ability and loosening of a TKA and is now for the first time described in a young and working patient suffering from recurring loosening of a (revised) TKA. The modified GSA technique created a pain-free and end-bearing residual limb, and good functional outcome, by achieving functional rehabilitation goals to the patient’s satisfaction. We hope that this case report will highlight the modified GSA as option for treatment.
