Energy-aware resource service scheduling based on utility evaluation in cloud manufacturing system

Abstract

In order to realize the manufacturing resource sharing and optimal allocation, many advanced manufacturing modes and technologies have been proposed and researched, but few works have been emphasized on resource service and capability transaction and scheduling management. With these conditions, in this article, the concept of cloud manufacturing mode is first briefly introduced, and a general cloud manufacturing resource service scheduling model is established. Then, the comprehensive utility models, which consider energy consumption, cost, and risk for the three sides (i.e. provider, consumer, and operator), are established in the resource service scheduling process in cloud manufacturing system. Four kinds of resource service scheduling modes, which are provider centered, consumer centered, operator centered, and system centered, are studied. These modes are based on the utility models that are investigated, as well as the system-centered cooperative scheduling method that is designed with risk-sharing strategy. The experimental results show that the system-centered scheduling method has the highest potential for realizing the aim of cloud manufacturing, and the system-centered cooperative scheduling method is rational to obtain the higher maximal utilities of the whole system and the three key users at the same time. It promotes the higher efficiency and utility, a higher rate of sharing, green and on-demand use of decentralized manufacturing resources and capability services in cloud manufacturing systems.

Keywords

Cloud manufacturing resources service scheduling utility evaluation system-centered scheduling energy aware

Introduction

In order to realize the manufacturing resource sharing and optimal allocation, many advanced manufacturing modes and technologies have been proposed, including networked manufacturing (NM),^1,2 application service provider (ASP),^3–5 manufacturing grid (MGrid),^6–13 industrial production-service system (IPS²),¹⁴ crowd sourcing, sustainable manufacturing (SM),^15,16 service-oriented manufacturing (SOM),^17,18 and similarly related. However, there still exist many bottlenecks to farther and optimally allocate manufacturing resource and to realize the full sharing and circulation of manufacturing resource and capability.¹⁹ At the same time, some new technologies have emerged⁶ and have been widely applied in various fields, such as cloud computing,^20,22 high-performance computing (HPC), ubiquitous computing, service-oriented technologies (e.g. service-oriented architecture (SOA),^23–27 web service,²⁸ semantic web, and ontology), Internet of thing (IoT),^29,30 and so forth. These technologies are the enabling force for effectively addressing the above-mentioned bottlenecks in manufacturing.

Combining the above-mentioned new technologies and existing theories and technologies of current enterprise informatization, cloud manufacturing (CMfg) as a computing and SOM mode has been proposed.¹⁹ The concept, architecture, core enabling technologies, and typical characteristics of CMfg are discussed, and four typical CMfg service platforms are investigated in the author’s previous works.¹⁹ The basic principle for CMfg model is illustrated in Figure 1.¹⁹ There are primarily three classes of users in CMfg system, resource service providers, consumers, and operator:¹⁹

A provider owns various manufacturing resources and capabilities involved in the whole life cycle of manufacturing. It publishes and registers its idle resource, product, and manufacturing capability to the CMfg platform and provides manufacturing resource and capability service which consumer requires. The provider can be a person, an organization, an enterprise, or a third party.

A consumer is the subscriber of the available resource service and capability in CMfg platform. It searches the optimal manufacturing resource and capability service and purchases the use of service on an operational expense according to their demands.

A operator operates the whole of CMfg platform to deliver services, capabilities, and functions to providers, consumers, and the third parties. They deal with the organization, sale, licensing of manufacturing resource, and capability service and provide, update, and maintain the technologies and services involved in the operations of the platform.

Figure 1.

Abstract architecture of cloud manufacturing.¹⁸

With the thought of “the distributed resources are integrated to be managed, and the integrated resources are distributed to be used” and the aim of higher efficiency and utility, higher rate of sharing, green and on-demand use of manufacturing resource and capability service in the operation of CMfg system, providers provide the available manufacturing resources and capabilities, consumers use the available services to execute their manufacturing tasks in the whole life cycle of products, and operator allocates providers’ services and matches them with consumers’ tasks.

Apparently, before the CMfg model or system has been fully accepted and used by users/enterprises and has been successfully and widely applied in manufacturing industry, the profit for each user using the system should be fully considered and guaranteed, especially for the providers and consumers.

However, the existing research emphases of current SOM models or systems (e.g. ASP, NM, and MGrid) are primarily (a) architectures;⁷ (b) modeling, service encapsulation, and digital description;³¹ and (c) task and workflow management,^32–36 service search and match,³⁷ optimal selection,^38,39 and service composition.^8,40–46 Few works have been emphasized on the allocation and transaction management of manufacturing resource and capability service, such as (a) manufacturing resource service cost management, (b) method for payments, (c) resource service transaction process monitoring management, (d) benefit guaranteeing mechanisms and optimal allocation methods for providers and consumers, (e) utility adding among consumer, provider, and operator, and so on. Then, it leads to that both provider and consumer lose their interest and enthusiasm to use the system, and the application of the above-mentioned proposed advanced manufacturing modes is hindered. Therefore, resource service optimal allocation and scheduling based on users’ utility evaluation are the key points to solve the above-mentioned problems in CMfg system and to achieve the higher utility of the whole system and improve the profits and positivity of the users.

However, at one time spot of the system’s operation, there are multiple consumers submitting the same functional manufacturing task requirements to the platform. Oriented to the same functional demands of multiple different consumers, there are many services provided by different providers in the virtual resource pool (i.e. manufacturing cloud) satisfying the requirement. Different from the existing advanced manufacturing modes, the large-scale resource service scheduling problem based on utility evaluation in the triple (i.e. providers, consumers, and operator) operation mode is the key point to promote the ratification and application of the CMfg mode and its service platform. This challenge is to figure out the reasonable mapping of large-scale services and requirements considering different and comprehensive scheduling objective (i.e. utility) of the whole system and the triple users. The comprehensive evaluation, utility, is used to present the shorter time, the better quality, the lower cost, the fewer energy consumption, the higher flexibility, the richer knowledge, and other comprehensive evaluation indexes. The higher utility presents the higher efficiency of a CMfg system and the better enterprise competitive power of the users.

Hence, in order to promote the three users’ comprehensive utility in a CMfg system, reduce the whole energy consumption, and make some contributions to the realization of green manufacturing (GM), so as to enable the CMfg system to be accepted and used in practice, resource service allocation and scheduling management with the objective of achieving the higher utility are carried out.

The rest of this article is organized as follows: A brief analysis of the related works is given in section “Related works.” Section “Problem description” presents the description of resource service scheduling problem in CMfg system. Section “Utility models for the provider, consumer, and operator” presents the general utility model and the detailed utility models for providers, consumers, and operator. In section “Resource service scheduling methods and comparisons,” the methods and experiments compared with utilities under the four scheduling methods (i.e. provider centered, consumer centered, operator centered, and system centered) are provided. Based on the above experiments, the next discussions and experiments about the provided models of utility with the system-centered cooperative scheduling method are given in section “System-centered cooperative scheduling method and experiments.” Section “Conclusions and future works” concludes this article and points out some future works.

Related works

The existing researches on manufacturing resource allocation and scheduling management in the advanced manufacturing systems are various, and most of these works can be classified into two categories: scheduling models and scheduling methods. In terms of scheduling models or contents, the existing studies on manufacturing resource allocation and scheduling primarily focus on the following aspects: (a) computing resource scheduling,^47–59 (b) supply chain scheduling,^60–65 (c) job-shop scheduling,^66–70 and (d) other related manufacturing enterprise resource service scheduling and allocation fields.^71–76

Furthermore, there are many attributes or criteria, which have been considered in resource allocation and scheduling in different studies. These attributes are primarily classified into the following five categories:

Cost-related indices,^{48,50–52,60–64,68,75} including material cost, storage cost, transportation cost, inventory holding and delivery cost, operational cost, and so on.

Time-related indices,^{47,50–52,67,70} including makespan of tasks, tardiness, reaction time, due date, efficiency, delivery time, and so on.

Risk-related indices,^51,75 including political stability, task execution risk, operational risk, performance of service or system, and so on.

Quality-related indices,^{53,54,73–75} including quality of service (QoS), capability level, and so forth.

Other indices, including execution rate of tasks,⁵³ utilization rate of services,^48,49,53 reputation,⁷⁵ energy consumption or carbon emission,^{47,55–57,77} and so on.

Different from the above scheduling models, resource service scheduling problem in a CMfg system includes the scheduling of hardware resource service, software resource service, capability service, product service, and so forth. The evaluation indices of the economic efficiency and performance of those various services are much more complex. However, from the above evaluation index categories, it is obvious that (a) it selects different multiple evaluation indices for different types of resource service scheduling; (b) more the evaluation indexes selected, better the scheduling method; and (c) the target of GM and SM makes the index of energy consumption more and more important.

Besides, in CMfg system, the on-demand use of manufacturing resource service is presented as not only the high-efficient and optimal quantity allocation of services, but also the optimal function and utility allocation of services. Then, the comprehensive utility evaluations based on the multiple indexes (i.e. time, quality, cost, energy, flexibility, and knowledge) for providers, consumers, operator, and system in CMfg are much more concerned by users. Then, the comprehensive evaluation criterion “utility” is attached with more and more importance by decision makers. Therefore, combining the target of multi-objective optimization scheduling, the concept of comprehensive evaluation criterion “utility” considering the key index of “energy” is provided in this article. Then, it is used to characterize the evaluation of multi-objective optimal scheduling and the economic efficiency and system performance of different manufacturing resource services.

In the aspect of scheduling methods, the existing researches concentrate on using intelligent optimization algorithms to solve the self-centered individual optimal scheduling problem, that is, to realize the optimization of evaluation for themselves. For example, the consumer-driven and consumer-centered scheduling is to achieve the maximal evaluation objective of consumer,^52,60,61 the provider/supplier-centered scheduling is to obtain the maximal evaluation objective of provider/supplier,^{63,64,67,68,70} and the operator/distributor-centered scheduling is to pursue the evaluation objective of operator/distributor.^62,78 However, different individual optimal scheduling methods are contradictory. Therefore, it needs to obtain the equilibriums among the different individual optimizations and the whole cooperative optimization scheduling of system in CMfg system. As for CMfg system and other SOM systems, few works have been emphasized on how to promote the profit for the three users using these systems. It results in the interest of provider is not effectively guaranteed, and providers do not want to provide and contribute their available manufacturing resource and capability, or they have no positive motivation to provide high-quality and reliable resource services. Consequently, without adequate, available, high-quality, and reliable manufacturing services, consumers’ requirements cannot be satisfied. Therefore, both providers and consumers lose their interest and enthusiasm to use these systems. The deeper development, wider practice, and application of these systems are hindered.

In summary, from the above analysis on scheduling models and scheduling methods, in order to analyze and promote different types of users’ comprehensive utility in CMfg, to map the large-scale resource services with task requirements, and to realize GM and SM with the higher efficiency and utility, there are following four innovative contributions in this article compared to the existing research:

Considering the triple users in the operations of CMfg system (providers, consumers, and operator), the resource service scheduling problem of CMfg system is analyzed, and the general model of this scheduling problem is presented with the thought of “the distributed resources are integrated to be managed, and the integrated resources are distributed to be used.”

The concept of utility and the evaluation index system of comprehensive utility are investigated, as well as the utility models for the system and each user (i.e. providers, consumers, and operator). It can help to realize the objective of GM and SM and reasonably evaluate the different users’ economic efficiency and system performance in the process of different manufacturing services providing, execution and allocation, and so on.

It is found that the system-centered scheduling method meets the system aim of CMfg after comparing it with the other three scheduling methods. It leads the system to obtain the maximal utility value and leads the triple users to obtain the second biggest utility value, which are close to their ideal or expected maximal utility value. Based on the above research, the system-centered cooperative scheduling method with risk-sharing strategy is designed to realize the higher utility and well win-win of the whole system and the triple users in CMfg system.

Experiments are conducted and discussed to verify the above models and methods of resource service scheduling in CMfg system.

Problem description

The resource service scheduling problem in CMfg platform, which is worked out in this article, is the combinational optimization problem to allocate which service of which provider for which manufacturing task of which consumer. This scheduling problem consisting of multiple providers (N providers), one operator, and multiple consumers (M consumers) is studied, as shown in Figure 2. It just considers the same functional manufacturing task and service scheduling problem here, and in the practical industry application, it can be divided into many kinds of the same functional task and service scheduling problems. Facing with the tasks with the same service function requirements submitted by different consumers, there are many services provided by different providers to execute them. At one time spot, let the service requirements submitted by consumer j to the platform be k_j (k_j = 1, 2, …, Q_j), and the services provided by provider i be k_i, of which there are n_i services can satisfy the functional requirements of k_j. The problem of resource service scheduling to be investigated is to find an allocation solution (i.e. a mapping between k_i and k_j) to maximize the comprehensive utility of the whole system under multiple objectives (e.g. minimization cost, energy consumption and risk, and maximization reliability) and multiple constraints.

Figure 2.

Resource service scheduling abstract model in CMfg.

In order to address the above problem, the concept of utility is introduced. In this article, the utility is defined as the comprehensive evaluation criteria to evaluate the comprehensive benefit for a user (e.g. consumer, operator, and provider) and the system. It is affected and computed by many factors including cost, time, reliability, energy consumption, risk, and so on.

In order to further describe the problem, a general resource service scheduling model for the problem is presented as follows:

Indices

l = 1, 2, …, L: criteria of utility

i = 1, 2, …, N: providers

j = 1, 2, …, M: consumers

k_i = 1, 2, …, n_i: the services of provider i that meet the functional requirement of consumers

k_j = 1, 2, …, Q_j: service requirements of consumer j

Parameters

U: utility

U_l: utility of the criterion l

${U_{l}}^{0}$ : presupposed expectation of criterion l

w_l: weight of U_l, and $\sum_{l = 1}^{L} w_{l} = 1$

$A_{i} = {a_{i k_{i}}}_{1 \times n_{i}}$ : service selected matrix of provider i

$A = {A_{1}, A_{2}, \dots, A_{i}, \dots, A_{N}} = {a_{i k_{i}}}_{1 \times \sum_{i = 1}^{N} n_{i}}$ : whole service selected matrix of providers

$B_{j k_{j}} = {b_{i k_{i}}^{j k_{j}}}_{1 \times \sum_{i = 1}^{N} n_{i}}$ : service execution matrix of the service k_i of provider i for the requirement k_j of consumer j

$B_{j} = {B_{j 1}, B_{j 2}, \dots, B_{j k_{j}}, \dots, B_{j Q_{j}}}^{T} = {b_{i k_{i}}^{j k_{j}}}_{Q_{j} \times \sum_{i = 1}^{N} n_{i}}$ : service execution matrix of the service k_i of provider i for the requirements of consumer j

$B = {B_{1}, B_{2}, \dots, B_{j}, \dots, B_{M}}^{T} = {b_{i k_{i}}^{j k_{j}}}_{\sum_{j = 1}^{M} Q_{j} \times \sum_{i = 1}^{N} n_{i}} :$ total service execution matrix of the service k_i of provider i for the requirements of all consumers.

Decision variables

$Sol = {i_{k_{i}}, j_{k_{j}}}$ when $b_{i k_{i}}^{j k_{j}} = 1$ : it means that the service k_i of provider i is executed for the service requirement k_j of consumer j, where the service selected elements

a_{i k_{i}} = {\begin{matrix} 1 The service k_{i} of provider i is to be called \\ 0 The service k_{i} of provider i is not to be called \end{matrix}

and the service allocation elements

b_{i k_{i}}^{j k_{j}} = {\begin{matrix} 1 & The service k_{i} of provider i is to be executed for requirement k_{j} of consumer j \\ 0 & The service k_{i} of provider i is not to be executed for requirement k_{j} of consumer j \end{matrix}

Objective function

\max (U) = \sum_{l = 1}^{L} w_{l} U_{l} (a_{i k_{i}}, b_{i k_{i}}^{j k_{j}})

(1)

Constraints

Because the whole resource service requirement quantity of consumers is $Q = \sum_{j = 1}^{M} Q_{j}$ , so there are following five constraints

\sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} a_{i k_{i}} = Q

(2)

\sum_{k_{j} = 1}^{Q_{j}} \sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} b_{i k_{i}}^{j k_{j}} = Q_{j}

(3)

\sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} b_{i k_{i}}^{j k_{j}} = 1

(4)

\sum_{j = 1}^{M} \sum_{k_{j} = 1}^{Q_{j}} b_{i k_{i}}^{j k_{j}} = a_{i k_{i}}

(5)

U_{l} (a_{i k_{i}}, b_{i k_{i}}^{j k_{j}}) \geq {U_{l}}^{0}

(6)

Constraint (2) denotes that the number of the selected services must equal the whole requirements, and constraint (3) means each requirement of consumer j should be allocated a service. Constraint (4) supposes one and only one service is needed for each requirement. Constraint (5) means the service execution matrix of the whole requirements of all consumers is the same as the total service selected matrix. Constraint (6) shows that the specific evaluation criteria l have the presupposed expectation. In this article, it assumes that one service is not permit to be used repeatedly at the same time spot.

Utility models for the provider, consumer, and operator

General model of utility

A series of criteria are involved in the utility as introduced in section “Problem description.” Because one of the initial aims of CMfg is to decrease the cost, energy, and risk, therefore, they are considered as the primary criteria in the utility (i.e. U) for each user in this article, and let U = f(Cost, Energy, Risk), which is evaluated using the following formulation

\begin{matrix} U = w_{C} U_{C} + w_{E} U_{E} + w_{R} U_{R} \\ = w_{C} e^{- λ_{C} C} + w_{E} e^{- λ_{E} E} + w_{R} (1 - R) \end{matrix}

(7)

where

U_C = f(FC, VC), U_E = f(DE, SE), and U_R = f(OR, SR) express the utility evaluation functions of the cost, energy, and risk, respectively, which are the functions of parameters $a_{i k_{i}} and b_{i k_{i}}^{j k_{j}}$ .

FC and VC denote the fixed cost and variable cost, DE and SE denote the daily energy and service additional energy, and OR and SR denote the operation risk and service-related risk of each kind of user. The detailed utility constitution of each kind of a user (i.e. provider, consumer, and operator) is shown in Table 1.

$λ_{C}$ and $λ_{E}$ denote the correction coefficient of cost and energy, $0 < λ_{C}, λ_{E} < 1$

$w_{C}$ , $w_{E}$ , and $w_{R}$ are the weights of $U_{C}$ , $U_{E}$ , and $U_{R}$ , respectively

Table 1.

Utility constitution of provider, consumer, and operator.

User	Criterion	Symbol	Description
Provider i (for the service k_i)	Cost	FC	Basic operation cost FC_i
		VC	Cost of service publication $p c_{i k_{i}}$
			Cost of service maintenance $m c_{i k_{i}}$
			Cost of service provided for the $k_{j}$ requirement of j ${dc}_{i k_{i}}^{j k_{j}}$
	Energy	DE	Basic daily energy $D E_{i}$
		SE	Energy of service material $m e_{i k_{i}}$
			Energy of service hydropower resource $r e_{i k_{i}}$
	Risk	OR	Operation risk
		SR	Risk of service provided for the $k_{j}$ requirement of j ${dr}_{i k_{i}}^{j k_{j}}$
Consumer j	Cost	FC	Basic operation cost $F C_{j}$
		VC	Cost of service calling for the $k_{j}$ requirement ${ic}_{i k_{i}}^{j k_{j}}$
			Cost of service logistics for the $k_{j}$ requirement ${lc}_{i k_{i}}^{j k_{j}}$
	Energy	DE	Basic daily energy $D E_{j}$
		SE	Energy of service hydropower resource for the $k_{j}$ requirement ${re}_{i k_{i}}^{j k_{j}}$
	Risk	OR	Operation risk
		SR	Risk of service invocation for the $k_{j}$ requirement ${ir}_{i k_{i}}^{j k_{j}}$
Operator	Cost	FC	Basic platform operation cost $O C_{o}$
		VC	Cost of service scheduling for the service k_i to the $k_{j}$ requirement of j ${ac}_{i k_{i}}^{j k_{j}}$
	Energy	DE	Basic platform energy PE
		SE	Unit additional energy of service scheduling SE
	Risk	OR	Risk of platform operation OR
		SR	Risk of service scheduling for the service k_i to the $k_{j}$ requirement of j ${ar}_{i k_{i}}^{j k_{j}}$

System of comprehensive evaluation indices

The comprehensive evaluation index system describes the constitutions of utility. The specific utility constitutions (i.e. cost, energy, and risk) of provider, consumer, and operator and the explanations are described in Table 1. Either as the providers, consumers, and operator, the cost criteria include the basic fixed operation cost and some service-related costs; the energy criteria include the basic daily energy and the service-related energy consumptions; the risk criteria also contain the operation risk and the service-related execution risks. The detailed criteria of the service-related cost, energy, and risk are evaluated, as the criteria shown in Table 1.

According to the general model of utility and the above analyses of specific utility constitutions of the triple users, the specific utility models of provider, consumer, and operator are researched in sections “Utility model for provider,”“Utility model for consumer,” and “Utility model for operator.”

Utility model for provider

The set of providers’ utilities is formulated as equation (8), the element of the providers’ utility matrix $U_{i}$ is the specific utility of provider i

UP = {U_{i}}_{1 \times N}

(8)

As to the specific provider i, from the above analyses of the specific utility constitutions, the cost of provider consists of the basic operation cost and the related cost of service (i.e. service publication cost, service maintenance cost, and service providing cost). Then, the cost of provider i, $C_{i}$ , is

C_{i} = F C_{i} + \sum_{k_{i} = 1}^{n_{i}} a_{i k_{i}} (p c_{i k_{i}} + m c_{i k_{i}} + \sum_{j = 1}^{M} \sum_{k_{j} = 1}^{Q_{j}} b_{i k_{i}}^{j k_{j}} d c_{i k_{i}}^{j k_{j}})

(9)

The energy consumption of provider i, $E_{i}$ , includes the basic daily energy of provider, the service-related material energy, and the service-related hydropower resource energy

E_{i} = D E_{i} + \sum_{k_{i} = 1}^{n_{i}} a_{i k_{i}} (m e_{i k_{i}} + r e_{i k_{i}})

(10)

Considering the service-related providing risk, the risk of provider i is

R_{i} = 1 - \prod_{k_{i} = 1; b_{i k_{i}}^{j k_{j}} = 1}^{n_{i}} (1 - {dr}_{i k_{i}}^{j k_{j}})

(11)

According to the above formulas (9)–(11), the utility of provider i is

U_{i} = w_{C} e^{- λ_{C} C_{i}} + w_{E} e^{- λ_{E} E_{i}} + w_{R} (1 - R_{i}) = (\begin{matrix} w_{C} e^{- λ_{C} (F C_{i} + \sum_{k_{i} = 1}^{n_{i}} a_{i k_{i}} (p c_{i k_{i}} + m c_{i k_{i}} + \sum_{j = 1}^{M} \sum_{k_{j} = 1}^{Q_{j}} b_{i k_{i}}^{j k_{j}} d c_{i k_{i}}^{j k_{j}}))} + \\ w_{E} e^{- λ_{E} (D E_{i} + \sum_{k_{i} = 1}^{n_{i}} a_{i k_{i}} (m e_{i k_{i}} + r e_{i k_{i}}))} + \\ w_{R} (\prod_{k_{i} = 1; b_{i k_{i}}^{j k_{j}} = 1}^{n_{i}} (1 - d r_{i k_{i}}^{j k_{j}})) \end{matrix})

(12)

Utility model for consumer

The set of consumers’ utilities is formulated as equation (13), and the element of the consumers’ utility matrix $U_{j}$ is the specific utility of consumer j

UC = {U_{j}}_{1 \times M}

(13)

Similarly to the provider, except of the basic operation cost, the cost of consumer still consists of the service invoking cost, service logistics cost, and so forth. Then, the cost of consumer j, $C_{j}$ , is

C_{j} = F C_{j} + \sum_{k_{j} = 1}^{Q_{j}} \sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} b_{i k_{i}}^{j k_{j}} ({ic}_{i k_{i}}^{j k_{j}} + {lc}_{i k_{i}}^{j k_{j}})

(14)

In addition to the energy consumption of provider i, the energy consumption of consumer j, $E_{j}$ , is formulated as follows

E_{j} = D E_{j} + \sum_{k_{j} = 1}^{Q_{j}} \sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} b_{i k_{i}}^{j k_{j}} {re}_{i k_{i}}^{j k_{j}}

(15)

The risk of consumer j, $R_{j}$ , is computed by considering the service-related invocation risk

R_{j} = 1 - \prod_{k_{j} = 1; b_{i k_{i}}^{j k_{j}} = 1}^{Q_{j}} (1 - {ir}_{i k_{i}}^{j k_{j}})

(16)

According to the above formulas (14)–(16), the utility of consumer j is

\begin{matrix} U_{j} = w_{C} e^{- λ_{C} C_{j}} + w_{E} e^{- λ_{E} E_{j}} + w_{R} (1 - R_{j}) \\ = (\begin{matrix} w_{C} e^{- λ_{C} (F C_{j} + \sum_{k_{j} = 1}^{Q_{j}} \sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} b_{i k_{i}}^{j k_{j}} ({ic}_{i k_{i}}^{j k_{j}} + {lc}_{i k_{i}}^{j k_{j}}))} + \\ w_{E} e^{- λ_{E} (D E_{j} + \sum_{k_{j} = 1}^{Q_{j}} \sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} b_{i k_{i}}^{j k_{j}} {re}_{i k_{i}}^{j k_{j}})} + \\ w_{R} (\prod_{k_{j} = 1; b_{i k_{i}}^{j k_{j}} = 1}^{Q_{j}} (1 - {ir}_{i k_{i}}^{j k_{j}})) \end{matrix}) \end{matrix}

(17)

Utility model for operator

Regarding to the operator, the cost constitution contains the basic operation cost of CMfg service platform and the service-related scheduling cost. The cost of operator $C_{o}$ is

C_{o} = O C_{o} + \sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} a_{i k_{i}} (\sum_{j = 1}^{M} \sum_{k_{j} = 1}^{Q_{j}} b_{i k_{i}}^{j k_{j}} {ac}_{i k_{i}}^{j k_{j}})

(18)

The energy consumption of operator $E_{o}$ is mainly consisted of two parts: one being the basic energy of platform operation and the other being the additional energy of service scheduling with the service scheduling quantity $Q$

E_{o} = PE + Qse

(19)

Different from the risk of provider and consumer, the risk of service platform operation is important for operator; then, the risk of operator $R_{o}$ includes the risk of service platform operation and the risk of the related service scheduling

R_{o} = 1 - (1 - O R) \prod_{i = 1}^{N} \prod_{k_{i} = 1; b_{i k_{i}}^{j k_{j}} = 1}^{n_{i}} (1 - a r_{i k_{i}}^{j k_{j}})

(20)

According to the above formulas (18)–(20), the utility of operator is

\begin{matrix} U_{o} = w_{C} e^{- λ_{C} C_{o}} + w_{E} e^{- λ_{E} E_{o}} + w_{R} (1 - R_{o}) \\ = (\begin{matrix} w_{C} e^{- λ_{C} (O C_{o} + \sum_{i = 1}^{N} \sum_{k_{i} = 1}^{n_{i}} a_{i k_{i}} (\sum_{j = 1}^{M} \sum_{k_{j} = 1}^{Q_{j}} b_{i k_{i}}^{j k_{j}} {ac}_{i k_{i}}^{j k_{j}}))} + \\ w_{E} e^{- λ_{E} (PE + Qse)} + \\ w_{R} ((1 - OR) \prod_{i = 1}^{N} \prod_{k_{i} = 1; b_{i k_{i}}^{j k_{j}} = 1}^{n_{i}} (1 - {ar}_{i k_{i}}^{j k_{j}})) \end{matrix}) \end{matrix}

(21)

Resource service scheduling methods and comparisons

Based on the above energy-aware utility evaluation models and the resource service scheduling problem model, the following analysis and comparisons are on the different resource service scheduling methods.

Resource service scheduling methods

In the resource service allocation and scheduling process, the following four types of scheduling modes can be used:

Consumer-centered resource service scheduling mode. It aims to maximize the utilities of the consumers, and its objective function is equation (22) with constraints (2)–(6)

\max (U_{c}) = w_{C} e^{- λ_{C} \sum_{j} C_{j}} + w_{E} e^{- λ_{E} \sum_{j} E_{j}} + w_{R} (\prod_{j} (1 - R_{j}))

(22)

Provider-centered resource service scheduling mode. It aims to maximize the utilities of the providers, and its objective function is equation (23) with constraints (2)–(6)

\max (U_{p}) = w_{C} e^{- λ_{C} \sum_{i} C_{i}} + w_{E} e^{- λ_{E} \sum_{i} E_{i}} + w_{R} (\prod_{i} (1 - R_{i}))

(23)

Operator-centered resource service scheduling mode. It aims to maximize the utility of the operator, and its objective function is the maximization of equation (21) (i.e. $\max (U_{o})$ ) with constraints (2)–(6).

System-centered resource service scheduling mode. It aims to maximize the utility of the whole system (including the providers, consumers, and operator), and its objective function is equation (24) with constraints (2)–(6)

\max (U_{s}) = (\begin{matrix} w_{C} e^{- λ_{C} (C_{c} + C_{p} + C_{o})} + w_{E} e^{- λ_{E} (E_{c} + E_{p} + E_{o})} + \\ w_{R} ((1 - R_{c}) (1 - R_{p}) (1 - R_{o})) \end{matrix})

(24)

where

C_{c} = \sum_{j} C_{j}

(25)

E_{c} = \sum_{j} E_{j}

(26)

R_{c} = 1 - \prod_{j} (1 - R_{j})

(27)

C_{p} = \sum_{i} C_{i}

(28)

E_{p} = \sum_{i} E_{i}

(29)

R_{p} = 1 - \prod_{i} (1 - R_{i})

(30)

Experiments and results

In order to verify the proposed utility models and compare the four resource service scheduling methods, four groups of experiments were conducted. The conditions consisting of two providers-one operator-two consumers were considered in the experiments. The functional requirements of consumers are the rough machining of various different complex surfaces. Therefore, the services of numerical control (NC) milling machines and machine centers can meet it to mill the complex surfaces. The detailed information of requirements and services of the consumers and providers in the experiments are shown in Table 2. The simulation experiments are done in MATLAB 7.1. The detailed parameters in the formulas are generated in random with the appropriate range under these conditions. Additionally, the experimental PC configuration is listed as Intel^® Core™ i3-CPU M380 at 2.53 GHz, 2 GB memory, Windows 7 of 32 bits.

Table 2.

Related information of consumers and providers.

	Requirements Qj
Consumer 1	1	The surface rough machining of constant velocity cylindrical cam of automobile engine
	2	The surface rough machining of piston skirt of automobile engine
	3	The rough machining of crankshaft of automobile engine
Consumer 2	1	The surface rough machining of impeller vane
	2	The surface rough machining of integral impeller
	3	The surface rough machining of the umbrella slot of the solid rocket motor
	Services k_i
Provider 1	1	The NC milling machine 1
	2	The NC milling machine 2
	3	The NC machining center
Provider 2	1	The NC milling machine
	2	The NC machining center 1
	3	The NC machining center 2

NC: numerical control.

According to the proposed utility models and scheduling modes, the utility of the consumers, providers, operator, and the whole system under these four resource service scheduling methods (i.e. provider centered, consumer centered, operator centered, and system centered) are shown in Figure 3. The abscissa is the different quantity combinations of service requirement of the two consumers, and the ordinate is the comprehensive utility values.

Figure 3.

Utility values of (a) providers, (b) consumers, (c) operator, and (d) system.

In Figure 3, the results of comprehensive utility values of consumers, providers, operator, and the whole system are marked with prefixes U_c, U_p, U_o, and U_s, respectively. The results obtained using provider-centered, consumer-centered, operator-centered, and system-centered resource service scheduling methods are marked with suffixes max(U_p), max(U_c), max(U_o), and max(U_s), respectively. All of the results in Figure 3 are the average of utility values after experiments running 10 times.

Discussions

As shown in Figure 3, using consumer-centered resource service scheduling method, the utilities of consumers are maximal, but the utilities of providers, operator, and system are not large. Similarly, using provider-centered scheduling method, the providers can obtain the maximal utilities, but others are not. Using operator-centered scheduling method, only operator obtains the maximal utilities.

It means that if each user applies self-centered (e.g. the consumer applies the consumer centered) scheduling method, it can obtain their own ideal or expected maximal utility values. Apparently, it is unrealistic only considering one side’s optimal profit or utility in any allocation and scheduling. Otherwise, the allocation or transaction cannot be happened.

Using system-centered scheduling method, the system can obtain the maximal utility value, which meets the aim of CMfg system that decreases the system’s cost, energy, and risk very well. Although the three types of users (i.e. consumer, provider, and operator) cannot obtain their ideal or expected maximal utilities, they can obtain the second biggest utility value at the same time. In a way, the above scheduling problem models and utility models are reasonable, for that the results with the comprehensive utility evaluation are similar to the economic law, and it is also obvious that centralized decision making is better than decentralized decision making for system.

Therefore, the system-centered resource scheduling method is the best choice for practical application and to realize the initial aim of CMfg system. It can lead to maximal comprehensive utility for the whole system while enabling the three key users (i.e. consumer, provider, and operator) to obtain the utility that approaching to their ideal or expected maximal utility. Actually, the system-centered scheduling method needs to be further studied and improved (i.e. the system-centered cooperative scheduling method) in the subsequent researches to make the three users’ utilities under system-centered scheduling method approach or exceed their expected values under “themselves-centered” scheduling methods.

System-centered cooperative scheduling method and experiments

Resource service cooperative scheduling method

Based on the comparisons with the utilities under the above four resource service scheduling methods (i.e. provider centered, consumer centered, operator centered, and system centered), the system-centered cooperative scheduling method based on the cooperative strategy of risk sharing is provided, that is, no matter provider, consumer, and operator, if they are linked by one service, they must share the corresponding service providing risk, service invocation risk, and service scheduling risk. After introducing the risk-sharing cooperative strategy, the risk of provider i ( $R_{i}^{C}$ ), the risk of consumer j ( $R_{j}^{C}$ ), and the risk of operator ( $R_{o}^{C}$ ) are formulated as follows

R_{i}^{C} = \frac{1}{(\sum_{j = 1}^{M} \sum_{k_{i} = 1; k_{j} = 1; b_{i k_{i}}^{j k_{j}} = 1}^{n_{i}; Q_{j}} \frac{1}{{dr}_{i k_{i}}^{j k_{j}}} + \frac{1}{{ir}_{i k_{i}}^{j k_{j}}} + \frac{1}{{ar}_{i k_{i}}^{j k_{j}}})}

(31)

R_{j}^{C} = \frac{1}{(\sum_{i = 1}^{N} \sum_{k_{i} = 1; k_{j} = 1; b_{i k_{i}}^{j k_{j}} = 1}^{n_{i}; Q_{j}} \frac{1}{{dr}_{i k_{i}}^{j k_{j}}} + \frac{1}{{ir}_{i k_{i}}^{j k_{j}}} + \frac{1}{{ar}_{i k_{i}}^{j k_{j}}})}

(32)

R_{o}^{C} = 1 - (1 - OR) (1 - SR)

(33)

where, except the risk of platform operation $OR$ , the sharing risk of the related service $SR$ is formulated as equation (34)

SR = \frac{1}{(\sum_{i = 1}^{N} \sum_{j = 1}^{M} \sum_{k_{i} = 1; k_{j} = 1 b_{i k_{i}}^{j k_{j}} = 1}^{n_{i}; Q_{j}} \frac{1}{{dr}_{i k_{i}}^{j k_{j}}} + \frac{1}{{ir}_{i k_{i}}^{j k_{j}}} + \frac{1}{{ar}_{i k_{i}}^{j k_{j}}})}

(34)

With respect to the system-centered cooperative scheduling method, it aims to maximize the utility of the whole system (including providers, consumers, and operator) and to make the three users’ utilities approach or exceed their expected values under “themselves-centered” scheduling methods at the same time. Therefore, the objective function is equation (35) with the general constraints (2)–(6) and the cooperative constraints (36)–(38)

m a x (U_{s}^{C}) = (\begin{matrix} w_{C} e^{- λ_{C} (C_{c} + C_{p} + C_{o})} + w_{E} e^{- λ_{E} (E_{c} + E_{p} + E_{o})} + \\ w_{R} ((1 - R_{c}^{C}) (1 - R_{p}^{C}) (1 - R_{o}^{C})) \end{matrix})

(35)

U_{p}^{C}_\max (U_{s}^{C}) \geq \max (U_{p})

(36)

U_{c}^{C}_\max (U_{s}^{C}) \geq \max (U_{c})

(37)

U_{o}^{C}_\max (U_{s}^{C}) \geq \max (U_{o})

(38)

where

R_{p}^{C} = 1 - \prod_{i} (1 - R_{i}^{C})

(39)

R_{c}^{C} = 1 - \prod_{j} (1 - R_{j}^{C})

(40)

For the above formulas (36)–(38), the symbols $U_{p}^{C}_\max (U_{s}^{C})$ , $U_{c}^{C}_\max (U_{s}^{C})$ , and $U_{o}^{C}_\max (U_{s}^{C})$ are the maximal utilities of providers, consumers, and operator under the system-centered cooperative scheduling method with risk-sharing strategy, respectively. Then, the utilities of providers, consumers, and operator after cooperation are formulated as equations (41)–(43)

U_{p}^{C} = w_{C} e^{- λ_{C} \sum_{i} C_{i}} + w_{E} e^{- λ_{E} \sum_{i} E_{i}} + w_{R} (\prod_{i} (1 - R_{i}^{C}))

(41)

U_{c}^{C} = w_{C} e^{- λ_{C} \sum_{j} C_{j}} + w_{E} e^{- λ_{E} \sum_{j} E_{j}} + w_{R} (\prod_{j} (1 - R_{j}^{C}))

(42)

U_{o}^{C} = w_{C} e^{- λ_{C} C_{o}} + w_{E} e^{- λ_{E} E_{o}} + w_{R} (1 - R_{o}^{C})

(43)

Similarly, the symbols $m a x (U_{p}), m a x (U_{c}), and m a x (U_{o})$ are the maximal utilities of providers, consumers, and operator under themselves-centered scheduling methods, respectively, which have been presented in section “Resource service scheduling methods.”

Experiments and results

According to the proposed system-centered cooperative scheduling method based on risk-sharing strategy, the maximal utilities of the consumers, providers, operator, and the whole system under the system-centered cooperative service scheduling method are shown in Figure 4. Similarly, all of the results in Figure 4 are the average of utility values after experiments running 10 times. They are compared with the maximal utilities of consumers, providers, operator, and the whole system under themselves-centered scheduling method. These comparison experiments are the subsequent testing of the experiments in section “Resource service scheduling methods and comparisons.” The detailed parameters, conditions, and the testing environment are the same with the previous experiments. In Figure 4, similarly to the suffix in the previous experiments, the results obtained using system-centered cooperative resource service scheduling method are marked with suffix max(U_sX).

Figure 4.

Comparisons of utility values of (a) providers, (b) consumers, (c) operator, and (d) system among self-centered scheduling methods and system-centered cooperative scheduling method under pre-/after cooperative.

In order to further verify the feasibility of the proposed system-centered cooperative scheduling method, the sizes of the above experiments are expanded from “two providers-one operator-two consumers” to “ten providers-one operator-ten consumers.” And the experiments are with the assumption that each consumer has only one service requirement, and each provider provides only one service. Then, the average maximal utilities of providers, consumers, operator, and the whole system under system-centered cooperative service scheduling method with the scheduling problem of “n providers-one operator-n consumers” are shown in Figure 5.

Figure 5.

Comparisons of utility values of (a) providers, (b) consumers, (c) operator, and (d) system among self-centered and system-centered cooperative scheduling methods under the “n-1-n” scheduling problem and under pre-/after cooperative.

Discussions

As shown in Figure 4, introducing the strategy of risk sharing, using system-centered cooperative resource service scheduling method, the utilities of system with different combinations of the demanded quantity are improved, and they are better than the utilities of system under the only system-centered scheduling method. Besides, the utilities of consumers, providers, and operator under system-centered cooperative scheduling method are larger than the maximal utilities under themselves-centered scheduling methods.

In addition to the results shown in Figure 5, under system-centered cooperative scheduling method, the lines of the average maximal utilities of n providers and n consumers, and the lines of the maximal utilities of operator and system, are still higher than those lines under themselves-centered scheduling methods.

It means that no matter how many providers and consumers there are in a CMfg system, using system-centered cooperative scheduling method with the strategy of risk sharing, the risks of users and the whole system are reduced that leads the increasing of the utility values. Hence, the whole system and the triple users (i.e. providers, consumers, and operator) can obtain the higher maximal utility values than using the other scheduling methods. That is, the strategy of risk sharing makes the system cake bigger, so that the users in the system can eat more cakes. Moreover, it meets the final aim of CMfg very well and makes various users accept and practice the new manufacturing resource and capability sharing mode, system, and platform of CMfg.

Therefore, system-centered cooperative resource scheduling method with the strategy of risk sharing is the best choice for practical application and to realize the initial aim of CMfg. It can leads to maximal comprehensive utility for the whole system while enabling the three key users (i.e. consumers, providers, and operator) to obtain their ideal or expected maximal utilities, which are better than the maximal values under themselves-centered scheduling methods.

Conclusions and future works

The research on CMfg is just a beginning, and many theories, technologies, and methods for implementing CMfg are not matured yet and need to be further studied. The main aim of CMfg is to realize full sharing and circulating, on-demand use of various manufacturing resources and capabilities, so as to realize GM and SM (e.g. minimize energy consumption and cost). An effective resource service scheduling method that can maximize the utility of the whole CMfg system is very important for realizing that aim. In this article, after compared with the utilities under the different four resource service scheduling methods (i.e. provider centered, consumer centered, operator centered, and system centered), it is found that the system-centered resource service scheduling method is the highest potential method to realize the aim of CMfg. Introducing the strategy of risk sharing into system-centered scheduling (i.e. system-centered cooperative scheduling method), it can lead to maximal comprehensive utility for the whole system while enabling the three key users (i.e. consumers, providers, and operator) to obtain the higher maximal utility they expected. With this scheduling method and strategy, CMfg and its platform will be applied by much more users and be used to realize the higher efficient sharing, green and on-demand use of manufacturing resource and capability. So far as to the other SOM systems with the tripartite users, the cooperative scheduling method and strategy are still adaptive. In future, much more strategies of system-centered scheduling methods will be further studied and improved, and much more indexes will also be added into the utility models to rationalize the comprehensive evaluation of manufacturing resource and capability service in CMfg.

Footnotes

Declaration of conflicting interests

The authors declare that there is no conflict of interest.

Funding

This work was supported in part by NSFC project (nos 51005012 and 61074144), the National Key Technology Research and Development Program (no. 2011BA K16B03), and the Fundamental Research Funds for the Central Universities in China.

References

Mitsuishi

Nagao

. Networked manufacturing with reality sensation for technology transfer. CIRP Ann: Manuf Techn 1999; 48(1): 409–412.

D’Amours

Montreuil

Lefrançois

. Networked manufacturing: the impact of information sharing. Int J Prod Econ 1999; 58(1): 63–79.

Smith

Kumar

. A theory of application service provider (ASP) use from a client perspective. Inform Manage 2004; 41(8): 977–1002.

Leem

Lee

. Development of certification and audit processes of application service provider for IT outsourcing. Technovation 2004; 24(1): 63–71.

Kern

Kreijger

Willcocks

. Exploring ASP as sourcing strategy: theoretical perspectives, propositions for practice. J Strategic Inf Syst 2002; 11(2): 153–177.

Tao

Zhang

Nee

AYC

. A review of the application of grid technology in manufacturing. Int J Prod Res 2011; 49(13): 4119–4155.

Tao

Zhang

. Resource service management in manufacturing grid system. New Jersey: Wiley, Scrivener Publishing, 2012, p. 550.

Tao

Zhao

. Resource service composition and its optimal-selection based on particle swarm optimization in manufacturing grid system. IEEE T Ind Inform 2008; 4(4): 315–327.

Tao

Zhou

. Application and modeling of resource service trust-QoS evaluation in manufacturing grid system. Int J Prod Res 2009; 47(6): 1521–1550.

10.

Tao

Zhao

. Study of failure detection and recovery in manufacturing grid resource service scheduling. Int J Prod Res 2010; 48(1): 69–94.

11.

Tao

Zhou

. Study on manufacturing grid & its executing platform. Int J Manuf Tech Manag 2008; 14(1–2): 35–51.

12.

Ding

Tao

Sheng

. Modeling and application of optimal-selection evaluation for manufacturing grid resource. Int J Comp Integ M 2008; 21(1): 62–72.

13.

Wenan

Yicheng

Wei

. A Methodology toward Manufacturing Grid-based Virtual Enterprise Operation Platform. Enter Inf Sys 2010; 4(3): 283–309.

14.

Meier

Roy

Seliger

. Industrial product-service systems—IPS2. CIRP Ann: Manuf Techn 2010; 59(2): 607–627.

15.

Griffiths

. Manufacturing paradigms: the role of standards in the past, the present and the future paradigm of sustainable manufacturing. Proc IMechE, Part B: J Engineering Manufacture 2012; 226(10): 1628–1634.

16.

De Coster

Bateman

. Sustainable product development strategies: business planning and performance implications. Proc IMechE, Part B: J Engineering Manufacture 2012; 226(10): 1665–1674.

17.

Zhang

Jiang

Zhu

. Modeling and analyzing of an enterprise collaboration network supported by service-oriented manufacturing. Proc IMechE, Part B: J Engineering Manufacture 2012; 226(9): 1579–1593.

18.

Tao

Cheng

Zhang

. Utility modelling, equilibrium, and coordination of resource service transaction in service-oriented manufacturing system. Proc IMechE, Part B: J Engineering Manufacture 2012; 226(6): 1099–1117.

19.

Tao

Zhang

Venkatesh

. Cloud manufacturing: a computing and service-oriented manufacturing model. Proc IMechE, Part B: J Engineering Manufacture 2011; 225(10): 1969–1976.

20.

Marston

Bandyopadhyay

. Cloud computing—the business perspective. Decis Support Syst 2011; 51(1): 176–189.

21.

Sotomayor

Montero

Llorente

. Virtual infrastructure management in private and hybrid clouds. IEEE Internet Comput 2009; 13(5): 14–22.

22.

Shangcang

Lida

Xinheng

. Integration of hybrid wireless networks in cloud services oriented enterprise information systems. Ent Inf Sys 2012; 6(2): 165–187.

23.

Bosin

Dessì

Pes

. Extending the SOA paradigm to e-Science environments. Future Gener Comp Sy 2011; 27(1): 20–31.

24.

Delamer

Lastra

JLM

. Service-oriented architecture for distributed publish/subscribe middleware in electronics production. IEEE T Ind Inform 2006; 2(4): 281–294.

25.

Cândido

Colombo

Barata

. Service-oriented infrastructure to support the deployment of evolvable production systems. IEEE T Ind Inform 2011; 7(4): 759–767.

26.

Sasa

Juric

Krisper

. Service-oriented framework for human task support and automation. IEEE T Ind Inform 2008; 4(4): 292–302.

27.

Lida

. Enterprise Systems: State-of-the-Art and Future Trends. IEEE Trans on Ind Inf 2011; 7(4): 630–640.

28.

Kalogeras

Gialelis

Alexakos

. Vertical integration of enterprise industrial systems utilizing web services. IEEE T Ind Inform 2006; 2(2): 120–128.

29.

Atzoria

Ierab

Morabito

. The Internet of things: a survey. Comput Netw 2010; 54(5): 2787–2805.

30.

Wang

. Compressed Sensing Signal and Data Acquisition in Wireless Sensor Networks and Internet of Things. IEEE Trans on Ind Inf 2012. Epub ahead of print 2012. DOI: 10.1109/TII.2012.2189222.

31.

Tao

Zhao

. Manufacturing grid resource and resource service digital description. Int J Adv Manuf Tech 2009; 44(9–10): 1024–1035.

32.

Lin

Fan

Newman

. Manufacturing process analysis with support of workflow modelling and simulation. Int J Prod Res 2009; 47(7): 1773–1790, http://www.informaworld.com/smpp/titlecontent=t713696255db=alltab=issueslistbranches=47-v47

33.

Xinqin

Lida

Xueping

. Workflow process modeling and resource allocation based on polychromatic sets theory. Ent Inf Sys 2013; 7(2): 198–226.

34.

Lida

Wattana

Puripan

. Using Propositional Logic for Requirements Verification of Service Workflow. IEEE Trans on Indl Info 2012; 8(3): 639–646.

35.

Wattana

Lida

Andrew

. Service Workflow Requirements Specification Language: The Formal Requirements Specification in Service Workflow Environments. IEEE Trans on Ind Info 2012; 8(3): 631–638.

36.

Lida

Huimin

Song

. Modeling and Analysis Techniques for Cross-Organizational Workflow Systems. Sys Res and Behav Sci 2009; 26(3): 367–389.

37.

Tao

Zhao

. Study on resource service match and search in manufacturing grid system. Int J Adv Manuf Tech 2009; 43(3–4): 379–399.

38.

Tao

Zhao

Zhang

. Resource service optimal-selection based on intuitionistic fuzzy set and non-functionality QoS in manufacturing grid system. Knowl Inf Syst 2010; 25(1): 185–208.

39.

Tao

Zhou

. Study on manufacturing grid & its resource service optimal-selection system. Int J Adv Manuf Tech 2008; 37(9–10): 1022–1041.

40.

Tao

Laili

. FC-PACO-RM: a parallel method for service composition optimal-selection in cloud manufacturing system. IEEE T Ind Inform 2012. DOI: 10.1109/TII.2012.2232936.

41.

Tao

Guo

Zhang

. Modelling of combinable relationship-based composition service network and theoretical proof of its scale-free characteristics. Enterprise Inform Syst 2012; 6(4): 373–404.

42.

Tao

Zhang

. Study on manufacturing grid resource service optimal-selection and composition framework. Enterprise Inform Syst 2012; 6(2): 237–264.

43.

Guo

Tao

Zhang

. Research on measurement method of resource service composition flexibility in service-oriented manufacturing system. Int J Comp Integ M 2012; 25(2): 113–135.

44.

Guo

Tao

Zhang

. Correlation-aware web services composition and QoS computation model in virtual enterprise. Int J Adv Manuf Tech 2010; 51(5–8): 817–827.

45.

Tao

Zhao

. Correlation-aware resource service composition and optimal-selection in manufacturing grid. Eur J Oper Res 2010; 201(1): 129–143.

46.

. Utility-based scheduling for grid computing under constraints of energy budget and deadline. Comp Stand Inter 2009; 31(6): 1131–1142.

47.

Maurer

Emeakaroha

Brandic

. Cost-benefit analysis of an SLA mapping approach for defining standardized cloud computing goods. Future Gener Comp Sy 2012; 28(1): 39–47.

48.

. Utility driven dynamic resource allocation using competitive markets in computational grid. Adv Eng Softw 2005; 36(6): 425–434.

49.

Kumar

Dutta

Mookerjee

. Maximizing business value by optimal assignment of jobs to resources in grid computing. Eur J Oper Res 2009; 194(3): 856–872.

50.

Tseng

Chin

Wang

. The anatomy study of high performance task scheduling algorithm for Grid computing system. Comp Stand Inter 2009; 31(4): 713–722.

51.

Cheng

Huang

. Utility-driven solution for optimal resource allocation in computational grid. Comput Lang Syst Str 2009; 35(4): 406–421.

52.

Izakian

Abraham

Ladani

. An auction method for resource allocation in computational grids. Future Gener Comp Sy 2010; 26(2): 228–235.

53.

Vanderster

Dimopoulos

Parra-Hernandez

. Resource allocation on computational grids using a utility model and the knapsack problem. Future Gener Comp Sy 2009; 25(1): 35–50.

54.

Yao

Liu

. Optimization analysis of supply chain scheduling in mass customization. Int J Prod Econ 2009; 117(1): 197–211.

55.

Beloglazov

Abawajy

Buyya

. Energy-aware resource allocation heuristics for efficient management of data centers for cloud computing. Future Gener Comp Sy 2012; 28(5): 755–768.

56.

Mezmaza

Melab

Kessaci

. A parallel bi-objective hybrid metaheuristic for energy-aware scheduling for cloud computing systems. J Parallel Distr Com 2011; 71(11): 1497–1508.

57.

Singh

Bhukya

. A hybrid genetic algorithm for the minimum energy broadcast problem in wireless ad hoc networks. Appl Soft Comput 2011; 11(1): 667–674.

58.

Warneke

Kao

. Exploiting dynamic resource allocation for efficient parallel data processing in the cloud. IEEE T Parall Distr 2011; 22(6): 985–997.

59.

Laili

Tao

Zhang

. A study of optimal allocation of computing resources in cloud manufacturing systems. Int J Adv Manuf Tech 2012; 63(5): 671–690.

60.

Sawik

. Coordinated supply chain scheduling. Int J Prod Econ 2009; 120(2): 437–451.

61.

Yeung

Choi

Cheng

TCE

. Supply chain scheduling and coordination with dual delivery modes and inventory storage cost. Int J Prod Econ 2011; 132(2): 223–229.

62.

Torabi

Fatemi Ghomi

SMT

Karimi

. A hybrid genetic algorithm of the finite horizon economic lot and delivery scheduling in supply chains. Eur J Oper Res 2006; 173(1): 173–189.

63.

Selvarajah

Steiner

. Batch scheduling in a two-level supply chain-a focus on the supplier. Eur J Oper Res 2006; 173(1): 226–240.

64.

Chou

H-Q

Yuan

X-M

. Analysis of a software-focused products and service supply chain. IEEE T Ind Inform 2006; 2(4): 295–302.

65.

Georgiadis

Levis

Tsiakis

. Optimisation-based scheduling: a discrete manufacturing case study. Comput Ind Eng 2005; 49(1): 118–145.

66.

Adibi

Zandieh

Amiri

. Multi-objective scheduling of dynamic job shop using variable neighborhood search. Expert Syst Appl 2010; 37(1): 282–287.

67.

Jayamoban

Rajendran

. Development and analysis of cost-based dispatching rules for job shop scheduling. Eur J Oper Res 2004; 157(2): 307–321.

68.

Engin

Ceran

Yilmaz

. An efficient genetic algorithm for hybrid flow shop scheduling with multiprocessor task problems. Appl Soft Comput 2011; 11(3): 3056–3065.

69.

Cheng

H-C

Chiang

T-C

L-C

. A two-stage hybrid memetic algorithm for multiobjective job shop scheduling. Expert Syst Appl 2011; 38(9): 10983–10998.

70.

Lei

. Simplified multi-objective genetic algorithms for stochastic job shop scheduling. Appl Soft Comput 2011; 11(8): 4991–4996.

71.

Tao

Qiao

Zhang

. GA-BHTR: an improved genetic algorithm for partner selection in virtual manufacturing. Int J Prod Res 2012; 50(8): 2079–2100.

72.

Zhang

Tao

Laili

. Green partner supplier selection in virtual enterprise based on Pareto genetic algorithms. Int J Adv Manuf Tech 2012. DOI: 10.1007/s00170-012-4634-x.

73.

Tao

Zhang

. A quantum multi-agent evolutionary algorithm for selection of partners in a virtual enterprise. CIRP Ann: Manuf Techn 2010; 59(1): 485–488.

74.

Tao

Zhao

. An approach to manufacturing grid resource service scheduling based on trust-QoS. Int J Comp Integ M 2009; 22(2): 100–111.

75.

Tao

Zhao

. Study on manufacturing grid resource service QoS modeling and evaluation. Int J Adv Manuf Tech 2009; 41(9–10): 1034–1042.

76.

Cucinotta

Palopoli

Abeni

. On the integration of application level and resource level QoS control for real-time applications. IEEE T Ind Inform 2010; 6(4): 479–491.

77.

Ghani

Monfared

Harrison

. Energy optimisation in manufacturing systems using virtual engineering-driven discrete event simulation. Proc IMechE, Part B: J Engineering Manufacture 2012; 226(11): 1914–1929.

78.

Jung

Jeong

Lee

C-G

. An order quantity negotiation model for distributor-driven supply chains. Int J Prod Econ 2008; 111(1): 147–158.
