On the underlying dynamics of traffic conflicts related to stochastic behaviour

Abstract

The aim of this paper is to analyse why and how air traffic conflicts occur as a result of the stochastic behaviour of both the ownship and the intruder and to show how system-level characteristics can be derived from such an analysis. Ensemble dynamics in a given traffic scenario have already been analysed using multi-agent simulations by many; however, such an analysis is hardly ever backed up and interpreted in terms of an analytical study. By making use of directional conflict probability maps, characteristics of integral, system-level quantities can be explained, providing further insight into the relationship of speed distribution parameters and system performance quantities, namely, safety and throughput.

Keywords

unmanned traffic management urban air mobility analytical modelling conflict detection analysis stochastic analysis

Introduction

Based on current, general aerospace trends an increase in traffic and the number of vehicles can be forecasted. According to the commercial market outlook¹ traffic will grow 4.0% annually in the next 20 years, with an airline fleet growth rate of 3.1%. Introduction and projected proliferation of Personal Aerial Vehicles (PAVs) would result in an even more intense increase for the urban airspace traffic. The rise in the volume and concentration of traffic leads to vehicle densities never seen before.^2,3 This changes traffic management, causes airspace to expand and requires new principles for its traffic control system.⁴ Even with the recent social and economic changes, forecasted annual growth for the urban air mobility market is between 12% and 33.9% for the 2022–2050 period.^5–12 Although the current market research results show significant diversity (from a $6.9 billion market by 2030⁵ to a $9 trillion market by 2050⁶), the fundamental need for these services does not seem to have changed, and the market growth predicted is significant.

Urban air mobility is defined by NASA as ‘a safe and efficient system for air passenger and cargo transportation within an urban area, inclusive of small package delivery and other urban Unmanned Aerial Systems (UAS) services, which supports a mix of on-board/ground-piloted and increasingly autonomous operations’.¹³ Due to the insufficient scalability of currently used Air Traffic Management (ATM) methods,^14–16 novel coordination methods are necessary, otherwise high-density operations ‘will stress the current ATM system’.¹⁷ Currently applied methods in ATM are not scalable, because they rely on human involvement for deconfliction, voice-based communication and a structure unsuitable for separation for UAM vehicles. Such systems cannot handle the number and density of operations predicted for UAM. Air traffic control was identified as a major scaling constraint for urban air mobility operations.¹⁴ The traffic management system for the future has to be able to accommodate unpiloted aircraft with high density, keeping or even exceeding the safety level of traditional ATM techniques.

This traffic management system is envisioned to encompass a spontaneous, self-organising, distributed, in-flight strategic deconfliction method. This is aligned with the proposed self-configuration, self-optimisation, self-protection and self-healing properties of UTM.² The method being spontaneous, self-organising and distributed comes from the predicted density of UAM operations. A centralised entity with the additional constraints would not be able to handle this density efficiently, due to poor scalability. The most relevant scaling constraints are communication, the type and the duration of operations, and the number of operations that can be handled by a single controller. This is why the fundamental operational concept for UTM relies on a distributed information network of interoperable, highly automated systems.¹⁶ Otherwise, controller workload limitations and separation minima would lead to limited-scale operations, which may not be economically feasible.¹⁴

To preserve the necessary flexibility and the ability to react to deviations from plans, the method applied needs to be in-flight and online. Considering that the number of aircraft that can be handled by tactical technical means (e.g. TCAS, ACAS Xu) is only a few, it is essential to have airspace coordination at a higher level. This is demonstrated by the current paper as well as a recent publication on the topic.¹⁸ The exact formulation of a traffic coordination method for UAM remains an open research question. As explored in the literature review, urban air mobility traffic management methods include offline scheduling, subliminal speed control similar to ATM, manoeuvre coordination, computational guidance and deconfliction using optimisation. This paper aims at contributing to the research towards a scaleable traffic management framework by analysing a system that can be used to coordinate global ensemble dynamics and limit the probability of dangerous intrusions. The technique is based on a distributed algorithm.

Within the scope of this paper, the free flight concept is adopted.¹⁹ Based on this, a decentralised and autonomous traffic management framework is developed. The proposed architecture has a hierarchical, human-over-the-loop structure similar to the one proposed by Valavanis.²⁰ The overall goal of the framework is to integrate low-level tactical avoidance methods with high-level optimal coordination to improve throughput. This shall be achieved while also providing probabilistic safety margins by limiting the probability of conflicts and the number of occasions tactical avoidance is triggered. All aircraft are assumed to be cooperative. To enable distributed decision making, all aircraft share their state data with others within their communication range via a protocol similar to ADS-B. The proposed framework is built-up of 3 + 1 layers, the top layer being the human supervisor, who monitors the system and intervenes when necessary.^14,15 Detailed human factors analysis however is beyond the scope of this paper. The lowest of the three conventional layers handles one-to-one collision avoidance, based on well-established methods. Also, to increase airspace capacity, aircraft create ad hoc formations based on similar heading, leading to clusters.²¹ Common heading can be agreed on, for example, by using consensus techniques.²² Dynamics within the cluster can be controlled by group flight algorithms. Control of collective motion of multi-agent systems may also be based on continuum mechanics.²³

Instead of trying to minimise the number of intrusions, their probability is managed so that conflicts can be resolved should they occur. It is assumed that an intruder can be avoided by the ownship given enough time to react and manoeuvre. One-to-one avoidance is managed by the lowest layer. The time necessary for an aircraft pair to resolve conflicts depends on aircraft performance characteristics, navigation uncertainty, communication latency and other factors. The purpose of the time threshold is similar to the purpose of separation distances in traditional sense and avoid systems. Since not all aircraft have the same characteristics in terms of dynamics and equipage, it is meaningful to consider different separation limits.²⁴ Also, a sufficient amount of clear airspace is needed to perform the avoidance; hence, it is meaningful to control global intrusion probability, and through that influence airspace complexity. In the current paper, the conflict time threshold is defined based on the expected separation limits for UAM vehicles, their characteristic speeds and yaw dynamics. How the time threshold can be selected and a sensitivity analysis can be found in a previous publication on the topic.²⁵ The exact relationship between dynamics, equipage and conflict time thresholds should be subject to future research.

This paper focuses on the dynamics and modelling of the middle layer, bridging the bottom and the top layers by applying a bottom-up analysis method. To investigate the effect of parameter changes on the system of aircraft, multi-agent simulation results are used. These are discussed in detail in terms of analytical calculations. With the appropriate combination of methods, further insight can be gained into the underlying dynamics; thus, simulation results can be put into context. The aim of this paper is to calculate system-level metrics for conflict probabilities (without resolution methods) for aircraft in a free flight environment. In this free flight environment, all agents have a speed according to a prescribed distribution (following guidance from the middle layer of the proposed framework).

In the proposed framework, the middle layer is distributed and stochastic by design. The reason for choosing a stochastic method is the robustness advantage.²⁶ Certain stochastic methods have a ‘self-repair’ property. This means that when perturbed, the system returns to the original, prescribed state without coordination. The distributed system property is essential from a scalability point of view. It is assumed that nominal heading angle and altitude are given by the flight plan (start and destination point). Heading and altitude changes are reserved for this layer. Therefore in the middle layer, the speed is manipulated only.

The aim of the middle layer is to regulate ensemble dynamics so that the probability of collision avoidance being triggered is sufficiently low, thus preserving airspace stability and preventing the domino effect.²¹ The domino effect, an indicator of airspace stability, was defined as the event when deconfliction ‘propagates into causing a subsequent conflict with three or more aircraft before the conflict can be resolved’. Therefore, if the number of times conflict resolution is necessary can be reduced, the risk of the domino effect can also be reduced. Another factor to decrease the risk of domino effect is to keep conflict scenarios simple and reduce the number of difficult to solve encounters.²⁷ The middle layer should be able to shift the encounter probability towards conflicts with fewer aircraft. The practical value for tolerable risk and the method to determine that is outside the scope of this paper. This is ultimately a regulatory question. As a guideline, the SORA methodology (and appendices) may be used.²⁸ SORA derives the relationship between overall risk and operational safety objectives.

With the increase of air traffic, the operational complexity is expected to increase exponentially.³ To this end, a distributed stochastic task allocation algorithm²⁹ is employed, which drives agent behaviour distribution (speed, within the scope of the current paper) to a predefined distribution. This algorithm has been used previously by the authors in the context of multi-agent simulations.²⁵ The desired distribution is defined in terms of a few parameters, which can be regarded as decision variables. The aim of the top level is to optimise a cost function by tuning these decision variables. Within the scope of this paper two distributions, the exponential and the normal distribution are investigated. The normal distribution can be thought of as an ordinary traffic flow with an inherent perturbation. The distribution of en-route ground speeds resembles a normal distribution.³⁰

In some exceptional circumstances, if privileged vehicles with higher speeds are present, it may be better to switch to exponential prescribed distribution. This is because exponential distribution generally enables higher, more extreme speeds with higher probability which emergency vehicles can deterministically occupy. Other vehicles would adapt to maintain the desired distribution, creating a self-optimising capability.²

Since the aim of the middle layer is to decrease the probability of a collision avoidance manoeuvre being necessary, to measure its effectiveness, the notion of speed conflict is introduced. Around the ownship two regions are defined. The outer one is the sensing range $(r_{S})$ , within which all intruders can be identified. This reflects on the communications range of agents. The event when the intruder reaches the inner circle, called the conflict range $(r_{C})$ , faster than a threshold time $(t_{th})$ is called a speed conflict. A geometric conflict is defined as the traversal of the intruder from the sensing to the conflict range, regardless of the time elapsed.

Metrics measuring the effectiveness of the middle layer are safety and throughput. Safety is defined as the probability of a speed conflict for all aircraft with any other aircraft and calculated according to Equation (1). In Equation (1), C is the number of conflicts during a given time period, n_a is the number of agents in a given area and t is the length of the investigated period of time.

S = \frac{C}{n_{a} \times t}

(1)

Throughput reflects on the mean speed of agents, taking into account that avoidance manoeuvres to resolve conflicts lengthen routes, leading to longer travel times. In Equation (2), n_a is the number of agents in a given area and t is the length of the investigated period of time, C is the number of conflicts during a period, v_i is the speed of the i^th agent and P is the avoidance manoeuvre related penalty.

T = \frac{1}{n_{a g e n t}} (\frac{t {(\sum_{i} v_{i})}^{2}}{t \sum_{i} v_{i} + C \times P})

(2)

Applicability and performance of several stochastic task allocation methods in terms of distribution distance and transient characteristics were previously analysed using multi-agent simulations.²⁵ These algorithms can be used to drive an ensemble to a given probability distribution.²⁶ It was also shown by Jang et al.²⁹ that organisation is possible using only local information. Application of these methods in a multi-agent simulation environment can reveal the relationship between distribution parameters and performance metrics $(S, T)$ on a system-wide scale. Simulation analysis, however, fails to explain the underlying dynamics of why and how parameter changes affect conflict probability. Moreover, they are only valid for the range of simulated parameters. Therefore, in this paper, the exact relationship is analysed based on previously derived formulae for directional conflict probability. This helps to better understand why and how conflicts occur and to reveal how conflict avoidance can be treated as a distribution shaping problem.

The paper is structured as follows. Related research is summarised in the section Literature review. Calculations corresponding to directional quantities are presented in the Directional quantities section. Parameter dependence of integral quantities is derived in the section Integral quantities. Concluding remarks are drawn and future work is summarised in the Conclusion section.

Literature review

Traffic management for urban air mobility has been a subject of extensive research. Generally, suggested methods rely on improved scalability of traditional ATM methods or attempt to use novel UTM methods for UAM.³¹ This research area shows significant variety regarding definitions, modelling and solution approaches and the level at which the problem is addressed. Aerial conflicts and deconfliction by optimal planning and scheduling, both in ATM and for UAS and UAM has been investigated in several papers.^32–34 Airspace design in an urban setting is also a topic of interest.^35–37 Improvement of collision avoidance methods³⁸ and computational guidance methods could also support the introduction of UAM. In the following, we review selected papers to provide an overview of ongoing research efforts.

An overview of collision detection and resolution is given by Kuchar and Yang.³⁹ A taxonomy of algorithms is provided based on the conflict detection (decision) definition and several other characteristics. The method for intruder state propagation can be nominal, worst-case or probabilistic. The state dimensions considered can be horizontal, vertical or both. The conflict resolution methods listed are prescribed, optimised, force field and manual. The potential resolution manoeuvres considered are turns, vertical manoeuvres and speed changes. Methods can also be classified according to how multiple conflicts are resolved. Different algorithms can consider all potential conflicts resolutions at the same time (global approach) or handle the problem as a sequence of pairwise deconfliction tasks (pairwise approach). The paper also describes the process of system design form as a series of the following steps. The process starts with choosing assumptions on aircraft motion and environment, trajectory modelling and threshold selection, based on which the method is synthesised. Performance is evaluated by simulations, possibly with fault injection, which also enables tuning of parameters till the number of incidents and false alarms can be balanced. A development step is to consider a probabilistic trajectory model. Following the taxonomic categories, the method presented in the current paper uses probabilistic state propagation in the horizontal plane. Detection threshold selection and resolution and manoeuvres available can be set according to the performance of the underlying resolution method. A key improvement of the method presented is that it takes into account information on global dynamics, thus enabling setting parameters a priori, based on a mathematical formulation, rather than after a simulation study.

Conflicts are detected by the SLIDE algorithm⁴⁰ assuming aircraft fly according to a straight-line path, with constant velocity. Conflicts are defined as an overlap between protected zones and detected by calculating the closest point of approach. State information is periodically exchanged. The effect of the selection of the broadcast cycle and look-ahead time is analysed by simulations. Packet losses and resulting errors in state information are also taken into account. Performance is analysed in terms of missed and false alarms. Time-averaged simulation results characterise capabilities appropriately; however, the directionality of conflicts is not analysed.

For UTM to remain scalable, safe and efficient, the overall goal of traffic management is not to minimise the number of potential conflicts, but to reduce the macroscopic complexity of the airspace so that it remains manageable. By combining 4D trajectory optimisation and flight planning an encounter aware flight planning method for free flight can be created.²⁷ To assess the performance of the method a multi-modal traffic region is simulated. Results show that multi-aircraft encounters cause disproportionately more near mid-air collisions, thus minimising the encounter shift (distribution distance from reference encounter distribution), and through that, the complexity of encounters is proven to be an appropriate control aim.

The method described in this paper relies on the offline scheduling of traffic. Scheduling requires significant computation a priori, that is, before aircraft take-off. Since the schedule is calculated a priori, the method cannot react to real-time disturbances or deviations from plans. This is because all decisions are made and fixed before any practical divergence occurs. Therefore, its resilience in itself is questionable. To compensate for inherent deviations and to handle off-nominal situations, an online method needs to be applied. The strategic and tactical functions in a proposed autonomous ATM system are summarised by Windhorst et al.⁴¹ The method presented by Egorov et al. can be used for strategic scheduling, combined with an online, tactical system, which incorporates feedback. Online coordination methods can use real-time information to drive the system back to the prescribed state after a perturbation. The study was later extended by a stress testing and validation framework.⁴²

For real-time collision avoidance, velocity planning can be applied effectively.⁴³ By discretising the airspace and creating a cubic grid, trajectories can be shared efficiently as residence times in a given cell. Conflicts are identified as overlaps in residence times. For velocity planning and deconfliction, a heuristic algorithm based on the combination of the search tree method and tabu search is proposed. The main advantage of the method presented is that it disturbs trajectories as little as possible while taking into account the constraints imposed by the dynamics model of aircraft. The result however relies heavily on the availability of global information, which may lead to issues with scalability. Moreover, the method cannot guarantee a solution for all scenarios or avoid situations where a solution is not possible. Nevertheless, research findings suggest that velocity control is an effective method to globally coordinate aircraft to avoid collisions, similarly to the velocity control applied in the current paper.

Subliminal speed control is shown to effectively reduce both the number and duration of conflicts, even in the presence of aircraft speed perturbations.⁴⁴ For speed regulation to remain subliminal for ATC, and because of aircraft dynamics and passenger comfort, only a narrow speed range is used. The paper also highlights that with the development of flight management systems the importance of speed control could increase. To minimise ATCs’ workload, conflict resolution is formulated as a nonlinear optimisation problem. The objectives are to minimise the total conflict duration or to maximise the number of conflicts resolved. The separation equations are linearised to enable a mixed integer program solution. To facilitate the solution, the problem is solved for simplified aircraft dynamics. The results, however, are validated with a realistic performance model, also taking into account uncertainties. The method can be applied by solving the problem periodically with a rolling horizon.

Manoeuvre coordination is also proposed to be used as a collision avoidance method for a high traffic density environment.⁴⁵ The technique presented is applicable for fixed-wing aircraft. The set of possible manoeuvre styles is constrained to nine possibilities. The proposed algorithm is composed of five modules: manoeuvre generation, trajectory prediction, threat management, manoeuvre evaluation and manoeuvre activation. In manoeuvre generation, each agent chooses three of the nine available styles, for these choices the trajectories are predicted in the trajectory prediction module. Trajectory errors and uncertainty is taken into account as a conical region. In the threat management module, the three most imminent threats are identified according to a combination of relative distance and relative speed. Combinations of selected manoeuvres are evaluated (using shared information between participants) and activated at the last possible moment to minimise disruption, preserve airspace stability and avoid interference. Even though the principle of noninterference is respected, the effect of conflict resolution on the wider airspace is not analysed. Also, no guarantee is provided that with the constrained set of avoidance manoeuvre styles potential conflicts can be avoided. Although manoeuvre coordination was recently proposed as a collision avoidance method for UAS it still requires significant research to become practically applicable.

Another example for manoeuvre coordination can be found in a paper by Tompa et al.⁴⁶ The research focuses on horizontal manoeuvre coordination as it is more relevant for unmanned aircraft. The key hypothesis is that a coordination scheme and agreement between aircraft enhances safety beyond what individual collision avoidance systems can achieve. The problem is modelled as a Markov decision process, using a master-slave approach. The states are relative range, azimuth angle, relative heading angle, speeds and whether aircraft are responding to their advisories. The state space is discretised. The action space is also discretised and contains the possible bank angles. Rewards are negative and are related to NMAC (near mid-air collision), proximity, manoeuvres and the strength of manoeuvres, and can be used to balance safety and efficiency. Only pairwise encounters are considered. The optimal policy for the MDP is determined using dynamic programming. Using the score table a coordination table is created, which contains whether the aircraft should perform the same or opposite actions. These coordination tables can be stored onboard. Coordination message relaying schemes, alternative coordination table generation methods and nonjoint action policies are also investigated. The safety benefit of the method is demonstrated by simulations. The results of the paper demonstrate how manoeuvre coordination can be applied in the future and highlight the difference between pairwise deconfliction and deconfliction in high-density airspace with complex conflicts.

The stochastic nature of air traffic and its effect on collision avoidance is widely researched. Path deviation can be taken into account by calculating the probabilistic reach sets of aircraft formulated as a chance-constrained optimisation problem.⁴⁷ The problem can be solved by the scenario approach. The nominal trajectory of aircraft is piecewise linear, which is then perturbed by the stochastic wind. Conflict is defined as an overlap of the ellipsoidal reach sets with a probability higher than a threshold. The resolution assumes spherical reach sets and is reformulated as a second-order cone program. Granted that a stochastic framework improves resilience since the method applies to a specific scenario its performance can only be analysed using simulations. Thus, no global performance metric can be determined, as results are not universal.

Mathematical models for air conflict and collision probability estimation are given by Mitici.⁴⁸ Based on mathematical formalism, models can be compared within a unified framework. Safety risk and validation models are also surveyed, creating a hierarchical description, reflecting on their practical applicability and analysing their characteristics. None of the models, however, can describe system-level dynamics of safety and throughput or use model results to deduce characteristics of emergent ensemble dynamics.

Results in the field of operations research have also contributed to the advancements in conflict detection and resolution. The application of decision support tools in ATM is necessary because of the increasing volume of flights. The emergence of urban air mobility is only going to exacerbate the problem. A survey of advancements and a unified mathematical framework is given by Pelegrín and D’Ambrosio.⁴⁹ A taxonomy of methods is proposed based on several characteristics, for example, the objective function, the type of model and the type of manoeuvres permitted. Commonly used benchmark scenarios are also outlined. It is noted in the paper that the number of aircraft that can be handled is still limited to several dozens. This is still below the expected number and density of UAM operations. Also, for practical applicability, a larger set of features needs to be considered. Benchmarks including these should also be developed.

Conflict probability can be calculated based on intent.⁵⁰ Aircraft trajectories are predicted in a probabilistic manner, using a hybrid dynamics model. The set of flight modes is finite, flight mode intent can be inferred from reported data and utilised for prediction. Conflict probability is calculated by integrating over the conflict zone. During the calculations, only one aircraft is behaving stochastically, due to wind and measurement uncertainty. Within the scope of the current paper, both aircraft are behaving stochastically, according to a predefined distribution.

Emergent behaviour due to the interaction of individual systems is modelled and analysed in free flight safety modelling and simulation.⁵¹ System dynamics are modelled as a stochastically and dynamically coloured Petri net, collision risk is estimated by running Monte Carlo simulations. The analysis is performed in a free flight scenario, which creates a distributed flight control architecture. The aim is to understand the relationship between safety and capacity. Conflict resolution is based on a modification of the potential field method. Results of the analysis show that with the current commercial air traffic density the probability of multiple aircraft conflicts is very low, however, with increasing density it rapidly increases. Traffic densities analysed are much lower than the ones forecasted for urban air mobility.

A self-organising, decentralised method for air traffic can be formulated in 3D.⁵² The number of indirect conflicts is expected to rise with air traffic density, deteriorating performance in terms of reliability, efficiency and capacity. Conflicts are detected using relative kinematics, knowing all aircraft intentions, with a safety sphere around each agent. Conflict resolution is formulated as a constrained optimisation problem, either by controlling velocity only during nominal operation or by changing velocity, heading and flight path in emergency scenarios. A distributed, self-organised capability for airspace management can lead to increased performance. Nevertheless, the need for intent information from all other aircraft can be prohibitive on scalability.

Self-organising can also be achieved by extending the Reynolds rules of flocking⁵³ for autonomous swarm flight collision avoidance. The optimised flocking model consists of the following forces: repulsion, velocity alignment, flock centring, force towards flight target and an additional anti-collision force. The anti-collision force is calculated in a pairwise manner, based on the closest point of approach, by linear extrapolation of the paths. The performance of the method is analysed using simulation, taking into account scenarios where conflict resolution may lead to a domino effect. The technique operates appropriately for the simulated scenarios. However, no evidence is provided for its practical applicability. It would also be important to analyse the limits of the method in terms of the number of aircraft handled, the complexity of the encounter scenario, communication requirements and the solution time. This could help to assess the potential of the technique.

The detection and resolution algorithm of the Traffic Collision Avoidance System (TCAS), the last resort means to reduce collision probability can be modelled using mathematical tools.⁵⁴ Moreover, the method is extended with the option of horizontal resolution; thus, multi-aircraft conflicts can be handled better. Using the causal encounter model, developed in a graphical modelling and analysis software, the effect of surrounding aircraft, induced collisions and the domino effect (secondary threats) can be analysed and avoided. While the method can be efficiently used to analysed the downstream effects of an issued resolution advisory in a given encounter scenario, no general conclusion can be drawn regarding global airspace dynamics or airspace stability.

TCAS resolution advisories can lead to induced collisions and induced secondary threats, which need to be analysed.⁵⁵ It is understood that increasing traffic densities would lead to potential collision situations. Encounters are modelled using the coloured Petri net formalism, which is then simulated to create a scenario database. This database can be used as a reference in real scenarios also aided by pattern recognition. It is understood from simulations that the TCAS logic can induce collisions, especially in dense traffic, in multi-aircraft scenarios. These densities are much higher than the design density of TCAS; however, the study illustrates why it is important not to focus on individual conflicts, but to control global dynamics in a high-density scenario.

Deconfliction for a free flight aerial sector can be achieved using a combination of speed and altitude changes.²⁴ This problem can be solved as a mixed integer linear optimisation, seeking to have an equilibrium number of manoeuvres for each aircraft. The paper also describes the advantages and disadvantages of speed and altitude changes. False conflicts and pathological cases can be treated with the proposed formulation. The method is verified by case studies, showing that the solution can be quickly calculated.

Using subliminal speed regulation during a time window for aerial deconfliction was explored by Cafieri and Durand.⁵⁶ The problem is modelled and solved as a mixed integer optimisation, the objective of minimising aircraft speed modifications while achieving deconfliction. The performance of an exact solver is shown to deteriorate with the increasing number of aircraft. Therefore, a heuristic based on local exact solutions is proposed, since generally, only a small group of aircraft get potentially in conflict. Using the heuristic, the results have good quality for medium-sized problems. The paper highlights the applicability of subliminal speed regulation in deconfliction.

Conflict resolution is also treated as a mixed integer linear programming problem by Cecen and Cetek.⁵⁷ Conflicts are resolved by changing entry points and speed before entering an airspace block because speed changing was identified as the best long-term resolution strategy. Aircraft motion is presumed to be deterministic for a one direction traffic flight level; thus, critical crossing points can be calculated, enabling space discretisation. Minimum separation is defined in terms of time. The set of possible airspeed values is also discrete. For efficient computation, a heuristic model is presented, which produces near-optimal solutions in a reasonably short time. However, the algorithm cannot take into account path or speed deviations and contains no feedback; therefore, its robustness is questionable. Also, the method needs a central entity to perform coordination.

New formulations for mixed integer programming are presented by Dias, Hijazi and Rey.⁵⁸ It is shown that disjunctive linear separation conditions are equivalent to traditionally used nonlinear separation conditions. The disjunctive linear separation conditions are nonconvex, so convex relaxation is applied. In 2D, speed and heading changes are both permitted (with preference weighting), and flight level changes are also available after extending the solution with lexicographic optimisation. The method is demonstrated to be scaleable by applying it to several benchmarking problems. It is reported that 87.8% of problems are successfully solved. The method shows promising results and could be adapted for different airspace environments, for example, urban air mobility.

As an alternative to mixed integer optimisation methods ant colony optimisation was proposed by Durand and Alliot.⁵⁹ In their seminal paper, they managed to solve problems (in the circular benchmark scenario) for up to 30 aircraft. Manoeuvres are modelled as heading changes and return to the original path. Each aircraft is represented as an ant colony, and a probabilistic optimisation method is used to optimise trajectories. The paper shows the potential for the use of probabilistic methods for deconfliction. However, no results for realistic simulation scenarios are presented.

A collision avoidance method for cooperative UAV clusters can be formulated by employing the complex network algorithm.⁶⁰ An important advantage of the approach is that only one resolution is necessary at a time, instead of a sequence of manoeuvres. Conflicts are detected for a given scenario by path extrapolation, based on which the network model can be constructed. For resolution, the key node is selected, and the sense is determined as a solution of an optimisation problem. The objective cost takes into account the number of intruder designated directions, network robustness and the connected component. It is assumed that by minimising the cost the domino effect is also reduced. To apply the method outlined, it is necessary to have global communication between all UAVs and global information needs to be instantaneously available, therefore the practical scalability of the method remains in question.

Using rolling optimisation and predictive state space an efficient collision prediction and avoidance method can be formulated.⁶¹ The airspace shared by all aircraft is divided into cubic cells, and time is discretised to time steps to enable efficient computation; thus, the set of available next waypoints is also limited. The next waypoint is selected according to the roulette method, while also taking into account distance to the goal and heading deviation. Conflict free trajectories are generated by iteration and shortened by using rolling optimisation, minimising flight distance. The algorithm is capable of handling several aircraft at the same time and resolving multiple aircraft conflicts. A weakness of the method is that it needs a central entity with global information to perform the computations, which may be prohibitive as the number of aircraft increases.

A metric to characterise the airspace, complexity is investigated by Koca.⁶² Trajectories are defined as a series of 4D waypoints. Based on these, a hierarchical method is outlined to define clusters by identifying relevant aircraft according to spatio-temporal boxes. Also, an ecosystem structure is introduced, taking into account the possible manoeuvres. Simulation results show a shift towards ecosystems with more members in a futuristic traffic scenario. Taking into account ecosystem interdependencies a better insight can be gained to understand underlying airspace dynamics. The definition of complexity and the calculation method presented may help air traffic control officers understand a situation better and resolve conflicts more efficiently, but provides no aid for airspace design.

Global, aggregate, system-level dynamics are usually modelled using macroscopic fundamental diagrams for ground vehicles. The existence of MFDs was demonstrated experimentally, in a large urban area by analysing data gathered.⁶³ Using the MFD, gating regulators can be designed to improve mobility.⁶⁴ Since the basic dynamics of the system are given by the MFD, robust feedback regulators can be designed, which can reduce overall, system-wide delay. An optimal solution for perimeter flow control is given by Aalipour.⁶⁵ The paper derives a heterogeneous two-region model, with perimeter controllers as a way to influence traffic flow between the regions. The optimal control policy is derived using Pontryagin’s maximum principle and the Hamilton–Jacobi–Bellman equation and solved by the Chebyshev pseudospectral approach. The paper demonstrates how, if the macroscopic dynamics are appropriately modelled, it is possible to maximise the number of vehicles arriving at their destination within a given time period. This underlines the necessity and importance of the research presented in the current paper.

Reviewing the related literature shows the extent and depth of research into conflict resolution for aerial vehicles. However, no analysis was yet performed to assess how conflict avoidance manoeuvres affect global, system-level characteristics in a stochastic environment. The aim of this paper is to address this issue. It should also be emphasised that the method presented and analysed can be implemented in a distributed manner, unlike any of the methods reviewed.

Directional quantities

To better understand how air traffic conflicts occur in the proposed framework for global ensemble dynamics coordination, directional conflict distribution according to approach angle is calculated using an analytical method. The technique has been previously used by the authors to create the directional probability maps. Full and truncated exponential and normal distributions were defined as prescribed speed distributions for the ownship and the intruder.

It is assumed that there is a range around the ownship within which it can sense an intruder, this is the sensing range $(r_{S})$ . Another, smaller range is defined around the ownship, the conflict range $(r_{C})$ . The event when the intruder reaches this range is called a geometric conflict. If the time taken during traversal between intruding the sensing and the conflict range is below a threshold, the event is called a speed conflict.

Conflict probability distributions according to the angle where the intruder is sensed on the sensing range $(δ)$ were calculated both for geometric and speed conflicts.

Geometric conflict probability can be calculated according to the following derivation. Both the ownship $(v_{ownship} = v_{o})$ and the intruder $(v_{intruder} = v_{i})$ speed distributions are given and the intruder heading $(θ)$ distribution (as a first approximation) is assumed uniform. Prescribed speed probabilities are either exponential or normal. To account for minimal and maximal speed limits, truncation of the distribution is also taken into account. Parameters are chosen so that the average speed of agents is realistic, between 20 kts and 90 kts. Speed range was selected according to the predicted speed range and performance characteristics of personal aerial vehicles.^3,37 For the minimum speed, handling characteristics were taken into account.^66,67 Therefore, for exponential distribution parameters were chosen as $a, b = [0.0025, 0.2]$ and for normal distribution the parameter range was selected as $μ, ν = [5,90]$ .

The ratio of velocities is defined as Equation (3).

f = \tan (γ) = \frac{v_{o}}{v_{i}}

(3)

The probability distribution of the apparent path angle $(Ω)$ can be derived by applying Equation (4).

{\begin{array}{l} Ω = \arctan (\frac{\tan γ}{\sin θ} + \cot θ) & i f 0 < θ < π \\ Ω = π + \arctan (\frac{\tan γ}{\sin θ} + \cot θ) & i f - π < θ < 0 \\ Ω = \frac{π}{2} & i f θ = 0 \\ Ω = \frac{π}{2} & i f θ = π \land v_{O} \geq v_{I} \\ Ω = - \frac{π}{2} & i f θ = π \land v_{O} < v_{I} \end{array}

(4)

This can then be compared to the angular diameters related to conflict, defined based on the angle corresponding to the conflict range from the entry point on the sensing range. Angular diameter is defined according to Equation (5).

d_{r_{C}} = δ \pm \arcsin (\frac{r_{C}}{r_{S}})

(5)

To simplify calculations, the tangent of both sides is taken. For speed conflicts, the traversal time from the sensing to the conflict range is also taken into account as intrusions are considered conflicts if the traversal time from the sensing range to the conflict range is less than a threshold $(t_{th})$ . The distance to be traversed by the intruder is denoted by d_traversal, the time taken is defined by Equation (6), where v denotes the resultant speed (Equation (7)).

t_{traversal} = \frac{d_{travelled}}{v}

(6)

v_{res} = v_{O} \sin Ω + v_{I} \sin (θ + Ω)

(7)

Since the integral corresponding to the actual traversal time cannot be evaluated, a lower and upper approximation is applied (Equation (8)). Also, the integration region is transformed from polar to Cartesian coordinates.

r_{S} - r_{C} \leq d_{traversal} \leq \sqrt{r_{S}^{2} - r_{C}^{2}}

(8)

Previously, calculations were based upon the assumption that the probability of appearance of an intruder on the sensing range is uniform. However, in real flight scenarios, this might not be the case. Therefore this assumption is relaxed. Within the scope of the paper, it is assumed that aircraft have a uniform position distribution, which was determined to be the safest.⁶⁸

The position of potential intruders is taken relative to the ownship as x and y, in a right-handed coordinate system aligned with the ownship heading. The position can also be given by polar coordinates as $δ_{0} = \arctan (\frac{y}{x})$ and $R = \sqrt{x^{2} + y^{2}}$ .

As an example, for perpendicular intruders $(θ = \frac{π}{2})$ , assuming unit density, the number of intruders arriving at the sensing range within time t_l for a given δ can be calculated as given by Equation (9).

\begin{array}{l} ℙ_{perp} (r_{S}) = \\ \int_{0}^{\frac{π}{2}} \int_{0}^{\infty} \int_{0}^{\infty} \cos (γ - δ) Δ (\frac{d_{travelled}}{v} \leq t_{l}) \\ v ℙ_{a} (v_{o} = v \cos (γ)) ℙ_{b} (v_{i} = v \sin (γ)) d R d v d γ \end{array}

(9)

The distance travelled $(d_{travelled})$ can be approximated according to Equation (10).

R - r_{S} \leq d_{travelled} \leq \sqrt{R^{2} - r_{S}^{2}}

(10)

The function Δ is defined according to Equation (11).

Δ (x \leq y) = {\begin{array}{l} 1 & i f x \leq y \\ 0 & e l s e \end{array}

(11)

Speed distributions $(ℙ_{a} (v_{o} = v \cos (γ)))$ and $(ℙ_{b} (v_{i} = v \sin (γ)))$ can be either truncated exponential distributions as defined by Equation (12) or truncated normal distributions as defined by Equation (13).

ℙ_{λ} (v = z, l, u) = {\begin{array}{l} \frac{λ e^{- λ z}}{e^{- λ l} - e^{- λ u}} & i f l \leq z \leq u \\ 0 & e l s e \end{array}

(12)

\begin{array}{l} ℙ_{η} (v = z, l, u) = \\ {\begin{array}{l} \frac{\frac{1}{\sqrt{2 π} σ} e^{- \frac{1}{2} {(\frac{z - η}{σ})}^{2}}}{\frac{1}{2} (e r f (\frac{u - η}{\sqrt{2} σ}) + 1) - \frac{1}{2} (e r f (\frac{l - η}{\sqrt{2} σ}) + 1)} & i f l \leq z \leq u \\ 0 & e l s e \end{array} \end{array}

(13)

The number of intruders was determined to scale linearly with agent density and elapsed time. To verify the formula, Monte Carlo simulations were performed for a range of parameters. During the simulations, intruders are randomly placed onto the playground and filtered according to the magnitude of the closing rate. Speeds are assigned according to the prescribed distribution. Then, the angle of the apparent path, arrival time at the sensing range and intrusion angle are calculated; thus, the number of intruders can be collected. Correcting for density and simulation time, the results match appropriately for all distribution parameters investigated (Figure 1).

Figure 1.

Directional distribution of perpendicular intrusion influx for truncated exponential speed distribution $(θ = π / 2, l = 15 kts, u = 180 kts, d_{travelled} \approx R - r_{s})$ .

The results of the Monte Carlo simulations are provided in Table A1. The table contains the maximal influxes, the angles where the maximum influx occurs, the maximum and mean difference between the analytical and simulated results and the coefficient of determination.

The scaling factor for the results given by Equation (9) is ρ t_l r_S, where ρ is agent density, which is the average number of agents within a given area $(n_{agent} / area)$ .

In the case of a normal prescribed distribution, calculations can be performed similarly as in the case of exponential distribution by changing the speed distribution probability density functions. For parameters corresponding to the same mean speed, results have a similar magnitude (Figure 2).

Figure 2.

Directional distribution of perpendicular intrusion influx for truncated normal speed distribution $(θ = π / 2, l = 15 kts, u = 180 kts, d_{travelled} \approx R - r_{s})$ .

Taking into account the formula for the angle of apparent path (Equation (4)) the calculation can be extended for arbitrary initial intruder headings (Equation (14)).

\begin{array}{l} ℙ_{θ} (r_{S}) = \int_{0}^{\frac{π}{2}} \int_{0}^{\infty} \int_{0}^{\infty} \cos (Ω - δ) \det (J) \\ Δ (\frac{d_{travelled}}{v} \leq t_{l}) ℙ_{a} (v_{o} = v \csc (θ) \cos (Ω)) \\ ℙ_{b} (v_{i} = - v \csc (θ) \cos (θ + Ω)) d R d v d γ \end{array}

(14)

The determinant of the Jacobian of the velocity projections is given by Equation (15).

\begin{array}{l} \det (J) = \\ = | \begin{matrix} \frac{\partial (v csc (θ) \cos (Ω))}{\partial v} & \frac{(\partial v csc (θ) \cos (Ω))}{\partial Ω} \\ \frac{\partial (- v csc (θ) \cos (θ + Ω))}{\partial v} & \frac{\partial (- v csc (θ) \cos (θ + Ω))}{\partial Ω} \end{matrix} | = \\ = \frac{v}{\sin (2 γ) \cos (θ) + 1} \end{array}

(15)

Results can be verified for both exponential and normal distributions (Figures 3 and 4).

Figure 3.

Directional distribution of intrusion influx for truncated exponential speed distribution $(θ = 3 π / 4, l = 15 kts, u = 180 kts, d_{travelled} \approx R - r_{s})$ .

Figure 4.

Directional distribution of intrusion influx for truncated normal speed distribution $(θ = π / 4, l = 15 kts, u = 180 kts, d_{travelled} \approx R - r_{s})$ .

Assuming all intruder headings have the same probability, integrating for all possible headings provides the general intrusion directional map (Equation (16)).

ℙ_{\bar{θ}} (r_{S}) = \int_{- π}^{π} ℙ_{θ} (r_{S}) d θ

(16)

Calculation results once again have been verified by Monte Carlo simulations (Figure 5). Analytical results are matched better for δ angles around 0° since a higher ratio of the sample can be used for evaluation. The scaling factor for the integral stays ρ t_l r_S to get the number of intrusions for a given scenario.

Figure 5.

Directional distribution of arbitrary heading intrusion influx for truncated exponential and normal speed distributions $(l = 15 kts, u = 180 kts, d_{travelled} \approx R - r_{s})$ .

Results show that the appearance probability on the sensing range is not uniform. Adjusting the boundary conditions of previous calculations assuming uniform appearance distribution gives the geometric conflict probability results for uniform position distribution outside the sensing range. It has been established that geometric conflict probability is related to the angular diameter of the conflict range circle from a point on the sensing range (Equation (5)). The formula thus becomes Equation (17).

\begin{array}{l} ℙ_{θ} (r_{C} | r_{S}) = \int_{0}^{\frac{π}{2}} \int_{0}^{\infty} \int_{0}^{\infty} \cos (Ω - δ) \det (J) \\ Δ (\frac{d_{travelled}}{v} \leq t_{l}) ℙ_{a} (v_{o} = v \csc (θ) \cos (Ω)) \\ Δ (δ - \arcsin (\frac{r_{C}}{r_{S}}) \leq Ω \leq δ + \arcsin (\frac{r_{C}}{r_{S}})) \\ ℙ_{b} (v_{i} = - v \csc (θ) \cos (θ + Ω)) d R d v d γ \end{array}

(17)

To gain the speed conflict probabilities only the intruders fast enough to complete the traversal within the prescribed threshold time need to be taken into account (Equation (18)). This also affects speed distribution, which is shifted from the prescribed to one with a higher average speed.

\begin{array}{l} ℙ_{θ}^{'} (r_{C} | r_{S}) = \int_{0}^{\frac{π}{2}} \int_{0}^{\infty} \int_{0}^{\infty} \cos (Ω - δ) det (J) \\ Δ (\frac{d_{travelled}}{v} \leq t_{l}) Δ (\frac{d_{traversal}}{v} \leq t_{th}) \\ ℙ_{a} (v_{o} = v csc (θ) \cos (Ω)) \\ Δ (δ - arcsin (\frac{r_{C}}{r_{S}}) \leq Ω \leq δ + arcsin (\frac{r_{C}}{r_{S}})) \\ ℙ_{b} (v_{i} = - v csc (θ) \cos (θ + Ω)) d R d v d γ \end{array}

(18)

Evaluating the integrals leads to the results shown in Figures 6 and 7, and can be verified by Monte Carlo simulations.

Figure 6.

Directional distribution of geometric and speed conflict probability for truncated exponential speed distribution $(a = b = 0.0025, θ = π / 2, l = 15 kts, u = 180 kts, d_{travelled} \approx R - r_{s})$ .

Figure 7.

Directional distribution of geometric and speed conflict probability for truncated normal speed distribution $(μ = ν = 90, θ = π / 4, l = 15 kts, u = 180 kts, d_{travelled} \approx R - r_{s})$ .

The calculation method presented can be generalised for arbitrary intruder heading, speed and position distributions. In the current scenario, results show that the maximum intrusion probability corresponds to the ownship heading and decreases with increasing relative heading as expected. Also, the relationship between speed distribution and mean speed (governed by the distribution parameter) and intrusion influx magnitudes are characterised. As the uneven distribution of influx to the sensing range is identified, the boundary conditions for conflict probability calculations could be adjusted, leading to more realistic results.

Integral quantities

In the previous section the Directional quantities (intrusion influxes and conflict probabilities) were calculated. These quantities are directional, as they depend on the relative position of the vehicles. The direction in this case is the direction at which the ownship senses the intruder. Integrating the directional conflict probabilities for all angles provides the total conflict probability for a given distribution parameter. This quantity can be used to describe the relationship between the distribution parameter and conflict probabilities, leading to a system-level understanding.

Safety, as defined by Equation (1) can be calculated as the integral of directional conflict probability for all directions (Figure 8). Results have been compared with multi-agent simulations. In these simulations, agents are placed randomly during initialisation, and they choose their speed by applying one of the following Markov chain task allocation methods: Homogeneous Markov Chain (HMC),²⁶ Inhomogeneous Markov Chain (IMC),⁶⁹ Local Information Consistency Assumption Inhomogeneous Markov Chain (LICA IMC)²⁹ and Asynchronous Local Information Consistency Assumption Inhomogeneous Markov Chain (Async LICA IMC).²⁹ It was found that results in a quasi-steady state are independent of the method applied. Simulation setup and results are explained in detail in another publication by the authors.²⁵ The calculated safety metric was then normalised with the number of agents, simulation area and the radius of the sensing range $(n_{agent} A r_{S})$ . The numerical results can be found in Table A2. The coefficients of determination for safety for the exponential and normal distribution are 0.962 and 0.987, respectively.

Figure 8.

Normalised safety (S) metric according to mean speed – comparison of analytical calculations and multi-agent simulation results (exponential and normal distribution.

Throughput is defined as in Equation (2) and can be calculated as the mean speed corresponding to a parameter, while also taking into account deviations caused by avoidance manoeuvres. Weighting the calculated number of conflicts for a given scenario by the deviation penalty $(P = 0.0091 nmi)$ and adjusting the mean speed leads to Figure 9. Similarly to safety, for throughput the analytical and numerical results correspond to each other. The coefficients of determination for the exponential and normal distribution are 0.962 and 0.995, respectively. It is worth noting that in the multi-agent simulations the states (possible speeds) available for agents are discrete; therefore, this discretisation also needs to be taken into account during calculations.

Figure 9.

Normalised throughput (T) metric according to mean speed – comparison of analytical calculations and multi-agent simulation results (exponential and normal distribution).

Calculation results show that safety and throughput metrics can be analytically calculated from directional conflict probabilities bridging local conflict avoidance and global traffic management and enabling assured safety coordination. The performance difference between exponential and normal distribution is clearly visible, in the medium speed range the exponential prescribed distribution results in higher conflict probability. For lower and higher speeds, the difference decreases. The technique presented can be applied for arbitrary speed distributions, enabling an optimal formulation of the speed distribution. Understanding the relationship between distribution shaping for conflicts and traffic management performance, and their dependence on speed distribution type and the prescribed parameter allows for their simultaneous co-design.

Conclusion

The paper presents a method to calculate air traffic conflict probabilities if both the ownship and the intruder are behaving according to a stochastic distribution. It is also demonstrated that by applying a bottom-analysis of two-aircraft conflict situations and determining the directional conflict maps, high-level, global characteristics of the system may be derived, namely, system-level safety and throughput. Results were in agreement with validation simulations.

This contributes towards the efforts for a distributed airspace management system with prescribed safety bounds since the acceptable conflict probability and the corresponding distribution parameter can be selected a priori. The method presented can be applied for any arbitrary stochastic distribution, within the scope of the paper the exponential and the normal distributions were analysed. It was shown that for the same mean speed, the exponential distribution results in higher conflict probability for the speed range investigated. Since the proposed distributed, stochastic framework is more scalable and robust than the current ATC system it might help overcome certain limitations of current methods.

The research presented also has its limitations. The applied algorithm requires constant communication between the vehicles to drive the ensemble to the prescribed distribution. This communication can be local and asynchronous. For the dissemination of the parameter, however, communication with a global, centralised optimiser is necessary. Within the scope of this paper, only nominal scenarios were investigated. All aircraft are assumed to be cooperative and can be modelled with the same, simplistic kinematic model. The practical applicability of the framework and the computational complexity of the algorithms were not investigated.

Future work consists of an analysis of the performance of different distributions and integration of the framework with low-level avoidance and high-level optimisation techniques. For more general applicability, the methods are planned to be extended into 3D.

Footnotes

Acknowledgements

The authors gratefully acknowledge that this research was supported by the Engineering and Physical Sciences Research Council, under grant EPSRC EP/N509450/1.

Declaration of conflicting interests

The author(s) declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.

Funding

The author(s) disclosed receipt of the following financial support for the research, authorship, and/or publication of this article: This study was supported by the Engineering and Physical Sciences Research Council, under grant EPSRC EP/N509450/1.

Data Availability

The data that support the findings of this study are available from the corresponding author, Zs. Ö., upon reasonable request. The authors confirm that the data supporting the findings of this study are available within the article and its supplementary materials. Raw data is available upon request.

ORCID iDs

Hyo-Sang Shin

Antonios Tsourdos

Table of results for directional quantities

Table A1.

Table of Results for Directional Quantities – R²: coefficient of determination.

Case, distribution and parameter	Maximum value	Maximum value angle	MC Maximum difference	MC Average difference	R ²
Perpendicular influx, exponential, a = b = 0.0025	66.82	45^◦	1.15	0.27	0.988
Perpendicular influx, exponential, a = b = 0.0075	58.86	45^◦	1.14	0.24	0.988
Perpendicular influx, exponential, a = b = 0.0224	40.33	45^◦	0.84	0.16	0.988
Perpendicular influx, exponential, a = b = 0.0669	21.78	45^◦	0.64	0.12	0.984
Perpendicular influx, exponential, a = b = 0.2	14.55	45^◦	0.61	0.12	0.977
Perpendicular influx, normal, μ = ν = 90	65.47	45^◦	1.37	0.27	0.989
Perpendicular influx, normal, μ = ν = 68.75	50.02	45^◦	1.20	0.21	0.988
Perpendicular influx, normal, μ = ν = 47.5	34.57	45^◦	0.98	0.16	0.987
Perpendicular influx, normal, μ = ν = 26.25	20.87	45^◦	0.78	0.13	0.983
Perpendicular influx, normal, μ = ν = 5	14.73	45^◦	0.67	0.12	0.977
θ = 3π/4 influx, exponential, a = b = 0.0025	35.93	67.5^◦	1.48	0.25	0.978
θ = 3π/4 influx, exponential, a = b = 0.0075	31.34	67.5^◦	1.55	0.25	0.975
θ = 3π/4 influx, exponential, a = b = 0.0224	22.05	67.5^◦	1.13	0.14	0.979
θ = 3π/4 influx, exponential, a = b = 0.0669	11.72	67.5^◦	0.40	0.12	0.969
θ = 3π/4 influx, exponential, a = b = 0.2	7.85	67.5^◦	0.91	0.24	0.901
θ = π/4 influx, normal, μ = ν = 90	85.57	22.5^◦	1.78	0.37	0.988
θ = π/4 influx, normal, μ = ν = 68.75	65.27	22.5^◦	1.52	0.28	0.988
θ = π/4 influx, normal, μ = ν = 47.5	45.16	22.5^◦	1.17	0.20	0.988
θ = π/4 influx, normal, μ = ν = 26.25	27.54	22.5^◦	0.78	0.16	0.983
θ = π/4 influx, normal, μ = ν = 5	19.13	22.5^◦	0.683	0.16	0.977
Average influx for all headings, exponential, a = b = 0.0025	48.00	0^◦	2.58	1.10	0.926
Average influx for all headings, normal, μ = ν = 90	46.02	0^◦	5.08	2.07	0.859
Geometric conflicts, θ = π/2, exponential, a = b = 0.0025	0.1308	45^◦	0.036	0.01	0.994
Speed conflicts, θ = π/2, exponential, a = b = 0.0025	0.099	45^◦	0.003	3.3 × 10⁻⁴	0.986
Geometric conflicts, θ = π/4, μ = ν = 90	0.90	22.5^◦	0.044	0.002	0.966
Speed conflicts, θ = π/4, μ = ν = 90	0.88	22.5^◦	0.042	0.002	0.966

Table of results for integral quantities

Table A2.

Table of Results for the Integral Quantities – Kts: speed in knots, S: safety, T: throughput, an: analytical, MC: Monte Carlo, exp: exponential distribution, norm: normal distribution.

Kts	S, an, exp	S, MC, exp	S, an, norm	S, MC, norm	T, an, exp	T, MC, exp	T, an, norm	T, MC, norm
20.79	0	0	0	0.0000	9.5910	9.4066	9.9299	9.9515
21.41	0	0	0	0.0000	9.8940	9.6980	10.2871	10.3521
22.14	0	0	0	0.0000	10.2504	10.0783	10.7052	10.6837
22.98	0	0	0	0.0000	10.6687	10.4917	11.1930	11.2371
23.96	0.0002	0	0	0.0000	11.1582	10.9007	11.7593	11.7279
25.09	0.0007	0.0005	0	0.0000	11.7278	11.5178	12.4121	12.4099
26.39	0.0023	0.0043	0	0.0000	12.3856	12.0911	13.1568	13.1753
27.88	0.0064	0.0036	0	0.0000	13.1372	12.8540	13.9962	14.0566
29.54	0.0156	0.0082	0	0.0000	13.9845	13.6585	14.9282	14.9105
31.39	0.0339	0.0278	0	0.0000	14.9250	14.3249	15.9464	15.9451
33.40	0.0651	0.0618	0	0.0000	15.9517	15.4931	17.0400	17.0547
35.55	0.1136	0.1017	0	0.0002	17.0532	16.6300	18.1955	18.3128
37.82	0.1815	0.1442	0.0003	0.0002	18.2159	17.6125	19.3980	19.2210
40.18	0.2693	0.2378	0.0010	0.0010	19.4257	18.9585	20.6339	20.6294
42.59	0.3773	0.3739	0.0032	0.0035	20.6696	20.4479	21.8917	21.8152
45.04	0.5008	0.4606	0.0088	0.0069	21.9371	21.3957	23.1625	23.0209
47.52	0.6395	0.5757	0.0229	0.0244	23.2205	22.5216	24.4403	24.4513
50.01	0.7908	0.7203	0.0508	0.0534	24.5148	23.8905	25.7211	25.7491
52.50	0.9558	0.8844	0.1021	0.1016	25.8164	25.3149	27.0022	26.9681
55.00	1.1248	1.1013	0.1847	0.1899	27.1243	26.8581	28.2820	28.2544
57.50	1.3071	1.2530	0.3626	0.3527	28.4367	27.9483	29.5555	29.6225
60.00	1.4788	1.3409	0.5500	0.5171	29.7547	28.7220	30.8286	30.7876
62.50	1.6665	1.5247	0.7623	0.7473	31.0759	30.1198	32.1000	31.9940
65.00	1.8491	1.7787	1.0743	1.0568	32.4014	31.8788	33.3645	33.3483
67.50	2.0441	1.9695	1.3512	1.3466	33.7299	33.1079	34.6315	34.6392
70.00	2.2399	2.1115	1.6042	1.6491	35.0616	34.0660	35.9001	35.7916
72.50	2.4358	2.4306	2.0120	1.9816	36.3966	36.3735	37.1581	37.2261
75.00	2.6113	2.6519	2.2549	2.2130	37.7358	37.6585	38.4275	38.3830
77.50	2.8265	2.8174	2.4943	2.5139	39.0748	38.8575	39.6971	39.7696
80.00	3.0254	3.0449	2.7562	2.7509	40.4172	40.0787	40.9652	41.0283
82.50	3.2236	3.3059	2.9392	2.9756	41.7617	41.9490	42.2387	42.2952
85.00	3.4338	3.5038	3.1333	3.2033	43.1070	43.0707	43.5114	43.5462
87.50	3.6014	3.7164	3.3506	3.4107	44.4566	44.6238	44.7826	44.7321
90.00	3.8131	3.9528	3.5541	3.6072	45.8043	46.0625	46.0547	45.9130

References

The Boeing Co.: Commercial Market Outlook

2019-2038. Available online: http://boeing.com/cmo

Kopardekar

. Unmanned aerial system (UAS) traffic management (UTM): enabling low-altitude airspace and UAS operations. NASA/TM—2014–218299, 2014.

UBER Elevate . Fast-forwarding to a future of on-demand urban air transportation, 2020. Available online http://uber.com/elevate

Airbus UTM . Blueprint for the sky: the roadmap for the safe integration of autonomous aircraft. Available online https://www.airbusutm.com/uam-resources-airbus-blueprint 2020.

Prescient & Strategic Intelligence . Urban air mobility market size, share, study by component (infrastructure, platforms), by operations (piloted and autonomous) by range (intercity and intracity), and segment forecasts, 2023-2030. Report Code: AT11992, February 2020. Available online https://www.psmarketresearch.com/market-analysis/urban-air-mobility-market

Morgan Stanley Research . eVTOL/urban air mobility TAM update: a slow take-off, but sky’s the limit, 2021. Report ID: 5310940.

MarkNTel Advisors . Global urban air mobility market research report: forecast (2021-2026), 2021. Report Code: AT55001 Available online https://www.marknteladvisors.com/research-library/global-urban-air-mobility-market.html

Emergen Research . Urban air mobility market by component (infrastructure, platform), by operations (piloted, autonomous, hybrid), by range (intercity, intracity), and by region, forecasts to 2027, 2020. Report ID: ER_00314. Available online https://www.emergenresearch.com/industry-report/urban-air-mobility-market

Reports and Data . Urban air mobility market size, share, study by component (infrastructure, platforms), by operations (piloted and autonomous) by range (intercity and intracity), and segment forecasts, 2023-2030, 2020. Report ID: RND_001185. Available online https://www.reportsanddata.com/report-detail/urban-air-mobility-market

10.

Mordor Intelligence . Urban air mobility market - growth, trends, COVID-19 impact, and forecasts (2021-2035), 2021. Report ID: 4897292. Available online https://www.mordorintelligence.com/industry-reports/urban-air-mobility-uam-market

11.

Markets and Markets . Urban air mobility market by component (infrastructure, platform), platform operation (piloted, autonomous), range (intercity, intracity), platform architecture, unmanned platform systems, end user and region - global forecast to 2030, 2021. Report Code: AS 6957. Available online https://www.marketsandmarkets.com/Market-Reports/urban-air-mobility-market-251142860.html

12.

BIS Research . Urban air mobility (UAM) market - a global and regional analysis: focus on range, application, ecosystem, operation, end-user, platform architecture, and country - analysis and forecast, 2023-2035, 2021. Report ID: 5310940. Available online https://bisresearch.com/industry-report/global-urban-air-mobility-market.html

13.

National Aeronautics and Space Administration . NASA embraces urban air mobility, calls for market study. Available online https://www.nasa.gov/aero/nasa-embraces-urban-air-mobility (2017).

14.

Vascik

Hansman

. Scaling constraints for urban air mobility operations: air traffic control, ground infrastructure, and noise. In: 2018 Aviation Technology, Integration, and Operations Conference, 2018, DOI: 10.2514/6.2018-3849.

15.

Thipphavong

Apaza

Barmore

, et al. Urban air mobility airspace integration concepts and considerations. In: AIAA Aviation Forum (Aviation 2018). Atlanta, GA, United States, 2018, DOI: 10.2514/6.2018-3676.

16.

Federal Aviation Administration . Unmanned aircraft system (UAS) traffic management (UTM) - concept of operations. U.S. Department of Transportation. Version 2.0. 2020.

17.

Goyal

. Urban air mobility (UAM) market study. Booz-allen and Hamilton, inc., HQ-E-DAA-TN65181. McLean, VA, United States, 2018.

18.

Yang

Wei

. Scalable multi-agent computational guidance with separation assurance for autonomous urban air mobility, J Guid Control, Dyn 2020; 43(8): 1473–1486, DOI: 10.2514/1.G005000.

19.

Schultz

Shaner

Zhao

. Free-flight concept. In: AIAA paper, 1997, pp. 3677–3697, DOI: 10.2514/6.1997-3677.

20.

Valavanis

. The entropy based approach to modeling and evaluating autonomy and intelligence of robotic systems. J Intell Robotic Syst 2018; 91(7): 7–22, DOI: 10.1007/s10846-018-0905-6.

21.

Krozel

Peters

Bilimoria

. A decentralised control strategy for distributed air/ground traffic separation. In: AIAA paper 2000-4062, 2000, DOI: 10.2514/6.2000-4062.

22.

Ren

Beard

Atkins

. Information consensus in multivehicle cooperative control. IEEE Control Syst Mag 2007; 27(2): 71–82, DOI: 10.1109/MCS.2007.338264.

23.

Rastgoftar

Kwatny

HGE

Atkins

. Asymptotic tracking and robustness of MAS transitions under a new communication topology. Trans Automation Sci Eng 2018; 15(1): 16–32, DOI: 10.1109/TASE.2016.2547885.

24.

Alonso-Ayuso

Escudero

Martin-Campo

. Collision avoidance in the air traffic management: a mixed integer linear optimization approach. In: IEEE transactions on intelligent transportation systems, 2011, DOI: 10.1109/TITS.2010.2061971.

25.

Öreg

Shin

H-S

Tsourdos

. Traffic conflict reduction based on distributed stochastic task allocation. Aeronaut J 2022; 126: 993–1025, DOI: 10.1017/aer.2021.119.

26.

Acikmese

Bayard

. Markov chain approach to probabilistic guidance for swarms of autonomous agents. Asian J Control 2015; 17(4): 1105–1124, DOI: 10.1002/asjc.982.

27.

Egorov

Kuroda

Sachs

. Encounter aware flight planning in the unmanned airspace. In: 2019 Integrated Communications, Navigation and Surveillance Conference (ICNS). Herndon, VA, USA, 2019, pp. 1–15, DOI: 10.1109/ICNSURV.2019.8735399.

28.

Joint Authorities for Rulemaking of Unmanned Systems . JARUS guidelines on specific operations risk assessment (SORA). In: JAR-DEL-WG6-D.04, 2019. Available online http://jarus-rpas.org/sites/jarus-rpas.org/files/jar_doc_06_jarus_sora_v2.0.pdf

29.

Jang

H-Shin

Tsourdos

. Local information-based control for probabilistic swarm distribution guidance. Swarm Intelligence 2018; 12: 327–359, DOI: 10.1007/s11721-018-0160-2.

30.

Yang

Han

Borst

, et al. Impact of aircraft speed heterogeneity on contingent flow control in 4D en-route operation. Transportation Res C: Emerging Tech 2020; 119: 102746, DOI: 10.1016/j.trc.2020.102746.

31.

Verma

Monheim

Moolchandani

, et al. Lessons learned: using UTM paradigm for urban air mobility operations. In: 2020 AIAA/IEEE 39th Digital Avionics Systems Conference (DASC), 2020, DOI: 10.1109/DASC50938.2020.9256650.

32.

Paul

Patterson

Varela

. Conflict-aware flight planning for avoiding near mid-air collisions. In: 2019 IEEE/AIAA 38th Digital Avionics Systems Conference (DASC), 2019, DOI: 10.1109/DASC43569.2019.9081658.

33.

Song

Yeo

. Development of optimal scheduling strategy and approach control model of multicopter VTOL aircraft for urban air mobility (UAM) operation. In: Transportation research Part C: emerging technologies, 2021, DOI: 10.1016/j.trc.2021.103181.

34.

Rigas

Kolios

. Scheduling aerial vehicles in an urban air mobility scheme. In: 2021 IEEE Vehicular Networking Conference (VNC), 2021, DOI: 10.1109/VNC52810.2021.9644626.

35.

Sedov

Polishchuk

. Centralized and distributed UTM in layered airspace. In: International Conference on Research in Air Transportation, 2018.

36.

Salleh

MFBM

Wanchao

Wang

, et al. Preliminary concept of adaptive urban airspace management for unmanned aircraft operations, AIAA 2018-2260. In: 2018 AIAA Information Systems-AIAA Infotech, 2018, DOI: 10.2514/6.2018-2260.

37.

Sunil

Ellerbroek

Hoekstra

, et al. Analysis of airspace structure and capacity for decentralized separation using fast-time simulations. J Guidance, Control Dyn 2017; 40(1): 38–51, DOI: 10.2514/1.G000528.

38.

Rodionova

Pant

Jang

, et al. Learning-to-Fly: learning-based collision avoidance for scalable urban air mobility. In: 2020 IEEE 23rd International Conference on Intelligent Transportation Systems (ITSC), 2020, DOI: 10.1109/ITSC45102.2020.9294425.

39.

Kuchar

JKL

Yang

. A review of conflict detection and resolution modeling methods,. IEEE Trans Intell Transportation Syst 2000; 1(4): 179–189, DOI: 10.1109/6979.898217.

40.

Mahjri

Dhraief

Belghith

, et al. SLIDE: a straight line conflict detection and alerting algorithm for multiple unmanned aerial vehicles. IEEE Trans Mobile Comput 2018; 17(5): 1190–1203, DOI: 10.1109/TMC.2017.2750144.

41.

Windhorst

Lauderdale

Sadovsky

, et al. Strategic and tactical functions in an autonomous air traffic management system. In: AIAA AVIATION 2021 FORUM. AIAA 2021-2355, 2021, DOI: 10.2514/6.2021-2355.

42.

Yang

Egorov

Evans

, et al. Stress testing of UAS traffic management decision making systems. In: AIAA AVIATION 2020 FORUM. AIAA 2020-2868, 2020, DOI: 10.2514/6.2020-2868.

43.

Rebollo

Ollero

. Collision avoidance among multiple aerial robots and other non-cooperative aircraft based on velocity planning. In: ROBOTICA 2007-7th Conference on Mobile Robots and Competitions. Albufeira, Portugal, 2007.

44.

Rey

Rapine

Fondacci

, et al. Subliminal speed control in air traffic management: optimization and simulation. Transportation Sci 2016; 50(1): 240–262, DOI: 10.1287/trsc.2015.0602.

45.

Wan

Tang

Lao

. Research on the collision avoidance algorithm for fixed-wing UAVs based on maneuver coordination and planned trajectories prediction. Appl Sci 2019; 9(4): 798, DOI: 10.3390/app9040798.

46.

Tompa

Wulfe

Kochenderfer

, et al. Horizontal maneuver coordination for aircraft collision-avoidance systems. J Aerospace Inf Syst 15 2018; 2: 92–106. DOI: 10.2514/1.I010576.

47.

Yang

Zhang

Cai

, et al. Multi-aircraft conflict detection and resolution based on probabilistic reach sets. IEEE Trans Control Syst Technol 2017; 25(1): 309–316, DOI: 10.1109/TCST.2016.2542046.

48.

Mitici

Blom

. Mathematical models for air traffic conflict and collision probability estimation. IEEE Trans Intell Transportation Syst 2019; 20(3): 1052–1068, DOI: 10.1109/TITS.2018.2839344.

49.

Pelegrín

Ambrosio

. Airspace conflict resolution: a unifying mathematical framework and review, 2020.

50.

Hwang

Chze

Seah

. Intent-based probabilistic conflict detection for the next generation air transportation system. Proc IEEE 2008; 96(12): 2040–2059, DOI: 10.1109/JPROC.2008.2006138.

51.

Blom

HAP

Bakker

Klein Obbink

, et al. Free flight safety risk modelling and simulation. In: 2nd International Conference on Research in Air Transportation ICRAT. Belgrade, 2006.

52.

Luongo

Di Vito

Corraro

. An advanced 3D algorithm for automatic separation assurance systems. In: 2012 20th Mediterranean Conference on Control & Automation (MED). Barcelona, 2012, pp. 1572–1578, DOI: 10.1109/MED.2012.6265863.

53.

Huang

Tang

Lao

. Collision avoidance method for self-organizing unmanned aerial vehicle flights. IEEE Access 2019; 7: 85536–85547, DOI: 10.1109/ACCESS.2019.2925633.

54.

Tang

Zhu

Piera

, et al. A causal encounter model of traffic collision avoidance system operations for safety assessment and advisory optimization in high-density airspace. Transportation Res Part C: Emerging Tech 2018; 96: 347–365, DOI: 10.1016/j.trc.2018.10.006.

55.

Tang

Piera

MAT

Guasch

. Coloured Petri net-based traffic collision avoidance system encounter model for the analysis of potential induced collisions. Transportation Res Part C: Emerging Tech 2016; 67: 357–377, DOI: 10.1016/j.trc.2016.03.001.

56.

Cafieri

Durand

. Aircraft deconfliction with speed regulation: new models from mixed-integer optimization, Journal of Global Optimization. Springer Verlag (Germany) 2014; 58(4): 613–629, DOI: 10.1007/s10898-013-0070-1.

57.

Cecen

Cetek

. Conflict-free en-route operations with horizontal resolution manoeuvers using a heuristic algorithm. Aeronaut J 2020; 124: 767–785, DOI: 10.1017/aer.2020.5.

58.

Dias

FHC

Hijazi

Rey

. Disjunctive linear separation conditions and mixed-integer formulations for aircraft conflict resolution. Eur J Oper Res 2021; 296(2).

59.

Durand

Alliot

J-M

. Ant colony optimization for air traffic conflict resolution. In: Eighth USA/Europe Air Traffic Management Research and Development Seminar (ATM2009), 2009.

60.

Huang

Tang

Lao

. Cooperative multi-UAV collision avoidance based on a complex network. Appl Sci 2019; 9(19): 3943, DOI: 10.3390/app9193943.

61.

Tang

Bai

, et al. Collision avoidance for cooperative UAVs with rolling optimization algorithm based on predictive state space. Appl Sci 2017; 7(4): 329, DOI: 10.3390/app7040329.

62.

Koca

Piera

Radanovic

. A methodology to perform air traffic complexity analysis based on spatio-temporal regions constructed around aircraft conflicts. IEEE Access 2019; 7: 104528–104541.

63.

Geroliminis

Daganzo

. Existence of urban-scale macroscopic fundamental diagrams: some experimental findings. Transportation Res B 2008; 42(9): 759–770, DOI: 10.1016/j.trb.2008.02.002.

64.

Keyvan-Ekbatania

Kouvelasb

Papamichaila

, et al. Exploiting the fundamental diagram of urban networks for feedback-based gating. Transportation Res Part B 2012; 46(10): 1393–1403, DOI: 10.1016/j.trb.2012.06.008.

65.

Aalipour

Kebriaei

Ramezani

. Analytical optimal solution of perimeter traffic flow control based on MFD dynamics: a Pontryagin’s maximum principle approach. Trans Intell Transportation Syst 2019; 20(9): 3224–3234, DOI: 10.1109/TITS.2018.2873104.

66.

Gerboni

Venrooij

Nieuwenhuizen

, et al. Control augmentation strategies for helicopters used as personal aerial vehicles in low-speed regime. In: AIAA paper 2016-2137, 2016, DOI: 10.2514/6.2016-2137.

67.

Perfect

Jump

White

. Handling qualities requirements for future personal aerial vehicles. J Guidance, Control Dyn 2015; 38(12): 2386–2398, DOI: 10.2514/1.G001073.

68.

Endoh

. Aircraft collision models, Massachusetts institute of technology. In: Flight transportation laboratory. Technical Report, 1982, p. 13223217, http://hdl.handle.net/1721.1/68072

69.

Bandyopadhyay

Chung

S-J

Hadaegh

. Probabilistic and distributed control of a large-scale swarm of autonomous agents. IEEE Trans Robotics 2017; 33(5): 1103–1123, DOI: 10.1109/TRO.2017.2705044.
