Engaging schools in the science of low-energy buildings

1. Introduction

The World Summit on Sustainable Development (WSSD, 2002) and the Sustainable Development Action Plan Brighter Futures – Greener Lives issued by the Department for Children, Schools and Families (DCSF, 2008) both argue for a UK population that is educated to understand sustainable development. This is a challenge that some UK schools were in a unique position to meet as a result of the “Building Schools for the Future” initiative. Building Schools for the Future (BSF) was a national initiative that aimed to use building design to support 21st-century education (Teachernet, 2009). The aim to increase standards of education was coupled with the opportunity to greatly reduce energy use, by developing carbon neutral schools.

The project “Engaging Pupils, Teachers and Governors in the Science, Engineering and Technology of Carbon ‘Neutral’ Schools” embraced the opportunity that BSF provided and strengthened the link between education for sustainable development (ESD) and the design and construction of new school buildings. Additionally, through the use of the sustainable development of school buildings, the research aimed to increase pupils’ interest in science and engineering. Researchers engaged with four schools in Leicester city, UK that were within Phase 1 of the BSF process. Experts from the Institute of Energy and Sustainable Development at De Montfort University, Leicester facilitated multiple engagement events for pupils, teachers and governors of the schools to increase their knowledge and understanding of issues surrounding climate change, and the science and engineering associated with low-energy school buildings. The project resulted in a number of discussions between school pupils, designers, architects and policy makers in which pupils expressed their requirements for a more energy-efficient school, using sophisticated terminology and complex design ideas. These ideas included the need to reduce energy demand across the school, the wish for more natural day lighting, the acknowledgement of site orientation for the maximization of solar gain and the aspiration for renewable technologies for use within lessons. The article demonstrates how engagement mechanisms were successfully employed and resulted in an increase in the knowledge and understanding of the sustainable development of low-energy school buildings.

2. Research context

The majority of current UK schools were designed either in the late 19th century by the Victorians, or in the post-war years of 1945–75. Many Victorian schools lack essential features and are in need of major and costly repair, and, additionally, those built in the post-war era have been severely criticized for failing to function effectively (Bentley et al., 2001). Subsequently, the BSF initiative was long overdue and had the potential to restructure not only buildings for future learning and teaching, but also to substantially improve the quality of that education. The programme was a key part of the previous government’s agenda for education reform (Teachernet, 2007) and subsequently it was suggested that the key driver and measure of its success would be the impact that the new schools have on teaching and learning transformation and how they contribute to an improved standard of education (LMEC, 2008). The positive impact that well-designed school buildings and environments have on their occupants’ everyday lives and wellbeing has been well researched (Olson and Kellum, 2003; Vaughan, 2009). Additionally, authors suggest that well-designed school buildings and environments can have a positive impact on attendance, behaviour and academic achievement (Durán-Narucki, 2008). In terms of the built environment, for instance, environmental psychologists have found that factors such as acoustics, air quality, light levels, noise levels and temperature all have measurable effects on individual performance by varying individuals’ levels of attention and alertness, concentration and effectiveness (Bentley et al., 2001).

There is a concern, however, that despite the wealth of design talent in the UK, we do not currently have the expertise required to design these innovative, sustainable and inspirational environments. Bentley et al. (2001) reported that out of the seven designers working on their school design project “not one had worked directly with schools before and hardly any could name a professional that had.” They concluded that if designers have no sense of the outcomes that the educational system is striving to deliver, or of the social and organizational characteristics of school life, it is difficult to see how they can design with these factors in mind.

The engagement and participation of pupils and teachers has been identified as one solution to this concern. The House of Commons report surrounding the BSF initiative suggested that the early engagement of the whole school community is an important part of the development process. It strongly encourages what is now common practice for key stakeholders, including school staff and pupils, to work collaboratively to develop a building brief (House of Commons Education and Skills Committee Report, 2006–07). Literature suggests that engaging pupils in the development of their new schools should come hand in hand with education for sustainable development. Scott (2002) advises that we ought to want schools to help learners develop critical understandings of sustainable development, and to achieve levels of critical environmental literacy that will enable them to develop and continually adapt their own understandings and make up their own minds as to how (and whether) to change the ways that they live. It would be more ethical, and more useful, were we to acknowledge that the purpose of education in relation to sustainable development was to explore the concept and its implications, tolerating different views in this process, rather than to persuade people to accept it, whatever its implications. A recent review of best practice concerning schools engagement with sustainability has been conducted by Symons (2008). The report suggests that those schools that have embedded sustainability report a range of positive outcomes including higher levels of attainment or “value-added progress” (Jackson, 2007), a motivator of enthusiasm and interest (Symons, 2008) and many found that ESD provided a useful vehicle for organizing and coordinating aspects of Every Child Matters (Ofsted, 2008). However, currently it appears that young people’s knowledge of natural resources and the environment can be patchy, mediated more through television than first-hand experience. Additionally, although The National Curriculum has, for many years, included specific references to sustainable development there is limited literature surrounding the success of ESD and, additionally, based on the findings from BSF Phase 1, there is substantial room for improvement (DSCF, 2008). Ofsted (2008) stated that most of the schools involved in their study had limited knowledge of sustainability and work in this area tended to be uncoordinated, often confined to special events rather than being an integral part of the curriculum. Consequently they recommended that:

Additionally, the Ofsted report suggests that pupils should not only have substantial knowledge surrounding sustainable development but that “they should develop the ability to discuss and debate issues at a sophisticated level, presenting well-argued opinions and considering the views of others.” Subsequently it appears that involving pupils in the design process is necessary, not only for the education of future generations, but additionally to provide designers with invaluable insight and guidance surrounding the requirements of a new school building.

3. Engaging young people in the development of low-energy schools

Having identified the need to involve young people in the development of their new schools, discussion now needs to concern ways in which this can best be achieved. Work has been undertaken on the link between educational programmes and changing the attitudes of pupils towards environmental problems (Devine-Wright et al., 2004). One major concern surrounding education is that many pupils are no longer finding scientific subjects interesting. It is suggested that although there is great potential, school science fails to convey the extent to which science is related to everyday life and affects all of us (Planet Science, Science Museum and Institute of Education, University of London, 2003). The National Curriculum states that real-world applications of science are an important part of the brief to enrich students’ curriculum experience. Science is not restricted to the laboratory, but is highly relevant to life outside school and the world of work in particular, (National Curriculum in Action, 2009). Space needs to be made to allow controversial issues to be included and to allow topics to be studied in more depth, (Planet Science, Science Museum and Institute of Education, University of London, 2003).

The majority of individuals do not believe that they are responsible for or can engage in any actions that will be environmentally efficacious (Uzzell, 2000). Consequently, removing pupils from their common learning environment to expose them to ways in which climate change and environmental issues are directly affecting them and their own communities may be a way of raising environmental awareness. Scott (2002) agrees, suggesting that institutions such as schools need to be free to take up and explore with learners what sustainable development might be in ways that make contingent and contextual sense.

Scott goes on to describe four kinds of responsibilities that educators have to learners regarding education for sustainable development:

The Department for Children, Schools and Families (DCSF) agree, stating that in addition to our own actions to improve our sustainability, we need to empower young people with the skills, knowledge and freedom to voice their opinions and to make a difference (DCSF, 2008). Therefore, educating and empowering them to make their own decisions and communicate these to appropriate decision makers and designers within the context of low-energy schools is a promising way to achieve this. It is important to stimulate without prescribing and to encourage pupils to see conceptual frameworks as scaffolding to build learning around, rather than as barriers to new ideas, (Scott, 2002).

4. Method

The literature presented has provided evidence that engaging pupils in the development of their new school buildings is a promising method of ensuring good school design and subsequently better standards of learning and teaching for the future. This literature has therefore informed the current study and resulted in the following aims:

As the area of sustainable development and low-energy building design is very complex, various methods were selected to communicate and engage with the pupils. Johnson et al. (1981) suggested that when individuals encourage and teach one another and use cooperative structures, they have a tendency to promote greater performance than in more competitive or individualistic situations. Subsequently, collaborative learning was implemented in the form of workshops and discussions, as opposed to individual assignments and examinations. The UK Department for Education and Skills (DfES) advised that sustainable development offers a real-life context that can make learning more meaningful and relevant. It can enhance pupils’ enjoyment and progress, and build practical life skills (DfES, 2006). For this reason engagement events used real-life contexts as much as possible, including the facilitation of visits to existing low-energy buildings to enable pupils to visualize energy efficiency more effectively.

In total 102 pupils from four secondary schools took part in the engagement events and were aged between 10 and 14 years old. Pupils were selected as they were already part of the school’s Eco-management and Audit Scheme (EMAS) or else they were members of the school council. The engagement events were developed and facilitated by researchers from De Montfort University, Leicester in collaboration with an educational consultant and teachers from the schools. This ensured that the study fitted in with current educational practice and the National Curriculum.

5. Findings

The project was successful in directly engaging 102 pupils in the science and engineering of low-energy school buildings. This was done through the use of multiple engagement techniques and activities. The reasons for engaging pupils in this way was to facilitate an increase in knowledge and understanding of low-energy building design so that pupils were able to participate in informed discussions with experts to influence the design of their schools. This section details how these aims were achieved.

5.1 Facilitating an increase in awareness, knowledge and understanding of climate change and low-energy building design

From the data it was possible to identify an increase in the knowledge, awareness and understanding of the science and engineering associated with the development of low-energy school buildings.

There was a significant increase in pupil awareness surrounding phrases associated with sustainable development and additionally places in which they had heard the phases. The most common phrases that pupils had heard of, following the engagement activities, were “Renewable Energy,” which increased from 86% to 100%, and “Climate Change,” which increased from 81% to 100%. There was also a substantial increase in pupils who had heard of the terms “Energy Efficiency,” “Sustainable Development,” “Global Warming” and “The Green House Effect.”

An increase in the number of sources from which the pupils had heard the terms also reflected a raised awareness surrounding the topic. At the end of the project, the pupils were hearing more about sustainability issues from wider sources of information. As expected, pupils showed a significant increase in hearing about the issues in school, which significantly rose from 81% to 94%. However, it was reported that newspapers, radio and friends were also increasingly discussing issues of sustainable development. This could also be because, as the pupils became more aware of the terms and meanings, they took notice when such issues were being talked about. The pupils found that they heard more about sustainability and energy efficiency issues from their friends than other social groups. This is encouraging, as within the study it was also identified that “friends” tend to be the social group that have the most influence over behaviour. Surprisingly, results suggested that the number of pupils who were discussing these issues at home decreased from 67% prior to the engagement events to 59% after the events. This could possibly be because of the focus of the events being around the school buildings. Future work needs to ensure that pupils are encouraged to discuss the knowledge they have gained at home and additionally the content of the events should include measures that pupils can take at home to reduce energy consumption as well as in school.

Findings from the study also suggest that, following the engagement events, pupils demonstrated a higher level of concern for the environment. Pupils were asked the question “How concerned are you about these specific issues?” and were given the options “very concerned,” “fairly concerned,” “not very concerned,” “not at all concerned” and “I don’t know.” Figure 1 represents the percentages of pupils that answered positively (very and fairly concerned) both before and after the engagement events. As shown, pupils’ level of concerns increased after the engagement activities in all areas. Two of the lowest percentages of concern were observed in “traffic congestion” and “traffic exhaust fumes.” This was possibly because the engagement events tended to focus on the development of new school buildings and so emissions from vehicles may not have been emphasized as much as “the use of natural resources” for example. When addressing the carbon footprint of a “sustainable” school’ it is often debated as to whether emissions from vehicles coming to and from the school should be included. However, the National Framework for Sustainable Schools (2009) suggests that “travel and traffic” should be part of a whole management approach to a more sustainable school. By 2020 the government would like all schools to be models of sustainable travel, where vehicles are used only when absolutely necessary and facilities for healthier, less polluting or less dangerous modes of transport are exemplary (National Framework for Sustainable Schools, 2009). Subsequently it is essential that traffic and travel is included in education for sustainable development.

OPEN IN VIEWER

Figure 1.

Percentage of pupils who responded positively to the question: How concerned are you about these specific issues?

The study also found that pupils became more aware of the impact that they themselves could have on the effects of climate change: 88% of the pupils thought that they could make a contribution to reducing the effects of climate change following the activities compared with 73% prior to the activities.

Figure 2 shows the responses to the question: “Which of the following have a responsibility for conserving energy?” The baseline survey reported that 80% of pupils thought that they themselves were responsible for conserving energy, which was an encouraging initial response. This then increased to 88% following the engagement events. There was also an increase in pupils who thought that local communities were responsible for energy conservation (from 60% to 81%). This is again encouraging, as frequently it is easier to assign responsibility to higher bodies rather than accepting responsibility at a local level.

OPEN IN VIEWER

Figure 2.

Percentage of pupils who answered “yes” to the question: Which of the following have a responsibility for conserving energy?

As shown in Figure 3, when asked “Which of the following have a responsibility for using renewable energy?” the percentage of pupils who deemed themselves as responsible was significantly smaller than for conserving energy. This may be because the young people perceived themselves as having little control over whether the buildings they used (e.g. school and home) were installed with renewable energy, where as energy conservation can be undertaken by anyone in any building.

OPEN IN VIEWER

Figure 3.

Percentage of pupils who answered “yes” to the question: Which of the following have a responsibility for using renewable energy?

When asked “What are the major contributors to climate change?” the pupils produced various responses to the options provided. The baseline survey revealed that the three most prominent contributors were thought to be “the destruction of forests” (80%), “the use of gas and electricity in industry” (73%), and “carbon dioxide emissions” (67%). These were joined by several other factors in the follow-up survey, which indicated that the pupils also recognized these factors as prominent contributors. The hole in the ozone layer became the third most popular contributor after the engagement events. The pupils found it difficult to distinguish between the causes of the hole in the ozone layer and the causes of climate change. This is understandable, as both are caused by the emission of gases into the atmosphere. However, education for sustainable development must clarify that the hole in the ozone layer doesn’t actually contribute to climate change (see Table 1).

OPEN IN VIEWER

Table 1.

Pupil responses to the question: Which of the following are major contributors to climate change?

	Pre yes	Post yes	Pre no	Post no	Pre don’t know	Post don’t know
Carbon dioxide emissions	67	71	20	0	13	29
Hole in the ozone layer	60	79	20	0	20	21
Emissions from power stations	47	64	20	7	33	26
Use of gas/electricity in homes	53	64	40	22	7	14
Use of gas/electricity in industry	73	86	7	0	20	14
Use of mobile phones	13	14	74	57	13	29
Cars not using unleaded petrol	54	43	33	14	13	43
Destruction of forests	80	86	0	0	20	14
Organic farming	20	21	53	43	27	36

When asked how confident they were that the earth’s climate and long-term weather patterns are changing, 88% of the pupils answered that they were very or fairly confident. This is a considerable increase from pre-activity answers in which 73% of pupils were confident.

Not only was there an increase in awareness of sustainability issues and the outcomes of climate change, but pupils also addressed their own responsibilities towards these issues. Post-engagement, 81% of pupils thought that human activity was the major cause of climate change, compared to only 67% pre-engagement. Only a small percentage (9%) did not think that human activity was the major cause of climate change, however post-engagement, this percentage fell to 0%. After the project 19% of pupils did not know if human activity was the major cause of climate change, which dropped from 24% prior to the engagement activities.

Pupils demonstrated an increase in their understanding of the possible implications of climate change, as represented in Figure 4. When asked “What things, if any, do you think will happen as a result of climate change?” the most popular answers were “the average temperature will increase” (93%), “changes in weather patterns” (87%) and “sea level rise and coastal flooding” (86%). Following the engagement events there was a significant increase in the percentage of all the responses with the exception of “problems with long term survival of humans in the world,” which decreased from 66% to 52%. Given that the engagement events were intended to provide pupils with examples of how climate change can be reduced through the use of sustainable development, this particular result does not appear to be concerning.

OPEN IN VIEWER

Figure 4.

Percentage of pupils who answered “yes” to the question: What things, if any, do you think will happen as a result of climate change?

Data from the surveys, completed by the pupils both prior to and following the engagement events, showed an increase in pupils awareness, knowledge and understanding surrounding climate change. Additionally, the data also provided evidence that the pupils became more aware of their own behaviours and attitudes, and were able to identify ways in which they could help reduce the effects of climate change, thus being more responsible for their actions. In addition to this, qualitative data was collected during the engagement activities. This was captured through the work that the pupils had done; posters, presentations and “wish lists” for their new schools, and also through discussions with pupils concerning what they had learnt from the project The following extracts were taken from the pupils responses:

You’ve got to look out for the environment. (Clare, 10),

I know more about the environment now than before. (Ryan, 11),

Before I just used to think that pollution is mostly car pollution and that, but in BSF you look deeper into it and find out new things. (Kieran, 13)

It has made me think how we can do something to change the way we live. (Rhian, 14)

I have become more aware through the BSF project about environmental issues. (Misha, 11)

Understand more about sustainability and orientations and energy. (Tom, 14)

I think the BSF has made me think more about environmental issues and all the stages. (Katie, 12)

There was also evidence that teachers had made a positive shift in their attitudes and knowledge, as shown in the following comment from one of the teachers who took part in the project:

It has been good to know that others share the same opinions and feelings. I already had some knowledge on the subject, but I have learnt a lot more

Architects, designers, policy makers and councillors who took part in the discussions with pupils were very impressed with the high level of knowledge demonstrated. The pupils were able to answer their questions, as the next section confirms.

6. Conclusions

A study of literature suggested that pupils should be engaged in the development of their new school buildings to enable improved school design, better standards of teaching and learning, and improved education in science and sustainable development. Following the development of a programme of engagement, the research was successful in providing multiple engagement events for 102 pupils, aged between 10 and 14, from four secondary schools in Leicester city, UK. This research was successful in increasing pupils’ awareness, knowledge and understanding of the science and engineering of low-energy schools. All the pupils taking part in the study agreed that the activities had increased their awareness of issues related to climate change and sustainable development. Additionally pupils stated that since the activities began they had contributed more frequently to conversations surrounding sustainability issues with parents, teachers and school governors in particular.

The research enabled pupils to engage in detailed discussions with the designers and architects of their new schools. The pupils presented their ideas for increased levels of thermal insulation and natural daylight, the acknowledgement of site orientation to maximize solar gain and their wish for natural ventilation. These features can now be seen in the new school buildings and additionally the pupils now have the confidence to present their ideas to professionals and are assured that those ideas will be acknowledged. For several pupils the research also reinforced the appeal of science and engineering. Following the engagement events, 58% of the pupils either “agreed” or “strongly agreed” that they found science and engineering interesting.

The Sustainable Development Commission suggests that because young people have the greatest stake in the future, it is our responsibility to empower them to look after the planet in adulthood and, crucially, to question and challenge the practices of present-day decision makers (SDC, 2009). Young people were provided with the awareness and capacity to discuss the merits of providing energy efficient technologies and design in the building of new schools. The use of a range of activities, including site visits and workshops, allowed the young people to gain valuable knowledge and understanding that were shown to have improved their capacity to engage with decision makers, designers and engineers.

The success of the study in raising awareness of sustainable development can largely be attributed to the use of non-formal learning. Taking students out of their familiar learning environment and into an inspirational and exciting low-energy building allowed them to have fun whilst also learning some valuable lessons about sustainable development. Learning outside the classroom, developments in the “informal education sector” and the outreach activities of universities and industry are a major way of widening and improving the understanding of science (Bell, 2008).

Engaging pupils in the design of their new school buildings is an excellent opportunity to introduce ESD at an early age. Not only are they learning about sustainable design and behaviour first hand but they are engaging in a process that will create a low-energy building from which they, and future pupils, can continue to learn from for generations to come. Subsequently, the BSF process is successfully coupling two time spans of long-term visions for the future and short-term actions. Low-energy buildings are good examples of tools through which to teach people of all ages about sustainable development and inspiring and innovative design options.

7. Lessons learnt and future work

The new coalition government has recently announced cuts in the BSF programme, but the scheme in Leicester is still going ahead. This work is now continuing with the 12 remaining Leicester city secondary schools, which are to be remodelled and rebuilt. The successful engagement activities presented in this article are being improved to continue to raise pupils’ awareness and understanding of climate change and sustainable development.

It is suggested that to teach effectively educators need to be comfortable with what they are teaching and have a sound understanding of the subject matter (Bell, 2008). Literature, as well as research undertaken within this study, suggests that knowledge surrounding sustainable development is inconsistent and the level of teacher knowledge surrounding the subject matter is unclear. Subsequently, future research needs to concern techniques to provide teachers, across curriculum subjects, with adequate knowledge and understanding of how ESD can effectively be incorporated into day-to-day lessons. This will be a first step to ensuring that ESD is considered to be part of the National Curriculum in all subjects, as opposed to being a one-off event or add on. Consequently, teacher training in ESD is being considered as a significant part of the follow-on project.

Although it would not be impossible to engage with all pupils across the 12 Phase 2 schools, it is important that as many pupils as possible are involved in the building and refurbishment projects and have the opportunity to increase their knowledge and understanding as a consequence. The next project will therefore aim to disseminate information and knowledge as widely as possible within each of the schools. This will be done through school assemblies, radio and newsletters and by working closely with teachers to incorporate engagement activities into everyday lessons.

Since everyone involved in sustainable building design is on a steep learning curve, it is crucial that knowledge is captured from post-occupancy evaluations for new waves of BSF (Wilkinson, 2008). Building Management Systems (BMS), do not always perform effectively. Some reports suggest that unnecessarily complicated “green features” can hamper teachers from getting on with teaching and in some cases are causing schools to use much more energy than ones built 10, 20 and even 100 years ago (O’Reilly, 2009). Future research is required to conduct post-occupancy evaluations of new BSF schools, including operational efficiency, effective commissioning and occupancy behavior. This is essential to provide subsequent phases of BSF with insight into the realistic operation of low-energy school buildings. Current research, in this area, within the Institute of Energy and Sustainable Development (IESD) focuses specifically on the development of methods and techniques for the post occupancy evaluation of school buildings.

Since the completion of the Phase 1 BSF schools, Leicester city Council (LCC) has focused significantly on the challenge of designing and constructing low-energy schools. A scrutiny committee was set up to specifically review and scrutinize the four completed schools. The subsequent report concluded that higher environmental standards were required within subsequent BSF phases in Leicester city. Additionally, the report suggested that all schools in Leicester city are to be “carbon neutral” by 2013; three years earlier than national targets. IESD is working closely with LCC to ensure that the next phase of schools achieves significantly higher levels of energy efficiency.
