Successful treatment of malakoplakia of the bladder in a kitten

Case Report

A 16-week-old female domestic shorthair kitten, weighing 2.28 kg was referred to Southpaws Specialty Surgery for Animals for evaluation of recurrent cystitis and a suspected bladder mass. The kitten had had clinical signs of hematuria and stranguria since being acquired at 5 weeks of age and was presented to the referring veterinarian for suspected constipation and pollakiuria. Physical examination identified a suspected bladder mass and in-house urinalysis showed pyuria and hematuria. The kitten was prescribed amoxicillin/clavulanic acid at 16 mg/kg q12h (Noroclav; Norbrook) and meloxicam (Metacam; Boehringer Ingelheim) for 10 days without improvement. A urine culture via cystocentesis revealed >100,000 colony forming units (cfu) of Escherichia coli susceptible to cephalexin, amoxicillin/clavulanic acid, trimethoprim-sulfa and enrofloxacin. Serum biochemistry results showed minor changes or were normal for the cat’s age. A complete blood count was, essentially, normal. Apart from these clinical signs, she had remained healthy.

Four weeks later the kitten presented to Southpaws Specialty Surgery for persistent cystitis despite appropriate antibiotics. Upon clinical examination, the kitten was bright and alert. She was small for her age, but appropriately proportioned. Vital signs were within normal ranges. Her bladder was firm and semi-distended upon palpation. No other abnormalities were present. Abdominal ultrasound revealed pronounced, diffuse thickening of the bladder wall (up to 0.52 cm), most prominent within the trigone region (Figure 1). No discrete bladder masses or other abnormalities were identified on abdominal ultrasound. Urinalysis via cystocentesis revealed a urine specific gravity of 1.046 and a pH of 6, with 2+ protein and an active sediment of >1000 ×10⁶/l red blood cells and >1000 ×10⁶/l white blood cells, but no ketones, glucose, bilirubin or bacteria were seen microscopically. A urine culture was not performed at this time, and the amoxicillin/clavulanic acid was continued. Feline leukemia and feline immunodeficiency virus enzyme-linked immunosorbent assay were negative. As the kitten was too small for cystoscopy to acquire mucosal biopsies and examine the lower urinary tract, an exploratory celiotomy and ovariohysterectomy was performed. The goal of surgery was to acquire full thickness biopsies to further characterize the bladder wall thickening, with the intention to direct therapy to the underlying cause and allow more accurate prognostication. At surgery, the bladder mucosa was grossly thickened with soft plaque-like proliferations covering the entire mucosal surface. Full-thickness bladder wall samples were acquired for histopathology and aerobic bacterial culture with sensitivity. The ureteral insertions into the trigone region were normal, as was the remainder of the abdomen. The kitten was discharged the following day on amoxicillin/clavulanic acid and buprenorphine (Temgesic; Rickitt-Benkiser) sublingually for analgesia.

OPEN IN VIEWER

Figure 1

Ultrasound image of the bladder at the kitten’s initial visit to Southpaws Specialty Surgery for Animals. The bladder wall was diffusely thickened and irregular, measuring up to 0.52 cm in sections and most prominently in the trigone region (not shown). The bladder contained a moderate amount of urine (8 MHz, curvilinear probe)

Culture of the bladder wall grew E coli with the same sensitivity panel as the previous isolate so amoxicillin/clavulanic acid was continued pending the histopathology results. Histopathologic evaluation of full thickness bladder biopsies stained with hematoxylin and eosin was performed. The bladder mucosa was covered by a hyperplastic transitional epithelium. The submucosa was markedly infiltrated and expanded or effaced by a diffuse sheet of large histiocytic cells consistent with von Hansemann cells (Figure 2), which had round, relatively uniform, central nuclei with small or insignificant nucleoli, a low mitotic rate and abundant cytoplasm containing numerous fine periodic acid-Schiff (PAS)-positive granules (Figure 3). Irregularly distributed between, or occasionally within the cytoplasm of, these cells there were numerous basophilic, mineralized, targetoid concretions (calcospherites) 5–10 µm in diameter, with morphology typical of Michaelis–Gutman bodies (Figure 4). These were strongly positive for calcium with Von Kossa stain (Figure 5). No microorganisms, particularly bacteria, or any significant inflammatory cells were identified in the bladder mucosa. These findings were diagnostic for urinary bladder malakoplakia. Fluorescent in situ hybridization (FISH) was performed on paraffin sections and some superficial bacteria were visualized. No invasive bacteria were seen despite a large number of autofluorescent inflammatory cells (Figure 6).

OPEN IN VIEWER

Figure 2

A low-power photomicrograph of the submucosa markedly infiltrated and expanded by diffuse sheet of large histiocytic cells, consistent with von Hansemann cells (hematoxylin and eosin stain)

OPEN IN VIEWER

Figure 3

A high-power photomicrograph of the submucosa revealing the von Hansemann cells containing abundant cytoplasm containing numerous fine periodic acid-Schiff (PAS)-positive granules. The von Hansemann cells have a low mitotic rate, are relatively uniform and have central nuclei with small or insignificant nucleoli (PAS stain)

OPEN IN VIEWER

Figure 4

A high power hematoxylin and eosin-stained photomicrograph of Michaelis–Gutman bodies, which are basophilic, mineralized, targetoid concretions (5–10 µm in diameter) situated between the von Hansemann cells or within the cytoplasm

OPEN IN VIEWER

Figure 5

The Michaelis–Gutman bodies stain strongly for calcium with Von Kossa stain (high power, Von Kossa stain)

OPEN IN VIEWER

Figure 6

Fluorescent in situ hybridization of the bladder wall. The results reveal many inflammatory cells, but no invasive bacteria are seen

Hematuria, stranguria and pollakiuria persisted postoperatively and urine culture obtained via cystocentesis 12 days postoperatively revealed persistent growth of E coli (220,000 cfu), with the same sensitivities as before. Based upon the histological diagnosis of malakoplakia, the kitten was started on sulfamethoxazole and trimethoprim (TMS) (Bactrim; Roche) in addition to amoxicillin/clavulanic acid. Over the next 12 weeks, the kitten’s clinical signs gradually reduced and improvement was seen with the bladder wall thickening, although the trigone region remained thickened. Urine culture remained positive for growth of E coli with the same sensitivities. By 22 weeks post surgery, the kitten’s clinical signs had completely resolved and there were 2 consecutive negative urine cultures, 1 month apart. Urinalysis revealed resolution of pyuria and hematuria, and the bladder was smooth with normal thickness ultrasonographically; antibiotics were discontinued after the second negative culture. Repeat urine cultures were performed at 2, 5 and 8 months post discontinuation of the antibiotics and the results revealed no bacterial growth. The patient remains asymptomatic 12 months after discontinuation of the medications.

Malakoplakia is an unusual chronic granulomatous inflammatory response most commonly affecting the genitourinary system, particularly the bladder. This condition has been well recognized in human patients since it was first identified in 1901 by von Hansemann and later described by Michaelis and Gutmann in 1902.^1,2 The term malakoplakia was coined by von Hansemann in 1903 and derived from the Greek words meaning malakos (soft) and plakos (plaque) to describe the soft, yellow–brown mucosal plaques associated with the disease.^1,2 There have been numerous cases (>400) in the human literature involving not only the bladder and kidneys, but the colon, prostate, lungs, tongue, skin and lymph nodes, with clinical signs varying according to the organ affected.^2–6 Age of onset varies from juveniles to the middle-aged, with bladder lesions appearing to be more common in females.^2,4,6 Malakoplakia is confirmed by the presence of pathognonomic microscopic mineralized target or ‘owl-eye’ cytoplasmic basophilic inclusions (calcospherites), known as Michaelis–Gutmann bodies (MG bodies) within large von Hansemann macrophages, which have abundant finely granular eosinophilic PAS-positive cytoplasm.^1,7 The composition of MG bodies appears to be calcium, mucopolysaccharide and lipid, which probably represents calcification of undigested bacteria due to ineffective phagocytosis.^1,6–9

The veterinary literature contains only pathological descriptions of the disease: three describing naturally-occurring disease, of which two involve incidental post mortem findings in pigs describing malakoplakia of the lymph nodes, and one with systemic involvement.^10,11 Most recently, Bayley et al ¹² described a kitten with a similar presentation to the one described herein. The kitten presented initially for stranguria and tenesmus which failed to respond to antibiotic therapy; the kitten was euthanased 3 weeks later. Malakoplakia of the bladder was identified at post-mortem examination. The present report provides valuable information on the management of patients with such a condition as malakoplakia.

The exact pathogenesis of malakoplakia remains obscure, but most agree that bacteria play a significant role in the development of the disease, but whether they act as primary or secondary agents is still debatable. ¹³ The majority of cases involving the urinary tract occur with coliform cystitis with or without concurrent immune suppression, and successful treatment of the infection generally results in resolution of the malakoplakia.^4,5 A number of studies have identified E coli or E coli antigen within the MG bodies, from urine if the urinary system is involved, or from purulent material.^1,4,14–16 Similar to the present case report, other studies have not been able to identify bacteria by light microscopy, electron microscopy or polymerase chain reaction techniques, but prior antibiotic therapy may have influenced these results.^9–12 FISH performed on the bladder wall in the present study and failed to reveal any bacteria within macrophages. This may have been a result of sparse distribution of these intracellular organisms. Others postulate that malakoplakia is due to an inherent abnormal monocyte response or abnormal immunological state affecting intracellular killing of bacteria.^1,7,9,17 One study demonstrated that von Hansemann macrophages contained less cyclic guanosine monophosphate, which is necessary for the normal function of microtubules and phagolysosomes. ¹⁷ Another hypothesis is that the bacteria may contribute to the ineffective macrophage function. ¹

Malakoplakia bears some resemblance to granulomatous colitis in Boxers and leptomeninigitis in Beagles, which are also associated with E coli and PAS-positive macrophages. Escherichia coli antigen has been identified within the characteristic macrophages in these diseases, but no MG bodies have been found.^8,18 Successful treatment of Boxer colitis can be achieved in most cases with fluoroquinolone antibiotics, further supporting the causal involvement of E coli in the pathogenesis of the disease. ¹⁹ It is unknown whether the individual bacterium promotes the granulomatous reaction or the individual exhibits an abnormal response to the bacteria; the pathogenesis is likely a combination of these factors.

Prolonged antimicrobial therapy is the mainstay of treatment for malakoplakia. Antibiotics with the ability to penetrate macrophages, such as trimethoprim-sulfamethoxazole and fluoroquinolones, appear to have the most success, and treatment is less successful with beta-lactams, which do not penetrate the cells.^5,9,15,16,20 Our kitten was treated initially for 4–6 weeks without improvement, with the most appropriate antibiotics based upon culture and sensitivity testing. Clinical improvement only occurred once treatment with TMS had started. Instillation of neosporin into the bladder and cholinergic agents, such as bethanechol, that increase the cyclic-GMP levels within macrophages have been used in humans with variable success.^3,9,13,14,21 As the disease has been associated with immune suppression, discontinuation of immune suppressant drugs is generally recommended.^4,6 Survival depends upon the organs affected and the extent of the lesion as there can be multiple organ involvement and subsequent organ failure (ie, hydronephrosis due to renal obstruction).^3–5 Plaques within the bladder appear to be the most amenable to treatment, but other cases require a multimodal therapeutic approach, including systemic antibiotics and, potentially, surgery to remove large masses or re-routing of ureters.^3–5,9,14

Conclusions

Malakoplakia is unusual in humans and greater awareness of it is needed in veterinary medicine, especially as its presentation may be similar to neoplasia. Treatment can be successful with prolonged antibiotics that penetrate macrophages.
