Inverse rigid-body dynamic analysis for a 3U P S- P RU parallel robot

Abstract

Inverse rigid-body dynamic analysis for a 3UPS-PRU parallel robot are conducted in this research. The position, velocity, acceleration, jerk, and singularity are considered in the inverse kinematics analysis. The rigid-body dynamic model is developed by means of the principle of virtual work and the concept of link Jacobian matrices. The driving torque, driving power, and required output work of motors have been computed in the inverse rigid-body dynamics analysis. For the pre-defined trajectory, the required output work generated by the driving motor is achieved by numerical integration technique. The inverse kinematics and rigid-body dynamics have been investigated in an exhaustive decoupled way. The effects of the velocity of the moving platform on the components of the joint acceleration, joint jerk, driving torque, and driving power, which are related to the velocity of the moving platform, are investigated. There are linear relationships between the acceleration of the moving platform and the components of the joint acceleration, joint jerk, driving torque, and driving power, which are related to the acceleration of the moving platform. The total driving torques, the torques related to the acceleration, velocity, and gravity, the torques related to the moving platform, strut connected with the moving platform, strut connected with the base platform, and motor rotor-coupler are calculated. The total driving powers, the powers related to the acceleration component of torque, velocity component of torque, gravity component of torque, and the powers related to the moving platform, strut connected with the moving platform, strut connected with the base platform, and motor rotor-coupler are also achieved.

Keywords

Parallel robot inverse rigid-body dynamics jerk torque power energy consumption

Introduction

Parallel robots have been widely used in motion simulators,^1–3 high-speed operations,^4–6 machine tools,^7–9 and so on. In order to have excellent structural characters, the rigid-body dynamics should be considered in the design stage when the parallel robots are used with high load applications, high-speed operations, and/or high acceleration situations.¹⁰ In the running process, the rigid-body dynamics should also be considered in order to pursue a good operating performance.¹¹ The rigid-body dynamics play an important role in the design stage and running process.

Many research works have been investigated on the rigid-body dynamics of the parallel robots.^{4,6,8–10,12
–27} Several mechanics approaches such as the virtual work principle,^{4,6,10,12–16,20,22–27} the Newton–Euler method,¹⁷ the Lagrangian method,^9,18 and the Kane’s method¹⁹ have been selected to develop the rigid-body dynamic model of the parallel robots. The virtual work principle is the most widely used mechanics approach for the rigid-body dynamic formulation of the parallel robots. Tsai¹² presents a systematic methodology for the inverse rigid-body dynamics of the Stewart–Gough manipulator based on the virtual work principle and the concept of link Jacobian matrices. Huang et al.¹³ set up rigid-body dynamic model for a 2-degree-of-freedom (2-DOF) high-speed translational parallel manipulator with the virtual work principle and adopted the model for estimating servomotor parameters of a parallel robot for rapid pick-and-place operations using the singular value decomposition. Zhao et al.^14,15 developed rigid-body dynamic models for the parallel robots considering jerk, power, and energy consumption. In addition, some of the models are also applied to the performance evaluation and the dynamic optimum design. Codourey¹⁶ formulated the rigid-body dynamic model of the Delta robot and used for the computed-torque control. Theoretically, it can be concluded that there is no trouble in the formulation of the rigid-body dynamics for the parallel robots with the virtual work principle or even with other mechanics approaches. Much more attention has also been paid on the model accuracy, computation efficiency, and practical application. However, the existing work on the inverse kinematics and rigid-body dynamics of the parallel robots seldom considers the decoupling of the rigid-body dynamic model and the effects of the velocity and acceleration of the moving platform on the acceleration, jerk, driving torque, and driving power of the actuating joints.

The goal of the research presented in this article is to develop the analytic models for inverse kinematics and rigid-body dynamics of a 3UPS-PRU parallel robot considering the position, velocity, singularity, acceleration, jerk, driving torque, driving power, and energy consumption. Through the analytic models, the decoupling of the rigid-body dynamic model and the effects of the velocity and acceleration of the moving platform on the acceleration, jerk, driving torque, and driving power of the actuating joints are investigated. The article is organized as follows. The 3UPS-PRU parallel robot is explained in section “3UPS-PRU parallel robot.” The inverse kinematics and rigid-body dynamics are provided in sections “Inverse kinematics” and “Inverse rigid-body dynamics,” respectively. Computation example and conclusion are given in sections “Example” and “Conclusion.”

3UPS-PRU parallel robot

The 3UPS-PRU parallel robot is shown in Figure 1. This parallel robot is composed of a moving platform connected with the base platform through three identical UPS limbs and one PRU limb. The central PRU limb is fixed on the base platform. Here, the U, P, S, and R represent, respectively, a universal, prismatic, spherical, and revolute joint and underlined P (i.e. P) denotes an active prismatic joint driven by a servomotor. Due to the proper constraints of the central limb and the three external limbs, the moving platform has one translational and three rotational DOFs. The 3UPS-PRU parallel robot can be adopted to develop a motion simulator, rehabilitation appliance or used for other applications required for one translational and three rotational DOFs. The studied 3UPS-PRU parallel mechanism is used to build a hyper-redundant robot.

Figure 1.

The 3 UPS-PRU parallel robot.

As shown in Figure 1, the following coordinate systems are defined for the modeling of the rigid-body dynamics: the reference coordinate system $B_{0} - xyz$ is located at the center of the base platform, and the moving coordinate system $A_{0} - uvw$ is attached to the center of mass of the moving platform. The orientation of the moving platform can be described by a rotation matrix ${{}^{B_{0}}R}_{A_{0}}$ . The rotation matrix can be defined by the parameters of roll, pitch, and yaw angle, namely, a rotation of $ϕ_{x}$ about the fixed x-axis, a rotation $ϕ_{y}$ about the fixed y-axis, and a rotation $ϕ_{z}$ about the fixed z-axis. Thus, the rotation matrix ${{}^{B_{0}}R}_{A_{0}}$ is

{{}^{B_{0}}R}_{A_{0}} = Rot (z, ϕ_{z}) Rot (y, ϕ_{y}) Rot (x, ϕ_{x})

(1)

The angular velocity and acceleration of the moving platform are given by¹²

ω = {[\begin{matrix} {\overset{\cdot}{ϕ}}_{x} & {\overset{\cdot}{ϕ}}_{y} & {\overset{\cdot}{ϕ}}_{z} \end{matrix}]}^{T}

(2)

\overset{\cdot}{ω} = {[\begin{matrix} {\overset{\cdot\cdot}{ϕ}}_{x} & {\overset{\cdot\cdot}{ϕ}}_{y} & {\overset{\cdot\cdot}{ϕ}}_{z} \end{matrix}]}^{T}

(3)

For the purpose of the rigid-body dynamic formulation, the local coordinate system of the ith limb is defined and shown in Figure 2. The orientation of the ith limb with respect to the base platform can be described by two angles. It can be thought of as a rotation of $ϕ_{i}$ about z-axis resulting in a $B_{i} - x'_{i} y'_{i} z'_{i}$ coordinate system followed by another rotation of $φ_{i}$ about the rotated $y'_{i} - axis$ . So the rotation matrix can be written as

{{}^{B_{0}}R}_{B_{i}} = Rot (z, ϕ_{i}) Rot (y'_{i}, φ_{i}) = [\begin{matrix} c ϕ_{i} c φ_{i} & - s ϕ_{i} & c ϕ_{i} s φ_{i} \\ s ϕ_{i} c φ_{i} & c ϕ_{i} & s ϕ_{i} s φ_{i} \\ - s φ_{i} & 0 & c φ_{i} \end{matrix}]

(4)

Figure 2.

The local coordinate system of the ith limb.

The unit vector along the limb in the coordinate system $B_{0} - xyz$ is as follows

w_{i} = {{}^{B_{0}}R}_{B_{i}} {{}^{B_{i}}w}_{i} = {{}^{B_{0}}R}_{B_{i}} [\begin{matrix} 0 \\ 0 \\ 1 \end{matrix}] = [\begin{matrix} c ϕ_{i} s φ_{i} \\ s ϕ_{i} s φ_{i} \\ c φ_{i} \end{matrix}]

(5)

So the angles $ϕ_{i}$ and $φ_{i}$ can be computed as follows

{\begin{matrix} c φ_{i} = w_{iz} \\ s φ_{i} = \sqrt{w_{ix}^{2} + w_{iy}^{2}}, (0 \leq φ_{i} < π) \\ s ϕ_{i} = w_{iy} / s φ_{i} \\ c ϕ_{i} = w_{ix} / s φ_{i} \\ if φ_{i} = 0, then ϕ_{i} = 0 \end{matrix}

(6)

Inverse kinematics

Position analysis

As shown in Figure 3, the position equation associated with the ith limb can be written as

q_{0} w_{0} + a_{i} = b_{i} + q_{i} w_{i} i = 1, 2, 3

(7)

where $q_{0}$ , $q_{i}$ , $w_{0}$ , $w_{i}$ , $a_{i}$ , and $b_{i}$ denote the joint variable of the central limb, the joint variable of the ith limb, the unit vector along the central limb, the unit vector along the ith limb, the vector $A_{0} A_{i}$ , and the vector $B_{0} B_{i}$ , respectively. $q_{0} w_{0}$ also represents the position vector of the moving platform.

Figure 3.

Vector diagram of the ith limb.

Taking norms on both sides of equation (7) leads to

q_{i} = \sqrt{{(q_{0} w_{0} + a_{i} - b_{i})}^{T} (q_{0} w_{0} + a_{i} - b_{i})}

(8)

Velocity analysis

Taking the derivative of equation (7) with respect to time, we get

{\overset{\cdot}{q}}_{0} w_{0} + ω \times a_{i} = {\overset{\cdot}{q}}_{i} w_{i} + ω_{i} \times q_{i} w_{i}

(9)

where $ω_{i}$ is the angular velocity vector of the ith limb and $ω$ is the angular velocity vector of the moving platform.

Taking the dot product of both sides of equation (9) with $w_{i}$ , we obtain

{\overset{\cdot}{q}}_{i} = {\overset{\cdot}{q}}_{0} w_{i}^{T} w_{0} + (a_{i} \times w_{i})^{T} ω

(10)

By rewriting equation (10) in the matrix form, we obtain

\overset{\cdot}{q} = J \overset{\cdot}{x}

(11)

where

\overset{\cdot}{q} = {[\begin{matrix} {\overset{\cdot}{q}}_{0} & {\overset{\cdot}{q}}_{1} & {\overset{\cdot}{q}}_{2} & {\overset{\cdot}{q}}_{3} \end{matrix}]}^{T}

(12)

\overset{\cdot}{x} = [\begin{matrix} v \\ ω \end{matrix}]

(13)

v = {\overset{\cdot}{q}}_{0}

(14)

J = [\begin{matrix} 1 & 0_{1 \times 3} \\ w_{1}^{T} w_{0} & {(a_{1} \times w_{1})}^{T} \\ w_{2}^{T} w_{0} & {(a_{2} \times w_{2})}^{T} \\ w_{3}^{T} w_{0} & {(a_{3} \times w_{3})}^{T} \end{matrix}] = [\begin{matrix} J_{0} \\ J_{1} \\ J_{2} \\ J_{3} \end{matrix}]

(15)

where v is the linear velocity of the moving platform, $\overset{\cdot}{x}$ is the velocity vector of the moving platform, and $J$ is the Jacobian matrix which maps the velocity vector of the moving platform into the joint velocity vector. There is a linear relationship between the velocity vector of the moving platform and the joint velocity vector.

The determinant of Jacobian matrix can be obtained from equation (15)

\det (J) = \det ([\begin{matrix} {(a_{1} \times w_{1})}^{T} \\ {(a_{2} \times w_{2})}^{T} \\ {(a_{3} \times w_{3})}^{T} \end{matrix}]) = \det ([\begin{matrix} (a_{1} \times w_{1}) & (a_{2} \times w_{2}) & (a_{3} \times w_{3}) \end{matrix}])

(16)

Based on the theorem of vector operation, the determinant of Jacobian matrix can be achieved as

\begin{matrix} det (J) = (a_{1} w_{1} w_{2}) (a_{2} a_{3} w_{3}) - (a_{1} w_{1} a_{2}) (w_{2} a_{3} w_{3}) \\ = (a_{1} a_{2} w_{2}) (w_{1} a_{3} w_{3}) - (w_{1} a_{2} w_{2}) (a_{1} a_{3} w_{3}) \\ = (a_{1} w_{1} a_{3}) (a_{2} w_{2} w_{3}) - (a_{1} w_{1} w_{3}) (a_{2} w_{2} a_{3}) \end{matrix}

(17)

$where (\cdot)$ is the mixed product of vectors. The mixed product of vectors equals to zero when the three free vectors are in the same plane. So the determinant of Jacobian matrix equals to zero when any of the following conditions is satisfied.

(a_{1} w_{1} w_{2}) = (a_{1} w_{1} a_{2}) = 0

(18a)

(a_{1} w_{1} w_{2}) = (w_{2} a_{3} w_{3}) = 0

(18b)

(a_{2} a_{3} w_{3}) = (a_{1} w_{1} a_{2}) = 0

(18c)

(a_{2} a_{3} w_{3}) = (w_{2} a_{3} w_{3}) = 0

(18d)

(a_{1} w_{1} w_{2}) = (a_{2} a_{3} w_{3}) = (a_{1} w_{1} a_{2}) = (w_{2} a_{3} w_{3}) = 0

(18e)

(a_{1} w_{1} w_{2}) (a_{2} a_{3} w_{3}) = (a_{1} w_{1} a_{2}) (w_{2} a_{3} w_{3}) \neq 0

(18f)

(a_{1} a_{2} w_{2}) = (w_{1} a_{2} w_{2}) = 0

(19a)

(a_{1} a_{2} w_{2}) = (a_{1} a_{3} w_{3}) = 0

(19b)

(w_{1} a_{3} w_{3}) = (w_{1} a_{2} w_{2}) = 0

(19c)

(w_{1} a_{3} w_{3}) = (a_{1} a_{3} w_{3}) = 0

(19d)

(a_{1} a_{2} w_{2}) = (w_{1} a_{3} w_{3}) = (w_{1} a_{2} w_{2}) = (a_{1} a_{3} w_{3}) = 0

(19e)

(a_{1} a_{2} w_{2}) (w_{1} a_{3} w_{3}) = (w_{1} a_{2} w_{2}) (a_{1} a_{3} w_{3}) \neq 0

(19f)

(a_{1} w_{1} a_{3}) = (a_{1} w_{1} w_{3}) = 0

(20a)

(a_{1} w_{1} a_{3}) = (a_{2} w_{2} a_{3}) = 0

(20b)

(a_{2} w_{2} w_{3}) = (a_{1} w_{1} w_{3}) = 0

(20c)

(a_{2} w_{2} w_{3}) = (a_{2} w_{2} a_{3}) = 0

(20d)

(a_{1} w_{1} a_{3}) = (a_{2} w_{2} w_{3}) = (a_{1} w_{1} w_{3}) = (a_{2} w_{2} a_{3}) = 0

(20e)

(a_{1} w_{1} a_{3}) (a_{2} w_{2} w_{3}) = (a_{1} w_{1} w_{3}) (a_{2} w_{2} a_{3}) \neq 0

(20f)

It should be pointed out that the Jacobian matrix is a singular matrix in mathematics when the moving platform is parallel to the base platform and $ϕ_{z} = 0$ since the three vectors $a_{1} \times w_{1}$ , $a_{2} \times w_{2}$ , and $a_{3} \times w_{3}$ are in the same plane.

Link velocity analysis

Taking the derivative of left side of equation (7) with respect to time, we get the velocity of the point of the joint $A_{i}$

v_{Ai} = {\overset{\cdot}{q}}_{0} w_{0} + ω \times a_{i} = v + ω \times a_{i}

(21)

where $v$ is the linear velocity vector of the moving platform, and

v = {\overset{\cdot}{q}}_{0} w_{0} = v w_{0}

(22)

Equation (21) can be described in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$

{{}^{B_{i}}v}_{Ai} = {{}^{B_{i}}R}_{B_{0}} v_{Ai} = {}^{B_{i}}v + {}^{B_{i}}ω \times {{}^{B_{i}}a}_{i}

(23)

where ${{}^{B_{i}}R}_{B_{0}} = ({{}^{B_{0}}R}_{B_{i}})^{- 1} = ({{}^{B_{0}}R}_{B_{i}})^{T}$ .

Taking the derivative of right side of equation (7) with respect to time and describing the result in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ , we get the velocity of point of joint $A_{i}$

{{}^{B_{i}}v}_{Ai} = {\overset{\cdot}{q}}_{i} {{}^{B_{i}}w}_{i} + {{}^{B_{i}}ω}_{i} \times q_{i} {{}^{B_{i}}w}_{i}

(24)

where ${{}^{B_{i}}ω}_{i}$ is the angular velocity of the ith limb described in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ .

Taking the cross product of both sides of equation (24) with ${{}^{B_{i}}w}_{i}$ and substituting ${{}^{B_{i}}ω}_{i}^{T} {{}^{B_{i}}w}_{i} = 0$ into it, we obtain

q_{i} {{}^{B_{i}}ω}_{i} = {{}^{B_{i}}w}_{i} \times {{}^{B_{i}}v}_{Ai}

(25)

Substituting equation (23) into equation (25), we get

\begin{matrix} {{}^{B_{i}}ω}_{i} = \frac{1}{q_{i}} (S ({{}^{B_{i}}w}_{i}) {{}^{B_{i}}R}_{B_{0}} v - S ({{}^{B_{i}}w}_{i}) S ({{}^{B_{i}}a}_{i}) {{}^{B_{i}}R}_{B_{0}} ω) \\ = \frac{1}{q_{i}} [\begin{matrix} S ({{}^{B_{i}}w}_{i}) {{}^{B_{i}}R}_{B_{0}} & - S ({{}^{B_{i}}w}_{i}) S ({{}^{B_{i}}a}_{i}) {{}^{B_{i}}R}_{B_{0}} \end{matrix}] [\begin{matrix} v \\ ω \end{matrix}] \\ = \frac{1}{q_{i}} [\begin{matrix} S ({{}^{B_{i}}w}_{i}) {{}^{B_{i}}R}_{B_{0}} & - S ({{}^{B_{i}}w}_{i}) S ({{}^{B_{i}}a}_{i}) {{}^{B_{i}}R}_{B_{0}} \end{matrix}] \\ [\begin{matrix} 0_{2 \times 4} \\ E_{4 \times 4} \end{matrix}] [\begin{matrix} v \\ ω \end{matrix}] \\ = J_{i ω} [\begin{matrix} v \\ ω \end{matrix}] i = 1, 2, 3 \end{matrix}

(26)

where

S ({{}^{B_{i}}w}_{i}) = [\begin{matrix} 0 & - {{}^{B_{i}}w}_{iz} & {{}^{B_{i}}w}_{iy} \\ {{}^{B_{i}}w}_{iz} & 0 & - {{}^{B_{i}}w}_{ix} \\ - {{}^{B_{i}}w}_{ix} & {{}^{B_{i}}w}_{ix} & 0 \end{matrix}]

S ({{}^{B_{i}}a}_{i}) = [\begin{matrix} 0 & - {{}^{B_{i}}a}_{iz} & {{}^{B_{i}}a}_{iy} \\ {{}^{B_{i}}a}_{iz} & 0 & - {{}^{B_{i}}a}_{ix} \\ - {{}^{B_{i}}a}_{iy} & {{}^{B_{i}}a}_{ix} & 0 \end{matrix}]

represent the screw matrix and

J_{i ω} = \frac{1}{q_{i}} [\begin{matrix} S ({{}^{B_{i}}w}_{i}) {{}^{B_{i}}R}_{B_{0}} & - S ({{}^{B_{i}}w}_{i}) S ({{}^{B_{i}}a}_{i}) {{}^{B_{i}}R}_{B_{0}} \end{matrix}] [\begin{matrix} 0_{2 \times 4} \\ E_{4 \times 4} \end{matrix}]

(27)

denotes the link Jacobian matrix of the ith limb which maps the velocity vector of the moving platform in the task space into the angular velocity vector of the ith limb described in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ .

Since the central limb is fixed on the base platform, we can get

{{}^{B_{0}}ω}_{0} = J_{0 ω} [\begin{matrix} v \\ ω \end{matrix}] = 0_{3 \times 1}

(28)

J_{0 ω} = 0_{3 \times 4}

(29)

The linear velocity of the center of mass $c_{i 1}$ in the ith limb described in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ is

{{}^{B_{i}}v}_{c_{i 1}} = {{}^{B_{i}}ω}_{i} \times {{}^{B_{i}}e}_{i 1} = - {{}^{B_{i}}e}_{i 1} \times {{}^{B_{i}}ω}_{i}

(30)

where

{{}^{B_{i}}e}_{i 1} = e_{i 1} {{}^{B_{i}}w}_{i}

(31)

Substituting equation (26) into equation (30), we get

\begin{matrix} {{}^{B_{i}}v}_{c_{i 1}} = - S ({{}^{B_{i}}e}_{i 1}) {{}^{B_{i}}ω}_{i} \\ = - S ({{}^{B_{i}}e}_{i 1}) J_{i ω} [\begin{matrix} v \\ ω \end{matrix}] \\ = J_{v c_{i 1}} [\begin{matrix} v \\ ω \end{matrix}] i = 1, 2, 3 \end{matrix}

(32)

where

J_{v c_{i 1}} = - S ({{}^{B_{i}}e}_{i 1}) J_{i ω}

(33)

is the link Jacobian matrix which maps the velocity vector of the moving platform into the linear velocity vector of the center of mass $c_{i 1}$ .

For the central limb, we can get

{{}^{B_{0}}v}_{c_{01}} = J_{v c_{01}} [\begin{matrix} v \\ ω \end{matrix}] = 0_{3 \times 1}

(34)

J_{v c_{01}} = 0_{3 \times 4}

(35)

By rewriting equations (26), (28), (32), and (34) in the matrix form, we get

[\begin{matrix} {{}^{B_{i}}v}_{c_{i 1}} \\ {{}^{B_{i}}ω}_{i} \end{matrix}] = [\begin{matrix} J_{v c_{i 1}} \\ J_{i ω} \end{matrix}] [\begin{matrix} v \\ ω \end{matrix}] = J_{c_{i 1}} [\begin{matrix} v \\ ω \end{matrix}]

(36)

The linear velocity of the center of mass $c_{i 2}$ in the ith limb described in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ is

{{}^{B_{i}}v}_{c_{i 2}} = {}^{B_{i}}v + {}^{B_{i}}ω \times {{}^{B_{i}}a}_{i} - {{}^{B_{i}}ω}_{i} \times {{}^{B_{i}}e}_{i 2}

(37)

where

{{}^{B_{i}}e}_{i 2} = e_{i 2} {{}^{B_{i}}w}_{i}

(38)

Substituting equation (26) into equation (37), we get

\begin{matrix} {{}^{B_{i}}v}_{c_{i 2}} = {}^{B_{i}}v - {{}^{B_{i}}a}_{i} \times {}^{B_{i}}ω + {{}^{B_{i}}e}_{i 2} \times {{}^{B_{i}}ω}_{i} \\ = ([\begin{matrix} {{}^{B_{i}}R}_{B_{0}} & - S ({{}^{B_{i}}a}_{i}) {{}^{B_{i}}R}_{B_{0}} \end{matrix}] [\begin{matrix} 0_{2 \times 4} \\ E_{4 \times 4} \end{matrix}] + S ({{}^{B_{i}}e}_{i 2}) J_{i ω}) \\ [\begin{matrix} v \\ ω \end{matrix}] \\ = J_{v c_{i 2}} [\begin{matrix} v \\ ω \end{matrix}] i = 1, 2, 3 \end{matrix}

(39)

where

J_{v c_{i 2}} = ([\begin{matrix} {{}^{B_{i}}R}_{B_{0}} & - S ({{}^{B_{i}}a}_{i}) {{}^{B_{i}}R}_{B_{0}} \end{matrix}] [\begin{matrix} 0_{2 \times 4} \\ E_{4 \times 4} \end{matrix}] + S ({{}^{B_{i}}e}_{i 2}) J_{i ω})

(40)

is the link Jacobian matrix which maps the velocity vector of the moving platform into the linear velocity vector of the center of mass $c_{i 2}$ .

For the central limb, we can get

{{}^{B_{0}}v}_{c_{02}} = v = {\overset{\cdot}{q}}_{0} w_{0} = J_{v c_{0, 2}} [\begin{matrix} v \\ ω \end{matrix}]

(41)

J_{v c_{02}} = [\begin{matrix} w_{i 0} & 0_{3 \times 3} \end{matrix}]

(42)

Acceleration analysis

Taking the derivative of equation (9) with respect to time, we get

{\overset{\cdot\cdot}{q}}_{0} w_{0} + \dot{ω} \times a_{i} + ω \times (ω \times a_{i}) = {\overset{\cdot\cdot}{q}}_{i} w_{i} + 2 {\dot{q}}_{i} (ω_{i} \times w_{i}) + {\dot{ω}}_{i} \times q_{i} w_{i} + q_{i} ω_{i} \times (ω_{i} \times w_{i})

(43)

Taking the dot product of both sides of equation (43) with $w_{i}$ , we obtain

{\overset{\cdot\cdot}{q}}_{i} - q_{i} (ω_{i}^{T} ω_{i}) = {\overset{\cdot\cdot}{q}}_{0} w_{i}^{T} w_{0} + {(a_{i} \times w_{i})}^{T} \dot{ω} + (w_{i}^{T} ω) (ω^{T} a_{i}) - (w_{i}^{T} a_{i}) (ω^{T} ω)

(44)

By rewriting equation (44) in the matrix form, we get

\begin{matrix} [\begin{matrix} {\overset{\cdot\cdot}{q}}_{0} \\ {\overset{\cdot\cdot}{q}}_{1} \\ {\overset{\cdot\cdot}{q}}_{2} \\ {\overset{\cdot\cdot}{q}}_{3} \end{matrix}] = [\begin{matrix} 1 & 0_{1 \times 3} \\ w_{1}^{T} w_{0} & {(a_{1} \times w_{1})}^{T} \\ w_{2}^{T} w_{0} & {(a_{2} \times w_{2})}^{T} \\ w_{3}^{T} w_{0} & {(a_{3} \times w_{3})}^{T} \end{matrix}] [\begin{matrix} {\overset{\cdot\cdot}{q}}_{0} \\ \overset{\cdot}{ω} \end{matrix}] \\ + [\begin{matrix} 0 \\ q_{1} (ω_{1}^{T} ω_{1}) + (w_{1}^{T} ω) (ω^{T} a_{1}) - (w_{1}^{T} a_{1}) (ω^{T} ω) \\ q_{2} (ω_{2}^{T} ω_{2}) + (w_{2}^{T} ω) (ω^{T} a_{2}) - (w_{2}^{T} a_{2}) (ω^{T} ω) \\ q_{3} (ω_{3}^{T} ω_{3}) + (w_{3}^{T} ω) (ω^{T} a_{3}) - (w_{3}^{T} a_{3}) (ω^{T} ω) \end{matrix}] \\ = J [\begin{matrix} \overset{\cdot}{v} \\ \overset{\cdot}{ω} \end{matrix}] + [\begin{matrix} V_{0} & V_{1} & V_{2} & V_{3} \end{matrix}]^{T} \end{matrix}

(45)

where $\overset{\cdot}{v}$ is the acceleration of the moving platform along the central limb, and

V_{0} = 0

(46)

V_{i} = q_{i} (ω_{i}^{T} ω_{i}) + (w_{i}^{T} ω) (ω^{T} a_{i}) - (w_{i}^{T} a_{i}) (ω^{T} ω)

(47)

\overset{\cdot}{v} = {\overset{\cdot\cdot}{q}}_{0}

(48)

From equation (26) and from equations (45) to (48), the joint acceleration related to the velocity of the moving platform is proportional to the square of the magnitude of the velocity of the moving platform.

Link acceleration analysis

Taking the derivative of equation (24) with respect to time and describing the result in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ , we get the acceleration of the point of the joint $A_{i}$

\begin{matrix} {}^{B_{i}}{\overset{\cdot}{v}}_{Ai} = {\overset{\cdot\cdot}{q}}_{i} {{}^{B_{i}}w}_{i} + 2 {\overset{\cdot}{q}}_{i} {{}^{B_{i}}ω}_{i} \times {{}^{B_{i}}w}_{i} + q_{i} {}^{B_{i}}{\overset{\cdot}{ω}}_{i} \times {{}^{B_{i}}w}_{i} \\ + q_{i} {{}^{B_{i}}ω}_{i} \times ({{}^{B_{i}}ω}_{i} \times {{}^{B_{i}}w}_{i}) \\ = {}^{B_{i}}{\overset{\cdot}{v}} + {}^{B_{i}}{\overset{\cdot}{ω}} \times {{}^{B_{i}}a}_{i} + {}^{B_{i}}ω \times ({}^{B_{i}}ω \times {{}^{B_{i}}a}_{i}) \end{matrix}

(49)

Taking the cross product of both sides of equation (49) with ${{}^{B_{i}}w}_{i}$ and substituting ${{}^{B_{i}}ω}_{i}^{T} {{}^{B_{i}}w}_{i} = {}^{B_{i}}{\overset{\cdot}{ω}}_{i}^{T} {{}^{B_{i}}w}_{i} = 0$ into it, we obtain

\begin{matrix} {}^{B_{i}}{\overset{\cdot}{ω}}_{i} = J_{i ω} [\begin{matrix} \overset{\cdot}{v} \\ \overset{\cdot}{ω} \end{matrix}] + \frac{1}{q_{i}} (({{}^{B_{i}}ω}^{T} {{}^{B_{i}}a}_{i}) ({{}^{B_{i}}w}_{i} \times {}^{B_{i}}ω) \\ - ({{}^{B_{i}}ω}^{T} {}^{B_{i}}ω) ({{}^{B_{i}}w}_{i} \times {{}^{B_{i}}a}_{i}) - 2 {\overset{\cdot}{q}}_{i} {{}^{B_{i}}ω}_{i} \end{matrix})

(50)

where $\overset{\cdot}{ω}$ is the angular velocity vector of the moving platform.

For the central limb, we can get

{}^{B_{0}}{\overset{\cdot}{ω}}_{0} = 0_{3 \times 1}

(51)

Taking the derivative of equation (30) with respect to time and describing the result in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ , we get the linear acceleration of the center of mass $c_{i 1}$ in the ith limb

{}^{B_{i}}{\overset{\cdot}{v}}_{c_{i 1}} = {}^{B_{i}}{\overset{\cdot}{ω}}_{i} \times {{}^{B_{i}}e}_{i 1} + {{}^{B_{i}}ω}_{i} \times ({{}^{B_{i}}ω}_{i} \times {{}^{B_{i}}e}_{i 1})

(52)

Substituting equation (50) into equation (52), we obtain

\begin{matrix} {}^{B_{i}}{\overset{\cdot}{v}}_{c_{i 1}} = J_{v c_{i 1}} [\begin{matrix} \overset{\cdot}{v} \\ \overset{\cdot}{ω} \end{matrix}] \\ - \frac{1}{q_{i}} (\begin{matrix} (({{}^{B_{i}}ω}^{T} {{}^{B_{i}}a}_{i}) ({{}^{B_{i}}e}_{i 1}^{T} {}^{B_{i}}ω) - ({{}^{B_{i}}ω}^{T} {}^{B_{i}}ω) ({{}^{B_{i}}e}_{i 1}^{T} {{}^{B_{i}}a}_{i})) {{}^{B_{i}}w}_{i} \\ + e_{i 1} (- ({{}^{B_{i}}ω}^{T} {{}^{B_{i}}a}_{i}) {}^{B_{i}}ω + ({{}^{B_{i}}ω}^{T} {}^{B_{i}}ω) {{}^{B_{i}}a}_{i}) \\ + 2 {\overset{\cdot}{q}}_{i} ({{}^{B_{i}}ω}_{i} \times {{}^{B_{i}}e}_{i 1}) \end{matrix}) \\ - ({{}^{B_{i}}ω}_{i}^{T} {{}^{B_{i}}ω}_{i}) {{}^{B_{i}}e}_{i 1} \end{matrix}

(53)

For the central limb, we can get

{}^{B_{0}}{\overset{\cdot}{v}}_{c_{01}} = 0_{3 \times 1}

(54)

Taking the derivative of equation (37) with respect to time and describing the result in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ , we get the linear acceleration of the center of mass $c_{i 2}$ in the ith limb

{}^{B_{i}}{\dot{v}}_{c_{i 2}} = {}^{B_{i}}{\dot{v}} + {}^{B_{i}}{\dot{ω}} \times {{}^{B_{i}}a}_{i} + {}^{B_{i}}ω \times ({}^{B_{i}}ω \times {{}^{B_{i}}a}_{i}) - {}^{B_{i}}{\dot{ω}}_{i} \times {{}^{B_{i}}e}_{i 2} - {{}^{B_{i}}ω}_{i} \times ({{}^{B_{i}}ω}_{i} \times {{}^{B_{i}}e}_{i 2})

(55)

Substituting equation (50) into equation (55), we get

\begin{matrix} {}^{B_{i}}{\overset{\cdot}{v}}_{c_{i 2}} = J_{v c_{i 2}} [\begin{matrix} \overset{\cdot}{v} \\ \overset{\cdot}{ω} \end{matrix}] + {}^{B_{i}}ω \times ({}^{B_{i}}ω \times {{}^{B_{i}}a}_{i}) - {{}^{B_{i}}ω}_{i} \times ({{}^{B_{i}}ω}_{i} \times {{}^{B_{i}}e}_{i 2}) \\ + \frac{1}{q_{i}} S ({{}^{B_{i}}e}_{i 2}) (({{}^{B_{i}}ω}^{T} {{}^{B_{i}}a}_{i}) ({{}^{B_{i}}w}_{i} \times {}^{B_{i}}ω) \\ - ({{}^{B_{i}}ω}^{T} {}^{B_{i}}ω) ({{}^{B_{i}}w}_{i} \times {{}^{B_{i}}a}_{i}) - 2 {\overset{\cdot}{q}}_{i} {{}^{B_{i}}ω}_{i}) \end{matrix}

(56)

For the central limb, we can get

{}^{B_{0}}{\overset{\cdot}{v}}_{c_{02}} = \overset{\cdot}{v} = {\overset{\cdot\cdot}{q}}_{0} w_{0} = J_{v c_{02}} [\begin{matrix} \overset{\cdot}{v} \\ \overset{\cdot}{ω} \end{matrix}]

(57)

Jerk analysis

Taking the derivative of equation (43) with respect to time, we obtain

\begin{matrix} {\overset{\dots}{q}}_{0} w_{0} + \overset{\cdot\cdot}{ω} \times a_{i} + 2 \overset{\cdot}{ω} \times (ω \times a_{i}) \\ + ω \times (\overset{\cdot}{ω} \times a_{i}) + ω \times (ω \times (ω \times a_{i})) \\ = {\overset{\dots}{q}}_{i} w_{i} + 3 {\overset{\cdot\cdot}{q}}_{i} ω_{i} \times w_{i} + 3 {\overset{\cdot}{q}}_{i} ({\overset{\cdot}{ω}}_{i} \times w_{i}) \\ + 3 {\overset{\cdot}{q}}_{i} (ω_{i} \times (ω_{i} \times w_{i})) + {\overset{\cdot\cdot}{ω}}_{i} \times q_{i} w_{i} \\ + 2 q_{i} {\overset{\cdot}{ω}}_{i} \times (ω_{i} \times w_{i}) + q_{i} ω_{i} \times ({\overset{\cdot}{ω}}_{i} \times w_{i}) \\ + q_{i} ω_{i} \times (ω_{i} \times (ω_{i} \times w_{i})) \end{matrix}

(58)

Taking the dot product of both sides of equation (58) with $w_{i}$ , we get

\begin{matrix} {\overset{\dots}{q}}_{i} - 3 {\overset{\cdot}{q}}_{i} (ω_{i}^{T} ω_{i}) - 3 q_{i} ({\overset{\cdot}{ω}}_{i}^{T} ω_{i}) = {\overset{\dots}{q}}_{0} w_{i}^{T} w_{0} \\ + (a_{i} \times w_{i})^{T} \overset{\cdot\cdot}{ω} + 2 ({\overset{\cdot}{ω}}^{T} a_{i}) (w_{i}^{T} ω) \\ - 3 ({\overset{\cdot}{ω}}^{T} ω) (w_{i}^{T} a_{i}) + (ω^{T} a_{i}) (w_{i}^{T} \overset{\cdot}{ω}) \\ - (ω^{T} ω) w_{i}^{T} (ω \times a_{i}) \end{matrix}

(59)

By rewriting equation (59) in the matrix form, we obtain

[\begin{matrix} {\overset{\dots}{q}}_{0} \\ {\overset{\dots}{q}}_{1} \\ {\overset{\dots}{q}}_{2} \\ {\overset{\dots}{q}}_{3} \end{matrix}] = J [\begin{matrix} \overset{\cdot\cdot}{v} \\ \overset{\cdot\cdot}{ω} \end{matrix}] + [\begin{matrix} Y_{0} & Y_{1} & Y_{2} & Y_{3} \end{matrix}]^{T}

(60)

where $\overset{\cdot\cdot}{v}$ and $\overset{\cdot\cdot}{ω}$ denote the linear jerk scalar along the central limb and the angular jerk vector of the moving platform, and

Y_{0} = 0

(61)

\begin{matrix} Y_{i} = 3 {\overset{\cdot}{q}}_{i} (ω_{i}^{T} ω_{i}) + 3 q_{i} ({\overset{\cdot}{ω}}_{i}^{T} ω_{i}) \\ + 2 ({\overset{\cdot}{ω}}^{T} a_{i}) (w_{i}^{T} ω) - 3 ({\overset{\cdot}{ω}}^{T} ω) (w_{i}^{T} a_{i}) \\ + (ω^{T} a_{i}) (w_{i}^{T} \overset{\cdot}{ω}) - (ω^{T} ω) w_{i}^{T} (ω \times a_{i}) \end{matrix}

(62)

From equations (11), (26), (50), and (60)–(62), the joint jerk related to the velocity of the moving platform is proportional to the cubic of the magnitude of the velocity of the moving platform.

Inverse rigid-body dynamics

Applied and inertia moments

The resultant of applied and inertia forces exerted at the center of mass of the moving platform can be described in the coordinate system $B_{0} - xyz$ by

Q = [\begin{matrix} f \\ n \end{matrix}] = [\begin{matrix} (f_{e} + m g - m {\overset{\cdot}{v}}_{c}) \\ n_{e} - {}^{B_{0}}I \overset{\cdot}{ω} - ω \times ({}^{B_{0}}I ω) \end{matrix}]

(63)

where m, $g$ , $f_{e}$ , and $n_{e}$ denote the mass of the moving platform, the acceleration of gravity, the external force, and moment exerted at the center of mass of the moving platform, respectively. ${}^{B_{0}}I = {{}^{B_{0}}R}_{A_{0}} {}^{A_{0}}I {{}^{A_{0}}R}_{B_{0}}$ is the inertia matrix of the moving platform about the center of mass in the coordinate system $B_{0} - xyz$ , and ${\overset{\cdot}{v}}_{c}$ is the acceleration of the center of mass of the moving platform. When the rotation point $A_{0}$ is not the center of mass of the moving platform, we get

r_{c} = q_{0} w_{0} + r_{A_{0} C}

(64)

where $r_{A_{0} C}$ is the vector from the point of joint $A_{0}$ to the center of mass of the moving platform, we can obtain

v_{c} = v + ω \times r_{A_{0} C}

(65)

{\overset{\cdot}{v}}_{c} = \overset{\cdot}{v} + \overset{\cdot}{ω} \times r_{A_{0} C} + ω \times (ω \times r_{A_{0} C})

(66)

when the point of joint $A_{0}$ and the center of mass of the moving platform are the same point, we can get $v_{c} = v$ and ${\overset{\cdot}{v}}_{c} = \overset{\cdot}{v}$ .

For the ith strut which is connected with the base platform, the resultant of applied and inertia forces exerted at the center of mass can be described in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$

{{}^{B_{i}}Q}_{c_{i 1}} = [\begin{matrix} {{}^{B_{i}}f}_{c_{i 1}} \\ {{}^{B_{i}}n}_{c_{i 1}} \end{matrix}] = [\begin{matrix} m_{c_{i 1}} {{}^{B_{i}}R}_{B_{0}} g - m_{c_{i 1}} {}^{B_{i}}{\overset{\cdot}{v}}_{c_{i 1}} \\ - {{}^{B_{i}}I}_{c_{i 1}} {}^{B_{i}}{\overset{\cdot}{ω}}_{i} - {{}^{B_{i}}ω}_{i} \times ({{}^{B_{i}}I}_{c_{i 1}} {{}^{B_{i}}ω}_{i}) \end{matrix}]

(67)

where $m_{c_{i 1}}$ is the mass of the ith strut connected with the base platform and ${{}^{B_{i}}I}_{c_{i 1}}$ is the inertia matrix of the ith strut about the center of mass in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ .

Similarly, for the ith strut which is connected with the moving platform, the resultant of applied and inertia forces exerted at the center of mass can be described in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$

{{}^{B_{i}}Q}_{c_{i 2}} = [\begin{matrix} {{}^{B_{i}}f}_{c_{i 2}} \\ {{}^{B_{i}}n}_{c_{i 2}} \end{matrix}] = [\begin{matrix} m_{c_{i 2}} {{}^{B_{i}}R}_{B_{0}} g - m_{c_{i 2}} {}^{B_{i}}{\overset{\cdot}{v}}_{c_{i 2}} \\ - {{}^{B_{i}}I}_{c_{i 2}} {}^{B_{i}}{\overset{\cdot}{ω}}_{i} - {{}^{B_{i}}ω}_{i} \times ({{}^{B_{i}}I}_{c_{i 2}} {{}^{B_{i}}ω}_{i}) \end{matrix}]

(68)

where $m_{c_{i 2}}$ is the mass of the ith strut connected with the moving platform and ${{}^{B_{i}}I}_{c_{i 2}}$ is the inertia matrix of the ith strut about the center of mass in the coordinate system $B_{i} - x_{i} y_{i} z_{i}$ .

Due to the rotation motion for lead screw, coupler, and motor, the resultant of applied and inertia forces exerted at the screw–coupler–rotor can be obtained

N_{i} = (τ_{i} - I_{LCMi} {\overset{\cdot\cdot}{θ}}_{i}) {{}^{B_{i}}w}_{i}

(69)

where $τ_{i}$ is the input torque actuated by the motor; $I_{LCMi}$ is the total rotary inertia of the lead screw, coupler, and motor rotor; ${\overset{\cdot\cdot}{θ}}_{i}$ is the angular acceleration of the motor rotor; and

{\overset{\cdot}{θ}}_{i} = \frac{2 π j_{i}}{p_{i}} {\overset{\cdot}{q}}_{i}

(70)

{\overset{\cdot\cdot}{θ}}_{i} = \frac{2 π j_{i}}{p_{i}} {\overset{\cdot\cdot}{q}}_{i}

(71)

where $p_{i}$ is the lead of the linear ball screw and $j_{i}$ is the reduction ratio.

Driving torque

Extending the principle of the virtual work from the static to the dynamic case with the D’Alembert’s principle, we can get

δ x_{c}^{T} Q + \sum_{i = 1}^{3} (δ {{}^{B_{i}}x}_{c_{i 1}}^{T} {{}^{B_{i}}Q}_{c_{i 1}}) + \sum_{i = 0}^{3} (δ {{}^{B_{i}}x}_{c_{i 2}}^{T} {{}^{B_{i}}Q}_{c_{i 2}} + δ θ_{i} {{}^{B_{i}}w}_{i}^{T} {{}^{B_{i}}N}_{i}) = 0

(72)

Substituting equation (69) into equation (72), we get

δ x_{c}^{T} Q + \sum_{i = 1}^{3} (δ {{}^{B_{i}}x}_{c_{i 1}}^{T} {{}^{B_{i}}Q}_{c_{i 1}}) + \sum_{i = 0}^{3} (δ {{}^{B_{i}}x}_{c_{i 2}}^{T} {{}^{B_{i}}Q}_{c_{i 2}}) + δ θ^{T} N = 0

(73)

where

δ θ = [\begin{matrix} δ θ_{0} & δ θ_{1} & δ θ_{2} & δ θ_{3} \end{matrix}]^{T} = A δ q

(74)

A = diag (\begin{matrix} \frac{2 π j_{0}}{p_{0}} & \frac{2 π j_{1}}{p_{1}} & \frac{2 π j_{2}}{p_{2}} & \frac{2 π j_{3}}{p_{3}} \end{matrix})

(75)

δ q = [\begin{matrix} δ q_{0} & δ q_{1} & δ q_{2} & δ q_{3} \end{matrix}]^{T}

(76)

N = τ - I_{LCM} \overset{\cdot\cdot}{θ}

(77)

τ = [\begin{matrix} τ_{0} & τ_{1} & τ_{2} & τ_{3} \end{matrix}]^{T}

(78)

\overset{\cdot\cdot}{θ} = [\begin{matrix} {\overset{\cdot\cdot}{θ}}_{0} & {\overset{\cdot\cdot}{θ}}_{1} & {\overset{\cdot\cdot}{θ}}_{2} & {\overset{\cdot\cdot}{θ}}_{3} \end{matrix}]^{T}

(79)

I_{LCM} = diag (\begin{matrix} I_{LCM 0} & I_{LCM 1} & I_{LCM 2} & I_{LCM 3} \end{matrix})

(80)

From equations (11), (36), (39), and (65), the relationships between the virtual displacement $δ θ$ , $δ {{}^{B_{i}}x}_{c_{i 1}}$ , $δ {{}^{B_{i}}x}_{c_{i 2}}$ , $δ x_{c}$ , and the virtual displacement $δ x$ can be obtained

δ θ = AJ δ x

(81)

δ {{}^{B_{i}}x}_{c_{i 1}} = J_{c_{i 1}} δ x

(82)

δ {{}^{B_{i}}x}_{c_{i 2}} = J_{c_{i 2}} δ x

(83)

δ x_{c} = [\begin{matrix} w_{0} & - S (r_{A_{0} C}) \\ 0_{3 \times 1} & E_{3 \times 3} \end{matrix}] δ x = J_{c} δ x

(84)

where $δ x_{c}$ is the rotational virtual displacement and the virtual displacement consists of the translational virtual displacement of the center of mass of the moving platform; $δ x$ is the rotational virtual displacement of the moving platform and the virtual displacement of the point of joint $A_{0}$ .

Substituting equations (81)–(84) into equation (73), we get

δ x^{T} J_{c}^{T} Q + \sum_{i = 1}^{3} (δ x^{T} J_{c_{i 1}}^{T} {{}^{B_{i}}Q}_{c_{i 1}}) + \sum_{i = 0}^{3} (δ x^{T} J_{c_{i 2}}^{T} {{}^{B_{i}}Q}_{c_{i 2}}) + δ x^{T} J^{T} A^{T} N = 0

(85)

Since equation (85) is always valid for any virtual displacement $δ x$ , it must follow

J_{c}^{T} Q + \sum_{i = 1}^{3} (J_{c_{i 1}}^{T} {{}^{B_{i}}Q}_{c_{i 1}}) + \sum_{i = 0}^{3} (J_{c_{i 2}}^{T} {{}^{B_{i}}Q}_{c_{i 2}}) + J^{T} A^{T} {}^{B_{i}}N = 0

(86)

Substituting equation (77) into equation (86), we get

τ = - A^{- T} J^{- T} (J_{c}^{T} Q + \sum_{i = 1}^{3} (J_{c_{i 1}}^{T} {{}^{B_{i}}Q}_{c_{i 1}}) + \sum_{i = 0}^{3} (J_{c_{i 2}}^{T} {{}^{B_{i}}Q}_{c_{i 2}})) + I_{L C M} \overset{\cdot\cdot}{θ}

(87)

Substituting equations (63) and (67)–(69) into equation (87), we obtain

\begin{matrix} τ = - A^{- T} J^{- T} (J_{c}^{T} [\begin{matrix} f_{e} \\ n_{e} \end{matrix}]) - A^{- T} J^{- T} {\begin{matrix} (J_{c}^{T} [\begin{matrix} m g \\ 0_{3 \times 1} \end{matrix}]) + \sum_{i = 1}^{3} (J_{c_{i 1}}^{T} [\begin{matrix} m_{c_{i 1}} {{}^{B_{i}}R}_{B_{0}} g \\ 0_{3 \times 1} \end{matrix}]) \\ + \sum_{i = 0}^{3} (J_{c_{i 2}}^{T} [\begin{matrix} m_{c_{i 2}} {{}^{B_{i}}R}_{B_{0}} g \\ 0_{3 \times 1} \end{matrix}]) \end{matrix}} \\ + A^{- T} J^{- T} {(J_{c}^{T} [\begin{matrix} m {\overset{\cdot}{v}}_{c} \\ {}^{B_{0}}I \overset{\cdot}{ω} \end{matrix}]) + \sum_{i = 1}^{3} (J_{c_{i 1}}^{T} [\begin{matrix} m_{c_{i 1}} {}^{B_{i}}{\overset{\cdot}{v}}_{c_{i 1}} \\ {{}^{B_{i}}I}_{c_{i 1}} {}^{B_{i}}{\overset{\cdot}{ω}}_{i} \end{matrix}]) + \sum_{i = 0}^{3} (J_{c_{i 2}}^{T} [\begin{matrix} m_{c_{i 2}} {}^{B_{i}}{\overset{\cdot}{v}}_{c_{i 2}} \\ {{}^{B_{i}}I}_{c_{i 2}} {}^{B_{i}}{\overset{\cdot}{ω}}_{i} \end{matrix}])} \\ + A^{- T} J^{- T} {\begin{matrix} (J_{c}^{T} [\begin{matrix} 0 \\ ω \times ({}^{B_{0}}I ω) \end{matrix}]) + \sum_{i = 1}^{3} (J_{c_{i 1}}^{T} [\begin{matrix} 0_{3 \times 1} \\ {{}^{B_{i}}ω}_{i} \times ({{}^{B_{i}}I}_{c_{i 1}} {{}^{B_{i}}ω}_{i}) \end{matrix}]) \\ + \sum_{i = 0}^{3} (J_{c_{i 2}}^{T} [\begin{matrix} 0_{3 \times 1} \\ {{}^{B_{i}}ω}_{i} \times ({{}^{B_{i}}I}_{c_{i 2}} {{}^{B_{i}}ω}_{i}) \end{matrix}]) \end{matrix}} + I_{LCM} \overset{\cdot\cdot}{θ} \end{matrix}

(88)

Substituting equations (12), (26), (50), (53), (56), (57), and (66) into equation (88), we get

\begin{matrix} τ = M (x) \overset{\cdot\cdot}{x} + V (x, \overset{\cdot}{x}) + g (x) - A^{- T} J^{- T} [\begin{matrix} f_{e} \\ n_{e} \end{matrix}] \\ = τ_{a} + τ_{v} + τ_{g} + τ_{e} \\ = τ_{mov} + τ_{lmov} + τ_{lbase} + τ_{LCM} + τ_{e} \end{matrix}

(89)

where $τ_{mov}$ , $τ_{lmov}$ , $τ_{lbase}$ , and $τ_{LCM}$ are the torques related to the moving platform, strut connect with the moving platform, strut connected with the base platform, and motor rotor-coupler, respectively. $τ_{a}$ , $τ_{v}$ , $τ_{g}$ , and $τ_{e}$ are the torques related to the acceleration, velocity, gravity, and external force components, respectively. $M (x)$ is the generalized inertia matrix which maps the acceleration of the moving platform into the driving torque

\begin{matrix} M (x) = A^{- T} J^{- T} \\ (\begin{matrix} J_{c}^{T} [\begin{matrix} m E_{3 \times 3} & 0_{3 \times 3} \\ 0_{3 \times 3} & {}^{B_{0}}I \end{matrix}] J_{c} \\ + \sum_{i = 1}^{3} (J_{v c_{i 1}}^{T} m_{c_{i 1}} J_{v c_{i 1}} + J_{i ω}^{T} {{}^{B_{i}}I}_{c_{i 1}} J_{i ω}) \\ + \sum_{i = 0}^{3} (J_{v c_{i 2}}^{T} m_{c_{i 2}} J_{v c_{i 2}} + J_{i ω}^{T} {{}^{B_{i}}I}_{c_{i 2}} J_{i ω}) \end{matrix}) + I_{LCM} AJ \\ = [\begin{matrix} M_{0} & M_{1} & M_{2} & M_{3} \end{matrix}] = [\begin{matrix} M_{v} & M_{ω} \end{matrix}] \end{matrix}

(90)

From equation (26), (50), (53), (55), and (88), the driving torque related to the velocity of the moving platform is proportional to the square of the magnitude of the velocity of the moving platform.

Driving power

The instantaneous required driving power of the ith actuating joint can be calculated by

P_{i} = τ_{i} {\overset{\cdot}{θ}}_{i}

(91)

where $τ_{i}$ and ${\overset{\cdot}{θ}}_{i}$ are the driving torque and angular velocity of ith actuating joint, respectively.

Substituting equation (89) into equation (91), we obtain

P_{i} = (τ_{ia} + τ_{iv} + τ_{ig} + τ_{ie}) {\overset{\cdot}{θ}}_{i} = P_{ia} + P_{iv} + P_{ig} + P_{ie}

(92)

\begin{matrix} P_{i} = (τ_{imov} + τ_{ilmov} + τ_{ilbase} + τ_{iLCM} + τ_{ie}) {\overset{\cdot}{θ}}_{i} \\ = P_{imov} + P_{ilmov} + P_{ibase} + P_{iLCM} + P_{ie} \end{matrix}

(93)

where $P_{imov}$ , $P_{ilmov}$ , $P_{ibase}$ , and $P_{iLCM}$ are the respective power components related to the moving platform, strut connected with the moving platform, strut connected with the base platform, and motor rotor-coupler. $P_{ia}$ , $P_{iv}$ , $P_{ig}$ , and $P_{ie}$ are the respective required powers of the ith actuating joint related to the acceleration component of torque, velocity component of torque, gravity component of torque, and external force component of torque, respectively.

From equations (26), (50), (53), (55), (88), and (91), the driving power related to the velocity of the moving platform is proportional to the cubic of the magnitude of the velocity of the moving platform. From equations (45), (50), (53), (55), (60), (88), and (91), there are linear relationships between the acceleration of the moving platform and the components of the joint acceleration, joint jerk, driving torque, and driving power, which are related to the acceleration of the moving platform.

Energy consumption

From the work-energy theorem and the concept of integral, the required output work generated by the ith driving motor during a specific motion period can be calculated by

W_{i} = \int_{t_{s}}^{t_{e}} | P_{i} | dt

(94)

where $t_{s}$ is the start time and $t_{e}$ is the end time of the motion.

Equation (94) can be implemented by the following numerical integration

W_{i} = \frac{Δ t}{2} [| P_{i} (t_{s}) | + | P_{i} (t_{e}) | + 2 \sum_{k = 1}^{num - 1} | P_{i} (t_{k}) |]

(95)

where

Δ t = \frac{t_{e} - t_{s}}{num}

(96)

And num is the number of the intervals, in general

num = 2^{n}

(97)

where n is a positive integer. The error of the numerical computation should satisfy

| W_{i} (num = 2^{n_{1}}) - W_{i} (num = 2^{n_{1} - 1}) | \leq e

(98)

where e is the maximum allowable numerical computation error and $n_{1}$ is the positive integer selected for the numerical integration.

Example

The numerical example for the computation of the position, velocity, acceleration, jerk, torque, power, and energy consumption for the 3UPS-PRU parallel robot is provided in this section when the trajectory of the moving platform is assigned. The parameters of the 3UPS-PRU parallel robot are given in Tables 1 –4. The distance from the point of joint $A_{0}$ to the center of mass of the moving platform is $r_{A_{0} C} = 0.005 m$ . The trajectory of the moving platform is assigned as

{\begin{matrix} z = z_{0} - 0.075 + \frac{a_{t max} T^{2}}{7.513188} (35 τ^{4} - 84 τ^{5} + 70 τ^{6} - 20 τ^{7}) \\ ϕ_{x} = - 0.10 + \frac{a_{r max} T^{2}}{7.513188} (35 τ^{4} - 84 τ^{5} + 70 τ^{6} - 20 τ^{7}) \\ ϕ_{y} = - 0.10 + \frac{a_{r max} T^{2}}{7.513188} (35 τ^{4} - 84 τ^{5} + 70 τ^{6} - 20 τ^{7}) \\ ϕ_{z} = 0.10 \end{matrix}

(99)

where $a_{r max} = 0.2 rad / s^{2}$ , $S_{r} = 0.2 rad$ , $S_{t} = 0.15 m$ , $a_{t max} = 0.15 m / s^{2}$ , $τ = t / T$ , $T = \sqrt{7.513188 S_{r} / a_{r max}}$ .

Table 1.

The parameters of the base platform (m).

	1	2	3
$x_{Bi}$	0.200000	−0.100000	−0.100000
$y_{Bi}$	0.000000	0.173205	−0.173205
$z_{Bi}$	0.000000	0.000000	0.000000

Table 2.

The parameters of the moving platform measured in the coordinate system $A_{0} - uvw$ (m).

	1	2	3
$x_{Ai}$	0.175000	−0.087500	−0.087500
$y_{Ai}$	0.000000	0.151554	−0.151554
$z_{Ai}$	0.000000	0.000000	0.000000

Table 3.

The length of the struts connected, respectively, with the moving platform and the base platform (m).

	0	1	2	3
$l_{ai}$	0.300000	0.300000	0.300000	0.300000
$l_{bi}$	0.300000	0.300000	0.300000	0.300000

Table 4.

The mass of the moving platform and the struts connected, respectively, with the moving platform and the base platform (kg).

$m_{i}$	$m_{c_{ij, 1}}$	$m_{c_{ij, 2}}$
2.597704	0.145047	0.099243

The variations of the position, velocity, acceleration, and jerk of the actuating joints are shown in Figure 4. It is shown in Figure 4 that the position, velocity, acceleration, and jerk of the second actuating joint are larger than those of the other three actuating joints. The velocity, acceleration, and jerk of the actuating joints are zeros at the start time and the end time of the specific motion period.

Figure 4.

Variations of (a) position, (b) velocity, (c) acceleration, and (d) jerk of actuating joints versus time.

The total driving torques and the driving torques related to the acceleration, velocity, and gravity are shown in Figure 5. The effects of the external force on the driving torques are not considered since the relationship between the driving torque and the external force is simple. It is shown in Figure 5 that the total driving torque and the driving torques related to the acceleration, velocity, and gravity of the central limb are larger than those of the other three limbs due to the gravity of the moving platform. For the three outer limbs, the torque related to the acceleration is larger than the torques related to the velocity and gravity.

Figure 5.

Variations of (a) total driving torques, (b) torques related to acceleration, (c) torques related to velocity, and (d) torques related to gravity versus time.

The driving torques related to the moving platform, motor rotor-coupler, strut connected with the moving platform, and strut connected with the base platform are shown in Figure 6. It is shown in Figure 6 that the driving torques related to the moving platform, strut connected with the moving platform, and strut connected with the base platform of the central limb are larger than those of the three outer limbs. The torque related to the moving platform is largest for the central limb. The torques related to the strut connected with the moving platform are larger than the torques related to the strut connected with the base platform.

Figure 6.

Variations of driving (a) torques related to moving platform, (b) torques related to motor rotor-coupler, (c) torques related strut connected with the moving platform, and (d) torques related to strut connected with the base platform versus time.

The required driving powers of the actuating joint and the driving powers related to the acceleration component of torque, velocity component of torque, and gravity component of torque are shown in Figure 7. It is shown in Figure 7 that the driving power of the central limb is larger than those of the three outer limbs. For the central limb, the driving power is dominated by the component related to the gravity component of torque in the simulation.

Figure 7.

Variations of (a) total driving powers, (b) powers related to acceleration component of torque, (c) powers related to velocity component of torque, and (d) powers related to gravity component of torque versus time.

The driving powers related to the moving platform, motor rotor-coupler, strut connected with the moving platform, and strut connected with the base platform are shown in Figure 8. It is shown in Figure 8 that the driving powers related to the moving platform, motor rotor-coupler, strut connected with the moving platform, and strut connected with the base platform of the central limb are larger than those of the three outer limbs. The power related to the moving platform is largest for the central limb. The powers related to the strut connected with the moving platform are larger than the powers related to the strut connected with the base platform. For the three outer limbs, the powers related to the strut connected with the moving platform are the largest, the powers related to the strut connected with the base platform take the second place, and the powers related to the moving platform and motor rotor-coupler are the smallest.

Figure 8.

Variations of driving (a) powers related to moving platform, (b) powers related to motor rotor-coupler, (c) powers related strut connected with the moving platform, and (d) powers related to strut connected with the base platform versus time.

From the numerical technique, when the moving platform translates and rotates along the pre-defined trajectory presented in equation (99), the required output work generated by the ith driving motor can be achieved by equation (95). The positive integer $n = 14$ and the approximation error $e = 10^{- 6}$ are selected for the numerical integration computation. For the pre-defined trajectory, the required output work generated by the ith driving motor and the sum considering all four motors are shown in Table 5. It is shown in Table 5 that the required output work generated by the central motor is largest. The required output work generated by the three outer motors is small due to the support by the central limb and the self-balance of the moving platform.

Table 5.

The required output work generated by the ith driving motor and the sum considering four motors for the pre-defined trajectory (J).

	0	1	2	3	Sum
$W_{i}$	4.471097	0.018114	0.030194	0.020261	4.539666

Conclusion

This article presents the inverse kinematics and rigid-body dynamics for a 3UPS-PRU parallel robot. The kinematics and rigid-body dynamics have been formulated and investigated in an exhaustive decoupled way. In the inverse kinematics analysis, the position, velocity, acceleration, jerk, and singularity have been considered. The driving torque, driving power, and required output work of motors have been computed in the inverse rigid-body dynamics analysis. The required output work generated by the driving motor is achieved by numerical integration technique. For the pre-defined trajectory, the required output work generated by the driving motor is achieved by numerical integration technique. The inverse kinematics and rigid-body dynamics have been investigated in an exhaustive decoupled way. There is a linear relationship between the velocity vector of the moving platform and the joint velocity vector. The components of the joint acceleration and driving torque, which are related to the velocity of the moving platform, are proportional to the square of the magnitude of the velocity of the moving platform. The components of the joint jerk and driving power, which are related to the velocity of the moving platform, are proportional to the cubic of the magnitude of the velocity of the moving platform. There are linear relationships between the acceleration of the moving platform and the components of the joint acceleration, joint jerk, driving torque, and driving power, which are related to the acceleration of the moving platform.

Footnotes

Acknowledgements

The authors would also like to thank the anonymous reviewers for their very useful comments.

Academic Editor: José Tenreiro Machado

Declaration of conflicting interests

The author(s) declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.

Funding

The author(s) disclosed receipt of the following financial support for the research, authorship, and/or publication of this article: This research is jointly sponsored by the National Natural Science Foundation of China (Grant No. 51375288), the Science and Technology Program of Guangdong Province (Grant No. 2015B090906001), and the Special Research Foundation of Discipline Construction of Guangdong Province (Grant No. 2013KJCX0075).

References

Dong

Xiao

. Development of a parallel kinematic motion simulator platform. Mechatronics 2013; 23: 154–161.

Zhao

Gao

. Development of 6-dof parallel seismic simulator with novel redundant actuation. Mechatronics 2009; 19: 422–427.

Cheng

Feng

. Configuration bifurcation and self-motion analysis of 3SPS + 1PS bionic parallel test platform for hip joint simulator. Mech Mach Theory 2015; 86: 62–72.

Staicu

Recursive modelling in dynamics of delta parallel robot. Robotica 2009; 27: 199–207.

Yang

Huang

Dynamics and elasto-dynamics optimization of a 2-DOF planar parallel pick-and-place robot with flexible links. Struct Multidiscip O 2009; 38: 195–204.

Zhao

Dynamic performance evaluation of a three translational degrees of freedom parallel robot. Int J Robot Autom 2012; 27: 31–40.

Mills

Benhabib

Dynamic modeling and control design for a parallel-mechanism-based meso-milling machine tool. Robotica 2014; 32: 515–532.

Zhang

Parallel robotic machine tools. New York: Springer, 2010.

Wang

Liu

. Dynamic performance comparison and counterweight optimization of two 3-DOF parallel manipulators for a new hybrid machine tool. Mech Mach Theory 2010; 45: 1668–1680.

10.

Zhao

Dynamic optimum design of a three translational degrees of freedom parallel robot while considering anisotropic property. Robot Cim: Int Manuf 2013; 29: 100–112.

11.

Chen

Liao

TT.

A hybrid strategy for the time- and energy-efficient trajectory planning of parallel platform manipulators. Robot Cim: Int Manuf 2011; 27: 72–81.

12.

Tsai

LW.

Solving the inverse dynamics of a Stewart-Gough manipulator by the principle of virtual work. J Mech Des: T ASME 2000; 122: 3–9.

13.

Huang

Mei

ZX.

A method for estimating servomotor parameters of a parallel robot for rapid pick-and-place operations. J Mech Des: T ASME 2005; 127: 596–601.

14.

Zhao

Qiu

Wang

. Inverse kinematics and rigid-body dynamics for a three rotational degrees of freedom parallel manipulator. Robot Cim: Int Manuf 2015; 31: 40–50.

15.

Zhao

Gao

The joint velocity, torque and power capability evaluation of a redundant parallel manipulator. Robotica 2011; 29: 483–493.

16.

Codourey

Dynamic modeling of parallel robots for computed-torque control implementation. Int J Robot Res 1998; 17: 1325–1336.

17.

Zhang

BZ.

Design and kinetostatic analysis of a new parallel manipulator. Robot Cim: Int Manuf 2008; 25: 782–791.

18.

Abdellatif

Heimann

Computational efficient inverse dynamics of 6-DOF fully parallel manipulators by using the Lagrangian formalism. Mech Mach Theory 2009; 44: 192–207.

19.

Liu

CN.

Dynamics analysis of the Gough–Stewart platform manipulator. IEEE T Robotic Autom 2000; 16: 94–98.

20.

Zhao

Gao

Inverse dynamics of the 6-dof out-parallel manipulator by means of the principle of virtual work. Robotica 2009; 27: 259–268.

21.

Ur-Rehman

Caro

Chablat

. Multi-objective path placement optimization of parallel kinematics machines based on energy consumption, shaking forces and maximum actuator torques: application to the Orthoglide. Mech Mach Theory 2010; 45: 1125–1141.

22.

Staicu

Zhang

A novel dynamic modelling approach for parallel mechanisms analysis. Robot Cim: Int Manuf 2008; 24: 167–172.

23.

. Dynamic analysis of a modified DELTA parallel robot for cardiopulmonary resuscitation. In: Proceedings of the IEEE/RSJ international conference on intelligent robotics and systems, Edmonton, AB, Canada, 2–6 August 2005, pp.3371–3376. New York: IEEE.

24.

Wang

. Dynamics and control of a planar 3-DOF parallel manipulator with actuation redundancy. Mech Mach Theory 2009; 44: 835–849.

25.

Gallardo

Rico

Frisoli

. Dynamics of parallel manipulators by means of screw theory. Mech Mach Theory 2003; 38: 1113–1131.

26.

Staicu

Liu

Explicit dynamics equations of the constrained robotic systems. Nonlinear Dyn 2009; 58: 217–235.

27.

Staicu

Dynamics of the spherical 3-UPS/S parallel mechanism with prismatic actuators. Multibody Syst Dyn 2009; 22: 115–132.
