Transient response and frequency domain analysis of an electrically variable transmission

Abstract

This article deals with the dynamic behavior of a passenger car equipped with an electrically variable transmission, which is analyzed both in time and frequency domains. After deriving the dynamic equations in the state-space form for both open- and closed-loop systems, a methodology for objectively evaluating the drivability of this over-actuated system is proposed. Several simulation results are presented with the aim of highlighting the transient response to fast engine torque changes and the effect of the generator speed controller calibration on the system dynamics. Moreover, the influence of the ratio between electrical and thermal power on the frequency response is discussed. The proposed analysis, which is based on a simple static torque split between internal combustion engine and propulsion electric motor, depicts the dynamic signature of the electrically variable transmission powertrain system, without any additional drivability filter. Hence, these results can constitute the base for the design of dynamic torque splitting aimed at optimizing the longitudinal vehicle response to the driver’s acceleration demand.

Keywords

Electrically variable transmission hybrid vehicles transmission modeling transmission dynamics drivability

Introduction

The ever-increasing popularity of hybrid electric vehicles (HEVs) has led to the development of new transmission systems combining electric motors and internal combustion engine (ICE) in an optimized way. An electrically variable transmission (EVT) is a type of power-split transmission used to propel HEVs. It uses two motor-generator units to obtain a continuously variable speed ratio between the engine crankshaft and the wheels, thereby permitting the engine to supply power very efficiently. The strategy to control the energy flow among these multiple sources is termed “energy management” and is crucial for fuel economy.

Most existing works in the literature focus on controllers that try to minimize fuel consumption, neglecting other attributes that affect the smoothness and responsiveness of vehicle, which are commonly referred to as drivability.¹

Vinot et al.² use optimal offline management with discrete dynamic programming to evaluate the fuel consumption in the global design process of an EVT, aiming at minimizing fuel consumption and the number of battery cells. Kessels et al.³ face the optimization of the power flow by means of an integrated powertrain control considering the efficiency of all powertrain components, aiming at energy efficiency. Similarly, other authors focus on different transmission layouts, for example, series⁴ or parallel⁵ hybrid architectures, always limiting to fuel economy or low emission aspects; Delkhosh et al.⁶ present a control strategy that can be used only for hybrid vehicles with Continuously Variable Transmission (CVT), proposing an optimization for different driving cycles.

Taylor and Katariya⁷ developed a dynamic model for a two-mode EVT and proposed a control system capable of meeting driver torque demands while also accommodating preferred engine operating points.

Other works⁸ discuss different layouts and solutions for EVT transmissions comparing the power performances of each proposal, but also considering some production aspects (costs, ease of manufacture, and sustainability).

Besides energy management tasks, drivability aspects are becoming increasingly important for HEVs. In particular, drivability refers to the powertrain capability of guaranteeing smooth and fast vehicle response to driver requests and to manage the operating mode change without perceptible noise and vibration. These aspects mainly affect the vehicle longitudinal dynamic performance and require finding a trade-off between comfort and sporty feeling also in relation to the specific segment and mission of the car.

In Opila et al.,¹ drivability restrictions are directly incorporated in a causal, optimal controller design method for the energy management system of an HEV. The focus is on drivability with respect to engine start-stop and gear shifts; a host of other drivability issues, such as low-frequency longitudinal vibration and other attributes which are typically mitigated by hardware design or low-level control actions, are not considered.

The purpose of the study reported in Galvagno et al.⁹ is to assess the drivability of a through-the-road-parallel HEV, with an ICE powering the front axle and an electric motor the rear axle. Through the simulation of a linearized model, the vehicle response to the diver request is analyzed in the time and frequency domain. The effect of the actual gear ratio is investigated and a sensitivity analysis of the influence of the torque distribution between the front (thermal) and rear (electric) axles on vehicle drivability is presented.

In the study by Koprubasi et al.,¹⁰ the typical drivability issues of a power-split hybrid-electric vehicle are considered and identified: pedal tip-in and tip-out, change of operating modes, and gear shifting are discussed. The proposed model is useful for the design, improvement, and calibration of control strategies.

The purpose of this article is to present a drivability-oriented dynamic model for the one-mode EVT, which takes into account the effect of the generator speed controller on the vehicle dynamic performance and on the low frequency torsional behavior of the transmission. After presenting the considered powertrain layout and the adopted lumped parameter model, the dynamic and kinematic equations are reported. The final state-space formulations of both uncontrolled (open loop) and controlled system, considering a closed-loop proportional generator speed controller, are shown.

A frequency response function (FRF) suitable for the drivability assessment of this kind of HEV architecture is proposed and then used to evaluate the influence of different parameters. Finally, the transient response during the application of engine torque disturbances is evaluated under different vehicle speeds and controller calibrations.

Series/parallel hybrid electric powertrain

Figure 1(a) shows the powertrain layout of a series/parallel HEV: this powertrain architecture, also known as input-split EVT, allows changing continuously the speed ratio between the engine and the driving wheels. In fact, the generator, in addition to enabling the transfer of mechanical power from the engine to the wheels through the power-split device by absorbing or generating electrical power, realizes a speed ratio controller, as will be shown in the article.

Figure 1.

Input-split EVT: (a) layout and (b) mechanical model.

With reference to Figure 1, the ICE E shaft is connected to the planet carrier c of the epicyclic gear set EGS (also known as power-split device) through a torsional damper. The other two mechanical interfaces of the EGS are connected to generator G, via sun gear s, and to electric motor M and final reduction stage of the transmission via the ring gear r. The final reduction stage is composed of a silent chain transmission SC and an ordinary gear train. Finally, the differential gear D splits the transmission output torque to the two half-shafts and allows the transfer of the mechanical power to the driving wheels W of the vehicle.

An appropriate lumped parameter model to study the drivability of the analyzed system is shown in Figure 1(b). The compliances of the transmission system are lumped in three spring and damper elements: one for the torsional damper downstream of the engine and one for each half-shaft. In addition, also the tire torsional flexibility is considered by means of a model that includes the effects of the tire relaxation-length. More details about the modeling process and assumptions are given in the following section.

Dynamic model

The model equations for each powertrain component are here reported.

Engine

A first-order differential equation is introduced for modeling the dynamics of the engine torque generation system

{\overset{\cdot}{T}}_{e} = \frac{1}{τ_{e}} (T_{de} - T_{e})

(1)

where $T_{de}$ is the desired engine torque, $T_{e}$ is the effective engine torque applied by the engine, and $τ_{e}$ is a time constant.

The second equation of the engine model is the dynamic balance of the moments applied to the engine shaft

T_{e} - J_{e} {\overset{\cdot\cdot}{θ}}_{e} - [k_{d} (θ_{e} - θ_{c}) + β_{d} ({\overset{\cdot}{θ}}_{e} - {\overset{\cdot}{θ}}_{c})] = 0

(2)

$J_{e}$ is the mass moment of inertia of the engine and flywheel, $k_{d}$ and $β_{d}$ are the torsional stiffness and damping of the torsional damper, ${\overset{\cdot}{θ}}_{e}$ and ${\overset{\cdot}{θ}}_{c}$ are the angular speeds of the engine and the planet carrier of the planetary gear set.

Electric generator

For the generator, a first-order model is also used to describe the torque generation system

{\overset{\cdot}{T}}_{g} = \frac{1}{τ_{g}} (T_{dg} - T_{g})

(3)

Newton’s second law applied to the generator rotating inertia gives

T_{g} - J_{g} {\overset{\cdot\cdot}{θ}}_{g} + T_{s / g} = 0

(4)

where $T_{g}$ is the effective generator torque, $J_{g}$ is the mass moment of inertia of the generator, $T_{s / g}$ is the EGS sun gear torque, and ${\overset{\cdot}{θ}}_{g}$ is the angular speed of the electric generator.

Electric motor

Similar to the other actuators, the delay due to the electric motor torque control system is modeled as follows

{\overset{\cdot}{T}}_{m} = \frac{1}{τ_{m}} (T_{dm} - T_{m})

(5)

T_{m} - J_{m} {\overset{\cdot\cdot}{θ}}_{m} + T_{r / m} - T_{sc} = 0

(6)

where $T_{m}$ is the effective propulsion electric motor torque, $J_{m}$ is the mass moment of inertia of the electric motor, $T_{r / m}$ is the EGS ring gear torque, $T_{sc}$ is the silent chain torque, and ${\overset{\cdot}{θ}}_{m}$ is the angular speeds of the electric motor.

Primary shaft

i_{sc} η_{sc} T_{sc} - J_{G 1} {\overset{\cdot\cdot}{θ}}_{G 1} - T_{G 2} = 0

(7)

$T_{G 2}$ is the torque coming from the secondary shaft, $i_{sc}$ and $η_{sc}$ the speed ratio and the efficiency of the silent chain, $J_{G 1}$ the moment of inertia of the primary reduction shaft, and ${\overset{\cdot\cdot}{θ}}_{G 1}$ its angular acceleration.

Secondary shaft

i_{G} η_{G} T_{G 2} - J_{G 2} {\overset{\cdot\cdot}{θ}}_{G 2} - T_{D} = 0

(8)

$T_{D}$ is the differential ring torque reflected to the secondary shaft, $i_{G}$ and $η_{G}$ the gear ratio and the efficiency of the gear pair, $J_{G 2}$ the moment of inertia of the secondary reduction shaft, and ${\overset{\cdot\cdot}{θ}}_{G 2}$ its angular acceleration.

Differential

i_{D} η_{D} T_{D} - J_{D} {\overset{\cdot\cdot}{θ}}_{D} - [k_{hs} (θ_{D} - θ_{w}) + β_{hs} ({\overset{\cdot}{θ}}_{D} - {\overset{\cdot}{θ}}_{w})] = 0

(9)

$i_{D}$ and $η_{D}$ are the gear ratio and the efficiency of the last reduction gear before differential, $J_{D}$ the moment of inertia of the differential and ${\overset{\cdot\cdot}{θ}}_{D}$ its angular acceleration, $k_{hs} = k_{hs, L} + k_{hs, R}$ and $β_{hs} = β_{hs, L} + β_{hs, R}$ are the torsional stiffness and damping of the half-shafts, and ${\overset{\cdot}{θ}}_{w}$ is the wheel angular speed. Note that, under the assumption of symmetry of the two half-shafts and wheels, the two transmission paths have the same mechanical behavior, hence can be modeled as an equivalent system with double stiffness, damping, and inertia.

Driving wheels (front axle)

[k_{hs} (θ_{D} - θ_{w}) + β_{hs} ({\overset{\cdot}{θ}}_{D} - {\overset{\cdot}{θ}}_{w})] - T_{t} - J_{w} {\overset{\cdot\cdot}{θ}}_{w} - T_{roll, f} = 0

(10)

$T_{t}$ is the effective wheel torque (two wheels) due to tire-road interaction, $T_{roll, f} = T_{roll, L} + T_{roll, R}$ is the rolling resistance torque of the front tires, and $J_{w} = J_{w, L} + J_{w, R}$ the moment of inertia of the front wheels.

Tire model

The linearization of the tires longitudinal force versus slip steady-state characteristic,¹¹ valid for low slip values, leads to an equivalent viscous damper with viscous friction coefficient $β_{t}$ placed between the wheels and the equivalent inertia of the vehicle,⁹ for further details

T_{t, ss} = β_{t} ({\overset{\cdot}{θ}}_{w} - {\overset{\cdot}{θ}}_{v})

(11)

β_{t} = \frac{C_{s} R_{w}}{{\overset{\cdot}{θ}}_{w 0}}

(12)

where $R_{w}$ is the wheel radius, ${\overset{\cdot}{θ}}_{w 0}$ is the wheel speed value about which the tire longitudinal force has been linearized, and $C_{s}$ is the longitudinal slip stiffness of the driving axle, that is, twice the value of a single tire. Moreover, the tire transient behavior is modeled introducing the longitudinal relaxation length L_x, resulting in a first-order system with time constant $τ_{t} = L_{x} / v$

{\overset{\cdot}{T}}_{t} = \frac{1}{τ_{t}} (T_{t, ss} - T_{t}) = \frac{β_{t}}{τ_{t}} {\overset{\cdot}{θ}}_{w} - \frac{β_{t}}{τ_{t}} {\overset{\cdot}{θ}}_{v} - \frac{1}{τ_{t}} T_{t}

(13)

where $T_{t, ss}$ is the steady-state wheel torque due to tire-road interaction, ${\overset{\cdot}{θ}}_{v} = v / R_{w}$ is the vehicle equivalent angular speed, and $v$ the vehicle longitudinal speed.

Vehicle

The dynamic balance of the vehicle longitudinal motion reflected to the front wheels axis gives

T_{t} - (R_{w}^{2} M_{v} + J_{w, r}) {\overset{\cdot\cdot}{θ}}_{v} = T_{roll, r} + R_{w} F_{aer}

(14)

where $T_{roll, r}$ is the rolling resistance torque of the rear wheels, $F_{aer}$ is the aerodynamic resistance of the vehicle, $M_{v}$ is the vehicle mass, $J_{w, r}$ the moment of inertia of the rear wheels.

Since the rear wheels are not driven, their behavior can be described using a simplified pure rolling model, that is

{\overset{\cdot}{θ}}_{w, r} = {\overset{\cdot}{θ}}_{v} = v / R_{w}

(15)

Since both rolling and aerodynamic resistances are nonlinear functions of the state variables, they need to be linearized as clarified later in a specific section.

EGS

Considering a unitary efficiency and neglecting the inertia of the inner components of the gear set, the following torque equations hold

T_{s / g} = \frac{R_{s}}{R_{r} + R_{s}} T_{c}

(16)

T_{r / m} = \frac{R_{r}}{R_{s} + R_{r}} T_{c}

(17)

where subscripts s, r, and c represent sun gear, ring gear, and planet carrier of the planetary gear set, respectively. R is the pitch radius of the gears. See Velardocchia et al.¹² and Galvagno¹³ for mathematical models of epicyclical gears including also mesh efficiency, bearings/seals losses, and inertial effects.

The gear train kinematic equation is

{\overset{\cdot}{θ}}_{c} = \frac{{\overset{\cdot}{θ}}_{s} R_{s} + {\overset{\cdot}{θ}}_{r} R_{r}}{R_{s} + R_{r}}

(18)

Since the generator is connected to the sun gear, the electric motor to the ring gear, and the carrier to the engine through the torsional damper, the former equation can be rewritten as follows under steady-state condition

{\overset{\cdot}{θ}}_{e} = \frac{{\overset{\cdot}{θ}}_{g} R_{s} + {\overset{\cdot}{θ}}_{m} R_{r}}{R_{s} + R_{r}}

(19)

From this kinematic equation, the possibility to control the engine speed through the electric generator becomes evident. The engine speed is a weighted mean of the generator and the motor/vehicle speed where the weights are functions of the gears radii. The parameter $i_{eg} = R_{r} / R_{s}$ , the EGS ratio, will be used in the following.

Linearization of the external forces

Rolling resistance is generally modeled as a quadratic function of the wheel speed and aerodynamic force as a quadratic function of the vehicle speed. A constant weight distribution between front and rear axle is considered, hence the longitudinal load transfer is neglected. The linearization of these functions gives

{\begin{matrix} T_{roll, r} = \frac{a}{L} R_{w} M_{v} g (f_{0} + K {\overset{\cdot}{θ}}_{w, r}^{2} R_{w}^{2}) \approx c_{0 r, r} + c_{1 r, r} {\overset{\cdot}{θ}}_{v} \\ T_{roll, f} = \frac{b}{L} R_{w} M_{v} g (f_{0} + K {\overset{\cdot}{θ}}_{w, f}^{2} R_{w}^{2}) \approx c_{0 r, f} + c_{1 r, f} {\overset{\cdot}{θ}}_{w} \\ F_{aer} = \frac{1}{2} ρ S_{v} C_{d} {\overset{\cdot}{θ}}_{v}^{2} R_{w}^{3} \approx c_{0 a} + c_{1 a} {\overset{\cdot}{θ}}_{v} \end{matrix}

(20)

where $a$ and $b$ are the distances from the vehicle center of mass to the front and rear wheels, $L$ the wheelbase, $f_{0}$ and $K$ are rolling resistance constant and quadratic coefficients, $ρ$ is the air density, $S_{v}$ the vehicle frontal area, and $C_{d}$ is the aerodynamic drag coefficient.

The expressions of the constants of linearization are reported in Appendix 1.

The linearization process of the system nonlinearities leads to different parameter values and consequently different system response for different vehicle speed as will be discussed in the “Simulation results” section.

State-space model of the uncontrolled system

The continuous time-invariant state-space representation of the uncontrolled mechanical system, that is, considering as input the torque requests to the three actuators, is

{\overset{\cdot}{z}} = \underset{14 x 14}{\underset{︸}{[A]}} {z} + \underset{14 x 3}{\underset{︸}{[B]}} {u} + \underset{14 x 1}{\underset{︸}{{H}}}

(21)

where the state vector ${z}$ includes the angular speeds and positions of the selected degrees of freedom of the system, the torque generated by the actuators and by the front tires

{z} = {{\overset{\cdot}{θ}}_{e}, {\overset{\cdot}{θ}}_{g}, {\overset{\cdot}{θ}}_{m}, {\overset{\cdot}{θ}}_{w}, {\overset{\cdot}{θ}}_{v}, θ_{e}, θ_{g}, θ_{m}, θ_{w}, θ_{v}, T_{e}, T_{g}, T_{m}, T_{t}}^{T}

(22)

The input vector ${u}$ contains the desired torque of engine, generator, and motor

{u} = {T_{de}, T_{dg}, T_{dm}}^{T}

(23)

The dynamic matrix $[A]$ , the input matrix $[B]$ , and the constant matrix $[H]$ , expressed in terms of the system parameters, are reported in Appendix 1.

Generator speed controller

Different from more traditional mechanical transmissions, for example, MT, AT, and DCT, an EVT does not represent a mechanical constraint for the speed ratio between engine and wheels. The generator accomplishes this specific objective: by controlling its shaft speed, it varies the ratio between the transmission input and output speeds. Moreover, it is of interest noting that while the speed ratio of the EVT can be continuously adjusted through the generator control, the torque ratio is constant and dependent on the mechanical parameters of the system.

In order to study the dynamic behavior of an EVT-equipped vehicle, it is therefore necessary to consider also the generator speed controller

T_{dg} = T_{ff} + T_{fb} = - \frac{T_{de}}{1 + i_{eg}} + K_{p} ({\overset{\cdot}{θ}}_{g, ref} - {\overset{\cdot}{θ}}_{g})

(24)

The generator torque demand $T_{g}$ can be generally expressed as the sum of a feed-forward term $T_{ff}$ , which is the steady-state solution of the nominal plant, and a feed-back term $T_{fb}$ , which attempts to minimize the error over the time between the target generator speed ${\overset{\cdot}{ϑ}}_{g, ref}$ and the actual generator speed ${\overset{\cdot}{ϑ}}_{g}$ . In this article, a pure proportional speed controlled is considered, and $K_{p}$ is the proportional gain.

Introducing a target overall speed ratio $i^{★}$ between the engine and the wheels and recalling that the speed of the driving wheels is proportional to the motor speed in steady-state conditions, the target speed ratio $ζ$ between engine and motor can be found

\frac{{\overset{\cdot}{θ}}_{e}}{{\overset{\cdot}{θ}}_{w}} = i^{★}; \frac{{\overset{\cdot}{θ}}_{e}}{{\overset{\cdot}{θ}}_{m}} = \frac{i^{★}}{i_{sc} i_{G} i_{D}} = ζ

(25)

The target ratio $ζ$ is an output of the energy management controller: in fact, the aim is to keep the engine operation point at the best possible efficiency during all operating conditions. The generator continuously adjusts the engine speed so that the engine can work on its optimal operation line.

The equation for calculating the generator speed set point ${\overset{\cdot}{θ}}_{g, ref}$ , for a given motor speed ${\overset{\cdot}{θ}}_{m}$ and a desired speed ratio $ζ$ is derived by inserting equation (25) into equation (19)

{\overset{\cdot}{θ}}_{g, ref} = {\overset{\cdot}{θ}}_{m} [ζ (1 + i_{eg}) - i_{eg}]

(26)

The engine speed and the electric motors speeds are available measures that are used as known quantities by the control system.

Hence, the reference speed for the generator can be easily computed and introduced in equation (24) to obtain the generator torque as a function of inputs and states

T_{dg} = - K_{p} {\overset{\cdot}{ϑ}}_{g} + K_{p} [ζ (1 + i_{eg}) - i_{eg}] {\overset{\cdot}{ϑ}}_{m} - \frac{1}{1 + i_{eg}} T_{de}

(27)

Inserting the former equation in equation (3), a new equation for the state space becomes available. Hence, $T_{dg}$ does not enter as an input in the state-space model anymore, but its value is automatically computed through equation (27) starting from the engine torque command $T_{de}$ , the speeds ${\overset{\cdot}{ϑ}}_{m}$ and ${\overset{\cdot}{ϑ}}_{g}$ of the electric machines, and the desired speed ratio $ζ$ .

Therefore, the state-space formulation of the controlled mechanical system has a reduced number of inputs, that are the torque demand for the engine and the electric motor, while the target speed ratio enters as a parameter in the dynamic matrix $[A_{C}]$ , in formulas

{\overset{\cdot}{z}} = \underset{14 x 14}{\underset{︸}{[A_{C} (ζ)]}} {z} + \underset{14 x 2}{\underset{︸}{[B_{C}]}} {\begin{matrix} T_{e} \\ T_{m} \end{matrix}} + \underset{14 x 1}{\underset{︸}{{H}}}

(28)

Powertrain torque control

Since the aim of this research is to investigate the “passive” dynamic behavior of an EVT-equipped vehicle, that is, in absence of drivability control, we assume to proportionally distribute the total effort requested at the wheels according to the energy management control strategy requirements. A simple gain between the desired engine torque and the desired electric motor torque is imposed, that is

T_{dm} (t) = k T_{de} (t)

(29)

It must be noted that a dynamic correction G(s) could be designed in order to tune the desired drivability performance of the vehicle, that is, $T_{m} = G (s) T_{e}$ ; this aspect goes beyond the main scope of the article.

At the same time, the generator exerts the reaction torque to the epicyclic gear train needed to enable the transfer of engine power to the wheels, according to its control logic explained in the former section.

In order to quantify the contribution to the vehicle propulsion of the engine and the electric motor, a parameter p is introduced. It represents the percentage of the total tractive torque, delivered at the drive wheels T_w by the engine in steady-state conditions.

The steady-state torque contributions of the actuators evaluated at the wheels can be easily obtained starting from the dynamic equations

T_{dw} = (T_{dm} + T_{de} \frac{i_{eg}}{1 + i_{eg}}) i_{sc} η_{sc}

(30)

Dividing equation (30) by $T_{dw}$ and introducing the percentage of utilization of the ICE p, it yields

1 = i_{sc} η_{sc} \frac{T_{dm}}{T_{dw}} + \frac{i_{sc} η_{sc} i_{eg}}{1 + i_{eg}} \frac{T_{de}}{T_{dw}} = (1 - p) + p

(31)

Isolating the engine and electric motor terms

\begin{matrix} {\begin{matrix} \frac{\bar{T_{de}}}{T_{dw}} = \frac{i_{sc} η_{sc} i_{eg}}{1 + i_{eg}} \frac{T_{de}}{T_{dw}} = p \\ \frac{\bar{T_{dm}}}{T_{dw}} = i_{sc} η_{sc} \frac{T_{dm}}{T_{dw}} = 1 - p \end{matrix} \end{matrix}

(32)

Consequently, if p = 1 the vehicle utilizes only the engine (and the generator) torque to propel the vehicle, whereas if p = 0 the vehicle is running in pure electric mode.

Finally, the following equations can be used to evaluate the engine torque demand and the electric motor torque demand from a given desired wheel torque and percentage of utilization p

{\begin{matrix} \frac{T_{de}}{T_{dw}} = \frac{1 + i_{eg}}{i_{sc} η_{sc} i_{eg}} p \\ k = \frac{T_{dm}}{T_{de}} = \frac{i_{eg} (1 - p)}{(1 + i_{eg}) p} \end{matrix}

(33)

Frequency response function for drivability assessment

Vehicle longitudinal acceleration is one of the most important quantities that is commonly used for the evaluation of the drivability of a vehicle because it can be strictly correlated to both comfort and sportiness perceived by the passengers of a car.

As it has been done for the drivability assessment of other HEV architectures,⁹ a transfer function to characterize the drivability performance of the EVT-equipped vehicle must be carefully chosen. It correlates the torque total request at the wheels, coming from the driver, to the actual response of the vehicle, in terms of longitudinal acceleration.

Since the system is over-actuated, this drivability transfer function cannot be derived immediately but requires some assumptions. A static torque split is applied also in this case, thus allowing to study the system response to synchronous harmonic excitations (same frequency and same phase) applied by the i.c. engine and the electric propulsion motor. The amplitude ratio between the two exciting torques is regulated by a torque distribution parameter.

From the mathematical point of view, the vehicle response to a driver request of acceleration can be evaluated starting from the transfer function between the wheel torque demand $T_{dw}$ and the vehicle acceleration $a_{x}$ , which can be easily computed from the state-space matrices

\frac{a_{x}}{T_{dw}} (s) = R_{w} s \frac{{\overset{\cdot}{ϑ}}_{V}}{T_{dw}} (s)

(34)

where $s$ is the Laplace variable.

Under the hypothesis of linear system and static torque split between the electric and thermal actuators, according to equation (33), the superposition principle can be applied, that is, the resulting FRF is the sum of the contributions of the two inputs

{\overset{\cdot}{ϑ}}_{V} (j ω) = \frac{{\overset{\cdot}{ϑ}}_{V}}{T_{de}} (j ω) \cdot T_{de} + \frac{{\overset{\cdot}{ϑ}}_{V}}{T_{dm}} (j ω) \cdot T_{dm}

(35)

Dividing by $T_{dw}$ and inserting equation (32) in it

\frac{{\overset{\cdot}{ϑ}}_{V} (j ω)}{T_{dw}} = \frac{1 + i_{eg}}{i_{sc} η_{sc} i_{eg}} p \cdot \frac{{\overset{\cdot}{ϑ}}_{V}}{T_{de}} (j ω) + \frac{1 - p}{i_{sc} η_{sc}} \cdot \frac{{\overset{\cdot}{ϑ}}_{V}}{T_{dm}} (j ω)

(36)

Introducing the former equation in equation (34) and rearranging to highlight the effect of the parameter p on the resulting FRF, we obtain

\frac{a_{x}}{T_{dw}} (j ω) = \frac{R_{w}}{i_{sc} η_{sc}} [\frac{1 + i_{eg}}{i_{eg}} \cdot \frac{{\overset{\cdot}{ϑ}}_{V}}{T_{de}} (j ω) \cdot p + \frac{{\overset{\cdot}{ϑ}}_{V}}{T_{dm}} (j ω) \cdot (1 - p)] j ω

(37)

Since we have considered a closed loop control of the generator speed directly implemented in the state-space model, the generator torque does not appear explicitly in the previous equation since its dynamic contribution is automatically included in the other two transfer functions. The calibration of the generator control plays an important role on the system dynamic performance as will be demonstrated in the “Simulation results” section.

Simulation results

In this section, the dynamic behavior of a vehicle equipped with an EVT is investigated through numerical simulation in both time and frequency domain.

The time domain simulated maneuver is a step change of the torques applied synchronously by the actuators. The engine torque demand changes from 0 to 100 N m at second 1 of the simulation and the percentage of distribution between the actuators is p = 50%.

The frequency domain analysis is focused on the acceleration response of the vehicle to in-phase harmonic excitations applied to the inputs.

In particular, the effects of the generator control calibration, the torque distribution between the electric motor and the i.c. engine, and the vehicle speed are analyzed in detail. Two plots for each sensitivity analysis are shown: the first is obtained considering low vehicle speed (30 km/h), for example, driving in city traffic, the second considering high speed (130 km/h), for example, driving on highways.

Effect of generator speed control

As already mentioned in the generator control section, a proportional speed controller is assumed. Figures 2 and 3 show the effect of the proportional gain on the FRF expressed by equation (37) and imposing p = 50%.

Figure 2.

Frequency response function $a_{x} / T_{dw}$ at a vehicle speed of 30 km/h: effect of the proportional gain of the generator speed controller with ζ = 1,9.

Figure 3.

Frequency response function $a_{x} / T_{w}$ at a vehicle speed of 130 km/h: effect of the proportional gain of the generator speed controller with ζ = 0,85.

Looking at Figure 2, the effect of the proportional gain can be summarized as follows:

For low $K_{p}$ values, that is, from 0 to 0.8, increasing the proportional gain increases the damping of the first peak of the FRF and shifts this peak to lower frequencies.

For high $K_{p}$ values, that is, from 0.8 to 100, on the contrary, increasing the proportional gain provokes an increase in the amplitude of this peak. The peak frequency slightly reduces if the gain increases. Moreover, increasing the proportional gain reduces the operating bandwidth of the controlled system.

Figure 3 shows the same FRFs but evaluated for a higher initial vehicle speed, that is, 130 km/h. The change occurred in the parameters values, due to system nonlinearities, led to FRF magnitude that is much lower than the previous case in the whole frequency range. The increased damping is mainly due to a reduction of the viscous friction coefficient of front tires β_t, which allows more tire slip and so a greater amount of vibrational energy dissipation. Moreover, the damping due to aerodynamic and rolling resistances increases quadratically with the vehicle speed; although these last damping parameters related to motion resistance are much higher in the high speed case, their quantitative effect is more limited if compared with tire damping. Same considerations done for the low speed maneuver, concerning the effect of K_p also apply to this case.

Comparing the results in the frequency domain, it can be noted that K_p = 0.8 gives very good dynamic performance, since it allows minimizing the H-infinity norm of the FRF, that is, its maximum magnitude over the considered frequency range, in both the low and high speed maneuvers. This parameter setting ensures high operating bandwidth with fast transient oscillation damping.

Figures 4 –6 show the effect of the proportional gain on the time history of the vehicle acceleration and of the actual speed ratio during Tip-In. The test specifications are step change from 0 to 100 N m of the engine torque demand and constant torque distribution p = 50%.

Figure 4.

Vehicle acceleration (on the left) and actual speed ratio (on the right) during a Tip-In test at 30 km/h with p = 50%: effect of the proportional gain of the generator speed controller.

Figure 5.

Vehicle acceleration (on the left) and actual speed ratio (on the right) during a Tip-In test at 130 km/h with p = 50%: effect of the proportional gain of the generator speed controller.

Figure 6.

Actual speed ratio versus time during Tip-In tests carried out at different vehicle speed while keeping the same calibration of the generator speed controller, ζ = 0,85.

Also from this point of view, evidently the optimal system response is obtained using an intermediate value of the proportional gain, that is, 0.8. In fact, both higher and lower values lead to higher overshoot, undershoot, and settling time of the vehicle acceleration, therefore worsening the system dynamic performance. In addition, looking at the speed ratio versus time plot, it can be noted that the tracking and disturbance rejection performance of the speed ratio controller is optimized for this gain choice. Comparing Figure 4 with Figure 5, it can be observed that the considered Tip-In maneuver is less critical at high cruising speed, because once again the higher the vehicle speed the higher the damping effect due to tire slip and motion resistance on the system dynamics.

Figure 6 depicts the instantaneous speed ratio computed during four tip-in tests, each carried out at a different vehicle speed (20, 50, 80, 110 km/h). From this graph, the effect of the vehicle speed on the performance of the generator controller (with constant calibration $K_{p} = 0.8$ ) can be assessed. In particular, the control is less effective at low speed, while it becomes progressively more insensitive to the disturbances introduced by the torque steps with increasing velocity. The steady-state error, which becomes evident at low speeds, could be eliminated adding an integral term in the generator feedback controller.

Effect of the torque distribution between the actuators

The effect of the torque distribution between the thermal and the electric actuators on the FRF is shown in the upper part of Figure 7 for low speed and in the lower part for high speed.

Figure 7.

FRFs $a_{x} / T_{w}$ at a vehicle speed of 30 km/h (top) and 130 km/h (bottom): effect of the torque distribution between the actuators.

At low speed, two resonance peaks are clearly visible in the FRFs. The frequency and damping of the first peak is quite insensitive to the variation of the parameter p, while the damping of the second mode increases substantially by increasing the engine torque contribution. The fully electric operating mode shows a more critical dynamic behavior with respect to the pure thermal mode due to a loosely damped second vibration mode.

At high speed, see the lower part of Figure 7, only the peak associated with the lowest torsional mode of the system can be seen. The second mode is highly damped and cannot be directly identified from this specific FRF, while the first mode gives origin to a peak whose magnitude slightly decreases as p decreases. Hence, contrarily to what happens at low vehicle speed, the increase in the electric motor contribution improves the dynamic response of the vehicle.

Conclusion

In this article, a dynamic analysis of an EVT-equipped powertrain is presented. After deriving the dynamic equations in the state-space form for both open- and closed-loop systems, a methodology for objectively evaluating the drivability of this overactuated system has been proposed. A synchronous excitation from the engine and the electric propulsion motor is assumed, while the generator torque is the output of a feedback controller aiming at keeping constant the speed ratio between the engine and transmission output shaft.

The dynamic system behavior, investigated through numerical simulation in both time and frequency domains, has some interesting features that can be summarized as follows:

The calibration of generator speed controller plays an essential role in the definition of the dynamic system response, especially during low-speed maneuvers. As an example, it has been shown that the optimal selection of the proportional gain of the feedback controller ensures high operating bandwidth with fast transient oscillation damping.

At high vehicle speeds, a greater damping of the system is observed. This in general leads to a more damped drivability FRF and therefore to less vibration issues.

The generator speed control is less effective at low speed, while it becomes progressively more insensitive to the disturbances introduced by the torque steps of the other actuators with increasing velocity.

The effect of the electric motor torque contribution is different depending on the vehicle speed range. At low speed, the fully electric operating mode shows a more critical dynamic behavior with respect to the pure thermal mode due to the presence of a loosely damped second vibration mode. Conversely, at high speed, the increase in the electric motor contribution improves the dynamic response of the vehicle; a flatter passband is obtained together with a higher bandwidth.

Footnotes

Appendix 1

Linearization constant expressions

c_{0 r, r} = \frac{R_{w} a M_{v} g}{L} (f_{0} - {KR}_{w}^{2} {\overset{\cdot}{θ}}_{w 0, r}^{2}) = \frac{R_{w} a M_{v} g}{L} (f_{0} - {KR}_{w}^{2} {\overset{\cdot}{θ}}_{v 0}^{2})

c_{1 r, r} = \frac{R_{w} a M_{v}}{L} (2 {KR}_{w}^{2} {\overset{\cdot}{θ}}_{w 0, r}) = \frac{R_{w} a M_{v} g}{L} (2 {KR}_{w}^{2} {\overset{\cdot}{θ}}_{v 0})

c_{0 r, f} = \frac{R_{w} b M_{v} g}{L} (f_{0} - {KR}_{w}^{2} {\overset{\cdot}{θ}}_{w 0, f}^{2}) = \frac{R_{w} b M_{v} g}{L} (f_{0} - {KR}_{w}^{2} {\overset{\cdot}{θ}}_{w 0}^{2})

c_{1 r, f} = \frac{R_{w} b M_{v} g}{L} (2 {KR}_{w}^{2} {\overset{\cdot}{θ}}_{w 0, f}) = \frac{R_{w} b M_{v} g}{L} (2 {KR}_{w}^{2} {\overset{\cdot}{θ}}_{w 0})

c_{0 a} = - \frac{1}{2} ρ S_{v} C_{d} {\overset{\cdot}{θ}}_{v 0}^{2} R_{w}^{2}

c_{1 a} = ρ S_{v} C_{d} {\overset{\cdot}{θ}}_{v 0} R_{w}^{2}

Handling Editor: Ling Zheng

Declaration of conflicting interests

The author(s) declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.

Funding

The author(s) received no financial support for the research, authorship, and/or publication of this article.

ORCID iD

Enrico Galvagno

References

Opila

Wang

McGee

et al . An energy management controller to optimally trade off fuel economy and drivability for hybrid vehicles. IEEE T Contr Syst T 2012; 20: 1490–1505.

Vinot

Reinbold

Trigui

. Global optimized design of an electric variable transmission for HEVs. IEEE T Veh Technol 2016; 65: 6794–6798.

Kessels

JTBA

Foster

van den Bosch

PPJ

. Integrated powertrain control for hybrid electric vehicles with electric variable transmission. In: Proceedings of the IEEE vehicle power and propulsion conference, Dearborn, MI, 7–10 September 2009, pp.376–381. New York: IEEE.

Johri

Filipi

. Optimal energy management of a series hybrid vehicle with combined fuel economy and low-emission objectives. Proc IMechE, Part D: J Automobile Engineering 2014; 228: 1424–1439.

Dorri

Shamekhi

. Design and optimization of a new control strategy in a parallel hybrid electric vehicle in order to improve fuel economy. Proc IMechE, Part D: J Automobile Engineering 2017; 225: 747–759.

Delkhosh

Foumani

Azad

et al . A new control strategy for hybrid electric vehicles equipped with a continuously variable transmission. Proc IMechE, Part D: J Automobile Engineering 2015; 230: 803–816.

Taylor

Katariya

. Dynamic modeling and feedback control of a two-mode electrically variable transmission. In: Proceedings of the IEEE international electric vehicle conference, Greenville, SC, 4–8 March 2012, pp.1–7. New York: IEEE.

Chen

Zhu

Zhang

et al . Design and analysis of an electrical variable transmission for a series–parallel hybrid electric vehicle. IEEE T Veh Technol 2011; 60: 2354–2363.

Galvagno

Morina

Sorniotti

et al . Drivability analysis of through-the-road-parallel hybrid vehicles. Meccanica 2013; 48: 351–366.

10.

Koprubasi

Westervelt

Rizzoni

et al . Experimental validation of a model for the control of drivability in a hybrid-electric vehicle. In: Proceedings of the ASME international mechanical engineering congress and exposition, Seattle, WA, 11–15 November 2007, pp.105–114. New York: ASME.

11.

Pacejka

. Tyre and vehicle dynamics. Stoneham, MA: Butterworth, 2006.

12.

Velardocchia

Bonisoli

Galvagno

et al . Efficiency of epicyclic gears in automated manual transmission systems. In: Proceedings of the 8th international conference on engines for automobiles, Capri, 16–20 September 2007. Warrendale: SAE International.

13.

Galvagno

. Epicyclic gear train dynamics including mesh efficiency. Int J Mech Control 2010; 11: 41–47.
