Trajectory tracking control for chain-series robot manipulator: Robust adaptive fuzzy terminal sliding mode control with low-pass filter

Abstract

This article investigates a difficult problem which focuses on the external disturbance and dynamic uncertainty in the process of trajectory tracking. This article presents a robust adaptive fuzzy terminal sliding mode controller with low-pass filter. The low-pass filter can provide smooth position and speed signals. The fuzzy terminal sliding mode controller can achieve fast convergence and desirable tracking precision. Chattering is eliminated with continuous control law, due to high-frequency switching terms contained in the first derivative of actual control signals. Ignoring the prior knowledge upper bound, the controller can reduce the influence of the uncertain kinematics and dynamics in the actual situation. Finally, the experiment is carried out and the results show the performance of the proposed controller.

Keywords

Robot fuzzy terminal sliding mode control low-pass filter dynamics uncertainty trajectory tracking

Introduction

Robot is a nonlinear and uncertain system. The controllers are intend to enable the manipulator to track the desired trajectory with ideal dynamic quality or at a specified position.^1

–6 The uncertainty of robot parameters and the existence of nonparametric uncertainty factors lead to the change and instability of the system.^7

–11 It is well known that the nonlinearity and uncertainty in the robot dynamic control, such as friction, external disturbance, and variable load, will reduce the robustness.

However, the main methods for the robust control are sliding mode control, fuzzy control, and other intelligent controllers. Recently, the combination of fuzzy control and sliding mode control has become the focus of current research. Sliding mode control has been widely used in application.^12
–14 Fuzzy sliding mode control can reduce the fuzzy rules in fuzzy control and reduce the chattering of sliding mode control. The chattering of sliding mode control under the condition of uncertainty and disturbance in robot dynamics model is described in the literature.^{2,8,15

–20} In Zheng and Liang,²¹ a fuzzy adaptive method is described on a 3-degree of freedom (DOF) planar robot. Due to the nonlinear and uncertain problems existing in the motion process of planar robot, an adaptive fuzzy sliding mode control method based on PID sliding die surface is proposed. The output gain fuzzy sliding mode is controlled, the chattering phenomenon is avoided, and the simulation verification is carried out. The validity of this method is verified. In Rezoug et al.,²² the control method combining fuzzy sliding mode control and dynamic control method is applied to the differential wheeled robot, and the simulation and experimental research are carried out to verify the proposed controller. In Matraji et al.,²³ an adaptive second-order sliding mode controller is introduced, a robust controller for ignoring disturbance is established. An adaptive hyper-torsion algorithm is designed, and the experimental results show that the proposed controller can accomplish the predetermined trajectory well.

The adaptive terminal sliding mode control strategy is also appearing in robotic field, especially in the dynamic control. In Riani et al.,²⁴ the terminal sliding mode control has also been deeply discussed, unlike the traditional sliding mode variable structure control. The terminal sliding mode controller has a nonlinear sliding mold surface. However, the tracking error of the system can have faster convergence speed compared with the traditional sliding mode control.^25

–30 In Wang et al.,³¹ in order to ensure the good control performance of cable-driven manipulator in complex uncertainty environment, a new continuous fractional order non-singular terminal sliding mode control scheme is proposed, which does not depend on model and system dynamics, and has high practical value. In Asl et al.,³² based on the principle of non-singular terminal sliding mode control, a new control law is established, a kind of non-trace Kalman filter is proposed for robot manipulator, which can withstand the uncertainty of external disturbance and noise, and the simulation verification is carried out on 6-DOF manipulator.

Considering the disturbance and dynamic uncertainty in the trajectory tracking, the robustness of the dynamic controller is discussed and a new controller is proposed. This article is organized as follows: firstly, the dynamic parameter equation of the robot is deduced under the condition of disturbance and dynamic uncertainty. In the second part, a fuzzy terminal sliding mode controller based on low-pass filtering is designed in this article, which can guarantee the fast convergence of the trajectory tracking and its stability is proved by Lyapunov stability theorem. In the third part, the validity and practicability of the proposed controller are verified by MATLAB simulation and physical experiment. In the fourth part, the experimental results show the performance of the proposed controller and compared with the PID controller. Finally, the results are discussed and the robustness of the proposed controller is conducted.

System model and objectives

Trajectory of the robot manipulator

x = h (q)

where $x \in R^{n}$ is the position vector in the robot task space, $q \in R^{n}$ is the joint angle vector in the joint space, and $h (q) \in R^{n} \to R^{n}$ represents a transformation matrix between workspace and joint space. The connection between the speed vector of the manipulator and the joint speed vector is as follows

\dot{x} = J (q) \dot{q}

Among them, $J (q) \in R^{n \times n}$ is the Jacobian matrix of task space to joint space. The robot dynamics equation can be expressed as

M_{0} (q) \ddot{q} + D_{0} (q, \dot{q}) = τ

Without considering friction and uncertainty, the kinetic equation of robot is established by Lagrange method for an n-DOF series arm with strong moment action on each joint (22):

$M_{0} (q)$ : bounded and positive definite inertial matrix, $M_{0} (q) \subset R^{m \times n}$ ;

$q, \dot{q}, \ddot{q}$ : n-dimensional position, velocity, and acceleration vector;

$u (t)$ : the input vector

D_{0} (q, \dot{q}) = C_{0} (q, \dot{q}) \dot{q} + G_{0} (q)

$C_{0} (q, \dot{q})$ : Coriolis force and centripetal forces, $C_{0} (q, \dot{q}) \in R^{m \times n}$ : dimensional gravity.

Therefore, the task space trajectory in the process of robot trajectory tracking can be described as x_d , the joint input torque τ is used to achieve the appropriate tracking of the task space trajectory, and ensure the stability and effectiveness of the entire tracking process.

In practical application, due to the existence of a large number of uncertainties, it is difficult to obtain the robot dynamics model as shown in formula (3); if these uncertainties are fully taken into account, then the following complete kinetic model is obtained (1)

M (q) \ddot{q} + C (q, \dot{q}) \dot{q} + G (q) + F (\dot{q}) + τ_{d} = τ

In the formula (5), $F (\dot{q})$ is friction, $τ_{d}$ is unknown disturbance, τ is controlled input, because of the uncertainty of the robotic arm, $M (q)$ , $C (q, \dot{q})$ , $G (q)$ is a real-time variable, it can be decomposed into two parts, part of the known part $M_{0} (q)$ , $C_{0} (q, \dot{q})$ , $G_{0} (q)$ , the other part is the indeterminate part, $Δ M (q)$ , $Δ C (q, \dot{q})$ , $Δ G (q)$ that is

\{\begin{matrix} M (q) = M_{0} (q) + Δ M (q) \\ C (q, \dot{q}) = C_{0} (q, \dot{q}) + Δ C (q, \dot{q}) \\ G (q) = G_{0} (q) + Δ G (q) \end{matrix}

When all the kinetic parameters are known, according to the kinematics equation (2)

\ddot{x} = J (q) \ddot{q} + \dot{J} (q) \dot{q}

The formulas (8) and (9) can be obtained by using formula (7), so that the relationship between the dynamic control law and the motion space can be obtained as follows

\ddot{q} = J^{- 1} (q) (\ddot{x} - \dot{J} (q) \dot{q})

τ = M (q) J^{- 1} (q) (\ddot{x} - j (q) \dot{q}) + H (q)

Low-pass filter and sliding mode controller design

For external disturbances and jitter generated by sliding mode controllers, the following low-pass filters are designed³³

Q (s) = \frac{λ}{s + λ}

where $λ > 0$ .

The ideal position instruction is $q_{d} (t)$ , and the tracking error is

e = q - q_{d}

{\dot{q}}_{r} = {\dot{q}}_{d} - \land e

where e, ${\dot{q}}_{r}$ represents the tracking error and the additional signal, where ∧ represents the normal matrix, and the sliding mode variable function can be designed as follows

s (t) = \ddot{e} + λ e

It can be obtained by formulas (5), (11), and (12)

M (q) \dot{s} = - V_{m} s + f (x) - τ_{d} + τ

\begin{matrix} f (x) = - M (q) {\ddot{q}}_{r} - V_{m} {\dot{q}}_{r} - F \dot{q} - f_{c} (\dot{q}) - G (q) \\ = M (q) ({\ddot{q}}_{d} - \land e) - V_{m} ({\dot{q}}_{d} - \land e) - F \dot{q} \\ - f_{c} (\dot{q}) - G (q) \end{matrix}

where $x = [\begin{array}{l} {\ddot{q}}_{d}^{T} & {\dot{q}}_{d}^{T} & q_{d}^{T} & {\dot{q}}^{T} & q^{T}]^{T} \end{array}$ .

The first and second items in the equation (14) help to improve closed-loop stability and transient performance, and more importantly, they help compensate for tracking errors caused by kinematics and dynamic uncertainties. The last term in equation (14) guarantees the existence of the sliding mode to improve the robustness of the robot system, especially when the system reaches the sliding surface, the robot system is absolutely robust to any disturbance. Considering the nonlinear manipulator, over the formula (9), the control law is designed as follows

τ = \hat{M} (q) {\hat{J}}^{- 1} (q) ({\ddot{x}}_{d} - \dot{\tilde{J}} (q) \dot{q} + \land \dot{e} + K_{V} s + K_{μ} sgn (s)) + \hat{H} (q, \dot{q})

The joint dynamics equation can be obtained by the formula (16) as follows

M (q) \ddot{q} + H (q, \dot{q}) = \hat{M} (q) {\hat{J}}^{- 1} (q) ({\ddot{x}}_{d} - \dot{\tilde{J}} (q) \dot{q} + \land \dot{e} + K_{V} s + K_{μ} sgn (s)) + \hat{H} (q, \dot{q})

Given the conditions for the dynamic uncertainty of the closed-loop system, the entire equation can be represented as shown in equation (18)

\hat{M} (q) \ddot{q} - \hat{M} (q) {\hat{J}}^{- 1} (q) ({\ddot{x}}_{d} - \dot{\hat{J}} (q) \dot{q} + K_{V} S + K_{μ} sgn (s)) = Y (q, \dot{q},) (\hat{p} - p) - Y (q, \dot{q}, \ddot{q}) Δ p

Among them, $Δ p = (p - \hat{p})$ is an estimate of the uncertainty of kinetic parameters.

Proof

Consider the following Lyapunov functions

V = \frac{1}{2} s^{T} s

It can be concluded

\begin{matrix} \dot{V} = s^{T} \dot{s} \\ = s^{T} (\ddot{e} + λ \dot{e}) \\ = s^{T} (f - K_{V} s - K_{μ} sgn (s)) \end{matrix}

Assuming $K_{μ} \geq | f |_{max}$ , it can be concluded

\dot{V} = s^{T} (f - K_{V} s - K_{μ} sgn (s)) \leq - s^{T} K_{V} s \leq 0

Therefore, the control law (16) can keep the control system on the sliding surface $s = 0$ of the and reach the state at the same time, $s \dot{s} \leq 0$ . Because of the “chattering” phenomenon caused by the discontinuity of the sliding mode control law, the stability and high frequency vibration of the equipment may be caused, in order to make up for this chattering, we use low-pass filter and fuzzy logic control to reduce the disturbance of this phenomenon to the system. The tracking error is defined as follows

e = q - q_{d}

where q is the joint position and q_d is the desired joint position. The terminal sliding surface is shown as follows

s = \dot{e} + α e^{q / p}

p and q are positive odd numbers and meet the condition $q < p < 2 q$ . The terminal sliding mode is defined as follows when $s = 0$

\dot{e} + α e^{q / p} = 0

Considering the following control input

u (e, t) = \{\begin{array}{l} u^{+} (e, t), i f s (e) > 0 \\ u^{-} (e, t), i f s (e) < 0 \end{array}

The sliding surface can be defined as

s = \dot{e} + λ e

where $λ = diag (λ_{1}, λ_{2}, λ_{3}, ...)$ and $λ_{i} (i = 1, 2, ..., n)$ is the normal number, and then the tracking error of the system quickly attenuates to zero. In terminal sliding mode control, the tracking error of the system can be described in the following form

\dot{e} = - α_{i} e_{i}^{q / p}, i = 1, ..., n

The solution of the equation (24) for a limited amount of time t_i can be given in the following form

t_{i} = - \int_{e_{i}}^{0} \frac{d e_{i}}{α_{i} e_{i}^{q / p}}

Among them, p and q satisfy the equation (23); then, t_i is the tracking error to reach zero after the terminal sliding mode is obtained. Speed errors is just as shown

s = \dot{e} + α e^{q / p} = \dot{q} - {\dot{q}}_{d} + α e^{q / p} = \dot{q} - \dot{q_{r}}

\dot{s} = \ddot{e} + α {(e^{q / p})}^{'} = \ddot{q} - \ddot{q_{d}} + α {(e^{q / p})}^{'} = \ddot{q} - {\ddot{q}}_{r}

where ${\dot{q}}_{r} = {\dot{q}}_{d} - α e^{q / p}, {\ddot{q}}_{r} = \ddot{q_{d}} - α {(e^{q / p})}^{'}$

${\ddot{q}}_{r}$ can be written in the following form

\begin{matrix} {\ddot{q}}_{r} = {\ddot{q}}_{d} - α \frac{d}{d t} (e^{q / p}) = {\ddot{q}}_{d} - \frac{q}{p} diag (α_{i} e_{i}^{(q - p) / p}) \times \dot{e} \\ = {\ddot{q}}_{d} + {[α_{1}^{2} \frac{q}{p} e_{1}^{(2 q - p) / p}, \dots α_{i}^{2} \frac{q}{p} e_{1}^{(2 q - p) / p} \dots α_{n}^{2} \frac{q}{p} e_{1}^{(2 q - p) / p}]}^{T} \end{matrix}

The vector ${\ddot{q}}_{r}$ must be bounded, when the tracking error e_i reaches 0 when the terminal sliding mode is controlled.

Applying formulas (29), (30) to (17), we can get

H \dot{s} = τ - H {\ddot{q}}_{r} - C s - C {\dot{q}}_{r} - G - T_{d}

We select the Lyapunov function

V = \frac{1}{2} s^{T} H s

After a differential

\dot{V} = s^{T} (τ - H {\ddot{q}}_{r} - C {\dot{q}}_{r} - G - T_{d})

Select control input

τ = - K sgn (s)

Bringing the equation (35) into the equation (34), we can get

\dot{V} = s^{T} [B - K sgn (s)] = \sum_{i = 1}^{n} s_{i} [B_{i} - K_{i i} sgn (s_{i})]

where $B = - H {\ddot{q}}_{r} - C {\dot{q}}_{r} - G - T_{d}$ .

When $s_{i} \neq 0$ and $e_{i} \neq 0$

From (22) and (27), if E and Ė are bounded, then B is bounded. Suppose, $|B_{i}| < {|B_{i}|}^{*}$ of which ${|B_{i}|}^{*}$ is on the upper border. If k is selected in the following way

K_{i i} > {|B_{i}|}^{*}

This ensures that the system tracking error converges quickly, and that $K_{i i}$ each should be selected large enough. When $s_{i} > 0$ from formula (20), we know

s_{i} [B_{i} - K_{i i} sgn (s_{i})] < 0

When $s_{i} < 0$ , from (36), it is known that $s_{i} [B_{i} - K_{i i} sgn (s_{i})] < 0$ , then $\dot{V} = \sum_{i = 1}^{n} s_{i} [B_{i} - K_{i i} sgn (s_{i})] < 0$

When $s_{i} \neq 0$ and $e_{i} = 0$

From (29), we can get

{\dot{q}}_{r} = {\dot{q}}_{d} - α e^{q / p} = {\dot{q}}_{d} - {[α_{1} e^{q / p}, \dots α_{i} e^{q / p} \dots α_{n} e^{q / p}]}^{T} = {\dot{q}}_{d} - {[α_{1} e^{q / p}, \dots, 0, \dots α_{n} e^{q / p}]}^{T}

where from (30), we can get

{\ddot{q}}_{r} = {\ddot{q}}_{d} - α \frac{d}{d t} (e^{q / p}) = {[{\ddot{q}}_{d 1} - \frac{q}{p} α_{1} e_{1}^{(q - p) / p} {\dot{e}}_{1}, \dots {\ddot{q}}_{d i} - \frac{q}{p} α_{i} e_{i}^{(q - p) / p} {\dot{e}}_{i} \dots {\ddot{q}}_{d n} - \frac{q}{p} α_{n} e_{n}^{(q - p) / p} {\dot{e}}_{n}]}^{T}

In this example, $s_{i} \neq 0$ and $e_{i} = 0$ , there are singular problems. In the literature,^29,34 a method is given to avoid singularity, and in the proposed method, singularity is avoided through the conversion of terminal sliding die surface and ordinary sliding surface. In this article, the singularity is avoided by converting a non-singular terminal sliding surface (5). The non-singular terminal sliding surface can be described as follows

S_{i} = {\dot{e}}_{i}^{p / q} + α e_{i}

where $a, p$ , and q are defined as formulas (23) and (27). After a differential of s_i , we may have to

{\dot{S}}_{l} = \frac{p}{q} {\dot{e}}_{i}^{(p - q) / p} * {\ddot{e}}_{i} + α {\dot{e}}_{i}

Remark 1

In this article, singularity can be avoided in the following ways

s_{i} = \{\begin{array}{l} {\dot{e}}_{i} + α e_{i}^{q / p}, & s_{i} = 0 or s_{i} \neq 0, |e_{i}| > ε \\ {\dot{e}}_{i} / p & s_{i} \neq 0, |e_{i}| \leq ε \end{array}

Choose $K_{i i} > {|B_{i}|}^{*}$ , then

\dot{V} = \sum_{i = 1}^{n} S_{i} [B_{i} - K_{i i} sgn (s_{i})] < 0

It is easy to verify that in the case of $s_{i} \neq 0$ , the terminal sliding mode state can meet the requirements well.

Multiple input and multiple output fast terminal sliding mode control for robotic manipulators

Although the above terminal sliding mode controller can drive the system tracking error converges to zero. For a limited amount of time, it has several drawbacks, like dynamic quality and “chatter” phenomenon. In order to enhance the dynamic quality and ensure the system tracking error converges to zero, each $K_{ii}$ must be selected. The new control input can be expressed as

τ = - T

And $T = {[T_{1}, \dots, T_{i} \dots T_{n}]}^{T}$ . Therefore, s_i similar to the selection process, the selection of T_i can be available from the following equations

\dot{V} = s^{T} [B - T] = \sum_{i = 1}^{n} s_{i} [B_{i} - T_{i}]

Fuzzy rules can be determined as follows.

By selecting weighted average de-fuzziness, the output of fuzzy inference system can be written

T_{i c} = \frac{\sum_{R = 1}^{M} θ_{i R} μ_{R} (s_{i})}{\sum_{R = 1}^{M} μ_{R} (s_{i})} = W_{i}^{T} θ_{i}

And M is the amount of rules, $θ_{i} = [θ_{i 1}, \dots θ_{i i} \dots θ_{i M}]$ is the constant parameters, and $W_{i}^{T} = {[w_{i 1}, \dots w_{i i}, \dots w_{i M}]}^{T}$ . Each of these variables $w_{i R}$ is defined by a fuzzy base function as follow

w_{i R} = \frac{μ_{R} (s_{i})}{\sum_{R = 1}^{M} μ_{R} (s_{i})}

The robotic operating system can be expressed as

T_{i} = \sum_{j = 1}^{n} f_{i j} \cdot T_{j c}

Fuzzy terminal sliding conditions can be met, so

|\sum_{j = 1}^{n} f_{i j} \cdot T_{j c}| > {|B_{i}|}^{*}

Then

\dot{V} = \sum_{i = 1}^{n} s_{i} [B_{i} - T_{i}] = \sum_{i = 1}^{n} s_{i} [B_{i} - \sum_{j = 1}^{n} f_{i j} \cdot T_{j c}] < 0

Therefore, the system tracking error is guaranteed to converge rapidly under the conditions of $s_{i} \neq 0$ , the MIMO FTSMC is shown in Figure 1.

Figure 1.

The structure of a MIMO FTSMC.

Multiple input and multiple output adaptive fast terminal sliding mode control for robotic manipulators

$T = f \cdot T_{c}$ is the chosen control law. With the output value ρs, where $ρ = diag [a_{1} + σ_{1}, \dots, a_{i} + σ_{i}, \dots a_{n} + σ_{n}]$ . The formula (49) brought into (17) formula can be obtained as follows

τ = - T - ρ s

Figure 2 show the fuzzy terminal sliding mode control based on the low-pass filter (LFFTSMC).

Figure 2.

Fuzzy terminal sliding mode control block diagram based on low-pass filter.

The output of adaptive fuzzy controller is $T = f \cdot T_{c}$ , in which T_c is the output of fuzzy inference system and f is the normalized factor of output variable. The output value of the compensator is ρs, where $ρ = diag [a_{1} + σ_{1}, \dots, a_{i} + σ_{i}, \dots a_{n} + σ_{n}]$ is the diagonal positive definite matrix, where a_i is the normal number and the $σ_{i}$ is positive. Formula (49) brought into (17) formula can be obtained

H \dot{s} = - C s + B - u - ρ s

With the optimal factor $f^{*}$ is defined as the following bound. Then, the error $ω_{i} > 0 (i = 1, 2, 3 \dots n)$ to guarantee

|B_{i} - \sum_{j = 1}^{n} f_{i j}^{*} \cdot T_{j c}| \leq w_{i} (1, \dots, n)

Defines the error of the normalized factor of the fuzzy output variable

{\tilde{f}}_{l j} = f_{i j} - f_{i j}^{*}

Then

\sum_{j = 1}^{n} f_{i j} \cdot T_{j c} = \sum_{j = 1}^{n} {\tilde{f}}_{l j} \cdot T_{j c} + \sum_{j = 1}^{n} f_{i j}^{*} \cdot T_{j c}

$σ_{i}^{*} |s_{i}|$ is the upper boundary and w_i is the optimization estimation error

w_{i} \leq σ_{i}^{*} |s_{i}| (i = 1, \dots, n)

Define

V = \frac{1}{2} (S^{T} H S) + \frac{1}{2} \sum_{i = 1}^{n} \sum_{j = 1}^{n} \frac{1}{2 γ_{i j}} {\tilde{f}}_{i j}^{2} + \sum_{i = 1}^{n} \frac{1}{2 η_{i}} {\tilde{σ}}_{i}^{2}

where H is a symmetrical positive definite matrix. ${\tilde{f}}_{i j}^{2}$ and ${\tilde{σ}}_{i}^{2}$ are normal numbers; therefore, V is positive

\begin{matrix} \dot{V} = \frac{1}{2} ({\dot{s}}^{T} H s + s^{T} \dot{H} s + s^{T} H \dot{s}) + \sum_{i = 1}^{n} \sum_{j = 1}^{n} \frac{1}{γ_{i j}} {\tilde{f}}_{i j} {\dot{\tilde{f}}}_{i j} + \sum_{i = 1}^{n} \frac{1}{η_{i}} {\tilde{σ}}_{i} {\dot{\tilde{σ}}}_{i} = s^{T} [H \dot{s} + c s] + \sum_{i = 1}^{n} \sum_{j = 1}^{n} \frac{1}{γ_{i j}} {\tilde{f}}_{i j} {\dot{\tilde{f}}}_{i j} + \sum_{i = 1}^{n} \frac{1}{η_{i}} {\tilde{σ}}_{i} {\dot{\tilde{σ}}}_{i} \\ = \sum_{i = 1}^{n} s_{i} [B_{i} - \sum_{j = 1}^{n} f_{i j} \cdot T_{j c} - α_{i} s_{i} - δ_{i} s_{i}] + \sum_{i = 1}^{n} \sum_{j = 1}^{n} \frac{1}{γ_{i j}} {\tilde{f}}_{i j} {\dot{\tilde{f}}}_{i j} + \sum_{i = 1}^{n} \frac{1}{η_{i}} {\tilde{σ}}_{i} {\dot{\tilde{σ}}}_{i} \end{matrix}

Due to $\sum_{j = 1}^{n} {\tilde{f}}_{i j} T_{j c} = \sum_{j = 1}^{n} f^{*}_{i j} T_{j c} + \sum_{j = 1}^{n} f_{i j} T_{j c}$ , then equation (56) can be as follows

\begin{matrix} \dot{V} = \sum_{i = 1}^{n} s_{i} [B_{i} - \sum_{j = 1}^{n} {\tilde{f}}_{i j} T_{j c} + \sum_{j = 1}^{n} f^{*}_{i j} T_{j c} - α_{i} s_{i} - s_{i} ({\tilde{σ}}_{i} + σ_{i}^{*})] + \sum_{i = 1}^{n} \sum_{j = 1}^{n} \frac{1}{γ_{i j}} {\tilde{f}}_{i j} {\dot{\tilde{f}}}_{i j} + \sum_{i = 1}^{n} \frac{1}{η_{i}} {\tilde{σ}}_{i} {\dot{\tilde{σ}}}_{i} \\ = \sum_{i = 1}^{n} - s_{i} α_{i} s_{i} + \sum_{i = 1}^{n} [s_{i} (B_{i} - \sum_{j = 1}^{n} f_{i j} \cdot T_{j c} - s_{i} σ_{i}^{*} s_{i})] + \sum_{i = 1}^{n} (\sum_{j = 1}^{n} \frac{1}{γ_{i j}} {\tilde{f}}_{i j} {\dot{\tilde{f}}}_{i j} - s_{i} \sum_{j = 1}^{n} {\tilde{f}}_{i j} \cdot T_{j c}) \\ + \sum_{i = 1}^{n} (\frac{1}{η_{i}} {\tilde{σ}}_{i} {\dot{\tilde{σ}}}_{i} - s_{i} {\tilde{σ}}_{i} s_{i}) \end{matrix}

Due to $s_{i} (B_{i} - \sum_{j = 1}^{n} f^{*}_{i j}) T_{j c} \leq |s_{i}| |B_{i} - \sum_{j = 1}^{n} f^{*}_{i j}| \leq |s_{i}| w_{i}$

\dot{V} \leq \sum_{i = 1}^{n} - s_{i} α_{i} s_{i} + \sum_{i = 1}^{n} (|s_{i}| w_{i} - s_{i} σ_{i}^{*} s_{i}) + \sum_{i = 1}^{n} \sum_{j = 1}^{n} \frac{1}{γ_{i j}} {\tilde{f}}_{i j} ({\dot{\tilde{f}}}_{i j} - s_{i} T_{j c}) + \sum_{i = 1}^{n} \tilde{σ} (\frac{1}{η_{i}} {\dot{\tilde{σ}}}_{i} - s_{i}^{2})

Owing to

w_{i} \leq σ_{i}^{*} |s_{i}|

Then $|s_{i}| w_{i} \leq σ_{i}^{*} |s_{i}| |s_{i}| = σ_{i}^{*} {|s_{i}|}^{2} = σ_{i}^{*} s_{i}^{2}$

\dot{V} \leq \sum_{i = 1}^{n} - S_{i} a_{i} s_{i} + \sum_{i = 1}^{n} \sum_{j = 1}^{n} {\tilde{f}}_{i j} (\frac{1}{γ_{i j}} {\dot{\tilde{f}}}_{i j} - s_{i} T_{j c}) + \sum_{i = 1}^{n} {\tilde{σ}}_{i} (\frac{1}{η_{i}} {\dot{σ}}_{i} - s_{i}^{2})

The adaptive law is

{\dot{f}}_{i j} = {\dot{\tilde{f}}}_{i j} = γ_{i j} s_{i} T_{j c}

{\dot{σ}}_{i} = {\dot{\tilde{σ}}}_{i} = η_{i} s_{i}^{2}

Then

\dot{V} \leq \sum_{i = 1}^{n} - s_{i} a_{i} s_{i} \leq 0

Since $a_{i} (i = 1, \dots, n)$ is a normal number, $\dot{V} < 0$ when $s \neq 0$ , then the controller combined with adaptive law can cause the tracking error of the system to converge to 0 in a limited amount of time, as $\dot{e} + α e^{q / p} \to 0$ .

When $t \to t^{'}$ , which $t^{'}$ represents any time. In other words, when $t \to t^{'}$ , $q \to q_{d}$ , $\dot{q} \to {\dot{q}}_{d}$ . Therefore, it is proved that the actual joint position achieves the desired trajectory in a limited time based on the low-pass filter MIMO adaptive fuzzy terminal sliding mode control input (50)

Simulation

In this part, the MATLAB2014 Toolbox is used to establish the robot model and carry out the simulation and the sampling time of the system is 0.005 s. The initial path used in the simulation is shown in the function (64)

\{\begin{matrix} x (t) = a \times sin (θ + 3 π {sin}^{3} (\frac{π t}{2 T})) t & \in [0, T] \\ y (t) = b \times cos (θ + 3 π {sin}^{3} (\frac{π t}{2 T}) t) & \in [0, T] \\ z (t) = 0 & t \in [0, T] \end{matrix}

Because of the uncertainty of robot dynamics model, the system model is applied to the parameter uncertainty matrix. In order to meet the stand, we choose the following stand: $\hat{M} = 0.95 * M$ , $\hat{C} = 0.95 * C$ , $\hat{G} = 0.95 * G$ . Adaptive fuzzy parameters are selected as α = π/12, σ = π/6. The external disturbance selects 6 + tan (πt) and the entire external disturbance is added in the direction of each other perpendicular to the robot manipulator.

The sampling grid time for the entire process is 0.005 s. As shown in Figure 3, after adding a filter, the LFFTSMC control approach can achieve better results than the other two controllers. More important, the whole tracking effect makes the tracking error reach the tracking effect of 0.2 mm. PID control method can be used to realize track tracking very well, but the whole process is not very good to achieve characteristics. The kinematics and dynamics parameters of the robot are shown in Tables 1 and 2.

Figure 3.

The trajectory tracking error in different controllers. (a) The errors of the three kinds of controllers are along the X-axis. (b) The errors of the three kinds of controllers are along the Y-axis. (c) The errors of the three kinds of controllers are along the Z-axis.

Table 1.

Robot mechanism parameters.

Link	a_i (mm)	α_i (°)	d_i (mm)	θ_i (°)
#1	0	90	0	θ ₁
#2	0	−90	−145.8	θ ₂
#3	α ₁	−90	520.6	0
#4	0	0	−128.9	θ ₄
#5	0	90	0	θ ₅

Table 2.

Robot dynamics parameters.

i	m_i (kg)	l_i (m)	Motor inertia (Jm, kg·m²)	Viscous friction coefficients (B, N·m·s⁻ ¹)
L ₁	5.7	1.2	360e ⁻ ⁴	1.48e ⁻ ³
L ₂	3.5	0.75	210e ⁻ ⁴	1.817e ⁻ ³
L ₃	1.4	0.75	70e ⁻ ⁴	7.12e ⁻ ⁴
L ₄	1.4	0.46	70e ⁻ ⁴	6.32e ⁻ ⁴
L ₅	0.6	0.15	33e ⁻ ⁴	1.16e ⁻ ⁴

The main characters of the controllers are just as follows:

The controller mentioned in this article can achieve the superior error tracking value.

Because of the phenomenon of “chattering” in the control of the slip mode structure, it can also be improved in the optimization of dynamic uncertainty equations.

The error distribution of the controller mentioned in this article is more uniform and concentrated, which shows the stability and effectiveness of the controller. In addition, the proposed LFFTSMC retention error converges to zero along the X-, Y-, and Z-axis.

Figure 4 depicts the input torque of each joint in the whole input process, especially after adding external disturbance, each joint carries on the effective signal input in 16 s. The input torque is effectively optimized, reducing the tracking error of the whole tracking process. As can be known from Figure 4, the parameter selection, adaptive law use and the use of fuzzy logic model of low-pass filter play a certain effect in the whole process. The following conclusions can be obtained by comparison.

Figure 4.

SMC, AFTSMC, LFFTSMC joint input torque.

In terms of control torque, sliding mode controller (SMC) has serious chattering phenomenon. AFTSMC method and LFFTSMC method basically overcome the chattering phenomenon. Compared with AFTSMC, LFFTSMC advantage is not particularly prominent.

In the aspect of error tracking, three methods position tracking method position tracking error has no particularly large error, showing good robustness; SMC, AFTSMC, and LFFTSMC in the control accuracy, LFFTSMC shows better control accuracy. The speed error of SMC method fluctuates obviously, while AFTSMC and LFFTSMC have good stability and dynamic quality.

From the torque diagram, AFTSMC and LFFTSMC can quickly reach the stable state, overshoot time, and other dynamic performance indicators to meet the requirements. The deficiency is that the two methods in the dynamic response time almost have no difference.

Experiment

The experimental device is composed of 5-DOF manipulator, six-dimensional force sensor, external PC, and non destructive inspection (NDI) measurement system. The experimental trajectory of the end effect point of the manipulator in Cartesian space is captured by using the NDI system, and the mark is fixed on the manipulator.

The six-dimensional force sensor measures the external force change of the manipulator during execution, marking the characteristics of the whole execution process. The hardware structure of the robotic arm is shown in Figure 5(b). The open version of the controller that is the network client is connected to the CAN connection based on the CAN protocol. The real-time external PC as a network server is extended in real time based on RTAI Linux. The two devices communicate at a frequency of 500 Hz, the industrial controller sends the actual bonding position and speed, and sends the motor current to the external PC and the external PC to answer to send the reference joint position and speed. The JR3 six-axis wrist force/torque sensor is mounted on the manipulator of the right-hand operator of the 5-DOF manipulator and connected to the PC through a DAQ board managed by the RTAI system. The analog voltage generated by the force sensor is obtained by a dedicated real-time thread, which is also responsible for reducing the impact of the measured noise by filtering each channel using the 10th-order moving average filter.

Figure 5.

The experiment setup. (a) Welding robot manipulator and other measurement system. (b) The hardware structure of manipulator. (c) The robot mechanism diagram. (d) The robot controller, respectively.

In the robot manipulator to establish mark point, in the process of robot operation, the use of NDI for effective tracking, especially in the process of research, A, B, C and other special feature points, using JR3 for effective dynamic force tracking, robotic kinematics and kinetic parameters are shown in Tables 1 and 3. Using experiments based on AFTSMC and LFFTSMC controller, the NDI measurement system realizes the position tracking of the manipulator, and the position error can be seen below. JR3 six-axis wrist force/torque sensor to achieve the manipulator of the power tracking, in the process of track tracking, to achieve X-, Y-, Z-direction of force measurement, the specific tracking effect from the following:

Table 3.

The fuzzy ruler.

When s_i chooses NB	And T_i is NB
When s_i chooses NB	And T_i is NB
When s_i chooses ZB	And T_i is ZB
When s_i chooses PB	And T_i is PB
When s_i chooses PB	And T_i is PB

In the course of the experiment, the JR3 six-axis wrist force/torque sensor is used to measure the change of torque in the whole research process, in the process of track tracking.

The results Figure 6 –8 show the proposed controller can obtain the better performance during the trajectory tracking, and the performance was enhanced through the dynamic controller.

Figure 6.

The experiment tested on 5-DOF manipulator with dynamic disturbance. DOF: degree of freedom. (a) The initial point. (b) The motion in process. (c) Another motion point. (d) The terminal point.

Figure 7.

The force measured by the force system during the proposed controller and the PID experiment.

Figure 8.

The errors that were measured during the LFFTSMC experiment and the PID method.

Conclusion

A MIMO-fuzzy terminal sliding mode control with low-pass filter was integrated. The novel controller performed better than others. The main contributions of this article are just as follows:

In this article, the low-pass filter and the fast terminal sliding mode controller were combined to reduce the trajectory tracking error to zero in a limited time.

The position and velocity characteristics of the robot joints wrest effectively processed, and the input torque was effectively optimized through the new controller to ensure the tracking process and dynamic characteristics.

The chattering phenomenon and the external disturbance and kinetic uncertainty in the process of track tracking in the fast terminal sliding mode control are optimized and controlled. The external disturbance and dynamic uncertainty on trajectory tracking was reduced, and the input torques were optimized.

The new experimental device and modern test equipment were introduced. Micro–macro robot, NDI, and six-dimensional force sensor were used to perform the result of the proposed method. And the results showed that the tracking accuracy was realized within 0.3 mm considering the dynamic uncertainty and disturbance.

Footnotes

Data availability statement

Some or all data, models, or code used during the study were provided by a third party (Nanjing University of Science and Technology Robotic Institution). Direct requests for these materials may be made to the provider.

Declaration of conflicting interests

The author(s) declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.

Funding

The author(s) disclosed receipt of the following financial support for the research, authorship, and/or publication of this article: This research was supported by National Key Research and Development Program of China (2018YFB1308301) and National Natural Science Foundation of China (nos 61374133 and 61673205).

ORCID iD

Pengcheng Wang

References

Eom

Suh

Wan

, et al. (eds). Disturbance observer based force control of robot manipulator without force sensor. In: IEEE international conference on robotics & automation, Leuven, Belgium, 20–20 May 1998.

Tran

Kang

. Adaptive terminal sliding mode control of uncertain robotic manipulators based on local approximation of a dynamic system. Neurocomputing 2016; 228: S0925231216312759.

Mondal

Mahanta

. Adaptive second order terminal sliding mode controller for robotic manipulators. J Franklin Instit 2014; 351(4): 2356–2377.

Dong

Dongbin

Jianqiang

, et al. Trajectory tracking control of omnidirectional wheeled mobile manipulators: robust neural network-based sliding mode approach. IEEE Trans Syst Man Cybern Part B (Cybern) 2009; 39(3): 788–799.

Wong

Rad

. Robust fuzzy tracking control for robotic manipulators. Simul Model Pract Theory 2007; 15(7): 801–816.

Eom

Suh

Chung

, et al. (eds). Disturbance observer based force control of robot manipulator without force sensor. In: Proceedings 1998 IEEE international conference on robotics and automation (Cat No. 98CH36146), Leuven, Belgium, 20–20 May 1998.

Amer

Sallam

Elawady

. Adaptive fuzzy sliding mode control using supervisory fuzzy control for 3 DOF planar robot manipulators. Appl Soft Comput 2011; 11(8): 4943–4953.

Yin

. Enhancing trajectory tracking accuracy for industrial robot with robust adaptive control. Robot Cim-Int Manuf 2018; 51: 97–102.

Feng

Liu

, et al. Disturbance observer based robust mixed H2/H∞ fuzzy tracking control for hypersonic vehicles. Fuzzy Set Syst 2017; 306: 118–136.

10.

Fei

. Tracking control of robot manipulators via output feedback linearization. Front Mech Eng China 2006; 1(3): 329–335.

11.

THS

Huang

. MIMO adaptive fuzzy terminal sliding-mode controller for robotic manipulators. Inf Sci 2005; 180(23): 4641–4660.

12.

Gazi

. Swarm aggregations using artificial potentials and sliding-mode control. IEEE Trans Robot 2005; 21(6): 1208–1214.

13.

Bessa

Dutra

Kreuzer

. Depth control of remotely operated underwater vehicles using an adaptive fuzzy sliding mode controller. Robot Auton Syst 2008; 56(8): 670–677.

14.

Wang

Savkin

Garratt

. A strategy for safe 3D navigation of non-holonomic robots among moving obstacles. Robotica 2018; 36(2): 275–297.

15.

Vijay

Jena

. Backstepping terminal sliding mode control of robot manipulator using radial basis functional neural networks. Comput Electr Eng 2017; 67: S0045790617312004.

16.

Yang

Fukushima

Qin

. Decentralized adaptive robust control of robot manipulators. IEEE Trans Control Syst Technol 2012; 20(5): 1357–1365.

17.

Xiaowei

Zhang

Wang

. Design of disturbance observer based sliding mode control for fuzzy systems. IFAC-PapersOnLine 2017; 50(1): 717–722.

18.

Liu

Zhang

. Fuzzy sliding mode control of robotic manipulators with kinematic and dynamic uncertainties. J Dyn Syst Measure Control 2012; 134(6): 72.

19.

Sun

Pei

Pan

, et al. Neural network-based sliding mode adaptive control for robot manipulators. Neurocomputing 2011; 74(14–15): 2377–2384.

20.

Zhao

Cheng

Wang

. Sliding mode control for a two-joint coupling nonlinear system based on extended state observer. ISA Trans 2018; 73: 130–140.

21.

Zheng

Liang

. Adaptive sliding mode trajectory tracking control of robotic airships with parametric uncertainty and wind disturbance. J Franklin Instit 2017; 355(1): S0016003217305707.

22.

Rezoug

Hamerlain

. Application of fuzzy sliding mode to control of manipulator robot actuated by pneumatic artificial muscles. IFAC Proc Vol 2009; 42(19): 580–585.

23.

Matraji

Al-Durra

Haryono

, et al. Trajectory tracking control of skid-steered mobile robot based on adaptive second order sliding mode control. Control Eng Pract 2018; 72: 167–176.

24.

Riani

Madani

Benallegue

, et al. Adaptive integral terminal sliding mode control for upper-limb rehabilitation exoskeleton. Control Eng Pract 2018; 75: 108–117.

25.

Yong

Man

. Non-singular terminal sliding mode control of rigid manipulators. Automatica 2002; 38(12): 2159–2167.

26.

Janardhanan

Bandyopadhyay

. On discretization of continuous-time terminal sliding mode. IEEE Trans Autom Control 2006; 51(9): 1532–1536.

27.

Tao

Taur

Mei-Lang

. Adaptive fuzzy terminal sliding mode controller for linear systems with mismatched time-varying uncertainties. IEEE Trans Syst Man Cybern Part B (Cybern) 2004; 34(1): 255–262.

28.

Wang

Chai

Zhai

. Neural-network-based terminal sliding-mode control of robotic manipulators including actuator dynamics. IEEE Trans Ind Electron 2009; 56(9): 3296–3304.

29.

Zhihong

. Fast terminal sliding-mode control design for nonlinear dynamical systems. IEEE Trans Circuit Syst I Fundam Theory Appl 2009; 49(2): 261–264.

30.

Zhihong

. Terminal sliding mode control of MIMO linear systems. IEEE Trans Circuit Syst I Fundam Theory Appl 2002; 44(11): 1065–1070.

31.

Wang

Jiang

Bai

, et al. A new continuous fractional-order nonsingular terminal sliding mode control for cable-driven manipulators. Adv Eng Softw 2018; 119: 21–29.

32.

Asl

Hagh

Palm

. Robust control by adaptive non-singular terminal sliding mode. Eng Appl Artif Intel 2017; 59: 205–217.

33.

Park

Lee

. Sliding mode controller with filtered signal for robot manipulators using virtual plant/controller. Mechatronics 1997; 7(3): 277–286.

34.

Zhao

Gao

. A new terminal sliding mode control for robotic manipulators. Int J Control 2009; 82(10): 1804–1813.
