Native Chondrocyte Viability during Cartilage Lesion Progression

Introduction

Articular cartilage disease defines a large disease burden afflicting our population.^1-5 Significant efforts continue in developing and tracking treatment solutions for articular cartilage lesions at various stages of their progression. ⁶ A considerable interest exists for effective surgical interventions that address an earlier stage of disease progression rather than waiting for full-thickness articular cartilage lesions to develop. Early surgical intervention is appealing for an aging population to mitigate downstream disease burden associated with full-thickness defects. Surgical treatment of fibrillated partial-thickness articular cartilage lesions remains an important category because these lesions can be readily diagnosed and characterized by visual and tactile cues during surgery and hence remain an attractive therapeutic target for early surgical intervention modalities.

Surgical treatment for fibrillated partial-thickness lesions has been traditionally limited to debridement chondroplasty techniques developed to remove the damaged articular cartilage that causes a mechanical and inflammatory impairment of joint function and leads to a deterioration of joint health. Smoothing the articular surface can eliminate the mechanical stress risers that cause symptoms and propagate cartilage damage; removal of the loose surface debris associated with loss of cartilage function decreases the biologic load the joint needs to address.^7-11 Although an attractive surgical approach, current debridement chondroplasty techniques are imprecise, are aggressive, and induce necrosis and collateral damage to contiguous untargeted cartilage tissue at the treatment site.^12-23 Accordingly, widespread adoption of current debridement chondroplasty techniques as an early surgical intervention modality to treat fibrillated partial-thickness lesions has not emerged due to the fear of contributing to disease progression resulting from an attempt to provide disease burden relief.

Because it is difficult to imagine an early surgical intervention for articular cartilage that does not include in situ removal of damaged tissue present at the lesion locale, researchers have sought to create more targeted interventions that are based on lesion progression. As early surgical intervention techniques become more precise and allow tissue preservation of articular cartilage, native chondrocyte viability at the treatment site before intervention becomes an important parameter to consider. The purpose of this study is to evaluate native chondrocyte viability in a series of specimens demonstrating the progression of articular cartilage lesions to determine if the chondrocyte viability profile changes during the evolution of articular cartilage disease to the level of surface fibrillation.

Materials and Methods

Osteochondral specimens were harvested from patients undergoing total knee replacement under an approved Institutional Review Board protocol. The total knee replacement procedures were performed by a single surgeon in the normal course of his practice. The tissue to be normally discarded during the procedure was examined prior to harvest once the knee joint was entered surgically to determine if it met the requirements for study inclusion. Specimens were included that demonstrated an area of uniform normal or partial-thickness damage of sufficient size to obtain test samples wherein harvest margin artifact would not be a confounding variable. ²⁴ Three groups were created within each patient tissue harvest based on visual and tactile characteristics of the specimens as customarily assessed during surgery: group 1 included visually and tactilely normal cartilage surfaces, group 2 included visually normal but tactilely soft (as judged by indentation pressure) cartilage surfaces, and group 3 included surface fibrillation of the cartilage surfaces.

Immediately after harvest, three 0.5-mm coronal sections of each cartilage sample were obtained referencing the center of the sample after removal of subchondral bone. The sections were prepared for staining by washing in HEPES buffered saline solution. Live/Dead^® Reduced Biohazard Cell Viability Kit 1 “green and red fluorescence,” SKU #L-7013 (Invitrogen, Carlsbad, California), was used per the manufacturer’s specification to stain specimens. Specimens were gluteraldehyde fixed, transferred to standard flat glass slides, and flooded with VectaShield^® fluorescence protection oil prior to the placement of #1.5 borosilicate glass coverslips over each specimen section.

The cartilage tissue and the articular surface were assessed by confocal fluorescence laser microscopy analysis performed by personnel blinded to the identity of the samples. Confocal imaging was performed with an Olympus IX-81 inverted microscope coupled to an Olympus FV300 confocal laser scanning unit (Center Valley, Pennsylvania) using 488-nm laser excitation. Live chondrocytes were captured under green fluorescent channel (505-525 nm), and dead chondrocytes were captured under red fluorescent channel (577-634 nm), generating a live image, a dead image, and an integrated image.

Results

Six separate osteochondral specimens originating from femoral condyle resection were included for study (n = 6), with 2 specimens per group. Figures 1 to 3 demonstrate representative images of the specimens. Interspecimen comparisons did not reveal significant differences in relative chondrocyte population densities, chondron orientation, or cellular distribution patterns. Comparison of specimens within a patient harvest indicated a distinct progression of lesion from normal to fibrillated.

OPEN IN VIEWER

Figure 1.

Confocal laser microscopy images, group 1. Representative images depicting live cell stain (green), dead cell stain (red), and a combined image with both live cell and dead cell stain. Original magnification 10x.

OPEN IN VIEWER

Figure 2.

Confocal laser microscopy images, group 2. Representative images depicting live cell stain (green), dead cell stain (red), and a combined image with both live cell and dead cell stain. Original magnification 10x.

OPEN IN VIEWER

Figure 3.

Confocal laser microscopy images, group 3. Representative images depicting live cell stain (green), dead cell stain (red), and a combined image with both live cell and dead cell stain. Original magnification 10x.

Group 1 specimens ( Figure 1 ) demonstrated intact and normal articular surfaces consistent with gross visual and tactile inspection of the harvested tissues. The superficial, transitional, and deep zones remained structurally intact with chondrocytes and chondron appearances typical of normal articular cartilage. Live chondrocytes were observed residing throughout the tissue abundantly and present in zonal density patterns typical of healthy cartilage. Dead chondrocytes were not observed within the substance of the cartilage tissue. The lamina splendens region appeared congruous without evidence of disruption.

Group 2 specimens ( Figure 2 ) demonstrated intact but softened articular surfaces consistent with gross visual and tactile inspection of the harvested tissues. The superficial, transitional, and deep zones remained structurally intact, but the superficial zone demonstrated areas with loss of surface cellularity and lacunar emptying within the superficial zone deep to the lamina splendens. Live chondrocytes were abundantly present in zonal density patterns typical of healthy cartilage around and below the surface changes. Dead chondrocytes were not observed within the substance of the cartilage tissue. Adjacent to the softened segments, a more typical normal appearance was observed without softening, loss of surface cellularity, or lacunar emptying, as noted in group 1 specimens indicating lesion transition.

Group 3 specimens ( Figure 3 ) demonstrated typical fibrillated articular surfaces consistent with gross visual and tactile inspection of the harvested tissues. The superficial zone was clearly disrupted by the fibrillation, but chondrocytes with a flattened appearance typical of this zone remained present even toward the base of the fibrillation. The fibrillation did not penetrate deep to the transitional zone of the articular cartilage tissue in any specimen. Within the fibrillated tissue itself, live chondrocytes were observed residing within the tissue at varying distances from the surface of the fibrillation. Live chondrocytes were abundantly present in zonal density patterns typical of healthy cartilage around and below the surface fibrillation. Occasional dead chondrocytes were observed to reside in a more extruded position at the margins of the fibrillation itself but not within the substance of the morphologically intact cartilage tissue. Adjacent to the fibrillated segments, a more typical softened appearance was observed without fibrillation but with loss of surface cellularity and lacunar emptying within the superficial zone deep to the lamina splendens, as noted in group 2 specimens indicating lesion transition.

Discussion

This study explored chondrocyte viability in tissue specimens demonstrating various levels of articular cartilage lesion progression in patients undergoing joint replacement surgery. Although a small sample size, the results indicate that articular cartilage retains a very high percentage of native viable chondrocytes even when lesion progression has led to matrix failure and subsequent surface fibrillation within the same patient. Because of the predominant chondrocyte viability noted, surface fibrillation appears to be an important stage to consider for early surgical intervention—a stage that can be readily diagnosed by visual and tactile cues during surgery.

Matrix failure–based early intervention for articular cartilage disease should be considered a therapeutic target because preserving functioning cartilage tissue is important. Injury and loss of the superficial zone has been strongly associated with the progression of cartilage disease,^25-29 and treatments that contribute to superficial zone injury accelerate the natural progression and disease burden of osteoarthritis.^25,29-33 Once articular cartilage lesions have progressed to matrix failure leading to surface fibrillation, those chondrocytes within the fibrillation, although noted to be viable in this study, may be not be useful to retain considering that fibrillation matrix stress risers can cause additional chondrocytes to become extruded as untreated fibrillation lesions propagate in response to additional loading.^34-41 Stabilizing superficial zone lamina flaps, cleavage planes, and the peeling or breaking of denatured collagen fibrils can be a reasonable matrix failure–based therapeutic target. From an early surgical intervention perspective, precisely removing this fibrillated tissue as a means to stabilize lesions is preferable, as long as the underlying intact chondrons are not injured, because it has been noted that spatial reorganization and proliferation of superficial zone chondrocytes occur in response to distant partial-thickness lesions and may serve as a mechanism to recruit metabolically active units to address focal disease. ⁴²

Although many studies have supported the efficacy of debridement chondroplasty in relieving patient symptoms by smoothing the articular surface and decreasing the biologic load of joint cartilage debris,^7-11 these benefits have yet to be shown to contribute to long-term joint health, to promote cartilage longevity, or to mitigate joint replacement surgery. This may be due to the nature of current interventions that are excessively damaging to these lesions and notably contribute to disease progression.^12-23 If iatrogenic cartilage damage can be eliminated during debridement chondroplasty, whereby superficial zone chondrocytes at or around the lesion are preserved, the opportunity to effect beneficial changes in chondrocyte function remains in that resident cell function may be recruited to aid healing.^42-47 Even though other experimental techniques have failed to show a significant repair response of native chondrocytes within partial-thickness lesions,^48-50 further study is required to determine whether early surgical intervention treatments that preserve and stabilize tissue permit or even induce a normal healing response.
