Hemangioma of the rib showing a relatively high 18F-FDG uptake: a case report with a literature review

Abstract

Hemangioma of the rib is a rare benign tumor that is often difficult to distinguish from malignant bone tumors. Rib hemangioma often shows bony disruption with a slight cortical disruption, extraosseous lesion, and expanded bone on computed tomography (CT). We report the case of a 68-year-old man with atypical rib hemangioma with a slight cortical disruption and no expanded bone. The tumor showed relatively high 18FDG-uptake on positron emission tomography (PET)/CT. Rib hemangioma often shows higher 18FDG-uptake. PET/CT may not provide useful information for distinguishing rib hemangioma from a malignant tumor. Close observation without surgical resection may be feasible if the tumor is diagnosed as a rib hemangioma by biopsy.

Keywords

18F-fluorodeoxyglucose (FDG)computed tomography (CT)hemangioma rib positron emission tomography (PET)

Introduction

Bone hemangiomas are benign hamartomatous vascular tumors. They account for less than 1% of all bone tumors (1). Approximately 50–80% of bone hemangiomas occur in the vertebral body or the skull (2). Hemangiomas of the rib are relatively rare; hence, they are often misdiagnosed as malignant tumors, such as metastatic tumors or primary malignant bone tumors. Given that 60–80% of the primary rib tumors are malignant (1), it is important to have knowledge of the features of rib hemangioma images.

We experienced a case with hemangioma of a rib showing relatively high 2-fluoro [fluorine-18]-2-deoxy-D-glucose (18F-FDG) uptake (maximum standard uptake value [SUVmax] = 2.9) on positron emission tomography (PET)/computed tomography (CT), which was difficult to distinguish from a malignant tumor. In this manuscript, we review the features of the rib hemangioma images and discuss the usefulness of PET/CT for distinguishing rib hemangiomas from malignant tumors. We discuss the surgical indications of rib hemangioma.

Case report

A bone tumor, 2 cm in diameter, of the fourth left rib was incidentally identified in a 68-year-old man upon a CT scan performed as part of his periodic examination for chronic pancreatitis. He did not want further investigation at the time, but the tumor had enlarged over half a year, and he then presented to our institution for a closer inspection.

He had no physical or visible symptoms. He had a history of myocardial infarction, hypertension, and chronic pancreatitis, but no history of malignancy. CT revealed a tumor in the neck of the fourth rib, 1.8 × 1.6 × 2.1 cm in size, presenting as a multicystic lesion with soap bubble appearance, with a slight cortical disruption, extraosseous lesion, but no expanded bone (Fig. 1).

Fig. 1.

CT image of the fourth left rib. The tumor occurred in the neck of the rib and showed bony disruption with a slight cortical disruption.

On magnetic resonance imaging (MRI), the lesion showed low to intermediate signal on T1-weighted (T1W) images, intermediate to high signal on the T2-weighted (T2W) images, and enhancement with gadolinium (Fig. 2a–c).

Fig. 2.

MR images of the affected rib. (a) T1W sequence, (b) T2W sequence, and (c) T1W fat-saturation sequence with gadolinium enhancement.

On PET/CT, the lesion showed relatively high 18FDG uptake (SUVmax = 2.9) (Fig. 3). Blood analysis demonstrated no remarkable findings and the tumor markers were negative. The tumor grew larger over the subsequent six months. In order to distinguish whether this was a malignant tumor, we performed open biopsy, with 20 mL bleeding. The specimen showed hyperplasia of the small vessels in the bone marrow (Fig. 4). No malignant findings of endothelial cells of the vessel were made and he was diagnosed as having a hemangioma of bone.

Fig. 3.

Slightly increased FDG accumulation in the tumor on PET/CT image. The SUVmax value of the tumor was 2.9.

Fig. 4.

Hematoxylin and eosin stain (original magnification × 100). The tumor showed hyperplasia of the small vessels in the bone marrow, and a diagnosis of hemangioma was made.

Surgical resection of the rib was not conducted as he was asymptomatic and hemangioma of the bone being a benign bone tumor. The patient was discharged on the eighth postoperative day without any complications. The tumor showed calcification formation but without any further growth, as assessed by CT one year after the biopsy (Fig. 5).

Fig. 5.

CT image of the fourth left rib one year after the biopsy. The tumor showed calcification, but had not enlarged since the biopsy.

Discussion

Hemangioma represents 1% of primary bone tumors; the tumor occurs in the vertebral body or the skull in 60–80% of patients. Hemangioma of the rib is a relatively rare tumor. Hemangioma of the bone is usually asymptomatic, but one or more symptoms occur in 42.6% of cases if the lesion occurs in a rib (3).

Of primary rib tumors, 89% are malignant (2). The differential diagnosis of rib tumor is usually primary or metastatic. Malignant tumors include malignant lymphoma, myeloma, chondrosarcoma, osteosarcoma, and Ewing sarcoma (2). Thus, it is important to distinguish hemangioma from malignant tumors in the rib and this requires knowledge of the imaging features of rib hemangioma.

Hemangiomas in flat bones, including the rib, show cortical destruction with extraosseous mass and osteolytic lesions (4). We reviewed 22 previously published reports, 23 cases with 24 hemangiomas, obtained by using the key words “hemangioma AND rib,” and investigated clinical and radiological findings. Patients in these reports were aged 11–76 years.

Rib hemangioma is typically asymptomatic. Ten of the 23 described cases reported symptoms such as pain as the most common symptom. On CT, rib hemangioma often shows three features, i.e. bone disruption, extraosseous lesion, and expanded bone (2 –23) (Table 1). Nineteen of the 24 hemangiomas showed bone disruption and 18 of the 24 hemangiomas showed extraosseous lesions. In particular, all rib hemangiomas demonstrated expanded bone. However, in our case, the tumor showed bony disruption, with a slight cortical disruption, but the extraosseous lesion showed no expanded bone. A tumor may show expanded bone if the tumor grows larger; however, the tumor in our case was somewhat smaller than in the other reported cases. The literature review indicated that hemangiomas occur in the body of the rib more frequently than in neck of the rib.

Table 1.

Summary of the previous reported cases.

Age (years)	Gender	Location			Size (cm)	Expanded bone	Bony disruption	Extraosseous lesion	Symptom	Author	Year	References
11	F	Rightt	6th	Neck	Not mentioned	+	–	+	Pain	Ortega	1986	(5)
65	F	Left	8th	Body	Not mentioned	+	–	+	Pain	Ortega	1986	(5)
56	F	Left	7th	Body	16 × 7 × 6	+	+	+	–	Kuo	1994	(6)
76	M	Right	3rd	Body	5 × 2.5	+	+	+	–	Clements	1998	(7)
59	F	Left	7th	Body	3.8 × 2.5	+	+	+	–	Okumura	2000	(8)
50	F	Right	1st	Body	Not mentioned	+	–	–	Thoracic outlet syndrome	Yeow	2001	(9)
45	M	Right	7th	Body	Not mentioned	+	+	+	Pain	Roy	2005	(10)
25	F	Left	8th	Neck	4 × 4 × 7	+	–	+	–	Ovali	2006	(11)
74	M	Left	5th	Body	9.5 × 6.5 × 3	+	+	–	Pain	Nakamura	2007	(12)
28	F	Right	5th	Neck	7 × 9 × 5	+	+	+	Pain	Sirmali	2007	(13)
54	F	Left	8th	Body	7 × 6 × 5	+	+	+	–	Cakir	2008	(14)
20	M	Right	5th	Neck	5	+	+	+	–	Tew	2011	(15)
48	F	Left	7th	Body	5 × 3.8	+	+	+	–	Abrao	2011	(2)
26	F	Right	8th	Neck	6.5 × 3 × 4.5	+	+	–	Swelling	Jain	2011	(16)
64	F	Left	5th	Body	8 × 4 × 2.5	+	+	–	–	Hashimoto	2011	(17)
54	F	Right	9th	Body	8 × 5 × 5	+	+	+	–	Jia	2011	(18)
57	F	Right	1st	Body	5.8 × 5.6 × 3.8	+	+	+	Not mentioned	Imai	2013	(19)
18	F	Right	3rd	Body	Not mentioned	+	+	+	Swelling	Deshmukh	2015	(20)
21	M	Left	5th	Neck	Not mentioned	+	+	+	Weakness in both lower limbs and loss of bowel bladder control	Shaik	2015	(21)
73	F	Left	6th	Body	2.9 × 2.5 × 1.9	+	+	+	–	Haro	2015	(3)
76	F	Left	4th to 6th	Body	10	+	+	+	Pain, intercostal paraesthesia, shortness of breath	Weinandt	2016	(22)
		Right	4th	Body	3	+	–	–
63	M	Left	6th	Body	5.5 × 2.5 × 1.5	+	+	–	–	Park	2016	(4)
55	M	Right	3rd	Body	3.5 × 2.5 × 2	+	+	+	–	Saito	2016	(23)
68	M	Left	4th	Neck	1.8 × 1.6 × 2.1	–	+	+	–	This case	2017	–

Hemangioma of the rib demonstrates low to intermediate signals on T1W images, intermediate to high signals on T2W images, and enhancement with gadolinium on MRI (15), similar to Ewing sarcoma or malignant lymphoma on MRI. Hemangioma of bone shows various signals, according to the proportion of vessel and lipomatous soft tissue elements. Thus, MRI images of hemangioma may not be specific for diagnosis.

18F-FDG PET/CT is increasingly being used to obtain more information about benign and malignant tumors, including metastatic tumors. On PET/CT, hemangioma of the rib presents with an SUVmax of 2.2–6.7 (3,12,23). Therefore, PET/CT may not provide useful information for distinguishing rib hemangiomas from malignant tumors.

A mainstay treatment for hemangioma is reported to be surgical resection (20). In our review of the literature, resection was conducted in all cases. In some cases, embolization was conducted preliminary to reduce intraoperative blood loss or bleeding after biopsy (20,21). Resection of the tumors was often performed without biopsy. Complications, such as massive bleeding and hematoma, may occur during a preoperative biopsy, complicating the process of distinguishing malignant tumors from benign entities (15). Preoperative needle biopsy before resection was found to be valuable because the most suitable treatment for the rib tumor could then be determined (12). However, in some cases, resection was performed after the diagnosis of rib hemangioma by means of needle biopsy, because it was not possible to exclude the possibility of malignant tumor (3). We chose to use open biopsy, because the tumor occurred in the neck of the rib and obtained enough specimen with little bleeding.

Hemangioma is a benign tumor; hence, we did not perform surgical resection of the tumor. The tumor in our case showed calcifications and did not enlarge over the duration of one year after the biopsy (Fig. 5). Close observation without surgical resection may be feasible if the tumor is diagnosed as hemangioma by means of needle biopsy.

Preoperative embolization of large rib hemangioma can reduce the size (20), and cement or alcohol injection have been conducted as treatment of vertebral hemangiomas (24).

If observation for rib hemangioma is decided, such percutaneous treatment might be one of the optional treatments.

In conclusion, the most common feature on CT was expanded bone. Observation without resection might be one of the treatments for rib hemangioma.

Footnotes

Declaration of conflicting interests

The author(s) declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.

Funding

The author(s) received no financial support for the research, authorship, and/or publication of this article.

References

Ogose

Hotta

Morita

et al.

Solitary osseous hemangioma outside the spinal and craniofacial bones. Arch Orthop Trauma Surg 2000; 120: 262–266.

Abrão

Tamagno

Canzian

et al.

Hemangioma of the rib. Ann Thorac Surg 2011; 91: 595–596.

Haro

Nagashima

. A rare case report of rib hemangioma mimicking a malignant bone tumor or metastatic tumor. Int J Surg Case Rep 2015; 16: 141–145.

Park

Lee

. Cavernous hemangioma of the rib: a case report. Iran J Radiol 2016; 13: e31677–e31677.

Ortega

Mahboubi

Dalinka

et al.

Computed tomography of rib hemangiomas. J Comput Assist Tomogr 1986; 10: 945–947.

Kuo

Lin

Sheu

et al.

Imaging diagnosis of cavernous hemangioma of the rib – one case report and review of the literature. Kaohsiung J Med Sci 1994; 10: 469–473.

Clements

Turnage

Tyndal

. Hemangioma of the rib: a rare diagnosis. Am Surg 1998; 64: 1027–1029.

Okumura

Asamura

Kondo

et al.

Hemangioma of the rib: a case report. Jpn J Clin Oncol 2000; 30: 354–357.

Yeow

Hsieh

. Thoracic outlet syndrome caused by first rib hemangioma. J Vasc Surg 2001; 33: 1118–1121.

10.

Roy

Isler

. Costal hemangioma presenting as rib pain after pneumonia. Can J Surg 2005; 48: 152–152.

11.

Ovali

Göktan

Serdar Tarhan

et al.

Hemangioma of the rib. Turk J Med Sci 2006; 36: 65–70.

12.

Nakamura

Kawasaki

Taguchi

et al.

Cavernous hemangioma of the rib diagnosed preoperatively by percutaneous needle biopsy. Gen Thorac Cardiovasc Surg 2007; 55: 134–137.

13.

Sirmali

Türüt

Findik

et al.

A huge mass destroying the fifth rib: a rare case of cavernous haemangioma. Acta Chir Belg 2007; 107: 454–456.

14.

Cakir

Tastepe

Agackiran

. Cavernous hemangioma of the rib: a rare tumour. Acta Chir Belg 2008; 108: 619–620.

15.

Tew

Constantine

Lew

WYC

. Intraosseous hemangioma of the rib mimicking an aggressive chest wall tumor. Diagn Interv Radiol 2011; 17: 118–121.

16.

Jain

Songra

Malhotra

et al.

Rib haemangioma: a rare differential for rib tumours. Indian J Surg 2011; 73: 447–449.

17.

Hashimoto

Takenaka

Akimoto

et al.

Capillary hemangioma in a rib presenting as large pleural effusion. Ann Thorac Surg 2011; 91: e59–61.

18.

Jia

Meng

Zhou

et al.

Asymptomatic rib cavernous hemangioma. Clin Nucl Med 2011; 36: 1112–1114.

19.

Imai

Saji

Ikeda

. Cavernous hemangioma of the first rib. Asian Cardiovasc Thorac Ann 2013; 21: 488–489.

20.

Deshmukh

Rathod

Hira

et al.

Hemangioma of rib: A different perspective. Pol J Radiol 2015; 80: 172–175.

21.

Shaik

Karapurkar

Bhojraj

et al.

Thoracic hemangioma from rib presenting as compressive paraparesis in a young adult. Spine 2015; 40: e1198–1200.

22.

Weinandt

Legras

Mordant

et al.

Chest wall resection for multifocal osseous hemangioma. Interact Cardiovasc Thorac Surg 2016; 22: 233–234.

23.

Saito

Akaike

Tomomasa

et al.

A case of epithelioid hemangioma of the right third rib in a 55-year-old man. Int J Clin Exp Pathol 2016; 9: 9681–9686.

24.

Tomasian

Wallace

Jennings

. Benign spine lesions: advances in techniques for minimally invasive percutaneous treatment. Am J Neuroradiol 2017; 38: 852–861.
