Pediatric Type II Tibial Spine Fractures: Addressing the Treatment Controversy With a Mixed-Effects Model

Abstract

Background:

Tibial spine fractures, although relatively rare, account for a substantial proportion of pediatric knee injuries with effusions and can have significant complications. Meyers and McKeever type II fractures are displaced anteriorly with an intact posterior hinge. Whether this subtype of pediatric tibial spine fracture should be treated operatively or nonoperatively remains controversial. Surgical delay is associated with an increased risk of arthrofibrosis; thus, prompt treatment decision making is imperative.

Purpose:

To assess for variability among pediatric orthopaedic surgeons when treating pediatric type II tibial spine fractures.

Study Design:

Cross-sectional study.

Methods:

A discrete choice experiment was conducted to determine the patient and injury attributes that influence the management choice. A convenience sample of 20 pediatric orthopaedic surgeons reviewed 40 case vignettes, including physis-blinded radiographs displaying displaced fractures and a description of the patient’s sex, age, mechanism of injury, and predominant sport. Surgeons were asked whether they would treat the fracture operatively or nonoperatively. A mixed-effects model was then used to determine the patient attributes most likely to influence the surgeon’s decision, as well as surgeon training background, years in practice, and risk-taking behavior.

Results:

The majority of respondents selected operative treatment for 85% of the presented cases. The degree of fracture displacement was the only attribute significantly associated with treatment choice (P < .001). Surgeons were 28% more likely to treat the fracture operatively with each additional millimeter of displacement of fracture fragment. Over 64% of surgeons chose to treat operatively when the fracture fragment was displaced by ≥3.5 mm. Significant variation in surgeon’s propensity for operative treatment of this fracture was observed (P = .01). Surgeon training, years in practice, and risk-taking scores were not associated with the respondent’s preference for surgical treatment.

Conclusion:

There was substantial variation among pediatric orthopaedic surgeons when treating type II tibial spine fractures. The decision to operate was based on the degree of fracture displacement. Identifying current treatment preferences among surgeons given different patient factors can highlight current variation in practice patterns and direct efforts toward promoting the most optimal treatment strategies for controversial type II tibial spine fractures.

Keywords

tibial spine fracture pediatric type II Meyers McKeever treatment decision making

Tibial spine fractures are relatively rare, occurring in approximately 3 out of 100,000 children annually, yet they account for about 2% to 5% of pediatric knee injuries associated with an effusion.^1,22 If not treated properly, patients with these injuries can develop significant complications, including arthrofibrosis, residual laxity, fracture nonunion or malunion, quadriceps atrophy, retropatellar pain, and tibial physis disruptions.^1,3,16,40 Tibial spine fractures have recently garnered increased attention owing to new noncontact sport injury mechanisms being reported for this injury in children.¹⁷

Fractures of the partially ossified tibial eminence occur after forced knee flexion with simultaneous tibia external rotation, or hyperextension, similar to anterior cruciate ligament (ACL) rupture mechanisms.²⁴ They are typically classified via plain radiographs with the Meyers and McKeever classification, based on displacement and morphology of the fracture fragment. Fractures were originally categorized into 3 types: type I fractures are nondisplaced; type II fractures are displaced anteriorly with an intact posterior cortical hinge; and type III fractures are completely displaced.²⁴ Further classifications include types IIIA and IIIB, with IIIA involving only the insertion point of the ACL and IIIB involving the entire intercondylar notch, as well as type IV for comminuted fractures.^20,39

The Meyers and McKeever classification is a core basis of treatment practice for many surgeons, where type I cases are managed nonoperatively and types III and IV are almost universally managed surgically.^14,25 Controversy exists surrounding the management of type II fractures, the focus of this study; similar to the controversy around type II supracondylar humerus fractures, some surgeons advocate surgical treatment and others advocate nonoperative treatment.^4,11,18 Closed management may be appropriate when displacement is less than 3 to 5 mm, earning improved reduction at the cost of greater arthrofibrosis risk.⁹ Surgical delay is associated with an increased risk of arthrofibrosis; thus, prompt treatment decision making is imperative.³⁵

Relative indications for arthroscopic reduction and internal fixation depend on the degree of displacement and patient attributes, including age, sex, injury mechanism, and athletic level. Tibial spine fractures with these attributes thus may be variably managed by pediatric orthopaedic surgeons without a standardization of treatment modality for these injuries. Therefore, the purpose of this study was to identify and characterize variability among pediatric orthopaedic surgeons when treating type II tibial spine fractures. In addition, we aimed to identify injury characteristics, patient attributes, and surgeon demographics that affected clinical decision making.

Methods

This was an observational cross-sectional study with level 4 evidence. A convenience sample of 20 pediatric orthopaedic surgeons in the United States, selected per their expertise in this area, reviewed 40 case vignettes that included radiographs displaying fractures with varying degrees of displacement and a brief description on the patient’s sex, age, mechanism of injury, and predominant sport (Figure 1). A copy of the survey is included in Appendix Figure A1, available as supplemental material. Existing literature^1,8,18,24 and expert opinion were used to select the attributes (sex, age, mechanism of injury, primary sport participation, and displacement) and their respective levels to be entered into the model. Radiographs were reviewed and confirmed with fracture fragment displacement by an independent musculoskeletal radiologist.

Figure 1.

A sample vignette includes anteroposterior and lateral knee radiographs of a type II tibial spine fracture with patient and injury characteristics, as well as fracture fragment displacement value shown on zoomed lateral view.

Skeletal physes were blinded, as radiographs showing the ossification centers surrounding the knee could be used by experienced pediatric orthopaedic surgeons to approximate true age. This allowed age to be included as a variable within the computer-generated model, where a vignette of an 8-year-old child could be matched with radiographs of an actual 17-year-old or vice versa. Displacement was not presented as a variable but rather as a fixed effect incorporated into the study model based on actual measured displacement on the lateral radiograph, via an electronic ruler on a picture archiving and communication system. Respondents were asked whether they would treat the fracture operatively (ie, arthroscopic reduction and internal fixation) or nonoperatively (ie, long-leg cast).

Patient ages included 8, 11, 14, and 17 years, representing the most common age range of 8 to 14 years seen in this injury,²¹ as well as the age spectrum of skeletally immature to mature for both males and females. Injury mechanisms included fall, collision, hyperextension, and twist. Primary sports included football, basketball, swimming, and nonathlete, with each representing a basic range of activity levels: contact sport with running/jumping, noncontact sport with running/jumping, noncontact and nonweightbearing sport, and no sport, respectively. Both the primary sports and injury mechanisms variables chosen in this study represented the most common reported in the literature.¹ Finally, displacement of fracture fragments ranged from 2.5 to 6.0 mm, with a mean ± SD value of 4.2 ± 1.1 mm, to represent a range of displacement that surgeons typically see in practice.¹ Figure 2 illustrates a vignette with larger displacement than Figure 1, as an example.

Figure 2.

A second sample vignette illustrates a tibial spine fracture with greater displacement than in Figure 1, as an example.

The Jackson Personality Inventory (JPI) Risk Taking subscale is a Likert scale, with 1 being risk averse and 4 being risk favorable, and it has been used in other peer-reviewed studies to examine providers’ favorability toward risk taking in their treatment of patients.^6,8 The JPI Risk Taking subscale was incorporated to account for any differences in individual risk tolerance among surveyed surgeons, which could serve as a confounding variable in treatment decision making. It consists of 6 questions asking respondents to rate their level of agreement with the following: enjoyment of risk taking, avoidance of situations with uncertain outcomes, discomfort with risk taking if involved gains are higher, consideration of security as an important life element, whether people have told the respondent that he or she seems to enjoy taking risks, and whether the respondent takes risks when another alternative is present.

A computerized discrete choice experiment was then conducted to determine the patient and/or injury attributes (fixed effects) that influence the management of type II pediatric tibial spine fractures by the surveyed pediatric orthopaedic surgeons. An orthogonal and balanced factorial design combined levels and patient attributes via a Bayesian D-optimal design with the Choice Modeling Program within JMP (v 12; SAS Institute). Data were deemed significant for P < .05. In addition, surgeon respondents were queried regarding their demographics and practice (age, sex, years of practice, practice geography and type, fellowship training, weekly call commitments, annual tibial spine treatment frequency) as well as risk-taking behavior via the JPI subscale. The association between (1) surgeon propensity for operative treatment and (2) surgeon training, years in practice, and risk-taking behavior was then assessed. Finally, a receiver operating characteristic (ROC) curve was used to determine the probability of surgical treatment based on the degree of fracture displacement.

Results

A total of 20 fellowship-trained pediatric orthopaedic surgeons participated in this study. Nineteen surgeons had completed pediatric fellowships; 1 had completed sports fellowship only; and 10 had completed multiple fellowships (Table 1). All surgeons were men, with a mean age of 43 years (range, 35-60 years) and a mean of 9 years of practice since fellowship training (range, 1-20 years). All participants (N = 20) had call responsibilities in pediatric orthopaedics at least 1 to 3 times weekly. Surgeon demographic and practice details are summarized in Table 1.

TABLE 1

Demographics of Pediatric Orthopaedic Surgeon Participants (N = 20)

Characteristic	Mean ± SD (Range) or n (%)
Age, y	43.4 ± 7.1
Sex: male	20 (100)
Years of practice	8.9 ± 6.1
Practice geography
Northeast	10 (50.0)
Southeast	1 (5.0)
Midwest	5 (25.0)
Northwest	2 (10.0)
Southwest	2 (10.0)
Practice type
Academic	18 (90.0)
Academic and private mix	2 (10.0)
Fellowship training
Pediatrics only	9 (45.0)
Sports only	1 (5.0)
Pediatrics and sports	9 (45.0)
Pediatrics and hip preservation	1 (5.0)
Days per week on-call	1.8 ± 0.6
Pediatric tibial spine fractures treated annually
Rarely (<1)	1 (5.0)
1-3	8 (40.0)
4-6	4 (20.0)
6-9	4 (20.0)
10-14	1 (5.0)
≥15	2 (10.0)
Adult tibial spine fractures treated annually
Rarely (<1)	10 (50.0)
1-3	8 (40.0)
4-6	1 (5.0)
6-9	1 (5.0)

The degree of fracture displacement was the only attribute significantly associated with treatment choice (P < .001). Surgeons were 28% more likely to treat the fracture operatively with each additional millimeter of displacement (P < .01). The probability of opting for surgical treatment exceeded 64% when the fracture had ≥3.5 mm of displacement. Age, sex, mechanism of injury, and primary sport did not significantly influence treatment choice (Table 2).

TABLE 2

Fixed-Effects Parameter Estimates

Attribute: Level	Estimate	95% Lower	95% Upper	P Value
Sex
Female	Reference	Reference	Reference	Reference
Male	0.00	–0.05	0.05	.96
Age, y
17	Reference	Reference	Reference	Reference
14	0.04	–0.05	0.13	.36
11	–0.01	–0.10	0.08	.82
8	–0.08	–0.17	0.01	.11
Injury mechanism
Fall	Reference	Reference	Reference	Reference
Hyperextension	0.04	–0.05	0.13	.40
Twist	0.06	–0.03	0.15	.23
Collision	–0.06	–0.16	0.03	.16
Primary sport
Nonathlete	Reference	Reference	Reference	Reference
Swimming	–0.03	–0.12	0.06	.55
Basketball	0.04	–0.05	0.13	.34
Football	0.07	–0.02	0.17	.11
Displacement	0.28	0.23	0.32	<.001 ^a

^a Statistically significant (P < .05).

Overall, surgical management was favored by the 20 respondents in 85% of the presented vignettes (Appendix Table A1). However, a statistically significant variation was identified in surgeons’ propensity for operative treatment of this fracture (P < .01). Of the 20 surgeons, 13 demonstrated a preference for operative treatment of this injury. Surgeon training, years in practice, and risk-taking scores were not associated with the respondents’ preference for surgical treatment. Overall, surgeon participants were neither highly risk averse nor risk favorable, with a mean risk score of 2.6 ± 0.3. Risk scores and preference for surgical management were very weakly correlated (r = 0.24, P = .31). Respondents’ treatment preference and risk scores are summarized in Table 3.

TABLE 3

Pediatric Orthopaedic Surgeons’ Predisposition to Treatment

Rater	Coefficient	Propensity for Surgical Treatment ^a	Risk Score ^b
1	0.15	Yes	2.50
2	0.24	Yes	2.67
3	0.19	Yes	2.17
4	0.06	Yes	2.67
5	0.24	Yes	3.17
6	–0.11	No	3.00
7	0.28	Yes	2.33
8	0.06	Yes	2.67
9	–0.33	No	2.83
10	–0.81	No	2.17
11	–0.37	No	2.50
12	–0.29	No	2.83
13	0.24	No	2.67
14	0.02	Yes	2.83
15	–0.15	No	2.50
16	–0.15	No	2.33
17	0.24	Yes	2.50
18	0.06	Yes	2.33
19	0.24	Yes	2.83
20	0.19	Yes	3.00
Risk score, mean ± SD (range)			2.63 ± 0.28 (2.17-3.17)
Participants preferring surgery, n (%)			13 (65.0)
Correlation between surgical propensity and risk score			r = 0.24

^a Preference of surgical over nonsurgical management in the included scenarios.

^b Risk assessment based on Jackson Personality Inventory Risk Taking subscale. Scores range from 1 to 4, with higher scores correspond to a greater likelihood/tolerance of taking risk.

Discussion

We conducted a discrete choice experiment and corresponding mixed-effect regression model that emphasize rater preferences and the importance of different included levels and factors based on random utility theory.^23,32 Although this analysis type has been used in examining other health care decision making,^23,32 it has not been used to study the variables that may affect pediatric orthopaedic surgeons’ management of tibial spine fractures. With a convenience sample of 20 pediatric orthopaedic surgeons, this study demonstrated that the presence of fracture displacement, as seen on plain knee radiographs, significantly influenced a surgeon’s decision to surgically treat type II tibial spine fractures (P < .001). Surgeons began favoring surgery at 3.5 mm of fracture displacement and were 28% more likely to treat the fracture operatively with each additional millimeter of displacement of the fracture fragment. Sex, age, mechanism of injury, and athletic level did not significantly influence the treatment strategy.

The tibial spine is the distal attachment site of the ACL, the primary restraint to anterior translation of the knee joint that provides >85% of total restraining force of the knee in flexion.²⁸ Management of tibial spine fractures is traditionally based on the Meyers and McKeever classification, with type I treated nonoperatively and types III and IV treated surgically. Controversy exists in the literature regarding whether type II fractures, the focus of this study, should be managed surgically or nonoperatively.^4,11,18

Nonoperative treatment usually involves closed reduction and immobilization in a long-leg cast with 20° of knee flexion, as originally advocated by Meyers and McKeever to minimize stress on the ACL during healing.^29,31 Others have advocated straight-leg casting, arguing improved fracture reduction from femoral condyle contact.^10,38 Regarding the prognosis of nonoperative treatment for type II fractures, Janarv et al¹⁴ showed in a small series that 75% of their patients treated nonoperatively had excellent Lysholm and Tegner score outcomes. A similar case series described 13 patients with no pain, swelling, disability, or instability at a mean postinjury follow-up of 3.5 years, although 4 patients had ACLs that were thinner or longer on magnetic resonance imaging.³⁶ Finally, a series of 15 type II fractures treated nonoperatively showed a mean 3.5 mm of anterior instability at final follow-up (mean, 4 years), despite patients having no symptoms.³⁷

Surgical treatment of tibial spine fractures is most commonly accomplished via arthroscopic reduction and internal fixation. Arthroscopic fixation has gained slight favor over open procedures in multiple reports, owing to a restoration of anatomic reduction and a reported reduction in long-term instability.^12,15,18,29 In all tibial spine fracture types, subsequent ACL laxity has been described in 10% of patients treated surgically, as opposed to 22% in patients treated nonoperatively.² Furthermore, risk of ACL reconstruction in the ipsilateral knee was reported to be greater in patients treated nonoperatively (10.0% vs 1.04%, P = .036).⁵ Type II fractures have been reported to have high rates of soft tissue entrapment, usually intermeniscal ligament or periosteum, which can increase risk of malunion and is often cited as justification for surgical management.^17,18,27 Louis et al¹⁹ described a series of 17 patients with type II fracture treated with open reduction and internal fixation (ORIF), with a mean follow-up of 3 years, who had no reduction in sports activities or instability and a mean Lysholm score of 99.7.

These studies demonstrate the conflicting opinions and literature regarding which treatment strategy is most preferable for type II tibial spine fractures, and our study reflects this variability among our respondents. Until larger trials are completed, perhaps the most pragmatic approach, an initial attempt at closed reduction, followed by surgery if unsuccessful, avoids surgical risks while optimizing fracture reduction.^9,11 Our study examined other factors that may influence pediatric orthopaedic surgeons to treat these fractures surgically versus nonsurgically.

Although age was not found to be an influential factor in surgeon decision making in our study, it has been shown that the odds of later ACL reconstruction increase by a factor of 1.3 for every year of increasing age at the time of tibial spine fracture in patients aged 5 through 18 years.²⁶ Interestingly, this conclusion was not found by Janarv et al¹⁴ in their series of pediatric tibial spine fractures, and they cautioned that growth disturbance remains a key risk of periphyseal orthopaedic surgery. In our study, patient sex also did not affect treatment choice. However, it can have a significant role in the severity of pediatric knee injuries, where girls are twice as likely to sustain knee injuries requiring surgery despite a higher overall rate of injury in boys.¹³ Sex of the patient may have a role in injury patterns as well, as females were 5.4 times more likely to have an ACL injury and twice as likely to sustain noncontact knee injuries as compared with males.^13,30

Although injury mechanisms did not affect treatment choice in our study, greater rates of arthrofibrosis have been described in the literature after high-energy mechanisms or the presence of concomitant soft tissue injuries.³³ Patients’ athletic level/sport also has been reported as a factor for treatment approach, where surgery may be deemed appropriate for higher-level athletes with injuries such as metatarsal fractures, rotator cuff tears, medial epicondyle fractures, and ACL ruptures.^8,34 It has even been shown in orthopaedic literature that football has the highest severe knee injury rate, followed by wrestling, girls’ basketball, and girls’ soccer.⁷ Despite these notions, our study found that neither patients’ primary sport nor injury mechanism affected surgeons’ treatment choice.

Fracture displacement was the only variable in our study that significantly influenced a surgeon’s decision to operatively manage the type II tibial spine fracture (P < .001). Surgeons began favoring surgery at 3.5 mm of fracture displacement, slightly larger than the lower limit of reported acceptable displacement of 3.0 mm for nonoperative treatment¹¹ and lower than the upper limit of reported acceptable displacement of 5.0 mm for nonoperative treatment.⁹ Our respondents were also 28% more likely to treat the fracture operatively with each additional millimeter of displacement of the fracture fragment. Outside these 2 studies and our own, the role of specific displacement measurement in tibial spine fracture treatment is overall scant in the literature and is a rich topic for future investigation.

This study has multiple limitations, despite its aim to identify variables affecting treatment choice for type II tibial spine fractures with a unique statistical model. First, our study was limited to a convenience sample of 20 academic surgeons with varied training backgrounds and institutions, which may have hindered our ability to detect smaller influential variables that may be detectable with a larger sample. We could not incorporate participant characteristics within the model, owing to a lack of statistical power, and the preponderance of respondents within the Northeast region may represent a geographic limitation. Second, the discrete choice experiment was limited to a dichotomous question, preventing differentiation of further treatment choice nuances, such as arthroscopic versus open approaches or the rationale behind surgeons’ decisions. Third, regarding the lack of correlation between risk score and predisposition to treatment, the JPI Risk Taking subscale may not be the best indicator of the role of surgeon personality on treatment decision making. Future similar studies with larger respondent populations could determine if any additional patient, fracture, or provider attributes influence treatment decisions. Finally, we recognize that the qualitative appearance of the physis is an important factor in treatment decision making versus age alone, and physeal appearances were blinded within our study.

Conclusion

There was substantial variation among pediatric orthopaedic surgeons when treating type II tibial spine fractures. The degree of fracture displacement was the only factor significantly affecting surgeons’ decision to operate. However, there is a lack of consensus in the literature regarding treatment of type II tibial spine fractures, and better treatment guidelines are needed to optimize patient outcomes. Learning about the current treatment preferences among surgeons, given different patient factors, highlights current variation in practice patterns and directs efforts toward promoting the most optimal treatment strategies.

Supplemental Material

Supplemental Material, Survey_(blinded) - Pediatric Type II Tibial Spine Fractures: Addressing the Treatment Controversy With a Mixed-Effects Model

Supplemental Material, Survey_(blinded) for Pediatric Type II Tibial Spine Fractures: Addressing the Treatment Controversy With a Mixed-Effects Model by Alexander J. Adams, Nathan N. O’Hara, Joshua M. Abzug, Julien T. Aoyama, Tibial Spine Research Group, Theodore J. Ganley, James L. Carey, Aristides I. Cruz, Henry B. Ellis, Peter D. Fabricant, Daniel W. Green, Benton E. Heyworth, Joseph A. Janicki, Mininder S. Kocher, John T.R. Lawrence, R. Jay Lee, Scott D. McKay, R. Justin Mistovich, Neeraj M. Patel, John D. Polousky, Jason T. Rhodes, Brant C. Sachleben, M. Catherine Sargent, Gregory A. Schmale, Kevin G. Shea and Yi-Meng Yen in Orthopaedic Journal of Sports Medicine

Footnotes

One or more of the authors has declared the following potential conflict of interest or source of funding: N.N.O. has stock/stock options in Arbutus Medical. J.M.A. has received consulting fees from Axogen, is a paid speaker/presenter for Axogen and Pacira Pharmaceuticals, has received honoraria from NDI Medical, and receives royalties from Springer Publishing. T.J.G. receives research support from Allosource and Vericel and has received educational support from Liberty Surgical and Arthrex. AOSSM checks author disclosures against the Open Payments Database (OPD). AOSSM has not conducted an independent investigation on the OPD and disclaims any liability or responsibility relating thereto.

Ethical approval for this study was waived by the Children’s Hospital of Philadelphia Institutional Review Board.

Full disclosures for the Tibial Spine Research Group: J.L.C. has received research support from Allosource, Anika Therapeutics, and Vericel; has received consulting fees from Vericel; and is a paid associate editor for the American Journal of Sports Medicine. A.I.C. has received educational support from Arthrex and receives royalties from the Journal of Bone and Joint Surgery–American. H.B.E. receives educational support from Pylant Medical; is a paid speaker/presenter for Pylant Medica, Smith & Nephew, and Synthes; and has received hospitality payments for Pylant Medical, Smith & Nephew, Arthrex, and Synthes. D.W.G. receives royalties from Arthrex, Pega Medical, and Wolters Kluwer Health–Lippincott Williams & Wilkins; has received consulting fees from Arthrex; is a paid speaker/presenter for Synthes; and has received hospitality payments from Arthrex and Synthes. B.E.H. has stock/stock options in Imagen Technologies, receives royalties from Springer Publishing, has received educational support from Kairos Surgical, and has received other financial/material support from Allosource and Vericel. J.A.J. has stock/stock options in Pfizer and is a paid speaker/presenter for Synthes. M.S.K. has received consulting fees from Best Doctors, OrthoPediatrics, Ossur, and Smith & Nephew; receives royalties from OrthoPediatrics, Ossur, Saunders/Mosby-Elsevier, and Wolters Kluwer Health–Lippincott Williams & Wilkins; and is a paid speaker/presenter for Smith & Nephew. J.T.R.L. receives royalties from Sawbones/Pacific Research Laboratories. R.J.L. has received research support from Arthrex and educational support from Arthrex and has grants/grants pending from Medtronic Sofamor Danek. R.J.M. has received consulting fees from OrthoPediatrics, has stock/stock options in Right Mechanics, and has received educational support from Arthrex. N.M.P. has received educational support from Liberty Surgical. J.D.P. has received consulting fees from the Joint Restoration Foundation, is a paid speaker/presenter for DePuy Orthopedics, and has grants/grants pending from Sanofi-Aventis. J.T.R. has received consulting fees from OrthoPediatrics. B.C.S. has grants/grants pending from and is a paid speaker/presenter for DJO. G.A.S. has received educational support from Arthrex and is a paid speaker/presenter for Sign Fracture Care International. K.G.S. has received research support from Allosource and Vericel, has received consulting fees from HealthTrust, is a paid speaker/presenter for DePuy Orthopaedics, has grants/grants pending from Sanofi-Aventis, and is an unpaid consultant for Clinical Data Solutions and SourceTrust. Y.-M.Y. has received consulting fees from OrthoPediatrics and Smith & Nephew and educational support from Kairos Surgical. AOSSM checks author disclosures against the Open Payments Database (OPD). AOSSM has not conducted an independent investigation on the OPD and disclaims any liability or responsibility relating thereto.

Supplemental Material

A Supplemental Figure for this article is available at

Appendix

TABLE A1

Treatment Choice by Case Vignette

	Raters, n (%)			Raters, n (%)
Case	Surgery	No Surgery	Case	Surgery	No Surgery
1	1 (5)	19 (95)	21	19 (95)	1 (5)
2	15 (75)	5 (25)	22	12 (60)	8 (40)
3	15 (75)	5 (75)	23	17 (85)	3 (15)
4	20 (100)	0 (0)	24	20 (100)	0 (0)
5	16 (80)	4 (20)	25	18 (90)	2 (10)
6	20 (100)	0 (0)	26	17 (85)	3 (15)
7	12 (60)	8 (40)	27	19 (95)	1 (5)
8	18 (90)	2 (10)	28	18 (90)	2 (10)
9	15 (75)	5 (25)	29	12 (60)	8 (40)
10	19 (95)	1 (5)	30	18 (90)	2 (10)
11	14 (70)	6 (30)	31	1 (5)	19 (95)
12	20 (20)	0 (0)	32	18 (90)	2 (10)
13	13 (65)	7 (35)	33	20 (100)	0 (0)
14	19 (95)	1 (5)	34	18 (90)	2 (10)
15	14 (70)	6 (30)	35	13 (65)	7 (35)
16	19 (95)	1 (5)	36	0 (0)	20 (100)
17	20 (100)	0 (0)	37	19 (95)	1 (5)
18	1 (5)	19 (95)	38	16 (80)	4 (20)
19	16 (80)	4 (20)	39	15 (75)	5 (25)
20	17 (85)	3 (15)	40	5 (25)	15 (75)

References

Adams

Talathi

Gandhi

Patel

Ganley

. Tibial spine fractures in children: evaluation, management, and future directions. J Knee Surg. 2018; 31(5): 374–381.

Aderinto

Walmsley

Keating

. Fractures of the tibial spine: epidemiology and outcome. Knee. 2008;15(3):164–167.

Ahn

Yoo

. Clinical outcome of arthroscopic reduction and suture for displaced acute and chronic tibial spine fractures. Knee Surg Sports Traumatol Arthrosc. 2005;13(2):116–121.

Beck

Patel

Ganley

. The pediatric knee: current concepts in sports medicine. J Pediatr Orthop B. 2014;23(1):59–66.

Bogunovic

Tarabichi

Harris

Wright

. Treatment of tibial eminence fractures: a systematic review. J Knee Surg. 2015;28(3):255–262.

Cheng

Pan

, et al. Physicians’ risk tolerance and head computed tomography use for pediatric patients with minor head injury [published online May 25, 2018]. Pediatr Emerg Care. doi:10.1097/PEC.0000000000001540

Darrow

Collins

Yard

Comstock

. Epidemiology of severe injuries among United States high school athletes: 2005-2007. Am J Sports Med. 2009;37(9):1798–1805.

Dua

Stein

O’Hara

, et al. Variation among pediatric orthopaedic surgeons when diagnosing and treating pediatric and adolescent distal radius fractures. J Pediatr Orthop. 2019;39(6):306–313.

Edmonds

Fornari

Dashe

Roocroft

King

Pennock

. Results of displaced pediatric tibial spine fractures: a comparison between open, arthroscopic, and closed management. J Pediatr Orthop. 2015;35(7):651–656.

10.

Hallam

Fazal

Ashwood

Ware

Glasgow

Powell

. An alternative to fixation of displaced fractures of the anterior intercondylar eminence in children. J Bone Joint Surg Br. 2002;84(4):579–582.

11.

Herman

Martinek

Abzug

. Complications of tibial eminence and diaphyseal fractures in children: prevention and treatment. J Am Acad Orthop Surg. 2014;22(11):730–741.

12.

Hunter

Willis

. Arthroscopic fixation of avulsion fractures of the tibial eminence: technique and outcome. Arthroscopy. 2004;20(2):113–121.

13.

Ingram

Fields

Yard

Comstock

. Epidemiology of knee injuries among boys and girls in US high school athletics. Am J Sports Med. 2008;36(6):1116–1122.

14.

Janarv

P-M

Westblad

Johansson

Hirsch

. Long-term follow-up of anterior tibial spine fractures in children. J Pediatr Orthop. 1995;15(1):63–68.

15.

Jung

Yum

Koo

. A new method for arthroscopic treatment of tibial eminence fractures with eyed Steinmann pins. Arthroscopy. 1999;15(6):672–675.

16.

Kocher

Foreman

Micheli

. Laxity and functional outcome after arthroscopic reduction and internal fixation of displaced tibial spine fractures in children. Arthroscopy. 2003;19(10):1085–1090.

17.

Kocher

Micheli

Gerbino

Hresko

. Tibial eminence fractures in children: prevalence of meniscal entrapment. Am J Sports Med. 2003;31(3):404–407.

18.

Lafrance

Giordano

Goldblatt

Voloshin

Maloney

. Pediatric tibial eminence fractures: evaluation and management. J Am Acad Orthop Surg. 2010;18(7):395–405.

19.

Louis

Guillaume

Launay

Toth

Jouvre

Bollini

. Surgical management of type II tibial intercondylar eminence fractures in children. J Pediatr Orthop B. 2008;17(5):231–235.

20.

Lubowitz

Elson

Guttmann

. Part II: arthroscopic treatment of tibial plateau fractures: intercondylar eminence avulsion fractures. Arthroscopy. 2005;21(1):86–92.

21.

Lubowitz

Grauer

. Arthroscopic treatment of anterior cruciate ligament avulsion. Clin Orthop Relat Res. 1993;294:242–246.

22.

Luhmann

. Acute traumatic knee effusions in children and adolescents. J Pediatr Orthop. 2003;23(2):199–202.

23.

Mangham

Hanson

McPake

. How to do (or not to do)…Designing a discrete choice experiment for application in a low-income country. Health Policy Plan. 2009;24(2):151–158.

24.

Meyers

McKeever

. Fracture of the intercondylar eminence of the tibia. J Bone Joint Surg Am. 1959;41(2):209–220.

25.

Meyers

McKeever

. Fracture of the intercondylar eminence of the tibia. J Bone Joint Surg Am. 1970;52(8):1677–1684.

26.

Mitchell

Mayo

Axibal

, et al. Delayed anterior cruciate ligament reconstruction in young patients with previous anterior tibial spine fractures. Am J Sports Med. 2016;44(8):2047–2056.

27.

Mitchell

Sjostrom

Mansour

, et al. Incidence of meniscal injury and chondral pathology in anterior tibial spine fractures of children. J Pediatr Orthop. 2015;35(2):130–135.

28.

Noyes

. The function of the human anterior cruciate ligament and analysis of single- and double-bundle graft reconstructions. Sports Health. 2009;1(1):66–75.

29.

Panni

Milano

Tartarone

Fabbriciani

. Arthroscopic treatment of malunited and nonunited avulsion fractures of the anterior tibial spine. Arthroscopy. 1998;14(3):233–240.

30.

Piasecki

Spindler

Warren

Andrish

Parker

. Intraarticular injuries associated with anterior cruciate ligament tear: findings at ligament reconstruction in high school and recreational athletes. An analysis of sex-based differences. Am J Sports Med. 2003;31(4):601–605.

31.

Prince

Laor

Bean

. MRI of anterior cruciate ligament injuries and associated findings in the pediatric knee: changes with skeletal maturation. AJR Am J Roentgenol. 2005;185(3):756–762.

32.

Ryan

Gerard

. Using discrete choice experiments to value health care programmes: current practice and future research reflections. Appl Health Econ Health Policy. 2003;2(1):55–64.

33.

Senekovic

Veselko

. Anterograde arthroscopic fixation of avulsion fractures of the tibial eminence with a cannulated screw: five-year results. Arthroscopy. 2003;19(1):54–61.

34.

van Yperen

Reijman

van Es

Bierma-Zeinstra

SMA

Meuffels

. Twenty-year follow-up study comparing operative versus nonoperative treatment of anterior cruciate ligament ruptures in high-level athletes. Am J Sports Med. 2018;46(5):1129–1136.

35.

Watts

Larson

Milbrandt

. Open versus arthroscopic reduction for tibial eminence fracture fixation in children. J Pediatr Orthop. 2016;36(5):437–439.

36.

Wilfinger

Castellani

Raith

Pilhatsch

Höllwarth

Weinberg

A-M

. Nonoperative treatment of tibial spine fractures in children—38 patients with a minimum follow-up of 1 year. J Orthop Trauma. 2009;23(7):519–524.

37.

Willis

Blokker

Stoll

Paterson

Galpin

. Long-term follow-up of anterior tibial eminence fractures. J Pediatr Orthop. 1993;13(3):361–364.

38.

Willis

Blokker

Stoll

Paterson

Galpin

. Long-term follow-up of anterior tibial eminence fractures. J Pediatr Orthop. 1993;13(3):361–364.

39.

Zaricznyj

. Avulsion fracture of the tibial eminence: treatment by open reduction and pinning. J Bone Joint Surg Am. 1977;59(8):1111–1114.

40.

Zhao

Huangfu

. Arthroscopic treatment of nonunited anterior cruciate ligament tibial avulsion fracture with figure-of-8 suture fixation technique. Arthroscopy. 2007;23(4):405–410.
