Immunohistochemical Detection of Protein Gene Product 9.5 (PGP 9.5) in Canine Epitheliotropic T-Cell Lymphoma (Mycosis Fungoides)

Abstract

Protein gene product 9.5 (PGP 9.5), a ubiquitin COOH-terminal hydrolase initially considered specific for neural and neuroendocrine tissues, is expressed in a variety of epithelial and mesenchymal tumors. During immunohistochemical evaluation of a cutaneous epitheliotropic T-cell lymphoma (mycosis fungoides [MF]) in a dog, strong reactivity for PGP 9.5 was observed. This unexpected result prompted us to examine PGP 9.5 immunoreactivity in 13 additional cases of canine mycosis fungoides. All tumors were confirmed as T-cell epitheliotropic lymphoma by histopathology and immunohistochemistry for CD3. Eight of 14 cases were positive for PGP 9.5, with reactivity mainly in the cytoplasm and less commonly in the nucleus. One case had strong reactivity in the cell membrane, sometimes with concurrent paranuclear staining. Immunoreactivity did not correlate with location (epidermal, dermal, and adnexal) of tumor cells. Disease outcome did not vary between PGP 9.5-positive and negative tumors. Although PGP 9.5 immunoreactivity in MF did not predict tumor behavior in these dogs, it has had prognostic value in certain human carcinomas. This unexpected staining of lymphocytes in mycosis fungoides with an antibody to PGP 9.5 demonstrates its presence in nonneuroendocrine tumors and precludes its use as the sole diagnostic marker in discrete cell tumors in the skin.

Keywords

CD3 CD79a dogs immunohistochemistry lymphoma mycosis fungoides pathology PGP 9.5

Protein gene product (PGP 9.5) is a 27-kDa protein originally isolated from the brain.¹⁵ A ubiquitin COOH-terminal hydrolase, PGP 9.5 forms part of the ubiquitin-proteasome system, a nonlysosomal proteolytic pathway involved in the regulation of cell growth, modulation of some membrane receptors, and turnover of cytoskeletal elements.^{12, 20, 33} Ubiquitin COOH-terminal hydrolases separate ubiquitin from its substrate during protein degradation in the proteasome, regulating protein catabolism.¹² The ubiquitin-proteasome pathway is involved in cancer-related deregulation.²⁸ PGP 9.5 expression has been implicated in tumor progression in non-small-cell lung cancer^{13, 24} and unfavorable outcome in pancreatic cancer.²⁹ PGP 9.5 was initially considered to be confined to neurons and neuroendocrine cells.³⁰ However, later studies detected PGP 9.5 in cells of the male genital system (epididymis, ejaculatory duct cells, spermatogonia, Leydig cells, prostatic secretory epithelium), female genital system (mammary epithelial cells, oocytes), skin (melanocytes, Langerhan's cells, Merkel cells, fibroblasts), and renal epithelial cells.^{2, 5, 7, 10, 14, 18, 19, 25, 26, 34} PGP 9.5 has also been detected in lymphocytes of germinal centers, occasional lymphocytes of interfollicular regions¹⁶ and thymic epithelial cells.³ Antibodies to PGP 9.5 are commonly used to characterize tumors of nervous (neuroblastoma, peripheral primitive neuroectodermal tumor, Ewing's sarcoma, malignant peripheral nerve sheath tumor, perineuroma, and neurofibroma) and neuroendocrine systems (melanoma, carcinoid, paraganglioma, and pheochromocytoma).^{4, 11, 22, 32} The sensitivity of PGP 9.5 for neural or neuroendocrine tumors is higher or similar to that of neuron-specific enolase or synaptophysin.^{11, 22} However, PGP 9.5 is no longer considered specific for neuronal or neuroendocrine tumors because it has been immunohistochemically detected in unrelated tumor types, particularly of mesenchymal origin⁴ and in several types of lymphoma.^{17, 27, 32}

Canine cutaneous epitheliotropic lymphoma (mycosis fungoides [MF]) is a T-cell lymphoma that shares many histologic features with its human counterpart. In dogs, MF pursues a progressive course of disease with several months to 2 years before death. MF neoplastic lymphocytes in humans and dogs are CD3-positive,^{9, 23} but canine neoplastic T cells are CD8-positive as opposed to CD4-positive in humans, except in some cases with aberrant expression of CD8.^{8, 9, 23} Although the presence of cerebroid cells is characteristic of MF in humans and animals, other lymphomas and some lymphocytes in dermatitis have similar nuclear features.²³ In dogs, the differential diagnosis for MF includes histiocytoma, round cell amelanotic melanoma, and Merkel cell tumor.⁹ During a routine diagnostic work-up of a cutaneous round cell tumor in a dog, we found strong positivity for PGP 9.5 in a tumor with some features of endocrine differentiation (e.g., packeting, high cellularity) but no reaction to other neuroendocrine markers and strong reaction to leukocytic markers, including CD3, confirming a diagnosis of mycosis fungoides. Because of this unexpected PGP 9.5 staining we decided to examine a group of cutaneous lymphomas (MF) to determine the degree of reactivity of an antibody to PGP 9.5 in neoplastic lymphocytes.

Methods

Fourteen cases of canine MF in the archives of the Animal Disease Diagnostic Laboratory-Purdue University diagnosed by histopathology and immunohistochemistry were selected in this study. Only excisional biopsies were examined. Slides and records were reviewed, and follow-up information obtained.

Surgical biopsies were fixed in neutral buffered formalin and embedded in paraffin. Four-micrometer-thick tissue sections were stained with HE. Immunohistochemical staining was done in an automatic stainer following previously reported protocols.²¹ The antibodies used were rabbit polyclonal antibody to CD3 (A0452, Dako, Carpinteria, CA), mouse monoclonal antibody to canine CD18 (CA 16.3C10, Dr. Moore, University of California-Davis), mouse monoclonal antibody to canine CD45 (CA12.10C12, Dr. Moore), mouse monoclonal antibody to CD79a (M7051, Dako), mouse monoclonal antibody to cytokeratins AE1/AE3 (M3515, Dako), mouse monoclonal antibody to Melan A (M7196, Dako), rabbit polyclonal antibody to PGP 9.5 (Z5116, Dako), rabbit polyclonal antibody to S100 (Z0311, Dako), and rabbit monoclonal antibody to synaptophysin (RM-9111, LabVision, Fremont, CA). Immunohistochemical staining for CD3, CD79a, and PGP 9.5 was done in all cases. Additional antibodies were used in individual cases to confirm leukocytic origin and to rule out other tumor types (e.g., melanoma, neuroendocrine carcinoma). There are no antibodies available to canine CD4 or CD8 reactive in formalin-fixed, paraffin-embedded tissues. Antigen retrieval was used as follows: pressure cooker with citrate buffer, pH 6.0 (CD3, CD45, CD18, cytokeratins, and S100); pressure cooker with EDTA buffer, pH 9.0 (CD79a, Melan A). Antibodies to PGP 9.5 and synaptophysin did not need antigen retrieval. The peroxidase-based detection systems used were LSAB2 (CD3, S100), LSAB+ (CD45, cytokeratins, synaptophysin), and ENVISION+ (CD18, CD79a, Melan A, PGP 9.5), all from Dako. Slides were counterstained with Mayer's hematoxylin. Immunoreactivity for PGP 9.5 was scored from 0 to 3 depending on the number of positive neoplastic cells: 3, >75% positive cells; 2, 30 to 74% positive cells; 1, 10 to 29% positive cells; 0, <10% positive cells. Location of the PGP 9.5 was recorded as cytoplasmic membrane, cytoplasmic, paranuclear, or nuclear reaction. To determine the specificity of the reaction, the primary antibody was replaced with commercially available negative control reagent containing rabbit immunoglobulins (Dako, N1699) for polyclonal antibodies or mouse immunoglobulins (Dako, N1698) for monoclonal antibodies. Positive controls for each antibody (e.g., normal canine lymph node for leukocytic markers and normal canine adrenal gland for PGP 9.5) were also included.

Results

Clinical data are summarized in Table 1. The age of the dogs ranged from 1.5 to 14 years (8.5 years on average). Eight dogs were male and six were female. A variety of medium-sized or small breeds were represented. The lesions were located in multiple cutaneous sites (8 cases), solitary (2 cases), and the lips or oral cavity (4 cases). One animal had only oral lesions. Lesions consisted of masses (10 cases), patches, plaques, ulcers, or pustules (1 case each). In only 2 cases was there a clinical diagnosis of MF with the rest considered to be dermatitis, sebaceous adenitis, or other tumors. The time between the onset of clinical signs and the biopsy ranged from 1 week to 6 months. Only 1 animal remained alive 7 months after diagnosis. The other animals were euthanized because of disease progression or died of undetermined causes 1 week to 1 year after the diagnosis. Four animals were lost to follow-up. Three animals were treated with chemotherapy. Twelve cases had the classical tumor stage form of MF with neoplastic cells infiltrating the epidermis, dermis, and subcutis (Fig. 1).⁹ The other 2 dogs had the pagetoid reticulosis form characterized by neoplastic lymphocytes confined to the epidermis and adnexal structures.⁹ One case had several lesions in the tumor stage and 1 lesion consistent with pagetoid reticulosis. In all cases more than 90% of neoplastic lymphocytes were reactive with antibody to CD3, highlighting their intraepithelial and intrafollicular location (Fig. 2). None of these cases reacted with antibody to CD79a. PGP 9.5 immunoreactivity on the neoplastic cells was present in 8 cases (57%), being strong in 5 cases, weak in 3 cases, and not detected in 6 cases. PGP 9.5 antigen was usually diffuse in the cytoplasm with fewer cells having strong nuclear staining (Figs. 3–6). In only 1 dog (case No. 12) was staining distinctly in the cell membrane with the cytoplasm less intensely stained. Paranuclear staining was also seen in several areas in this case, sometimes combined with cell membrane and cytoplasmic stain. Nuclear stain was not seen in this case (Figs. 7–8). PGP 9.5 staining was observed at all levels of the neoplastic growth (intraepidermal/intramucosal, intrafollicular, dermal/submucosal) although the intensity of the reaction sometimes varied within a tumor. We did not observe significant differences in the outcome between positive and negative tumors to PGP 9.5 in our series.

Fig. 1.

Skin; dog, case No. 8. Epitheliotropic lymphoma. Neoplastic cells infiltrate the epidermis. HE. Bar = 100 μm.

Fig. 2.

Skin; dog, case No. 8. Epitheliotropic lymphoma. Strong reactivity for CD3 in the epidermis and dermis. LSAB2-peroxidase immunohistochemistry for CD3, Mayer's hematoxylin counterstain. Bar = 200 μm.

Fig. 3.

Skin; dog, case No. 8. Epitheliotropic lymphoma. The pattern of staining for PGP 9.5 is similar to that for CD3. ENVISION+-peroxidase immunohistochemistry for PGP 9.5, Mayer's hematoxylin counterstain. Bar = 200 μm.

Fig. 4.

Skin; dog, case No. 8. Epitheliotropic lymphoma. Numerous intraepithelial lymphocytes are positive for PGP 9.5. ENVISION+-peroxidase immunohistochemistry for PGP 9.5, Mayer's hematoxylin counterstain. Bar = 50 μm.

Fig. 5.

Skin; dog, case No. 3. Epitheliotropic lymphoma. A dermal lymphoid infiltrate is diffusely positive for PGP 9.5. ENVISION+-peroxidase immunohistochemistry for PGP 9.5, Mayer's hematoxylin counterstain. Bar = 100 μm.

Fig. 6.

Skin; dog, case No. 5. Epitheliotropic lymphoma. Strong nuclear and cytoplasmic immunoreactivity. ENVISION+-peroxidase immunohistochemistry for PGP 9.5, Mayer's hematoxylin counterstain. Bar = 50 μm.

Fig. 7.

Skin; dog, case No. 12. Epitheliotropic lymphoma. Infiltrating lymphocytes in the epidermis and dermis have PGP 9.5 immunoreactivity. ENVISION+-peroxidase immunohistochemistry for PGP 9.5, Mayer's hematoxylin counterstain. Bar = 200 μm.

Fig. 8.

Skin; dog, case No. 12. Epitheliotropic lymphoma. Distinct cell membrane staining in most cells. Many cells also have paranuclear staining. ENVISION+-peroxidase immunohistochemistry for PGP 9.5, Mayer's hematoxylin counterstain. Bar = 50 μm. Inset: Detail of membrane staining. Bar = 10 μm.

Table 1.

Summary of clinical data, histologic type, PGP 9.5 staining, and outcome in 14 dogs.


Case No.	Breed	Sex∗	Age (years)	Location	Histologic Type†	PGP 9.5‡	Postdiagnosis Survival (months)§

1	Boxer	MN	7	Multiple: pinna, trunk mucocutaneous	PR	1+	1
2	Pembroke Welsh Corgi	M	11	Two masses, oral	CTF	Neg	2
3	Dachshund	MN	9	Multiple skin masses	CTF	1+	1
4	Mixed	FS	14	Eyelid	CTF	Neg	12
5	Boxer	M	8.5	Multiple skin masses	CTF	3+	ND
6	Mixed	M	7.5	Multiple skin masses	PR	1+	ND
7	Mixed	FS	6	Lip, oral	CTF	Neg	ND
8	Boston Terrier	M	11	Lip, oral	CTF	3+	7
9	Schnauzer	M	12	Multiple skin masses	CTF	3+	1
10	West Highland White Terrier	FS	7	Lip	CTF	Neg	Alive 7 months
11	Boxer	FS	5	Ventral abdomen	CTF	Neg	0.25
12	Labrador Retriever	FS	9	Multiple: trunk and limbs	CTF	3+	3
13	Boxer	M	1.5	Multiple: trunk and limbs	CTF	3+	ND
14	Mixed	FS	11	Multiple: foot and nasal planum	CTF	Neg	1.5

∗

MN = male neutered; M = male; FS = female spayed.

†

PR = pagetoid reticulosis; CTF = classic tumor form.

‡

Neg = negative.

ND = not determined.

Discussion

MF is an uncommon cutaneous disease of dogs.⁹ Oral involvement is even less common and rarely reported.¹ However, 1 of the 14 cases in our series had only oral involvement. Human MF with primary oral involvement or secondary to cutaneous disease is also uncommon.^{6, 31} To our knowledge, there are no reports examining PGP 9.5 immunoreactivity in epitheliotropic T-cell lymphomas. Some researchers have detected PGP 9.5 in lymphocytes and their tumors,^{16, 17, 27, 32} with only one group observing PGP 9.5 immunoreactivity in T-cell lymphomas.¹⁷ In one study, PGP 9.5 was detected in most (98%) mantle cell lymphomas with fewer cases (58%) and weaker reactivity in B-small lymphocytic lymphoma.²⁷ In another study PGP 9.5 was detected in centrocytic lymphoma, lymphoblastic lymphoma, immunoblastic lymphoma, and pleomorphic large T-cell lymphomas.¹⁷ PGP 9.5 has also been reported in anaplastic large cell lymphoma.³² It is interesting that some authors report PGP 9.5 immunoreactivity in lymphocytes and their tumors only after heat-induced epitope retrieval (HIER).^{16, 17} In our case we did not use antigen retrieval because during standardization of the procedure following a published protocol²¹ we observed more background with HIER than with no antigen retrieval at all; enzymatic retrieval did not demonstrate any reactivity. This disparity may reflect use of different PGP 9.5 polyclonal antibodies in those studies.^{16, 17, 27} The cause of immunoreactivity of PGP 9.5 in MF or other nonneuroendocrine tumors is unknown. Two possible explanations have been given: 1) cross-reactivity of the antibody with epitopes in other ubiquitin hydrolases, or 2) abnormal upregulation of PGP 9.5 in mesenchymal and lymphoid neoplasms.⁴

The clinical significance of our findings is undetermined. Immunohistochemical staining with PGP 9.5 has been used to predict tumor progression in human lung cancer^{13, 24} and the outcome in pancreatic cancer.²⁹ However, PGP 9.5 immunoreactivity was not associated with type or grade of human lymphoma.¹⁷ MF in dogs is usually fatal with little improvement in the outcome regardless of the chemotherapy protocol.⁹ Our results are in line with multiple reports in humans indicating the wide range of cell types and tumors that may express PGP 9.5^{2, 4, 5, 7, 10, 14, 17–} ^{19, 25–} ^{27, 32, 34} despite the early claims that PGP 9.5 was a specific marker of neural and neuroendocrine tissues.³⁰ This unexpected staining of MF with an antibody to PGP 9.5 highlights the need of a wide variety of cell markers to characterize some cases of discrete cell tumors (e.g., leukocytic, endocrine, melanocytic) in the skin. Further validation studies are needed to determine the expression of PGP 9.5 in canine nonendocrine tumors. Because MF in humans and dogs share many similarities it is expected that some human epitheliotropic lymphomas will show reactivity to PGP 9.5.

Footnotes

Acknowledgements

We appreciate the technical expertise of Dee DuSold in performing immunohistochemistry and Drs. A. Abbo, D. Bevier, S. Borter, G. Boyd, E. Greene, M. Hohenstein, P. Jackson, J. Lortie, L. Mehringer, D. Morgan, R. Rudolph, D. Turmail, and A. Zwingleberg for submitting the biopsy specimens and providing follow-up information.

References

1 Ackerman

: Oral T cell-like lymphoma in a dog. J Amer Anim Hosp Assoc 20: 955–958, 1984

2 Aumuller

Renneberg

Leonhardt

Lilja

Abrahamson

: Localization of protein gene product 9.5 immunoreactivity in derivatives of the human Wolfian duct and in prostate cancer. Prostate 38: 261–267, 1999

3 Brelińiska

Ostalska

Zabel

: Subtypes of thymic epithelial cells defined by neuroendocrine markers. Histochem Cell Biol 114: 239–244, 2000

4 Campbell

Thomas

Lamps

Smoller

Folpe

: Protein gene product 9.5 is not a specific marker of neural and nerve sheath tumors: An immunohistochemical study of 95 mesenchymal neoplasms. Mod Pathol 16: 963–969, 2003

5 D'Andrea

Malinovsky

Berni

Biancari

Biassoni

Di Matteo

Corbellini

Falvo

Santoni

Spyrou

De Antoni

: The immuno-localization of PGP 9.5 in normal human kidney and renal cell carcinoma. G Chir 18: 521–524, 1997

6 De la Fuente

Rodriguez-Peralto

Ortiz

Barrientos

Vanaclocha

Iglesias

: Oral involvement in mycosis fungoides: report of two cases and a literature review. Acta Dermatol Venereol 80: 299–301, 2000

7 Diomedi-Camascci

Ravà

Lerut

Callea

Van Damme

: Protein gene product 9.5 and ubiquitin are expressed in metabolically active epithelial cells of normal and pathologic human kidney. Nephrol Dial Transplant 20: 2714–2719, 2005

8 Fletcher

CDM

: Mycosis fungoides. In: Diagnostic Histopathology of Tumors, ed. Fletcher

CDM

, 2nd ed., pp. 1440–1442. Churchill Livingstone, London, 2002

9 Gross

Ihrke

Walder

Affolter

: Epitheliotropic lymphoma. In: Skin Diseases of the Dog and Cat, ed. Gross

Ihrke

Walder

Affolter

, 2nd ed., pp. 876–883. Blackwell, Oxford, 2005

10.

10 Hamzeh

Gaudillère

Sabido

Tchou

Lambert

Schmitt

Genin

Misery

: Expression of PGP9.5 on Langerhan's cells and their precursors. Acta Derm Venereol 80: 14–16, 2000

11.

11 Harris

Moore

Steart

Weller

: Protein gene product (PGP) 9.5 as a reliable marker in primitive neuroectodermal tumours. An immuno-histochemical study of 21 childhood cases. Histopathology 16: 271–277, 1990

12.

12 Hershko

Ciechanover

Varshavsky

: The ubiquitin system. Nat Med 6: 1073–1081, 2000

13.

13 Hibi

Westra

Borges

Goodman

Sidransky

Jen

: PGP9.5 as a candidate tumor marker for non-small-cell lung cancer. Am J Pathol 155: 711–715, 1999

14.

14 Hilliges

Hellman

Ahlstrom

Johansson

: Immunohistochemical studies of neurochemical markers in normal human buccal mucosa. Histo-chemistry 101: 235–244, 1994

15.

15 Jackson

Thompson

: The demonstration of new human brain-specific proteins by high-resolution two-dimensional polyacrylamide gel electrophoresis. J Neurol Sci 49: 429–438, 1981

16.

16 Langlois

NEI

King

Herriot

Thompson

: Non-enzymatic retrieval of antigen permits staining of follicle centre cells by the rabbit polyclonal antibody to protein gene product 9.5. J Pathol 173: 249–253, 1994

17.

17 Langlois

NEI

King

Herriot

Thompson

: An evaluation of the staining of lymphomas and normal tissues by the rabbit polyclonal antibody to protein gene product 9.5 following non-enzymatic retrieval of antigen. J Pathol 175: 433–439, 1995

18.

18 Martin

Fraile

Peinado

Arenas

Elices

Alonso

Paniagua

Martin

Santamaria

: Immunohistochemical localization of protein gene product 9.5, ubiquitin, and neuropeptide Y immunoreactivities in epithelial and neuroendocrine cells from normal and hyperplastic human prostate. J Histochem Cytochem 48: 1121–1130, 2000

19.

19 Olerud

Chiu

Usui

Gibran

Ansel

: Protein gene product 9.5 is expressed by fibroblasts in human cutaneous wounds. J Invest Dermatol 111: 565–572, 1998

20.

20 Pickart

: Back to the future with ubiquitin. Cell 116: 181–190, 2004

21.

21 Ramos-Vara

Beissenherz

: Optimization of immunohistochemical methods using two different antigen retrieval methods on formalin-fixed, paraffin-embedded tissues: experience with 63 markers. J Vet Diag Invest 12: 307–311, 2000

22.

22 Rode

Dhillon

Doran

Jackson

Thompson

: PGP 9.5, a new marker for human neuroendocrine tumours. Histopathology 9: 147–158, 1985

23.

23 Rosai

: Mycosis fungoides and related peripheral T-cell lymphomas. In: Rosai and Ackerman's Surgical Pathology, ed. Rosai

, 9th ed., pp. 197–199. Mosby, Edinburgh, UK, 2004

24.

24 Santamaria

Martin

Paniagua

Fraile

Nistal

Terenghi

Polak

: Protein gene product 9.5 and ubiquitin immunoreactivities in rat epididymis epithelium. Histochemistry 100: 131–138, 1993

25.

25 Sasaki

Yukiue

Moriyama

Kobayasho

Nakashima

Kaji

Fukai

Kiriyama

Fujii

: Expression of the protein gene product 9.5, PGP9.5, is correlated with T-status in non-small cell lung cancer. Jpn J Clin Oncol 31: 532–535, 2001

26.

26 Schumacher

Mitchell

Kaiserling

: The neuronal marker protein gene product 9.5 (PGP 9.5) is phenotypically expressed in human breast epithelium, in milk, and in benign and malignant breast tumors. DNA Cell Biol 13: 839–843, 1994

27.

27 Singh

Wright

: The value of immunohisto-chemistry on paraffin wax embedded tissue sections in the differentiation of small lymphocyte and mantle cell lymphomas. J Clin Pathol 50: 16–21, 1997

28.

28 Spataro

Norbury

Harris

: The ubiquitin-proteasome pathway in cancer. Br J Cancer 77: 448–455, 1998

29.

29 Tezel

Hibi

Nagasaka

Nakao

: PGP9.5 as a prognostic factor in pancreatic cancer. Clin Cancer Res 6: 4764–4767, 2000

30.

30 Thompson

Doran

Jackson

Dhillon

Rode

: PGP 9.5- a new marker for vertebrate neurons and neuroendocrine cells. Brain Res 278: 224–228, 1983

31.

31 Wain

Setterfield

Judge

Harper

Pemberton

Russell-Jones

: Mycosis fungoides involving the oral mucosa in a child. Clin Exp Dermatol 28: 499–501, 2003

32.

32 Wang

Einhorn

Triche

Seeger

Reynolds

: Expression of protein gene product 9.5 and tyrosine hydroxylase in childhood small round cell tumors. Clin Cancer Res 6: 551–558, 2000

33.

33 Wilkinson

Lee

Deshpande

Duerksen-Hughes

Boss

Pohl

: The neuron-specific protein PGP 9.5 is a ubiquitin carboxyl-terminal hydrolase. Science 246: 670–673, 1989

34.

34 Wilson

Barber

Hamid

Power

Dhillon

Rode

Day

Thompson

Polak

: The immunolocalization of protein gene product 9.5 using rabbit polyclonal and mouse monoclonal antibodies. Br J Exp Pathol 69: 91–104, 1988
