On a discrete scheme for time fractional fully nonlinear evolution equations

Abstract

We introduce a discrete scheme for second order fully nonlinear parabolic PDEs with Caputo’s time fractional derivatives. We prove the convergence of the scheme in the framework of the theory of viscosity solutions. The discrete scheme can be viewed as a resolvent-type approximation.

Keywords

Approximation to solutions Caputo’s time fractional derivatives second order fully nonlinear equations viscosity solutions

1. Introduction

In this paper, we are concerned with the second order fully nonlinear PDEs with Caputo’s time fractional derivatives:

where $α \in (0, 1)$ is a given constant, $u : R^{n} \times [0, \infty) \to R$ is an unknown function and $D u$ and $D^{2} u$ , respectively, denote its spatial gradient and Hessian of u. We always assume that $u_{0} \in BUC (R^{n})$ , which denotes the space of all bounded uniformly continuous functions in $R^{n}$ . We denote Caputo’s time fractional derivative by $\partial_{t}^{α} u$ , i.e., $\begin{matrix} \partial_{t}^{α} u (x, t) : = \frac{1}{Γ (1 - α)} \int_{0}^{t} {(t - s)}^{- α} \partial_{s} u (x, s) d s, \end{matrix}$ where Γ is the Gamma function.

We assume that F is a continuous degenerate elliptic operator, that is, $\begin{matrix} F (x, t, p, X_{1}) ⩽ F (x, t, p, X_{2}) \end{matrix}$ for all $x \in R^{n}, t ⩾ 0, p \in R^{n}$ and $X_{1}, X_{2} \in S^{n} with X_{1} ⩾ X_{2}$ , where $S^{n}$ denotes the space of $n \times n$ real symmetric matrices. Moreover, throughout this work we assume that F is locally bounded in the sense that $\begin{matrix} (1.3) & M_{R} : = sup_{\begin{array}{c} (x, t) \in R^{n} \times [0, \infty) \\ | p |, | X | ⩽ R \end{array}} | F (x, t, p, X) | < \infty for any R > 0 . \end{matrix}$

Studying differential equations with fractional derivatives is motivated by mathematical models that describe diffusion phenomena in complex media like fractals, which is sometimes called anomalous diffusion (see [13] for instance). It has inspired further research on numerous related topics. We refer to a non-exhaustive list of references [1,2,5,6,9,11,12,14,17,18] and the references therein.

Among these results, the authors of [1,2] mainly study regularity of solutions to a space-time nonlocal equation with Caputo’s time fractional derivative in the framework of viscosity solutions. More recently, the existence of unique viscosity solutions to the initial value problem with Caputo’s time fractional derivatives has been established in the thesis of Namba [15] and independently and concurrently by Topp and Yangari [18]. The main part of [15] on this subject has been published in [9,14]. For example, a comparison principle, Perron’s method, and stability results for (1.1) in bounded domains with various boundary conditions have been established in [9,14]. Similar results for whole space has been established in [18] for nonlocal parabolic equations. Existence, uniqueness and regularity of classical solutions to time-fractional viscous Hamilton–Jacobi equations are recently studied in [4].

Motivated by these works, in this paper we introduce a discrete-in-time scheme for (1.1), (1.2), which will be explained in details in the subsection below. Our scheme is naturally and simply defined from the definition of Caputo’s time fractional derivatives, and turns out to be monotone. Note that for usual elliptic and parabolic equations it is by now well-known that the monotone scheme converges (see [3,16] for instance). For example, it is well known that an implicit Euler scheme for parabolic equation converges in [3]. However, the existing theory does not yield the convergence of our scheme. In Section 3, we prove the convergence of the scheme by carefully handling the term coming from the time-fractional derivative.

Finally it is worth to point out that our scheme is not only natural but also possibly useful to compare with several definitions of solutions to equations having fractional time derivative especially for linear equations in [11,17,19] for which notions of weak solutions defined by integration by parts are available, since the argument is based on the standard elliptic theory.

1.1. The discrete scheme

Our scheme is naturally derived from the definitions of Riemann integral and Caputo’s time fractional derivative. We first observe that $\begin{array}{l} \partial_{t}^{α} u (x, m h) & = \frac{1}{Γ (1 - α)} \int_{0}^{m h} {(m h - s)}^{- α} \partial_{s} u (x, s) d s \\ = \frac{1}{Γ (1 - α)} \sum_{k = 0}^{m - 1} \int_{k h}^{(k + 1) h} {(m h - s)}^{- α} \partial_{s} u (x, s) d s \end{array}$ for $x \in R^{n}$ , $m \in N$ and $h > 0$ . If u is smooth in $R^{n} \times [0, \infty)$ and h is small, then we can approximately think that $\begin{array}{l} \int_{k h}^{(k + 1) h} {(m h - s)}^{- α} \partial_{s} u (x, s) d s \\ \approx \int_{k h}^{(k + 1) h} {(m h - s)}^{- α} \frac{u (x, (k + 1) h) - u (x, k h)}{h} d s . \end{array}$ Note that $z Γ (z) = Γ (z + 1)$ and $\begin{array}{l} \int_{k h}^{(k + 1) h} {(m h - s)}^{- α} d s & = \frac{1}{1 - α} ({((m - k) h)}^{1 - α} - {((m - k - 1) h)}^{1 - α}) \\ = \frac{1}{1 - α} f (m - k) h^{1 - α}, \end{array}$ where we set $\begin{matrix} (1.4) & f (r) : = r^{1 - α} - {(r - 1)}^{1 - α} for r ⩾ 1 . \end{matrix}$ Thus, $\begin{array}{l} \partial_{t}^{α} u (\cdot, m h) & \approx \frac{1}{Γ (2 - α) h^{α}} \sum_{k = 0}^{m - 1} f (m - k) (u (x, (k + 1) h) - u (x, k h)) \\ = \frac{1}{Γ (2 - α) h^{α}} {u (x, m h) - \sum_{k = 0}^{m - 1} C_{m, k} u (x, k h)}, \end{array}$ where we set $\begin{matrix} C_{m, 0} : = f (m), C_{m, k} : = f (m - k) - f (m - (k - 1)) for k = 1, \dots, m - 1 . \end{matrix}$ Since f is a non-increasing function, we easily see that $\begin{matrix} (1.5) & C_{m, k} ⩾ 0 for k = 0, \dots, m - 1, \end{matrix}$ which implies monotonicity of the scheme (see Proposition 2.1).

Inspired by this observation, for any fixed $h > 0$ , we below define a family of functions ${U^{h} (\cdot, m h)}_{m \in N \cup {0}} \subset BUC (R^{n})$ by induction. Set $U^{h} (\cdot, 0) : = u_{0}^{h}$ , where $u_{0}^{h} \in BUC (R^{n})$ satisfies $\begin{matrix} (1.6) & sup_{R^{n}} | u_{0}^{h} - u_{0} | \to 0 as h \to 0 . \end{matrix}$ Let $U^{h} (\cdot, m h) \in C (R^{n})$ for $m ⩾ 1$ be the viscosity solution of $\begin{matrix} (1.7) & \frac{1}{Γ (2 - α) h^{α}} {u (x) - \sum_{k = 0}^{m - 1} C_{m, k} U^{h} (x, k h)} + F (x, m h, D u, D^{2} u) = 0 in R^{n} . \end{matrix}$ Let us emphasize here that the equation (1.7) is an (degenerate) elliptic problem with the elliptic operator strictly monotone in u. In fact, for any $m ⩾ 1$ the elliptic equation is of the form $\begin{matrix} (1.8) & λ u (x) + F (x, t, D u, D^{2} u) = g (x) in R^{n}, \end{matrix}$ where $t = m h$ , $λ > 0$ and $g \in BUC (R^{n})$ . We can obtain such a unique viscosity solution $U^{h} (\cdot, m h) \in BUC (R^{n})$ to (1.7) for any $m \in N$ under appropriate assumptions on F.

Define the function $u^{h} : R^{n} \times [0, \infty) \to R$ by $\begin{matrix} (1.9) & u^{h} (x, t) : = U^{h} (x, m h) for each x \in R^{n}, t \in [m h, (m + 1) h), m \in N \cup {0} . \end{matrix}$ Our main result of this paper is to show the convergence of $u^{h}$ to the unique viscosity solution of (1.1)–(1.2).

We remark that our scheme can be regarded as a resolvent-type approximation. Recall the implicit Euler scheme for the differential equation: $\begin{matrix} u_{t} + F [u] : = u_{t} + F (x, t, D u, D^{2} u) = 0, \end{matrix}$ which is given by $\begin{matrix} u^{h} (\cdot, m h) - u^{h} (\cdot, (m - 1) h) + h F [u^{h} (\cdot, m h)] = 0 (m \in N) . \end{matrix}$ This is a typical scheme by approximating u by a function $u^{h}$ piecewise linear in time with time grid length h. The resulting equation is a resolvent type equation for $u^{h} (\cdot, m h)$ if $u^{h} (\cdot, (m - 1) h)$ is given. It is elliptic if the original equation is parabolic.

1.2. Main results

We first give an abstract framework on the convergence of $u^{h}$ .

Theorem 1.1 (Scheme convergence).

Assume that ( 1.3 ) and the following two conditions hold.

For any $g \in BUC (R^{n})$ , there exists a viscosity solution $u \in BUC (R^{n})$ to ( 1.8 ) for any $t > 0$ . Moreover, if $u, v \in BUC (R^{n})$ are, respectively, a subsolution and a supersolution of ( 1.8 ) with any fixed $t > 0$ , then $u ⩽ v$ in $R^{n}$ .

Let $u \in USC (R^{n} \times [0, \infty))$ and $v \in LSC (R^{n} \times [0, \infty))$ be, respectively, a sub- and a supersolution of ( 1.1 ). Assume u and v are bounded in $R^{n} \times [0, T)$ for any $T > 0$ . If $u (\cdot, 0) ⩽ v (\cdot, 0)$ in $R^{n}$ , then $u ⩽ v$ in $R^{n} \times [0, \infty)$ .

Let

u^{h}

be given by ( 1.9 ) for any

h > 0

, where initial data

u_{0}^{h}

is assumed to fulfill ( 1.6 ). Then,

u^{h} \to u

locally uniformly in

R^{n} \times [0, \infty)

h \to 0

, where u is the unique viscosity solution to ( 1.1 )–( 1.2 ).

We obtain the following corollary of Theorem 1.1 under more explicit sufficient conditions of (H1) and (H2).

Corollary 1.2.
Assume that ( 1.3 ) and the following two conditions hold.
There exists a modulus of continuity $ω : [0, \infty) \to [0, \infty)$ such that $\begin{matrix} F (x, t, μ (x - y), Y) - F (y, t, μ (x - y), X) ⩽ ω (| x - y | (μ | x - y | + 1)) \end{matrix}$ for all $μ > 0$ , $x, p \in R^{n}$ , $t ⩾ 0$ and $X, Y \in S^{n}$ satisfying $\begin{matrix} (\begin{matrix} X & 0 \\ 0 & - Y \end{matrix}) ⩽ μ (\begin{matrix} I & - I \\ - I & I \end{matrix}) . \end{matrix}$

There exists a modulus of continuity $\tilde{ω} : [0, \infty) \to [0, \infty)$ such that $\begin{matrix} | F (x, t, p, X) - F (x, t, q, Y) | ⩽ \tilde{ω} (| p - q | + | X - Y |) \end{matrix}$ for all $x \in R^{n}$ , $t ⩾ 0$ , $p, q \in R^{n}$ and $X, Y \in S^{n}$ .
Then, the conclusion of Theorem 1.1 holds.
Remark 1.
The assumption (F2) can be removed in the presence of periodic boundary condition, that is, $x \mapsto u_{0} (x)$ and $x \mapsto F (x, t, p, X)$ are periodic with the same period. Recall that in a bounded domain or with the periodic boundary condition, (H1) is established in [7] and (H2) is available in [9, Theorem 3.1], [14, Theorem 3.4] under (F1).

The comparison result in (H1) under (F1), (F2) in an unbounded domain is due to [10]. Existence of solutions in this case can be obtained by Perron’s method. In fact, thanks to (1.3) with $R = 0$ , we can take $C > 0$ large such that C and $- C$ are, respectively, a supersolution and a subsolution of (1.8). We then can prove the existence of solutions by adopting the standard argument in [7,8]. In addition, as shown in [18], (H2) is also guaranteed by (F1) and (F2).

Our results above apply to a general class of nonlinear parabolic equations. We refer the reader to [7, Example 3.6] for concrete examples of F that satisfy our assumptions, especially the condition (F1).

Finally, it is worthwhile to mention that the idea for a discrete scheme in this paper can be adopted to handle a more general type of time fractional derivatives as in [5,6], provided that the comparison theorems can be obtained. In this paper, we choose Caputo’s time fractional derivatives to simplify the presentation.

This paper is organized as follows. In Section 2, we give the monotonicity and boundedness of discrete schemes. Section 3 is devoted to the proof of Theorem 1.1.
2. Preparations

We first recall the definition of viscosity solutions to (1.1).

Definition 1 (Definition of viscosity solutions).

For any $T > 0$ , a function $u \in USC (R^{n} \times [0, T))$ (resp., $u \in LSC (R^{n} \times [0, T))$ ) is called a viscosity subsolution (resp., supersolution) of (1.1) if for any $ϕ \in C^{2} (R^{n} \times [0, T))$ one has $\begin{matrix} (2.1) & \partial_{t}^{α} ϕ (x_{0}, t_{0}) + F (x_{0}, t_{0}, D ϕ (x_{0}, t_{0}), D^{2} ϕ (x_{0}, t_{0})) ⩽ (resp., ⩾) 0 \end{matrix}$ whenever $u - ϕ$ attains a local maximum (resp., minimum) at $(x_{0}, t_{0}) \in R^{n} \times (0, T)$ .

We call $u \in C (R^{n} \times [0, T))$ a viscosity solution of (1.1) if u is both a viscosity subsolution and a supersolution of (1.1).

Remark 2.
Our definition essentially follows [14, Definition 2.2]. In fact, since $\begin{matrix} (2.2) & \partial_{t}^{α} ϕ (x, t) = \frac{1}{Γ (1 - α)} (\frac{ϕ (x, t) - ϕ (x, 0)}{t^{α}} + α \int_{0}^{t} \frac{ϕ (x, t) - ϕ (x, s)}{{(t - s)}^{1 + α}} d s) \end{matrix}$ for any $ϕ \in C^{1} (R^{n} \times [0, \infty))$ , our definition is thus the same as [14, Definition 2.2]. A similar definition of viscosity solutions is cocurrently and independently proposed in [18, Definition 2.1] for general space-time nonlocal parabolic problems.

Another possible way to define sub- or supersolutions is to separate the term $\partial_{t}^{α} ϕ (x, t)$ in (2.1) into two parts like (2.2) and replace ϕ in one or both of the parts by u. See [18, Definition 2.1] and [9, Definition 2.5]. Such definitions are proved to be equivalent to Definition 1. We refer to [18, Lemma 2.3] and [14, Proposition 2.5] for proofs. Note that the original definition of viscosity solutions in [9,15] looks stronger but it turns out that it is the same [15, Lemma 2.9, Proposition 3.6].

For any $h > 0$ and any locally bounded function u on $R^{n} \times [0, \infty)$ , we define $\partial_{t}^{α, h} u$ to be $\begin{matrix} (2.3) & \partial_{t}^{α, h} u (x, t) : = \frac{1}{Γ (2 - α) h^{α}} {u (x, m h) - \sum_{k = 0}^{m - 1} C_{m, k} u (x, k h)} \end{matrix}$ for $(x, t) \in R^{n} \times [0, \infty)$ , and $m \in N \cup {0}$ satisfying $m = ⌊ t / h ⌋$ , where $⌊ s ⌋$ denotes the greatest integer less than or equal to $s ⩾ 0$ .

A locally bounded function $u : R^{n} \times [0, \infty) \to R$ is said to be a subsolution (resp., supersolution) of $\begin{matrix} (2.4) & \partial_{t}^{α, h} u + F (x, t, D u, D^{2} u) = 0 in Ω \times (0, \infty) \end{matrix}$ if for any $m \in N$ , $U = u (\cdot, m h) \in USC (R^{n})$ (resp., $U = u (\cdot, m h) \in LSC (R^{n})$ ) is a viscosity subsolution (resp, supersolution) of $\begin{matrix} \frac{1}{Γ (2 - α) h^{α}} {U - \sum_{k = 0}^{m - 1} C_{m, k} u (\cdot, k h)} + F (x, m h, D U, D^{2} U) = 0 in R^{n} . \end{matrix}$ By definition, it is clear that $u^{h}$ given by (1.9) is a solution of (2.4).
Proposition 2.1 (Monotonicity).

Fix $h > 0$ . Assume that (H1) holds. Let $U^{h} (\cdot, t)$ , $V^{h} (\cdot, t) \in BUC (R^{n})$ for all $t ⩾ 0$ be, respectively, a subsolution and supersolution to ( 2.4 ). Then, $U^{h} (\cdot, m h) ⩽ V^{h} (\cdot, m h)$ in $R^{n}$ for all $m \in N$ .

Proof.
Due to the positiveness (1.5) of $C_{m, k}$ , one can easily see that the scheme is monotone by iterating the comparison principle in (H1) for elliptic problems. □

We next discuss below the boundedness of the scheme. Lemma 2.2 (Barrier).

For any $h > 0$ , let $V^{h} (x, t) : = {(m h)}^{α}$ for all $x \in R^{n}$ and $t ⩾ 0$ with $m = ⌊ t / h ⌋$ . Then, $\begin{matrix} (2.5) & \partial_{t}^{α, h} V^{h} (x, t) ⩾ \frac{(1 - α) α}{Γ (2 - α)} for all x \in R^{n} and t ⩾ h . \end{matrix}$

Proof.
We have $\begin{matrix} (2.6) & \partial_{t}^{α, h} V^{h} (x, t) = \frac{1}{Γ (2 - α)} \sum_{k = 0}^{m - 1} f (m - k) ({(k + 1)}^{α} - k^{α}) \end{matrix}$ for all $x \in R^{n}$ and $t ⩾ h$ . Noting that $\begin{array}{l} f (m - k) ⩾ (1 - α) / {(m - k)}^{α} ⩾ (1 - α) / m^{α}, \\ {(k + 1)}^{α} - k^{α} ⩾ α / {(k + 1)}^{1 - α} ⩾ α / m^{1 - α}, \end{array}$ we can plug these estimates into (2.6) to deduce (2.5). □
Lemma 2.3 (Uniform boundedness).

Assume that ( 1.3 ) and (H1) hold. Let $u^{h}$ be given by ( 1.9 ) for any fixed $h > 0$ . Then, $\begin{matrix} | u^{h} (x, t) | ⩽ sup_{R^{n}} | u_{0}^{h} | + \frac{Γ (2 - α) M_{0}}{(1 - α) α} t^{α} for all h > 0, x \in R^{n}, t ⩾ 0 . \end{matrix}$

Proof.
We define $\begin{matrix} W^{h} (x, t) : = sup_{R^{n}} | u_{0}^{h} | + \frac{Γ (2 - α) M_{0}}{(1 - α) α} V^{h} (x, m h) \end{matrix}$ for any $(x, t) \in R^{n} \times [0, \infty)$ , where $m = ⌊ t / h ⌋$ and $V^{h}$ is given in Lemma 2.2. In light of Lemma 2.2, we have $\begin{matrix} \partial_{t}^{α, h} W^{h} (x, m h) + F (x, m h, D W^{h} (x, m h), D^{2} W^{h} (x, m h)) ⩾ M_{0} + F (x, m h, 0, 0) ⩾ 0 \end{matrix}$ for all $m \in N$ . Combining with $\begin{matrix} U^{h} (\cdot, 0) ⩽ W^{h} (\cdot, 0) on R^{n}, \end{matrix}$ by Proposition 2.1, we get $\begin{matrix} U^{h} (\cdot, m h) ⩽ W^{h} (\cdot, m h) \end{matrix}$ for all $m \in N$ . Symmetrically, we get $\begin{matrix} U^{h} (x, m h) ⩾ - W^{h} (\cdot, m h) \end{matrix}$ for all $m \in N \cup {0}$ , which implies the conclusion. □

3. Convergence of discrete schemes

Let $u^{h}$ be the function defined by (1.9). By Lemma 2.3 and (1.6), we can define the half-relaxed limit of $u^{h}$ as follows: $\begin{matrix} (3.1) & \begin{matrix} \overline{u} (x, t) : = lim_{δ \to 0} sup {u^{h} (y, s) : | x - y | + | t - s | ⩽ δ, s ⩾ 0, 0 < h ⩽ δ}, \\ \underline{u} (x, t) : = lim_{δ \to 0} inf {u^{h} (y, s) : | x - y | + | t - s | ⩽ δ, s ⩾ 0, 0 < h ⩽ δ} \end{matrix} \end{matrix}$ for all $(x, t) \in R^{n} \times [0, \infty)$ .

By the definition of Riemann integral and the operator $\partial_{t}^{α, h}$ , we have the following.

Lemma 3.1.
Let $\partial_{t}^{α, h}$ be given by ( 2.3 ). Then for any $ψ \in C^{1} (R^{n} \times [0, \infty))$ , we have $\begin{matrix} \partial_{t}^{α, h} ψ \to \partial_{t}^{α} ψ locally uniformly in R^{n} \times (0, \infty) as h \to 0 . \end{matrix}$
Proposition 3.2 (Sub- and supersolution property).

Let $\overline{u}$ and $\underline{u}$ be the functions defined by ( 3.1 ). Then $\overline{u}$ and $\underline{u}$ are, respectively, a subsolution and supersolution to ( 1.1 ).

Proof.
We only prove that $\overline{u}$ is a subsolution to (1.1) as we can similarly prove that $\underline{u}$ is a supersolution to (1.1).

Take a test function $φ \in C^{2} (R^{n} \times [0, \infty))$ and $(\hat{x}, \hat{t}) \in R^{n} \times (0, \infty)$ so that $\overline{u} - φ$ takes a strict maximum at $(\hat{x}, \hat{t})$ with $\begin{matrix} (\overline{u} - φ) (\hat{x}, \hat{t}) = 0 . \end{matrix}$ By adding $| x - \hat{x} |^{4}$ to φ (we still denote it by φ), we may assume that $φ (x, t) \to \infty$ as $| x |$ uniformly for all $t ⩾ 0$ .

We first claim that there exists $(x_{j}, t_{j}) \in R^{n} \times (0, \infty)$ , $h_{j} > 0$ so that $(x_{j}, t_{j}) \to (\hat{x}, \hat{t})$ and $h_{j} \to 0$ as $j \to \infty$ , $\begin{array}{l} (3.2) & u^{h_{j}} (\cdot, t_{j}) - φ (\cdot, t_{j}) takes a maximum at x_{j}, \\ (3.3) & sup_{(x, t) \in R^{n} \times (0, \infty)} (u^{h_{j}} - φ) (x, t) < (u^{h_{j}} - φ) (x_{j}, t_{j}) + h_{j} . \end{array}$ Indeed, by definition of $\overline{u}$ , there exists $(y_{j}, s_{j}) \in R^{n} \times (0, \infty)$ , and $h_{j} > 0$ so that $\begin{array}{l} (y_{j}, s_{j}) \to (\hat{x}, \hat{t}), h_{j} \to 0, and u^{h_{j}} (y_{j}, s_{j}) \to \overline{u} (\hat{x}, \hat{t}) as j \to \infty . \end{array}$ We next take $ξ_{j} \in R^{n}$ and $τ_{j} > 0$ satisfying $\begin{matrix} (3.4) & sup_{(x, t) \in R^{n} \times (0, \infty)} (u^{h_{j}} - φ) (x, t) < (u^{h_{j}} - φ) (ξ_{j}, τ_{j}) + h_{j} . \end{matrix}$

Set $\begin{matrix} N_{j} : = ⌊ τ_{j} / h_{j} ⌋, t_{j} : = N_{j} h_{j} . \end{matrix}$ Then we have $\begin{matrix} (3.5) & u^{h_{j}} (\cdot, τ_{j}) = u^{h_{j}} (\cdot, t_{j}) = U^{h_{j}} (\cdot, N_{j} h_{j}) in R^{n} . \end{matrix}$ In addition, there exists $\tilde{c} > 0$ depending on the local bound of $| \partial_{t} φ |$ near $(\hat{x}, \hat{t})$ such that $\begin{matrix} φ (ξ_{j}, τ_{j}) ⩽ φ (ξ_{j}, t_{j}) + \tilde{c} h_{j}, \end{matrix}$ which, together with (3.4) and (3.5), implies that $\begin{matrix} (3.6) & sup_{(x, t) \in R^{n} \times (0, \infty)} (u^{h_{j}} - φ) (x, t) ⩽ (u^{h_{j}} - φ) (ξ_{j}, t_{j}) + c h_{j} \end{matrix}$ with $c = \tilde{c} + 1$ .

Also, by Lemma 2.3 and the continuity of $u^{h_{j}} (\cdot, t_{j})$ in $R^{n}$ , there exists $x_{j} \in R^{n}$ such that $\begin{matrix} sup_{x \in R^{n}} (u^{h_{j}} - φ) (x, t_{j}) = max_{x \in R^{n}} (u^{h_{j}} - φ) (x, t_{j}) = (u^{h_{j}} - φ) (x_{j}, t_{j}) . \end{matrix}$ In view of (3.6), this implies that $\begin{matrix} (u^{h_{j}} - φ) (y_{j}, s_{j}) ⩽ sup_{(x, t) \in R^{n} \times (0, \infty)} (u^{h_{j}} - φ) (x, t) ⩽ (u^{h_{j}} - φ) (x_{j}, t_{j}) + c h_{j} . \end{matrix}$ Noticing that $(\hat{x}, \hat{t})$ is the unique maximizer of $\overline{u} - φ$ over $R^{n} \times (0, \infty)$ , one can easily check that $(x_{j}, t_{j}) \to (\hat{x}, \hat{t})$ as $j \to \infty$ .

Since $U^{h_{j}} (\cdot, N_{j} h_{j})$ is a viscosity solution to (1.7) with $m = N_{j}$ and $h = h_{j}$ , in light of (3.2), we obtain $\begin{matrix} \partial_{t}^{α, h_{j}} u^{h_{j}} (x_{j}, t_{j}) + F (x_{j}, t_{j}, D φ (x_{j}, t_{j}), D^{2} φ (x_{j}, t_{j})) ⩽ 0 . \end{matrix}$ Set $σ_{j} : = {max}_{x \in R^{n}} (u^{h_{j}} - φ) (x, t_{j}) = u^{h_{j}} (x_{j}, t_{j}) - φ (x_{j}, t_{j})$ . In light of (3.3), we have $\begin{matrix} (u^{h_{j}} - φ) (x_{j}, k h_{j}) ⩽ c h_{j} + σ_{j} \end{matrix}$ for all $k = 0, \dots, N_{j} - 1$ . Hence, $\begin{array}{l} Γ (2 - α) {(h_{j})}^{α} \partial_{t}^{α, h_{j}} u^{h_{j}} (x_{j}, t_{j}) \\ = u^{h_{j}} (x_{j}, N_{j} h_{j}) - \sum_{k = 0}^{N_{j} - 1} C_{N_{j}, k} u^{h_{j}} (x_{j}, k h_{j}) \\ ⩾ φ (x_{j}, N_{j} h_{j}) + σ_{j} - \sum_{k = 0}^{N_{j} - 1} C_{N_{j}, k} (φ (x_{j}, k h_{j}) + c h_{j} + σ_{j}) . \end{array}$ Noting that $\begin{matrix} \sum_{k = 0}^{N_{j} - 1} C_{N_{j}, k} = f (1) = 1, \end{matrix}$ we obtain $\begin{array}{l} \partial_{t}^{α, h_{j}} u^{h_{j}} (x_{j}, N_{j} h_{j}) & ⩾ \frac{1}{Γ (2 - α) {(h_{j})}^{α}} {φ (x_{j}, N_{j} h_{j}) - \sum_{k = 0}^{N_{j} - 1} C_{N_{j}, k} φ (x_{j}, k h_{j}) - c h_{j}} \\ = \partial_{t}^{α, h_{j}} φ (x_{j}, N_{j} h_{j}) + O (h_{j}^{1 - α}) . \end{array}$ We therefore obtain $\begin{matrix} \partial_{t}^{α,, h_{j}} φ (x_{j}, N_{j} h_{j}) + F (x_{j}, t_{j}, D φ (x_{j}, t_{j}), D^{2} φ (x_{j}, t_{j})) ⩽ O (h_{j}^{1 - α}) . \end{matrix}$ By Lemma 3.1 and the continuity of F, sending $j \to \infty$ yields $\begin{matrix} \partial_{t}^{α} φ (\hat{x}, \hat{t}) + F (\hat{x}, \hat{t}, D φ (\hat{x}, \hat{t}), D^{2} φ (\hat{x}, \hat{t})) ⩽ 0 . \end{matrix}$ □
Proposition 3.3 (Initial consistency).

Assume that ( 1.3 ) and (H1) hold. Let $\overline{u}$ and $\underline{u}$ be the functions defined by ( 3.1 ). Then $\overline{u} (\cdot, 0) ⩽ u_{0} ⩽ \underline{u} (\cdot, 0)$ in $R^{n}$ .

Proof.

Fix any $x_{0} \in R^{n}$ . Since $u_{0} \in BUC (R^{n})$ and (1.6) holds, for any $σ > 0$ we can find a bounded smooth function $ϕ_{σ}$ such that $\begin{matrix} ϕ_{σ} (x_{0}) ⩽ u_{0} (x_{0}) + σ \end{matrix}$ and $\begin{matrix} u_{0}^{h} (x) ⩽ ϕ_{σ} (x) \end{matrix}$ for all $x \in R^{n}$ and all $h > 0$ small. We claim that $\begin{matrix} ϕ^{h} (x, t) = ϕ_{σ} (x) + \frac{M_{R_{σ}} Γ (2 - α)}{(1 - α) α} t^{α} \end{matrix}$ is a supersolution of (2.4) with $h > 0$ small, where $M_{R_{σ}}$ is given in (1.3) with $\begin{matrix} R_{σ} = sup_{R^{n}} (| D ϕ_{σ} | + | D^{2} ϕ_{σ} |) . \end{matrix}$ Indeed, for any $x \in R^{n}$ , applying Lemma 2.2, we deduce that for all $m \in N$ , $\begin{matrix} \partial_{t}^{α, h} ϕ^{h} (x, m h) ⩾ M_{R_{σ}} ⩾ - F (x, m h, D ϕ_{σ} (x), D^{2} ϕ_{σ} (x)) \end{matrix}$ for all $x \in R^{n}$ . We thus can adopt Proposition 2.1 to obtain that $u^{h} (x, N h) ⩽ ϕ^{h} (x, N h)$ for all $x \in R^{n}$ and $t ⩾ 0$ with $N = ⌊ t / h ⌋$ , which implies that $\begin{matrix} u^{h} (x, t) ⩽ ϕ_{σ} (x) + \frac{M_{R_{σ}} Γ (2 - α)}{(1 - α) α} t^{α} \end{matrix}$ for all $x \in R^{n}$ and $t ⩾ 0$ . We thus have $\begin{matrix} \overline{u} (x_{0}, 0) ⩽ ϕ_{σ} (x_{0}), \end{matrix}$ which implies, by letting $σ \to 0$ , that $\overline{u} (x_{0}, 0) ⩽ u_{0} (x_{0})$ . The proof for the part on $\underline{u}$ is symmetric and therefore omitted here. □

Proof of Theorem 1.1.

If (H2) holds, then the conclusion of the theorem is a straightforward result of Propositions 3.2 and 3.3. □
