CD26 expression on donor harvest as a risk predictive biomarker for developing graft-versus-host disease post-allogeneic hematopoietic stem cell transplantation: A ten-year follow-up study

Abstract

BACKGROUND:

Allogeneic hematopoietic stem cell transplantation (ASCT) is the preferred treatment option for patients with several hematologic disorders and immunodeficiency syndromes. Graft-versus-host disease (GVHD) is an immune mediated post-transplant complication which has a major impact on long-term transplant outcomes.

OBJECTIVE:

Current efforts are focused on identification of new markers that serve as potential predictors of GVHD and other post-transplant clinical outcomes.

METHODS:

This study includes donor harvests collected from twenty-three allogeneic donors during period 2008–2009 and respective transplant recipients followed for clinical outcomes till March 2019. Percent CD26+ and CD34+ cells in donor harvest were analyzed using flow cytometry. Percent expression and infused dose of CD26+ and CD34+ cells were evaluated for association with various clinical outcomes.

RESULTS:

Total 23 healthy donors with median age of 28 years (13 males), and transplant recipients with median age of 24 years (17 males) formed the study cohort. The diagnosis included malignant ( $n=$ 13) and non-malignant ( $n=$ 10) hematological disorders. Median CD34brCD45lo HSC expression was 0.57% (IQR 0.24–1.03) while median CD26 expression was 19.64% (IQR 8.96–33.56) of all nucleated cells. CD26 expression was associated with donor age ( $P=$ 0.037). CD26 percent expression correlated with WBC engraftment ( $P=$ 0.015) and with acute GVHD ( $P=$ 0.023) whereas infused CD26 cell dose correlated with WBC engraftment ( $P=$ 0.004) and risk of CMV reactivation ( $P=$ 0.020). There was no statistically significant correlation of either CD26 expression or cell dose with chronic GVHD, EFS or OS.

CONCLUSIONS:

Our findings suggest a role of CD26 expression on human donor harvest as a potential predictor of acute GVHD. This association warrants further exploration.

Keywords

CD26 expression immuno-ectoenzyme stem cell transplantation engraftment graft-versus-host disease biomarker clinical long-term follow-up

Graphical abstract

Highlights

Study has identified biomarker immuno-ectoenzyme CD26 for predicting outcome in allogeneic stem cell transplants.

First study correlating CD26 expression on donor stem cell harvest with acute GVHD, and CMV reactivation.

Lower CD26 expression associates with lesser acute GVHD.

These data form the basis of going forward with further studies regarding CD26.

1. Introduction

Allogeneic stem cell transplantation (ASCT) is the preferred treatment in patients with high-risk hematolymphoid malignancies and few hematological disorders viz. Fanconi’s anemia, aplastic anemia, several hemoglobinopathies, etc. These diseases can be cured by ASCT that brings about donor stem cell-mediated hematopoiesis and immune reconstitution. Among the several factors that affect the long-term success of ASCT (diagnosis, disease status at transplant, age and gender of patient and donor, degree of human leukocyte antigen (HLA) match or mismatch, and many more) are the infused cell doses [1, 10, 24]. Traditionally, CD34 has been considered as the standard marker for stem cells, however, the correlation between CD34 cell dose and several post-transplant outcomes has not been consistent. Data from our analysis has shown no correlation between CD34 cell dose and acute or chronic GVHD (aGVHD or cGVHD) [10, 24]. In view of these, attempts have been made by us and others to identify other potential markers which may have a correlation with transplant outcomes. CD26/(dipeptidylpeptidase-IV/DPPIV) is an immunoregulatory enzyme which is expressed constitutively on many hematopoietic cell populations (including natural killer cells and activated B and T lymphocytes) endothelial cells, fibroblasts, epithelial cells, and mesenchymal stem cells [14, 19]. The secretory form (which is the extracellular domain of CD26) also carries catalytic activity [7, 22]. CD26 is also crucial for mobilization of hematopoietic stem cells (HSCs) from bone marrow niche and homing towards lymphoid organs. CD26/DPPIV exhibits a complex biology encompassing cell-membrane associated activation of intracellular signal transduction pathways, cell-cell interaction and migration [6, 7, 14, 19]. CD26 plays a key role as a T-cell co-stimulatory molecule. Other known functions of CD26 include cleavage of several neurohormones, and as a receptor for adenosine deaminase [14, 19]. Mice models have shown that inhibition of enzymatic activity of CD26 suppress antibody production [16]. These and several other data point to an important role played by CD26 in immune responses. Previously we had reported for the first time that increased CD26 expression on cells of donor harvest from related donors led to early WBC engraftment in cancer patients [23]. In the current paper, we report long-term outcomes (with a ten-year follow-up) of an expanded cohort of our earlier study. To the best of our knowledge, this is first study to analyze correlation between CD26 expression on donor harvests and CD26+ cell dose with long-term transplant outcomes.

2. Patients and methods

This study was a single-centre prospective study. Consecutive patients undergoing 1 ${}^{\text{st}}$ allogeneic transplant who consented were included in the study. A total of 23 patient-donor pairs were included. The study included 19 peripheral blood stem cell (PBSC) harvest samples (all of whom were mobilized using human granulocyte – colony stimulating factor (G-CSF) at a dose of 10 $\mu$ g/kg/day in 2 divided doses for 4 days, followed by harvest on the 5 ${}^{\text{th}}$ day) and 4 bone marrow harvest samples collected during period 2008–2009. Donors who underwent marrow harvests did not receive G-CSF. No product manipulation was done for the harvests. Patients were followed up for clinical outcomes till March 2019. The study was approved by the Institutional Ethics Committee (Study #266). All patients provided consent for study participation. The donor details, patient demographics, transplant characteristics, and post-transplant outcomes are summarized in Table 1.

Table 1
Donor characteristics, patient demographics, transplant details and clinical outcomes

Donor details
Characteristic	Number ${}^{*}$	Percent ${}^{*}$
Age in years, median (range)	28 (2–50)	–
Gender
Males	13	57%
Females	10	43%
Patient demographics
Age in years, median (range)	24 (5–51)	–
Gender
Males	17	74%
Females	6	26%
Diagnosis
Aplastic anemia	8	35%
Fanconi anemia	2	9%
AML	7	30%
ALL	4	17%
MDS	1	4.5%
CMML	1	4.5%
Disease status at ASCT (for malignant diseases, $n=$ 13)
In complete remission	9	69%
With disease	4	31%
CMV serostatus
Donor $+$ / Recipient $+$	22	96%
Donor $-$ / Recipient $+$	1	4%
Transplant details
Type of transplant
Matched related transplant	22	96%
Matched unrelated donor transplant	1	4%
ABO mismatched transplants	9	39%
Gender mismatched transplants	10	43%
Stem cell source
PBSC	19	82%
BM	4	18%
Degree of HLA matching
Full match	22	96%
1 antigen mismatch	1	4%
Type of conditioning regimen ${}^{\#}$
Full intensity	10	43%
Reduced intensity	13	57%
Cell doses infused
TNC [10 ${}^{8}$ /kg] (Mean $\pm$ Standard error)	7.27 $\pm$ 0.81	–
CD34 [10 ${}^{6}$ /kg] (Median (IQR))	3.64 (0.86–7.16)	–
CD3 [10 ${}^{6}$ /kg] (Mean $\pm$ Standard error)	202.55 $\pm$ 28.57	–
GVHD prophylaxis
CsA alone	3	13%
CsA $+$ short course MTX	20	87%
Post-transplant outcomes
Day of WBC engraftment, median	12
Day of platelet engraftment, median	12
aGVHD	4	17%
cGVHD ${}^{\$}$	3	13%
CMV reactivation	8	35%
Long-term (5 year) survival	15	65%

${}^{*}$ Data are expressed in number and percentage, except where stated. ${}^{\#}$ Defined as per standard published criteria. ${}^{\$}$ All cGVHD were limited stage cGVHD. AML: Acute myeloid leukemia; ALL: Acute lymphoid leukemia; MDS: Myeloid dysplastic syndrome; CMML: Chronic myelomonocytic leukemia; CMV: Cytomegalovirus; PBSC – Peripheral blood stem cell; BM: Bone Marrow; HLA: Human leukocyte antigen; TNC: Total nucleated cell; IQR: Interquartile range; CsA: Cyclosporine A; MTX: Methotrexate; GVHD: acute Graft-versus-host disease; aGVHD: actue GVHD; cGVHD: chronic GVHD; WBC: White blood cells.

2.1 CD34 and CD26 expression by flow cytometry

Cell surface expression of CD34 and CD26 antigens was performed as described previously [23]. Red blood cells were separated and nucleated cells from the stem cell harvest were suspended in FACS (Fluorescence activated cell sorting) buffer (Phosphate buffered saline with 1% Fetal Calf Serum and 0.02% sodium azide) and stained with anti-human CD26 conjugated with Fluorescein-isothiocyanate (FITC), anti-human CD3 conjugated with FITC, anti-human CD34-conjugated with Phycoerythrin (PE) and anti-human CD45–FITC (Becton Dickinson, San Jose, CA) antibodies. Stained cells were acquired using Flow Cytometer (FACS Caliber, Becton Dickinson, San Jose, CA), and analysed with CELLQuest Software (Becton Dickinson). CD34+ cells were defined as described earlier in International Society for Hematotherapy and Graft Engineering (ISHAGE) protocol for CD34 analysis [29]. The gating strategy followed for CD34 and CD26 is shown in Supplementary Figure S1. Infused cell dose of CD26+ cells, CD3+ cells and CD34+ cells was calculated in terms of body weight of transplant recipient.

2.2 Post-transplant outcomes

2.2.1 WBC and platelet engraftment

WBC engraftment was considered to have occurred on the first of 3 consecutive days in which the total leukocyte count exceeded 1.0 $\times$ 10 ${}^{9}$ /L or absolute neutrophil count exceeded 0.5 $\times$ 10 ${}^{9}$ /L. Platelet engraftment was considered to have occurred on the first day of 7 consecutive days in which platelet count exceeded 2.0 $\times$ 10 ${}^{9}$ /L without platelet transfusion.

2.2.2 Graft versus host disease

The diagnosis and grading of aGVHD was done clinically according to Gluksberg criteria [14]. Histological confirmation was done only if clinically necessary. Chronic GVHD was diagnosed clinically with biopsy confirmation obtained only when clinically necessary. Chronic GVHD was classified into limited stage and extensive stage according to the standard modified Seattle criteria. For analysis of aGVHD, patients were divided into 2 groups, those with grade II-IV aGVHD (GVHD-Yes) and those with grade I aGVHD or no GVHD (GVHD-No).

2.2.3 Viral reactivation

Cytomegalovirus (CMV) DNA was monitored by polymerase chain reaction in all patients. Monitoring was started from the beginning of conditioning chemotherapy and continued till day +100 post-transplant (or later, if the patient was on immunosuppression for GVHD). Evaluation of other viruses was done only when clinically indicated.

Figure 1.

Scatter plots of percent CD34/CD26 expression and WBC/Platelet engraftment day. This figure depicts scatter plots of percent CD34 expression (Panel A), percent CD26 expression (Panel B) on donor harvest cells. The number and (–) on each panel denote median value of the percent CD34/CD26 expression observed in allogeneic donor harvests ( $n=$ 23). Solid pink () and solid blue () in both the panels depict incidence of GVHD and no incidence of GVHD, respectively reported in transplant recipients at 100 ${}^{\text{th}}$ day post-transplant. Panel C demonstrates scatter plot for WBC/Platelet engraftment day for all transplant recipients ( $n=$ 23) observed post donor harvest infusion.

2.2.4 Survival

Event Free Survival (EFS) was measured as the time interval between date of transplant and date of relapse or death. Those patients who had not relapsed or died at their last follow-up were censored on the dates of their last follow-up. Overall Survival (OS) was measured as the time interval between date of transplant and date of death by any cause. Again, patients alive at their last follow-up were censored.

2.3 Correlation of cell doses and outcomes

The percentage expression of CD26 and CD34, as well as the infused CD26 and CD34 cell doses were analyzed for correlation with all of the above post-transplant outcomes. Additionally, infused total nucleated cell (TNC) and CD3+ cell doses were also correlated with outcomes.

2.4 Statistical analysis

Descriptive statistics, including mean $\pm$ standard error of mean or median interquartile range (IQR) for continuous parameters as per distribution, and number and percent of patients for categorical parameters, are presented. The normality assumption was tested using Shapiro-Wilk test [9]. Correlation between percent CD26 and CD34 expression was analyzed using Spearman’s rho correlation or Pearson’s correlation coefficient as appropriate. Infused cell dose comparison between viral reactivation, acute GVHD, chronic GVHD was performed using Independent T test or Mann Whitney U test. The Receiver Operating Characteristic (ROC) curve is a mapping of the sensitivity versus 1-specificity for all possible values of the cut-point between cases and controls. ROC analysis was carried out to identify an optimal cut-off value of % CD26 expression and infused CD26+ cell dose values to discriminate surviving from dead patients. Overall survival time was calculated from date of transplant to date of death or last follow-up date. Event free survival time was calculated from date of transplant to date of relapse or date of death or last follow up date. The survival analysis was done using the Kaplan Meier method. Univariate survival analysis was presented hazard ratio (95% C.I.) using cox regression for the all continuous biomarker data. All reported $P$ -values were two tailed and a level of $<$ 0.05 was accepted as statistically significant. All analysis was done using SPSS 21.0 software (SPSS Inc., Chicago, IL, USA).

Figure 2.

Association of CD26 expression in donor harvest with donor age. Scatter plots show association of percent CD26 expression (Panel A) and infused CD26+ cell dose (Panel B) with donor age in years.

Figure 3.

Association of percent CD26 expression and CD34 infused cell dose with post-transplant clinical outcomes. Box-Whisker plots exhibit distribution of percent CD26 expression (Panel A) and infused CD26+ cell dose (Panel B) in patients with (YES, $n=$ 4) and without (NO, $n=$ 19) acute GVHD.

3. Results

3.1 CD34 and CD26 expression on stem cell harvest and infused cell doses

Twenty-three allogeneic donors with median age of 28 (IQR: 17–37) years and 13 (56.52%) males formed the study cohort (Table 1). CD34 ${}^{\text{br}}$ CD45 ${}^{\text{lo}}$ HSPC expression in donor harvest ( $n=$ 23) ranged from 0.01% to 1.6% with median of 0.57% (IQR: 0.24–1.03%; Fig. 1A). The median CD26 expression was 19.64% (IQR: 8.96–33.56) of all nucleated cells (Fig. 1B). Median infused CD26+ cell dose was 190.33 $\times$ 10 ${}^{6}$ /kg of patient body weight (IQR: 89.42–458.27). Other cell doses (TNC, CD34+ and CD3+) are shown in Table 1.

3.2 Transplant outcomes

WBC engraftment was achieved in all patients at median days of 12 (IQR: 11–13; Fig. 1C). Engraftment of platelets was also achieved with a median of 12 days (IQR: 10–14) (Fig. 1C). Incidence of grade II-IV aGVHD, cGVHD, and CMV reactivation is shown in Table 1. Among 13 patients with malignant disorders, 7 (54%) relapsed. Among the entire cohort of 23 patients, 15 (65%) are long term survivors. Among the 8 patients who died, 7 died of disease, and 1 died due to GVHD.

3.3 Correlation of CD26 expression with donor characteristics

Donor age correlated significantly with CD26 percent expression ( $P=$ 0.037) and infused CD26+ cell dose ( $P=$ 0.027) (Supplementary Table ST1; Fig. 2A and B). CD26 expression on donor harvest increased with donor age. Harvests from female donors had a higher CD26 expression compared to harvests from male donors, however, this was not statistically significant ( $P=$ 0.196, Supplementary Table ST1). Infused CD34+ cell dose did not correlate with donor gender, or donor age (Supplementary Table ST1).

Table 2
Association of CD26 expression on donor harvest and infused cell dose with transplant clinical outcomes

	Clinical			Infused cell dose/Kg
	parameters	Category	% CD26	CD26 ${}^{+}$ cells *10 ${}^{6}$	CD34 ${}^{+}$ cells *10 ${}^{6\ }$	CD3 ${}^{+}$ cells *10 ${}^{6}$	TNC *10 ${}^{8}$
1	WBC Engraftment	$r$	$-$ 0.499	$-$ 0.599	$-$ 0.017	$-$ 0.672	$-$ 0.362
		$P$	0.015 ${}^{\#}$	0.004	0.941	0.001 ${}^{\#\#}$	0.097
2	Platelet Engraftment	$r$	$-$ 0.285	$-$ 0.289	$-$ 0.037	$-$ 0.187	$-$ 0.288
		$P$	0.188	0.204	0.873	0.416	0.194
3	Viral	Yes	24.61 (12.03–55.72)	502.85 (194.74–738.77)	4.94 (1.24–13.54)	280.19 (167.75–318.77)	13.43 $\pm$ 1.66
	reactivation ${}^{\$}$	No	15.5 (7.12–26.9)	107.34 (15.91–274.88)	4.39 (1.36–5.47)	149 (67.2–223.7)	11.15 $\pm$ 1.80
		$P$	0.245*	0.020	0.664	0.03	0.411**
4	Acute GvHD	Yes	39.81 (27.18–57.91)	546.03 (458.26–641.27)	0.20 (0.098–1.07)	314.86 $\pm$ 129.39	4.38 $\pm$ 2.91
		No	15.50 (7.12–26)	149.50 (17.43–312.02)	4.46 (1.38–9.54)	183.83 $\pm$ 25.45	7.39 $\pm$ 1.10
		$P$	0.023	0.056	0.009	0.110	0.330
5	Chronic	Yes	21.2 (17.52–42.83)	547.43 (243.67–771.28)	9.54 (4.38 –14.88)	306.7 (273.47–322.80)	12.2 $\pm$ 1.06
	GvHD	No	17.57 (7.58–32.17)	149.50 (17.43–366.46)	2.45 (0.27–5.5)	152.5 (104.9–234.1)	6.16 $\pm$ 1.07
		$P$	0.523	0.088	0.191	0.044	0.420
6	Overall Survival ${}^{@}$	$P$	0.311	0.066	0.155	0.050	0.177
7	Event Free Survival	$P$	0.169	0.482	0.119	0.555	0.458

This table includes CD26 and CD34 percent expression from stem cell harvest of allogeneic donors (PBSC harvest; $n=$ 19 and Bone marrow harvest; $n=$ 4) and clinical parameters from transplant recipients ( $n=$ 23). $P$ value of $<$ 0.05 is considered significant and marked bold while $P$ value of reaching significance is marked in italics. ${}^{\#}$ Spearman’s correlation co-efficient rho (r) was analysed by Non-Parametric Correlation analysis when data was not normal. ${}^{\#\#}$ Pearson’s correlation co-efficient was analysed by Parametric Correlation analysis when data was normal. ${}^{\$}$ Patients who presented with CMV reactivation were included. ${}^{*}$ Data was analysed by Mann-Whitney test and represented as Median (Interquartile range). ${}^{**}$ Data was analysed by Independent T-test and represented as Mean $\pm$ Standard Error. ${}^{@}$ Survival was analysed by Cox Regression Model. Abbreviations: WBC White blood cell.

Table 3

Univariate Cox regression analysis

	HR (95% CI)		$P$ -value	HR (95% CI)	$P$ -value
	OS		EFS
% CD26	1.018	(0.984–1.053)	0.311	1.019 (0.992–1.045)	0.169
Infused CD26 ${}^{+}$ cells *10 ${}^{6}$	1.002	(1–1.005)	0.066*	1.001 (0.999–1.003)	0.482
Infused CD34 ${}^{+}$ cells *10 ${}^{6}$	0.791	(0.572–1.093)	0.155	0.867 (0.725–1.037)	0.119
Infused CD3 ${}^{+}$ cells *10 ${}^{6}$	1.007	(1–1.015)	0.050	1.002 (0.996–1.008)	0.555
Infused TNC *10 ${}^{8}$	0.914	(0.802–1.042)	0.177	0.964 (0.874–1.063)	0.458

Univariate Cox regression was performed to detect the coefficients which relate to hazard. Hazard ratio (HR) of less than 1 indicate that the predictor is protective (i.e., associated with improved survival). While Hazard ratio of greater than 1 signifies that the predictor is associated with increased risk (or decreased survival). ${}^{*}$ Values marked in italics are showing tendency towards statistical significance. OS: Overall Survival; EFS: Event Free Survival; HR: Hazard ratio; CI: 95% Confidence interval for risk of all cause and cause specific mortality; TNC: Total nucleated cell.

3.4 Correlation of CD34, CD26 and CD3 expression and infused cell doses with clinical outcomes

CD26, CD34 and CD3 expression and infused cell doses were correlated with transplant outcomes viz. WBC/ platelet engraftment day, aGVHD, cGVHD, viral reactivation, EFS and OS.

3.4.1 Engraftment

CD26 percent expression ( $P=$ 0.015) and infused CD26+ cells ( $P=$ 0.004) exhibited statistically significant negative correlation with the day of WBC engraftment (Table 2). Correlation of engraftment with other cell doses is shown in Table 2.

3.4.2 Graft-versus-host disease

CD26 percent expression ( $P=$ 0.023; Fig. 3A) as well as infused CD26+ cells ( $P=$ 0.056; Fig. 3B) exhibited significant association with aGVHD (Table 2) but did not with cGVHD (Table 2). Low CD26 expression was associated with low risk of developing aGVHD post-transplant. Infused CD34+ cell dose correlated significantly with aGVHD (Table 2; $P=$ 0.009) but did not show any correlation with cGVHD (Table 2). Other correlations are as shown in Table 2.

3.4.3 Viral reactivation

Infused CD26+ cell dose correlated significantly with viral (CMV) reactivation ( $P=$ 0.020; Table 2). Patients with CMV reactivation had a statistically significantly higher infused CD26 cell dose compared to those without. However, correlation of CD26 expression with CMV reactivation was not statistically significant ( $P=$ 0.245; Table 2). Among the other cell doses, only infused CD3+ cell dose ( $P=$ 0.030) exhibited significant positive association with risk of viral reactivation post-transplant (Table 2).

3.4.4 Survival

Median Survival time was 92 months (95% C.I. 87.5, 96.15) months. More than 50% patients were survived till 96 months. Median Event free survival time was 28 (95% C.I. 16, 41) months. 3-year OS and EFS probability was 64.7% and 42.7%, respectively. ROC identified an optimal cut-off of 20.4% for CD26 expression and 217 $\times$ 10 ${}^{6}$ /kg for infused CD26+ cell dose. Using this cut-off, the EFS and OS were not statistically different between patients with high and low CD26 expression or infused cell doses (Fig. 4). Univariate analysis did not identify any correlation between CD26 expression or infused dose with EFS or OS (Table 3).

Figure 4.

Association of percent CD26 expression and CD26 infused cell dose with post-transplant overall and event-free survival. ROC curves demonstrated area under curve for % CD26 expression (Panel A) and infused CD26 cell dose (Panel D) in donor harvest. Overall survival Kaplan Meier curves of donor harvest % CD26 expression (Panel B) and infused CD26 cell dose (Panel E) and Event free survival Kaplan Meier curves of donor harvest % CD26 expression (Panel C) and infused CD26 cell dose (Panel F). Values mentioned at right bottom of each panel indicate statistical significance by Log Rank test. $P<$ 0.05 was considered statistically significant.

3.4.5 Association of CD26 expression and infused cell dose with other markers

Association of CD26 expression was also evaluated with that of CD34, CD3 expression and TNC. Spearman’s correlation applied to evaluate the association of CD26 percent expression ( $P=$ 0.421, $r=$ $-$ 0.183) and infused CD26+ cell dose ( $P=$ 0.841, $r=$ $-$ 0.047) with a known marker of stem cell transplantation – infused CD34+ cell dose demonstrated that there was no correlation (Fig. 5). The correlation of infused CD26+ cell dose with infused CD3+ cell dose ( $P=$ 0.001, $r=$ 0.691) and TNC dose ( $P=$ 0.000001, $r=$ 0.845) was found to be statistically significant.

Figure 5.

Association of percent CD26 expression and CD26 infused cell dose with CD34 infused cell dose. The figure exhibits association between percent CD26 expression (left panel) and infused CD26 cell dose (right panel) with a known marker of post-transplantation recovery – infused CD34 cell dose in nucleated cells of stem cell harvest ( $n=$ 23). As per Spearman’s Correlation Coefficient r values, there was no significant correlation. $P<$ 0.05 was considered statistically significant.

4. Discussion

Variable reports on correlation of CD34 expression and/or infused CD34+ cell dose and transplant outcome have led to search of novel markers for predicting post-transplant outcomes [1, 2, 3, 13, 14, 15, 16, 17]. CD26 is expressed on several hematopoietic cells (and also other cells) as well as exist in soluble form in the blood. All functions of CD26 are not known. However, some of its important functions include – acting as a co-stimulatory molecule for T-cell activation, cleaving several cytokines and neuropeptides, and as receptor for adenosine deaminase [14, 19]. Thus, it has many significant functions in the immune system. Simeoni et al. [28] demonstrated that CD26-knock-out and -deficient animal models, transgenic mice with human CD26 displayed impairment in thymocyte proliferation to mitogens and CD4 ${}^{+}$ /CD8 ${}^{+}$ T cell differentiation, suggesting an important role of DPP4 in the T lymphocyte homeostasis in peripheral blood. As against, another report showed that inhibition of DPP4 activity by pro-boropro led to costimulating effect in hematopoietic colony assays for macrophage and also in organ cultures of immature thymocytes [3].

In the field of allogeneic stem cell transplant, there is sparse literature regarding the role of CD26. The fact that CD26/DPP-IV regulates CXCL12 (stromal cell derived factor 1 or SDF1) led to the hypothesis that CD26 inhibition may have an impact on engraftment. However, studies have yielded conflicting results [4, 26]. Subsequently, following the identification of role of CD26+T cells in several auto-immune disorders, their role in pathology and prevention of GVHD has been studied. It has been shown in human-derived xenograft models of GVHD that there is an infiltration of CD26+ T cells in target organs affected by acute GVHD [12]. The same study also reports a significant improvement of GVHD with anti CD26 monoclonal antibody [12]. However, there is no correlation in literature about the CD26+ cells in donor stem cell harvest and transplant outcomes.

Previously, we had reported the correlation between CD26 expression on donor harvest and engraftment [23]. However, it was also important to address the correlation between CD26 expression and other ASCT outcomes. With a long-term follow-up, we found a strong association between CD26 percent expression on donor harvest and infused CD26 cell dose with acute GVHD. However, we did not find an association between chronic GVHD, and event-free and overall survival. Our finding of correlation between CD26 expression and donor age could provide a biological basis for clinical observation of increased risk of GVHD seen with older donors [25, 32].

Given the potential role of CD26+ T cells in GVHD, several groups have studied inhibition of CD26 for prevention and treatment of GVHD. Bacigalupo et al. [2] studied the role of anti CD26 monoclonal antibody begelomab for the treatment of steroid refractory GVHD and found an impressive response rate of about 60%. More recently, sitagliptin, a DPP-IV inhibitor has been shown in a clinical trial to very effectively prevent acute GVHD [8]. Importantly, experimental [12] and human studies [8] targeting CD26 for prevention of GVHD suggest that the graft-versus-leukemia effect remains preserved making this an even more attractive option for prevention and treatment of acute GVHD. The predictive and prognostic values of CD26 and their comparisons with some other known predictive and prognostic biomarkers (like ST2 and Reg3a) [11] remains to be studied.

Infused CD34 ${}^{+}$ cell dose is a known predictor of post-stem cell transplantation recovery. In our study too, infused CD34 ${}^{+}$ cell dose demonstrated a significant negative association with aGVHD incidence post-transplantation. High infused CD34 ${}^{+}$ cell dose of stem cell harvest led to reduced risk of developing aGVHD in transplant recipients. However, there have been conflicting reports published concerning infused CD34 ${}^{+}$ cell dose as a predictor of risk for developing GVHD [5, 18]. As we observed in our current study CD26 expression and infused CD26 dose as positive predictors for risk of developing aGVHD, we wanted to evaluate if CD26 expression has any correlation with infused CD34 cell dose. It was observed that neither CD26 expression nor infused CD26 cell dose correlated with infused CD34 dose of stem cell harvest, hence high CD26 expression in stem cell harvest can be considered as an independent predictive marker of aGVHD occurrence post-transplantation.

Since circulatory CD26 (sCD26) carries enzymatic activity [23], it would also be important to correlate circulating levels of CD26 with the risk of developing GVHD. We could not evaluate sCD26 in the current long-term follow-up study, however, in our new ongoing prospective study we have been finding leads that sCD26 correlates negatively with the risk of GVHD occurrence (data not shown).

CD26 (DPP4) has been shown to be a therapeutic target in autoimmune diabetes (Type 1 Diabetes Mellitus, T1DM) patients [27]. Inhibitors of CD26 have demonstrated an increase in T-regulatory (Treg) cells and a decrease in Th1 cell response [20]. Preclinical trials with CD26 inhibitor therapy have led to reversal or delay in the onset of diabetes in streptozotocin-induced NOD-SCID mice model of autoimmune T1DM [13, 29]. In mouse models of aGVHD, down-regulation of CD26 prevented GVHD but retained graft-versus-tumor effect. Further a two-stage, phase 2, a non-randomized clinical trial conducted to test the therapeutic effect of CD26 inhibitor – sitagliptin along with immunosuppressors tacrolimus and sirolimus resulted in considerable reduction in the incidence of grade II to IV acute GVHD by day 100 post-stem cell transplantation with filgrastim-mobilized blood cells from HLA-matched related or unrelated donors [8]. These studies have focused on exploring CD26 as a therapeutic target to improve stem cell transplantation clinical outcome. As against, our study is the first study which shows CD26 surface receptor on stem cell harvest as a predictive biomarker for risk of developing aGVHD post-transplantation.

Our study has limitations of small sample size, heterogenous diagnosis, and different conditioning regimens. Additionally, the stem cell source included marrow as well as peripheral blood stem cells. Also, we could not perform a multivariate analysis because of the small sample size. Nonetheless, our study does provide an important insight into the potential role of an easily measurable surface protein CD26 as a predictive biomarker of acute GVHD.

Summarizing, our study forms the first study demonstrating the association of CD26 expression and/or infused CD26+ cell dose with engraftment and acute GVHD. It adds to the existing body of literature in suggesting that CD26 may be a potential target for prophylaxis and treatment of GVHD. Further studies are warranted to explore the association of CD26 with GVHD. Additionally, studies are also warranted to address whether CD26 expression could potentially be used to individualize GVHD prophylaxis.

Funding

This work was supported by a grant from the Indian Co-operative Oncology Network-Academic Research Organization, Mumbai, India. (Project # 266, grant to KP).

Author information

Sachin Punatar and Shruti Kandekar contributed equally to this work.

Author contributions

Conception: Jyoti Kode, Sachin Punatar, Kumar Prabhash and Navin Khattry.

Interpretation or analysis of data: Jyoti Kode, Navin Khattry, Sachin Punatar, Anant Gokarn, Kumar Prabhsh, Ashish Bakshi, Pallavi Rane, Libin Mathew, Shubhada Chiplunkar.

Preparation of the manuscript: Jyoti Kode, Sachin Punatar, Shruti Kandekar and Navin Khattry.

Revision for important intellectual content: Kumar Prabhash, Shubhada Chiplunkar.

Supervision: Jyoti Kode, Sachin Punatar, Navin Khattry.

Final approval of the manuscript: Jyoti Kode, Sachin Punatar and all coauthors.

Research involving human participants

Informed consent for participation in this study was obtained in accordance with guidelines by Institutional Ethics Committee (IEC-I, Tata Memorial Centre, Mumbai), with approval from the IRB (Study # 266; IEC approval dated 16/June/2006. The experiments described here were performed in ACTREC, Tata Memorial Centre, Navi Mumbai, in accordance with IEC regulations.

Consent to participate

Written informed consent was obtained from the donors and patients selected for stem cell transplant procedure.

Supplementary data

The supplementary files are available to download from https://dx-doi-org.web.bisu.edu.cn/10.3233/CBM-210137.

sj-docx-1-cbm-10.3233_CBM-210137.docx - Supplemental material

Supplemental material, sj-docx-1-cbm-10.3233_CBM-210137.docx

Footnotes

Acknowledgments

Study was funded by Indian Co-operative Oncology Network-Academic Research Organization, Mumbai, India. The authors thank all the patients, their families, healthy donors and the support groups who cared for participants for their contributions to this study. Authors wish to acknowledge the support provided by Transfusion department and flow cytometry facility of the institute.

Conflict of interest

The authors declare that they have no conflict of interest.
