Diagnostic and prognostic utility of TROP-2,SLP-2,and CXCL12 expression in papillary thyroid carcinoma

Abstract

BACKGROUND:

Papillary thyroid carcinoma (PTC) is the most frequent thyroid malignancy. Histopathological examination is widely accepted as the gold standard test for the diagnosis of PTC. However, the histopathological examination sometimes can’t differentiate PTC from other thyroid diseases. Differentiating PTC from other thyroid diseases is essential for a therapeutic approach and prognosis.

OBJECTIVES:

The current study was performed to investigate the utility of TROP-2, SPL-2, and CXCL12 mRNA and protein expression in discriminating PTC from other thyroid diseases that mimic PTC.

METHODS:

The current study was performed on 75 cases of surgically resected thyroid glands. The cases were distributed in two groups: the PTC group and the non-PTC group. The PTC group consisted of 35 cases (25 patients of the classic PTC variant and 10 patients of the PTC follicular variant). The non-PTC group consisted of 40 cases (10 cases were multinodular goiter, 5 cases were Graves’ disease, 5 cases were Hashimoto thyroiditis, 15 patients were follicular adenoma (FA) and 5 cases were follicular carcinoma). TROP-2, SPL-2, and CXCL12 mRNA expression were estimated by qRT-PCR, and protein expression was estimated by immunohistochemistry.

RESULTS:

There were upregulated TROP-2, SPL-2, and CXCL12 mRNA and protein expressions in PTC compared to non-PTC ( $P<$ 0.001, for each). There was a statistically significant upregulation in the mRNA expression of the three genes among PTC cases with larger tumor sizes ( $P<$ 0.001, for each), those with tumor stages III and IV ( $P=$ 0.008, 0.002 and $<$ 0.001 respectively), and those with LN metastasis ( $P<$ 0.001, for each). Moreover, there was a statistically significant upregulation in CXCL-12 gene expression among PTC cases with extra-thyroid extension ( $P<$ 0.001).

CONCLUSION:

mRNA expression of TROP-2, SPL-2, and CXCL12 among PTC cases increased in larger tumor size, tumor stages III and IV, and LN metastasis. Moreover, there was an increase in CXCL-12 gene expression among PTC cases with extra-thyroid extension. Thus, TROP-2, SPL-2, and CXCL12 expressions could be possible diagnostic and prognostic markers in PTC.

Keywords

TROP-2 SPL-2 CXCL12 papillary thyroid carcinoma

Abbreviations

PTC	Papillary thyroid carcinoma
TROP-2	Trophoblast cell surface antigen-2
Tacstd2	the tumor associated calcium signal
	transducer 2
SLP-2	Stomatin-like protein-2
CXCL12	Chemokine (C-X-C motif) ligand 12
ROC	Receiver Operator Curve

1. Introduction

Papillary thyroid carcinoma (PTC) is the most prevalent primary malignant thyroid tumor. It represents about 80% of thyroid cancer cases worldwide. It has a low aggressive behavior and a favorable outcome [1]. In Egypt, primary thyroid tumors constitute 1.96% of malignant tumors and represent 74.7% of malignant endocrine neoplasms. PTC represents the most prevalent primary malignant thyroid tumor (70.94% of all thyroid malignant tumors) [2].

Histopathological examination is widely accepted as the gold standard test in PTC diagnosis. Most PTC cases can be diagnosed and categorized depending on the histopathologic examination. However, the histopathologic examination sometimes can’t differentiate between PTC and other similar diseases [3].

To remove this discrepancy and reach a final diagnosis, a variety of immunohistochemical and biochemical markers have been investigated. Several studies used immunohistochemical markers to distinguish PTC from other thyroid lesions such as HBME-1, galectin-3, and cytokeratin 19. Some difficulties were associated with those markers including low specificity, variable sensitivity, and background staining. So, we require novel markers with high sensitivity and specificity to improve PTC diagnosis [3].

Trophoblast cell surface antigen-2 (TROP-2) is a transmembrane glycoprotein encoded by the tumor-associated calcium signal transducer 2 (Tacstd2) gene. Originally, it was found in human trophoblast and choriocarcinoma cell lines. It acts as a cell surface receptor where it recognizes certain ligands and increases the intracellular calcium [4]. Also, it is an oncogene that is upregulated in several human cancers with low to no expression in normal tissues [5]. Its upregulation has been correlated with poor prognosis in different cancers [6], as it has pro-proliferative and pro-invasive properties [9, 10]. Moreover, it is an immunotherapeutic target [3]. In thyroid cancer, TROP-2 was significantly elevated [22, 31, 1]. Additionally, TROP-2 immunostaining may differentiate PTC from other thyroid carcinomas or normal follicular tissues [25, 7, 8].

Stomatin-like protein-2 (SLP-2) belongs to the stomatin family. It is identified as a mitochondrial inner membrane protein encoded by the gene STOML2. It plays a role in controlling mitochondrial membrane stability and function [13]. It was strongly associated with many human cancers, such as gallbladder and cervical cancers [11, 12]. Liu et al. [10] found that SLP-2 mRNA and protein expression were overexpressed in PTC.

Chemokine (C-X-C motif) ligand 12 (CXCL12), also named stromal cell-derived factor-1 (SDF-1), belongs to the chemokine family that binds to CXCR4. The biological effect of CXCL12 is attributed to CXCR4-mediated activation of G protein-coupled signaling molecules, including ERK1/2, MAPK, JNK, and AKT [14, 15]. Also, it has a powerful chemotactic ability to lymphocytes. Moreover, it has an important role in angiogenesis, carcinogenesis, and tumor migration [17]. Chung et al. [35] demonstrated that CXCL12 was exclusively upregulated in PTC whatever the histopathological subtype when compared to other thyroid lesions. Also, Zhu et al. [36] found that CXCL12 was exclusively expressed in PTC tissue samples while it was not expressed in benign thyroid lesions and other thyroid malignancies.

Distinguishing PTC from other thyroid lesions is important because it determines the therapeutic intervention and prognosis. However, the pathological findings sometimes can’t differentiate between PTC and other thyroid lesions. Thus, our study aimed to evaluate the utility of TROP-2, SPL-2, and CXCL12 mRNA and protein expression in distinguishing PTC from other thyroid lesions that mimic PTC.

Table 1
Primer sequence of the studied genes

	Forward	Reverse
TROP2	5’-ACAACGATGGCCTCTACG AC-3’	5’-GTCCAGGTCTGAGTGGT TGAA-3’
SLP-2	5’-GTGACTCTCGACAATGTAAC-3’	5’-TGATCTCATAACGGAGGCAG-3’
CXCL12	5’-ATTCTCAACACTCCAAACTGTGC	5’-ACTTTAGCTTCGGGTCAATGC-3’
$\beta$ actin	5’-CACGAAACTACCTTCAACTCC-3’	5’-CATACTCCTGCTTGCTGATC-3’

2. Material and methods

This study was conducted on 75 surgically resected thyroid glands after written informed consent from patients attending the Zagazig University Hospitals and Surgical Oncology Department, Ismailia Teaching Oncology Hospital, Egypt during the period between October 2021 and March 2023. The cases were distributed in two groups: the PTC and the non-PTC groups. The PTC group consisted of 35 cases (25 patients of the classic PTC variant and 10 patients of the follicular variant PTC (FVPTC)). The non-PTC group consisted of 40 cases (10 cases were multinodular goiter, 5 patients were Graves’ disease, 5 patients were Hashimoto thyroiditis, 15 patients were follicular adenoma (FA) and 5 cases were follicular carcinoma). Exclusion criteria included patients with indefinite diagnosis or equivocal features. The classification and evaluation of thyroid tumors were performed depending on the 4^th edition WHO Classification of Tumors of Endocrine Organs in 2017 [18].

Immediately after surgery, the resected tissues were divided into 2 parts. The first was preserved at $-$ 80^∘C till further processing and the other part was kept in formalin for further pathological examinations.

Clinicopathological data including age, sex, tumor size, lymph node involvement, and distant spread were recorded. PTC patients were staged according to the pathological TNM system of the American Joint Committee of Cancer 8^th edition 2017. Our study got approval from the institute review board (IRB), (ZU-IRB # 10022/25-10-2022).

2.1 RNA extraction, cDNA synthesis, and qRT-PCR

RNA extraction from the homogenates of thyroid tissues was carried out by GENEzol^TM (Geneaid). Nanodrop spectrophotometry (ND 1000-NanoDrop^®) was used to estimate the quality and the quantity of the extracted RNA. Then, TOPscript^TM cDNA Synthesis Kit (Enzynomics) was used for the synthesis of cDNA. Real-time polymerase chain reaction was carried out using Rotor-Gene Q 2 Plex (Qiagen, Hilden, Germany). The relative gene expressions of TROP-2, SLP-2 and CXCL12 were calculated with the 2^-ΔΔct method. $\beta$ -actin was used as a housekeeping gene. The sequence of the used primers is listed in the Table 1 [1, 19].

2.2 Histopathological examination of thyroid tissues

Thyroid tissues were preserved in formalin. After paraffin block formation, tissue sectioning into 4-micrometer sections was performed. Staining with hematoxylin and eosin was performed [20].

2.3 Immunohistochemical staining

The staining was performed on 4-micrometer thickness tissue samples. Absolute ethyl alcohol was used to remove the paraffin-xylene solution. Tissue sections were incubated for an hour with an anti-TROP-2 antibody (Santa Cruz Biotechnology, USA) at 1:40 dilution, an anti-SLP-2 antibody (Proteintech Group, Chicago, IL, USA) at 1:200 dilution, and an anti-CXCL12 antibody (R&D Systems, Minneapolis, MN, USA) at 1:50 dilution. Mayer’s hematoxylin was used as a counterstain.

2.4 Assessment of immunohistochemical stains

Regarding TROP-2 expression, the extent of membranous staining was evaluated. Samples with no staining or membranous staining in less than 5% of cells were classified as negative and membranous staining of more than 5% of the cells was categorized as positive. Positive cases were graded as 1 $+$ (5–25%), 2 $+$ (26–50%), 3 $+$ (51–75%), and 4 $+$ ( $>$ 75%). Scores of 1 $+$ , 2 $+$ , 3 $+$ , and $+$ 4 were considered positive, and a score of 0 was considered negative [21].

Regarding SLP-2 expression, the extent of cytoplasmic staining was evaluated. Samples with no staining or staining less than 10% of cells were classified as negative and cases with a cytoplasmic expression of more than 10% were categorized as positive [1].

Regarding CXCL12 expression, the extent of cytoplasmic staining was graded from 0 to 3 $+$ as follows: 0, negative; 1 $+$ , focal weak staining; 2 $+$ , diffuse weak or focal strong staining; and 3 $+$ , diffuse strong staining. Scores of 1 $+$ , 2 $+$ , and 3 $+$ were considered positive, and a score of 0 was considered negative [17].

2.5 Statistical analysis

The continuous data were represented as mean $\pm$ standard deviation (SD) and analyzed by $t$ -test. Comparing the categorical variables between groups was analyzed by the $\chi^{2}$ test or Fisher’s exact test. $P<$ 0.05 was considered statistically significant.

Table 2
Basic characteristics among both studied groups

		Group I (non-PTC) $N=$ 40	Group II (PTC) $N=$ 35	$t$ -test/ $X^{2}$	$P$
Age $\backslash$ years		44.5 $\pm$ 10.6	46.7 $\pm$ 15.2	0.676	0.508
Gender	Male	10 (25%)	7 (20%)	0.266	0.605
	Female	30 (75%)	28 (80%)
Positive TROP-2 IHC expression		2 (5%)	34 (97.1%)	63.4	$<$ 0.001^**
Positive SLP-2 IHC expression		3 (7.5%)	31 (88.6%)	49.3	$<$ 0.001^**
Positive CXCL-12 IHC expression		1 (2.5%)	33 (94.3%)	63.5	$<$ 0.001^**
TROP-2 gene expression		1.18 $\pm$ 0.72	4.49 $\pm$ 0.26	77.2	$<$ 0.001^**
SLP-2 gene expression		1.15 $\pm$ 0.53	3.03 $\pm$ 0.27	46.7	$<$ 0.001^**
CXCL-12 gene expression		1.09 $\pm$ 0.47	2.52 $\pm$ 0.56	16.9	$<$ 0.001^**

^*: a significant difference; ^**: a highly significant difference.

Table 3

Relation between genes expression and basic characteristics of the lesion among studied PTC cases

Variables	PTC cases $N=$ 35		TROP-2 gene expression		$P$	SLP-2 gene expression		$P$	CXCL-12 gene expression		$P$
Tumor size
$<$ 2 cm	12	(34.3%)	4.28	$\pm$ 0.119	$<$ 0.001^**	2.81	$\pm$ 0.178	$<$ 0.001^**	2.07	$\pm$ 0.192	$<$ 0.001^**
$>$ 2 cm	23	(65.7%)	4.59	$\pm$ 0.247		3.15	$\pm$ 0.237		2.76	$\pm$ 0.543
TNM stage
I–II	31	(88.6%)	4.45	$\pm$ 0.23	0.008^*	2.98	$\pm$ 0.24	0.002^*	2.38	$\pm$ 0.42	$<$ 0.001^**
III–IV	4	(11.4%)	4.8	$\pm$ 0.26		3.4	$\pm$ 0.18		3.6	$\pm$ 0.26
T stage
I–II	25	(71.4%)	4.4	$\pm$ 0.21	$<$ 0.001^**	2.93	$\pm$ 0.23	$<$ 0.001^**	2.3	$\pm$ 0.396	$<$ 0.001^**
III–IV	10	(28.6%)	4.75	$\pm$ 0.25		3.3	$\pm$ 0.21		3.16	$\pm$ 0.48
LN metastasis
Positive	12	(34.3%)	4.69	$\pm$ 0.24	$<$ 0.001^**	3.25	$\pm$ 0.21	$<$ 0.001^**	3.03	$\pm$ 0.51	$<$ 0.001^**
Negative	23	(65.7%)	4.38	$\pm$ 0.201		2.92	$\pm$ 0.23		2.26	$\pm$ 0.38
Extra-thyroid extension
Positive	2	(5.7%)	4.8	$\pm$ 0.14	0.08	3.35	$\pm$ 0.21	0.09	3.8	$\pm$ 0.14	$<$ 0.001^**
Negative	33	(94.3%)	4.47	$\pm$ 0.25		3.01	$\pm$ 0.26		2.44	$\pm$ 0.47

^*: significant difference; ^**: highly significant difference.

3. Results

3.1 Clinicopathological features

There was no significant difference in age between PTC and non-PTC patients ( $P=$ 0.508). The mean ages $\pm$ SD were 46.7 $\pm$ 15.2 and 44.5 $\pm$ 10.6, respectively. Also, there was no significant difference regarding in gender between PTC and non-PTC patients ( $P=$ 0.605) (Table 2).

Regarding PTC cases, twelve patients (34.3%) had tumor sizes less than 2 cm while 23 (65.7%) patients had tumor sizes more than 2 cm. Thirty-one patients (88.6%) were I–II TNM stage while 4 patients (11.4%) were III–IV TNM stage. Twenty-five patients (71.4%) were I–II T stage while 10 patients (28.6%) were III–IV T stage. Twelve patients (34.3%) had lymph node metastasis and two patients (5.7%) had extra-thyroid extension (Table 3).

3.2 Histopathological and immunohistochemical results

H&E staining showed that PTC sections had papillary projections with nuclear features of PTC (Fig. 1A). FVPTC sections showed capsulated tumors with prominent nuclear features of PTC (Fig. 1B). Colloid goiter sections showed variable-sized follicles with flat lining (Fig. 1C). Graves’ disease showed hyperplastic thyroid follicles with papillary projections (Fig. 1D). Hashimoto thyroiditis sections showed prominent lymphoid follicles with abundant Hurthle cells (Fig. 1E). Follicular adenoma sections showed intact capsules (Fig. 1F). Follicular carcinoma showed thickened capsules with full thickness penetration (Fig. 1G) with prominent atypia and mitosis (Fig. 1H).

Figure 1.

(A) PTC: papillary projections with nuclear features of PTC (X 200), (B) FVPTC: capsulated tumor with prominent nuclear features of PTC (X200), (C) Colloid goiter: variable sized follicles with flat lining (X100), (D) Graves’ disease: hyperplastic thyroid follicles with papillary projections (X200), (E) Hashimoto thyroiditis: prominent lymphoid follicles with abundant hurthle cells (X100), (F) follicular adenoma with intact capsule (X100), (G) Follicular carcinoma; thickened capsule with full thickness penetration (X100), (H) Follicular carcinoma with prominent atypia and mitosis (X200).

Figure 2.

TROP2 immunostaining: (A) PTC positive membranous staining (x400), (B) FVPTC: positive membranous staining (x200), (C) Colloid goiter: negative (x200), (D) Graves’ disease with papillary hyperplasia-negative (x400), (E) Hashimoto negative (x100), (F) Follicular adenoma negative (x200), (G) Follicular carcinoma negative (x200).

Figure 3.

SLP2 immunostaining: (A) PTC positive cytoplasmic staining (x200), (B) FVPTC: positive cytoplasmic staining (x200), (C) Colloid goiter: negative (x200), (D) Graves’ disease with papillary hyperplasia-negative (x200), (E) Hashimoto negative (x200), (F) Follicular adenoma negative (x200), (G) Follicular carcinoma negative (x200).

Figure 4.

CXCL2 immunostaining: (A) PTC positive cytoplasmic staining (x400), (B) FVPTC: positive cytoplasmic staining (x200), (C) Colloid goitre: negative (x200), (D) Graves’ disease with papillary hyperplasia-negative (x200), (E) Hashimoto negative (x200), (F) Follicular adenoma negative (x200), (G) Follicular carcinoma negative (x200).

Our results revealed significant positive immunohistochemical expression of (TROP2, SLP2, and CXCL2) in the PTC group compared to the non-PTC group (Figs 2–4 respectively).

3.3 Relation between mRNA and protein expression and clinicopathological features in PTC

There was a highly statistically significant elevation in TROP-2, SPL-2, and CXCL12 mRNA and protein expression among the PTC group ( $P<$ 0.001) (Table 2). There was a statistically significant upregulation in the three gene expressions among PTC cases with larger tumor size ( $P<$ 0.001 for each), tumor stages III and IV ( $P<$ 0.001 for each), and TNM stages III and IV (0.008, 0.002 and $<$ 0.001 respectively). There was a statistically significant upregulation in CXCL-12 gene expression among PTC cases with extra-thyroid extension ( $P<$ 0.001) (Table 3). However, none of the clinicopathological parameters was related to the three markers’ IHC expression (Table 4).

Table 4
Relation between immune-histochemistry results of TROP-2, SLP-2, CXCL-12 and tumor characteristics

		TROP2		$P$	SLP-2		$P$	CXCL-12		$p$
		Positive	Negative		Positive	Negative		Positive	Negative
T size	$<$ 2 cm ( $n=$ 12)	11 (91.7%)	1 (8.3%)	0.343	9 (75%)	3 (25%)	0.106	12 (100%)	0 (0.0%)	0.536
	$>$ 2 cm ( $n=$ 23)	23 (100%)	0		22 (95.7%)	1 (4.3%)		21 (91.3%)	2 (8.7%)
LN metastasis	Yes ( $n=$ 12)	12 (100%)	0	0.665	12 (100%)	0	0.275	10 (83.3%)	2 (16.7%)	0.111
	No ( $n=$ 23)	22 (95.7%)	1 (4.3%)		19 (82.6%)	4 (17.4%)		23 (100%)	0 (0.0%)
Distant metastasis	M0 ( $n=$ 34)	33 (97.1%)	1 (2.9%)	0.971	30 (88.2%)	4 (11.8%)	0.971	32 (94.1%)	2 (5.9%)	0.943
	M1 ( $n=$ 1)	1 (100%)	0		1 (100%)	0		1 (100%)
Extra-thyroid extension	Yes ( $n=$ 2)	2 (100%)	0	0.943	2 (100%)	0	0.793	2 (100%)	0	0.889
	No ( $n=$ 33)	32 (97%)	1 (3%)		29 (87.9%)	4 (12.1%)		31 (93.9%)	2 (6.1%)

3.4 Receiver Operator Curve (ROC) for TROP2, SLP2 and CXCL2

Receiver Operator Curve (ROC) analysis of TROP-2 gene expression detected that the sensitivity was 94.3%, the specificity was 97.5%, the positive predictive value (PPV) was 97.1%, the negative predictive value (NPV) was 95.1%, and the accuracy was 96% at a cut-off $>$ 4.15. SLP-2 sensitivity was 97.1%, the specificity was 92.5%, the positive predictive value (PPV) was 91.9%, the negative predictive value (NPV) was 97.4%, the accuracy was 94.7% at a cut-off $>$ 2.4. CXCL-12 sensitivity was 94.3%, the specificity was 97.5%, the positive predictive value (PPV) was 97.1%, the negative predictive value (NPV) was 95.1%, and the accuracy was 96% at a cut-off $>$ 1.85 (Fig. 5, Table 5).

Table 5
Receiver Operator Curve (ROC) curve analysis of studied gene expression as diagnostic predictors of PTC cases

Variable(s)	AUC	Cut-off	Sensitivity	Specificity	PPV	NPV	Accuracy	$P$
TROP-2 gene	0.976	$>$ 4.15	94.3%	97.5%	97.1%	95.1%	96%	$<$ 0.001
SLP-2 gene	0.966	$>$ 2.4	97.1%	92.5%	91.9%	97.4%	94.7%	$<$ 0.001
CXCL-12 gene	0.975	$>$ 1.85	94.3%	97.5%	97.1%	95.1%	96%	$<$ 0.001

Table 6

Function of the proteins encoded by the studied genes

Gene	Protein	Function	Reference
Tumor associated calcium signal transducer 2 (Tacstd2)	Trophoblast cell surface antigen-2 (TROP-2)	Regulates the level of intracellular calcium regulates epithelial cell migration and proliferation, cell growth, transformation, regeneration, and proliferation.	Lin et al., 2012
Stomatin-like protein 2 (STOML2)	Stomatin-like protein-2 (SLP-2)	Intracellular calcium ion homeostasis, mitochondrion organization, lipid localization, positive regulation of interleukin-2 production, mitochondrial protein processing.	Wang et al., 2014Xiao et al., 2015
C-X-C motif chemokine ligand 12	Chemokine (C-X-C motif) ligand 12 (CXCL12), stromal cell-derived factor-1 (SDF-1)	Chemoattractant active on T-lymphocytes and monocytes. Activates the CXCR4 to induce a rapid and transient rise in the level of intracellular calcium ions and chemotaxis. During embryonic development, B-cell lymphopoiesis, myelopoiesis in bone marrow and heart ventricular septum formation.	Lu et al., 2009 Roland et al., 2003 Lee et al., 2020

Figure 5.

Receiver Operator Curve (ROC) for TROP2, SLP2 and CXCL2.

4. Discussion

Regarding TROP-2 IHC expression, only 5% (2/40) of non-PTC cases showed positive TROP-2 expression. This result was similar to Addati et al. [22] who found that TROP-2 was positive in 6/56 of non-neoplastic samples, and Abdou et al. [3] who found that TROP-2 was positive in 4/21 of non-neoplastic samples. Saffar et al. found that TROP-2 was positive in 5/71 samples of the non-PTC group and all from Hashimoto thyroiditis samples. However, Nesreen et al. [24], Simms et al. [25], and Murtezaoglu et al. [26] did not find any positivity in non-neoplastic samples.

The only benign lesion that showed positive TROP-2 expression was Hashimoto thyroiditis which is attributed to the abundance of Hurthle cells in this lesion. These cells have endogenous biotin activity that may show odd positive staining patterns with several antibodies [27]. In addition, follicular cells in Hashimoto thyroiditis may show PTC-like nuclear changes and may carry the same genetic mutation as classical PTC and may express PTC-associated proteins. This mutation activates the mitogen-activated protein kinases (MAPK) pathway, the same pathway through which TROP-2 conveys its signals. Moreover, chronic lymphocytic thyroiditis has follicular epithelial dysplasia displaying cytological atypia resembling PTC with a similar immunohistochemical profile [28].

In our study, none of the follicular carcinoma samples showed positive TROP-2 expression. This is similar to earlier studies reported by Simms et al. [25], Bychkov et al. [8], Liu et al. [7], and Abdel Raouf et al. [29].

Our study showed positive membranous TROP-2 expression in 97.1% of PTC cases (34 out of 35). These results were consistent with the research conducted by Yang et al. [1], Zargari et al. [21], and Saffer et al. [23]. TROP-2 positivity was 96%, 93%, and 98% in them, respectively. On the other hand, the results were different from the research performed by Abdou et al. [3], Murtezaoglu et al. [26], Bychkov et al. [8], and Lui et al. [7] that reported lower TROP-2 expression in PTC (71.4%, 50%, 81.5%, and 81.6% respectively).

The current study showed that there is a significant difference in TROP-2 positive expression between PTC cases and non-PTC cases. This result is compatible with Abdou et al. [3], Addati et al. [22], Saffer et al. [23], Bychkov et al. [8], and Lui et al. [7] that reported that TROP-2 is a new marker in the diagnosis of PTC.

The diagnostic validity of TROP-2 in the PTC samples showed 94.3% sensitivity and 97.5% specificity, 97.1% PPV, 95.1% NPV and the accuracy was 96%. Similarly, Yang et al. [1] detected that TROP-2 sensitivity in PTC was 96% [1], on the other hand, Bychkov et al. [8] detected that TROP-2 sensitivity in PTC was 75%, but the specificity was 98.4%.

None of the clinicopathological parameters was related to TROP-2 IHC expression. This result was similar to the previous studies performed by Yang et al. [1], Bychkov et al. [8], and Kong et al. [30]. However, TROP-2 positive expression may indicate poor PTC prognosis and be associated with advanced tumor stage as detected by Guan et al. [31].

As regards SLP-2 expression, the current study showed that only 7.5% (3/35) of the non-PTC cases showed positive SLP-2 expression, and 88.6% of PTC cases (31 out of 35) showed positive cytoplasmic expression. This finding was compatible with that found by Yang et al. [1] who found 83.3% of PTC cases showing positive SLP-2 expression. Also, they stated that the mRNA expression and positive SLP-2 staining in PTC were higher than in follicular adenoma with no association with any of the clinicopathological features similar to our findings. They reported that SLP-2 sensitivity was 83.3%, specificity was 79.3%, PPV was 80.6%, NPV was 82.1%, and accuracy was 81.4%.

Liu et al. [7] reported that SLP-2 mRNA and protein expressions were upregulated in PTC cases. 72% (77 out of 107) of PTC cases were positive for SLP2 expression. Similar to our findings, upregulated SLP-2 m RNA was correlated with larger tumor sizes, advanced tumor stages, and lymph node metastasis. They concluded that SLP-2 is a marker for the diagnosis of classic PTC. However, no differences in SLP-2 expression regarding age, gender, or multifocal tumors were detected. SLP-2 expression was strongly correlated with primary tumor size where its expression in T1 cases (tumor $<$ 2 cm) was significantly different from its expression in other stages. There were no differences in SLP-2 expression among T2-T4 cases. Those findings supported the prognostic role of SLP-2.

Bartolome et al. [32] reported that 97 of 150 (65%) PTCs were SLP-2 positive. Benign thyroid tissue did not have SLP-2 immunostaining. Follicular carcinomas and anaplastic carcinomas (except in one case) showed no or weak/focal SLP-2 expression. They indicated that SLP-2 was a possible marker for the recognition of high-risk PTC. SLP-2 expression was higher in the classic PTC than in the follicular variant of PTC. Different from our findings, significant positive correlations were detected between increased SLP-2 and lymph node spread, extra-thyroid spread, and higher tumor stages. Similar to our findings, no correlations were detected between SLP-2 expression and other clinicopathological features of the patients (age, gender, tumor size).

Additionally, the expression of SLP-2 was significantly associated with clinicopathological features and the expression of Ki-67, a cell proliferation marker. Moreover, western blot results showed that SLP-2 was upregulated by TGF- $\beta$ 1, a cytokine with a key role in PTC tumorigenesis. They found that SLP-2 was clinically relevant to the invasion of PTC.

As regards CXCL12 IHC, our study reported that 94.3% (33 out of 35) of PTC cases showed positive CXCL12 expression. This result was compatible with Conley-LaComb et al. [33]. CXCL12 had 90.8% sensitivity, 96.8% specificity, 98.9% PPV, 76.9% NPV, and 92.2% accuracy in tissue specimens of PTC and with Jung et al. [34] that reported 93.6% sensitivity, 88.6% specificity, 91.7% PPV, 91.2% NPV, and 91.5% accuracy and suggested that CXCL12 may be a supplementary diagnostic marker for PTC. Lee et al. [17] showed that CXCL12 immunoreactivity had 98.3% sensitivity, 93.5% specificity, 96.6% PPV, 96.7% NPV, and 96.6% accuracy in TMA specimens. Chung et al. [35] found that CXCL12 expression was exclusively detected in PTC compared to other thyroid diseases. 91.1% of the variant PTCs and 90.6% of the classical type were associated with CXCL12 immunohistochemical expression, irrespective of the histological subtype. On the other side, very few thyroid lesions, excluding PTC, were positive for CXCL12. The Validity of CXCL12 in PTC showed 90.8% sensitivity, 96.8% specificity, 98.9% PPV, 76.9% NPV, and 92.2% accuracy.

In contrast, Zhu et al. [36] found that CXCL12 expression was detected in 75% of PTC cases and 10% of follicular adenoma cases but was not detected in other studied cases.

In our study, TROP-2, SLP-2, and CXCL-12 mRNA expressions were upregulated in PTC. Similarly, Liu et al. [10] were the first to detect SLP-2 overexpression (mRNA and protein levels) in PTC samples. Similar to our findings, SLP-2 upregulation was significantly associated with LN involvement and tumor stage where it was correlated with tumors $>$ 1 cm in size, advanced-stage tumors and lymph node metastasis. Our results were also similar to that found by Yang et al. [1]. They found upregulated TROP-2 and SLP-2 mRNA expressions in PTC compared to follicular adenomas (FA). In contrast to our findings, no correlation was found between their expressions and the clinicopathological factors. They stated that TROP-2, SLP-2, and CD56 were possible diagnostic markers for PTC, especially when combined. Similar to our findings, Guan et al. [31] found that TROP-2 was associated with TNM staging and N classification. MMP2 expression was upregulated by TROP-2. Bartolome et al. [32] stated that upregulated SLP-2 in the aggressive PTC had a close relationship with BRAF mutation, and SLP-2 could help in the identification of high-risk PTC.

Regarding the potential mechanisms of TROP-2 in PTC carcinogenesis, it was found to enhance the invasion of thyroid cancer by inducing MMP2 through ERK and JNK pathways [31]. Also, CXCL12 plays an important role in angiogenesis and carcinogenesis, including tumor migration [17]. Its effect is related to CXCR4-mediated activation of G protein-coupled signaling molecules, including ERK1/2, MAPK, JNK, and AKT [14, 15]. In anaplastic thyroid cancer cells in particular, CXCL12/CXCR4 axis-mediated migration has been reported which is associated with AKT and ERK activation [16]. Zhu et al. [36] added that CXCL12/CXCR4/CXCR7 axis may contribute to thyroid cancer development by regulating cancer cell migration/invasion via AKT and ERK signaling and MMP-2 activation.

SLP-2 is upregulated in mitochondrial stress and interacts with prohibitins and chaperones in the mitochondrial inner membrane. It is required for stress-induced mitochondrial hyperfusion. Its upregulation increases the mitochondrial membrane phospholipid cardiolipin content and binds to cardiolipin to induce mitochondrial biogenesis [13]. Its expression is regulated by transforming growth factor- $\beta$ (TGF- $\beta$ ), a cytokine that plays an important role in PTC tumorigenesis [37] where a correlation between TGF- $\beta$ signaling and EMT was also found in poorly differentiated thyroid carcinoma [39]. The TGF- $\beta$ /Smad signaling pathway is involved in the epithelial-mesenchymal transformation, local invasion, and LN metastasis of PTC [38].

5. Conclusion

TROP-2, SPL-2, and CXCL12 expressions could be possible diagnostic and prognostic markers in PTC. mRNA and protein expression of the three markers were increased in PTC cases compared to non-PTC. They were also significantly increased in PTC cases with larger tumor size, tumor stages III and IV, and LN metastasis. Moreover, there was a statistically significant increase in CXCL-12 gene expression among PTC cases with extra-thyroid extension.

Funding

None.

Author contributions

Conception: Amany Selim Attia, Samia Hussein, and Reham Sameh.

Interpretation or analysis of data: Hend Sameh, Amr Khalil, Ahmad Barakat Waley, and Ihab Matar.

Preparation of the manuscript: Amany Selim Attia and Samia Hussein.

Revision for important intellectual content: Reham Sameh and Samia Hussein.

Supervision: Reham Sameh and Samia Hussein.

Footnotes

Acknowledgments

None.

Conflict of interest

None.
