Effects of the direction of kinesiology tape application on the delayed onset of quadriceps muscle fatigue in athletes

Abstract

BACKGROUND:

A number of studies have assessed the effect of kinesiology tape (KT) application with respect to the delayed onset of muscle fatigue.

OBJECTIVE:

To determine the effects of direction of KT application on the delayed onset of quadriceps fatigue.

METHODS:

An isokinetic dynamometer was used to induce concentric quadriceps fatigue in 15 healthy participants prior to applying KT. The KT was randomly applied on the muscles in two possible orientations: from origin to insertion or from insertion to origin. After the application the number of repetitions of knee extension required to induce fatigue was recorded.

RESULTS:

Regardless of the direction of application, the number of repetitions needed to generate muscle fatigue increased after the KT was applied. On the other hand, there was no significant difference between taping directions.

CONCLUSIONS:

KT application on the quadriceps delays the onset of its isokinetically-induced fatigue, irrespective of the direction of application. Therefore, using KT may be considered as a possible technique in those tasks where fatigue may seriously hamper performance.

Keywords

Isokinetic KT fatigue delayed onset peak moment

1. Introduction

Application of KT during sports activities is used for the purposes of injury prevention [1], functional improvement [2], and reduction of muscle fatigue [3]. In this way, it is used not only for immobilization, but also for therapeutic purposes [4]. The primary cause of sports injuries is reported to be imbalance between joints and muscles, which control agile movement [5]. In particular, the inability of the nervous system to smoothly control muscle contraction due to fatigue is considered the primary cause of the higher incidence of sports injuries during the second half of an event in comparison to the first half [6].

Figure 1.

Flow diagram for the study.

Fatigue is associated with muscle activity and reduced muscle performance [7]. Moreover, fatigue develops from complex and diverse processed involving nervous system activities and muscle metabolism, calcium secretion from the sarcoplasmic reticulum, and interaction between myosin and actin [8]. After muscle fatigue, the risk of injury and pain increases, while physical performance also decreased [9, 10]. Methods for preventing and reducing such muscle fatigue include stretching, massage, electrostimulation, and KT. In particular, KT can be applied directly to the skin to provide the effects of pain relief through mechanical stimulation [11], improved joint range of motion (ROM) [11, 12, 13], and alignment [14] increased muscle strength [15, 16, 17].

Yeung et al. [18] reported that applying KT to the quadriceps muscles had the effect of increased muscle strength, while Huang et al. [2] reported that applying KT on the gastrocnemius muscle increased muscle activities. Studies that applied KT on athletes after musculoskeletal injury demonstrated the efficacy of such an intervention in facilitating the return to sports [19, 20, 21]. Ward et al. reported that applying KT on the patella and anterior thigh of fatigued runners had the effect of reducing their level of fatigue [22]. However, there are few studies that have assessed the effect of KT application with respect to the delayed onset of muscle fatigue.

Accordingly, the present study applied KT while inducing muscle fatigue in the quadriceps muscles with an isokinetic device for the purpose of investigating the effects of such application on delaying the onset of muscle fatigue and the effects of the direction of KT application on delaying the onset of muscle fatigue.

2. Methods

2.1 Participants

The present study recruited a total of 15 athletes (10 males and 5 females) who consented to participate in the study (19.53 $\pm$ 2.42 years; 176.93 $\pm$ 6.9 cm in height; 72.87 $\pm$ 13.02 kg in weight) (Table 1). All subjects had no limitations in activities of daily living due to knee pain; no previous history of surgery; no joint deformity; and no low back pain. The present study received the approval from the Institutional Review Board at Dong-Eui University (DIRB-201708-HR-E-030).

Table 1
General characteristics of the subjects

	Experimental ( $n=$ 15)
Gender (Male/Female)	10/5
Dominant (Right/Left)	15/0
Age (years)	19.53	$\pm$ 2.42 ${}^{\dagger}$
Height (cm)	176.93	$\pm$ 6.9
Weight (kg)	72.87	$\pm$ 13.02

${}^{{\dagger}}$ Mean $\pm$ SD.

2.2 Study design

The present study used a single blind, crossover design and applied KT on 15 subjects in random directions over the course of one week interval. The experimental design is shown in Fig. 1. An isokinetic dynamometer was used to measure and record the peak moment (PM) of the quadriceps first. Applying a fatigue protocol [23], fatigue in this muscle was induced using the dynamometer without applying KT for providing the resistance and, recording the number of repetitions of knee joint motion required to induce muscle fatigue. One week later, the KT was applied on the quadriceps in random direction, after which the fatigue protocol was repeated. Following another week, KT was applied in the direction opposite of the previous application and the number of repetitions of knee joint motion required to induce muscle fatigue was again recorded.

2.3 Instrumentation

A Biodex system 4 (Biodex Medical System Inc., New York, USA), was used to induce quadriceps fatigue and measure PM.

2.4 The taping technique

With the knee bent at 90 ${}^{\circ}$ , approximately 2 $\sim$ 3 cm of KT (BB Tape, WETAPE Inc., Pyeongtaek, Korea) was stretched by approximately 20 $\sim$ 25%. Importantly, the beginning and end portions of the tape were not stretched. The KT was applied to 3 of 4 muscles that constitute the quadriceps: the rectus femoris, vastus lateralis, and vastus medialis [24, 25, 26, 27]. The direction of tape application was from: the origin (anterior superior iliac spine) to insertion (superior border of the knee) for the rectus femoris [Fig. 2A(A)]; from the medial aspect of the origin (intertrochanteric line) to insertion (medial superior aspect of the knee) for the vastus medialis [Fig. 2A(B)]; and from the origin (greater trochanter of femur) to insertion (lateral superior knee) for the vastus lateralis [Fig. 2A(C)] [24, 28]. The direction of tape application was from insertion (superior border of the knee) to origin (anterior superior iliac spine) for the rectus femoris [Fig. 2B(A)]; from insertion (medial superior aspect of the knee) to the medial aspect of the origin (intertrochanteric line) of the vastus medialis [Fig. 2B(B)]; and from insertion (lateral superior knee) to the origin (greater trochanter of femur) for the vastus lateralis [Fig. 2B(C)] [24, 28].

Figure 2.

Application of KT in quadriceps: A, Origin to insertion direction; (A) rectus femoris, (B) vastus medialis, (C) vastus lateralis; B, Insertion to origin direction; (A) rectus femoris, (B) vastus medialis, (C) vastus lateralis.

Table 2

Comparison of the required number of repetitions to induce quadriceps muscle fatigue prior to and after intervention

Variables		Repetition number		$p$
		Pre	Post
Origin to insertion	60 ${}^{\circ}$ /sec	184.68 $\pm$ 35.50 ${}^{{\dagger}}$	209.18 $\pm$ 38.20	0.001 ${}^{\ast}$
Insertion to origin	60 ${}^{\circ}$ /sec	186.00 $\pm$ 41.77	212.51 $\pm$ 40.05	0.000 ${}^{\ast}$

${}^{{\dagger}}$ Mean $\pm$ SD, ${}^{\ast}p<$ 0.05.

Table 3

Comparison of change quantity in variables between isokinetic peak moment of origin to insertion and insertion to origin taping direction

Variables	Repetition number		$p$
	Origin to insertion	Insertion to origin
Fatigue induced repetition	111.67 $\pm$ 43.41 ${}^{{\dagger}}$	112.67 $\pm$ 40.79	0.949

${}^{{\dagger}}$ Mean $\pm$ SD, ${}^{\ast}p<$ 0.05.

2.5 Strength measurement

Prior to actual testing, the subjects performed 5 minutes of low-intensity warm up exercise consisting of cycling and stretching [16]. As the subject sat in the Biodex chair with his or her back against the chair, a belt was used to immobilize the torso, thighs, and ankles. Then, the knee joints were fixed to the axis of the dynamometer. A monitor was used to allow biofeedback and the examiner verbally encouraged the subject for maximum muscle recruitment. Maximal PM value was calculated from 5 repeated measurements with angular velocity of 60 ${}^{\circ}$ /s and measurements were taken within the designated joint ROM [16].

2.6 Muscle fatigue protocol

After measuring the PM, fatigue was induced by performing maximal strength repetitions at 60 ${}^{\circ}$ /s [23]. Moment dropping below 50% of PM value on 3 consecutive measurements was determined as marking fatigue and the number of repetitions was recorded [23]. The examiner verbally encouraged the subject to move as fast as possible while in the sitting position.

2.7 Statistical analysis

For comparing the number of repetitions, a paired t-test was used. To compare the effects of the direction of KT application on delaying the onset of muscle fatigue, an independent t-test was used. SPSS version 18.0 was used for the statistical analysis.

3. Results

Regardless of the direction of application, applying KT significantly increased the number of repetitions required to induce muscle fatigue ( $p<$ 0.05), which indicated that the onset of muscle fatigue was delayed (Table 2). There was no significant difference in the number of repetitions required to induce muscle fatigue according to the direction of KT application ( $p>$ 0.05). Origin to insertion direction taping was 111.67 $\pm$ 43.41 and insertion to origin direction taping was 112.67 $\pm$ 40.79 (Table 3).

4. Discussion

The current study indicates that applying KT on the quadriceps prior to inducing fatigue in this muscle increased the number of repetitions required to induce muscle fatigue, regardless of the direction of application. A study by Zulfikri and Justine reported that when KT was applied to the fatigued quadriceps, biceps femoris and the gastrocnemius it was effective as per the Modified Star Excursion Balance Test of fatigued lower extremity [29]. KT application such as tactile and mechanical receptor stimulation compensated for the reduction of afferent feedback caused by fatigue and enhanced dynamic balance by maintaining the accuracy of the muscle spindle information and maintaining the proprioceptive input [29].

Konishi reported that when KT was applied to weakened quadriceps after vibratory stimulation, maximum voluntary contraction and average EMG signal of the quadriceps increased significantly compared to when KT was not applied [30]. Tactile stimulation, such as KT application, increases maximum voluntary contraction and average EMG signal by stimulating the afferent nerves in the skin, while activation of gamma motor neurons regulates Ia afferent pathways to indirectly activate the alpha motor neurons [30].

Ward et al. applied KT on the anterior lower limb of runners after artificially inducing fatigue and found that there were no differences in their step length and stride length compared to the state of no fatigue [22]. Skeletal muscles possess extensibility and elasticity properties [31, 32, 33]. The stretch and recoil properties of muscles play an important role in generating force, but when muscle fatigue occurs, the muscle cannot function properly as these properties are compromised [34, 35]. It was reported that there were no changes in step length and stride length even when fatigue occurred because of the rubber band-like elasticity of KT [22]. In the present study, when the dynamometry was used to induce muscle fatigue after applying KT the elasticity of the KT applied to the skin helped the stretch and recoil properties of the quadriceps, which delayed the onset of muscle fatigue, as indicated by the increased number of repetitions required to induce muscle fatigue. Moreover, tactile stimulation from KT application activated alpha motor neurons, whereas applying KT stimulated the Golgi receptors to activate inhibitory motor neurons, which increased muscle strength that led to delayed onset of muscle fatigue.

Meanwhile, there was no significant difference in the number of repetitions required to induce muscle fatigue according to the direction of KT. Although there are no studies on the delayed onset of muscle fatigue after KT application, a study by Au et al. applied KT in different directions on patients with lateral epicondylitis and found no significant differences in muscle activities and pain in the wrist extensor [36], whereas studies by Cai et al. and Serrão et al. equally reported no significant differences in muscle activities of the wrist extensor and quadriceps according to the direction of KT application [37, 38]. Bravi et al. found no significant differences when KT was applied on the wrist [39], while Vercelli et al. have indicated no difference in muscle strength based on the direction of application when inhibition and facilitation tape were applied [40].

The present study is qualified by the following limitations. First, since the subjects were athletes, it would be difficult to generalize the results to all people. Second, since the study was a cross over study with a 1-week interval, there may have been some carryover effect. Finally, since the intervention was applied only on the quadriceps, the effects on other muscles are unknown. In the future, additional studies are needed to determine how to prevent muscle fatigue by using KT while addressing these limitations and applying KT on various other muscles.

5. Conclusion

In the present study, KT was applied to major components of the quadriceps muscles (i.e., the rectus femoris, vastus lateralis, and vastus medialis) prior to inducing muscle fatigue using the isokinetic dynamometer. The number of knee joint motion repetitions required to induce muscle fatigue increased, regardless of the direction of KT application on the quadriceps muscles, which indicated delayed onset of muscle fatigue. Therefore, prior to the onset of muscle fatigue in the quadriceps muscles during muscle activity, KT may be applied, regardless of direction, on the rectus femoris, vastus lateralis, and vastus medialis muscles.

Footnotes

Acknowledgments

This manuscript is based on a part of the first author’s Doctor’s Dissertation from Dong-Eui University.

Conflict of interest

The authors declared no conflict of interest.

References

Hosp

Folie

Csapo

, et al. Eccentric exercise, Kinesiology tape, and balance in healthy men. J Athl Train 2017; 52: 636-642.

Huang

Hsieh

, et al. Effect of the Kinesio tape to muscle activity and vertical jump performance in healthy inactive people. Biomed Eng Oline 2011; 10: 70.

El-abd

Ibrahim

El-Hefez

. Efficacy of kinesiology tape versus postural correction exercises on neck disability and axioscapular muscles fatigue in mechanical neck dysfunction: A randomized blinded clinical trial. J Bodyw Mov Ther 2017; 21: 314-321.

González-lglesias

Fernández-de-Las-Peñas

Cleland

, et al. Short-term effects of cervical kinesio taping on pain and cervical range of motion on patients with acute whiplash injury: a randomized clinical trial. J Orthop Sports Phys Ther 2009; 39: 515-521.

Fong

Hong

Chan

, et al. A systematic review on ankle injury and ankle sprain in sports. Sports Med 2007; 37: 73-94.

Mair

Seaber

Glisson

, et al. The role of fatigue in susceptibility to acute muscle strain injury. Am J Sports Med 1996; 24: 137-143.

Allen

Lamb

Westerblad

. Skeletal muscle fatigue: cellular mechanisms. Physiol Rev 2008; 88: 287-332.

Cooke

. Modulation of the actomyosin interaction during fatigue of skeletal muscle. Muscle Nerve 2007; 36: 756-777.

Björklund

Crenshaw

Djupsjöbacka

, et al. Position sense acuity is diminished following repetitive low-intensity work to fatigue in a simulated occupational setting. Eur J Appl Physiol 2000; 81: 361-367.

10.

Allen

Peoske

. Effect of muscle fatigue on the sense of limb position and movement. Exp Brain Res 2006; 170: 30-38.

11.

Lee

Yoo

. Application of posterior pelvic tilt taping for the treatment of chronic low back pain with sacroiliac joint dysfunction and increased sacral horizontal angle. Phys Ther Sport 2012; 13: 279-285.

12.

Kocyigit

Acar

Turkmen

, et al. Kinesio taping or just taping in shoulder subacromial impingement syndrome? A randomized, double-blind, placebo-controlled trial. Physiother Theory Pract 2016; 32: 501-508.

13.

Lee

. The immediate effects of ankle balance taping with kinesiology tape on ankle active range of motion and performance in the Balance Error Scoring System. Phys Ther Sport 2017; 25: 99-105.

14.

Choe

Peng

, et al. The immediate effects of posterior pelvic tilt with taping on pelvic inclination, gait function and balance in chronic stroke patients. J Korean Soc Phys Med 2017; 12: 11-21.

15.

Williams

Whatman

Hume

, et al. Kinesio taping in treatment and prevent of sports injuries: a meta-analysis of the evidence for its effectiveness. Sports Med 2012; 42: 153-164.

16.

Wong

Cheung

. Isokinetic knee function in healthy subjects with and without kinesio taping. Phys Ther Sport 2012; 13: 255-258.

17.

Fratocchi

Di Mattia

Rossi

, et al. Influence of Kinesio Taping applied over biceps brachii on isokinetic elbow peak torque. A placebo controlled study in a population of young healthy subjects. J Sci Med Sport 2013; 16: 245-249.

18.

Yeung

Sakunkaruna

, et al. Acute effects of kinesio taping on knee extensor peak torque and electromyographic activity after exhaustive isometric knee extension in healthy young adult. Clin J Sport Med 2015; 25: 284-290.

19.

Kalron

Bar-Sela

. A systematic review of the effectiveness of kinesio taping®-fact or fashion? Eur J Phys Rehabil Med 2013; 49: 1-11.

20.

Morris

Jones

Ryan

, et al. The clinical effects of kinesio® Tex taping: a systematic review. Physiother Theory Pract 2013; 29: 259-270.

21.

Mostafavifar

Wetz

Borchers

. A systematic review of the effectiveness of kinesio taping for musculoskeletal injury. Phys Rev Lett 2012; 40: 33-40.

22.

Ward

Sorrels

Coats

, et al. The ergogenic effect of elastic therapeutic tape on stride and step length in fatigued runners. J Chiropr Med 2014; 13: 221-229.

23.

Gribble

Hertel

. Effect of lower-extremity muscle fatigue on postural control. Arch Phys Med Rehabil 2004; 85: 589-592.

24.

Lee

Choi

. Balance Taping: Clinical Application of Elastic Therapeutic Tape for Musculoskeletal Disorders. Paju: Korea WETAPE; 2016, p. 180.

25.

Han

Lee

Yoon

. The mechanical effect of kinesiology tape on rounded shoulder posture in seated male workers: a single-blinded randomized controlled pilot study. Physiother Theory Pract 2015; 31: 120-125.

26.

Hwangbo

Lee

Kim

. Efficacy of kinesiology taping for recovery of dominant upper back pain in female sedentary worker having a rounded shoulder posture. Thechnol Health Care 2013; 21: 607-612.

27.

Kim

Lee

Kim

, et al. Effects of ankle balance taping with kinesiology tape for a patient with chronic ankle instability. J Phys Ther Sci 2015; 27: 2405-2406.

28.

Han

Lee

. Effects of kinesiology taping on respositioning error of the knee joint after quadriceps muscle fatigue. J Phys Ther Sci 2014; 26: 921-923.

29.

Zulfikri

Justine

. Effects of Kinesio® Taping on Dynamic Balance Following Fatigue: a Randomized Controlled Trial. Phys Ther Res. 2017; 20: 16-22.

30.

Konishi

. Tactile stimulation with kinesiology tape alleviates muscle weakness attributable to attenuation of Ia afferents. J Sci Med Sport 2013; 16: 45-48.

31.

Brandenburg

Eby

Song

, et al. Ultrasound elastography: the new frontier in direct measurement of muscle stiffness. Arch Phys Med Rehabil 2014; 95: 2207-2219.

32.

Muraki

Ishikawa

Morise

, et al. Ultrasound elastography-based assessment of the elasticity of the supraspinatus muscle and tendon during muscle contraction. J Shoulder Elbow Surg 2015; 24: 120-126.

33.

Rosenfeld

. The influence of filament elasticity on transients after sudden alteration of length of muscle or load. Eur Biophys J 2014; 43: 367-376.

34.

St Clair Gibson

De Koning

Thompson

, et al. Crawling to the finish line: why di endurance runners collapse? Implications for understanding of mechanisms underlying pacing and fatigue. Sports Med 2013; 43: 413-424.

35.

Patterson

McGrath

Caulfield

. Using a tri-axial accelerometer to defect technique breakdown due to fatigue in distance runners: a preliminary perspective. Conf Proc IEEE Eng Biol Soc 2011; 2011: 6511-6514.

36.

IPH

Fan

PCP

Lee

, et al. Effects of Kinesio tape in individuals with lateral epicondylitis: A deceptive crossover trial. Physiother Theory Pract 2017; 33: 914-919.

37.

Cai

Cheung

. Facilitatory and inhibitory effects of kinesio tape: Fact or fad? J Sci Med Sport 2016; 19: 109-112.

38.

Serrão

Mezêncio

Claudino

, et al. Effect of 3 different applications of kinesio taping denko® on electromyo-graphic activity: inhibition or facilitation of the quadriceps of males during squat exercise. J Sports Sci Med 2016; 15: 403-409.

39.

Bravi

Chen

Quarta

, et al. Effect of direction and tension of kinesio taping application on sensorimotor coordination. Int J Sports Med 2016; 37: 909-914.

40.

Vercelli

Sartorio

Foti

, et al. Immediate effect of kinesiotaping on quadriceps muscle strength: A single-blind, placebo-controlled crossover trial. Clin J Sport Med 2012; 22: 319-326.
