Preliminary research of the classification of the brain acute stroke lesions by the Diffusion Kurtosis Imaging (DKI) and Diffusion Weighted Imaging (DWI) parameters

1. Introduction

Diffusion-weighted magnetic resonance imaging (DWI) is a mature scanning technique. With high sensitivity in detecting cerebral infractions, it has become an essential part of the clinical evaluation of acute stroke [1, 2]. However, with the update in medical ideals and treatment, clinicians are now focusing on distinguishing between reversible and irreversible brain tissue damage rather than detecting ischaemic lesions alone.

The former research has shown that the mismatch between diffusion-weighted imaging (DWI) and perfusion-weighted imaging (PWI) shows superior sensitivity to ischemic brain injury [1, 2]. Nevertheless, the significance of mismatched tissues is unclear. The status of mismatched tissues depends on many complex factors, such as the duration and nature of the ischemic injury and the proximity of patent vessels. In a word, perfusion diffusion mismatch only approximates a genuine ischemic hemi-dark band. Despite the drawbacks, this mismatch is usually used to guide clinical decision-making in diagnosing and treating acute stroke [3, 4, 5]. Thus, more and more methods are explored to help clinicians better understand ischemic brain injury.

Diffusion kurtosis imaging (DKI) is a new diffusion-weighted sequence approach that measures the non-Gaussianity of water diffusion, which can be used to characterize the complexity or heterogeneity of the tissue microenvironment. Compared with 3D q-space imaging, DKI has low requirements in imaging time, hardware requirements, and post-processing [4]. Thus, DKI has been shown to detect microstructural brain tissue changes in the ageing brain, acute stroke, and tumors.

We systematically studied the different parameters of DKI in acute stroke patients and the normal experiments in the literature. DKI, compared with DWI, has more parameters that can provide more information about the infarct core. We also followed the prognosis of patients with different types. We supposed that DKI could stratify heterogeneous DWI lesions, improving the characterization of tissue injury. In the literature, the characteristics of DKI have been systematically studied in acute stroke patients.

2. Method

3. Results

4. Discussion

Diffusion-weighted imaging (DWI) is the most reliable neuroimaging technique to assess acute ischemic stroke [5, 6]. Nowadays, DWI has been extensively used in acute stroke patients because of its high sensitivity. DWI has its deficit: it cannot reflect the actual tissue damage of the acute stroke lesions, which are uneven and may partially recover during treatment [7]. The ischemic core manifests that the diffusion-weighted image showed high intensity, and the apparent diffusion coefficient was significantly reduced (ADC). ADC is usually maintained at low levels 4 days after stroke and then gradually pseudo-normalized. In the subacute or chronic stage, the value of ADC becomes normal or high [8, 9]. There is a fundamental limitation of ADC which can only analyze the date approximating Gaussian distribution. However, the injury tissue of cerebral infarction conforms to non-Gaussian distribution.

DKI is an extension of DWI and DTI technology, an emerging MR technology based on the principle of non-Gaussian diffusion movement of water molecules in vivo. It can quantitatively describe the non-Gaussian diffusion characteristics of water molecules inside and outside cells and provide more prosperous, more authentic and accurate tissue microstructure information than DWI and DTI technology [8, 9]. DKI technology was first proposed by Professor Jenson of New York University in 2005. In recent years, DKI has been gradually applied to study diseases of various systems, especially in the brain, prostate and other tumors have achieved preliminary results, showing good clinical value [8, 9, 10].

DKI introduces the fourth-order kurtosis K value to quantify the degree of restriction of the non-Gaussian diffusion movement of water molecules in tissues. The reference of higher-order statistics can better reflect the signal characteristics of the tissue itself [11]. In addition to the diffusion parameters, the main parameters that the DKI model can obtain include: mean kurtosis, MK, a parameter reflecting the degree of diffusion restriction of water molecules in the tissue; indicators reflecting anisotropy-kurtosis anisotropy (KA); indicators that reflect the direction of parallel or vertical maximum eigenvalues-axial kurtosis, AK or K//) and radial kurtosis (RK or K). Due to the high sensitivity and specificity of DKI in reflecting the microstructure characteristics of tissues, it has excellent clinical application potential [12].

Because of different cell membranes and biochemical characteristics, biological tissues shift the diffusion of water molecules to the normal distribution and become non-Gaussian. The magnitude of water molecule diffusion deviation from Gaussian distribution can be quantified by a dimensionless scale, that is, excess kurtosis. This parameter can quantify the degree of water molecule diffusion restriction and diffusion inhomogeneity, thereby reflecting the situation of water molecule diffusion hindered or limited. If K = 0, it indicates that water molecules diffuse into the Gaussian distribution; The larger the K value, the more significant the deviation from the Gaussian distribution and the more complex the microstructure [10, 11, 12].

The diffusion kurtosis coefficient (K) is a quantitative measure of non-Gaussian properties of white matter (WM) and grey matter (GM); Because of the multiple barriers like cellular/axonal membranes, organelles, and or chambers, the water diffusion in biological tissue is limited; thus, it results in positive K [13].

The increase in K of the ischemic injuries may indicate an increase in the water microenvironment’s complexity or heterogeneity in WM and GM [14]. MK is the most critical parameter of DKI technology, defined as the average of diffusion kurtosis in all directions, and is considered to be an indicator of the complexity of tissue microstructure [15]. Compared with DWI, MK has the advantage of not relying on the spatial orientation of the tissue structure and can be used in both the grey and white matter in the brain.

The size of MK depends on the complexity of the tissue microstructure in the region of interest. The more complex the structure (e.g., the lower the degree of differentiation of cancer cells and the greater the cell density), the more significant the spread of non-Gaussian water molecules, and the larger the MK [16].

KA is somewhat similar to FA, evolving according to the standard deviation of kurtosis. The KA value represents the degree to which water molecules tend to diffuse anisotropy. That is, the larger the value, the more obvious the degree of tendency [17].

The former study showed that, in experimental models of traumatic brain injury, in which nerve tissue was impacted in the subacute phase, MK was elevated in the pseudo-normalization of MD and FA [18]. Studies have shown that an increase in MK is associated with higher reactive astrocyte proliferation, confirming K as a tissue heterogeneity biomarker. Similar results have been observed in previous patient and animal stroke DKI preliminary studies.

In other words, K is an in vivo measure of microenvironmental complexity and inhomogeneity, which can provide complementary information to the traditional diffusion index and may be a more sensitive biomarker for exploring pathophysiological changes [17, 18].

In diagnosing of acute ischemic stroke, DKI can further reflect the hemodynamic and tissue metabolic damage severity information based on DWI. At the same time, it can effectively judge the changes and prognosis of brain tissue structure in patients with acute ischemic stroke in short-term treatment. DKI indexes can potentially reflect tumor cell density and cell proliferation characteristics. The indicators obtained by DKI imaging can be used as a non-invasive clinical tool with high diagnostic accuracy to identify low and high-grade gliomas or distinguish different histological subtypes of tumors.

5. Conclusion

Our findings suggest that DWI/DKI mismatches may reflect mild injury and potentially recoverable ischemic lesions, while matched regions may indicate irreversible cell damage. In our studies, MK and Ka were significantly different in Type II, which may mean the real infraction core in the mismatch acute store patients.

DKI, compared to DWI, provides more helpful information about acute ischemic cerebral infraction, which can deepen the understanding of ischemic tissue injury. Our classification of the brain acute stroke lesions by DKI parameters and DWI may do a favor to a new understanding of the real infraction core.

Ethics statement

The study was approved by the institutional review board (CWO) of the Second Affiliated Hospital of Xiamen Medical University. All patients provided written informed consent.

Availability of data and material

All datasets related to the current study are available from the corresponding author upon reasonable request.

Author contributions

Xin Liu and Gen Yan conceived and designed the experiments; Xin Liu, Fang Chen and Lei Wang performed the experiments and collected the data; Xin Liu wrote the paper; Bo Zheng help analyze the data. All authors read and approved the final manuscript.
