Global Finite-Time Stabilization for Nonholonomic Mobile Robots Based on Visual Servoing

Abstract

In this paper, the global finite-time stabilization problem is considered for nonholonomic mobile robots based on visual servoing with uncalibrated visual parameters, control direction and unmatched external disturbances. Firstly, the simple dynamic chained-form systems is obtained by using a state and input transformation of the kinematic robot systems. Secondly, a new discontinuous switching controller is presented in the presence of uncertainties and disturbances, it is rigorously proved that the corresponding closed-loop system can be stabilized to the origin equilibrium point in a finite time. Finally, the simulation results show the effectiveness of the proposed control design approach.

Keywords

Nonholonomic Mobile Robots Chained-form System Visual Servoing Finite-time Stabilization Switching Control

1. Introduction

Addressing the stabilization problem of nonholonomic systems is a challenging task which has attracted a continuously increasing attention in the control community. As pointed out in [1], such a class of nonlinear systems can not be stabilized to a point with pure smooth (or even continuous) state feedback control. To overcome this difficult, up to now, there have been a lot of control methods to stabilize such systems, which includes discontinuous feedback control laws [2]–[5], continuous time-varying feedback control laws [6]-[8] and hybrid feedback control laws [9]-[11]. As a typical model of the nonholonomic system, the nonholonomic characteristic of wheeled mobile robots arises from the wheel which is rolling without slipping. Many research results of controlling nonholonomic mobile robots have been given in recent decades, such as formation control or cooperative control of multi-robot systems [12]-[15], motion planning [16], trajectories tracking [17]-[19] and point stabilization [20]-[24], etc.

Recently, based on visual servoing model, a new robust control issue is considered in [25]-[31] for nonholonomic mobile robots with uncalibrated camera parameters. Under a single camera fixed on the ceiling, the trajectory tracking and point stabilization (practical stabilization) problems are discussed for the kinematic model with uncertain visual parameters in [25], [27] and [28]. Detailedly, by using Barbalat theorem and Lyapunov techniques, a dynamic feedback robust controller is proposed in [25] that can enable the mobile robot configuration tracking despite the lack of depth information and the lack of precise visual parameters. In [27] and [28], two different switching control design strategies are proposed to address the stabilization problem of the mobile robots, and compared with other results on the same subject (visual servoing feedback control of nonholonomic mobile robots), it is more realistic to suppose that all the parameters of the camera system are unknown in this two papers. In addition, in [26], a new time varying feedback controller is proposed for the exponential stabilization of the nonholonomic chained system with unknown parameters by using state-scaling and switching technique, in [29], the authors have presented a robust adaptive tracking controller for the dynamic mobile robots system.

Additionally, it's worth mentioning that based on visual servoing, the finite-time tracking control for nonholonomic mobile robots and the finite-time tracking control for multiple nonholonomic mobile robots have been discussed in [30] and [31], respectively. However, these results have not involved the finite-time stabilization problem for nonholonomic mobile robots with uncertain camera parameters, as is known to all, two classes of problems-stabilization and tracking control for nonholonomic systems are not the same at all.

Finite-time stabilization problems have been studied mostly in the contexts of optimality, controllability, and deadbeat control for several decades [32]-[38], in which, compared to the regular asymptotic stabilization, it was demonstrated that finite-time stable systems might enjoy not only faster convergence but also better robustness and disturbance rejection properties.

This article considers the global finite-time stabilization problem for a class of nonholonomic mobile robots based on visual servoing with uncalibrated visual parameters and external disturbances. The main contributions can be summarized as the following two respects:

1)
By using a state and input transformation, the dynamic extended chained-form systems is introduced, then according to its special chained structure, two uncertain subsystems is used to designed the discontinuous switching controller.
2)
To propose the step-by-step switching control law, the systematic strategy of combining the finite-time stability theory and a three-step discontinuous design method is adopted to deal with the uncertainties and disturbances. Moreover, the rigorous proof is presented to demonstrate that the corresponding closed-loop system can be stabilized to the origin equilibrium point in a finite time.
3)
The structure of the article is as follows: Section 2 gives a formalization of the problem considered in this paper. A proper assumption and some lemmas are also presented in this section. Section 3 states our main results including switch controller design and stability analysis. Section 4 provides an illustrative numerical example and the corresponding simulation results of the proposed methodology. Finally, a conclusion is shown in Section 5.
2. Problem Statement

As shown in Figure 1, the two fixed rear wheels of the robot are controlled independently by motors, and a front castor wheel prevents the robot from tipping over as it moves on a plane. Assuming that the geometric center point and the mass center point of the robot are the same, and that the radii r are identical for all the wheels and the distance 2R between the fixed wheels is a known positive constant. Its kinematic model can be described by the following differential equations [39]:

{\begin{array}{l} \dot{x} = v \cos θ, \\ \dot{y} = v \sin θ, \\ \dot{θ} = ω, \end{array}

(1)

where (x, y) is the position of the mass center of the robot moving in the plane, is the forward velocity, ω is the steering velocity and θ denotes its heading angle from the horizontal axis.

Figure 1.

Nonholonomic wheeled mobile robot

We consider that the movement of the mobile robot above can be measured by using a pinhole camera fixed to the ceiling (as shown in Figure 2). Assuming that the camera plane, the image plane and the robot plane are parallel. There are four coordinate frames, namely the inertial frame X – Y – Z, the camera frame x – y – z, the image frame u – o₁ – v, and the attached robot frame X₁ – P – X₂. Point C is the crossing point between the optical axis of the camera and X – Y plane. Its coordinate relative to X – Y plane is (c_x, c_y). The coordinate of the original point of the camera frame with respect to the image frame is defined by (O_c1, O_c2), and (x, y) is the coordinate of the mass center P of the robot with respective to X – Y plane, its image position is noted as (x_m, y_m).

The pinhole camera model can be expressed as [25]-[31], [37]:

(\begin{matrix} x_{m} \\ y_{m} \end{matrix}) = (\begin{matrix} α_{1} & 0 \\ 0 & α_{2} \end{matrix}) R (\begin{matrix} x - c_{x} \\ y - c_{y} \end{matrix}) + (\begin{matrix} O_{c_{1}} \\ O_{c_{2}} \end{matrix})

(2)

where α₁ and α₂ are positive constants, which are dependent on the depth information, focal length, scalar factors along u axis, and v axis, respectively; and

R = (\begin{matrix} \cos θ_{0} & \sin θ_{0} \\ - \sin θ_{0} & \cos θ_{0} \end{matrix}),

(3)

where θ₀ denotes the angle between X axis and y axis with a positive anticlockwise orientation.

Figure 2.

Nonholonomic wheeled mobile robot under a fixed camera

From (1), (2) and (3), by using a simple derivation, the image-based kinematical equation of the robot can be obtained:

{\begin{array}{l} {\dot{x}}_{m} = α_{1} v \cos (θ - θ_{0}), \\ {\dot{y}}_{m} = α_{2} v \sin (θ - θ_{0}), \\ \dot{θ} = ω . \end{array}

(4)

In the field of visual servoing control of robots, usually the camera parameters α₁, α₂ and the angle θ₀ can be gotten by calibration. But this process will take a lot of time, which implies that it is impossible to use this method in high requirement of real-time. Therefore, it is necessary to consider how to design a control law in the case of dealing with these uncalibrated parameters.

As in [25], we make the following assumption:

Assumption 1: θ₀ = 0, α₁, α₂ are unknown and bounded, the bounds of which are known positive constants:

0 < α_{i}^{\min} \leq α_{i} \leq α_{i}^{\max}, i = 1,2.

Remark 1: Compared with it in [25], our assumptions are more relaxed since it is not necessary to suppose α₁ = α₂ in this paper.

Under this case, system (4) can be rewritten as

{\begin{array}{l} {\dot{x}}_{m} = α_{1} v \cos θ, \\ {\dot{y}}_{m} = α_{2} v \sin θ, \\ \dot{θ} = ω, \end{array}

taking a state and input transformation [41]:

x_{0} = x_{m}, x_{1} = y_{m}, x_{2} = \tan θ,

we obtain

{\begin{array}{l} {\dot{x}}_{0} = α_{1} u_{0}, \\ {\dot{x}}_{1} = α_{2} x_{2} u_{0}, \\ {\dot{x}}_{2} = u_{1} . \end{array}

(5)

It is noted that system (5) is so-called canonical chained-form with three-order and two control inputs u₀, u₁. The finite-time stabilization problem of (5) can be completely addressed by applying the controller given in [35], moreover, the authors have dealt with the nonholonomic chained systems with uncertain parameters and a matched disturbance.

In this paper, we will consider the finite-time stabilization problem of the extended chained-form systems (6) with unknown parameters α₁, α₂, uncertain control direction _γi(t), (i = 1,2) and unmatched un-modeled dynamics (or external disturbance) ϕ_i(t), (i = 1,2).

{\begin{array}{l} {\dot{x}}_{0} = α_{1} u_{0}, \\ {\dot{x}}_{1} = α_{2} x_{2} u_{0}, \\ {\dot{x}}_{2} = u_{1}, \\ {\dot{u}}_{0} = γ_{1} (t) τ_{1} + φ_{1} (t), \\ {\dot{u}}_{1} = γ_{2} (t) τ_{2} + φ_{2} (t), \end{array}

(6)

where τ₁ and τ₂ are the new control inputs, the bounded measurable functions γ_i(t), ϕ_i(t), (i = 1,2) are supposed to satisfy that

γ_{i}^{m} \leq γ_{i} (t) \leq γ_{i}^{M}, | φ_{i} (t) | \leq φ_{i}^{M}, (i = 1,2)

here $γ_{i}^{m}, γ_{i}^{M}, φ_{i}^{m}, φ_{i}^{M}, (i = 1,2)$ are positive constants.

Remark 2: Usually, the new control inputs τ₁ and τ₂ in the extended nonholonomic system (6) can be seen as the form of force or torque inputs, which is more practical than the form of velocity or acceleration controller u₀ and u₁ of (5) in the engineering application, because the new controller can be easier to implement for electrical engineer.

The following lemmas and conclusions are needed for our controller design later.

Lemma 1 ([42]): Considering the following system

\dot{\bar{x}} = f (\bar{x}), f (0) = 0, \bar{x} \in R^{n},

(7)

suppose there exists a continuous function $\bar{V} (\bar{x}) : U \to R$ such that the following conditions hold

(i)

$\bar{V} (\bar{x})$ is positive definite.

(ii)

There exist real numbers $\bar{c} > 0$ and $\bar{c} > 0$ and $\bar{α} \in (0,1)$ ∊ (0,1) and an open neighbourhood U₀ ∊ U of the origin such that $\dot{\bar{V}} (\bar{x}) + \bar{c} {\bar{V}}^{\bar{α}} (\bar{x}) \leq 0, \bar{x} \in U_{0} ﹨ {0}$ .

Then the origin is a finite-time stable equilibrium of system (7). If U = U₀ = Rⁿ, then the origin is a globally finite-time stable equilibrium of system (7).

Lemma 2 ([43]): If $0 < p = p_{1} / p_{2} \leq 1$ , where $p_{1} > 0, p_{2} > 0$ are positive odd integers, then

| x^{p} - y^{p} | \leq 2^{1 - p} | x - y |^{p} .

(8)

Lemma 3 ([44]): For x ∊ R,y ∊ R, let c,d be positive real numbers, then

| x |^{c} | y |^{d} \leq \frac{c}{c + d} | x |^{c + d} + \frac{d}{c + d} | y |^{c + d} .

(9)

Lemma 4 ([43]): For x_i ∊ R, i = 1,2,…, n, 0 p ≤ 1 is a real number, then the following inequality holds:

{(| x_{1} | + | x_{2} | + … + | x_{n} |)}^{p} \leq | x_{1} |^{p} + … + | x_{n} |^{p}

(10)

Theorem 1: Consider an uncertain nonlinear system:

\leq n^{1 - p} {(| x_{1} | + … + | x_{n} |)}^{p} .

(11)

where z ∊ R^r is the state vector and u ∊ R is the control input. Unknown parameters β_i > 0, (i = 1,2,…, r – 1), the functions ϕ(·) and γ(·) are arbitrary measurable functions that represent bounded uncertainty:

| φ (t) | \leq \bar{φ}, γ_{m} \leq γ (t) \leq γ_{M},

where $\bar{φ}, γ_{m}, γ_{M}$ , γ_m, γ_M are positive constants. For the following system (12),

\begin{array}{l} {\dot{z}}_{i} = β_{i} z_{i + 1}, i = 1,…, r - 1, \\ {\dot{z}}_{r} = {\bar{u}}_{0}, \end{array}

(12)

if there exist a state-feedback control law ū₀(z), a positive definite C¹ function $\tilde{V}$ and real numbers $\tilde{c}$ > 0 and $\tilde{α} \in (0,1)$ ∊ (0,1) satisfying the conditions (for every z ∊ R^r):

(i)

$\dot{\tilde{V}} (z) + \tilde{c} {\tilde{V}}^{\tilde{α}} (z) \leq 0$

(ii)

$\frac{\partial \tilde{V}}{\partial z_{r}} (z) {\bar{u}}_{0} (z) \leq 0, a n d {\bar{u}}_{0} (z) = 0 \Rightarrow \frac{\partial \tilde{V}}{\partial z_{r}} = 0$

Let

u = ({\bar{u}}_{0} + \bar{φ} s i g n ({\bar{u}}_{0})) / γ_{m},

then system (11) is finite-time stable with respect to the origin.

Proof.: See Appendix A. □ Next, the control task is to present a switching controller for system (6) such that all the states converge to the origin equilibrium point in a finite time.

3. Main Results

In this section, the main results will be presented. Firstly, we will state the basic idea to design a switching controller for system (6).

Motivated by the results of Theorem 1, we give a finite-time stable controller for the following system:

{\begin{array}{l} {\dot{x}}_{0} = α_{1} u_{0}, \\ {\dot{x}}_{1} = α_{2} x_{2} u_{0}, \\ {\dot{x}}_{2} = u_{1}, \\ {\dot{u}}_{0} = {\tilde{τ}}_{1}, \\ {\dot{u}}_{1} = {\tilde{τ}}_{2}, \end{array}

where ${\tilde{τ}}_{1}$ and ${\tilde{τ}}_{2}$ are the control inputs. In the first place, according to the special structure of the system above, two subsystems are considered, respectively. One is

{\begin{array}{l} {\dot{x}}_{1} = α_{2} x_{2} u_{0}, \\ {\dot{x}}_{2} = u_{1}, \\ {\dot{u}}_{1} = {\tilde{τ}}_{2}, \end{array}

(13)

and the other is

{\begin{array}{l} {\dot{x}}_{0} = α_{1} u_{0}, \\ {\dot{u}}_{0} = {\tilde{τ}}_{1} . \end{array}

(14)

Based on which, by using the design method of Theorem 1, we will propose a switching controller such that all the states of system (6) can be stabilized to zero in a finite time.

3.1 Switching controller design

According to the design idea above, a discontinuous switching controller is presented as follows.

Step 1:
Let

$τ_{1} = ({\tilde{τ}}_{1} + φ_{1}^{M} s i g n ({\tilde{τ}}_{1})) / γ_{1}^{m}, τ_{2} = 0,$

where

${\tilde{τ}}_{1} = - λ_{1} s i g n (u_{0} - 1) | u_{0} - {1 |}^{q_{0}},$

where Λ 0, q₀ ∊ (0,1) are design parameters. Then there exists a finite time T₁ +∞ such that <u₀(t) = 1 as t ≥ T₁, and go to Step 2.
Step 2:
Let

$τ_{1} = ({\tilde{τ}}_{1} + φ_{1}^{M} s i g n ({\tilde{τ}}_{1})) / γ_{1}^{m}, τ_{2} = ({\tilde{τ}}_{2} + φ_{2}^{M} s i g n ({\tilde{τ}}_{2})) / γ_{2}^{m},$

where

${\tilde{τ}}_{2} = - l_{3} {(u_{1}^{\frac{1}{2 q_{1} - 1}} + l_{2}^{\frac{1}{2 q_{1} - 1}} (x_{2}^{\frac{1}{q_{1}}} + l_{1}^{\frac{1}{q_{1}}} x_{1}))}^{3 q_{1} - 2},$

q₁ = p/q ∊ (2/3, 1), p, q are positive odd integers, l_i > 0, (i = 1,2,3) k_j > 0, (j = 1,2) are design parameters satisfying the following conditions:

$+ \frac{(3 - 2 q_{1}) (1 - q_{1})}{k_{2} q_{1} (1 + q_{1})} l_{1}^{\frac{1}{q_{1}} - 1} {(2}^{2 - 2 q_{1}} l_{2}^{\frac{2 q_{1}}{2 q_{1} - 1}} + 2^{4 - 4 q_{1}} l_{2}^{\frac{1}{2 q_{1} - 1}}) + \frac{α_{2} (3 - 2 q_{1}) q_{1}}{k_{2} (1 + q_{1})} 2^{2 - 2 q_{1}} l_{1}^{1 + \frac{1}{q_{1}}} l_{2}^{\frac{1}{2 q_{1} - 1}} < 0,$
(15)

$2) \frac{2^{1 - q_{1}} q_{1}}{1 + q_{1}} - \frac{l_{2}}{k_{1}} + \frac{α_{2} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}}}{k_{1}} (\frac{2^{1 - q_{1}} l_{1}}{1 + q_{1}} + 2^{2 - 2 q_{1}}) + \frac{(3 - 2 q_{1}) q_{1}}{k_{2} (1 + q_{1})} 2^{3 - 3 q_{1}} l_{1}^{\frac{1}{q_{1}}} l_{2}^{\frac{1}{2 q_{1} - 1}} + \frac{(2 - q_{1} {) 2}^{2 - 2 q_{1}}}{k_{1} (1 + q_{1})} + \frac{(3 - 2 q_{1}) l_{2}^{\frac{1}{2 q_{1} - 1}}}{k_{2} q_{1} (1 + q_{1})} {(2}^{2 - 2 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} l_{2} (2 q_{1} - 1) + 2^{2 - q_{1}} q_{1} l_{2} + 2^{4 - 3 q_{1}} (1 - q_{1})) < 0,$
(16)

$3) \frac{(2 q_{1} - {1) 2}^{2 - 2 q_{1}}}{k_{1} (1 + q_{1})} + \frac{(3 - 2 q_{1}) l_{2}^{\frac{1}{2 q_{1} - 1}}}{k_{2} q_{1} (1 + q_{1})} {(2}^{2 - 2 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} l_{2} + 2^{2 - q_{1}} l_{2} + 2^{5 - 3 q_{1}} q_{1} + 2^{5 - 4 q_{1}} q_{1} l_{1}^{\frac{1}{q_{1}} - 1}) + \frac{α_{2} (3 - 2 q_{1})}{k_{2} (1 + q_{1})}$
(17)

Then there exists a finite time $T_{1} < + \infty$ such that $u_{0} (t) \equiv 1$ as $t \geq T_{1}$ , and go to Step 3.

Step 3: Let

$τ_{1} = ({\tilde{τ}}_{1} + φ_{1}^{M} s i g n ({\tilde{τ}}_{1})) / γ_{1}^{m}, τ_{2} = ({\tilde{τ}}_{2} + φ_{2}^{M} s i g n ({\tilde{τ}}_{2})) / γ_{2}^{m},$

where

${\tilde{τ}}_{1} = - {\tilde{k}}_{3} {(u_{0}^{q_{2}} + {\tilde{k}}_{1}^{q_{2}} x_{0})}^{\frac{2}{q_{2}} - 1}$

q₂ = p₁/q₁ ∊ (0,1), p₁, q₁ are positive integers, ${\tilde{k}}_{i} < 0, (i = 1, 2, 3)$ are design parameters satisfying that

$- \frac{3}{4} {\tilde{k}}_{1} + \frac{{\tilde{k}}_{1}^{2 + q_{2}} α_{1}}{4 {\tilde{k}}_{2}} 2^{1 - \frac{1}{q_{2}}} < 0,$
(18)

$\frac{2^{1 - \frac{1}{q_{2}}}}{1 + q_{2}} {(\frac{2^{3 - \frac{1}{q_{2}}} q_{2}}{(1 + q_{2}) {\tilde{k}}_{1}})}^{q_{2}} + \frac{{\tilde{k}}_{1}^{q_{2}} α_{1}}{{\tilde{k}}_{2}} 2^{1 - \frac{1}{q_{2}}} + \frac{{\tilde{k}}_{1}^{1 + q_{2}} q_{2} α_{1} 2^{1 - \frac{1}{q_{2}}}}{(1 + q_{2}) {\tilde{k}}_{2}} {(\frac{4}{(1 + q_{2}) {\tilde{k}}_{1}})}^{\frac{1}{q_{2}}} - \frac{{\tilde{k}}_{3}}{{\tilde{k}}_{2}} < 0.$
(19)

Then there exists a finite time $T_{3} < + \infty$ such that $x_{0} (t) = u_{0} (t) \equiv 0$ as $t \geq T_{3}$ , and let $τ_{1} = τ_{2} = 0,$ stop.
3.2 Stability analysis

Theorem 2: Under Assumption 1, the switching controller composed by Step 1 ~ Step 3 in Section A ensures that system (6) can be stabilized to zero in a finite time.

Proof. Firstly, in Step 1, for a first-order system ${\dot{u}}_{0} = {\tilde{τ}}_{1}$ , let ${\dot{\tilde{u}}}_{0} = {\tilde{τ}}_{1}$ , we have

{\dot{\tilde{u}}}_{0} = {\tilde{τ}}_{1} = - λ_{1} s i g n ({\tilde{u}}_{0}) | {\tilde{u}}_{0} |^{q_{0}} .

Choosing a lyapunov function ${\tilde{V}}_{0} = \frac{1}{2} {\tilde{u}}_{0}^{2}$ , then its time derivative along the ${{\tilde{u}}_{0}} -$ system is

{\dot{\tilde{V}}}_{0} = {\tilde{u}}_{0} {\dot{\tilde{u}}}_{0} = {\tilde{u}}_{0} {\tilde{τ}}_{1} = - λ_{1} | {\tilde{u}}_{0} |^{1 + q_{0}} \leq 0,

which can be rewritten by

{\dot{\tilde{V}}}_{0} + λ_{1} \sqrt{2} {({\tilde{V}}_{0})}^{\frac{1}{2}} \leq 0.

(20)

Hence, according to Lemma 1, it's clear that under the controller ${\tilde{τ}}_{1}$ , there exists a finite time T₁ < +∞ such that ${\tilde{u}}_{0} (t) \equiv 0$ as $t \geq T_{1}$ . As for the following uncertain system

{\dot{\tilde{u}}}_{0} = γ_{1} (t) τ_{1} + φ_{1} (t),

(21)

because

\frac{\partial {\tilde{V}}_{0}}{\partial {\tilde{u}}_{0}} {\tilde{τ}}_{1} ({\tilde{u}}_{0}) = {\tilde{u}}_{0} (- λ_{1} s i g n ({\tilde{u}}_{0}) | {\tilde{u}}_{0} |^{q_{0}}) = - λ_{1} | {\tilde{u}}_{0} |^{1 + q_{0}} \leq 0,

(22)

and

{\tilde{τ}}_{1} ({\tilde{u}}_{0}) = 0 \Rightarrow {\tilde{u}}_{0} = 0 \Rightarrow \frac{\partial {\tilde{V}}_{0}}{\partial {\tilde{u}}_{0}} = 0.

(23)

By (20), (22)-(23) and from Theorem 1, system (21) can be stabilized to zero in the finite time T₁ with the controller τ₁, i.e., u₀(t) =1 as t ≥ T₁.

Next, in Step 2, substituting u₀ = 1 into the subsystem (13), it has

{\begin{array}{l} {\dot{x}}_{1} = α_{2} x_{2}, \\ {\dot{x}}_{2} = u_{1}, \\ {\dot{u}}_{1} = {\tilde{τ}}_{2} . \end{array}

(24)

Take a positive definite, radially unbounded function about x₁

V_{1} (x_{1}) = \frac{x_{1}^{2}}{2 α_{2}} .

Its time derivative along (24) is

\begin{array}{l} {\dot{V}}_{1} (x_{1}) = x_{1} x_{2} = x_{1} (x_{2} - x_{2}^{*}) + x_{1} x_{2}^{*} \\ \leq | x_{1} | \cdot | x_{2} - x_{2}^{*} | + x_{1} x_{2}^{*}, \end{array}

where $x_{2}^{*} = - l_{1} x_{1}^{q_{1}}$ is a virtual controller. Then we have

{\dot{V}}_{1} (x_{1}) \leq - l_{1} x_{1}^{1 + q_{1}} + | x_{1} | | x_{2} - x_{2}^{*} | .

(25)

As in [44], we take a C¹, positive definite and proper Lyapunov function about (x₁, x₂) as follows

V_{2} (x_{1}, x_{2}) = V_{1} (x_{1}) + \frac{1}{k_{1}} \int_{x_{2}^{*}}^{x_{2}} {(s^{\frac{1}{q_{1}}} - x_{2}^{* \frac{1}{q_{1}}})}^{2 - q_{1}} d s .

We can obtain

\begin{array}{l} {\dot{V}}_{2} (x_{1}, x_{2}) = {\dot{V}}_{1} (x_{1}) + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} u_{1} \\ + \frac{1}{k_{1}} (2 - q_{1}) \frac{\partial x_{2}^{* \frac{1}{q_{1}}}}{\partial x_{1}} {\dot{x}}_{1} \int_{x_{2}^{*}}^{x_{2}} {(s^{\frac{1}{q_{1}}} - x_{2}^{* \frac{1}{q_{1}}})}^{1 - q_{1}} d s, \end{array}

where $ξ_{1} = x_{2}^{\frac{1}{q_{1}}} - x_{2}^{* \frac{1}{q_{1}}}$ . So

\begin{array}{l} {\dot{V}}_{2} (x_{1}, x_{2}) = {\dot{V}}_{1} (x_{1}) + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} u_{1} \\ - \frac{α_{2}}{k_{1}} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}} x_{2} \int_{x_{2}^{*}}^{x_{2}} {(s^{\frac{1}{q_{1}}} - x_{2}^{* \frac{1}{q_{1}}})}^{1 - q_{1}} d s, \end{array}

Then

\begin{array}{l} {\dot{V}}_{2} (x_{1}, x_{2}) \leq {\dot{V}}_{1} (x_{1}) + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} x_{3}^{*} + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} \\ \cdot | u_{1} - x_{3}^{*} | + \frac{α_{2} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}}}{k_{1}} | x_{2} | | x_{2} - x_{2}^{*} | | ξ_{1} |^{1 - q_{1}}, \end{array}

(26)

where $x_{3}^{*} = - l_{2} ξ_{1}^{2 q_{1} - 1}$ is seen as a virtual controller.

By using (8) in Lemma 2, we have

| x_{2} - x_{2}^{*} | \leq 2^{1 - q_{1}} | ξ_{1} |^{q_{1}} .

(27)

Note that $x_{2} = x_{2}^{*} + (x_{2} - x_{2}^{*})$ , from (27), it has

| x_{2} | \leq | x_{2}^{*} | + | x_{2} - x_{2}^{*} | \leq l_{1} | x_{1} |^{q_{1}} + 2^{1 - q_{1}} | ξ_{1} |^{q_{1}} .

(28)

From (27)-(28) and (9) in Lemma 3, we have

\begin{array}{l} | x_{2} | | x_{2} - x_{2}^{*} | | ξ_{1} |^{1 - q_{1}} \\ \leq (l_{1} | x_{1} |^{q_{1}} + 2^{1 - q_{1}} | ξ_{1} |^{q_{1}} {) 2}^{1 - q_{1}} | ξ_{1} |^{q_{1}} | ξ_{1} |^{1 - q_{1}} \\ \leq 2^{1 - q_{1}} l_{1} \frac{q_{1} x_{1}^{1 + q_{1}} + ξ_{1}^{1 + q_{1}}}{1 + q_{1}} + 2^{2 - 2 q_{1}} ξ_{1}^{1 + q_{1}} . \end{array}

Substituting (25), (27) and the formula above into (26), we have

\begin{array}{l} {\dot{V}}_{2} (x_{1}, x_{2}) \leq - l_{1} x_{1}^{1 + q_{1}} + 2^{1 - q_{1}} | x_{1} | | ξ_{1} |^{q_{1}} + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} x_{3}^{*} \\ + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} | u_{1} - x_{3}^{*} | + \frac{α_{2} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}}}{k_{1}} \\ \cdot {(2}^{1 - q_{1}} l_{1} \frac{q_{1} x_{1}^{1 + q_{1}} + ξ_{1}^{1 + q_{1}}}{1 + q_{1}} + 2^{2 - 2 q_{1}} ξ_{1}^{1 + q_{1}}) . \end{array}

Because $x_{3}^{*} = - l_{2} ξ_{1}^{2 q_{1} - 1}$ , therefore

\begin{array}{l} {\dot{V}}_{2} (x_{1}, x_{2}) \leq - l_{1} x_{1}^{1 + q_{1}} + 2^{1 - q_{1}} | x_{1} | | ξ_{1} |^{q_{1}} - \frac{l_{2}}{k_{1}} ξ_{1}^{1 + q_{1}} \\ + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} | u_{1} - x_{3}^{*} | + \frac{α_{2} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}}}{k_{1}} \\ \cdot {(2}^{1 - q_{1}} l_{1} \frac{q_{1} x_{1}^{1 + q_{1}} + ξ_{1}^{1 + q_{1}}}{1 + q_{1}} + 2^{2 - 2 q_{1}} ξ_{1}^{1 + q_{1}}) . \end{array}

Applying Lemma 3 again, we have

\begin{array}{l} {\dot{V}}_{2} (x_{1}, x_{2}) \leq (- l_{1} + \frac{2^{1 - q_{1}}}{1 + q_{1}} + \frac{α_{2} (2 - q_{1} {) 2}^{1 - q_{1}}}{k_{1} (1 + q_{1})} l_{1}^{1 + \frac{1}{q_{1}}} q_{1}) \\ \cdot x_{1}^{1 + q_{1}} + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} | u_{1} - x_{3}^{*} | + (\frac{2^{1 - q_{1}} q_{1}}{1 + q_{1}} - \frac{l_{2}}{k_{1}} \\ + \frac{α_{2} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}}}{k_{1}} (\frac{2^{1 - q_{1}} l_{1}}{1 + q_{1}} + 2^{2 - 2 q_{1}})) ξ_{1}^{1 + q_{1}} . \end{array}

(29)

Taking a Lyapunov function about (x₁, x₂, u₁) for system (24) as follows

\begin{array}{l} V_{3} (x_{1}, x_{2}, u_{1}) = V_{2} (x_{1}, x_{2}) \\ + \frac{1}{k_{2}} \int_{x_{3}^{*}}^{u_{1}} {(s^{\frac{1}{2 q_{1} - 1}} - x_{3}^{* \frac{1}{2 q_{1} - 1}})}^{3 - 2 q_{1}} d s . \end{array}

Let

ξ_{2} = u_{1}^{\frac{1}{2 q_{1} - 1}} - x_{3}^{* \frac{1}{2 q_{1} - 1}},

and the time derivative along (24) is

\begin{array}{l} {\dot{V}}_{3} (x_{1}, x_{2}, u_{1}) = {\dot{V}}_{2} (x_{1}, x_{2}) \\ - \frac{3 - 2 q_{1}}{k_{2}} (\frac{\partial x_{3}^{* \frac{1}{2 q_{1} - 1}}}{\partial x_{1}} α_{2} x_{2} + \frac{\partial x_{3}^{* \frac{1}{2 q_{1} - 1}}}{\partial x_{2}} u_{1}) \cdot \\ \int_{x_{3}^{*}}^{u_{1}} {(s^{\frac{1}{2 q_{1} - 1}} - x_{3}^{* \frac{1}{2 q_{1} - 1}})}^{2 - 2 q_{1}} d s + \frac{ξ_{2}^{3 - 2 q_{1}}}{k_{2}} {\tilde{τ}}_{2} . \end{array}

Note that

\begin{array}{l} \frac{\partial x_{3}^{* \frac{1}{2 q_{1} - 1}}}{\partial x_{1}} = l_{1}^{\frac{1}{q_{1}}} {(- l_{2})}^{\frac{1}{2 q_{1} - 1}}, \\ \frac{\partial x_{3}^{* \frac{1}{2 q_{1} - 1}}}{\partial x_{2}} = \frac{1}{q_{1}} {(- l_{2})}^{\frac{1}{2 q_{1} - 1}} x_{2}^{\frac{1}{q_{1}} - 1}, \end{array}

Thus

\begin{array}{l} {\dot{V}}_{3} (x_{1}, x_{2}, u_{1}) \leq {\dot{V}}_{2} (x_{1}, x_{2}) + \frac{3 - 2 q_{1}}{k_{2}} l_{2}^{\frac{1}{2 q_{1} - 1}} \\ (l_{1}^{\frac{1}{q_{1}}} α_{2} | x_{2} | + \frac{1}{q_{1}} | x_{2} |^{\frac{1}{q_{1}} - 1} | u_{1} |) | ξ_{2} |^{2 - 2 q_{1}} | u_{1} - x_{3}^{*} | \\ + \frac{ξ_{2}^{3 - 2 q_{1}}}{k_{2}} {\tilde{τ}}_{2} . \end{array}

(30)

From (8) in Lemma 2, it has

| ξ_{2} |^{2 - 2 q_{1}} | u_{1} - x_{3}^{*} | \leq 2^{2 - 2 q_{1}} | ξ_{2} | .

(31)

From (28), (31) and (10) in Lemma 4, it has

\begin{array}{l} | x_{2} | | ξ_{2} |^{2 - 2 q_{1}} | u_{1} - x_{3}^{*} | \\ \leq (l_{1} | x_{1} |^{q_{1}} + 2^{1 - q_{1}} | ξ_{1} |^{q_{1}} {) 2}^{2 - 2 q_{1}} | ξ_{2} | \\ \leq 2^{2 - 2 q_{1}} l_{1} \frac{q_{1} x_{1}^{1 + q_{1}} + ξ_{2}^{1 + q_{1}}}{1 + q_{1}} + 2^{3 - 3 q_{1}} \frac{q_{1} ξ_{1}^{1 + q_{1}} + ξ_{2}^{1 + q_{1}}}{1 + q_{1}} \end{array}

(32)

Therefore, from (32), we have

\begin{array}{l} | u_{1} | | ξ_{2} |^{2 - 2 q_{1}} | u_{1} - x_{3}^{*} | \leq | u_{1} - x_{3}^{*} + x_{3}^{*} {| 2}^{2 - 2 q_{1}} | ξ_{2} | \\ \leq 2^{2 - 2 q_{1}} l_{2} \frac{(2 q_{1} - 1) ξ_{1}^{2 q_{1}} + ξ_{2}^{2 q_{1}}}{2 q_{1}} + 2^{4 - 4 q_{1}} ξ_{2}^{2 q_{1}} \end{array}

(33)

By using (33) and Lemmas 2–4, we have

\begin{array}{l} | x_{2} |^{\frac{1}{q_{1}} - 1} | u_{1} | | ξ_{2} |^{2 - 2 q_{1}} | u_{1} - x_{3}^{*} | \\ \leq (| x_{2}^{*} |^{\frac{1}{q_{1}} - 1} + | x_{2}^{\frac{1}{q_{1}} - 1} - x_{2}^{* \frac{1}{q_{1}} - 1} |) \\ \cdot {(2}^{2 - 2 q_{1}} l_{2} \frac{(2 q_{1} - 1) ξ_{1}^{2 q_{1}} + ξ_{2}^{2 q_{1}}}{2 q_{1}} + 2^{4 - 4 q_{1}} ξ_{2}^{2 q_{1}}) \\ \leq \frac{2^{2 - 2 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} l_{2}}{1 + q_{1}} ((1 - q_{1}) x_{1}^{1 + q_{1}} + (2 q_{1} - 1) ξ_{1}^{1 + q_{1}} \\ + ξ_{2}^{1 + q_{1}}) + 2^{2 - q_{1}} l_{2} \frac{q_{1} ξ_{1}^{1 + q_{1}} + ξ_{2}^{1 + q_{1}}}{1 + q_{1}} \\ + \frac{2^{4 - 4 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1}}{1 + q_{1}} ((1 - q_{1}) x_{1}^{1 + q_{1}} + 2 q_{1} ξ_{2}^{1 + q_{1}}) \\ + 2^{4 - 3 q_{1}} \frac{(1 - q_{1}) ξ_{1}^{1 + q_{1}} + 2 q_{1} ξ_{2}^{1 + q_{1}}}{1 + q_{1}} \end{array}

(34)

Substituting (29), (32)-(34) into (30), we have

\begin{array}{l} {\dot{V}}_{3} (x_{1}, x_{2}, u_{1}) \\ \leq (- l_{1} + \frac{2^{1 - q_{1}}}{1 + q_{1}} + \frac{α_{2} (2 - q_{1} {) 2}^{1 - q_{1}}}{k_{1} (1 + q_{1})} l_{1}^{1 + \frac{1}{q_{1}}} q_{1}) \\ \cdot x_{1}^{1 + q_{1}} + \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} 2^{2 - 2 q_{1}} | ξ_{2} |^{2 q_{1} - 1} \\ + (\frac{2^{1 - q_{1}} q_{1}}{1 + q_{1}} - \frac{l_{2}}{k_{1}} + \frac{α_{2} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}}}{k_{1}} (\frac{2^{1 - q_{1}} l_{1}}{1 + q_{1}} \\ + 2^{2 - 2 q_{1}})) ξ_{1}^{1 + q_{1}} + \frac{3 - 2 q_{1}}{k_{2}} l_{2}^{\frac{1}{2 q_{1} - 1}} l_{1}^{\frac{1}{q_{1}}} α_{2} \\ \cdot {(2}^{2 - 2 q_{1}} l_{1} \frac{q_{1} x_{1}^{1 + q_{1}} + ξ_{2}^{1 + q_{1}}}{1 + q_{1}} + 2^{3 - 2 q_{1}} \frac{q_{1} ξ_{1}^{1 + q_{1}} + ξ_{2}^{1 + q_{1}}}{1 + q_{1}}) \\ + \frac{3 - 2 q_{1}}{k_{2} q_{1}} l_{2}^{\frac{1}{2 q_{1} - 1}} {(2}^{2 - 2 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} l_{2} \\ \frac{(1 - q_{1}) x_{1}^{1 + q_{1}} + (2 q_{1} - 1) ξ_{1}^{1 + q_{1}} + ξ_{2}^{1 + q_{1}}}{1 + q_{1}} \\ + 2^{2 - q_{1}} l_{2} \frac{q_{1} ξ_{1}^{1 + q_{1}} + ξ_{2}^{1 + q_{1}}}{1 + q_{1}} \\ + 2^{4 - 4 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} \frac{(1 - q_{1}) x_{1}^{1 + q_{1}} + 2 q_{1} ξ_{2}^{1 + q_{1}}}{1 + q_{1}} \\ + 2^{4 - 3 q_{1}} \frac{(1 - q_{1}) ξ_{1}^{1 + q_{1}} + 2 q_{1} ξ_{2}^{1 + q_{1}}}{1 + q_{1}}) + \frac{ξ_{2}^{3 - 2 q_{1}}}{k_{2}} {\tilde{τ}}_{2}, \end{array}

(35)

Because

\begin{array}{l} \frac{1}{k_{1}} | ξ_{1} |^{2 - q_{1}} 2^{2 - 2 q_{1}} | ξ_{2} |^{2 q_{1} - 1} \\ \leq \frac{1}{k_{1}} 2^{2 - 2 q_{1}} \frac{(2 - q_{1}) ξ_{1}^{1 + q_{1}} + (2 q_{1} - 1) ξ_{2}^{1 + q_{1}}}{1 + q_{1}}, \end{array}

(36)

and

\begin{array}{l} {\tilde{τ}}_{2} = - l_{3} {(u_{1}^{\frac{1}{2 q_{1} - 1}} + l_{2}^{\frac{1}{2 q_{1} - 1}} (x_{2}^{\frac{1}{q_{1}}} + l_{1}^{\frac{1}{q_{1}}} x_{1}))}^{3 q_{1} - 2} \\ = - l_{3} ξ_{2}^{3 q_{1} - 2}, \end{array}

(37)

substituting (36) and (37) into (35) has

\begin{array}{l} {\dot{V}}_{3} (x_{1}, x_{2}, u_{1}) \\ \leq (- l_{1} + \frac{2^{1 - q_{1}}}{1 + q_{1}} + \frac{α_{2} (2 - q_{1} {) 2}^{1 - q_{1}}}{k_{1} (1 + q_{1})} l_{1}^{1 + \frac{1}{q_{1}}} q_{1} \\ + \frac{α_{2} (3 - 2 q_{1}) q_{1}}{k_{2} (1 + q_{1})} 2^{2 - 2 q_{1}} l_{1}^{1 + \frac{1}{q_{1}}} l_{2}^{\frac{1}{2 q_{1} - 1}} + \frac{(3 - 2 q_{1}) (1 - q_{1})}{k_{2} q_{1} (1 + q_{1})} \\ \cdot l_{1}^{\frac{1}{q_{1}} - 1} {(2}^{2 - 2 q_{1}} l_{2}^{\frac{2 q_{1}}{2 q_{1} - 1}} + 2^{4 - 4 q_{1}} l_{2}^{\frac{1}{2 q_{1} - 1}})) x_{1}^{1 + q_{1}} \\ + (\frac{2^{1 - q_{1}} q_{1}}{1 + q_{1}} - \frac{l_{2}}{k_{1}} + \frac{α_{2} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}}}{k_{1}} (\frac{2^{1 - q_{1}} l_{1}}{1 + q_{1}} + 2^{2 - 2 q_{1}}) \\ + \frac{(2 - q_{1} {) 2}^{2 - 2 q_{1}}}{k_{1} (1 + q_{1})} + \frac{(3 - 2 q_{1}) q_{1}}{k_{2} (1 + q_{1})} 2^{3 - 3 q_{1}} l_{1}^{\frac{1}{q_{1}}} l_{2}^{\frac{1}{2 q_{1} - 1}} \\ + \frac{(3 - 2 q_{1}) l_{2}^{\frac{1}{2 q_{1} - 1}}}{k_{2} q_{1} (1 + q_{1})} {(2}^{2 - 2 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} l_{2} (2 q_{1} - 1) + 2^{2 - q_{1}} q_{1} l_{2} \\ + 2^{4 - 3 q_{1}} (1 - q_{1}))) ξ_{1}^{1 + q_{1}} + (\frac{(2 q_{1} - {1) 2}^{2 - 2 q_{1}}}{k_{1} (1 + q_{1})} \\ + \frac{α_{2} (3 - 2 q_{1})}{k_{2} (1 + q_{1})} l_{1}^{\frac{1}{q_{1}}} l_{2}^{\frac{1}{2 q_{1} - 1}} {(2}^{2 - 2 q_{1}} l_{1} + 2^{3 - 3 q_{1}}) - \frac{l_{3}}{k_{2}} \\ + \frac{(3 - 2 q_{1}) l_{2}^{\frac{1}{2 q_{1} - 1}}}{k_{2} q_{1} (1 + q_{1})} {(2}^{2 - 2 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} l_{2} + 2^{2 - q_{1}} l_{2} \\ + 2^{5 - 4 q_{1}} q_{1} l_{1}^{\frac{1}{q_{1}} - 1} + 2^{5 - 3 q_{1}} q_{1})) ξ_{2}^{1 + q_{1}} . \end{array}

From (15)-(17), we can rewrite the formula above as follows

{\dot{V}}_{3} (x_{1}, x_{2}, u_{1}) \leq β_{1} x_{1}^{1 + q_{1}} + β_{2} ξ_{1}^{1 + q_{1}} + β_{3} ξ_{2}^{1 + q_{1}},

(38)

where

\begin{array}{l} β_{1} = - l_{1} + \frac{2^{1 - q_{1}}}{1 + q_{1}} + \frac{α_{2} (2 - q_{1} {) 2}^{1 - q_{1}}}{k_{1} (1 + q_{1})} l_{1}^{1 + \frac{1}{q_{1}}} q_{1} \\ + \frac{α_{2} (3 - 2 q_{1}) q_{1}}{k_{2} (1 + q_{1})} 2^{2 - 2 q_{1}} l_{1}^{1 + \frac{1}{q_{1}}} l_{2}^{\frac{1}{2 q_{1} - 1}} + \frac{(3 - 2 q_{1}) (1 - q_{1})}{k_{2} q_{1} (1 + q_{1})} \\ \cdot l_{1}^{\frac{1}{q_{1}} - 1} {(2}^{2 - 2 q_{1}} l_{2}^{\frac{2 q_{1}}{2 q_{1} - 1}} + 2^{4 - 4 q_{1}} l_{2}^{\frac{1}{2 q_{1} - 1}}) < 0, \end{array}

(39)

\begin{array}{l} β_{2} = \frac{2^{1 - q_{1}} q_{1}}{1 + q_{1}} - \frac{l_{2}}{k_{1}} + \frac{α_{2} (2 - q_{1}) l_{1}^{\frac{1}{q_{1}}}}{k_{1}} (\frac{2^{1 - q_{1}} l_{1}}{1 + q_{1}} + 2^{2 - 2 q_{1}}) \\ + \frac{(2 - q_{1} {) 2}^{2 - 2 q_{1}}}{k_{1} (1 + q_{1})} + \frac{(3 - 2 q_{1}) q_{1}}{k_{2} (1 + q_{1})} 2^{3 - 3 q_{1}} l_{1}^{\frac{1}{q_{1}}} l_{2}^{\frac{1}{2 q_{1} - 1}} \\ + \frac{(3 - 2 q_{1}) l_{2}^{\frac{1}{2 q_{1} - 1}}}{k_{2} q_{1} (1 + q_{1})} {(2}^{2 - 2 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} l_{2} (2 q_{1} - 1) \\ + 2^{2 - q_{1}} q_{1} l_{2} + 2^{4 - 3 q_{1}} (1 - q_{1})) < 0, \end{array}

(40)

\begin{array}{l} β_{3} = \frac{(2 q_{1} - {1) 2}^{2 - 2 q_{1}}}{k_{1} (1 + q_{1})} + \frac{α_{2} (3 - 2 q_{1})}{k_{2} (1 + q_{1})} l_{1}^{\frac{1}{q_{1}}} l_{2}^{\frac{1}{2 q_{1} - 1}} {(2}^{2 - 2 q_{1}} l_{1} \\ + 2^{3 - 3 q_{1}}) - \frac{l_{3}}{k_{2}} + \frac{(3 - 2 q_{1}) l_{2}^{\frac{1}{2 q_{1} - 1}}}{k_{2} q_{1} (1 + q_{1})} {(2}^{2 - 2 q_{1}} l_{1}^{\frac{1}{q_{1}} - 1} l_{2} \\ + 2^{2 - q_{1}} l_{2} + 2^{5 - 4 q_{1}} q_{1} l_{1}^{\frac{1}{q_{1}} - 1} + 2^{5 - 3 q_{1}} q_{1}) < 0. \end{array}

(41)

According to the definition of V₃(x₁,x₂,u₁), by using (27) and (31), we have

V_{3} (x_{1}, x_{2}, u_{1}) \leq \frac{x_{1}^{2}}{2 α_{2}^{\min}} + \frac{2^{1 - q_{1}}}{k_{1}} ξ_{1}^{2} + \frac{2^{2 - 2 q_{1}}}{k_{2}} ξ_{2}^{2} .

Let

ρ_{1} = \max {\frac{1}{2 α_{2}^{\min}}, \frac{2^{1 - q_{1}}}{k_{1}}, \frac{2^{2 - 2 q_{1}}}{k_{2}}},

it has

V_{3} (x_{1}, x_{2}, u_{1}) \leq ρ_{1} (x_{1}^{2} + ξ_{1}^{2} + ξ_{2}^{2}) .

(42)

From (38)-(41), take

\begin{array}{l} ρ_{2} = \max {β_{1}, β_{2}, β_{3}} < 0, 0 < c < - \frac{ρ_{2}}{ρ_{1}^{α}}, \\ α = \frac{1 + q_{1}}{2} \in (0,1), \end{array}

then we can obtain

\begin{array}{l} {\dot{V}}_{3} (x_{1}, x_{2}, u_{1}) + c V_{3}^{α} (x_{1}, x_{2}, u_{1}) \\ \leq (ρ_{2} + c ρ_{1}^{α}) (x_{1}^{1 + q_{1}} + ξ_{1}^{1 + q 1} + ξ_{2}^{1 + q_{1}}) \leq 0. \end{array}

(43)

Formulas (42)-(43) ensure that controller (37) can stabilize system (24) to zero in a finite time. Furthermore,

\begin{array}{l} \frac{\partial V_{3}}{\partial u_{1}} {\tilde{τ}}_{2} = \frac{1}{k_{2}} ξ_{2}^{3 - 2 q_{1}} (- l_{3}) ξ_{2}^{3 q_{1} - 2} = - \frac{l_{3}}{k_{2}} ξ_{2}^{1 + q_{1}} \leq 0, \\ a n d {\tilde{τ}}_{2} = 0 \Rightarrow ξ_{2} = 0 \Rightarrow \frac{\partial V_{3}}{\partial u_{1}} = \frac{1}{k_{2}} ξ_{2}^{3 - 2 q_{1}} = 0. \end{array}

Therefore, according to Theorem 1, subsystem of (6)

{\begin{array}{l} {\dot{x}}_{1} = α_{2} x_{2}, \\ {\dot{x}}_{2} = u_{1}, \\ {\dot{u}}_{1} = γ_{2} (t) τ_{2} + φ_{2} (t), \end{array}

can be stabilized to zero in a finite time T₂ by the controller τ₂ in Step 2.

Finally, by using the similar proof method, it's simple to prove that the subsystem of (6)

{\begin{array}{l} {\dot{x}}_{0} = α_{1} u_{0}, \\ {\dot{u}}_{0} = γ_{1} (t) τ_{1} + φ_{1} (t), \end{array}

can be stabilized to zero in a finite time T₃ by the controller τ₁ in Step 3. For brevity, here omit the detailed process in this step. And this completes the proof of Theorem 2. □

Remark 3: Note that, if we choose sufficiently large k₁ and k₂ in (15)-(17), then it's possible to find a group of feasible solutions for the design parameters although it's difficult to obtain all the solutions of these parameters as pointed out in [46]. Here, we propose a simple search algorithm for finding a group of feasible solutions of the parameters step by step as follows:

First, choose $q_{1} = \frac{p}{q} \in (\frac{2}{3},1)$ , ${\bar{k}}_{i j} > 0, (i = 1,2; j = 1,2,3)$ , then select k₁,k₂,l₁,l₂,l₃ in turn.

Step a: Given a sufficiently large $\bar{l} > 0$ , select k₁ > 0 satisfying (44)-(46):

\begin{array}{l} \frac{α_{2}^{\max} (2 - q_{1} {) 2}^{1 - q_{1}}}{k_{1} (1 + q_{1})} {\bar{l}}^{1 + \frac{1}{q_{1}}} q_{1} < {\bar{k}}_{11}, \end{array}

(44)

\begin{array}{l} \frac{α_{2}^{\max} (2 - q_{1})}{k_{1}} {\bar{l}}^{\frac{1}{q_{1}}} (\frac{2^{1 - q_{1}} \bar{l}}{1 + q_{1}} + 2^{2 - 2 q_{1}}) \\ + \frac{(2 - q_{1} {) 2}^{2 - 2 q_{1}}}{k_{1} (1 + q_{1})} < {\bar{k}}_{12}, \end{array}

(45)

\frac{(2 q_{1} - {1) 2}^{2 - 2 q_{1}}}{k_{1} (1 + q_{1})} < {\bar{k}}_{13} .

(46)

Select k₂ > 0 satisfying (47)-(49):

\begin{array}{l} \frac{(3 - 2 q_{1}) (1 - q_{1}) {\bar{l}}^{\frac{1}{q_{1}} - 1}}{k_{2} q_{1} (1 + q_{1})} {(2}^{2 - 2 q_{1}} {\bar{l}}^{\frac{2 q_{1}}{2 q_{1} - 1}} + 2^{4 - 4 q_{1}} {\bar{l}}^{\frac{1}{2 q_{1} - 1}}) \\ + \frac{α_{2}^{\max} (3 - 2 q_{1}) q_{1}}{k_{2} (1 + q_{1})} 2^{2 - 2 q_{1}} {\bar{l}}^{1 + \frac{1}{q_{1}}} {\bar{l}}^{\frac{1}{2 q_{1} - 1}} < {\bar{k}}_{21}, \end{array}

(47)

\begin{array}{l} \frac{(3 - 2 q_{1}) q_{1}}{k_{2} (1 + q_{1})} 2^{3 - 3 q_{1}} {\bar{l}}^{\frac{1}{q_{1}}} {\bar{l}}^{\frac{1}{2 q_{1} - 1}} + \frac{(3 - 2 q_{1}) {\bar{l}}^{\frac{1}{2 q_{1} - 1}}}{k_{2} q_{1} (1 + q_{1})} \\ \cdot {(2}^{2 - 2 q_{1}} {\bar{l}}^{\frac{1}{q_{1}} - 1} \bar{l} (2 q_{1} - 1) + 2^{2 - q_{1}} q_{1} \bar{l} \\ + 2^{4 - 3 q_{1}} (1 - q_{1})) < {\bar{k}}_{22}, \end{array}

(48)

\begin{array}{l} \frac{(3 - 2 q_{1}) {\bar{l}}^{\frac{1}{2 q_{1} - 1}}}{k_{2} q_{1} (1 + q_{1})} {(2}^{2 - 2 q_{1}} {\bar{l}}^{\frac{1}{q_{1}} - 1} \bar{l} + 2^{2 - q_{1}} \bar{l} + 2^{5 - 3 q_{1}} q_{1} \\ + 2^{5 - 4 q_{1}} q_{1} {\bar{l}}^{\frac{1}{q_{1}} - 1}) + \frac{α_{2}^{\max} (3 - 2 q_{1}) {\bar{l}}^{\frac{1}{q_{1}}} {\bar{l}}^{\frac{1}{2 q_{1} - 1}}}{k_{2} (1 + q_{1})} \\ {(2}^{2 - 2 q_{1}} \bar{l} + 2^{3 - 3 q_{1}}) < {\bar{k}}_{23} . \end{array}

(49)

If $\max {{\bar{l}}_{1}, {\bar{l}}_{2}} \leq \bar{l}$ , then go to Step b. Else if $\max {{\bar{l}}_{1}, {\bar{l}}_{2}} > \bar{l}$ , let $\bar{l} : = \max {{\bar{l}}_{1}, {\bar{l}}_{2}}$ , go to Step a. Where

{\bar{l}}_{1} = \frac{2^{1 - q_{1}}}{1 + q_{1}} + {\bar{k}}_{11} + {\bar{k}}_{21}, {\bar{l}}_{2} = k_{1} (\frac{2^{1 - q_{1}} q_{1}}{1 + q_{1}} + {\bar{k}}_{12} + {\bar{k}}_{22}) .

Step b: Select l₁, l₂, l₃ such that

\bar{l} > l_{1} > {\bar{l}}_{1}, \bar{l} > l_{2} > {\bar{l}}_{2}, l_{3} > k_{2} ({\bar{k}}_{13} + {\bar{k}}_{23}) .

Remark 4: As for (18)-(19), we can choose $q_{2} = \frac{p_{1}}{q_{1}} \in (0,1)$ , ${\tilde{k}}_{1} > 0$ , then choose ${\tilde{k}}_{2} > 0$ such that

\frac{{\tilde{k}}_{1}^{2 + q_{2}} α_{1}^{\max}}{4 {\tilde{k}}_{2}} 2^{1 - \frac{1}{q_{2}}} < \frac{3}{4} {\tilde{k}}_{1} .

Finally, we select ${\tilde{k}}_{3} > 0$ such that

\frac{{\tilde{k}}_{3}}{{\tilde{k}}_{2}} > \frac{2^{1 - \frac{1}{q_{2}}}}{1 + q_{2}} {(\frac{2^{3 - \frac{1}{q_{2}}} q_{2}}{(1 + q_{2}) {\tilde{k}}_{1}})}^{q_{2}} + \frac{{\tilde{k}}_{1}^{q_{2}} α_{1}^{\max}}{{\tilde{k}}_{2}} 2^{1 - \frac{1}{q_{2}}}

Remark 5: In this paper, we present a finite-time switching controller for the uncertain robot systems, but it is challenging to estimate the bounds for the settled time, because this time depends on the bounds of uncertain parameters, the external disturbance and the initial state value.

4. Simulations

In this section, the switching controller proposed in Theorem 2 is used to show how to stabilize the uncertain visual feedback system (6) in a finite time. We will demonstrate the effectiveness of our methods by an example.

In the following simulation, we assume that: $α_{i}^{\min} = 0.5, α_{i}^{\max} = 1.5$ , $γ_{i}^{m} = 1, γ_{i}^{M} = 2$ , $φ_{i}^{M} = 2.5, (i = 1,2)$ According to the discussion of selecting parameters in Remark 2 and Remark 3, for given $\bar{l} = 4.5, {\bar{k}}_{i j} = 0.6, (i = 1,2; j = 1,2,3)$ , choosing $q_{0} = \frac{1}{2}, q_{1} = \frac{7}{9}, q_{2} = \frac{1}{3}$ , $λ_{1} = 1, k_{1} = 2.4, k_{2} = 1.7$ , $l_{1} = 2, l_{2} = 4.2, l_{3} = 2.1$ , ${\tilde{k}}_{1} = 1.5, {\tilde{k}}_{2} = 2.6, {\tilde{k}}_{3} = 6.5$ The initial condition of (6) is (−0.2, 0.3, −0.5, 5.6, 0.8).

Figures 3–5 show some simulation results with MATLAB. Figure 3 shows that the state variable (x₀, u₀) goes to zero in a finite time t ≤ 35s. From which, one can observe that u₀ is stabilized to a constant (u₀ = 1) and keep it in Step 2 until it is driven to zero together with x₀ in the last step.

Note that in Figure 3, for u₀, during the control process, we design a controller τ₁ to make it converge to the constant 1 in Step 1 - Step 2, while in Step 3, we give another robust controller τ₁ such that (x₀, u₀) can be stabilized to zero in a finite time, and thus, we find that there is a peak at t=25s because of using this discontinuous switching controller.

Figure 4 shows the state (x₁, x₂, u₁) can be stabilized to zero step by step within the finite-time interval [0, 35s] under this switching controller (τ₁, τ₂) demonstrated in Figure 5.

Figure 3.

The response of the state variable (x₀, u₀) with respect to time

Figure 4.

The response of state variable (x₁, x₂, u₁) with respect to time

Figure 5.

The response of the control input (τ₁, τ₂) with respect to time

Figure 6.

The response of the state variable x_m with respect to time

Figure 7.

The response of the state variable y_m with respect to time

Figure 8.

The response of the state variable θ with respect to time

Additionally, the following simulation results Figures 6–8 are about the original mobile robot system with visual servoing (4), from which, we can observe that the system state (x_m, y_m, θ) can also be stabilized to zero in a finite time.

5. Conclusion

In this article, a new switching controller is presented for solving the global finite-time stabilization problem of the nonholonomic mobile robots based on visual serving with uncalibrated camera parameters and external perturbation. The best innovation of this paper is that the discontinuous controller design is based on applying the stability theorem of finite-time and a new switching design method such that the states of closed-loop system can be stabilized to origin point in a finite time. In the near future, we will discuss the corresponding finite-time stabilization problem with saturated control inputs.

Footnotes

6.

This paper was supported by the National Science Foundation of China (61304004, 61203014, 11274092,1077403), the China Postdoctoral Science Foundation funded project (2013M531263), the Jiangsu Planned Projects for Postdoctoral Research Funds (1302140C), the National Science Foundation of Jiangsu Province (BK2012283), the Ministry of Education of Jiangsu Province (1066-B11025), the R & D Special Fund for Public Welfare Industry (201101014), the Ministry of Education of China (MS2010HHDX044) and the National Basic Research Program of China (973 Program) (2010CB832702).

Appendix A.

Adopt the similar proof method as it in [45], the time derivative of the Lyapunov function $\tilde{V}$ along a non-trivial trajectory of system (11) is given as

\begin{array}{l} \dot{\tilde{V}} = \sum_{i = 1}^{r - 1} \frac{\partial \tilde{V}}{\partial z_{i}} β_{i} z_{i + 1} + \frac{\partial \tilde{V}}{\partial z_{r}} (γ (t) u + φ (t)) \\ \leq \sum_{i = 1}^{r - 1} \frac{\partial \tilde{V}}{\partial z_{i}} β_{i} z_{i + 1} + \frac{\partial \tilde{V}}{\partial z_{r}} {\bar{u}}_{0} (z) \\ + \frac{\partial \tilde{V}}{\partial z_{r}} (\frac{γ (t)}{γ_{m}} \bar{φ} s i g n ({\bar{u}}_{0} (z)) + φ (t)) \end{array}

Because $\frac{\partial \tilde{V}}{\partial z_{r}} (z) {\bar{u}}_{0} (z) \leq 0$ , if ${\bar{u}}_{0} (z) \geq 0$ , then $\frac{\partial \tilde{V}}{\partial z_{r}} \leq 0,$

\frac{\partial \tilde{V}}{\partial z_{r}} (\frac{γ (t)}{γ_{m}} \bar{φ} s i g n ({\bar{u}}_{0} (z)) + φ (t)) \leq \frac{\partial \tilde{V}}{\partial z_{r}} (\bar{φ} - | φ (t) |) \leq 0.

On the other hand, if ${\bar{u}}_{0} (z) < 0$ , then $\frac{\partial \tilde{V}}{\partial z_{r}} \geq 0$ and

\begin{array}{l} \frac{\partial \tilde{V}}{\partial z_{r}} (\frac{γ (t)}{γ_{m}} \bar{φ} s i g n ({\bar{u}}_{0} (z)) + φ (t)) = \frac{\partial \tilde{V}}{\partial z_{r}} (\frac{- γ (t)}{γ_{m}} \bar{φ} + φ (t)) \\ \leq \frac{\partial \tilde{V}}{\partial z_{r}} (| φ (t) | - \bar{φ}) \leq 0. \end{array}

Therefore, we have

\dot{\tilde{V}} \leq \sum_{i = 1}^{r - 1} \frac{\partial \tilde{V}}{\partial z_{i}} β_{i} z_{i + 1} + \frac{\partial \tilde{V}}{\partial z_{r}} {\tilde{u}}_{0} (z) \leq - \tilde{c} {\tilde{V}}^{\tilde{α}} (z) .

According to Lemma 1, any a non-trivial trajectory z of system (11) reaches zero and stays there in a finite time.

References

Brockett

R. W.

, “Asymptotic stability and feedback stabilization”, in: Brockett

R. W.

Millman

R. S.

Sussmann

H. J.

(Eds.), Differential Geometric Control Theory, Birkhauser, Boston, pp. 181–208, 1983.

Murray

R. M.

and Sastry

S. S.

, “Nonholonomic motion planning: Steering using sinusoids”, IEEE Trans. Automat. Control., vol. 38, no. 5, pp. 700–716, May 1993.

Tian

Y. P.

and Li

, “Exponential stabilization of nonholonomic dynamic systems by smooth time-varying control”, Automatica, vol. 38, no. 7, pp. 1139–1146, 2002.

Teel

Murry

and Walsh

, “Nonholonomic control systems: From steering to stabilization with sinusoids”, in Proc. IEEE Conf. Decision Control, pp. 1603–1609, 1992.

Sordalen

O. J.

and Egeland

, “Exponential stabilization of nonholonomic chained systems”, IEEE Trans. Automat. Control., vol. 40, no. 1, pp. 35–49, 1995.

Hespanha

J. P.

, “Stabilization of the nonholonomic integrator via logic-based switching”, in Yale University, Technical Report, 1995.

Aguiar

A. P.

and Pascoal

, “Stabilization of the extended nonholonomic double integrator via logic based hybridcontrol”, in Proceedings of 6th international IFAC symposium on robot control, ViennaíCAustria, September 2000.

Astolfi

, “Discontinuous control of nonholonomic systems”, Syst. Control Lett., vol. 27, pp. 37–45, 1996.

Bloch

A. M.

and Drakunov

, “Stabilization of a nonholonomic systems via sliding modes”, in Proc. IEEE Conf. Decision Control, pp. 2961–2963, 1995.

10.

Canudas de Wit

and Sordalen

O. J.

, “Exponential stabilization of mobile robots with nonholonomic constraints”, IEEE Trans. Automat. Control., vol. 37, no. 11, pp. 1791–1797, 1992.

11.

Laiou

M. C.

and Astolfi

, “Discontinuous control of high-order generalized chained systems”, Syst. Control Lett., vol. 37, pp. 309–322, 1999.

12.

Desai

J. P.

Ostrowski

J. P.

and Kumar

, “Modeling and control of formations of nonholonomic mobile robots”, IEEE Transactions on Robotics and Automation, vol. 17, no. 6, pp. 905–908, 2001.

13.

Vidal

Shakernia

and Sastry

, “Formation control of nonholonomic mobile robots with omnidirectional visual servoing and motion segmentation”, in: IEEE International Conference on Robotics and Automation, vol. 1, pp. 584–589, 2003.

14.

Wenjie Dong, “Tracking control of multiple-wheeled mobile robots with limited information of a desired trajectory”, IEEE Transactions on Robotics, vol. 28, no. 1, pp. 262–268, 2012.

15.

Tengfei

Liu

and Zhongping

Jiang

, “Distributed formation control of nonholonomic mobile robots without global position measurements”, Automatica, vol. 49, no. 2, pp. 592–600, 2013.

16.

Laumond

J. P.

Jacobs

P. E.

Taix

and Murray

R. M.

, “A motion planner for nonholonomic mobile robots”, IEEE Transactions on Robotics and Automation, vol. 10, no. 5, pp. 577–593, 1994.

17.

Fukao

Nakagawa

and Adachi

, “Adaptive tracking control of a nonholonomic mobile robot”, IEEE Transactions on Robotics and Automation, vol. 16, no. 5, pp. 609–615, 2000.

18.

Park

B. S.

Yoo

S. J.

Park

J. B.

and Choi

Y. H.

, “A simple adaptive control approach for trajectory tracking of electrically driven nonholonomic mobile robots”, IEEE Transactions on Control Systems Technology, vol. 18, no. 5, pp. 1199–1206, 2010.

19.

Chen

Hua

Wang

Chaoli

Zhang

Binwu

and Dongkai

Zhang

, “Saturated tracking control for nonholonomic mobile robots with dynamic feedback”, Transactions of the Institute of Measurement and Control, vol. 35, no. 2, pp. 105–116, 2013.

20.

Giildiier

kin

V. I.

, “Stabilization of nonholonomic mobile robots using Lyapunov functions for navigation and sliding mode control”, in: The 33rd IEEE Conference on Decision and Control, vol. 3, pp. 2967–2972, 1994.

21.

Zhang

Xuebo

Fang

Yongchun

and Ning

Sun

, “Visual servoing of mobile robots for posture stabilization: from theory to experiments”, International Journal of Robust and Nonlinear Control, doi: 10.1002/rnc.3067, 2013.

22.

Jianga

Z. P.

Lefeberb

and Nijmeijer

, “Saturated stabilization and tracking of a nonholonomic mobile robot”, Syst. Control Lett., vol. 42, no. 5, pp. 327–332, 2001.

23.

Huang

Jiangshuai

Wen

Changyun

Wang

Wei

Jiang

Zhongping

, “Adaptive stabilization and tracking control of a nonholonomic mobile robot with input saturation and disturbance”, Syst. Control Lett., vol. 62, no. 3, pp. 234–241, 2013.

24.

Chen

Hua

Wang

Chaoli

Yang

Liu

and Dongkai

Zhang

, “Semiglobal stabilization for nonholonomic mobile robots based on dynamic feedback with inputs saturation”, Journal of Dynamic Systems, Measurement, and Control, vol. 134, no. 4, pp. 041006. 1–041006.8, 2012.

25.

Wang

Chaoli

Mei

Yingchun

Liang

Zhenying

and Qingwei

Jia

, “Dynamic feedback tracking control of nonholonomic mobile robots with unknown camera parameters”, Transactions of the Institute of Measurement and Control, vol. 32, no. 2, pp. 155–169, 2010.

26.

Zhenying

Liang

and Chaoli

Wang

, “Robust Exponential Stabilization of Uncertain Nonholonomic Chained Systems Based on Visual Feedback,” Journal of Systems Science and Complexity, vol. 25, pp. 441–450, 2012.

27.

Chen

Hua

Zhang

Jinbo

Chen

Bingyan

and Baojun

, “Global practical stabilization for nonholonomic mobile robots with uncalibrated visual parameters by using a switching controller,” IMA Journal of Mathematical Control and Information, doi: 10.1093/imamci/dns044, 2013.

28.

Chen

Hua

Chen

Bingyan

Baojun

and Jinbo

Zhang

, “Practical stabilization of uncertain nonholonomic mobile robots based on visual servoing model with uncalibrated camera parameters,” Mathematical Problems in Engineering, https://dx-doi-org.web.bisu.edu.cn/10.1155/2013/395410, 2013.

29.

Yang

Fang

Wang

Chaoli

and Guangzhu

Jing

, “Adaptive tracking control for dynamic nonholonomic mobile robots with uncalibrated visual parameters”, International Journal of Adaptive Control and Signal Processin, vol. 27, pp. 688–700, 2013.

30.

Meiying

Shihua

and Chaoli

Wang

, “Finite-time tracking control for nonholonomic mobile robots based on visual servoing”, Asian Journal of Control, vol. 16, no. 3, pp. 1–13, 2014.

31.

Meiying

Shihua

and Chaoli

Wang

, “Finite-time tracking control for multiple nonholonomic mobile robots based on visual servoing”, International Journal of Control, doi: 10.1080/00207179.2013.803157, 2013.

32.

Yiguang

Hong

, “Finite-time stabilization and stabilizability of a class of controllable systems,” Syst. Control Lett., vol.46, pp.231–236, 2002.

33.

Bhat

S. P.

Bernstein

D. S.

, “Continuous Finite-Time Stabilization of the translational and rotational double integrators,” IEEE Trans. Automat. Control., vol.43, pp.678–682, 1998.

34.

Haimo

V. T.

, “Finite-time controllers,” SIAM J Control Optim, vol.24, pp.760–770, 1986.

35.

Hong

Yiguang

Wang

Jiankui

and Zairong

, “Stabilization of uncertain chained form systems within finite settling time,” IEEE Trans. Automat. Control., vol.50, no.9, pp.1379–1384, 2005.

36.

Qinglei

Zhang

Aihua

, “Robust finite-time control allocation in spacecraft attitude stabilization under actuator misalignment,” Nonlinear Dynamics, vol. 73, pp. 53–71, 2013.

37.

Zhao

Junjie

Shen

Hao

Wang

Jing

, “Finite-time H-infty control for a class of Markovian jump delayed systems with input saturation,” Nonlinear Dynamics, vol. 73, pp. 1099–1110, 2013.

38.

Aghababa

Mohammad Pourmahmood

, “Finite-time chaos control and synchronization of fractional-order nonautonomous chaotic (hyperchaotic) systems using fractional nonsingular terminal sliding mode technique,” Nonlinear Dynamics, vol. 69, pp. 247–261, 2012.

39.

Campion

Bastin

and D'Andrea-Novel

, “Structural Properties and Classification of Kinematic and Dynamic Models of Wheeled Mobile Robots”, IEEE Trans. Robot. Autom., vol. 12, no. 1, pp. 47–62, 1996.

40.

Wang

Chaoli

Liang

Zhenying

and Yunhui

Liu

, “Dynamic Feedback Robust Regulation of Nonholonomic Mobile Robots Based on Visual Servoing”, in Joint 48th IEEE Conference on Decision and Control and 28th Chinese Control Conference, 4384–4389, 2009.

41.

Zhenying

Liang

and Chaoli

Wang

, “Robust stabilization of nonholonomic chained form systems with uncertainties”, ACTA Automatica Sinica, vol. 37, no. 2, pp. 129–142, 2011.

42.

Bhat

S. P.

Bernstein

D. S.

, “Finite-time stability of continuous autonomous systems”, SIAM J. Control Optim., vol. 38, no. 3, pp. 751ÍC766, 2000.

43.

Hardy

G. H.

Littlewood

J. E.

and Polya

, “Inequalities”, Cambridge university press, 1952.

44.

Qian

and Lin

, “A continuous feedback approach to global strong stabilization of nonlinear systems”, IEEE Trans. Automat. Control., vol. 46, no. 7, pp. 1061–1079, 2001.

45.

Harmouche

Laghrouche

and Chitour

, “A Lyapunov approach to robust and adaptive finite time stabilization of integrator chains with bounded uncertainty”, ar Xiv preprint, arXiv:1303.5117, 2013.

46.

Wang

Zhao

Shihua

and Shumin

Fei

, “Finite-time tracking control of a nonholonomic mobile robot”, Asian Journal of Control, vol. 11, no. 7, pp. 344–357, 2009.
