Near-infrared (NIR) spectroscopy is a well-established technique for the chemical analysis of organic and inorganic matter. Accordingly, spectroscopic instrumentation of different complexity has been developed and is currently commercially available. However, there are an increasing number of new mobile applications that have come into focus and that cannot be addressed by the existing technology due to size and cost. Therefore, a new miniaturized scanning grating spectrometer for NIR spectroscopy has been developed at Fraunhofer IPMS. It is based on micro–electro–mechanical systems (MEMS) technology, and has been designed to meet the requirements for mobile application, regarding spectral range, resolution, overall size, robustness, and cost. The MEMS spectrometer covers a spectral range from 950 nm to 1900 nm at a resolution of 10 nm. The instrument is extremely small and has a volume of only 2.1 cm³. Therefore, it is well suited for integration, even into a mobile phone. A first sample of the new spectrometer has been manufactured and put into operation. The results of a series of test measurements are in good agreement with the requirements and specifications.

The change in custody of fuel shipments at depots, pipelines, and ports could benefit from an analyzer that could rapidly verify that properties are within specifications. To meet this need, the design requirements for a fuel analyzer based on near-infrared (NIR) spectroscopy, such as spectral region and resolution, were examined. It was found that the 1000 to 1600 nm region, containing the second CH overtone and combination vibrational modes of hydrocarbons, provided the best near-infrared to fuel property correlations when path length was taken into account, whereas 4 cm⁻¹ resolution provided only a modest improvement compared to 16 cm⁻¹ resolution when four or more latent variables were used. Based on these results, a field-portable near-infrared fuel analyzer was built that employed an incandescent light source, sample compartment optics to hold 2 mL glass sample vials with ∼1 cm path length, a transmission grating, and a 256 channel InGaAs detector that measured the above stated wavelength range with 5–6 nm (∼32 cm⁻¹) resolution. The analyzer produced high signal-to-noise ratio (SNR) spectra of samples in 5 s. Twenty-two property correlation models were developed for diesel, gasoline, and jet fuels with root mean squared error of correlation – cross-validated values that compared favorably to corresponding ASTM reproducibility values. The standard deviations of predicted properties for repeat measurements at 4, 24, and 38℃ were often better than ASTM documented repeatability values. The analyzer and diesel property models were tested by measuring seven diesel samples at a local ASTM certification laboratory. The standard deviations between the analyzer determined values and the ASTM measured values for these samples were generally better than the model root mean squared error of correlation—cross-validated values for each property.

A real-time image processing algorithm is developed to enhance the sensitivity of a planar single-mode waveguide miniature spectrometer with integrated waveguide gratings. A novel approach of averaging along the arcs in a curved coordinate system is introduced which allows for collecting more light, thereby enhancing the sensitivity. The algorithm is tested using CdSeS/ZnS quantum dots drop casted on the surface of a single-mode waveguide. Measurements indicate that a monolayer of quantum dots is expected to produce guided mode attenuation approximately 11 times above the noise level.

Two-dimensional color CMOS cameras have become ubiquitous. They promise to support ubiquitous spectrometry. When raw illumination levels can be measured by such cameras, their use for spectrometry depends on using as many pixels as possible and on being able to calibrate images at point-of-use. Stacked, mutually rotated transmission diffraction gratings provide a means to generate multi-order, wide dynamic range dispersed visible spectra suitable for absorption, reflection, and fluorescence spectrometry. The theoretical basis for dispersion, resolution, and normalization of such spectra are derived, and initial characterization is reported.

A new low-cost experimental setup based on two compact dispersive optical spectrometers has been developed to measure optical absorption transmission spectra over the 350–2500 nm energy range. We demonstrate how near-infrared (NIR) data are essential to identify the coloring species in addition to ultraviolet visible data. After calibration with reference glasses, the use of an original sample stage that maintains the window panel in the vertical position enables the comparison of ancient and modern glasses embedded in a panel from the Sainte-Chapelle of Paris, without any sampling. The spectral resolution enables to observe fine resonances arising in the absorption bands of Cr³⁺, and the complementary information obtained in the NIR enables to determine the contribution of Fe²⁺, a key indicator of glassmaking conditions.

An expedited field analysis method was developed for the determination of polychlorinated biphenyls (PCBs) in soil matrices using a portable gas chromatography–mass spectrometry (GC-MS) instrument. Soil samples of approximately 0.5 g were measured with a portable scale and PCBs were extracted by headspace solid-phase microextraction (SPME) with a 100 µm polydimethylsiloxane (PDMS) fiber. Two milliliters of 0.2 M potassium permanganate and 0.5 mL of 6 M sulfuric acid solution were added to the soil matrices to facilitate the extraction of PCBs. The extraction was performed for 30 min at 100 ℃ in a portable heating block that was powered by a portable generator. The portable GC-MS instrument took less than 6 min per analysis and ran off an internal battery and helium cylinder. Six commercial PCB mixtures, Aroclor 1016, 1221, 1232, 1242, 1248, 1254, and 1260, could be classified based on the GC chromatograms and mass spectra. The detection limit of this method for Aroclor 1260 in soil matrices is approximately 10 ppm, which is sufficient for guiding remediation efforts in contaminated sites. This method was applicable to the on-site analysis of PCBs with a total analysis time of 37 min per sample. However, the total analysis time could be improved to less than 7 min per sample by conducting the rate-limiting extraction step for different samples in parallel.

A key quality and processing parameter for cotton fiber is micronaire, which is a function of the fiber's maturity and fineness. Near-infrared (NIR) spectroscopy has previously shown the ability to measure micronaire, primarily in the laboratory and using large, research-grade laboratory NIR instrumentation. International interest has been expressed by the industry in the measurement of fiber micronaire using small, portable NIR spectroscopy instruments for both laboratory and outside the laboratory (e.g., field or greenhouse) locations. New, very small NIR micro-spectrometers have been commercialized that offer the potential advantages of smaller size and lower weight, lower cost, and increased portability over current portable units. A program was implemented to determine the feasibility of a small NIR micro-spectrometer to measure fiber micronaire both in the laboratory and outside the laboratory, with initial emphasis on laboratory measurements prior to moving to field evaluations. In the laboratory, distinct spectral differences with increasing micronaire were observed. Optimal sampling and instrumental procedures and protocols for two units (different spectral wavelength capabilities) were established. Comparative evaluations established very good method micronaire agreement between the micro-spectrometer and a standard portable spectrometer, with high Regression (R) value, low residuals, and few outliers (less than 20%). The NIR micro-spectrometer measurements were fast (<1 min per sample), required no sample preparation, and were easy to perform. All end-state criteria were exceeded. The rapid and accurate laboratory measurement of fiber micronaire with a NIR micro-spectrometer was demonstrated.

In this article we outline how ultra-compact, yet high performance spectrometers can be designed and built with highly dispersive transmission gratings. By using fused silica as the grating material, and by careful design of the detailed grating structure, we demonstrate an ultraviolet spectrometer with a high and nearly flat efficiency from 178 to 409 nm, a resolution of 0.2 nm, and dimensions of only 61 mm × 64 mm × 19 mm. We tested this spectrometer in a laser-induced breakdown spectroscopy experiment and showed that the spectral information gathered with the spectrometer can be used to obtain quantitative results for sulfur.

While laser-induced breakdown spectroscopy (LIBS) has been in use for decades, only within the last two years has technology progressed to the point of enabling true handheld, self-contained instruments. Several instruments are now commercially available with a range of capabilities and features. In this paper, the SciAps Z-500 handheld LIBS instrument functionality and sub-systems are reviewed. Several assayed geochemical sample sets, including igneous rocks and soils, are investigated. Calibration data are presented for multiple elements of interest along with examples of elemental mapping in heterogeneous samples. Sample preparation and the data collection method from multiple locations and data analysis are discussed.

Near-infrared spectroscopy as a rapid and non-destructive analytical technique offers great advantages for pharmaceutical raw material identification (RMID) to fulfill the quality and safety requirements in pharmaceutical industry. In this study, we demonstrated the use of portable miniature near-infrared (MicroNIR) spectrometers for NIR-based pharmaceutical RMID and solved two challenges in this area, model transferability and large-scale classification, with the aid of support vector machine (SVM) modeling. We used a set of 19 pharmaceutical compounds including various active pharmaceutical ingredients (APIs) and excipients and six MicroNIR spectrometers to test model transferability. For the test of large-scale classification, we used another set of 253 pharmaceutical compounds comprised of both chemically and physically different APIs and excipients. We compared SVM with conventional chemometric modeling techniques, including soft independent modeling of class analogy, partial least squares discriminant analysis, linear discriminant analysis, and quadratic discriminant analysis. Support vector machine modeling using a linear kernel, especially when combined with a hierarchical scheme, exhibited excellent performance in both model transferability and large-scale classification. Hence, ultra-compact, portable and robust MicroNIR spectrometers coupled with SVM modeling can make on-site and in situ pharmaceutical RMID for large-volume applications highly achievable.

Copper laden ore is often concentrated using flotation. Before the head flow slurry can be smelted, it is important to know the concentration of copper and contaminants. The concentration of copper and other elements fluctuate significantly in the head flow, often requiring modification of the concentrations in the slurry prior to smelting. A rapid, real-time analytical method is needed to support on-site optimization of the smelter feedstock. A portable, handheld X-ray fluorescence spectrometer was utilized to determine the copper concentration in a head flow suspension at the slurry origin. The method requires only seconds and is reliable for copper concentrations of 2.0–25%, typically encountered in such slurries.

This research describes the application of portable field Raman spectroscopy combined with a statistical analysis of the resulting spectra, employing principal component analysis (PCA) and linear discriminant analysis (LDA), in which we determine that this method provides a high degree of reliability in the early detection of Huanglongbing (HLB) on Sweet Orange, disease caused by the bacteria Candidatus Liberibacter asiaticus. Symptomatic and asymptomatic plant samples of Sweet Orange (Citrus sinensis), Persian Lime (C. latifolia), and Mexican Lime (C. aurantifolia) trees were collected from several municipalities, three at Colima State and three at Jalisco State (HLB presence). In addition, Sweet Orange samples were taken from two other Mexican municipalities, one at San Luis Potosí and the other at Veracruz (HLB absent). All samples were analyzed by real-time PCR to determine its phytosanitary condition, and its spectral signatures were obtained with an ID-Raman mini. Spectral anomalies in orange trees HLB-positive, were identified in bands related to carbohydrates (905 cm⁻¹, 1043 cm⁻¹, 1127 cm⁻¹, 1208 cm⁻¹, 1370 cm⁻¹, 1272 cm⁻¹, 1340 cm⁻¹, and 1260–1280 cm⁻¹), amino acids, proteins (815 cm⁻¹, 830 cm⁻¹, 852 cm⁻¹, 918 cm⁻¹, 926 cm⁻¹, 970 cm⁻¹, 1002 cm⁻¹, 1053 cm⁻¹, and 1446 cm⁻¹), and lipids (1734 cm⁻¹, 1736 cm⁻¹, 1738 cm⁻¹, 1745 cm⁻¹, and 1746 cm⁻¹). Moreover, PCA–LDA showed a sensitivity of 86.9 % (percentage of positives, which are correctly identified), a specificity of 91.4 % (percentage of negatives, which are correctly identified), and a precision of 89.2 % (the proportion of all tests that are correct) in discriminating between orange plants HLB-positive and healthy plants. The Raman spectroscopy technique permitted rapid diagnoses, was low-cost, simple, and practical to administer, and produced immediate results. These are essential features for phytosanitary epidemiological surveillance activities that may conduct a targeted selection of highly suspicious trees to undergo molecular DNA analysis.

Transportable energy dispersive X-ray fluorescence (XRF) spectrometers allow the elemental composition of coins to be measured at collections, enhancing security while maximizing access to historically important material. We assessed 10 silver coins, using five XRF spectrometers. We found no systematic differences between analyses using Mo- and Rh-anode tubes, and no substantial advantage using He flush over air for elements heavier than Ti. Higher voltage X-ray tubes enhanced analytical precision. Understanding patina composition made a numerical correction possible, allowing an approximation of the underlying coin metal with good results for metals including Cu, Ag, Au, Pb, and Bi.

The aim of this contribution is to demonstrate the transfer of spectra that have been measured on two different laboratory Fourier transform near-infrared (FT-NIR) spectrometers to the format of a handheld instrument by measuring only a few samples with both spectrometer types. Thus, despite the extreme differences in spectral range and resolution, spectral data sets that have been collected and quantitative as well as qualitative calibrations that have been developed thereof, respectively, over a long period on a laboratory instrument can be conveniently transferred to the handheld system. Thus, the necessity to prepare completely new calibration samples and the effort required to develop calibration models when changing hardware platforms is minimized. The enabling procedure is based on piecewise direct standardization (PDS) and will be described for the data sets of a quantitative and a qualitative application case study. For this purpose the spectra measured on the FT-NIR laboratory spectrometers were used as “master” data and transferred to the “target” format of the handheld instrument. The quantitative test study refers to transmission spectra of three-component liquid solvent mixtures whereas the qualitative application example encompasses diffuse reflection spectra of six different current polymers. To prove the performance of the transfer procedure for quantitative applications, partial least squares (PLS-1) calibrations were developed for the individual components of the solvent mixtures with spectra transferred from the master to the target instrument and the cross-validation parameters were compared with the corresponding parameters obtained for spectra measured on the master and target instruments, respectively. To test the retention of the discrimination ability of the transferred polymer spectra sets principal component analyses (PCAs) were applied exemplarily for three of the six investigated polymers and their identification was demonstrated by Mahalanobis distance plots for all polymers.

Alakai Defense Systems has recently developed a man-portable ultraviolet Raman spectrometer system. The portable Raman improvised explosives detector was designed to provide rapid, standoff detection of chemicals of interest to the end user, including, but not limited to explosives, narcotics, toxic industrial chemicals, and toxic industrial materials. In this paper, we discuss general aspects of the system design and user interface. Spectral and instrument performance data are shown for several common materials involved in narcotics manufacture, as well as cocaine and heroin, with comparisons to currently marketed handheld Raman instruments.

A cheap portable visible light spectrometer is presented. The spectrometer uses readily sourced items and could be constructed by anyone with a knowledge of electronics. The spectrometer covers the wavelength range 450–725 nm with a resolution better than 5 nm. The spectrometer uses a diffraction grating to separate wavelengths, which are detected using a 128-element diode array, the output of which is analyzed using a microprocessor. The spectrum is displayed on a small liquid crystal display screen and can be saved to a micro SD card for later analysis. Battery life (2 × AAA) is estimated to be 200 hours. The overall dimensions of the unit are 120 × 65 × 60 mm, and it weighs about 200 g.

We fabricated a visible–near-infrared (Vis-NIR) portable field imaging spectrometer with a prism–grating–prism element and a scanning mirror. The developed Vis-NIR imaging spectrometer, consisting of an INFINITY 3-1 detector and a V10E spectrometer from Specim Corporation, is designed to measure the spectral range between 0.4 and 1 µm with spectral resolution of 2–4 nm. In recent years, sulfur fumigation has been abused during the processing of certain freshly harvested Chinese herbs. Fourier transform infrared spectroscopy, fiber optic NIR spectrometry, and liquid chromatography–mass spectrometry are typically used to analyze the chemical profiles of sulfur-fumigated and sun-dried Chinese herbs. Field imaging spectrometry is rarely used to identify sulfur-fumigated herbs. In this study, field imaging spectrometry, principal component analysis, and the partial least squares-discriminant analysis multivariate data analysis method are used to distinguish sun-dried and sulfur-fumigated Chinese medicinal herbs with a sensitivity of 96.4% and a specificity of 98.3% for RPA identification. These results suggest that hyperspectral imaging is a potential technique to control medicine quality for medical applications.

Portable gas chromatography–mass spectrometry (GC-MS) systems are being deployed for field use, and are designed with this goal in mind. Performance characteristics of instruments that are successful in the field are different from those of equivalent technologies that are successful in a laboratory setting. These field-portable systems are extending the capabilities of the field user, providing investigative leads and confirmatory identifications in real time. Many different types of users benefit from the availability of this technology including emergency responders, the military, and law-enforcement organizations. This manuscript describes performance characteristics that are important for field-portable instruments, especially field-portable GC-MS systems, and demonstrates the value of this equipment to the disciplines of explosives investigations, fire investigations, and counterfeit-drug detection. This paper describes the current state of portable GC-MS technology, including a review of the development of portable GC-MS, as well as a demonstration of the value of this capability using different examples.

In this work, we study the detection of acetylene (C₂H₂), carbon dioxide (CO₂) and water vapor (H₂O) gases in the near-infrared (NIR) range using an on-chip silicon micro-electro-mechanical system (MEMS) Fourier transform infrared (FT-IR) spectrometer in the wavelength range 1300–2500 nm (4000–7692 cm⁻¹). The spectrometer core engine is a scanning Michelson interferometer micro-fabricated using a deep-etching technology producing self-aligned components. The light is free-space propagating in-plane with respect to the silicon chip substrate. The moving mirror of the interferometer is driven by a relatively large stroke electrostatic comb-drive actuator corresponding to about 30 cm⁻¹ resolution. Multi-mode optical fibers are used to connect light between the wideband light source, the interferometer, the 10 cm gas cell, and the optical detector. A wide dynamic range of gas concentration down to 2000 parts per million (ppm) in only 10 cm length gas cell is demonstrated. Extending the wavelength range to the mid-infrared (MIR) range up to 4200 nm (2380 cm⁻¹) is also experimentally demonstrated, for the first time, using a bulk micro-machined on-chip MEMS FT-IR spectrometer. The obtained results open the door for an on-chip optical gas sensor for many applications including environmental sensing and industrial process control in the NIR/MIR spectral ranges.

Wireless data acquisition using smartphones or handhelds offers increased mobility, it provides reduced size and weight, it has low electrical power requirements, and (in some cases) it has an ability to access the internet. Thus, it is well suited for mobile spectrometry applications using miniaturized, field-portable spectrometers, or detectors for chemical analysis in the field (i.e., on-site). There are four main wireless communications standards that can be used for wireless data acquisition, namely ZigBee, Bluetooth, Wi-Fi, and UWB (ultra-wide band). These are briefly reviewed and are evaluated for applicability to data acquisition of transient signals (i.e., time-domain) in the field (i.e., on-site) from a miniaturized, field-portable photomultiplier tube detector and from a photodiode array detector installed in a miniaturized, field-portable fiber optic spectrometer. These are two of the most widely used detectors for optical measurements in the ultraviolet–visible range of the spectrum. A miniaturized, 3D-printed, battery-operated microplasma-on-a-chip was used for generation of transient optical emission signals. Elemental analysis from liquid microsamples, a microplasma, and a handheld or a smartphone will be used as examples. Development and potential applicability of wireless data acquisition of transient optical emission signals for taking part of the lab to the sample types of mobile, field-portable spectrometry applications will be discussed. The examples presented are drawn from past and ongoing work in the authors’ laboratory. A handheld or a smartphone were used as the mobile computing devices of choice.

Quick and presumptive identification of seized drug samples without destroying evidence is necessary for law enforcement officials to control the trafficking and abuse of drugs. This work reports an automated screening method to detect the presence of cocaine in seized samples using portable Fourier transform infrared (FT-IR) spectrometers. The method is based on the identification of well-defined characteristic vibrational frequencies related to the functional group of the cocaine molecule and is fully automated through the use of an expert system. Traditionally, analysts look for key functional group bands in the infrared spectra and characterization of the molecules present is dependent on user interpretation. This implies the need for user expertise, especially in samples that likely are mixtures. As such, this approach is biased and also not suitable for non-experts. The method proposed in this work uses the well-established “center of gravity” peak picking mathematical algorithm and combines it with the conditional reporting feature in MicroLab software to provide an automated method that can be successfully employed by users with varied experience levels. The method reports the confidence level of cocaine present only when a certain number of cocaine related peaks are identified by the automated method. Unlike library search and chemometric methods that are dependent on the library database or the training set samples used to build the calibration model, the proposed method is relatively independent of adulterants and diluents present in the seized mixture. This automated method in combination with a portable FT-IR spectrometer provides law enforcement officials, criminal investigators, or forensic experts a quick field-based prescreening capability for the presence of cocaine in seized drug samples.

Concrete is by far the world’s most common construction material. Modern concrete is a mixture of industrial pozzolanic cement formulations and aggregate fillers. The former acts as the glue or binder in the final inorganic composite; however, when exposed to a fire the degree of concrete damage is often difficult to evaluate nondestructively. Fourier transform infrared (FT-IR) spectroscopy through techniques such as transmission, attenuated total reflectance, and diffuse reflectance have been rarely used to evaluate thermally damaged concrete. In this paper, we report on a study assessing the thermal damage of concrete via the use of a nondestructive handheld FT-IR with a diffuse reflectance sample interface. In situ measurements can be made on actual damaged areas, without the need for sample preparation. Separate multivariate models were developed to determine the equivalent maximal temperature endured for three common industrial concrete formulations. The concrete mixtures were successfully modeled displaying high predictive power as well as good specificity. This has potential uses in forensic investigation and remediation services particularly for fires in buildings.
