Human Gene Therapy

Baculovirus vectors recently have been shown to be capable of efficient transduction of human hepatoma cells and primary hepatocytes in culture. This paper describes the generation of a novel recombinant baculovirus (VGZ3) in which the vesicular stomatitis virus glycoprotein G (VSV G) is present in the viral envelope. The gene encoding VSV G was inserted into the baculovirus genome under the control of the polyhedrin promoter such that it was expressed at very high levels in infected insect cells but not in mammalian cells. Expression of the lacZ reporter gene was driven by a promoter that is functional in mammalian cells (the Rous sarcoma virus long terminal repeat). We show by Western analysis that VSV G protein was present in purified baculovirus preparations. A VSV G monoclonal antibody blocked transduction of mammalian cells by VGZ3. This virus was morphologically distinct from baculovirus lacking VSV G, with virions adopting an oval rather than rod-shaped morphology. VGZ3 transduced human hepatoma cells in vitro at an efficiency roughly 10-fold greater than baculovirus lacking VSV G (the virus Z4). VGZ3 was also capable of transducing cell lines that could not be transduced efficiently by Z4. We provide evidence that VSV G protein may enhance transduction by increasing the efficiency of escape of baculovirus from intracellular vesicles rather than by increasing cell binding or uptake of the virus. The possible use of this and related baculoviruses in gene therapy is discussed.

One of the major limitations to current gene therapy is the low-level and transient vector gene expression due to poorly defined mechanisms, possibly including promoter attenuation or extinction. Because the application of gene therapy vectors in vivo induces cytokine production through specific or nonspecific immune responses, we hypothesized that cytokine-mediated signals may alter vector gene expression. Our data indicate that the cytokines interferon-γ (IFN-γ) and tumor necrosis factor-α (TNF-α) inhibit transgene expression from certain widely used viral promoters/enhancers (cytomegalovirus, Rous sarcoma virus, simian virus 40, Moloney murine leukemia virus long terminal repeat) delivered by adenoviral, retroviral or plasmid vectors in vitro. A constitutive cellular promoter (β-actin) is less sensitive to these cytokine effects. Inhibition is at the mRNA level and cytokines do not cause vector DNA degradation, inhibit total cellular protein synthesis, or kill infected/transfected cells. Administration of neutralizing anti-IFN-γ monoclonal antibody results in enhanced transgene expression in vivo. Thus, standard gene therapy vectors in current use may be improved by altering cytokine-responsive regulatory elements. Determination of the mechanisms involved in cytokine-regulated vector gene expression may improve the understanding of the cellular disposition of vectors for gene transfer and gene therapy.

Retroviral vectors are efficient tools for gene transfer studies. Their major advantage is that they can permanently integrate the transgene into the target cell's genome. However, because of the compulsory nuclear expression phase of their life cycle, it can be difficult for retroviruses to carry complex expression cassettes. In a attempt to mimic the structural features of most eukaryotic genes and obtain a potentially self-amplifying system for retrovirus production, we tested the feasibility of Semliki Forest virus (SFV) expression to mediate cytoplasmic synthesis of retrovirus vector RNA. An equivalent of a retrovirus virion RNA (retrovirus vector cassette, RVC) was cloned under the SFV 26S promoter, and full-length chimeric SFV-RVC RNA was produced in vitro. This RNA was introduced into retrovirus packaging cells, either via electroporation or transduction in SFV virions, and supernatants were analyzed for the presence of biologically active retroviruses. We demonstrate that this strategy can be used for cytoplasmic retrovirus production. The resulting viral particles are fully functional; they can transduce target cells, undergo reverse transcription, and integrate into genomic DNA. We also demonstrate that the SFV virion-based RVC delivery into packaging cells can yield high transient titers, in this case more than 10⁵ G418^R cfu/ml. This study shows that a simple, one-plasmid, heterologous viral RNA production system can be used to create functional retroviral RNA outside the cell nucleus.

The identification of transgenes with antitumor activity is critical to the development of gene therapy of cancer. Retrovirus-mediated transfer of the Escherichia coli gpt gene into rat C6 glioma cells without subsequent selection still inhibited the proliferation of this mixed polyclonal population upon addition of the prodrug, 6-thioxanthine, with an ID₅₀ of 4.1 μM, whereas parental C6 cells were not affected at a concentration of 500 μM. In a time-course assay, effects of the prodrug on the mixed polyclonal cell proliferation required at least 10 days of exposure. In mixed co-cultures, a bystander effect was not present over the first 4 days of prodrug exposure, but required trypsinization of the co-cultures and replating at lower densities. This “modified” bystander assay thus revealed a 50% decrease in C6 cell proliferation, even when the initial ratio of gpt-expressing to parental C6 cells was as low as 1:19. In a nude mouse model of subcutaneous tumors, co-grafts of C6 glioma and gpt-retrovirus producer cells displayed retarded growth upon exposure to 6-thioxanthine (6-TX). In a nude mouse model of intracerebral tumors, grafting of the gpt-retrovirus producer cells leads to an 80% reduction in intracerebral tumor volumes after 6-TX treatment. This reduction results in a 28% increase in the mean time of survival of animals that harbor intracerebral tumors (p < 0.0005). These antitumor effects indicate that the gpt/6-TX enzyme/prodrug pair is a promising alternative to the thymidine kinase gene and ganciclovir combination in the gene therapy of cancer.

A second-generation replication-conditional herpes simplex virus type 1 (HSV) vector defective for both ribonucleotide reductase (RR) and the neurovirulence factor γ34.5 was generated and tested for therapeutic safety and efficiency in two different experimental brain tumor models. In culture, cytotoxic activity of this double mutant HSV vector, MGH-1, for 9L gliosarcoma cells was similar to that of the HSV mutant, R3616, which is defective only for γ34.5, but was significantly weaker than that of the HSV mutant hrR3, which is defective only for RR. The diminished tumoricidal effect of the γ34.5 mutants could be accounted for by their reduced ability to replicate in 9L cells. The MGH-1 vector did not achieve significant prolongation of survival in vivo in the syngeneic 9L rat gliosarcoma model for either single brain tumor focus or multiple intracerebral and leptomeningeal tumors, when the vector was applied intratumorally or intrathecally, respectively, and with or without subsequent ganciclovir (GCV) treatment. In identical 9L brain tumor models with single and multiple foci, application of hrR3 with or without GCV was previously shown to result in marked long-term survival. Contrary to the findings with intrathecal injection of hrR3, no vector-related mortality was observed in any animals treated with MGH-1. Thus, in these rat brain tumor models, the double mutant, replication-conditional HSV vector MGH-1 showed a higher therapeutic safety than the RR-minus vector, hrR3, but had clearly decreased therapeutic efficiency compared to hrR3. The development of new HSV vectors for brain tumor gene therapy will require a balance between maximizing therapeutic efficacy and minimizing toxicity to the brain. Standardized application in brain tumor models as presented here will help to screen new HSV vectors for these requirements.

Retroviral transduction of antifolate-resistant variants of human dihydrofolate reductase (hDHFR) into cells can increase their resistance to the cytotoxic effects of these drugs. We evaluated the ability of wild-type hDHFR and 20 mutant enzymes (13 with single-amino acid substitutions, 7 with two substitutions) to prevent growth inhibition in antifolate-treated CCRF-CEM cells. The wild-type enzyme and all of the variants significantly protected transduced cells from trimetrexate (TMTX)-induced growth inhibition. However, only half of the variants conferred more protection than does the wild-type enzyme. For the variants tested, the observed protective effect was higher for TMTX than for methotrexate (≤7.5-fold increased resistance), piritrexim (≤16-fold), and edatrexate (negligible). Transduction of the variants L22Y-F31S and L22Y-F31R led to the greatest protection against TMTX (∼200-fold). Protection from loss of cell viability was similar to protection from growth inhibition. The protection associated with a particular mutant hDHFR did not result from the level of expression: Efficient protection resulted from low affinity of the variant for antifolates, reasonable catalytic activity, and good thermal stability. Clones isolated from a polyclonal population of transduced cells varied by as much as 30-fold in their resistance to TMTX, the resistance differences depending on hDHFR expression levels.

Successful retroviral gene transfer into human hematopoietic stem cells was demonstrated in preliminary clinical trials at low efficiency. We have shown previously that gene transfer into committed hematopoietic progenitor cells is more efficient using a gibbon ape leukemia virus (GALV)-pseudotyped retroviral vector instead of an amphotropic retroviral vector. Here, we have conducted a systematic study of human hematopoietic progenitor cells after extended transduction with a GALV-pseudotyped retroviral vector. CD34⁺/CD38^lo Cells were transduced for 5 days and reselected according to phenotype after culture and analyzed for cell cycle status, long-term culture-initiating cell (LTC-IC) activity, and gene transfer. Reselection of rare, very primitive progenitor cells was successful. Equal to fresh CD34⁺/CD38^lo cells, >90% of reselected CD34⁺/CD38^locells were in G₀/G₁. CD34⁺/CD38^lo reselection enriched for LTC-IC (10-fold), as compared to freshly isolated CD34⁺/CD38^lo cells with excellent specificity (82.7% of total LTC-IC were recovered in the reselected CD34⁺/CD38^lo population) and recovery (62% of initial LTC-IC number in CD34⁺/CD38^lo cells were recovered in the reselected fraction after transduction). Gene transfer into primitive progenitor cells was efficient with 50.5% G418-resistant LTC-IC colonies and more than 40 copies of vector provirus detectable per 100 nuclei of CD34⁺/CD38^lo cells. To our knowledge, this is the first systematic analysis of phenotype, function, and cell cycle demonstrating retroviral gene transfer into rare, very primitive human hematopoietic progenitor cells. The chosen strategy should be of considerable value for analyzing and improving gene therapy of the hematopoietic system.

The herpes simplex virus-thymidine kinase/ganciclovir (HSVtk/GCV) system produces both direct and immune-mediated tumor cell killing. Here, we compare the efficacy of HSVtk/GCV with cytokines, alone and in combination, on the tumorigenicity and immunogenicity of B16 cells. With respect to single gene modifications, only HSVtk/GCV, or high-level interleukin-2 (IL-2) secretion, completely prevented tumor growth, whereas granulocyte-macrophage colony-stimulating factor (GM-CSF) generated the best levels of long-term systemic protection. To augment both local killing and immune activation, we constructed bicistronic constructs that express HSVtk and a cytokine within the same cell. Co-expression of HSVtk with IL-2 or GM-CSF enhanced the local antitumor activity of any gene alone. In a tumor-prevention model, HSVtk killing, in an environment preprimed with GM-CSF, generated the best long-term immune protection. However, in a short-term therapy model, continued IL-2 expression was most effective against 3-day established tumors. This probably reflects differences in the activities of IL-2 and GM-CSF in generating short-term, nonspecific immune stimulation compared to long-term immunological memory, respectively. As a prelude to in vivo delivery experiments, we also demonstrated that these bicistronic cassettes can be packaged normally into retroviral (5 × 10⁵ virus/ml from pooled populations) and adenoviral vectors (5 × 10⁹ virus/ml) and function as predicted within virally infected cells. This family of bicistronic vectors can be used to stimulate synergy between suicide and cytokine genes, overcomes the problems of delivering two genes on separate vectors, and should allow easier preparation of vectors for the delivery of multiple genes to patients' tumor cells.

Human adenovirus (HAV) serotypes 2 and 5 are commonly used as vector backbones for adenovirus-mediated gene transfer. However, HAVs were chosen as a backbone for the vectors for historical reasons and have a number of significant disadvantages when used as a shuttle for gene transfer in humans. As an initial trial to circumvent some of the shortcomings of HAV vectors, we have produced an E1-deleted canine adenovirus type 2 (CAV-2) vector for gene transfer. Initially, we demonstrated that CAV-2 undergoes an abortive viral cycle in a wide range of human-derived cell lines. Second, we assayed human sera containing HAV-5 neutralizing antibodies for their ability to inhibit CAV-2-induced plaques on permissive cells. In the cohort tested, our data demonstrate that the humoral response directed against HAV-5 does not inhibit CAV-2 plaque formation in the majority of cases. Canine cell lines expressing the E1 region of CAV-2 were generated and characterized. A recombinant CAV vector (CAVRSV βgal) deleted in the E1 region and harboring lacZ was constructed. We show that CAVRSV βgal is able to transduce and direct expression of the transgene in vitro in a variety of mammalian cells, most notably primary human-derived cells. In addition, gene transfer is demonstrated in vivo using chick embryos.

Efficient expression of therapeutic genes in irradiated tumor cells would facilitate the conversion of a malignant tumor nodule into a cancer vaccine in situ. We reported previously that transgene expression from an adenoviral vector could be markedly enhanced by treating transduced tumor cells with butyrate. In this study, we demonstrated that a similar butyrate effect could be achieved in irradiated tumor cells. In addition, irradiating cells at doses of 2–40 Gy prior to transduction could also amplify recombinant adenoviral transgene products in a cell-type-specific manner. This suggests that adenovirus-mediated gene therapy, radiation therapy, and butyrate-mediated cancer therapy may potentially be formulated into one synergistic protocol for cancer treatment.

Gyrate atrophy is a progressive blindness associated with deficiency of ornithine aminotransferase (OAT). The strategy of using an autologous keratinocyte graft, modified to express high levels of OAT as an ornithine-catabolizing skin-based enzyme sink, is investigated. Two OAT-containing retroviral vectors were constructed with or without a resistance gene. When packaged in a retroviral vector particle generated with the gibbon ape leukemia (GALV) virus envelope (PG13), these vectors could readily transduce >50% of target keratinocytes. The transduced keratinocytes in culture expressed up to 75-fold more OAT than normal control keratinocytes and these gene-modified cells extracted [¹⁴C]ornithine more efficiently than controls. The vector prepared without neo transduced cells more efficiently and led to higher levels of OAT expression than the neo-containing vector. Ornithine catabolism was maintained at high levels when the transduced patient keratinocytes were differentiated in vitro as a multilayered cutaneous organoid.

Today, nonviral gene transfer vectors attract more attention as a therapeutic strategy for human diseases, because viral vectors such as adenoviral and herpes viral vectors have been proven to have problems, especially in immunogenicity and cytotoxicity. However, the main limitation of nonviral vectors has been low efficiency of gene expression. To overcome this defect, we have developed a new class of transfection vehicles, HVJ–cationic liposomes. The use of the cationic lipid DC-cholesterol facilitates efficient entrapment of negatively charged macromolecules (plasmid DNA, oligodeoxynucleotides, and proteins) and efficient interaction with negatively charged plasma membranes of cultured cells in vitro. Moreover, the fusogenic envelope proteins of hemagglutinating virus of Japan (HVJ) enhance delivery of the enclosed materials into cells. Using firefly luciferase as a marker, we optimized the liposome formula. As a result, we have succeeded in obtaining 100–800 times higher gene expression in vitro than with the conventional HVJ–anionic liposomes. However, in vivo gene transfer experiments have revealed that the use of cationic lipid instead of anionic lipid reduced the transgene expression dramatically in organs such as muscle and liver. We further discovered that the use of anionic liposomes with a viral-mimic king lipid composition increased transfection efficiency by several times in vivo. We conclude that the alternative usage of transfer vectors, for example, HVJ–anionic liposomes for in vivo delivery to extended areas of organs and HVJ–cationic liposomes for in vitro delivery (and possibly for in vivo delivery to a restricted area of organs), is of significance.
