Interventional Neuroradiology

Anterior inferior cerebellar artery (AICA) aneurysms are rare and published clinical experience with these aneurysms is limited.

The objective of this article is to report angiographic characteristics and results associated with premeatal, meatal and postmeatal segments, surgical and endovascular therapies.

A literature review was performed through PubMed using “anterior inferior cerebellar artery aneurysm” through January 2016. Clinical data, angiograms, management techniques, and patient outcomes were reviewed for 47 collected cases in 30 previous reports.

Of these aneurysms, 21 (44.7%) were associated with meatal segment, 10 (21.3%) were postmeatal and 16 (34.0%) were premeatal. Patients with meatal aneurysms are more likely to present with subarachnoid hemorrhage and hearing loss and facial palsy (77.8%). Patient outcomes of meatal aneurysms presented with more neuropathies (51.7%) and cerebellar symptoms (14.3%) (p = 0.049). Four cases of meatal aneurysm with preoperative cranial nerve deficits (two VII and two VIII) showed improvement after surgery. Endovascular treatment achieved outcomes similar to surgical treatment (p = 0.327).

AICA aneurysms have a predilection for meatal segment. Patients with meatal aneurysms are more likely to present with subarachnoid hemorrhage and hearing loss and facial palsy. Patient outcomes of meatal aneurysms presented with more neuropathies and cerebellar symptoms. Endovascular treatment achieved outcomes similar to surgical treatment.

The objective of this article is to compare the results of endovascular treatment of ruptured middle cerebral artery (MCA) aneurysms with ruptured aneurysms of other anatomic locations.

Fifty consecutive ruptured aneurysms of the MCA and 209 aneurysms at other anatomical locations were selected retrospectively. We compared epidemiological, clinical and radiological variables, prognosis and complications.

The MCA aneurysms had a greater size and a poor dome/neck ratio. There were no significant differences in endovascular technique complications, occlusion rate or rebleeding between the two groups (p > 0.1). There were no significant differences in the mortality and number of dependent patients after one month.

The endovascular treatment of ruptured MCA aneurysms without hematoma is as safe and effective as other aneurysm localizations. Complication rates, occlusion rates and rebleeding of ruptured MCA aneurysms are comparable to other locations.

Penumbra SMART coils differ from traditional microcoils used for endovascular coil embolization of intracranial aneurysms (IAs) in that they (1) become progressively softer from their distal to proximal end, rather than being of uniform stiffness, (2) have a tight conformational structure, and (3) have a more robust stretch-resistance platform. These properties aid in preventing microcatheter prolapse and coil herniation during coil deployment and in filling small pockets of the aneurysm sac.

To determine the safety and efficacy of this device, the records of 17 consecutive patients with IAs treated with SMART coils were retrospectively analyzed.

Thirteen female and four male patients were identified. Eleven patients presented with subarachnoid hemorrhage, four had recurrent aneurysms, and two had incidentally discovered aneurysms. Twelve aneurysms (two of which were recurrent) were treated with stand-alone coiling, three were treated with stent-assisted coiling, and two with flow diversion with adjuvant coiling. Microcatheter prolapse occurred in one case of a recurrent aneurysm, due to mechanical limitations imposed by a stent placed during prior coiling. Raymond-Roy Occlusion Classification (RROC) I or II occlusion was achieved in 12 aneurysms, including all 10 undergoing primary stand-alone coiling. Of the five RROC III occlusions, two were expected given treatment with flow diversion, while the other three occurred in complex, recurrent aneurysms. One patient suffered a thromboembolic complication of unclear clinical significance.

The Penumbra SMART coil is a safe and effective device for the endovascular treatment of IAs. Follow-up studies are required to establish long-term results.

Recent studies demonstrated the capacity of stents to modify cerebral vascular anatomy. This study evaluates arterial anatomy deformation after Leo stent placement according to the stenting site and the impact on the immediate postoperative and six-month degree of aneurysmal occlusion.

A total of 102 stents were placed against the neck of aneurysms situated in the anterior cerebral circulation. Aneurysms were classified into two groups: The first was called the distal group (n = 62) and comprised aneurysms situated in the middle cerebral and anterior communicating arteries and the second was called the proximal group (n = 40) and comprised aneurysms in other sites. The stented arterial segment was classified as deformed or non-deformed by blinded review and superimposition of anonymised films before and after stenting. The degree of occlusion was determined immediately postoperatively and at six months.

Significantly, anatomical deformity was observed in the distal group compared to the proximal group (85% vs 28%). No significant difference was observed between the two groups in terms of postoperative degree of occlusion. At six months, a significant difference was observed between the two groups: three recurrences in the distal group vs 10 recurrences in the proximal group. Two (3%) recurrences were observed in the deformed group vs 11 (31%) recurrences in the non-deformed group.

Arterial deformity induced by stenting is even more marked for distal aneurysms. The recurrence rate is smaller when the stent placement results in an arterial anatomical change. The percentage of recurrence is lower when anatomy was amended by stent implantation.

Distal landing zone accuracy is critical in some intracranial aneurysms treated with the Pipeline Embolization Device (PED), and delayed opening of the distal end of the device can complicate the procedure. Here, we report a technical nuance that facilitates accurate placement of the distal end of the PED by ex-vivo, pre-implantation release of the PED Flex polytetrafluoroethylene (PTFE) sleeves.

The PED Flex is partially pushed out of the introducer sheath ex-vivo, pre-implantation until the distal PED opens entirely and the PTFE sleeves are located distal to the device. Without inverting the PTFE sleeves, the PED is carefully pulled back into the introducer sheath placing the PTFE sleeves inside the device. The PED is loaded into the microcatheter and advanced toward the site of implantation. When the PED is initially deployed and pushed out of the microcatheter, it opens immediately and provides an anchor for the remainder of the deployment process. We present a video (supplementary material) that illustrates the technique along with an illustrative case.

Ex-vivo, pre-implantation release of the PTFE sleeves is an option in aneurysm treatment where distal landing accuracy is critical. Even without the protection of the PTFE sleeves, our clinical observation shows that the PED can be advanced safely through the microcatheter in selected cases.

Flow-diverter stents (FDS) are new devices for the endovascular treatment of intracranial aneurysms (IAs) promoting progressive aneurysmal thrombosis. To date, the delay of aneurysmal exclusion remains unclear. We evaluated the correlation between angiographic changes in the first 24 hours and 12-month occlusion in aneurysms treated with FDS.

We retrospectively analyzed the intra-aneurysmal flow by evaluating the in-flow and out-flow delays on preoperative, immediate postoperative, 24-hour and 12-month follow-up angiography. Dichotomy of in-flow and out-flow within the aneurysm was considered as the time of contrast filling and time of contrast washing relatively to the parent artery. The delay times were compared and correlated with the therapeutic success of FDS at 12 months of follow-up.

Out of 14 treated IAs, in 13 consecutive patients, n = 10 (71%) aneurysms showed complete occlusion at 12 months. Between immediate postoperative and 24-hour control, 10 aneurysms (71%) demonstrated in-flow modification, with eight increasing, two decreasing and four having no change. There were no statistical differences in therapeutic success in relation to the different flow-related profiles of intra-aneurysmal flux.

Out-flow modifications were found in 11 aneurysms (79%) between immediate postoperative and 24-hour control, with five increasing, six decreasing and three having no change. Similar to the in-flow changes, there were no statistical differences in therapeutic success relative to the flow-related profiles.

Early angiographic changes after FDS placement are very frequent, but are not correlated with the 12-month technical success of flow-diversion techniques.

Single-volume reconstruction of three-dimensional (3D) digital subtraction angiography (DSA) can be effectively used for aneurysm assessment and planning of endovascular embolization. Unfortunately, post-embolization follow-up angiographic images can be obscured by artifact. The dual-volume reconstruction technique was developed in order to reduce artifact and enhance the visualization of the aneurysm, the parent vessel and side branches, and endovascular devices. The purpose of this study was to compare the reliability of dual- vs single-volume reconstruction of 3D DSA in evaluation of follow-up images after endovascular embolization of intracranial aneurysms.

Four cerebrovascular neurosurgeons independently and blindly reviewed 20 randomly selected dual-and single-volume reconstructions of 3D DSAs demonstrating cerebral aneurysms treated with primary coil embolization, stent-assisted coil embolization, or Pipeline embolization. Five images were repeated for each modality (single and dual volume) in order to assess intra-rater reliability. The intraclass correlation coefficient was calculated as a measure of the overall inter-rater agreement. Cohen’s kappa value was used to assess repeat measurement consistency for each rater.

Overall inter-rater agreement using dual- and single-volume reconstruction was 0.81 and 0.75, respectively. Dual-volume reconstruction resulted in superior agreement in assessing location, occlusion status, position of aneurysm recanalization or residual, status of nearby branches, presence of coil migration and presence of intravascular devices (stent or Pipeline).

Three-dimensional reconstruction is an important complementary imaging technique in evaluating the angioarchitecture of aneurysms and recanalization after endovascular embolization. Dual-volume reconstruction imaging was associated with superior inter- and intra-rater reliability.

Endovascular coil embolization of cerebral aneurysms is an effective treatment for the prevention of aneurysm rebleeding after subarachnoid hemorrhage. It is also often used in unruptured aneurysms, but it is associated with aneurysm remnants and recurrences in up to 20%–33% of patients. We hypothesized that better aneurysm occlusion rates can be achieved with coils of larger caliber.

The Does Embolization with Larger coils lead to better Treatment of Aneurysms (DELTA) trial is an investigator-initiated, multicenter, prospective, randomized, controlled clinical trial. To test the hypothesis that 15-caliber coiling systems are superior to 10-caliber coils, 564 patients with aneurysms measuring 4–12 mm will be randomized 1:1 to embolization with either 10-caliber coils exclusively (control group) or the highest safely achievable proportion of 15-caliber coils (intervention group). The primary efficacy endpoint of the trial is the occurrence of a major recurrence or a residual aneurysm at one year. A pilot phase of 165 patients will be conducted to verify feasibility of the coiling strategy, compliance to treatment allocation, safety of a 15-caliber platinum coil embolization strategy, recruitment rates, and the capacity to improve packing density.

The DELTA trial will test the hypothesis that the use of coils of larger caliber can improve angiographic results of endovascular coiling.

The purpose of this study is to demonstrate our experience in endovascular reconstruction of carotid dissections using the Wingspan Stent System™ (Boston Scientific, Natick, MA, USA), a device we use because of its high radial force and its navigation in extreme curves.

We treated 11 consecutive patients with acute ischemic stroke due to carotid dissection with the Wingspan stent, in the cervical carotid artery.

Functional evaluation revealed that 10 of the 11 patients were independent at 3 months post surgery and that the 11 stents used were found to be patent at the 6-month follow-up digital subtraction angiography (DSA).

The Wingspan stent is an alternative to classic carotid stents and flow diverters for the treatment of cervical internal carotid artery (ICA) dissection associated with ectasias or large loops. The device remains patent over the long term and it is not associated with arterial wall complications.

The purpose of this article is to present a case series of transarterial venous sinus occlusion for dural arteriovenous fistulas (DAVFs) of the transverse and sigmoid sinuses.

From 2006 to 2012, 11 patients with DAVF of the transverse and sigmoid sinuses were treated with transarterial closure of the affected venous sinus using ethylene vinyl alcohol copolymer (ONYX). The consecutive retrospective cohort included six female and five male patients with an age range of 30–79. Patients presented with stroke, intracranial hemorrhage, seizure, headache, focal neurologic deficit or cognitive change. Lesions were categorized as Cognard II a + b (n = 5) or Cognard II b (n = 6). Four of this latter group consisted of isolated sinus segments. Selection criteria for dural sinus occlusion included direct multi-hole fistulas involving a broad surface in length or circumference of the sinus wall. External carotid artery (ECA) branches were directly embolized when considered safe. High-risk arterial supply from ICA, PICA, AICA or ECA cranial nerve branches were closed via retrograde approach during sinus occlusion.

DAVF closure was accomplished in all 11 patients with a total of 17 embolization procedures using ONYX. High-risk arterial collaterals were closed via artery-artery or artery-sinus-artery embolization. The vein of Labbe was spared in the four cases with initial antegrade flow. No neurologic complications occurred, and DAVF closures were durable on three-month angiography.

Transarterial closure of the transverse and sigmoid sinuses.
