Innovations: Technology and Techniques in Cardiothoracic and Vascular Surgery

Due to the increase in new Interventional cardiovascular technologies, traditional lines of division between the interventional and surgical aspects are expected to blur, with these procedures modified and adopted into cardiovascular surgical practice. This proposal introduces new concepts and visions for such new devices and procedures.

I-Precision Planning

II-Examples of Proposed Devices

III-Examples of Proposed Procedures

Over the past few years there has been a growing sense of anxiety about new interventional devices in the cardiovascular surgical community. As physicians, our main task is to formulate simpler, more effective and safer solutions to clinical problems; and as surgeons, we “devise mechanical solutions to clinical problems.”

Nowadays, there is an urgent need for the cardiovascular surgical community to rediscover and reinvent itself. We should see these new innovations as exciting new ideas and tools that we can “modify, simplify and apply” to revitalize our own practice.

Due to the increase in new Interventional cardiovascular technologies, traditional lines of division between the interventional and surgical aspects are expected to blur, with these procedures modified and adopted into cardiovascular surgical practice. This proposal introduces new concepts and visions for such new devices and procedures.

I-Precision Planning

II-Examples of Proposed Devices

III-Examples of Proposed Procedures

Over the past few years there has been a growing sense of anxiety about new interventional devices in the cardiovascular surgical community. As physicians, our main task is to formulate simpler, more effective and safer solutions to clinical problems; and as surgeons, we “devise mechanical solutions to clinical problems.”

Nowadays, there is an urgent need for the cardiovascular surgical community to rediscover and reinvent itself. We should see these new innovations as exciting new ideas and tools that we can “modify, simplify and apply” to revitalize our own practice.

To validate the safety and applicability of a previously unreported innovative technique: bipolar epicardial radiofrequency pulmonary vein ablation for the treatment of atrial fibrillation (AF) in conjunction with off-pump coronary artery bypass surgery.

After the completion of off-pump coronary artery bypass grafting (OPCAB) via sternotomy, patients underwent epicardial pulmonary vein ablation using a bipolar radiofrequency clamp placed on the left atrial cuff. The left atrial appendage was removed or excluded in all patients.

Fifteen patients (aged 59–81 years) were treated and reviewed. An average of 2.8 ± 1 grafts were performed per patient; all patients received left internal mammary artery grafts. All sets of pulmonary veins were encircled successfully and ablated. Four patients had additional lesions placed. No patient had pulmonary vein injury. There were no reoperations for bleeding and no mortality. Preoperatively, AF was continuous in 4 patients and intermittent in 11; 10 patients were taking Coumadin preoperatively and 11 were taking antiarrhythmic drugs (AAD). At the follow-up evaluation (7.6 ± 4.4 months; range 1–16 months), 12 patients (80%) are in sinus rhythm (100% in the intermittent AF group, 25% in the continuous AF group); Coumadin has been discontinued in 5 of 10 patients (50% reduction) and AAD have been discontinued in 7 of 11 patients (74% reduction).

Bipolar radiofrequency epicardial pulmonary vein ablation can be safely and reproducibly used for the treatment of AF in conjunction with OPCAB. Patients with intermittent AF should be strongly considered for adjunctive treatment at the time of OPCAB.

To validate the safety and applicability of a previously unreported innovative technique: bipolar epicardial radiofrequency pulmonary vein ablation for the treatment of atrial fibrillation (AF) in conjunction with off-pump coronary artery bypass surgery.

After the completion of off-pump coronary artery bypass grafting (OPCAB) via sternotomy, patients underwent epicardial pulmonary vein ablation using a bipolar radiofrequency clamp placed on the left atrial cuff. The left atrial appendage was removed or excluded in all patients.

Fifteen patients (aged 59–81 years) were treated and reviewed. An average of 2.8 ± 1 grafts were performed per patient; all patients received left internal mammary artery grafts. All sets of pulmonary veins were encircled successfully and ablated. Four patients had additional lesions placed. No patient had pulmonary vein injury. There were no reoperations for bleeding and no mortality. Preoperatively, AF was continuous in 4 patients and intermittent in 11; 10 patients were taking Coumadin preoperatively and 11 were taking antiarrhythmic drugs (AAD). At the follow-up evaluation (7.6 ± 4.4 months; range 1–16 months), 12 patients (80%) are in sinus rhythm (100% in the intermittent AF group, 25% in the continuous AF group); Coumadin has been discontinued in 5 of 10 patients (50% reduction) and AAD have been discontinued in 7 of 11 patients (74% reduction).

Bipolar radiofrequency epicardial pulmonary vein ablation can be safely and reproducibly used for the treatment of AF in conjunction with OPCAB. Patients with intermittent AF should be strongly considered for adjunctive treatment at the time of OPCAB.

Surgical repair of mitral valve disease and concomitant coronary artery occlusive disease has high operative risk. Myocardial protection for protracted, complicated procedures is seminal to the overall operative outcome; specifically, preservation of left ventricular function.

The authors conducted a retrospective review of 25 patients undergoing combined mitral valve repair/replacement (MVR) and coronary artery bypass surgery (CABG) using the beating-heart technique at the Miller/University of Miami School of Medicine. The CABG was performed without cardiopulmonary bypass support. During the mitral valve surgery the perfusion pressure was maintained at 80–90 mm Hg and the systemic temperature at 35–36°C. The aorta was not cross-clamped.

Twenty-five patients underwent MVR/CABG, including 7 patients with acute myocardial infarction. Preoperative echocardiograms revealed a mean ejection fraction (EF) of 41 ± 4.5%. One patient required a preoperative intraarterial balloon pump. An average of 2.12 ± 0.9 grafts and a total of 10 mitral valve repairs were performed. The average length of stay in the intensive care unit was 14 ± 1.8 days, and average hospitalization time was 23 ± 3. The mean postoperative EF was 41 ± 4.5%. The mortality in this patient group was 12 % (3/25) with a morbidity rate of 52% (13/25).

The data suggest that the technique is safe and reproducible, and that it potentially has a short-term benefit on left ventricular function. Therefore, this particular technique may be efficacious in patients with compromised left ventricular function requiring a combined MVR/CABG.

Surgical repair of mitral valve disease and concomitant coronary artery occlusive disease has high operative risk. Myocardial protection for protracted, complicated procedures is seminal to the overall operative outcome; specifically, preservation of left ventricular function.

The authors conducted a retrospective review of 25 patients undergoing combined mitral valve repair/replacement (MVR) and coronary artery bypass surgery (CABG) using the beating-heart technique at the Miller/University of Miami School of Medicine. The CABG was performed without cardiopulmonary bypass support. During the mitral valve surgery the perfusion pressure was maintained at 80–90 mm Hg and the systemic temperature at 35–36°C. The aorta was not cross-clamped.

Twenty-five patients underwent MVR/CABG, including 7 patients with acute myocardial infarction. Preoperative echocardiograms revealed a mean ejection fraction (EF) of 41 ± 4.5%. One patient required a preoperative intraarterial balloon pump. An average of 2.12 ± 0.9 grafts and a total of 10 mitral valve repairs were performed. The average length of stay in the intensive care unit was 14 ± 1.8 days, and average hospitalization time was 23 ± 3. The mean postoperative EF was 41 ± 4.5%. The mortality in this patient group was 12 % (3/25) with a morbidity rate of 52% (13/25).

The data suggest that the technique is safe and reproducible, and that it potentially has a short-term benefit on left ventricular function. Therefore, this particular technique may be efficacious in patients with compromised left ventricular function requiring a combined MVR/CABG.

Dyskinetic areas of the lateral and inferior left ventricular (LV) wall are frequently encountered in patients with coronary artery disease. In clinical practice, all of the techniques described for the restoration of shape and function of the LV require cardiopulmonary bypass. A new technique of LV external reshaping that aims to obtain a near-normal ventricular conical shape is described. This technique is performed during an off-pump coronary artery bypass graft (CABG) operation. It is used mainly on the inferior and lateral walls of the ventricle, but also on the anterolateral wall when warranted. This technique can be considered an alternative to classic aneurysmectomy in high-risk cases.

All patients underwent total arterial revascularization without aortic manipulation. Intraoperative transesophageal echocardiography was used in all cases to define the dilated akinetic/dyskinetic area. This area was effectively plicated using interrupted mattress sutures reinforced with Teflon felt or pericardial strips. This technique allows near normalization of the geometry of the ventricle and LV end-diastolic volume reduction. In cases of preexisting mitral regurgitation (MR), a reduction of the MR was observed after lateral wall restoration. From September 2002 to April 2005, the external reshaping technique was applied on 56 cases among 949 off-pump CABG cases (5.9%). A detailed transthoracic echocardiogram was obtained preoperatively. The mean ejection fraction of all enrolled patients was 31.2 ± 7%. The location of the plication was: lateral wall in 22, inferior wall in 16, and anterolateral wall in 18. The average number of coronary anastomoses was 2.6. Twelve patients were found to have 2–3 + MR. All patients were followed up during a period of 35 months.

One patient died due to severe right ventricular dysfunction. Seven patients developed atrial fibrillation, and one had ventricular tachycardia. During the follow-up period, we observed a reduction of left ventricular end-diastolic diameter and a parallel augmentation of ejection fraction (mean 42.2 ± 4%). The ventricular cavity's architecture was normalized. Among the 12 patients with MR, an improvement of regurgitation was noted in 10 (from 2–3+ to 1–2+). One patient died during the follow-up period, and 1 patient required reoperation due to persistent severe MR.

The external reshaping of the LV during beating heart surgery is technically feasible, has promising results, and can be performed without major complications.

Dyskinetic areas of the lateral and inferior left ventricular (LV) wall are frequently encountered in patients with coronary artery disease. In clinical practice, all of the techniques described for the restoration of shape and function of the LV require cardiopulmonary bypass. A new technique of LV external reshaping that aims to obtain a near-normal ventricular conical shape is described. This technique is performed during an off-pump coronary artery bypass graft (CABG) operation. It is used mainly on the inferior and lateral walls of the ventricle, but also on the anterolateral wall when warranted. This technique can be considered an alternative to classic aneurysmectomy in high-risk cases.

All patients underwent total arterial revascularization without aortic manipulation. Intraoperative transesophageal echocardiography was used in all cases to define the dilated akinetic/dyskinetic area. This area was effectively plicated using interrupted mattress sutures reinforced with Teflon felt or pericardial strips. This technique allows near normalization of the geometry of the ventricle and LV end-diastolic volume reduction. In cases of preexisting mitral regurgitation (MR), a reduction of the MR was observed after lateral wall restoration. From September 2002 to April 2005, the external reshaping technique was applied on 56 cases among 949 off-pump CABG cases (5.9%). A detailed transthoracic echocardiogram was obtained preoperatively. The mean ejection fraction of all enrolled patients was 31.2 ± 7%. The location of the plication was: lateral wall in 22, inferior wall in 16, and anterolateral wall in 18. The average number of coronary anastomoses was 2.6. Twelve patients were found to have 2–3 + MR. All patients were followed up during a period of 35 months.

One patient died due to severe right ventricular dysfunction. Seven patients developed atrial fibrillation, and one had ventricular tachycardia. During the follow-up period, we observed a reduction of left ventricular end-diastolic diameter and a parallel augmentation of ejection fraction (mean 42.2 ± 4%). The ventricular cavity's architecture was normalized. Among the 12 patients with MR, an improvement of regurgitation was noted in 10 (from 2–3+ to 1–2+). One patient died during the follow-up period, and 1 patient required reoperation due to persistent severe MR.

The external reshaping of the LV during beating heart surgery is technically feasible, has promising results, and can be performed without major complications.

Minimally invasive aortic valve surgery is usually performed through a right parasternal incision or a modification of partial sternotomy. We explored the feasibility of using a videoassisted small right lateral thoracotomy (RLT) to approach the aortic valve.

From August 2003 to December 2004, 12 patients with aortic stenosis (9) or regurgitation (3) underwent an aortic valve replacement through an 8 cm RLT in the 4th intercostal space. There were 4 men and 8 women with a mean age of 61 years (range 30–79 years). Nine mechanical and 3 biologic prostheses were implanted. Endotracheal narcosis was combined with high thoracic epidural anesthesia. Transesophageal echocardiographic monitoring was performed in all cases. Cannulation was done via the right femoral artery and vein and right jugular vein. The video-assisted operation was performed in moderate hypothermia (30°C) and in cardioplegic arrest. Transthoracic aortic clamping was used in all cases.

Mean operation, perfusion, and clamping times were 223 minutes, 132 minutes, and 73 minutes, respectively. There was no mortality. One patient required conversion to sternotomy due to discovery of a calcium fragment entrapped in a mechanical prosthesis. One patient developed a groin seroma that was treated surgically. All patients, except one were extubated in the operative room and transferred to the intermediate care unit after 6 hours; all had an uneventful recovery.

Aortic valve replacement through an RLT is feasible and safe. Operative time, perfusion, and cross-clamping times are only marginally longer than a conventional operation, and recovery is rapid.

Minimally invasive aortic valve surgery is usually performed through a right parasternal incision or a modification of partial sternotomy. We explored the feasibility of using a videoassisted small right lateral thoracotomy (RLT) to approach the aortic valve.

From August 2003 to December 2004, 12 patients with aortic stenosis (9) or regurgitation (3) underwent an aortic valve replacement through an 8 cm RLT in the 4th intercostal space. There were 4 men and 8 women with a mean age of 61 years (range 30–79 years). Nine mechanical and 3 biologic prostheses were implanted. Endotracheal narcosis was combined with high thoracic epidural anesthesia. Transesophageal echocardiographic monitoring was performed in all cases. Cannulation was done via the right femoral artery and vein and right jugular vein. The video-assisted operation was performed in moderate hypothermia (30°C) and in cardioplegic arrest. Transthoracic aortic clamping was used in all cases.

Mean operation, perfusion, and clamping times were 223 minutes, 132 minutes, and 73 minutes, respectively. There was no mortality. One patient required conversion to sternotomy due to discovery of a calcium fragment entrapped in a mechanical prosthesis. One patient developed a groin seroma that was treated surgically. All patients, except one were extubated in the operative room and transferred to the intermediate care unit after 6 hours; all had an uneventful recovery.

Aortic valve replacement through an RLT is feasible and safe. Operative time, perfusion, and cross-clamping times are only marginally longer than a conventional operation, and recovery is rapid.

Most cardiac surgeons routinely perform bicaval venous cannulation for mitral valve operations. We describe the technique and advantage of a single-venous cannulation strategy.

Single venous cannulation with a 29-French small-bore cannula (facilitated by vacuum-assisted venous drainage) yields reliable decompression of the right heart and affords outstanding exposure of the mitral valve.

We recommend and use this technique for all mitral valve operations not requiring opening the right atrium.

Most cardiac surgeons routinely perform bicaval venous cannulation for mitral valve operations. We describe the technique and advantage of a single-venous cannulation strategy.

Single venous cannulation with a 29-French small-bore cannula (facilitated by vacuum-assisted venous drainage) yields reliable decompression of the right heart and affords outstanding exposure of the mitral valve.

We recommend and use this technique for all mitral valve operations not requiring opening the right atrium.

Management of pain in patients with chronic pancreatitis can be frustrating. The authors retrospectively evaluated their experience with video-assisted thoracoscopic surgery (VATS) for pain secondary to chronic pancreatitis.

From September 1999 to August 2004, 16 patients underwent VATS for pain associated with chronic pancreatitis. Data were collected retrospectively.

Eight patients were female and 8 were male. Their ages ranged from 17 to 81 years, with a mean age of 40 years. There were 22 VATS splanchnicectomies performed: 7 right, 10 left, and 5 bilateral. The average operative time was 75 minutes for right VATS splanchnicectomy, 86 minutes for left VATS splanchnicectomy, and 88 minutes for bilateral VATS splanchnicectomies. The average length of stay (LOS) was 2.6 days after right VATS splanchnicectomy, 2.2 days after left VATS splanchnicectomy, and 1 day after bilateral VATS splanchnicectomies. Two cases were nonelective and not included in the determination of LOS. No postoperative complications occurred in any of the patients admitted for elective operations. Postoperative mortality was zero. Complete resolution of pain occurred in 4 patients (25%): 1 right splanchnicectomy, 1 left splanchnicectomy, and 2 bilateral splanchnicectomies. Total pancreatectomy with islet cell transplant was subsequently performed in 5 patients (31%), who improved but then had recurrent pain. Continued chronic pain managed with nonsteroidal antiinflammatory drugs and narcotic analgesics was the result in 7 patients (44%)

Video-assisted thoracoscopic splanchnicectomy surgery may alleviate pain in patients with chronic pancreatitis. It can be performed with minimal morbidity and mortality, and has been safe and useful in the workup, evaluation, and management of pain associated with chronic pancreatitis.

Management of pain in patients with chronic pancreatitis can be frustrating. The authors retrospectively evaluated their experience with video-assisted thoracoscopic surgery (VATS) for pain secondary to chronic pancreatitis.

From September 1999 to August 2004, 16 patients underwent VATS for pain associated with chronic pancreatitis. Data were collected retrospectively.

Eight patients were female and 8 were male. Their ages ranged from 17 to 81 years, with a mean age of 40 years. There were 22 VATS splanchnicectomies performed: 7 right, 10 left, and 5 bilateral. The average operative time was 75 minutes for right VATS splanchnicectomy, 86 minutes for left VATS splanchnicectomy, and 88 minutes for bilateral VATS splanchnicectomies. The average length of stay (LOS) was 2.6 days after right VATS splanchnicectomy, 2.2 days after left VATS splanchnicectomy, and 1 day after bilateral VATS splanchnicectomies. Two cases were nonelective and not included in the determination of LOS. No postoperative complications occurred in any of the patients admitted for elective operations. Postoperative mortality was zero. Complete resolution of pain occurred in 4 patients (25%): 1 right splanchnicectomy, 1 left splanchnicectomy, and 2 bilateral splanchnicectomies. Total pancreatectomy with islet cell transplant was subsequently performed in 5 patients (31%), who improved but then had recurrent pain. Continued chronic pain managed with nonsteroidal antiinflammatory drugs and narcotic analgesics was the result in 7 patients (44%)

Video-assisted thoracoscopic splanchnicectomy surgery may alleviate pain in patients with chronic pancreatitis. It can be performed with minimal morbidity and mortality, and has been safe and useful in the workup, evaluation, and management of pain associated with chronic pancreatitis.
