Gelatin, a degraded collagen, has been widely used as a scaffolding material in tissue engineering applications. In this work, we aimed at the development of in situ, cross-linking, cytocompatible hydrogels by the use of transglutaminase as a cross-linker for potential application in the regeneration of tissues.

Hydrogels were prepared from gelatin of different concentrations and bloom degree (175 (G175) or 300 (G300) bloom gelatin) and cross-linked with various amounts of microbial transglutaminase (mTG) at 37°C. Mechanical properties and cross-linking degree were studied by rheology and swelling experiments. Four hydrogels with different stiffness were selected for studies with embedded human adipose-derived stem cells (hASCs).

Hydrogels were obtained with storage modulus (G’) values between 11 (±1) Pa and 1,800 (±200) Pa with gelation times between 80 (±6) and 450 (±36) seconds. G300 cross-linked gelatin hydrogels displayed higher gel stiffness, lower swelling ratio and gelled more rapidly compared to the hydrogels prepared from G175. Stiffer hydrogels (50 and 200 Pa) showed greater ability to support the proliferation of hASCs than softer ones (11 and 30 Pa). The highest cell proliferation was observed with a hydrogel of 200 Pa modulus.

Overall, transglutaminase cross-linked gelatin hydrogels might be suitable as injectable hydrogels for the engineering of musculoskeletal and other types of connective tissues.

To overcome the shortcomings of pancreas transplantation and insulin injection treatment for type I diabetes, biocompatible materials were used to prepare alginate-chitosan-alginate microcapsules that co-encapsulated bone marrow mesenchymal stem cells and mouse pancreatic β cells to treat diabetic mice.

Blank alginate-chitosan-alginate (ACA) microcapsules and co-microencapsulated cells were prepared using a high-voltage electrostatic method and then characterized using an inverted microscope. Cell viability was evaluated using AO/EB staining. ELISA kit was used to detect insulin secretion. Peri-orbital blood samples were obtained from the mice for blood glucose determination every week for one month.

After 28 days of in vitro culture, the secretion of insulin following co-microencapsulation was higher than that observed for microencapsulated beta-TC-6 cells alone. On the 28^th day after transplantation, the blood glucose level was 6.86 mmol/L in the microencapsulated beta-TC-6 group. On the 14^th day, the blood glucose level was 6.80 mmol/L in the co-microencapsulated BMSC/beta-TC-6 group, which was close to the normal blood glucose level of healthy mice. These results indicated that the efficacy in reducing blood glucose was better in the co-microencapsulated BMSC/beta-TC-6 group.

This primary study indicated that combining microencapsulation technology and co-culture of stem cells and somatic cells shows promise for the treatment of type I diabetes mellitus.

Biodegradable PCL-b-PTMC-b-PCL triblock copolymers based on trimethylene carbonate (TMC) and ε-caprolactone (CL) were prepared and used in the 3D printing of tissue engineering scaffolds. Triblock copolymers of various molecular weights containing equal amounts of TMC and CL were prepared. These block copolymers combine the low glass transition temperature of amorphous PTMC (approximately -20°C) and the semi-crystallinity of PCL (glass transition approximately -60°C and melting temperature approximately 60°C).

PCL-b-PTMC-b-PCL triblock copolymers were synthesized by sequential ring opening polymerization (ROP) of TMC and ε-CL. From these materials, films were prepared by solvent casting and porous structures were prepared by extrusion-based 3D printing.

Films prepared from a polymer with a relatively high molecular weight of 62 kg/mol had a melting temperature of 58°C and showed tough and resilient behavior, with values of the elastic modulus, tensile strength and elongation at break of approximately 120 MPa, 16 MPa and 620%, respectively. Porous structures were prepared by 3D printing. Ethylene carbonate was used as a crystalizable and water-extractable solvent to prepare structures with microporous strands. Solutions, containing 25 wt% of the triblock copolymer, were extruded at 50°C then cooled at different temperatures. Slow cooling at room temperature resulted in pores with widths of 18 ± 6 μm and lengths of 221 ± 77 μm, rapid cooling with dry ice resulted in pores with widths of 13 ± 3 μm and lengths of 58 ± 12 μm. These PCL-b-PTMC-b-PCL triblock copolymers processed into porous structures at relatively low temperatures may find wide application as designed degradable tissue engineering scaffolds.

In this preliminary study we prepared biodegradable triblock copolymers based on 1,3-trimethylene carbonate and ε-caprolactone and assessed their physical characteristics. Furthermore, we evaluated their potential as melt-processable thermoplastic elastomeric biomaterials in 3D printing of tissue engineering scaffolds.

Perfused bioreactors have been demonstrated to be effective in the delivery of nutrients and in the removal of waste products to and from the interior of cell-populated three-dimensional scaffolds. In this paper, a perfused bioreactor hosting a macroporous scaffold provided with a channel is used to investigate transport phenomena and culture parameters on cell growth.

MG63 human osteosarcoma cells were seeded on macroporous poly(ε-caprolactone) scaffolds provided with a channel. The scaffolds were cultured in a perfused bioreactor and in static conditions for 5 days. Cell viability and growth were assessed while the concentration of oxygen, glucose and lactate were measured. An in silico, multiphysics, numerical model was set up to study the fluid dynamics and the mass transport of the nutrients in the perfused bioreactor hosting different scaffold geometries.

The experimental and numerical results indicated that the specific cell metabolic activity in scaffolds cultured under perfusion was 30% greater than scaffolds cultured under static conditions. In addition, the scaffold provided with a channel enabled the shear stress to be controlled, the initial seeding density to be retained, and adequate mass transport and waste removal.

We show that the macroporous scaffold provided with a channel cultured in a macroscale bioreactor can be a robust reference experimental model system to systematically investigate and assess crucial culture parameters. We also show that such an experimental model system can be employed as a simplified “representative unit” to improve the performance of both perfused culture systems and hollow, fiber-integrated scaffolds for large-scale tissue engineering.

Our team previously designed and validated a new bioartificial liver (BAL) called Suppliver based on a Prismaflex^™ device, including fluidized bed bioreactors hosting alginate-encapsulated hepatocytes. To ensure correct fluidization within the bioreactor, the beads need to become heavier with the addition of inert glass microspheres.

In this study, we assessed the impact of this additional component on the bead production process, bed fluidization, mass transfer and the mechanical properties of the beads, as well as cell viability and basic metabolic function.

A concentration of 20 mg (1% v/v) of microspheres for 15–20 million cells per milliliter of alginate solution appears to be the best configuration. The filling ratio for the beads in the bioreactors can reach 60%. Four 250-mL bioreactors represent approximately 15% of the hepatocytes in a liver, which is a reasonable target for extracorporeal liver supply.

Increasing bead density clearly maintained the performances of the fluidized bed with plasma of different compositions, without any risk of release out of the bioreactor. A 1% (v/v)-concentration of microspheres in alginate solution did not result in any alteration of the mechanical or biological behavior. This concentration can thus be applied to the production of large-scale encapsulated biomass for further use of the Suppliver setup in human scale preclinical studies.
