SLAS DISCOVERY: Advancing the Science of Drug Discovery

Many diseases in humans are caused by mutations that decrease the stability of specific proteins or increase their susceptibility to aggregation. Consequently, the availability of high-throughput methods for assessing protein stability and aggregation properties under physiological conditions (e.g., 37 °C) is necessary to analyze physicochemical properties under conditions that are closer to in vivo models. Therefore, the authors have explored the use of isothermal denaturation (ITD) in a 384-well format to evaluate the reproducibility of the method in assessing the stability of proteins at temperatures below the melting temperature and detecting the binding of ligands. Under the conditions tested, the authors were able to assess the stability of citrate synthase and malate dehydrogenase at different constant temperatures and detect the binding of oxaloacetate and nicotinamide adenine dinucleotide to these 2 enzymes, respectively, using the 384-well format. The ITD experiments detected ligand binding to these proteins at about 4 times lower concentration compared with techniques that measure changes in melting temperature. The data show that ITD can be applied to screen libraries of a relatively large number of compounds or detect small stability differences between protein variants. (Journal of Biomolecular Screening 2008:337-342)

The potential for metabolism-related drug-drug interactions by new chemical entities is assessed by monitoring the impact of these compounds on cytochrome P450 (CYP) activity using well-characterized CYP substrates. The conventional gold standard approach for in vitro evaluation of CYP inhibitory potential uses pooled human liver microsomes (HLM) in conjunction with prototypical drug substrates, often quantified by LC-MS/MS. However, fluorescent CYP inhibition assays, which use recombinantly expressed CYPs and fluorogenic probe substrates, have been employed in early drug discovery to provide low-cost, high-throughput assessment of new chemical entities. Despite its greatly enhanced throughput, this approach has been met with mixed success in predicting the data obtained with the conventional gold standard approach (HLM+LC-MS). The authors find that the predictivity of fluorogenic assays for the major CYP isoforms 3A4 and 2D6 may depend on the quality of the test compounds. Although the structurally more optimized marketed drugs yielded acceptable correlations between the fluorogenic and HLM+LC-MS/MS assays for CYPs 3A4, 2D6, and 2C9 (r ² = 0.5-0.7; p < 0.005), preoptimization, early discovery compounds yielded poorer correlations (r ² ≤ 0.2) for 2 of these major isoforms, CYPs 3A4 and 2D6. Potential reasons for the observed differences are discussed. (Journal of Biomolecular Screening 2008;343-353)

Measurement of intracellular calcium release following agonist challenge within cells expressing the relevant membrane protein is a commonly used format to derive structure-activity relationship (SAR) data within a compound profiling assay. The Fluorometric Imaging Plate Reader (FLIPR) has become the gold standard for this purpose. FLIPR traditionally uses cells that are maintained in continuous culture for compound profiling of iterative chemistry campaigns. This supply dictates that assays can only be run on 4 of 5 weekdays, or alternative cell culture machinery is required such that plating can occur remotely at the weekend. The data reported here demonstrate that high-quality compound profiling data can be generated from the use of cryopreserved cells and that these cells can also be plated at various densities to generate equivalent data between 24 and 72 h post-plating. Hence, the authors report a method that allows data generation throughout the week and without the requirement of highly automated cell culture or continuous culture. (Journal of Biomolecular Screening 2008:354-362)

One of the most fundamental challenges in genome-wide RNA interference (RNAi) screens is to glean biological significance from mounds of data, which relies on the development and adoption of appropriate analytic methods and designs for quality control (QC) and hit selection. Currently, a Z-factor-based QC criterion is widely used to evaluate data quality. However, this criterion cannot take into account the fact that different positive controls may have different effect sizes and leads to inconsistent QC results in experiments with 2 or more positive controls with different effect sizes. In this study, based on a recently proposed parameter, strictly standardized mean difference (SSMD), novel QC criteria are constructed for evaluating data quality in genome-wide RNAi screens. Two good features of these novel criteria are: (1) SSMD has both clear original and probability meanings for evaluating the differentiation between positive and negative controls and hence the SSMD-based QC criteria have a solid probabilistic and statistical basis, and (2) these QC criteria obtain consistent QC results for multiple positive controls with different effect sizes. In addition, I propose multiple plate designs and the guidelines for using them in genome-wide RNAi screens. Finally, I provide strategies for using the SSMD-based QC criteria and effective plate design together to improve data quality. The novel SSMD-based QC criteria, effective plate designs, and related guidelines and strategies may greatly help to obtain high quality of data in genome-wide RNAi screens. (Journal of Biomolecular Screening 2008:363-377)

RNA interference (RNAi) not only plays an important role in drug discovery but can also be developed directly into drugs. RNAi high-throughput screening (HTS) biotechnology allows us to conduct genome-wide RNAi research. A central challenge in genome-wide RNAi research is to integrate both experimental and computational approaches to obtain high quality RNAi HTS assays. Based on our daily practice in RNAi HTS experiments, we propose the implementation of 3 experimental and analytic processes to improve the quality of data from RNAi HTS biotechnology: (1) select effective biological controls; (2) adopt appropriate plate designs to display and/or adjust for systematic errors of measurement; and (3) use effective analytic metrics to assess data quality. The applications in 5 real RNAi HTS experiments demonstrate the effectiveness of integrating these processes to improve data quality. Due to the effectiveness in improving data quality in RNAi HTS experiments, the methods and guidelines contained in the 3 experimental and analytic processes are likely to have broad utility in genome-wide RNAi research. (Journal of Biomolecular Screening 2008:378-389)

Chinese materia medica (CMM) is becoming increasingly important in modern health care, with the potential for new or improved clinical protocols and reduction in treatment costs. Conventional approaches to drug discovery are based on knowledge of biological systems and screen phenotypes in the context of a whole organism. It will be valuable to identify the CMM that would induce certain biological responses (such as angiogenesis). The authors have developed a database that they plan to commercialize that contains traditional knowledge of Chinese medicine and pharmacology along with their own experimental data from controlled scientific observations by using the zebrafish as a model of CMM-induced pathology. The database is visualized and functions via the World Wide Web by subscription or license. The authors have also written software for personal digital assistant (PDA) devices that supports multiple users performing screening experiments worldwide. This provides a platform for the study of CMM, and data mining of this resource will help evaluate CMM in the context of experimental observations of biological aberrations. (Journal of Biomolecular Screening 2008:390-395)

Twenty human proteins encode Phox/Bem1p (PB1) domains, which are involved in forming protein heterodimers. MEKK2, MEKK3, and MEK5 are 3 serine-threonine protein kinases that have PB1 domains. MEKK2, MEKK3, and MEK5 are the MAP3Ks and the MAP2K in the ERK5 mitogen-activated protein kinase (MAPK) signaling module. ERK5 is a critical MAPK for both development of the vasculature and vascular homeostasis in the adult, but no other MAPK has been shown to be critical in vascular maintenance in the adult animal. MEKK2 and MEKK3 are the only MAP3Ks shown to physically interact with and activate the MEK5-ERK5 signaling module. Interaction of MEKK2 or MEKK3 with MEK5 is mediated by heterodimerization of the MEKK2 (or MEKK3) PB1 and MEK5 PB1 domains. The authors have developed a homogeneous, time-resolved fluorescence resonance energy transfer (TR-FRET) assay to monitor PB1-PB1 domain heterodimerization. The assay uses a europium-chelate conjugated GST-MEK5 PB1 domain chimera, biotinylated MEKK2 PB1 domain, and streptavidin-Cy5. Interaction of the MEKK2 and MEK5 PB1 domains gives a robust FRET signal (Z′ factor = 0.93), which is completely abrogated by mutation of 2 acidic residues (⁶⁴D⁶⁵E→AA) within the MEK5 PB1 domain that causes loss of stable PB1-PB1 domain interaction. This assay can be used to study the specificity of PB1-PB1 domain interactions and to screen for molecules that can regulate MEKK2/MEKK3-MEK5 interactions. Disruption of PB1 domain interactions represents a novel approach for selectively regulating the ERK5 signaling pathway independent of kinase active site-directed adenosine triphosphate competitive inhibitors. (Journal of Biomolecular Screening 2008:396-405)

Small-molecule inhibitors of HIV integrase (HIV IN) have emerged as a promising new class of antivirals for the treatment of HIV/AIDS. The compounds currently approved or in clinical development specifically target HIV DNA integration and were identified using strand-transfer assays targeting the HIV IN/viral DNA complex. The authors have developed a second biochemical assay for identification of HIV integrase inhibitors, targeting the interaction between HIV IN and the cellular cofactor LEDGF/p75. They developed a luminescent proximity assay (AlphaScreen™) designed to measure the association of the 80-amino-acid integrase binding domain of LEDGF/p75 with the 163-amino-acid catalytic core domain of HIV IN. This assay proved to be quite robust (with a Z′ factor of 0.84 in screening libraries arrayed as orthogonal mixtures) and successfully identified several compounds specific for this protein-protein interaction. (Journal of Biomolecular Screening 2008:406-414)

Inherited deficiency of galactose-1-phosphate uridyltransferase (GALT) can result in a potentially lethal disorder called classic galactosemia. Although the neonatal lethality associated with this disease can be prevented through early diagnosis and a galactose-restricted diet, the lack of effective therapy continues to have consequences: developmental delay, neurological disorders, and premature ovarian failure are common sequelae in childhood and adulthood. Several lines of evidence indicate that an elevated level of galactose-1-phosphate (gal-1-p), the product of galactokinase (GALK), is a major, if not sole, pathogenic mechanism in patients with classic galactosemia. The authors hypothesize that elimination of gal-1-p production by inhibiting GALK will relieve GALT-deficient cells from galactose toxicity. To test this hypothesis, they obtained human GALK using a bacterial expression system. They developed a robust, miniaturized, high-throughput GALK assay (Z′ factor = 0.91) and used this assay to screen against libraries composed of 50,000 chemical compounds with diverse structural scaffolds. They selected 150 compounds that, at an average concentration of 33.3 µM, inhibited GALK activity in vitro more than 86.5% and with a reproducibility score of at least 0.7 for a confirmatory screen under identical experimental conditions. Of these 150 compounds, 34 were chosen for further characterization. Preliminary results indicated that these 34 compounds have potential to serve as leads to the development of more effective therapy of classic galactosemia. ( Journal of Biomolecular Screening 2008:415-423)

A recently developed nanotechnology, the Integral Molecular lipoparticle, provides an essentially soluble cell-free system in which G-protein-coupled receptors (GPCRs) in their native conformations are concentrated within virus-like particles. As a result, the lipoparticle provides a means to overcome 2 common obstacles to the development of homogeneous, nonradioactive GPCR ligand-binding assays: membrane protein solubilization and low receptor density. The work reported here describes the first application of this nanotechnology to a fluorescence polarization (FP) molecular binding assay format. The GPCR chosen for these studies was the well-studied chemokine receptor CXCR4 for which a peptide ligand (T-22) has been previously characterized. The EC₅₀ determined for the CXCR4-T-22 peptide interaction via FP with CXCR4 lipoparticles (15 nM) is consistent with the IC₅₀ determined for the unlabeled T-22 peptide via competitive binding (59 nM). (Journal of Biomolecular Screening 2008:424-429)
