Journal of Endovascular Therapy

To analyze the 2-year outcomes of female patients after endovascular aortic aneurysm repair (EVAR) with the Zenith AAA Endovascular Graft.

A retrospective analysis was conducted of data from the US Zenith multicenter trial and the Zenith female registry on 40 women (10.9%, study group) and 326 men (89.1%, control group) enrolled. All patients had completed their 2-year follow-up. Primary study endpoints were survival, aneurysm rupture, and conversion rate. Significance was assumed if p<0.05.

Overall rates of mortality (12.5% for women versus 13.2% for men, p=0.94) and aneurysm rupture (2.5% for women versus 0% for men, p=0.11) were comparable between groups. Conversion to open repair within 2 years was significantly more frequent in women compared to men (7.5% versus 0.6%, p=0.01). The incidence of endoleaks of any type was equivalent between groups at 2 years (13.3% for women versus 6.9% for men, p=0.30). No difference was observed in the need for secondary interventions (15% for women versus 13.5% for men, p=0.81) or aneurysm dilatation >5 mm (10.5% for women versus 2.3% for men, p=0.10). None of the patients developed device migration .10 mm or required intervention for migration.

While women underwent conversion to open repair more frequently compared to men at 2 years post EVAR, there was no difference in survival, freedom from aneurysm rupture, or need for secondary interventions between groups. As in men, the Zenith AAA Endovascular Graft provides reliable protection from aneurysm rupture and aneurysm-related death in women in a midterm follow-up.

To elucidate the association of impaired pulmonary status (IPS) and diabetes mellitus (DM) with clinical outcome and the incidences of aortic neck dilatation and type I endoleak after elective endovascular infrarenal aortic aneurysm repair (EVAR).

In 164 European institutions participating in the EUROSTAR registry, 6383 patients (5985 men; mean age 72.4±7.6 years) underwent EVAR. Patients were divided into patients without versus with IPS or with/without DM. Clinical assessment and contrast-enhanced computed tomography (CT) were performed at 1, 3, 6, 12, 18, and 24 months and annually thereafter. Cumulative endpoint analysis comprised death, aortic rupture, type I endoleak, endovascular reintervention, and surgical conversion.

Prevalence of IPS was 2733/6383 (43%) and prevalence of DM was 810/6383 (13%). Mean follow-up was 21.1±18.4 months. Thirty-day mortality, AAA rupture, and conversion rates did not differ between patients with versus without IPS and between patients with versus without DM. All-cause and AAA-related mortality, respectively, were significantly higher in patients with IPS compared to patients with normal pulmonary status (31.0% versus 19.0%, p<0.0001 and 6.8% versus 3.3%, p=0.0057) throughout follow-up. In multivariate analysis adjusted for smoking, age, gender, comorbidities, fitness for open repair, co-existing common iliac aneurysm, neck and aneurysm size, arterial angulations, aneurysm classification, endograft oversizing >15%, and type of stent-graft, the presence of IPS was not associated with significantly higher rates of aortic neck dilatation (30.6% versus 38.0%, p>0.05) and did not influence cumulative rates of type I endoleak, endovascular reintervention, or conversion to open surgery (p>0.05). Similarly, the presence of DM did not influence the above-mentioned study endpoints.

In contrast to observations regarding the natural course of AAAs, impaired pulmonary status does not negatively influence aortic neck dilatation, while the presence of diabetes does not protect from these dismal events after EVAR.

To describe the short-term consequences of endovascular aortic aneurysm repair (EVAR) on renal function after infrarenal (IR) versus transrenal (TR) stent-graft fixation.

Between December 1996 and January 2006, 369 consecutive patients were treated with EVAR. All patients had an AneuRx or a Talent stent-graft implanted using IR (AneuRx) or transrenal (Talent) fixation. Post-EVAR, a standardized follow-up scheme included computed tomography (CT) scanning and serum creatinine measurements at 2 days, 3 months, and 12 months. Postoperative renal dysfunction was defined as a >20% decrease in serum creatinine clearance compared to baseline, the presence of new-onset dialysis, or both. Of the 369 patients, 309 (291 men; mean age 71±7 years, range 63–82) had complete 1-year follow-up and were included in this study. An IR stent-graft was placed in 190 patients, and a TR stent-graft was placed in the remaining 119 patients.

At discharge, renal dysfunction occurred in 3.7% of the patients in the IR group versus 5.9% in the TR group (p=NS) and rose significantly to 13.7% in the IR group (p=0.001) and 15.1% in the TR group (p=0.02) at the 1-year follow-up. However, no significant difference was noted between the IR and TR groups at either time point. At the 1-year follow-up, at least 50% of renal dysfunction was caused by obstructions of (accessory) renal arteries and renal infarctions. During the follow-up interval, 3 (0.97%) of 309 patients underwent new-onset dialysis.

Both infrarenal and transrenal fixation techniques in EVAR will lead to a significant rise in renal dysfunction during the first year. A few patients with dysfunction will require dialysis.

To assess the hemodynamic forces on a bifurcated abdominal aortic stent-graft under realistic conditions of flow, blood pressure, and sac pressure.

Computational fluid dynamics was used to study the temporal and spatial variations in surface pressure and shear through the cardiac cycle on models of bifurcated stent-grafts derived from computed tomography in 4 patients who had previously undergone endovascular repair of abdominal aortic aneurysm (AAA). The trunk, bifurcation, and limbs of the graft were analyzed separately and as parts of a unified whole. Analyses were repeated under varying conditions of sac pressure, reflecting different conditions of perigraft flow and sac diameter change.

Pressure-related forces were far larger than flow-related forces in all 3 segments of all 4 cases. The largest forces acted at the bifurcation of the stent-graft. High sac pressures, seen in patients with endoleak or aneurysm dilatation, were associated with reduced transmural pressure and low-pressure—derived forces.

Several parameters of stent-graft design affect the magnitude and distribution of forces on a bifurcated stent-graft. The forces on a stent-graft are also affected by the pressure within the aneurysm sac, which depends on stent-graft performance.

To present the concept of double tube stent-grafts and examine the indications for and results achieved with these devices.

From January 1, 2000, to December 31, 2005, 759 patients who underwent endovascular repair of infrarenal aortic aneurysms at 2 centers. Of these, 45 (5.9%) patients received a double tube stent-graft; complete operative and follow-up data were available for retrospective analysis in 41 patients (33 men; mean age 73.1±8.9 years). Diameters measured before stent-graft implantation and at follow-up (12, 24, 36, and 48 months) with clinical examination, 2-phase computed tomographic angiography, duplex sonography, and biplanar abdominal radiography were tested for significant changes using ANOVA with the Bonferroni-Dunn correction. Late outcomes (clinical success and endoleak) were analyzed by the Kaplan-Meier method.

The postoperative complication rate was 12.2%, with 2.4% systemic complications (1 patient with angina pectoris); the early mortality rate was 0%. Mean follow-up was 21.9±12.8 months (range 12–61) for the 41 patients. Four (9.8%) patients died during follow-up of cardiac causes (n=2), lung cancer (n=1), and bowel ischemia (n=1). Four (9.8%) endoleaks were observed during follow-up: 1 distal type I, 2 type II, and 1 type III. Maximum aneurysm diameters shrank from 52.0±9.5 mm preoperatively to 44.0±10.8 mm (p<0.0001) postoperatively at the latest available follow-up.

Our study supports the use of this double tube technique for repair of appropriate saccular infrarenal aortic aneurysms. The double tube stent-graft method appears safe in terms of endoleaks and migration, so we recommend that it be considered an option of endovascular aortic aneurysm therapy.

To compare the results of thoracic endovascular grafting of different aortic segments performed with commercially available stent-grafts.

Between January 1999 and October 2006, 178 patients (150 men; mean age 69.4±10.2 years) underwent endovascular grafting of the thoracic aorta (68 hybrid procedures) with commercially produced stent-grafts from 4 manufacturers. Patients were divided into 3 groups according to the aortic segment involved: 64 aortic arch cases (37 hybrids for supra-aortic trunks revascularization), 100 descending thoracic aorta (DTA) cases (17 hybrid: 12 for access and 5 for associated abdominal aortic aneurysm), and 14 thoracoabdominal aorta (TaA) patients excluded from conventional repair (14 hybrids for renal and splanchnic revascularization).

The technical success was 93.8% (167/178). Overall 30-day mortality was 5.6% (10/178). There were 10 (5.6%) type I endoleaks. Initial clinical success was 88.2% (157/178). At a mean follow-up of 29.3±21.2 months, the midterm clinical success was 89.9% (160/178). In the arch group, the technical success was 85.9% (55/64). Thirty-day mortality was 6.3% (4/64). There were 8 (12.5%) type I endoleaks. Initial and midterm clinical success rates were 79.7% (51/64) and 85.9% (55/64), respectively. In the 100-patient DTA group, the technical success was 98.0%. Thirty-day mortality was 2.0%. The type I endoleak rate was 2.0%. Clinical success was 96.0% initially and 95.0% at midterm. All 14 of the TaA cases were completed successfully, but 30-day mortality was 28.6% (4/14). There were no type I endoleaks. Clinical success rates initially and at midterm were both 71.4% (10/14).

Over the last 6 years, synergy between endovascular and surgical procedures allowed treatment of all segments of the thoracic aorta. Overall perioperative and medium-term results were reasonably favorable; however, they were more satisfactory when the descending thoracic aorta alone was involved. Hybrid procedures allowed treatment of all aortic segments, but they decreased the success rates significantly. Endovascular grafting is currently our preferred method of treating pathologies involving the DTA and aortic arch, while our data suggest limiting the use of stent-grafts to high-risk patients or compassionate indications when the thoracoabdominal aorta is involved.

To examine in a canine model the feasibility of antegrade fenestration of abdominal aortic stent-grafts to preserve the patency of the renal arteries.

Two large dogs underwent antegrade fenestration of stent-grafts in the perirenal aorta. Before fenestration, bare stents were inserted in both renal arteries as fluoroscopic landmarks. A 12-mm iliac extension served as the canine aortic endograft. The first procedure was done under ultrasound and fluoroscopic guidance, using an intravascular ultrasound (IVUS) probe inserted in the vena cava and a Pioneer IVUS catheter. The second was performed exclusively under fluoroscopic guidance with a Brockenbrough needle. Angiograms and duplex ultrasound were planned for 1 month, after which the dogs would be sacrificed for autopsy. The explanted endograft was subjected to biomaterials analysis, with a focus on fabric tear.

Perforation of the aortic graft and catheterization of the renal arteries with a floppy guidewire were possible in both animals. In dog 1, aortic graft dilation and subsequent fenestration were not possible, and the experiment was terminated. However, the procedure was successful in both renal arteries of dog 2. At 1-month follow-up in this dog, both renal arteries were patent. Stent fractures were observed bilaterally. There was no extension of the damage to the fabric beyond the area of fenestration.

In vivo antegrade fenestration of aortic endografts is technically feasible. However, improvements in technique, instrumentation, and materials are required to make it a reliable and reproducible way of allowing stent-graft vascularization of aortic side branches.

To determine whether fenestrated stent-grafts provide better stability to resist migration than standard non-fenestrated stent-grafts.

Truncated fenestrated stent-grafts with a single fenestration were deployed in bovine aortic segments with a side branch. Balloon-expandable stents were then delivered into the branches. Similarly, standard stent-grafts of the same dimensions were deployed for comparison. The aorta was pressurized to achieve stent-graft oversizing of 5%, 10%, or 20%. The force required to cause distal migration was recorded by a digital force gauge attached to the stent-graft.

Displacement of the stent-grafts occurred in 2 distinct phases: an initial yield during which the barbs embedded in the aortic wall and a final displacement leading to significant migration and dislodgement of the device. The displacement force that initiated each phase was dependent upon the degree of oversizing of the stent-graft relative to the aortic diameter. For 5%, 10%, and 20% oversizing, the mean displacement forces in the initial displacement phase were 3.39±0.37, 4.32±0.63, and 7.69±1.18 N, respectively, in non-fenestrated grafts and 10.48±1.23, 11.45±1.48, 12.12±1.42 N in fenestrated grafts. The displacement forces in the final displacement phase were 8.10±0.92, 10.76±1.74, and 16.82±0.92 N for non-fenestrated and 22.56±1.60, 28.24±1.56, and 33.01±1.75 N for fenestrated stent-grafts. The differences in displacement forces between standard and fenestrated stent-grafts were significant for both phases (p<0.001) at all oversizing levels.

Improvement in fixation strength was noted with increasing stent-graft oversizing of up to 20%. Fenestrated stent-grafts offer higher ultimate fixation compared to standard devices. However, the ultimate fixation strength was not recruited until an initial phase of short migration occurred as the barbs engaged. While this movement is inconsequential with standard stent-grafts, it has the potential to crush the stents placed into aortic side branches with fenestrated endografts.

To report a prospective, nonrandomized pilot study to determine whether fibrin glue aneurysm sac embolization at the time of endovascular aneurysm repair (EVAR) is a safe and effective procedure to primarily prevent type II endoleaks.

Between June 2003 and December 2005, 84 consecutive patients (79 men; mean age 73.8±7.8 years, range 64–86) with degenerative infrarenal abdominal aortic aneurysm underwent EVAR with bifurcated stent-grafts and fibrin glue injection into the aneurysm sac at the conclusion of the endovascular procedure. A total of 424 imaging studies and 348 visits were recorded during the study period and reviewed.

Selective catheterization of the aneurysm sac and fibrin glue injection immediately after initial stent-graft deployment was successful in 83 (99%) of 84 cases; there was one failure to access the excluded aneurysm sac due to severe iliac artery calcification. The estimated primary and assisted clinical success rates at 2 years were 91.3% and 98.8%, respectively, but the major findings were the low rate of delayed type II endoleak (2.4%) and the statistically significant decrease in the maximum transverse aneurysm diameter (50.40±6.70 versus 42.03±6.50 mm, p=0.0001) at follow-up. In addition, of 31 patients available for 24-month follow-up, 14 (45.2%) patients showed a reduction in maximum transverse aneurysm diameter by ≥5 mm; 16 (51.6%) patients had no significant changes, whereas only 1 patient showed a >5-mm enlargement.

This clot engineering approach to aneurysm sac embolization at the time of endografting appears to be safe and may spare the patient a repeated catheter-based intervention or surgical procedure.

To describe a technique for access site closure in percutaneous abdominal aortic aneurysm (AAA) repair using double Perclose ProGlide devices to overcome the problems associated with the bulky delivery system and braided suture of the antecedent (Prostar) device.

After obtaining guidewire access, 2 Perclose ProGlide sutures are deployed at 90° to each other. The appropriate sheaths are placed over the stiff guidewires. After the stent-graft procedure is completed, an assistant holds pressure while the knots are tightened with the stiff guidewire still in the artery. Once the second knot is tightened with the knot pusher and after confirming adequate hemostasis, the wire is removed, pressure is applied, and heparin reversed. This method has been used in 17 consecutive patients (age range 65–85 years) undergoing endovascular AAA repair. One patient needed patch angioplasty and 2 required small incisions for additional suture placements (81% primary success rate for total percutaneous repair, 90% success rate for all sites).

We have found the double Perclose ProGlide technique to be easy to use, safe, and feasible for total percutaneous AAA repair. More experience with longer follow-up is needed to assess its potential to replace the Perclose Prostar closure device for total percutaneous AAA repairs.

To determine if angioplasty of atherosclerotic renal artery stenosis, which reduces the activation of the renin-angiotensin-aldosterone system (RAAS), may lead to regression of left ventricular hypertrophy.

The study included 102 patients (58 men; mean age 67 years, range 66–69) who underwent stent-supported percutaneous transluminal renal angioplasty (PTRA) and were included in a clinical follow-up program (mean 24±14 months, range 6–60). As a control group, 101 contemporaneous patients (68 men; mean age 68 years, range 66–70) with essential hypertension were investigated. The primary endpoint was the change in left ventricular mass index (LVMI) determined by echocardiography.

Mean follow-up intervals were 24±14 months (range 6–60) in the study group and 27±14 months (range 6–60) in the controls (p=0.09). LVMI decreased significantly by −10±26 g/m² in the study group, while it increased significantly by 9±28 g/m² in the control group (p=0.001 between groups). In the study group, mean arterial blood pressure was significantly reduced from 99±11 mmHg to 90±11 mmHg (p<0.0001) during follow-up despite a significant reduction in medication, whereas it increased significantly from 102±11 mmHg to 105±11 mmHg (p=0.008) in the control group, although medication was significantly increased. After adjustment for various factors and covariables, PTRA prevailed as an independent predictor for regression of LVMI (p=0.038).

PTRA induces regression of LVMI that is independent of the reduction in blood pressure induced by this procedure. Reduced activity of the RAAS may account for this regression.

To report early clinical experience with virtual histology intravascular ultrasound (VH IVUS) in carotid endoluminal repair.

A 2.9-F, 20-MHz catheter that utilizes computer software to demonstrate the histological components of arteriosclerotic plaque was evaluated during carotid angioplasty and stenting. VH IVUS images were created following a pullback through the carotid stenosis and produced a color-coded map of the different histological constituents of the disease (dark green: fibrous, yellow/green: fibrofatty, white: calcified, and red: necrotic lipid core plaque).

VH IVUS produces a color-coded map of the different histological components of artery plaque. It has the potential to predict how the plaque is likely to behave at the moment of endoluminal treatment.

To determine the effect of stent coverage of the external carotid artery (ECA) after carotid artery stenting (CAS) compared to eversion endarterectomy of the ECA after carotid endarterectomy (CEA).

The records of 101 CAS and 165 CEA procedures performed over 2 years were reviewed. Duplex velocities and history and physical examinations were taken prior to the procedure, at 1 month, and at 6-month intervals subsequently. CAS was performed by extending the stent across the internal carotid artery (ICA) lesion into the common carotid artery (CCA) thereby covering the ECA. CEA was performed with eversion endarterectomy of the ECA.

The mean peak systolic velocities (PSV) in the ICA pre-CAS and pre-CEA were 361 and 352 cm/s, respectively. In terms of CAS, there was a significant increase in ECA velocities versus baseline at 12 (p=0.009), 18 (p=0.00001), and 24 (p=0.005) months. In the CEA group, there was a significant decrease in ECA velocities versus baseline at 1 (p=0.01) and 6 (p=0.004) months. There were 2 occluded ECAs in follow-up in the CAS group and none in the CEA group. No significant differences were noted when comparing preprocedural ICA or ECA velocities. However, at the 1-, 6-, and 12-month intervals, the ECA velocities in the CAS group were significantly higher than in the CEA group (p=0.03, p=0.001, and p=0.0004, respectively). There were no neurological symptoms in any patients during the study period.

Although progressive stenosis of the ECA is noted during CAS, the ECA usually does not occlude. Furthermore, there are no associated neurological symptoms. Thus, apprehension for progressive ECA occlusion should not be a contraindication to CAS. In addition, concern for ECA coverage should not deter stent extension from the ICA to the CCA during CAS.

To report a technique for emergency CAS of a stenotic internal carotid artery (ICA) lesion with an intraluminal thrombus, which predisposes to distal thromboembolism and could aggravate pre-existing neurological symptoms.

A 77-year-old man with fluctuating stroke underwent successful emergency CAS for an ICA stenosis with intraluminal thrombus using a tandem balloon protection technique featuring proximal balloon blockade and a PercuSurge GuardWire system for distal protection.

This experience suggests that emergency CAS with tandem balloon protection is a potential treatment for a stenotic lesion with an intraluminal thrombus in patients with fluctuating stroke.

To report the 12- and 24-month results after directional atherectomy (DA) of below-the-knee (BTK) arterial lesions with the SilverHawk device.

Forty-nine BTK lesions in 36 patients (58% men; mean age 70611 years) with peripheral occlusive disease of the lower limbs were treated with DA; 19 (53%) of the limbs were classified with Rutherford-Becker 4 or 5 ischemia. Target lesions were in the popliteal artery (n=6, 12%), tibioperoneal trunk (n=25, 51%), peroneal artery (n=10, 20%), anterior tibial artery (n=5, 10%), and posterior tibial artery (n=3, 6%). Nine (18%) lesions were located in a stent. Twelve lesions extended to 2 artery segments. The average degree of diameter stenosis was 89%±10% (range 70%–100%); there were 11 (22%) occlusions. The mean lesion length was 48±28 mm.

Sixteen (33%) lesions were treated after predilation; 33 (67%) lesions were treated with primary DA. All but 1 (2%) lesion could be treated with DA. In 19 (39%) lesions, additional balloon angioplasty was performed, and 2 (4%) lesions required stent implantation as a result of dissection. The mean stenosis diameter after DA was 12%±18% (range 0%–100%). After additional therapy, the mean stenosis diameter was 8%±9% (range 0%–100%). A residual stenosis ≤30% was achieved in 48 (98%) lesions. The mean ankle-brachial index significantly increased from 0.48±0.26 to 0.81±0.32 (p<0.05) before discharge and remained improved during follow-up. Primary and secondary patency rates were 67% and 91% after 1 year and 60% and 80% after 24 months. The 12-and 24-month cumulative event-free survival rates (primary patency) by Kaplan-Meier analysis were 58%±8% and 46%±9%; at the same time intervals, the cumulative survival rates (secondary patency) were 88%±6% and 73%±9%, respectively.

BTK lesions can be treated successfully and safely with DA. Midterm clinical results are encouraging.

To report the 1-year angiographic and clinical outcome from a prospective single-center study investigating the infrapopliteal application of sirolimus-eluting versus bare metal stents in patients with critical limb ischemia (CLI) who underwent below-the-knee endovascular revascularization.

Stenting was performed as a bailout procedure for suboptimal angioplasty results (flow-limiting dissection, elastic recoil, or postangioplasty residual stenosis >30%). In the first 29 patients, infrapopliteal stenting was performed with bare metal stents (group B) and with sirolimus-eluting stents in the other 29 patients (group S).

Below-the-knee angioplasty and stenting involved 65 lesions in 40 infrapopliteal arteries of 29 limbs in group B and 66 lesions in 41 infrapopliteal arteries of 29 limbs in group S. Baseline comorbidities (hyperlipidemia and symptomatic cardiac and carotid disease) were more pronounced in group S (p<0.05). At 6 months, sirolimus-eluting stents demonstrated significantly higher primary patency (OR 5.625, 95% CI 1.711 to 18.493, p=0.004) and decreased in-stent binary restenosis (OR 0.067, 95% CI 0.021 to 0.017, p<0.001) and in-segment binary restenosis (OR 0.229, 95% CI 0.099 to 0.533, p=0.001). After 1 year, sirolimus-eluting stents were steadily associated with increased primary patency (OR 10.401, 95% CI 3.425 to 31.589, p<0.001) and significantly less in-stent (OR 0.156, 95% CI 0.060 to 0.407, p<0.001) and in-segment (OR 0.089, 95% CI 0.023 to 0.349, p=0.001) binary restenosis. In addition, sirolimus-eluting stents were associated with significantly fewer cumulative target lesion reinterventions at 6 months (OR 0.057, 95% CI 0.008 to 0.426, p=0.005) and 1 year (OR 0.238, 95% CI 0.067 to 0.841, p=0.026). No significant differences between groups B and S were noted at 1 year with respect to mortality (10.3% versus 13.8%, respectively), minor amputation (17.2% versus 10.3%), or limb salvage (100% versus 96%).

The application of sirolimus-eluting stents reduces the restenosis rate in the infrapopliteal arteries and the rate of repeat endovascular procedures the first year after treatment.

To report a single-center clinical experience with ultrasound-enhanced thrombolysis in the treatment of both arterial and venous thromboses.

From January 2005 to June 2006, 33 patients (23 men; age range 39–90 years) with 36 occlusions were treated using ultrasound-enhanced thrombolytic therapy for acute and chronic arterial and venous occlusions. After diagnostic angiography, the occlusions were crossed with an appropriately sized Lysus infusion catheter for infusion of urokinase (80,000–120,000 IU/h).

Technical success and complete lysis was achieved in 96% of the arterial and 83% of the venous occlusions. Two patients with chronic occlusions (one superficial femoral artery and one iliac vein) were refractory to lytic therapy. Average time for complete lysis was 16.4 hours (range 3–25) for arterial occlusions and 21.2 hours (range 6–43) in patients with deep vein thrombosis.

Successful clot lysis can be achieved with a high rate of success in a shorter time than conventional thrombolysis using ultrasound-enhanced thrombolysis in both acute and chronic arterial and venous thromboses.

To describe the use of the Amplatzer vascular plug to treat a partially uncovered left subclavian artery (LSA) causing digital embolism following thoracic endovascular aneurysm repair.

A 70-year-old man presented with digital ischemia of the left index and middle fingers due to embolism from a partially covered LSA orifice during thoracic endovascular aneurysm repair for a type I thoracic aortic aneurysm. The orifice was successfully occluded using the vascular plug, supplemented by a left carotid-subclavian bypass to treat ongoing arm and hand claudication. The patient has had no further embolic episodes.

A partially uncovered LSA during thoracic endovascular aneurysm repair poses a risk of thromboembolism, with resultant upper limb claudication or tissue loss. If recognized at the time of the procedure, this should be treated by proximal extension; otherwise, proximal LSA occlusion using an Amplatzer occluder may be a safe and effective option in preventing further embolic episodes.

To report a novel complication of a hybrid “frozen elephant trunk” endograft used in the treatment of a multisegmentally diseased aorta.

A 53-year-old man with chronic type A aortic dissection and previous replacement of the supracoronary ascending aorta underwent a “frozen elephant trunk” procedure using a hybrid endograft. The stent-graft was placed deep in the descending aorta to cover the multiple distal re-entries. Due to ineffective covering of the re-entries, a patent false lumen led to rapid repressurization of the false lumen immediately distal to the circumferential elephant trunk anastomosis. Compression of the non-stented portion of the hybrid endograft caused a functional aortic stenosis, with severe hemodynamic consequences. Endovascular treatment of the compression by retrograde transfemoral placement of a stent-graft in the non-stented portion of the hybrid endograft achieved free flow in the distal aorta.

This case documents a new complication of the frozen elephant trunk procedure; a pseudocoarctation from a repressurized proximal false lumen was successfully managed with a stent-graft to support the non-stented segment of the hybrid endograft.
