The aim of this study was to assess whether tumoral and peritumoral apparent diffusion coefficient values and intratumoral susceptibility signals on susceptibility-weighted imaging could distinguish between high-grade gliomas and brain metastases, and to investigate their associations with the Ki-67 proliferation index.

Fifty-seven patients with pathologically confirmed diagnoses of either high-grade glioma or brain metastasis were enrolled in this study (23 with high-grade gliomas and 34 with brain metastases). The minimum and mean apparent diffusion coefficients in the enhancing tumoral region (ADC_min and ADC_mean) and the minimum apparent diffusion coefficient in the peritumoral region (ADC_edema) were measured from apparent diffusion coefficient maps, and intratumoral susceptibility signal grades acquired by susceptibility-weighted imaging were calculated. Ki-67 proliferation index values were obtained from the hospital database. These parameters were evaluated using the Mann-Whitney U test, independent-sample t-test, Spearman correlation analysis, receiver operating characteristic curve, and logistic regression analyses.

ADC_mean, ADC_min values, and intratumoral susceptibility signal grades in brain metastases were significantly lower than those in high-grade gliomas (all p < 0.05). Ki-67 proliferation index values showed significant correlations with ADC_mean, ADC_min, and intratumoral susceptibility signal grade in brain metastases (all p < 0.05), but no correlation was found in high-grade gliomas (all p > 0.05). According to receiver operating characteristic curve analysis, ADC_mean achieved the highest diagnostic performance for discriminating high-grade gliomas from brain metastases. Furthermore, the combination of tumoral apparent diffusion coefficient parameters with intratumoral susceptibility signal grade provided a higher area under the curve than univariate parameters.

The combination of tumoral apparent diffusion coefficient with intratumoral susceptibility signal grade can offer better diagnostic performances for differential diagnosis. Apparent diffusion coefficient and intratumoral susceptibility signal may reflect cellular proliferative activity in brain metastases, but not in high-grade gliomas.

Focal hyperintensity in the dorsal brainstem (HDB) has been described in large cerebellopontine angle tumours and is thought to represent vestibular nuclei degeneration, but its functional significance has not been thoroughly investigated. Our aim was to analyse its relationship to imaging characteristics of the tumour and inner-ear structures and to vestibulocochlear functional tests.

We retrospectively reviewed 54 patients with a histological diagnosis of vestibular schwannoma (VS). Magnetic resonance imaging tumour characteristics (size, cystic composition and distance from the cochlear aperture), signal intensity ratio of the cochlea and vestibule in fluid-attenuated inversion recovery (FLAIR) and fast imaging employing steady-state acquisition (FIESTA)/fast spin-echo imaging with variable flip angles (CUBE) and vestibulocochlear function tests (audiometry, auditory brainstem response (ABR) and video head impulse testing (vHIT)) were obtained. Statistical analyses were performed to evaluate their relation to focal HDB.

Focal HDB was found in 22% of VS. It was significantly associated with large (p < 0.001) and cystic (p = 0.004) tumours and also with tumours located further from the cochlear aperture (p = 0.039). The signal intensity ratio of the cochlea on FLAIR was higher in patients with HDB (p < 0.014), but this difference was not observed in FIESTA/CUBE (p = 0.981). Audiometry, ABR and vHIT results did not significantly differ in patients with HDB, but ABR results were worse in patients with higher cochlear signal intensity on FLAIR sequences (p = 0.026).

Focal HDB in patients with VS was associated with increased signal intensity ratio of the cochlea on FLAIR in patients with VS but not directly to the results of vestibulocochlear function tests.

Magnetic resonance imaging (MRI) of the brain in scrub typhus meningoencephalitis is non-specific, and in the majority of the cases, conventional MRI fails to detect any abnormality. However, autopsy reports depict central nervous system involvement in almost all patients. There is therefore a need for research on the quantitative assessment of brain parenchyma that can detect microstructural abnormalities. The study aimed to assess the microstructural integrity changes of scrub typhus meningoencephalitis by using different diffusion tensor imaging (DTI) parameters.

This was a retrospective analysis of scrub typhus meningoencephalitis. Seven patients and seven age- and sex-matched healthy controls were included. Different DTI parameters such as apparent diffusion coefficient (ADC), fractional anisotropy (FA), relative anisotropy (RA), trace, volume ratio (VR) and geodesic anisotropy (GA) were obtained from six different regions of subcortical white matter at the level of the centrum semiovale. Intergroup significant difference was determined by one-way analysis of variance followed by Tukey’s post hoc test. Receiver operating characteristic curves were constructed to determine the accuracy of the DTI matrices.

There was a significant decrease in FA, RA and GA as well as an increase in ADC and VR in the subcortical white matter in patients with scrub typhus meningoencephalitis compared to controls (p < 0.001). The maximum sensitivity of the DTI parameters was 85.7%, and the maximum specificity was 81%.

There was an alteration of subcortical white-matter integrity in scrub typhus meningoencephalitis that represents the axonal degeneration, myelin breakdown and neuronal degeneration. DTI may be a useful tool to detect white-matter abnormalities in scrub typhus meningoencephalitis in clinical practice, particularly in patients with negative conventional MRI.

Vessel wall magnetic resonance imaging can improve the evaluation of intracranial atherosclerotic disease. However, pathological validation is needed to improve vessel wall magnetic resonance imaging techniques. Human pathology samples are not practical for such analysis, so an animal model is therefore needed.

Watanabe heritable hyperlipidemic rabbits and apolipoprotein E knockout rabbits were evaluated against New Zealand white wild-type rabbits. Evaluation of intracranial arteries was performed with vessel wall magnetic resonance imaging and pathological analysis, rating the presence and severity of disease in each segment. Two-tailed t-tests were performed to compare disease occurrence and severity prevalence among rabbit subtypes. Sensitivity and specificity were calculated to assess the diagnostic accuracy of vessel wall magnetic resonance imaging.

Seventeen rabbits (five Watanabe heritable hyperlipidemic, four apolipoprotein E knockout and eight New Zealand white) were analysed for a total of 51 artery segments. Eleven segments (five Watanabe heritable hyperlipidemic and six apolipoprotein E knockout) demonstrated intracranial atherosclerotic disease on pathology. Disease model animals had lesions more frequently than New Zealand white animals (P<0.001). The sensitivity and specificity of vessel wall magnetic resonance imaging for the detection of intracranial atherosclerotic disease were 68.8% and 95.2%, respectively. When excluding mild cases to assess vessel wall magnetic resonance imaging accuracy for detecting moderate to severe intracranial atherosclerotic disease lesions, sensitivity improved to 100% with unchanged specificity.

Intracranial atherosclerotic disease can be reliably produced and detected using 3T vessel wall magnetic resonance imaging-compatible Watanabe heritable hyperlipidemic and ApoE rabbit models. Further analysis is needed to characterize better the development and progression of the disease to correlate tissue-validated animal findings with those in human vessel wall magnetic resonance imaging studies.

Cervical discopathy and demyelinating lesions often co-exist in patients with multiple sclerosis (MS). Our study examines the possible association between these two pathologies.

Medical records and cervical magnetic resonance imaging scans of MS patients with cervical discopathy who were seen at our MS clinic during 2018 were retrospectively reviewed. The severity of the disc disease was classified as grade I (no compression), grade II (compression of the dural sac) and grade III (cord compression). The spinal cord in each scan was divided into six segments corresponding to the intervertebral space of the spine (C1–C6). Each segment was defined as containing demyelinating lesion and disc pathology (group 1), demyelinating lesion without disc pathology (group 2), disc pathology without demyelinating lesion (group 3) and no demyelinating lesion or disc pathology (group 4). Fisher’s exact test was used to test the association between demyelinating lesions and disc pathology.

Thirty-four MS patients with cervical discopathy were included in the study (26 females; average age 42.9 ± 13.7 years; average disease duration 8.4 ± 5.4 years). A total of 204 spinal cord segments were evaluated. Twenty-four segments were classified as group 1, 27 segments as group 2, 52 segments as group 3 and 101 segments as group 4. There was no association between demyelinating lesions and the grade of disc disease (p = 0.1 for grade I, p = 0.3 for grade II and p = 1 for grade III disc disease).

Our study did not find any association between cervical disc disease and demyelinating spinal cord lesion.

Brain metastasis and glioblastoma multiforme are two of the most common malignant brain neoplasms. There are many difficulties in distinguishing these diseases from each other.

The purpose of this study was to determine whether the mean apparent diffusion coefficient and absolute standard deviation derived from apparent diffusion coefficient measurements can be used to differentiate glioblastoma multiforme from brain metastasis based on cellularity levels.

Magnetic resonance images of 34 patients with histologically verified brain tumors were evaluated retrospectively. Apparent diffusion coefficient and standard deviation values were measured in the enhancing tumor, peritumoral region, and contralateral healthy white matter. Then, to determine whether there was a statistical difference between brain metastasis and glioblastoma multiforme, we analyzed different variables between the two groups.

Neither mean apparent diffusion coefficient values and ratios nor standard deviation values and ratios were significantly different between glioblastoma multiforme and brain metastasis. Receiver operating characteristic curve analysis of the logistic model with backward stepwise feature selection yielded an area under the curve of 0.77, a specificity of 84%, a sensitivity of 67%, a positive predictive value of 83.33%, and a negative predictive value of 78.26% for distinguishing between glioblastoma multiforme and brain metastasis. The absolute standard deviation and standard deviation ratios were significantly higher in the peritumoral edema compared to the tumor region in each case.

Apparent diffusion coefficient values and ratios, as well as standard deviation values and ratios in peritumoral edema, cannot be used to differentiate edema with infiltration of tumor cells from vasogenic edema. However, standard deviation values could successfully characterize areas of peritumoral edema from the tumoral region in each case.

Compressed sensing is used for accelerated acquisitions with incoherently under-sampled k-space data, and intracranial time-of-flight magnetic resonance angiography is suitable for compressed sensing. Compressed sensing time-of-flight is beneficial in decreasing acquisition time and increasing spatial resolution while maintaining acquisition time. In this retrospective study, we aimed to evaluate the image quality and diagnostic performance of compressed sensing time-of-flight with high spatial resolution and compare with parallel imaging time-of-flight using digital subtraction angiography as a reference.

In total, 39 patients with 46 intracranial aneurysms underwent parallel imaging and compressed sensing time-of-flight in the same imaging session and digital subtraction angiography before or after magnetic resonance angiography. The overall image quality, artefacts and diagnostic confidence were assessed by two observers. The contrast ratio, maximal aneurysm diameters and diagnostic performance were evaluated.

Compressed sensing time-of-flight showed significantly better overall image quality, degree of artefacts and diagnostic confidence in both observers, with better inter-observer agreement. The contrast ratio was significantly higher for compressed sensing time-of-flight than for parallel imaging time-of-flight in both observers (source images, P < 0.001; maximum intensity projection images, P < 0.05 for both observers); however, the measured maximal diameters of aneurysms were not significantly different. Compressed sensing time-of-flight showed higher sensitivity, specificity, accuracy and positive and negative predictive values for detecting aneurysms than parallel imaging time-of-flight in both observers, with better inter-observer agreement. Compressed sensing time-of-flight was preferred over parallel imaging time-of-flight by both observers; however, parallel imaging time-of-flight was preferred in cases of giant and large aneurysms.

Compressed sensing-time-of-flight provides better image quality and diagnostic performance than parallel imaging time-of-flight. However, neuroradiologists should be aware of under-sampling artefacts caused by compressed sensing.

The COVID-19 pandemic led to a widespread socioeconomic shutdown, including medical facilities in many parts of the world. The purpose of this study was to assess the impact on neuroimaging utilisation at an academic medical centre in the United States caused by this shutdown.

Exam volumes from 1 February 2020 to 11 August 2020 were calculated based on patient location, including outpatient, inpatient and emergency, as well as modality type, including computed tomography and magnetic resonance imaging. 13 March 2020 was designated as the beginning of the shutdown period for the radiology department and 1 May 2020 was designated as the reopening date. The scan volumes during the pre-shutdown, shutdown and post-shutdown periods were compared using t-tests.

Overall, neuroimaging scan volumes declined significantly by 41% during the shutdown period and returned to 98% of the pre-shutdown period levels after the shutdown, with an estimated 3231 missed scans. Outpatient scan volumes were more greatly affected than inpatient scan volumes, while emergency scan volumes declined the least during the shutdown. In addition, the magnetic resonance imaging scan volumes declined to a greater degree than the computed tomography scan volumes during the shutdown.

The shutdown from the COVID-19 pandemic had a substantial but transient impact on neuroimaging utilisation overall, with variable magnitude depending on patient location and modality type.
