A study is reported which shows that accommodation can be stimulated by a blur stimulus which is below the threshold for visual perception. It is also shown that perceptual fading of the target, caused by stabilization of the retinal image (Troxler phenomenon), can eliminate the accommodative response causing it to default to its resting level. The first finding suggests a way in which the visual system can filter the percept of blur out of our conscious awareness and still effectively utilize the blur as a steady-state error for the accommodative control system. The second finding is consistent with a locus for the Troxler phenomenon in the early afferent part of the visual pathway, ie the retinal ganglion cells.

One of the issues faced by engineers when designing a system which records an external event and represents it in the form of a digitized image on a VDU screen is which type of grey scale to use. An experiment is described which compares, in a simulated digitized image, the effect of a linear and a logarithmic grey scale on the detectability of a straight-line signal embedded in visual noise. It was found that both bright and dark signals were detected more easily with the linear scale. A signal detection theory analysis was carried out to compare human performance with that of an ‘ideal’ observer who performed the detection task with a filter spatially matched to the signal. It was found that the model of performance for this ideal observer accounted well for the results provided the assumption of a linear transformation of luminance was made. The analysis showed that the superiority of the linear over the logarithmic grey scale was simply due to the higher signal-to-noise ratio of the signals in the former.

A method is described for minimizing the ghost images which normally appear when anaglyphs are presented on color television screens. This is done by careful adjustment of the phosphor levels in each of the anaglyph regions.

A solid (ie filled-in) two-dimensional form is seen in motion toward another solid object of different shape and not towards an outline object of the same shape. The interpretation of these findings in terms of luminance-domain spatial frequency filtering is challenged by experiments in which the same results were obtained with kinetic and cyclopean forms.

A number of pictorial devices were compared in order to assess their relative effectiveness in depicting events. Effectiveness, as measured by a rating task, did not seem to be a function of the classification of a device as natural or metaphorical. Rather, it depended on whether a given device highlighted a distinctive aspect of a particular event (running, jumping, or moving), or simply modified the event. This observation was buttressed by the existence in a forced-choice task of a category boundary for depictions of running (pictures with a certain device were seen as running, those without it were not) but not for moving or jumping. Even preschool children displayed some understanding of metaphorical devices. They chose figures with those devices as running faster than the experimental standard. Results are discussed in the context of Kennedy's characterization of pictorial metaphors and Gibson's framework for understanding the relationship between pictorial and environmental information.

A new dynamic visual illusion is reported: contrast reversal of a horizontal and vertical plaid pattern (produced by adding two orthogonal sinusoidal gratings) causes the pattern to appear as an array of lustrous diamonds, cut by sharp lines into a diagonal lattice structure. On the basis of computer simulations it is suggested that the illusion results from rivalrous interaction of motion detectors tuned to opposing directions of motion.

A study is reported in which the acuity of azimuth and elevation discrimination under monaural listening conditions was measured. Six subjects localised a sound source (white noise through a speaker) which varied in position over a range of elevations (−40° to +40°) and azimuths (0° to 180°), at 10° intervals, on the left side of the head. Monaural listening conditions were established by the fitting of an ear defender and one earmuff to the right ear. The absolute and algebraic, azimuth and elevation errors were measured for all subjects at each position of the source. The results indicate that all subjects suffered a marked reduction of azimuth acuity under monaural conditions, although a coarse capacity to discriminate azimuth still remained. Considerable between-subject variability was observed. Front/back discrimination was retained, although it was slightly impaired compared to that observed under normal listening conditions. Elevation discrimination was, on the whole, quite good under monaural conditions. However, a comparison of the performance of these subjects under monaural conditions with that observed under normal listening conditions indicated that some reduction in elevation localisation acuity occurred in the frontal quadrants in the median plane and in the upper quadrants of more lateral source positions. The reduction in acuity seen in these regions is attributed to the loss of information from the pinna of the occluded ear rather than to the observed reduction in azimuth error. The results provide partial support for the binaural pinna disparity model.

The third and fourth fingertips of five subjects were pressed against each other so as to produce a skin displacement. A single spherical stimulus was then applied simultaneously to the two fingertips in order to test perceptual experiences with different amounts of skin displacement. The results show that the probability of detecting one stimulus when a single stimulus was applied to the skin in the resting position was 0.90. This probability decreased with increments in skin displacement. At the maximum skin displacement tested the probability of detecting one stimulus when a single stimulus was applied to the two displaced fingertip surfaces was only 0.04: this means that the single stimulus was perceived to be double with a probability of 0.96. The occurrence of this doubling, similar to Aristotle's crossed-finger illusion, shows that a diplopia-like phenomenon is present in the somesthetic system. How this ‘tactile diplopia’ could represent an interesting approach to the study of tactile perception is discussed.
