A study is reported of (i) the perceived inclination of a textured surface in depth about a horizontal axis as a function of disparity magnitude for horizontal-shear disparity, vertical-shear disparity, and rotation disparity; and (ii) interactions between patterns with shear or rotation disparity and superimposed or adjacent patterns or lines with zero disparity. Horizontal-shear disparity produced strong inclination which was enhanced by superimposed or adjacent zero-disparity stimuli. It produced little or no inclination contrast in superimposed or adjacent zero-disparity stimuli. Vertical-shear disparity produced inclination in the opposite direction (induced effect) which was reduced to near zero by a superimposed zero-disparity pattern. Adjacent vertical-shear and zero-disparity patterns appeared inclined at slightly different angles with a wide curved boundary. This suggests that vertical-shear disparities are averaged over a wide area. Rotation disparity produced minimal inclination. A superimposed or adjacent zero-disparity line appeared strongly inclined. A superimposed or adjacent zero-disparity pattern appeared vertical and caused the pattern with rotation disparity to appear inclined. Four mechanisms are proposed to account for the results: depth contrast, depth enhancement, deformation-disparity processing, and disparity transfer arising from cyclovergence.

The integration of binocular disparity, shading, and texture was measured for two different aspects of three-dimensional structure: (1) shape index, which is a measure of scale-independent structure, and (2) curvedness, which is a measure of scale-dependent structure. Binocular disparity was found to contribute significantly more to judged shape index than it does to judged curvedness, and shading and texture were both found to contribute more to judged curvedness than to judged shape index. These results demonstrate that different cues do not contribute equally to different aspects of perceived surface structure. This finding suggests that, for the case of linear integration, multiple cues to three-dimensional structure do not combine on the basis of a single type of representation shared by all the ‘shape-from-X’ processes in the visual system.

First steps of visual-information processing in primates are characterised by a highly ordered representation of the outside world on the cortex. Two prominent features of cortical organisation are the retinotopic mapping of position in the visual field on the first stages of the visual stream, and the systematic variation of orientation preference in the same areas. In an attempt to understand the relation of position and orientation representation, we need to know the minimum spatial requirements for orientation detection. In the present paper, the spatial limits for detecting orientation are analysed by simulating simple orientation filters and testing the ability of human observers to detect the orientation of small lines at various positions in the visual field. At sufficiently high contrast levels, the minimum physical length of a line to discriminate orientation differences of 45°–90° is not constant when presented at various eccentricities, but covaries inversely with the cortical magnification factor. In consequence, a line needs to correspond to about 0.2 mm of cortical surface, independently of the actual eccentricity at which the stimulus is presented, in order to allow observers to recognise its orientation. This has consequences for our understanding of orientation detection, (i) In combination with simulation experiments, it becomes clear that the elementary process underlying orientation detection is a local operation, which seems to focus on small regions compared with cortical receptive fields, (ii) With respect to the number of inputs to the visual cortex, the performance of this local operation approaches the physical limits, requiring hardly more than three-four input LGN axons to be activated for detecting the orientation of a highly visible line segment. Comparing these spatial characteristics with the receptive fields of orientation-sensitive neurons in the primate visual system could suggest new insights into the neuronal circuits underlying orientation mapping in the human cortex.

Two experiments are reported in which the decline or decrement in the magnitude of the Brentano Müller-Lyer illusion was measured. Observers made a pre-test judgment and, after a variable intervening time period, a post-test judgment of illusion magnitude. In experiment 1, the intervening time periods were 1, 2, and 3 min during which time the independent groups of observers allocated to each of the three time periods either systematically scanned the Brentano figure (inspection conditions) or waited until the intervening period had elapsed (no-inspection conditions). Experiment 2, which included an additional 5 min intervening time period, evaluated a response-bias explanation for the results of the inspection conditions of experiment 1. Taken together, the findings of the two experiments indicate that sheer inspection of the Brentano figure produces illusion decrement. However, illusion decrement was independent of the duration of the inspection period, with equivalent amounts of decrement occurring across the range of viewing times examined in the two experiments. The pattern of these results suggests that theories of Müller-Lyer decrement must incorporate a factor attributable to, or correlated with, inspection time, whose effect in reducing illusion magnitude is confined mainly to the first 1 or 2 min of active visual inspection of the Brentano illusion figure.

Theories of weight illusions have traditionally emphasised either the primary contribution of low-level sensory cues or the role of expectation based on knowledge and past experience. Current models of weight illusions lean quite strongly towards sensory-based interpretations. The current experiment raises a problem for such approaches by generating a weight illusion that is difficult to explain other than by the participants' knowledge. Golfers (who expect a weight difference between ball types) reliably judged practice golf balls to weigh more than real golf balls of the same weight. In contrast, non-golfers (who expect no weight difference between ball types) judged practice and real balls of equal weight to weigh the same. Furthermore, within the group of golfers, those who expected the weights of the two ball types to be the most discrepant prior to lifting tended to report the strongest illusions subsequent to lifting. Because there is no low-level sensory cue between ball types that on its own would signal a weight difference, the current finding suggests that there is a top-down component to weight perception that is based on experience with specific objects.

After viewing a blank region surrounded by a dynamic noise stimulus, viewers report the perception of prolonged dynamic twinkle in the unstimulated blank region. This twinkle aftereffect may be induced over long ranges in the visual field, up to 10° from the edge of the noise in central vision. Our previous studies of the properties of this aftereffect suggested mediation by the magnocellular processing system. We therefore evaluated the properties predicted by the magnocellular hypothesis by varying the coloring, the temporal and the spatial frequency of the stimulus. No aftereffect could be induced by an equiluminant color stimulus or by luminance noise below the temporal frequency of 5 Hz. The aftereffect obtained by luminance noise above 5 Hz was stronger for larger inducing elements. These results are consistent with known properties of the magnocellular processing system.

We investigated human cortical activity during four ‘effortless-pop-out’ visual search tasks with the use of magnetoencephalography. The search display, which was identical across all the tasks, consisted of vertical line segments, one of which was rotated abruptly 45° clockwise or counterclockwise. In the passive-viewing task the observers gave no response to the search display. In the target-detection task they responded to the onset of the target motion irrespective of its location and direction. In the target-localisation task the observers reported whether the line rotation appeared above or below the fixation point while ignoring the direction of the rotation. In contrast, in the target-identification task they indicated the direction of the line rotation, and the location of the rotation in the array was irrelevant. Cortical activity was recorded with a whole-scalp magnetometer while the observers were performing each task. In addition to the expected activation of the occipital and somatomotor cortical regions, two other active cortical areas were consistently identified in both hemispheres: one in the occipito-temporal area, probably corresponding to the motion-specific V5 complex, and another in the parieto-temporal region. The activation of the right occipito-temporal source depended on the task. The maximum amplitude was smallest for the passive viewing, increased for the detection task, and was largest for the localisation and identification.

The effects of different kinds of cues on the perception of second-order motion-defined animal shapes were assessed. In the first experiment discrimination thresholds for motion-defined animals without biological motion (non-BioM) were compared with motion-defined animals with biological motion (BioM). The results show no significant difference between the two conditions, suggesting that BioM does not interact with simple contour motion. In order to isolate the relative strength and interaction between the motion cues a second experiment was conducted where four conditions were used. The first condition consisted of animal contours with non-BioM, the second condition consisted of animal contours with BioM, the third condition was composed of dots present at the joints of the animals with non-BioM, and the fourth condition was composed of dots with BioM. In all cases the animal shapes traveled across the screen for a given number of frames. As in the first experiment, the results of the second study show no interaction between cues. Furthermore, the data show that the thresholds are similar whether BioM or contour cues are presented. The only condition which is significantly different is the condition without either contour or BioM cues. It is concluded that the form representation generated from these cues in motion-defined animal shapes consists of separate mechanisms which appear equally efficient for discrimination and which do not interact with one another.
