Liver biopsies are the main method in the diagnosis and treatment of paediatric liver pathologies. Major complication rates of paediatric liver biopsies range from 0% to 6.6% in the literature and minor complication rates range from 0% to 25%. In this study, we aimed to review the complications, indications and results of percutaneous core liver biopsies with paediatric sonography in a tertiary care centre by an interventional radiologist.

We retrospectively evaluated the results, indications and complications of paediatric liver biopsies performed in our tertiary health centre between January 2017 and December 2020. Biopsies were performed with a 16G semi-automatic needle in 17 patients (29.8%) and with an 18G semi-automatic needle in 40 patients (70.2%). Biopsies were performed only with local anaesthesia in patients older than 12 years; in younger patients, it was performed under general anaesthesia.

Fifty-eight liver biopsies were obtained from 57 children (34 males, 23 females). The most common indications were elevated liver enzymes (33 patients), cholestasis (14 patients), and adiposity and metabolic problems (6 patents). The most common pathological diagnoses were chronic hepatitis (33 patients) and steatosis (10 patients). Major complication in the form of symptomatic subcapsular haematoma developed after liver biopsy performed with 18G needle in only one patient (1.8%).

As previously stated in the literature, percutaneous biopsies performed by interventional radiologists in paediatric patients under the guidance of sonography can be used in diagnosis and treatment; the complication rate is low and it is a safe method.

Saving Babies’ Lives Care Bundle Version 2 highlights the importance of correct identification and reporting of echogenic bowel to improve maternal and newborn outcomes. Yet there is no national consensus to guide sonographers in identifying and reporting fetal echogenic bowel. This two-phase study aims to develop a national consensus to guide sonographers on the identification, classification and reporting of fetal echogenic bowel during the Fetal Anomaly Screening Programme (FASP) second trimester anomaly scan. Phase 1 results are presented capturing the national current practice of sonographers in its identification.

An online questionnaire survey was deployed to capture numerical and free text data. Data analysis was by descriptive statistics. Participants were recruited via social media and through professional networks and organisations.

A total of 95 participants completed the questionnaire during an 11-week period. Common practice across England included sonographers using a subjective method for identifying fetal echogenic bowel and making comparisons to fetal bone. However, there was wide variance in the fetal bone used and the transducer frequency typically used to assess bowel echogenicity. Confirmation of echogenic bowel was made at the 20-week scan in 58% of cases, 32% following fetal medicine department review with the remaining 10% unsure when confirmation occurred.

While there is common practice in identifying and report echogenic fetal bowel in some areas, there remains disparity within sonographer practice in England’s national screening service. This study allowed baseline data to be collated, providing the first steps towards development of guidance for sonographers in identifying and reporting this appearance.

Adenomyosis is histologically defined by the presence of endometrial glands and stroma in the myometrium. Ultrasound findings of adenomyosis are being redefined to better diagnose adenomyosis pre-operatively.

A single-centre retrospective study was performed at a regional hospital. The myometrial–cervical ratio was calculated on pre-operative ultrasounds, and histopathology reviewed for each case. Logistic regression was used to estimate the association between the myometrial–cervical ratio and adenomyosis confirmed on histopathology, and the area under the receiver operating characteristic curve was calculated. Comparisons were performed based on the presence of fibroids on ultrasound.

Complete data were available for 136 benign hysterectomies between 1 January 2015 and 31 December 2020. When the myometrial–cervical ratio was treated as a continuous variable in a logistic regression of adenomyosis on histopathology, there was no statistical evidence (χ²(1) < 0.01, p = 0.98) of an association. When cases including fibroids in the myometrial–cervical ratio were excluded, there was a non-significant association between myometrial–cervical ratio and adenomyosis on histopathology (odds ratio = 3.435, 95% confidence interval = 0.964, 12.235; χ²(1) = 3.62, p = 0.057); area under the receiver operating characteristic = 0.637 (95% confidence interval = 0.504, 0.770). The optimal myometrial–cervical ratio cutpoint was 1.875 (95% confidence interval = 1.698, 2.051), which achieved 71.43% sensitivity and 60.00% specificity. There was strong statistical evidence (χ²(1) = 9.02, p = 0.003) that the myometrial–cervical ratio outperformed standard pre-operative ultrasound identification of adenomyosis.

While accuracy remains suboptimal, the myometrial–cervical ratio outperformed standard ultrasound diagnostic features of adenomyosis in a regional setting. The myometrial–cervical ratio may offer a simple imaging measurement for adenomyosis in inexperienced hands when fibroids are absent.

Point-of-care ultrasound is becoming increasingly popular, and we sought to examine its role in evaluating ocular and periocular structures and facial vasculature. With the large number of point-of-care ultrasound devices available, it is difficult to determine which devices may be best suited for ophthalmic and facial aesthetic applications. This study compares five popular handheld point-of-care ultrasound devices to help guide clinicians in choosing the device best suited for their needs.

We compared five point-of-care ultrasound devices: Butterfly IQ+ (Butterfly, Burlington, MA), L15 (Clarius Mobile Health, Vancouver, British Columbia, Canada), L20 (Clarius Mobile Health, Vancouver, British Columbia, Canada), Lumify (Philips, Amsterdam, Netherlands) and Vscan Air (GE, Boston, MA). Three ophthalmologists obtained the following views on three volunteers: eight arteries, four ocular and periocular structures and areas of filler injections. The image quality of each view was graded on a four-point Likert-type scale. In addition, graders filled out a survey. The data were analysed using analysis of variance tests with the significance level set to p < 0.05.

In terms of overall image quality, the L20 received the highest mean rating, followed by the L15, Vscan Air, Butterfly IQ+ and the Lumify (p < 0.05). With further stratification for structure type, the L20 was ranked first for filler, artery and orbital imaging (p < 0.05).

The L20 received the highest image quality rankings. While image quality is an important aspect of point-of-care ultrasound device selection, other factors such as cost, wireless capabilities, range of presets and battery life should also be considered.

Patients with posterior knee swellings are commonly encountered in clinical practice with the vast majority referred for an ultrasound scan to assess for a clinically suspected Baker’s cyst.

Our aim was to determine the incidence of different pathologies in patients investigated for a posterior knee swelling of a clinically suspected Baker’s cyst using ultrasound. We also wanted to investigate the incidence of significant pathologies in the popliteal fossa to assess whether the ultrasound scan findings influenced patient management.

Retrospective analysis was performed on all patients who underwent an ultrasound scan for a suspected Baker’s cyst or posterior knee swelling at our institution, between January 2017 and December 2018. Patient demographics, ultrasound findings, further imaging investigations and histopathology were recorded. Patient records were followed up for a minimum period of 3 years after ultrasound.

A total of 680 patients had a posterior knee ultrasound scan. Of that, 51% (347/680) had a Baker’s cyst and 40% (273/680) had a normal ultrasound scan. Sixty (9%) patients had other abnormalities identified within the popliteal fossa. Four patients had significant findings on ultrasound that required a change of management. No malignancies identified.

This study confirms the high incidence of Baker’s cysts in patients presenting with a posterior knee swelling. In the absence of red flag symptoms, ultrasound of the posterior knee for a clinically suspected Baker’s cyst is of limited clinical value.

Intracranial atherosclerotic stenosis is a common cause of ischemic cerebrovascular events and is associated with a high risk of stroke recurrence. This study aimed to assess the diagnostic accuracy of transcranial color-coded duplex sonography for moderate-to-severe middle cerebral artery stenosis in stroke patients.

A retrospective analysis was carried out, including 31 patients aged ⩾18 years hospitalized for ischemic cerebrovascular event in whom middle cerebral artery stenosis ⩾30% was identified on computed tomography angiography. Transcranial color-coded duplex sonography findings were compared to the degree of stenosis blindly identified on the computed tomography angiography used as the reference method.

Overall, 27 patients had M1 stenosis and the other 4 had M2 stenosis. To detect M2 stenosis ⩾ 50% and ⩾ 70%, stenotic to pre-stenotic ratio ⩾ 2 and ⩾ 3 had a sensitivity of 100%, respectively. To detect M1 stenosis ⩾ 70%, peak systolic velocity ⩾ 300 cm/s had a sensitivity of 53.8% and specificity of 85.7% with area under the receiver-operating characteristic curve of 0.753 (95% confidence interval: 0.568–0.938; p  =  0.026), and stenotic to pre-stenotic ratio ⩾ 3 had a sensitivity of 84.6% and a specificity of 78.6% (area under the curve = 0.854; 95% confidence interval: 0.707–1; p  =  0.002). Middle cerebral artery/anterior cerebral artery velocity ratio < 0.7 had a sensitivity of 57.1% and specificity of 90% to detect dampened pre-stenotic flow in middle cerebral artery secondary to downstream M1 stenosis ⩾ 70% (area under the curve = 0.800; 95% confidence interval: 0.584–1; p = 0.040).

This study showed that stenotic to pre-stenotic ratio ⩾ 3 was more sensitive than peak systolic velocity ⩾ 300 cm/s to screen M1 stenosis ⩾ 70%. Middle cerebral artery/anterior cerebral artery ratio < 0.7 was a good indirect sign to detect dampened pre-stenotic flow due to M1 stenosis ⩾ 70%.

This study investigated the depth-related bias and the influence of scan plane angle on performance of point-shear-wave elastometry in a chronic hepatitis C patient cohort.

We included 104 patients affected by chronic liver disease related to the hepatitis C virus. Liver surface nodularity was the reference to diagnose cirrhosis. The ultrasound platform was the Siemens S2000, equipped with point-shear-wave elastometry software. Measurements were obtained in left lateral decubitus from the liver surface to the maximum depth of 8 cm in two orthogonal scan planes according to a standard sampling plane. Scatterplot and box plots explored the depth-related bias graphically. The area under the receiver operating characteristic was used to determine the point-shear-wave elastometry diagnostic performance at progressive depths according to liver surface nodularity.

Of the 104 patients, 68 were cirrhotics. Depth-related bias equally modified point-shear-wave elastometry in the two orthogonal scan planes. A better point-shear-wave elastometry diagnostic performance was observed between depths of 4 and 5 cm. The frontal scan plane assured better discrimination between cirrhotic patients and non-cirrhotic patients.

Depth is crucial for point-shear-wave elastometry performance. Excellent diagnostic performance at a depth between 4 and 5 cm can also be obtained with a smaller number of measurements than previously recommended.

Cavernous haemangioma is the most common benign non-infiltrative neoplasm of the orbit. Most cavernous haemangiomas are intraconal and lateral in location.

We present a rare case of a cavernous haemangioma with an unusual location in the supraorbital region of the orbit, presenting with soft tissue swelling.

Cavernous haemangiomas are the most common benign non-infiltrative neoplasms of the orbit and have a slowly progressive mass effect. A slowly progressive proptosis is the typical presenting symptom. Extraocular muscle impairment and impaired visual function are seen with large lesions and with lesions located at the orbital apex. Most cavernous haemangiomas are typically intraconal and lateral in location. Extraconal and medial locations are uncommon. Ultrasound, computed tomography and magnetic resonance imaging are useful imaging techniques for the evaluation of such tumours. Treatment of the tumour is surgical excision. Complete excision is generally accomplished as the tumour is well-encapsulated with relatively few feeding vessels.

Hepatic portal venous gas is a rare and life-threatening condition characterised by the presence of gas in the portal vein. Hepatic portal venous gas is frequently associated with intestinal ischaemia and necrosis. We present the case of a paediatric patient with acute appendicitis with hepatic portal venous gas detected using ultrasonography.

A 5-year-old boy was admitted to our hospital with a respiratory tract infection. The boy started vomiting on day 2 of hospitalisation. He did not complain of any symptoms due to developmental retardation. We performed bedside point-of-care ultrasound, which detected hepatic portal venous gas, although the appendix could not be detected due to an acoustic shadow associated with bowel gas. Contrast-enhanced computed tomography revealed perforated appendicitis and pneumatosis intestinalis associated with paralytic ileus. An emergency laparoscopic appendectomy was performed. He was discharged on day 25 of hospitalisation after antibiotic therapy.

The present case suggests that the mechanism of hepatic portal venous gas was paralytic ileus, which caused gas-forming bacterial proliferation. The gas produced by bacteria and/or the gas-forming bacteria entered the bowel wall, which caused pneumatosis intestinalis. The bubbles in the intestinal wall floated in the portal system and were detected as hepatic portal venous gas. Perforated appendicitis and paralytic ileus seemed to be caused by a delayed diagnosis of appendicitis. The point-of-care ultrasound examination was useful for detecting hepatic portal venous gas and for helping establish the diagnosis of appendicitis.

Hepatic portal venous gas is a rare finding associated with appendicitis in children. In addition, point-of-care ultrasound is useful for detecting hepatic portal venous gas in paediatric patients.
