Minimal Consequences of CMAH and DBA/2 Backgrounds on a FKRP Deficient Model

ABBREVIATIONS

CMAH

cytidine monophosphate-sialic acid hydroxylase

INTRODUCTION

Muscular dystrophies (MD) are a large group of genetic diseases due to mutations affecting muscle functions. The most frequent forms of the disease include the relatively frequent Duchenne muscular dystrophy (DMD) and the genetically heterogeneous group of limb-girdle muscular dystrophies (LGMD). In these pathologies, the primary genetic default causes a myofiber degeneration that triggers a regenerative and inflammatory response. With the evolution of the disease, a replacement of myofibers by fibrotic and/or fat tissue occurs, leading to progressive muscle weakness [1]. The severity of the clinical presentation is variable between the different MD, but also between patients affected by the same form according to factors such as the type of mutations or additional genetic modifiers. In particular, transcriptome and genome profiling led to the identification of variants in SPP1, ANXA6, CD40 or Growth Hormone and its receptor (GH/GHR) as modifiers which can alter strength and ambulation in patients affected by DMD [2–4]. An interesting genetic study performed on γ-sarcoglycan null mice, a model of Limb-Girdle Muscular Dystrophy 2C (LGMD2C), identified a polymorphism of Latent TGFβ Binding Protein 4 (LTBP4), specific of the DBA/2 background, which leads to an exacerbated phenotype [5]. This observation led to the demonstration that single nucleotide polymorphisms in the LTBP4 gene were associated with an earlier loss of ambulation in DMD patients [3]. The implication of LTBP4 was also confirmed to worsen the phenotype of the mdx mouse, a mouse model carrying a stop mutation in the DMD gene, when backcrossed on the DBA/2 background [6–8]. In another study, the comparison of activated/inactivated genes present in Human and mouse led to the identification of the cytidine monophosphate-sialic acid hydroxylase (CMAH) as a potential modifier of DMD. During evolution, this gene has been inactivated in Human, but not in mouse. It was hypothesized that this genetic loss could explain why the consequences of dystrophin mutation are more severe in Human than in the mouse species. Consequently, the mdx mutation was evaluated on a Cmah^-/- background, resulting in a modified glycome and muscle alteration closer to the human clinical presentation [9].

The dystrophic process was previously described to be modulated by disrupting the Cmah gene or by introducing dystrophy mutations into the DBA/2 background. In this study, we sought to investigate whether these backgrounds could also worsen a milder phenotype such as the one observed in a mouse model of LGMD2I (LGMD-R9 according to the new nomenclature [10]). LGMD2I is the less severe presentation associated with defects in Fukutin-related protein (FKRP) which can also lead to more severe pathologies like Walker Warburg Syndrome (WWS), Muscle Eye Brain (MEB) disease or Congenital Muscular Dystrophy (MDC1C) [11, 12]. Comparison of the dystrophic presentation in different mouse models for LGMD2I [13–17] showed that the nature of the mutation and FKRP expression level were critical for the phenotype severity [14]. However, no study has been performed to describe the effect of genetic backgrounds in any of these models. Therefore, we investigated, in a side by side study, the consequences of the reduced activity of LTBP4 [18] and of the inactivation of CMAH on dystrophic features using a knock-in model of LGMD type 2I [FKRP^L276I] [16], together with the severe mdx model previously investigated. The FKRP^L276I model carries a L276I missense mutation which corresponds to the most frequent mutation observed in patients [16]. The evaluation of the models after backcrossing onto the DBA/2 and Cmah^-/- backgrounds led to the observation that the DBA/2 background has no observable effect on FKRP^L276I mouse phenotype, although some changes are present at molecular level. The Cmah^-/- background has virtually no effect on the FKRP^L276I mouse and an effect on the regeneration level in the mdx mice. Altogether, CMAH and LTBP4 deficiency did not further worsen the FKRP phenotype in the limb and respiratory muscles, and adding these alleles did not provide more relevant animal model for the pathophysiological characterisation of FKRP deficiency.

MATERIALS AND METHODS

RESULTS

The FKRP^L276I mouse, a model for LGMD2I, was modified in two ways: either by backcrossing onto the DBA/2 mouse strain, or by crossing with the Cmah^-/- strain and selecting individuals carrying both mutations. The strains B10.Cg-Cmah^tm1Avrk Dmd ^mdx /PtmJ (Cmah^-/--mdx) and D2.B10-Dmdmdx/J (DBA/2-mdx), two models carrying the mdx mutation and for which the effect of these two modifiers has already been reported [6–9], were used in parallel. The double-homozygous animals were then evaluated at an age at which dystrophic signs are well established for the parental dystrophic models and using muscles evaluated in previous studies [16, 21]. It is worth pointing out that neither DBA/2 nor Cmah^-/- mice presented dystrophic signs at the corresponding ages ( Figure S1 ).

The FKRP^L276I mouse model is a mildly affected model. Therefore, we evaluated the consequences of the backcrossing on DBA/2-FKRP^L276I and Cmah^-/--FKRP^L276I at 6 months of age. At this age, the parental mouse model is described to present a mild dystrophic phenotype, with centronucleation observed only in proximal muscles as psoas and gluteus [16] but not in distal muscles as tibialis anterior. In line with this description, centronucleated fibers were observed in psoas but not in tibialis anterior. In addition, small areas of fibrosis and adipocytes were observed in diaphragm (Fig. 1A). No aggravation sign was noticeable in neither of the two crossings in these three muscles (Fig. 1A). According to the disease evolution, the DBA/2-mdx and Cmah^-/--mdx models were observed earlier than the FKRP^L276I models, at the age of 2.5 months. At this age, the mdx mouse presents an important level of centronucleated fibers (nearly 100% of the fibers) but the phenotype has not yet evolved towards fibrosis and adipogenesis. Histological stainings of different muscles from DBA/2-mdx mice (tibialis anterior, quadriceps and diaphragm), highlighted large areas of degeneration overspread by fibrosis and inflammatory cells and even calcification (Fig. 1B). For Cmah^-/--mdx mice, no change was observed at the histological level at that age (Fig. 1A).

OPEN IN VIEWER

Fig. 1

Histological characterization of FKRP and dystrophin deficient mouse models. A. Hematoxylin-phloxine-saffron stained muscle sections of psoas (Pso), tibialis anterior (TA) and diaphragm (Dia) of FKRP-deficient models. B. Hematoxylin-phloxine-saffron stained muscle sections of quadriceps (Qua), tibialis anterior (TA) and diaphragm (Dia) of dystrophin-deficient models. As an example, centronucleated fibers, fibrosis and inflammation are indicated respectively by arrow, asterisk and head arrow. Size bars: 50μm.

In order to quantitatively compare the dystrophic impairment depending on the genetic backgrounds, we measured the expression of genes selected as markers of the different features of the dystrophic process, namely degeneration/regeneration, inflammation and fibrosis. For each of these characteristics, both a coding gene and a non-coding gene were quantified (Fig. 2 and Table S1 for individual data).

Regeneration was first assessed, using the quantification of the Mymk gene, coding for myomaker, a factor involved in myoblast fusion [22], and the micro-RNA miR-31, expressed in proliferating myoblasts [23]. In the FKRP^L276I mouse models, an increase was observed for the DBA/2 background, which was not observed at the histological level, reaching significance for Mymk in psoas and tibialis anterior (respectively 4.8-fold increase and 6.9-fold increase) and for miR-31 in tibialis anterior (5-fold increase) whereas there was no difference in the expression of the markers for the Cmah^-/- strain. In the mdx models, the expression of both genes was elevated compared to WT counterparts, which is in accordance with the high level of regeneration in all three genetic backgrounds, as shown above by the important number of centronucleated fibers. The crossing with the DBA/2 background did not induce an overall change in the regenerative markers. In contrast, the crossing with the Cmah^-/- strain seemed to increase regeneration, since Mymk and miR-31 were found significantly elevated in most muscles with this background, compared to the parental mdx model. The increase can be observed in quadriceps (1.9-fold increase) and in diaphragm (3.7-fold increase) for Mymk, and in quadriceps (3.8-fold increase) and in tibialis anterior (9.5-fold increase) for miR-31 (Fig. 2).

OPEN IN VIEWER

Fig. 2

Quantitative evaluation of dystrophic impairment in deficient mouse models. Levels of expression of regeneration, inflammation and fibrosis-related genes in the FKRP and dystrophin deficient mouse models were measured by RT-qPCR. Data were normalized with data from wild-type (C57BL/6 or C57BL/10, DBA/2, Cmah^–/–) samples. Statistical analyses were performed versus FKRP^L276I (FKRP-deficient model) or mdx (dystrophin-deficient model). (*) for P < 0.05, (**) for P < 0.01 and (***) for P < 0.001.

The effect of the backcrossing on inflammation was evaluated using the quantification of gene expression of Cd11b, a macrophage marker, and miR-142.3p, which is expressed in all cells of hematopoietic origin [24]. For both FKRP^L276I and mdx models, the crossing with DBA/2 background induced an increase of both Cd11b and miR-142.3p expression, which was more pronounced in the DBA/2-mdx strain. This was correlated with the presence of inflammatory cells positive for CD11b staining in the corresponding sections (data not shown). In FKRP^L276I model, the increase was only observed in tibialis anterior (3.0-fold increase for Cd11b and 4.5-fold increase for miR-142.3p) (Fig. 2). In the mdx model, there was a general increase of the markers in all muscles (from 2.5 to 9-fold increase for Cd11b and 4.2 to 12.0-fold increase for miR-142.3p). The Cmah^-/- background had no impact on the expression level of these two genes in any of the models.

The levels of expression of fibronectin 1 (FN1), a component of the extracellular matrix [25], and of miR-21, a positive regulator of TGFβ pathway [26], were used for fibrosis assessment. In FKRP^L276I mice, the switch to any of the two backgrounds had a similar effect with an increased expression of Fn1 in the tibialis anterior (1.4 and 2.2-fold increase with DBA/2 and Cmah^-/- backgrounds, respectively) and no significant difference for miR-21 expression. Surprisingly, an important increase of the level of Fn1 was observed in the diaphragm for the DBA/2 background (123-fold increase). For DBA/2-mdx mice, Fn1 expression was increased in all the observed muscles (3.7 to 5.9-fold increase), which was correlated with an increase of miR-21 expression in quadriceps and in tibialis anterior (respectively 3.0 and 14.6-fold increase), but not in diaphragm where it was decreased. The Cmah^-/- background had no effect on the expression of the two marker genes in all muscles but the diaphragm where miR-21 was decreased (Fig. 2). Thus, the DBA/2 background seems to have a more important effect on fibrosis than the Cmah^-/- background in a severe model as mdx mouse and in diaphragm tissue of the mildly affected FKRP^L276I model.

DISCUSSION

In this study, we investigated the hypothesis that known modifiers of the presentation of dystrophin deficiency could also worsen a milder phenotype such as the FKRP^L276I model by crossing this model with two mouse strains harbouring mutations in modifier genes described to exacerbate MD. In addition to the histological assessment, our analysis of the influence of the genetic modifiers was defined molecularly using quantification of expression of specific genes. Thanks to this analysis, we were able to detect precocious dystrophic features by quantitative PCR that were not visible by histological observation. We also observed that the dystrophic process present in the diaphragm is different from the pattern observed in limb muscles and therefore may call for specific makers for this muscle.

Overall, we showed that the DBA/2 background has a weak effect on FKRP^L276I mouse phenotype and the Cmah knock-out has none. It is noteworthy that the DBA/2 background induces an important increase of the expression level of Fn1, a component of the extracellular matrix. although no fibrosis deposit was observed at the histological level. In addition, we observed that the worsening of the phenotype observed in the severe mdx mouse model on the DBA/2 or Cmah^-/- backgrounds originates from different modulated pathways. The DBA/2 background is associated with an elevated inflammation and fibrotic tissue replacement, while the Cmah^-/- background leads to an increase of the regeneration process in most of the mdx muscles compared to the C57BL/10 background. This interesting association with the regeneration process sheds a new light on the influence of this background on the dystrophic phenotype.

The DBA/2 genetic background is characterized by a partial loss-of-function of LTBP4 [18], a protein participating in the control of the TGFβ signalling. TGFβ1, acting via the Smad2/3/4 pathway, induces the expression of genes coding for extracellular matrix (ECM) components and enzymes inhibiting ECM degradation [27]. This pathway is crucial for muscle repair in case of tissue damages but its over-activation leads to an excessive ECM deposition and fibrosis. TGFβ also stimulates the inflammatory response by acting as a potent chemoattractant for immune cells [28]. The consequences of the impaired function of DBA/2 LTBP4 mutation corresponds more to a lack of control of the TGFβ signaling rather than a hyperactivity per se. This context is thus consistent with the observed consequences: a worsening in an inflammatory context in the mdx animals, an absence of consequence in WT and a minimal effect in skeletal muscles of FKRP-deficient model. In the diaphragm of DBA/2-FKRP^L276I mice, the increase of the Fn1 expression and the absence of large fibrosis areas at the histological level could indicate that a compensatory mechanism counterbalances this increase of expression and inhibit fibrosis deposit. Fn1 gene is thereby not the best marker to assess fibrosis in the diaphragm. Of note, the mdx muscles in the DBA/2 background present an important level of calcification which is also in line with the role of TGFβ in heterotopic ossification [29, 30].

Interestingly and in contrast to the DBA/2 background, the biomarker analysis pinpointed that Cmah deficiency has an aggravating effect mainly on the regeneration process in mdx mice only. CMAH is the only enzyme known to synthesize Neu5Gc from Neu5Ac, both being the major kind of sialic acids present at the surface of all mammalian cells, including myofibers and satellite cells [31]. Sialic acids play a role in cell-cell and cell-ECM interactions, notably in the adhesion of cells to ECM and in cell migration [32, 33]. The mechanism by which the modification of sialylation at the membrane may influence regeneration is not known. However, it can be hypothesized that some phenomena such as quiescence of the satellite cells or fusion of these cells to the fibers could be impacted by the sialylation of the involved molecules. One can cite as examples of such candidate molecules the calcitonin receptor for the quiescence in the niche [34, 35] or Neural Cell Adhesion Molecule (NCAM) for the fusion [36, 37]. Interestingly, it was observed that, in the absence of Neu5Gc, the binding of α-dystroglycan to its ECM ligands laminin and agrin was decreased, and this was proposed as a mechanism contributing to the more severe phenotype observed with Cmah inactivation [9]. Since, in FKRP-deficient models, the binding of α-dystroglycan with its ECM partners is already compromised, the lack of worsening of the phenotype would be consistent with this mechanism [9]. This point of the study would call for further investigations.

In conclusion, we showed an interesting association of the CMAH modifier with the regeneration process in the mdx model, shedding a new light on the influence of this protein on the dystrophic phenotype. We also showed that none of the two modifiers impacted the severity of the presentation in the FKRP^L276I model. A potential limitation of our study relates to the low number of animals used, i.e. 4 mice per group. Nevertheless, while increasing the number of animals could have allowed detection of more subtle differences at the level of the biomarker analysis, the inter-individual homogeneity observed at the level of muscle histology supports the claims of lack of consequences of the changes of background for FKRP deficiency. Another limitation is the absence of functional tests to evaluate the difference between animals in term of muscle force. Since usually the force is tightly correlated with the histological aspects in muscular dystrophies, it is likely that such analysis would have led to the same conclusion. Finally, it can be postulated that the absence of impact on the severity of the presentation in the FKRP^L276I model is possibly due to the mechanism of action of the modifiers. The choice of the genetic background to worsen a phenotype or to evaluate a specific treatment should be selected according to the features of interest and according to the modifier genes involved.
