International Journal of Aeroacoustics

An accurate triangular spectral element method (TSEM) is developed to simulate acoustic problems in complex computational domains. With Fekete points and Koornwinder-Dubiner polynomials introduced, triangular elements are used in the present method to substitute quadrilateral elements in traditional spectral element method (SEM). The efficiency of discretizing complex geometry is enhanced while high accuracy of SEM is remained. The weak form of the second-order governing equations derived from the linearized Euler equations (LEEs) are solved, and perfectly matched layer (PML) boundary condition is implemented. Three benchmark problems with analytical solutions are employed to testify the exponential convergence rate, convenient implementation of solid wall boundary condition and capable discretization in complex geometries of the present method respectively. An application on Helmholtz resonator (HR) is presented as well to demonstrate the possibility of using the present method in practical engineering. The numerical resonance frequency of HR reaches an excellent agreement with the theoretical result.

This paper deals with the topic of upper surface blowing noise. Using a model-scale rectangular nozzle of an aspect ratio of 10 and a sharp trailing edge, detailed noise contours were acquired with and without a subsonic jet blowing over a flat surface to determine the noise source location as a function of frequency. Additionally, velocity scaling of the upper surface blowing noise was carried out. It was found that the upper surface blowing increases the noise significantly. This is a result of both the trailing edge noise and turbulence downstream of the trailing edge, referred to as wake noise in the paper. It was found that low-frequency noise with a peak Strouhal number of 0.02 originates from the trailing edge whereas the high-frequency noise with the peak in the vicinity of Strouhal number of 0.2 originates near the nozzle exit. Low frequency (low Strouhal number) follows a velocity scaling corresponding to a dipole source where as the high Strouhal numbers as quadrupole sources. The culmination of these two effects is a cardioid-shaped directivity pattern. On the shielded side, the most dominant noise sources were at the trailing edge and in the near wake. The trailing edge mounting geometry also created anomalous acoustic diffraction indicating that not only is the geometry of the edge itself important, but also all geometry near the trailing edge.

The focus of this work is on understanding the effect of water injection from the launch pad on the noise generated during rocket’s lift-off. To simplify the problem, we consider a supersonic jet impinging on a flat plate with water injection from the impingement plate. The Volume of Fluid model is adopted in this work to simulate the two-phase flow. A Hybrid Large Eddy Simulation – Unsteady Reynolds Averaged Simulation approach is employed to model turbulence, wherein Unsteady Reynolds Averaged Simulation is used near the walls, and Large Eddy Simulation is used elsewhere in the computational domain. The numerical issues associated with simulating the noise of two-phase supersonic flow are addressed. The pressure fluctuations on the impingement plate obtained from numerical simulations agree well with the experimental data. Furthermore, the predicted effect of water injection on the far-field broadband noise is consistent with that of the experiment. The possible mechanisms for noise reduction by water injection are discussed.

This work provides an experimental investigation into the interaction between a jet flow and a semi-finite plate parallel to the jet. Wall pressure fluctuations have been measured in a high compressible subsonic regime and for different distances between the jet and the plate trailing edge. The experiment has been carried out in the ISVR anechoic Doak Laboratory at the University of Southampton, using wall pressure transducers flush mounted on the plate surface. Signals were acquired in the stream-wise direction along the jet centreline and in the span-wise direction in a region close to the trailing edge. The radial position of the flat plate was fixed very close to the jet axis to simulate a realistic jet–wing configuration. The plate was moved axially in order to investigate four different jet-trailing edge distances and to include measurements upstream of the nozzle exhaust. The acquired database was analyzed in both the frequency and the time domains providing an extensive statistical characterization in terms of spectral uni– and multi–variate quantities as well as high order statistical moments. A wavelet analysis was performed as well to investigate the time evolution of the wall pressure events.

The objective of this work is to investigate the effect of the porous trailing edge on the aeroacoustics performance of the NACA 65(12)-10 aerofoil. The motivation behind this study is to investigate the effect of the porous parameters to explore the noise control concepts. Experimental testing in an aeroacoustics open jet wind tunnel was performed at chord-based Reynolds numbers between 0.2 and 0.6 million, and effective angles of attack at ±1.7 degree, including at 0 degrees. The porous trailing edge at porosity 30% with different holes diameters and the length of these porous trailing edges are used in the acoustic experiments. The study reveals that the level of the reduction of the broadband noise becomes larger as the diameter of the holes decreases and the length of the porous trailing edge increases at lower Reynolds numbers. Bluntness-induced tone noise is produced at high Reynolds number. Meanwhile, the porous trailing edge can suppress the laminar instability noise at the middle and low frequency regions.
