Perception

Three experiments are reported in which it is tested whether the Gestalt effect of configural orientation on shape perception operates on two-dimensional (2-D) or three-dimensional (3-D) representations of space. It is known that gravitationally defined squares and diamonds take longer to discriminate in diagonal arrays than in horizontal or vertical arrays. In the first experiment it is shown that this interference effect decreases dramatically in magnitude when pictorial depth information is added so that subjects perceive the target shapes in different depth planes. In the second experiment this difference is shown not to be due to relative size of the target shapes or to occlusion of a background plane. It is also shown, in the final experiment, that this difference is not due to linear perspective information or merely to perception of the target figures in a 3-D scene. The overall pattern of results supports the position that this configural reference frame effect arises primarily when the elements of the configuration are coplanar, and that the principal organization underlying it is the structure of the perceived 3-D environment rather than that of the 2-D image. In all three experiments, however, there is also a small interference effect in the noncoplanar 3-D conditions. This might be due either to some aspect of reference frame selection operating on the 2-D image representation or to the failure of subjects to see depth in the 3-D stimuli on some proportion of the trials.

Four experiments in which logarithmic intervals between 25 and 1600 ms were used for stimulus duration in tests for the tilt illusion are reported. It is demonstrated that the direct and the indirect tilt illusions both increase in magnitude inversely with length of stimulus presentation. The data suggest that whereas the direct effect peaks with a value of about +7° at the shortest flash duration used (25 ms), peak indirect effects (of about +2°) do not occur at this duration. In addition, whereas direct effects level out after 100 ms stimulus exposure times, to the usual magnitude obtained with long presentations (about + 2°), indirect effects reach their standard magnitude (−0.5° to −1.0°) later, at exposures of about 400 ms. Even at very short flash durations, a luminance square frame surrounding the illusion display reduces the indirect effect by two thirds of its magnitude but has no effect at all on the direct effect. It is suggested that direct effects arise early in visual processing, in area V1, where there are transient mechanisms and where corruption of orientation analysis by the inducing grating would occur prior to later, extrastriate, global analysis of the surrounding peripheral frame. Indirect effects, on the other hand, may arise later, along the sustained parvocellular colour—form pathway, where more global processing occurs and susceptibility to surrounding fields might be expected.

An asymmetric model is described for interactions in the perception of two dimensions (length and orientation) of a single visual stimulus. Two methods were used to test these interactions, and models for the interpretation of the possible outcomes of these tests are discussed. A length discrimination task showed facilitation (decreased reaction time) when orientation was covaried with length, and interference (increased reaction time) when random orientation variation was introduced. A smaller effect was seen when length was varied in an orientation discrimination task in a correlated or random fashion. Analysis of sequential effects showed that reaction times are fastest on repetition trials and are slowed by either the need to change the response or the need for additional sensory processing. With the second method, it was found that the amount of information transmitted in the estimation of orientation was not affected by the introduction of the redundant dimension of length, but that there was a significant gain in the amount of information transmitted in the estimation of length by the addition of the redundant dimension of orientation. It is concluded that orientation is probably a perceptual primitive of the visual system whereas length is a computed variable.

The Fourier descriptor (FD) method of shape representation provides a convenient description for the outlines of shapes. It can also be used to generate orthogonal patterns (FD stimuli) which are uniquely characterized by their frequency, amplitude, and phase. Psychophysical studies were conducted to assess threshold tuning properties and frequency specificity during adaptation to FD stimuli. The results suggest the operation of filters which are characterized by the parameter ‘curvature frequency’.

Possible transient-system deficiencies in subjects with specific reading disabilities (SRDs) were investigated in groups of 13-year-old SRDs and control normal readers. In experiment 1, in which a 6 Hz uniform-field flicker (UFF) mask and a stationary test stimulus were used, it was found that the overall effect of UFF masking was to reduce differences in contrast sensitivity between SRDs and normal readers. In experiments 2a and 2b, with UFF masks of 6 and 20 Hz and a 6 Hz moving (experiment 2a) or flickering (experiment 2b) test stimulus, contrast sensitivity in both groups was decreased in the presence of the 6 Hz UFF mask. Only the control group, however, showed a further decrease in sensitivity with the 20 Hz UFF mask. This indicates that the groups differ in terms of a mechanism sensitive to high temporal frequencies. A 20 Hz counterphase flickering test stimulus was used in experiment 3 in the presence of 6 Hz UFF, and it was found that SRDs are less sensitive than controls to 20 Hz flicker across all spatial frequencies used. The 6 Hz mask, however, did not differentially affect the two groups. These findings provide further evidence for a transient-system deficit in the visual systems of SRDs, but also suggest a more complex situation by showing that the two groups differ in a high-temporal-frequency mechanism.

The behavior of a neural network model for binocular rivalry is explored through the development of an analogy between it and an electronic astable multivibrator circuit. The model incorporates reciprocal feedback inhibition between signals from the left and the right eyes prior to binocular convergence. The strength of inhibitory coupling determines whether the system undergoes rivalrous oscillations or remains in stable fusion: strong coupling leads to oscillations, weak coupling to fusion. This implies that correlation between spatial patterns presented to the two eyes can affect the strength of binocular inhibition. Finally, computer simulations are presented which show that a reciprocal inhibition model can reproduce the stochastic behavior of rivalry. The model described is a counterexample to claims that reciprocal inhibition models as a class cannot exhibit many of the experimentally observed properties of rivalry.

One-dimensional arrangements of dots immediately group into contours. It is reported that, when these contours participate in certain larger arrangements, there is an abrupt point at which the percept changes as a function of dot spacing (or density along the contour). Closely spaced arrangements give rise to subjective effects involving apparent brightness and depth, whereas sparsely spaced ones do not. The effects are most clear in configurations that involve endpoints and possible occlusions. For these configurations, densely dotted contours are perceptually equivalent to solid ones, but sparse ones are not. This change in percept occurs abruptly and consistently at a dot to space ratio of 1:5, when the dot density is normalized by dot size, and this point is called the size/spacing constraint. It holds only for dots of the order of 1 min visual angle in diameter when small to modest contrast values are used. The subjective effects are not present for dotted contours (or even for solid ones) that are smaller (<0.5 min), and differ for contours that are larger (> 10 min). To demonstrate the significance of size/spacing constraints for early vision, a framework for grouping consisting of processes at many different levels is outlined, and the requirements for the earliest one (orientation selection) are sketched in greater detail. The size/spacing constraint follows directly from one of these requirements—receptive field structure—and seems to indicate a switch from early orientation-selection processes to later ones.

Task materials were devised which allowed two different explanations of the Piagetian water-level task to be distinguished. Two experiments are reported with 5–6 and 7–8 year olds in which both a predictive and a perceptual task were used. The results support Ibbotson and Bryant's explanation that the performance of young children is affected by a perpendicular bias. This effect was weaker, particularly among 7–8 year olds, in the perceptual task.

Random-dot techniques were used to examine the interactions between the depth cues of dynamic occlusion and motion parallax in the perception of three-dimensional (3-D) structures, in two different situations: (a) when an observer moved laterally with respect to a rigid 3-D structure, and (b) when surfaces at different distances moved with respect to a stationary observer. In condition (a), the extent of accretion/deletion (dynamic occlusion) and the amount of relative motion (motion parallax) were both linked to the motion of the observer. When the two cues specified opposite, and therefore contradictory, depth orders, the perceived order in depth of the simulated surfaces was dependent on the magnitude of the depth separation. For small depth separations, motion parallax determined the perceived order, whereas for large separations it was determined by dynamic occlusion. In condition (b), where the motion parallax cues for depth order were inherently ambiguous, depth order was determined principally by the unambiguous occlusion information.

How does the pattern of eye fixation vary as an informative part of a word is encountered? If the processing of information lags behind the movement of the eyes, then we should expect no variation in the pattern; but if processing is immediate, then the movements of the reader's eyes should correspond to the distribution of information being inspected. An experiment is reported which examined the ways that the text ahead of the point of current fixation can be used to guide the eyes to future fixations, by monitoring fixations during a sentence comprehension task. The patterns of eye fixations upon words with uneven distributions of information (where, for example, words predictable from the sight of their first few letters but not from their last few letters are defined as containing informative beginnings) were observed, and it was found that more and longer fixations were produced when subjects looked at the informative parts of words, particularly at the informative endings of words. The results support the suggestion that eye movements are under the moment-to-moment control of cognitive mechanisms.
