Perceived difference in depth between two adjacent stimuli decreases with increasing disparity gradient even if the disparity stays constant, ie when the stimuli approach each other along paths within fronto-parallel planes. This depth scaling effect is more pronounced with line stimuli than with two isolated points or two small symbols and is insignificant for easily discriminable symbols. The decrease in perceived depth is more pronounced for horizontal orientation than for oblique or vertical orientation. The ratio of perceived depth difference to displayed disparity difference also decreases when the distance between the stimuli increases at a constant gradient in depth. This is to say that we are more correct in our depth estimates for steep gradients in depth when the euclidean distance between the stimuli is short.

Moving phantom visibility was measured in two experiments where the global figure-ground and depth relations within phantom-inducing patterns were manipulated. The local inducing environment where the illusion occurred was identical for all patterns. Phantom visibility was significantly reduced when occlusion cues specified the phantom-inducing parts of a pattern as ground. These results suggest conflicting figure – ground and depth information interferes with the representation and perception of phantoms as figure regions.

Subjects attempted to recognize simple line drawings of common objects using either touch or vision. In the touch condition, subjects explored raised line drawings using the distal pad of the index finger or the distal pads both of the index and of the middle fingers. In the visual condition, a computer-driven display was used to simulate tactual exploration. By moving an electronic pen over a digitizing tablet, the subject could explore a line drawing stored in memory; on the display screen a portion of the drawing appeared to move behind a stationary aperture, in concert with the movement of the pen. This aperture was varied in width, thus simulating the use of one or two fingers. In terms of average recognition accuracy and average response latency, recognition performance was virtually the same in the one-finger touch condition and the simulated one-finger vision condition. Visual recognition performance improved considerably when the visual field size was doubled (simulating two fingers), but tactual performance showed little improvement, suggesting that the effective tactual field of view for this task is approximately equal to one finger pad. This latter result agrees with other reports in the literature indicating that integration of two-dimensional pattern information extending over multiple fingers on the same hand is quite poor. The near equivalence of tactual picture perception and narrow-field vision suggests that the difficulties of tactual picture recognition must be largely due to the narrowness of the effective field of view.

One mechanism frequently proposed for the creation of subjective contours and their related brightness effects involves lateral neural interactions on the retina, such as the lateral inhibitory effects that underlie brightness contrast. Subjective contour stimuli were displayed under an intermittent light source, with rapid onset and slow offset as has been shown to increase lateral inhibitory interactions by allowing summation of neural onset transients. A sample of forty subjects, using magnitude estimates, reported increased subjective contour clarity and brightness effects under these exposure conditions. The effects were larger for relative brightness differences than for contour visibility. It appears that this technique may have applications in exploring retinal contributions to other aspects of the perception of subjective contours.

Two kinds of figural condition affecting the formation of anomalous surfaces were examined in three experiments. The strengths of two factors (figural incompleteness and width of the inducing areas) were compared in order to determine: i) which of the two factors is more effective in the creation of the illusion, and ii) whether the inducing-area width is so important that it can also destroy the illusion when the inducers are clearly incomplete or ‘gappy’. The results show that the inducing-area width seems to predominate over figural incompleteness in the formation of anomalous surfaces.

Many experimental comparisons between real and anomalous contours have proven the functional equivalence of the two conditions; however, there are some contradictory findings. One of these is obtained by analyzing the anomalous contours in the light of a new illusion, called the ‘illusion of angularity’. A circle becomes a polygon when it covers the centre of a radial arrangement of black stripes, and a polygon changes its perceptual shape depending on its orientation with respect to the same radial arrangement. Phenomenally, it appears like a very pointed polygon, in which every side is concave or, alternatively, a shape that looks like a circle with angles added in the spaces between the radial stripes, or a polygonal shape in which every side is convex.

The reciprocal anomalous counterparts of these conditions, obtained by removing the geometrical/polygonal contours, reveal different results. In the first case, one sees a perfect circle; in the second case, a polygon with blunted vertices, or a circular shape with angular protrusions; in the third case, a deformed circle.

These results are inconsistent with some theoretical models proposed to explain the emergence of anomalous contours, namely, all the top-down models expressed in terms of cognitive constructions and perceptual hypotheses, or in terms of global figural organizations. Rather, these comparisons suggest a different interpretation for the two phenomena (the illusion of angularity and anomalous contours). This interpretation is based on dynamic interactions or on network computations that synthesize both real and anomalous contours.

It is recognized that a fundamental role in the perception of anomalous figures is played by the intensity and shape of brightness modifications induced by line ends. The aim of this work was to study the structure of these modifications experimentally, by using variously arranged dots as probes. It was thus assumed that dots can measure activations generated inside abrupt line ends. The results show distribution of activation which differs according to dot distance and angle with respect to the continuation of the line near its end. These data do not agree with the predictions of information processing models in the literature on anomalous figures, which are based on perceptually postulated figures accounting for unlikely gaps. However, they do agree with the dynamic model proposed here, which is based on the idea that certain figure characteristics, eg the differential brightness of anomalous figures, depend on activation distribution which in turn depends on the organization of the forces in play. This idea is rooted in Gestalt theory. Another model supported by our experimental data is Grossberg's neural dynamic approach. In this case too, the basic idea is that of activation distribution which depends on the interaction of complex neural networks functioning according to special algorithms.

Subjective contours have been of considerable interest because of their importance to theories and physiological models of form perception. In particular, they have recently been characterized as the result of magnocellular cortical processing. There is, however, a paucity of parametric data relating to basic psychophysical parameters in this field.

Two experiments are reported in which the roles of subjective contour size, retinal eccentricity, and flicker rate in subjective contour salience were investigated. Eleven observers estimated subjective contour magnitude using an Ehrenstein configuration. Configurations ranging in size from 0.25 to 3 deg were presented to three retinal loci (fovea, 2 deg, and 4 deg) at flicker rates ranging from 5 to 15 Hz. Subjective contour brightness and distinctness were measured separately. Brightness was greatest at a subjective contour size of about 1.25 deg, at flicker rates of 5 – 7 Hz, and at 3 deg peripheral for all flicker rates and all but the smallest stimulus sizes. Distinctness decreased with eccentricity and flicker, but remained high at small diameters (thus implicating spatially sensitive mechanisms). Taken together, the results support a magnocellular processing of subjective contours with respect to brightness, but also suggest that there is a parvocellular contribution to subjective contour sharpness.

A new type of illusory contour is presented whose appearance is generated by the graphic representation of groups of human figures interacting in a coordinated manner with external reality. When numerous pictorial indicators of cause-effect relationships are provided, and appropriate techniques and sufficiently ambiguous observation conditions are used, hallucinatory objects congruent with expectations linked to the meaning of the configurations appear. There is thus a high-level semantic component that is active in the formation of visual illusory contours and is even capable of interacting with other known factors: brightness contrast, the number of elements, the degree of alignment of the elements, etc.

This new type of illusory contour fits current definitions and can be experimentally modified. The variations in subjective clarity scores are presented for a study in which twenty subjects observed nineteen experimental figures, certain variables of which were manipulated. The issue is worthy of further experimental investigation.

A new type of motion-induced illusory figure determined by local kinematic information is investigated. The new figure is induced by radial line patterns subjected to either figure motion (the lines change as if they were stationary and a triangle was rotating in front of them) or background motion (the lines change as if they were being rotated behind a stationary triangle). Although the two kinds of motion are equivalent from the viewpoint of relative displacements, perceptually they yield very different results. With background motion, observers tend to perceive rigid figures that have a triangular shape. With figure motion, observers report seeing deforming figures with shapes that vary depending on the number of lines in the display. We consider two alternative accounts for this asymmetry which we term the background superiority effect (BSE). The first account proposes that the effect is due to retinal persistence and to figure stability. Against this line of explanation, we demonstrate that observers also see rigid triangular shapes in displays where both the figure and the radial lines rotate (double motion displays). The second account proposes that the effect depends on the availability of local kinematic information constraining contour orientation. This second line of explanation is consistent with observers' reports of bowed edges in double motion displays rotating in phase or in counterphase. Candidate mechanisms for extracting local kinematic information are discussed.
