International Journal of Applied Electromagnetics and Mechanics

This work compares three nonlinear solution methods for the performance of an induction motor’s magnetic equivalent circuit model with magnetic saturation. The interrelation between magnetic flux density and permeability introduces nonlinearities in the differential system of equations. Three popular nonlinear solution methods are selected for comparison, namely (i) the Gauss–Seidel method, (ii) the Newton–Raphson method and (iii) the inverse Broyden’s method. While all three methods have been applied in this context before, no comparison study has been published to the authors’ best knowledge. The study finds that the inverse Broyden’s method is most performant in terms of the number of required iterations, the computation time per iteration and the resulting total computation time. However, for substantial saturation levels, the authors recommend a hybrid implementation of multiple solution methods to obtain robust and reliable convergence.

Toroidal transformers are designed using a circular core instead of the traditional laminated rectangular core, which reduces inductance losses and increases efficiency. The primary goal of this study is to understand the cooling mechanisms involved in electrical transformers, which are critical components in power systems. Steady electromagnetic, fluid flow and temperature equations are simultaneously solved (direct method) using the finite elements method FEM of a shielded toroidal transformer. The paper focuses on creating a direct-coupled model (DCM) to understand the processes involved in electrical transformers cooling, using Magneto-AeroDynamic (MAD) models. The nonlinear models developed will be implemented and validated in this parametric study for different inlet velocities and the number of outlet. Transformers generate heat during operation, and it’s important to control the temperature to prevent overheating and ensure reliable operation.

The article discusses the impact of reactive power load on additional power losses in a high-power transformer operating at a VAr static compensation station. The presence of an almost pure capacitive load on the secondary side together with the thyristor switches is the cause of high-frequency components in the phase currents. The additional effect of electrical resonance between the transformer inductance and the load capacitance is also taken into account. The analysis is achieved using a three-dimensional finite element approach.

The accurate and time-saving prediction of essential machine variables (output power, torque, and efficiency) is crucial for manufacturers offering a wide power range of induction machines. Many motor variants are typically produced by axially scaling and rewinding the machine. Rescaling procedures of electromagnetic models of induction machines are in everyday use and well known. However, while a high accuracy can be achieved by rescaling in theory, more significant deviations between simulated and measured output parameters of the realized scaled device occur in praxis. These deviations can mainly be attributed to the faulty separation of effects in the distinct machine components, such as the rotor, stator, and bearings. This paper introduces an optimization-aided modeling approach based on the induction machine’s simple equivalent circuit representation. The method is validated by measurement data obtained from many induction machines with various axial lengths and winding configurations.

This work proposes a novel state-space model for eccentric induction motors, allowing the use of modern control theory to diagnose the eccentricity faults and to mitigate their effects. The proposed model is derived from the inductance-based multiple coupled circuit model. Instead of actual stator windings and rotor bars placed in slots, equivalent ideally distributed stator and rotor windings are considered in the motor modelling. The self and mutual inductances that incorporate the effects of static eccentricity in motors are evaluated using the modified winding function approach. Moreover, the rotor quantities are referred to the stator side to reduce the number of characteristic inductances. An eccentricity-oriented coordinate transformation is implemented to decouple the flux linkages in the new coordinate system and to reduce the system complexity further. Hereafter, stator currents and rotor fluxes are selected as system states, forming a fourth-order state-space model for the electromagnetic system of an eccentric motor. The proposed model is validated through comparisons with the reference data sourced from both the experiments and the finite element method. The potential of the proposed model for static eccentricity fault diagnosis purposes is explored.

We propose a 6-phase 12/10 switched reluctance motor (SRM) with a polygon connection. The transformation between star and polygon connections is not equivalent to that between star and delta connections of a conventional 3-phase motor. In this paper, the transformation between star and polygon connections is theoretically described. In addition, the current condition that maximizes torque is described. Finally, the torque of both connections is compared in terms of the AC-DC current ratio.

We propose a magnetic-geared motor with controllable step-out torque. The operational principle which controls the step-out torque using DC currents is described. The controllable step-out torque characteristics are computed using finite element method. In addition, the load characteristics under vector control are also computed using finite element method. Two inherent characteristics are observed in this analysis result. One is that this magnetic-geared motor can generate the torque more than the step-out torque. The other is that the phase angle difference between the rotors when both rotors step out is around 30 deg. In this paper, the mechanism of these inherent characteristics is investigated by finite element method, and these inherent characteristics are verified by carrying out measurements on a prototype.

This paper presents a parametric study of linear induction motor for design purpose. The chosen mathematical model uses a 2D formulation with magnetic vector potential A. The implementation of the model is carried out with the finite element method on the free platform Gmsh-GetDP. Circuit model is coupled to FE model so that constant voltage supply mode can be considered. This work aims to highlight the effect of the pole pair number on the characteristics and the performances of the linear induction machine through two numerical models associated to an analytical one. Furthermore, the study shows the effect of the pole pair number on the phase imbalance and the spatial harmonic spectrum of the machine. Reducing this imbalance and higher order harmonics presence will increase machine performances.

Liquid hydrogen turbopumps are used in large high-performance rockets. Stable high-speed rotation is required for rocket turbopumps. The damping mechanism of the pump must suppress vibration not only in the radial direction but also in the axial direction. However, conventional damping elements using oil or rubber cannot be used due to the cryogenic temperature of liquid hydrogen. Therefore, the application of eddy current dampers to liquid hydrogen turbopumps is focused on in this paper. Although various structures of eddy current dampers have been developed, the multi-degree-of-freedom damping characteristics of dual Halbach array type eddy current dampers for liquid hydrogen turbopumps have not yet been investigated. The variation of damping characteristics with temperature has also not yet been verified. In this paper, we propose a novel dual Halbach array type eddy current damper for liquid hydrogen turbopumps. The proposed damper can generate high damping force and can be operated maintenance-free at the cryogenic temperature. The analysis results show that the damping characteristics strongly depend on temperature and that the amplitude reduction effect is greater at low temperatures. It was also found that the proposed damper has a higher damping force density than conventional dampers.

This article proposes a design of windings for medium-frequency transformers (MFTs) at the heart of high-power Solid-State Transformers (SSTs). With aluminum interleaved foils of the correct thicknesses, it is possible to obtain low winding losses and a very low leakage inductance well adapted to high-power SSTs able to operate in the medium-voltage grid (5–20 kV). The MFT equivalent resistance and leakage inductance are determined using an analytical model based on Dowell’s hypotheses. Several interleaved winding configurations are analyzed and compared to the standard structure made of two concentric foil coils. The experimental validation is made with short-circuit tests of an MFT fed by a low-level square voltage source at several kHz, which can provide the necessary high current.

Reliable, repeatable, and flexible testing is crucial for assessing system performance and ensuring the quality of communication. In reverberation chambers (RC), real-life propagation environments can be emulated by loading absorbers, facilitating controlled testing of the system. This work presents over-the-air (OTA) testing of the LTE-A PHY layer in the RC. We assessed the performance of the LTE-A link using key performance indicators (KPIs) such as error vector magnitude (EVM), bit error rate (BER), and signal-to-noise ratio (SNR) for varying transmitter (Tx) and receiver (Rx) gains. Additionally, we have compared the results both in an empty RC and when the RC was loaded with RF absorbers. We used software-defined radio (SDR) for OTA transmission of LTE-A frames. The measurement results indicate that loading the RC with RF absorbers improves EVM, BER, and SNR. We also quantified the performance of the LTE-A link by changing the position of RF absorbers. Results showed that loading absorbers yielded up to 72.8% improvement in EVM, and placing absorbers closer to Rx helped reduce the amount of multipath, resulting in better transmission performance.

Finite element models of electrical machines allow insights in electrothermal stresses which endanger the insulation system of the machine. This paper presents a thermal finite element model of a 3.7 kW squirrel-cage induction machine. The model resolves the conductors and the surrounding insulation materials in the stator slots. A set of transient thermal scenarios is defined and measured in the machine laboratory. These data are used to assess the finite element model.

The aim of this paper is to present the fundamentals of an original method of shaft alignment for rotating machines based on the principle of wireless power transfer (WPT) process. WPT alignment of shafts in rotating machinery is simple and more accurate than existing methods (conventional mechanical methods or Laser-optical method) and can result in reduced power consumption and minimized mean time between failures. Shaft alignment is an important factor in the proper functioning and longevity of machinery. Proper shaft alignment ensures that the rotating shafts of a machine are in a straight line and rotate on the same axis. This contributes to reducing the wear and tear on the bearings and other components of the machine, leading to improved reliability and longer service life. A high precision WPT alignment system has been designed with the primary coil placed in the driver machine, as an electrical motor, and the secondary coil placed in the driven machine, as a pump. The calculation of the magnetic interactions between both coils (primary and secondary coils), in particular the mutual inductance and coupling coefficient, perfectly explains deviations in the shaft (angular misalignment and parallel offset) and aligns entirely with measurement results, with a difference of approximately 4%. This new alignment method with magnetic interactions has proven effective in designing and implementing actual shaft alignment. WPT alignment offers precise shaft alignment tools for proper alignment of shafts and reduces troubleshooting issues.

This paper proposes a method to reduce torque ripple in axial gap motors by multi objective optimization of permanent magnets (PMs) shape using genetic algorithm (GA). Torque ripple is a problem because it causes vibration and noise. Conventionally, torque ripple has been reduced by quantitatively designing the PMs in the shape of multiplicative wave. However, it is difficult to optimize the objective function only by quantitative evaluation through sensitivity analysis. Therefore, in this study, the functions constituting the PMs interface shape are expressed as a Fourier-based series. The PMs is optimized by optimizing combination of their coefficients with GA. As a result, the proposed model is almost equal to the average torque of the basic model and the torque ripple is significantly reduced. Furthermore, fillets are applied and the effect on each characteristic is verified.

In this article, a magnetic shield for automotive Wireless Power Transfer (WPT) systems is proposed. Its innovative feature consists in the positioning of the shield, that is part of the Ground Assembly (GA) of the WPT system. Passive coils, assembled in an array-like structure to build the shields properly located near the transmitting coils are investigated. Currently, there are a variety of shielding methods, each of them with its peculiar feature. The proposed method is simple and does not increase the transmitting and the receiving coil sizes, a constraint that is often critical from a practical and an economical point of view. The main characteristic of the proposed shielding method is the location of the shielding coils on the same level as the GA. The results here presented are validated by Finite Element (FE) based simulations and are referred to an experimental prototype of wireless charging systems for electric vehicles operating at 85 kHz with a transmitted nominal power of 3.3 kW. The results show that the proposed shield reduces the leakage magnetic flux density in the system up to 37% with a marginal impact on the transmission efficiency, complying the SAE J2954 international standard.

A multiple-input and multiple-output planar actuator is proposed, which utilizes mechanically driven stator magnet arrays to levitate a permanent magnet mover. A state of levitation and actuation is obtained by mechanically altering the orientation of the stator magnets to control the forces and torques on the mover. A challenge for the design and control of the actuator is inverting the relationship between the force and stator magnet rotation angles, as there is no closed-form analytical solution. In this study, a feed-forward neural network is applied to model the forward relation between stator magnet angle input and a force and torque output to reduce the forward computation time for the design process and for error estimation in real-time applications. Additionally, the neural network is considered for inverting the solution for a motion profile sampled at 1000 Hz. The developed forward model is able to calculate the forces and torques on the mover a factor 10 faster than the equivalent charge or Fourier model with an absolute error of 3 mN and 0.1 mNm for the forces and torques, respectively, and a feed-forward neural network is able to accurately learn an inverse solution for small motion profiles.

This paper aims to improve the efficiency, affordability, and safety of Wireless Power Transfer (WPT) devices. While wireless inductive charging is common in devices like smartphones, charging electric vehicles presents significant challenges due to high frequency electromagnetic fields that can be dangerous for users and those nearby. Current systems are expensive due to the use of specialized materials and components. By developing WPT systems with drastically reduced frequency levels, this research has the potential to significantly impact the widespread adoption of affordable, safe, and efficient WPT devices for high-power applications like electric vehicle charging. In fact, using lower frequencies allows us to build WPT systems with far less expensive materials, e.g. no need of Litz wires and ferrites that can be replaced by single core copper wires and classical magnetic steels. The effectiveness of the method is demonstrated through simulation using MATLAB Simulink^® and experimental tests. The results indicate that it is possible to maintain good performance, reduce limitations and costs, and improve user acceptance of WPT systems by considerably lowering the frequency of electromagnetic fields that are classically used in such systems.

The paper presents the results of research on the spatial distribution of the multi-phase, distributed windings in electric machines. The focus was on the analysis of the harmonics of the current linkage spatial distributions. To perform calculations for different windings patterns, taking into account the number of phases, pole pairs, and the number q of slots per pole and phase, the dedicated code was developed in the Matlab environment. Nine different multi-phase windings were studied, for which magnetomotive force (MMF) was determined to investigate the harmonic content and total harmonic distortion. The obtained results were compared with a reference three-phase symmetric system. Studies were also carried out on torque ripple and power density for different numbers of winding phases.

This paper deals with the design and test of a contactless capacitive power converter operating at a frequency of 1 MHz, intended to supply the excitation winding of an 80 kW wound rotor synchronous machine. The methodology integrates the electromagnetic design of the rotor and its impact on the different parameters of the converter. To verify the validity of the concept, a first prototype was built by using surface-mounted capacitors grounded on the structure of a 1 MHz Class E resonant power converter. Then, a more representative capacitive contactless coupler was designed and implemented. Comparisons between simulation and experimental results have shown the limits of the proposed contactless power transmission. Special attention was paid on losses and efficiency which are crucial for this application.

In this work, a 3D analytical magnetic model based on hybridation of the sub-domain’s method and the image’s theory to compute magnetic field and translational motion eddy current in the conducting plate of the Halbach permanent magnet induction heater planar topology is developed. The main objective is to remedy the problem of the transverse edge effect, and hence improving the efficiency of analytical model and the accuracy of results. The developed model also allows fast and precise simulations of 3D magnetic phenomena, and presents an important reduction in computation time compared to 3D finite element simulations.

The design of industrial rectifier transformers for use in the field of aluminum production requires the evaluation of the effects of current harmonics in the waveforms, in terms of electromagnetic fields interacting with the transformer’s constituent materials. The waveforms of the currents flowing through the windings and high-current output connections of transformers are highly distorted waveforms due to a high presence of harmonics that contribute significantly to the overall losses developed within the system causing overstress of the insulation materials. The evaluation of the electromagnetic effects of these harmonics cannot be approached by means of a time-harmonic steady-state study of the problem, but a time transient must be simulated for a more accurate evaluation.

Electrical machines that can run at high speeds are more and more studied as they can respond to the increasing need of power onboard of aircrafts. However, to allow high-speed operability mechanical handling of the rotating parts need to be insured. In this paper an analytic design process of a novel high-speed induction machine is presented. The analytical magnetic and mechanical models developed are presented and validated with finite element simulations. The magnetic model is based on a classic equivalent electrical diagram of induction machine with a specific adaptation for the rotor leakage inductance as the squirrel cage is buried. The mechanical model is based on a field displacement approach leading to the stress tensor in all the rotating part. A four degrees of freedom vibration analysis model considering gyroscopic effects based on Euler–Lagrange equation allows to identify the critical speeds of the system. It is shown that some geometrical parameters will have opposed effects on the two physics. Thus, an optimization-based coupling between the different physics allows to design rapidly the desired machine regarding any technical specifications as analytical models are being used.
